Crestron SAROS ICS8T User manual

Saros®8” Subwoofer In-Ceiling Speakers
quickstart guide
SAROS_ICS8T
www.crestron.com
888.273.7876 201.767.3400
Specifications subject to
change without notice.
SAROS_ICS8T
Set the Transformer Tap Selector Switch
The speakers are equipped with a 70/100 V matching transformer for distributed audio
systems. The transformer tap selector switch on the front panel is used to set the speaker
power level. Use a flat blade screwdriver to adjust the switch.
1. For SAROS_ICS8T 70 V systems, use the left side settings and select from 3.75, 7.5,
15, 30, or 60 watts.
2. For SAROS_ICS8T 100 V systems, use the right side settings and select from 7.5,
15, 30, or 60 watts. The Xposition should not be used.
The switch may also be set to 8Ω operation, bypassing the transformer completely. This
setting should be used only for 8 Ω audio systems.
QUICKSTART DOC. 7494A (2037421) 11.13
1
1Installation
Saros®speakers by Crestron®deliver professional grade performance
and flexible installation in a range of popular sizes for demanding
commercial applications. Solid construction, easy installation, and
high end components are hallmarks of the complete Saros speaker
line.
Ideal for use in background or foreground music, paging, and sound
reinforcement systems, Saros speakers are engineered to achieve
smooth, even coverage, high output, and clear, natural sound quality.
The SAROS_ICS8T model is an 8 inch in-ceiling subwoofer designed
to extend the low frequency response of Crestron’s full range Saros
speakers. It is intended for use with Crestron’s AMP-series
Commercial Power Amplifiers which can provide low impedance or
70/100 V distributed power to the Saros speaker line. Because of the
internal crossover, no biamping is required.
SAROS_ICS8T subwoofers are available in white or black and may
be painted to blend with the ceiling surface.
Prepare Mounting Hole
Before finalizing the speaker location, check to make sure there are no fixtures, pipes, air ducts, joists,
or other possible obstructions. If applicable, use a good quality stud finder to locate joists. If there are
no obstructions, use the supplied template to trace an outline of the mounting hole.
For drop tile ceilings, remove the ceiling tile and place on a flat surface to trace the mounting hole. For
drywall or standard construction ceilings, use the template to trace the mounting hole directly on the
ceiling.
Install Cable
Run the cable from the audio source to the speaker location, observing all appropriate local codes.
Strip the ends of the speaker cables approximately 1/8” to 3/16” (~3 mm to ~5 mm) and, if the cable is
stranded, twist the strands.
Install Tile Bridge
The included tile bridge components provide proper support when the speaker is installed in a typical
drop tile ceiling. Refer to the illustration below.
1. Based on the location of the mounting hole determined in “Prepare Mounting Hole” above, use the
two supplied screws to attach the support ring to the rails so that when installed, the ring is
aligned with the mounting hole and the rails rest on the ceiling grid frame.
2. Adjust the support ring position as necessary to enable off-center speaker positioning. The tile
bridge assembly can be folded to fit through the speaker cutout in blind-mount situations.
Mount/Remove Speaker
The in-ceiling speaker includes four toggle clamps that simplify the mounting process. If the grille is
mounted on the speaker, remove it before proceeding. (Refer to “Install/Remove Grille” above.)
1. Referring to the illustrations to the right, remove the screw securing the rear cover panel, and lift
the cover panel off to expose the supplied terminal block.
2. Route the speaker cable through the cover cable clamp and connect the wires to the terminal
block, using the outer IN terminals: red to +and black to –. Use the inner +and – THRU terminals
to connect a pass-through (parallel) speaker.
3. Allow some slack in the speaker cable(s) and position the cover panel on the back, making certain
it engages the mounting clips. Secure the cover panel using the screw removed in step 1 and
tighten the cable clamp to secure the cable(s). Do not overtighten. Use a safety tether attached to
the rear enclosure to prevent the speaker from accidentally falling.
4. The toggle clamps offer two positions to accommodate both standard and extra thick surfaces up
to 2.4 inches (61 mm). For extra thick tiles, reset the toggle clamps to the upper position before
continuing.
a. With the toggle clamps turned inward, insert the speaker into the opening.
b. Hold the speaker against the ceiling and begin tightening the four screws on the front of the
speaker. The toggle clamps first rotate into clamping position (as indicated in the front view
illustration to the right) and then begin holding the speaker to the ceiling.
c. Tighten the screws until the speaker is secure. Do not overtighten.
5. Speaker removal is accomplished by reversing steps 1 through 4 above.
Tile Bridge Assembly
Install/Remove Grille
The zero-bezel frameless grille is held in place by powerful magnets. A safety tether is included to
prevent any possibility of the grille falling from the ceiling. With the tether attached, place the grille in
position on the speaker. To remove the grille, grip the edges and pull away from the speaker.
Paint the Speaker Grille
Speaker grille painting should be done prior to mounting.
1. Carefully remove the material on the underside of the grille and set it aside for reinstallation. It
may be necessary to use a knife or other sharp instrument to free an edge of the material so it
can be peeled away. Use care to avoid cutting or tearing the material.
