Crestron Sonnex SWAMP-24X8 User manual

Crestron SWAMP(I)-24X8
Sonnex®Multiroom Audio System
Operations Guide

Important Safety Instructions
•Read these instructions.
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water.
•Clean only with dry cloth.
•Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
•Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
•Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding-type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
•Only use attachments/accessories specified by the
manufacturer.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPARATUS TO RAIN OR
MOISTURE. THE APPARATUS SHALL NOT BE EXPOSED
TO DRIPPING OR SPLASHING. OBJECTS FILLED WITH
LIQUIDS, SUCH AS VASES, SHOULD NOT BE PLACED
ON THE APPARATUS.
WARNING:
TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE
COVER. THERE ARE NO USER SERVICEABLE PARTS
INSIDE. ONLY QUALIFIED SERVICE PERSONNEL
SHOULD PERFORM SERVICE.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product's enclosure t hat may be of sufficient magnitude
to constitute a risk of electric shock to persons.
•Use only with the cart, stand, tripod, bracket or
table specified by the manufacturer or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING:
THIS IS AN APPARATUS WITH CLASS I
CONSTRUCTION. IT SHALL BE CONNECTED TO AN
ELECTRICAL OUTLET WITH AN EARTHING GROUND
TERMINAL.
IMPORTANT:
These devices can be used with Class 2 output wiring.
•Unplug this apparatus during lightning storms or when
unused for long periods of time.
•Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
•Disconnect power prior to connecting or disconnecting
equipment.
•Do not install in direct sunlight.
•
The apparatus must be installed in a way that the power cord
can be removed either from the wall outlet or from the
device itself in order to disconnect the mains power.
•Prevent foreign objects from entering the device.

The specific patents that cover Crestron products are listed at patents.crestron.com.
Crestron, the Crestron logo, ADMS Intermedia Delivery System, AIR, Aspire, Cresnet, Crestron Home, Crestron Studio, Crestron Toolbox, Essence,
Excite, Fusion RV, Saros, Sonnex, Sonnex Speaker Protect, and SSP are either trademarks or registered trademarks of Crestron Electronics, Inc. in the
United States and/or other countries. iPod is either a trademark or registered trademark of Apple Computer, Inc., in the United States and/or other
countries. Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities claiming the marks and
names or their products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for errors in
typography or photography.
This document was written by the Technical Publications department at Crestron.
©2014 Crestron Electronics, Inc.
Regulatory Compliance
These products conform to UL 60065; certified to CSA C22.2 No. 60065.03.
As of the date of manufacture, the SWAMP-24X8 and SWAMPI-24X8 have been tested and found to
comply with specifications for CE marking.
Federal Communications Commission (FCC) Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions:
(1) This device may not cause harmful interference and (2) this device must accept any interference received,
including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna
•Increase the separation between the equipment and receiver
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
•Consult the dealer or an experienced radio/TV technician for help
Industry Canada (IC) Compliance Statement
CAN ICES-3(B)/NMB-3(B)

Crestron SWAMP(I)-24X8 Sonnex Multiroom Audio System
Operations Guide – DOC. 7049E Contents •i
Contents
Sonnex Multiroom Audio System: SWAMP(I)-24X8 1
Introduction ...............................................................................................................................1
Features and Functions................................................................................................1
Applications.................................................................................................................7
Specifications ..............................................................................................................8
Physical Description.................................................................................................. 11
Setup ........................................................................................................................................ 17
Network Wiring......................................................................................................... 17
Sonnex Link Wiring .................................................................................................. 17
Identity Code ............................................................................................................. 17
Installation ................................................................................................................. 18
Hardware Hookup ..................................................................................................... 20
Configuration........................................................................................................................... 26
Source Setup.............................................................................................................. 26
Zone Setup................................................................................................................. 27
Expander Status......................................................................................................... 35
Amplifier Status ........................................................................................................ 36
Network Setup........................................................................................................... 36
Control Setup............................................................................................................. 39
About......................................................................................................................... 40
Uploading and Upgrading........................................................................................................ 41
Establishing Communication..................................................................................... 41
Programs and Firmware ............................................................................................ 42
Program Checks ........................................................................................................ 43
Operation ................................................................................................................................. 44
Power......................................................................................................................... 44
Operating Modes ....................................................................................................... 44
Volume Control......................................................................................................... 45
Problem Solving ...................................................................................................................... 46
Troubleshooting......................................................................................................... 46
Check Network Wiring.............................................................................................. 46
Reference Documents................................................................................................ 47
Further Inquiries ........................................................................................................ 47
Future Updates .......................................................................................................... 47
Return and Warranty Policies.................................................................................................. 49
Merchandise Returns / Repair Service ...................................................................... 49
Crestron Limited Warranty........................................................................................ 49

Crestron SWAMP(I)-24X8 Sonnex Multiroom Audio System
Operations Guide – DOC. 7049E Sonnex Multiroom Audio System: SWAMP(I)-24X8 •1
•Advanced multiroom audio distribution for homes and businesses
•Robust, high-efficiency audiophile grade amplification built in
•140 watts/channel @ 8 ohms , 400 watts/channel bridged
•Provides eight amplified stereo zone outputs
•Provides two additional S/PDIF stereo zone outputs
Sonnex Multiroom Audio System:
SWAMP(I)-24X8
Introduction
The SWAMP-24X8 is the centerpiece of a fully scalable audio distribution system
that delivers high-output audiophile sound quality to every room with significantly
reduced cabling, low power consumption, advanced DSP, and integrator-friendly
setup. The Sonnex®Multiroom Audio System takes audio distribution to a higher
level, facilitating massive systems with up to 74 zones and over 30,000 watts of
power.
Employing a unique system topology, Sonnex minimizes speaker wiring distances by
allowing expansion units to be placed central to the rooms they serve. Twenty-four
stereo channels of uncompressed digital audio and control are routed to each
expander over a single inexpensive shielded CAT5e cable.* Gone is all the clutter of
amplifier interconnects and input loop-thru cables, integrating eight zones of high-
performance power amplification and signal processing, plus input switching for a
generous 24 analog and digital sources, all in one compact 4-space rack-mountable
package.
The SWAMP-24X8 and SWAMPI-24X8 are functionally identical. For simplicity
within this guide, the term “SWAMP-24X8” is used except where noted.
Features and Functions
(Continued on following page)
* For connection of the Sonnex Link between the SWAMP-24X8 and each expander, use Crestron®
DM-CBL-8G or high-quality CAT5e shielded twisted-pair cable. The maximum cable length using
DM-CBL-8G or CAT5e is 200 ft (61 m) per run. For longer distances, use the S-EXT1-S Sonnex
Link over Fiber Extender (sold separately).

Sonnex Multiroom Audio System Crestron SWAMP(I)-24X8
2•Sonnex Multiroom Audio System: SWAMP(I)-24X8 Operations Guide – DOC. 7049E
•Additional line-level, S/PDIF, and “CH” CAT5 balanced outputs
available1
•70/100 Volt “constant-voltage” output options available
•Output bussing enables linked operation of multiple adjacent zones
•Bridgeable outputs provide extra power for pools and other large areas
•Sonnex Link provides a 1-wire, plug-and-play interface to eight
SWAMPE expanders up to 200 feet (61 meters) away2,3
•Sonnex Link over Fiber Extender S-EXT1-S (sold separately) enables
distances up to 2000 feet (610 meters)
•Includes 12 unbalanced, 4 balanced/unbalanced, and 8 S/PDIF inputs
•Supports direct audio connection of the CEN-IDOCV Docking
Interface (sold separately) and other “CH” CAT5 sources4
•Allows audio return channel capability and extension of line-level and
S/PDIF signals using AUD-EXT Audio Extenders
•User adjustable volume, bass, treble, loudness, and selectable tone
profiles
•Installer adjustable 5-band graphic or parametric EQ per zone
•Dynamic Range Control maintains even listening levels in both quiet
and loud ambient environments
•Speaker Profiles allow upload of custom preset speaker settings
•Sonnex Speaker Protect®output limiting affords extra headroom while
preventing component damage
•Individual zone power control and global standby
•Setup and adjustment via front panel or Sonnex Tools software
•Remote fault monitoring
•Seamless Crestron®system integration
•Heavy duty detachable terminal blocks ease speaker wire termination
•Low power consumption, cool-running operation
•4-space 19” rack-mountable
Features and Functions
(Continued)
1. Additional S/PDIF and analog line outputs may be added using the SWE-8 Sonnex Multiroom Audio
Unamplified Expander (sold separately).
2. For connection of the Sonnex Link between the SWAMP-24X8 and each expander, use Crestron
DM-CBL-8G or high-quality CAT5e shielded twisted-pair cable. The maximum cable length using
DM-CBL-8G or CAT5e is 200 ft (61 m) per run. For longer distances, use the S-EXT1-S Sonnex
Link over Fiber Extender (sold separately).
3. If using Cresnet®as the control system interface, system expansion is limited to one expander.
Support for more than one expander requires Ethernet as the control system interface.
4. CH (Crestron Home®) CAT5 balanced audio is supported using balanced inputs 13 – 16. All other
inputs require an ABAR-1 CAT5 Balanced Audio Receiver.