2. Dry brush or lightly spray the surface to be painted. Use care to avoid clogging the holes in the
grille.
100V
70V
20.91 in
(531 mm)
Support
Ring
Screws
(Supplied)
25.92 in
(659 mm)
Front View (Grille Removed)
Tighten
Screws
70V 100V
IN
THRU
Terminal Block
Not Shown
Screw
Cable
Clamp
Speaker
Cable
Terminal
Block
Mounting
Clips
Rear
Cover
Panel
Safety Tether
Rigging Points
Speaker Cable Connections

QUICKSTART DOC. 7494A (2037421) 11.13
Saros®8” Subwoofer In-Ceiling Speakers
quickstart guide
SAROS_ICS8T
www.crestron.com
888.273.7876 201.767.3400
Specifications subject to
change without notice.
SAROS_ICS8T
The specific patents that cover crestron products are listed at patents.crestron.com.
Crestron, the Crestron logo, and Saros are either trademarks or registered trademarks of Crestron
Electronics, Inc., in the United States and/or other countries. Other trademarks, registered
trademarks, and trade names may be used in this document to refer to either the entities claiming
the marks and names or their products. Crestron disclaims any proprietary interest in the marks
and names of others. Crestron is not responsible for errors in typography or photography.
This document was writtren by the Technical Publications department at Crestron.
©2013 Crestron Electronics, Inc.
3Specifications
2
SAROS_ICS8T Specifications
Specification The following table provides corrective action for possible trouble situations. If
further assistance is required, please contact a Crestron customer service
representative.
Further Inquiries
To locate specific information or resolve questions after reviewing this guide,
contact Crestron's True Blue Support at 1-888-CRESTRON [1-888-273-7876] or,
for assistance within a particular geographic region, refer to the listing of Crestron
worldwide offices at www.crestron.com/offices.
To post a question about Crestron products, log onto Crestron’s Online Help at
www.crestron.com/onlinehelp. First-time users must establish a user account to
fully benefit from all available features.
Future Updates
As Crestron improves functions, adds new features, and extends the capabilities
of the SAROS_ICS8T, additional information may be made available as manual
updates. These updates are solely electronic and serve as intermediary
supplements prior to the release of a complete technical documentation revision.
Check the Crestron website periodically for manual update availability and its
relevance. Updates are identified as an “Addendum” in the Download column.
TROUBLE POSSIBLE CAUSE(S)
CORRECTIVE ACTION
No sound or
intermittent
sound is
coming from
the speaker.
There is a cable
connection error.
Verify the cable connections
between the amplifier and
speaker.
The amplifier is not
receiving an input signal
or there is a malfunction.
Verify that the amplifier is
functioning correctly, that it is
receiving an input signal, and
that the correct input source
is selected.
There is a faulty device
in the system.
Verify that all system devices
are functioning properly.
Constant noise
such as buzz,
hum, or hiss is
coming from
the speaker.
There is a system
grounding fault.
Verify that system grounding is
correct.
Low
frequency
output is poor.
There is an incorrect
polarity connection at
the speaker or amplifier.
Verify speaker connection
polarity (+on amplifier to +on
speaker).
4Problem Solving
Troubleshooting
2Physical Views
Construction
Enclosure Zinc-plated steel, plenum-rated, 1/2 in or 3/4 in conduit knockout top and side
Baffle ABS UL94V-0 plastic
Grille Steel with textured finish, paintable, magnetically-held zero-bezel frameless,
safety tether
Mounting Flush ceiling mount using four integral 2-step toggle clamps, 2.4 in (61 mm) maximum
surface thickness, tile bridge included; (2) Rigging points for safety tether,
(SPKA-ST-15, sold separately)
Dimensions
Diameter 12.07 in (307 mm) not including toggles
Depth 9.10 in (231 mm)
Recommended cutout
diameter 11.20 in (285 mm)
Minimum mounting
depth 8.90 in (226 mm)
Weight 14.0 lb (6.4 kg)
Connection (1) 4-pin 5 mm detachable terminal block with screw-down flanges;
Speaker input with parallel pass-through;
Maximum wire size: 12 AWG
Controls
Transformer Tap (1) Recessed 5-position screwdriver-adjustable rotary switch on baffle;
Used to select 70/100 V tap settings or 8Ω (bypass)
Environmental
Temperature -2° to 120° F (-19° to 49° C)
Humidity 5% to 95% RH (non-condensing)
8.0 in (203 mm) polypropylene with rubber surround, steel basket, and phase plug
8 Ω nominal with transformer set to 8Ω
3.75, 7.5,15, 30, 60 watts at 70 V; 7.5, 15, 30, 60 watts at 100 V
125 Hz, 2nd order
45 Hz to 125 Hz (±3 dB)
35 Hz to 125 Hz (-10 dB)
100 watts program (8 Ω)
90 dB @ (1W/1m)
Woofer
Impedance
Transformer Taps
Low-Pass Filter
Frequency Response
Frequency Range
Power Handling
Sensitivity
Rear and Side Views
IN
THRU
Recommended
Cutout Diameter
Diameter
Minimum
Mounting Depth
Front View (Grille Removed)
Details