Crestron SWAMP(I)-24X8 Sonnex Multiroom Audio System
Operations Guide – DOC. 7049E Sonnex Multiroom Audio System: SWAMP(I)-24X8 •3
Integrated Audiophile Amplifier
The amplifiers in the SWAMP-24X8 use a custom hybrid amplifier design that
achieves the warmth and neutrality of a fine Class AB amplifier with all of the
efficiency benefits of modern Class D.
Each of the SWAMP-24X8’s 16 channels (configured as eight stereo zones) delivers
140 watts into 8 ohms, or 240 watts into 4 ohms. For large, noisy areas around the
pool or patio, or in a game room or gym, any two adjacent outputs can be bridged
(Zone 1 + Zone 2, Zone 3 + Zone 4, Zone 5 + Zone 6, Zone 7 + Zone 8) to produce
400 watts per channel at 8 ohms. The SWAMP-24X8 uses only four rack spaces
while maintaining effective cooling with no need for extra clearance above or below.
Each zone is individually controllable, saving further energy by turning off any
unused channels.
24x8 Matrix Switcher
Designed with flexibility and expansion in mind, the Sonnex Multiroom Audio
System provides numerous inputs to manage a multitude of stereo audio sources,
both analog and digital.
•A total of 24 discrete inputs are spread across an array of connectors,
including unbalanced RCA, balanced terminal blocks, and S/PDIF coaxial.
Sonnex easily handles the multizone outputs from a Crestron ADMS
Intermedia Delivery System™ or TunerRack Modular Multi-Tuner
(CEN-TRACK), plus digital television receivers and other devices.
•Audio return channels are easily added using Crestron AUD-EXT Audio
Extenders to receive signals from remote AV receivers located up to 2000
feet (610 m) away.
•Sonnex even accepts a direct input from the CEN-IDOCV Interface for
iPod®and other Crestron Home®CAT5 Balanced sources without requiring
a separate converter. 1
For ease of use, descriptive names for every source input and zone output can be
displayed on the front panel LCD and pushbuttons. Via the front panel controls, or
from a Crestron touch screen or remote, any input can be selected for listening in any
zone or group. Additional features include mono summing for distribution to non-
stereo zones, scaling factor settings for defining minimum and maximum volume
levels, source signal detection, and source gain compensation to assure a consistent
level when switching between disparate sources.
Bonus Zones
In addition to its eight amplified zone outputs, the SWAMP-24X8 provides two
additional S/PDIF digital outputs for sharing stereo sources with centralized audio
processors and AV receivers.2These outputs can even be extended to feed remote
AV receivers anywhere in the house using AUD-EXT Audio Extenders.
1. CH (Crestron Home) CAT5 balanced audio is supported using balanced inputs 13 – 16. All other
inputs require an ABAR-1 CAT5 Balanced Audio Receiver.
2. Additional S/PDIF and analog line outputs may be added using the SWE-8 Sonnex Multiroom Audio
Unamplified Expander (sold separately).

Sonnex Multiroom Audio System Crestron SWAMP(I)-24X8
4•Sonnex Multiroom Audio System: SWAMP(I)-24X8 Operations Guide – DOC. 7049E
Sonnex Digital Audio Transport
Among the many features that set Sonnex apart from all other multiroom systems is
the Sonnex Audio Transport. On the rear of the SWAMP-24X8 are eight Sonnex
Link ports, enabling the connection of up to eight Sonnex Multiroom Audio
Expanders (SWAMPE-4 or SWAMPE-8).1Each link transports professional-quality
24-bit, 48 kHz digital audio from all 24 inputs simultaneously to each expander,
supporting wiring distances up to 200 feet (61 meters) over a single CAT5e shielded
twisted-pair (STP) cable.2
While the expanders can be installed centrally with the SWAMP-24X8, the ease of
running just one tiny wire instead of 16 heavy speaker cables clearly affords a much
better decentralized system approach. Installing each expander local to the rooms it
serves, whether on a different floor, another wing, or a completely separate building,
significantly reduces the amount of speaker wiring needed to install. The benefits of
reducing speaker wiring include faster, easier, and less expensive installation, as well
as overall higher performance and efficiency by minimizing the signal loss inherent
in long speaker runs.
Plug and Play Expansion
Control for each expander is also embedded in the Sonnex Link, dramatically
simplifying installation and setup through a true 1-wire interface. There is no need to
set addresses or write any special programming. Simply connect each expander to
the SWAMP-24X8 and instantly control the complete system from the
SWAMP-24X8’s front panel or Sonnex Tools software.
Advanced DSP
To truly deliver an ultimate listening experience in every room, Sonnex includes
built-in digital signal processing, providing a virtual arsenal of controls and
adjustments, intelligently deployed to streamline both the installer setup procedure
and day-to-day user operation. Key setup functions are accessible via the front panel,
while more advanced settings are provided via Sonnex Tools software. Naturally, the
essential user controls can be made available on any Crestron touch screen, keypad,
handheld remote, or mobile device as part of a complete Crestron system.
The following features are included in Sonnex DSP:
•User Controls allow a Crestron touch screen or other user interface to
provide the essential controls for day-to-day listening. Controls include
room volume, bass, treble, balance, loudness, mute, zone on/off, and five
selectable tone profiles. Through the control system program, many
advanced user functions are possible including priority modes (who can
control which sources), zone grouping (source sharing), paging,
do-not-disturb, alarm clock, sleep timer, and much more.
•Tone Profiles allow users to select from five preset EQ curves including
Classical, Jazz, Pop, Rock, or Spoken Word, each tailored for a different
type of material or listening preference.
1. If using Cresnet as the control system interface, system expansion is limited to one expander. Support
for more than one expander requires Ethernet as the control system interface.
2. For connection of the Sonnex Link between the SWAMP-24X8 and each expander, use Crestron
DM-CBL-8G or high-quality CAT5e shielded twisted-pair cable. The maximum cable length using
DM-CBL-8G or CAT5e is 200 ft (61 m) per run. For longer distances, use the S-EXT1-S Sonnex
Link over Fiber Extender.

Crestron SWAMP(I)-24X8 Sonnex Multiroom Audio System
Operations Guide – DOC. 7049E Sonnex Multiroom Audio System: SWAMP(I)-24X8 •5
•Dynamic Range Control (DRC) is a user-selectable feature to help keep
everything at a consistent level, whether in a quiet bedroom, a loud
swimming pool, or an outdoor patio, facilitating a more cohesive listening
experience.
•Sonnex Speaker Protect®(SSP) output limiting assures maximum headroom
while preventing damage to the amplifier or speakers. SSP®output limiting
lets the installer set the protection to match the speakers’ power handling
capability, achieving a transparent effect right up to the limits of the speaker
device.
CAUTION: As speaker ratings vary greatly across manufacturers, there is
no guarantee that SSP protects against speaker damage in all situations.
•5-Band Equalizer provides the choice of graphic or parametric 5-band EQ.
Using Sonnex Tools software and a wireless laptop, the installer can easily
move from room to room, sculpting the sound for optimal audio clarity and
impact.
Speaker Profiles
The Speaker Profiles feature in Sonnex Tools alleviates many repetitive adjustments
from room-to-room, and project-to-project, by allowing installers to save a complete
set of EQ and SSP settings for each type of speaker, room, and customer. Tuning a
complete project can be as simple as loading the appropriate Speaker Profile for each
zone, effectively pre-tuning the whole system before a single note of music or test
signal is even played.
Output Bussing
The spacious, open floor plans typical of today’s homes and businesses commonly
present multiple adjacent listening zones with no sonic boundary between them such
as a kitchen and dinette, a living room and dining room, or an outdoor pool and
terrace. One click in Sonnex Tools instantly busses adjacent zones together to
function as one group while preserving the individual speaker profile settings.
Volume offset adjustments easily allow for balancing the levels of each bussed zone
for smooth, even coverage of the complete space.
Passive Subwoofer Support
Sonnex provides extended low frequency performance in any room, providing high-
performance biamplification capability to support a passive in-wall, in-floor, or
freestanding subwoofer. Configuring Sonnex to handle a 2.1 speaker system is both
simple and powerful, offering the choice of 2nd or 4th order active crossover filters for
each sub and satellite output, plus up to four parametric EQ filters for room
correction and tonal enhancement. With 400 watts available in bridged mode, there
is plenty of power on hand to fill any room with deep, gratifying bass.*
Active (powered) subwoofers are supported using the SWE-8 Sonnex Multiroom
Audio Unamplified Expander (sold separately).
* Passive subwoofer support requires one zone output to drive the main left and right (i.e., satellite)
speakers, plus one additional zone output to drive a subwoofer with 140 watts @ 8 ohms, or two
additional zone outputs bridged to drive a subwoofer with 400 watts @ 8 ohms.

Sonnex Multiroom Audio System Crestron SWAMP(I)-24X8
6•Sonnex Multiroom Audio System: SWAMP(I)-24X8 Operations Guide – DOC. 7049E
Unamplified Outputs
For applications requiring line level zone outputs, Crestron offers the SWE-8 Sonnex
Multiroom Audio Unamplified Expander (sold separately). Each SWE-8 provides an
assortment of analog line level, S/PDIF digital, and Crestron Home (CH) CAT5
balanced audio outputs, offering a solution for routing audio to AV receivers,
powered subwoofers, headphone amplifiers, phone systems (for music-on-hold), and
other audio equipment.
70/100 V Option
Any amplified zone output can be converted to 70- or 100-volt output using one or
more Sonnex Output Transformers (SAT-70V/100V-2 or SAT-70V/100V-4, sold
separately). A 70/100 V (constant-voltage) speaker system allows for the connection
of numerous speakers per circuit and long wire runs using small-gauge wire. Typical
applications include outdoor speaker zones, commercial retail spaces, hallways, and
common areas.
Intelligent Monitoring and Protection
To help ensure the most seamless user experience and long-lived operation, Sonnex
includes several ways to keep tabs on its operating status and health. On its own,
Sonnex possesses the intelligence to protect itself from many types of faults
including over temperature, over current, over voltage, under voltage, and dc offset
on any channel. In the event of a fault, the front panel LCD provides clear fault
indication to speed the troubleshooting of incorrect wiring, poor rack ventilation, and
other unforeseen issues. Fault alerts may also be sent to a system touch screen or
mobile device, and integrators can even monitor and track the data remotely through
Crestron’s Fusion RV®software to ensure a rapid service response.
Ultimate Integration
Without question, Sonnex delivers unprecedented intelligence from source to
speaker. Via Cresnet®* or high-speed Ethernet, Sonnex affords incredible integration
potential as part of a complete Crestron system, enabling seamless control of every
room and source through a wide selection of touch screens, keypads, wireless
remotes, computers, and mobile devices. Complete setup is afforded via USB or
Ethernet, using Sonnex Tools software, part of the Crestron Toolbox™ installer
toolkit.
* If using Cresnet as the control system interface, system expansion is limited to one expander. Support
for more than one expander requires Ethernet as the control system interface.

Crestron SWAMP(I)-24X8 Sonnex Multiroom Audio System
Operations Guide – DOC. 7049E Sonnex Multiroom Audio System: SWAMP(I)-24X8 •7
Applications
The following diagram shows a SWAMP-24X8 in a multizone application.
SWAMP-24X8 in a Multizone Application

Sonnex Multiroom Audio System Crestron SWAMP(I)-24X8
8•Sonnex Multiroom Audio System: SWAMP(I)-24X8 Operations Guide – DOC. 7049E
Specifications
Specifications for the SWAMP(I)-24X8 are listed in the following table.
SWAMP(I)-24X8 Specifications
SPECIFICATION DETAILS
Audio
Features 24 x 10 stereo matrix switcher, 8-channel
stereo DSP, 8-channel stereo power
amplifier, Sonnex Digital Audio Transport,
speaker profiles, Sonnex Speaker Protect,
5-band graphic or parametric EQ, Dynamic
Range Control (DRC), tone profiles, source
gain compensation, amp bridging, output
bussing, individual zone power control,
global standby, source signal detection,
amplifier temperature and fault monitoring,
priority modes,1paging,1do-not-disturb,1
alarm clock, and sleep timer1
Input Signal Types Stereo analog line (unbalanced and
balanced), S/PDIF coaxial (2-channel PCM
only)
Output Signal Types Stereo speaker level, S/PDIF coaxial
(2-channel PCM only), Sonnex Link
Analog-to-Digital Conversion224-bit 48 kHz
Source Compensation2±10.0 dB per input
Input Monitoring2Source Signal Detect
Digital-to-Analog Conversion324-bit 48 kHz
Output Power3140 watts per channel at 8 ohms
240 watts per channel at 4 ohms
400 watts per channel at 8 ohms bridged
Damping Factor3> 200 @ 20 Hz
Amplifier Monitoring3Over Current, Over/Under Voltage, Over
Temperature, DC Offset, Clipping
Frequency Response320 Hz to 20 kHz, ±0.5 dB
Total Harmonic Distortion
(THD)3
0.02%
S/N Ratio3>105 dB S/PDIF in, >100 dB balanced or
unbalanced analog in, A-weighted
Stereo Separation3> 90 dB
Zone Separation3> 95 dB
Zone Volume Level Control3-80.0 to +20.0 dB, adjustable from 0% to
100% plus mute
Bass Control3±12.0 dB
Treble Control3±12.0 dB
Loudness Compensation3On/Off
Dynamic Range Control3On/Off
Balance Control3Left/right adjustable
Mono Summing3Selectable
(Continued on following page)

Crestron SWAMP(I)-24X8 Sonnex Multiroom Audio System
Operations Guide – DOC. 7049E Sonnex Multiroom Audio System: SWAMP(I)-24X8 •9
SWAMP(I)-24X8 Specifications (Continued)
SPECIFICATION DETAILS
Audio (continued)
Power Limiting3Sonnex Speaker Protect (SSP) output
limiting;
Configurable 40 to 140 watts @ 8 ohms
40 to 240 watts @ 4 ohms
40 to 400 watts @ 8 ohms bridged
Tone Profiles3Flat, Classical, Jazz, Pop, Rock, Spoken
Word
EQ Modes
3
5-band graphic or 5-band parametric EQ
GEQ Center Frequencies363 Hz, 250 Hz, 1 kHz, 4 kHz, 16 kHz
GEQ Gain3±12.0 dB per band
PEQ Filter Types3EQ, High Pass, Low Pass, Treble Shelf,
Bass Shelf, Notch
PEQ Center Frequency310 to 20,000 Hz per band
PEQ Gain3±12.0 dB per band
PEQ Bandwidth30.1 to 3.5 octaves per band
Speaker Profiles3Comprises 5-band GEQ and SSP settings
Bus Volume Offset3±12.0 dB per zone for output bussing
Resolution/Bitrate424-bit 48 kHz
Communications
Ethernet For control and console, 10/100 Mbps,
auto-switching, auto-negotiating,
auto-discovery, full/half duplex, DHCP
Cresnet For control and console Cresnet slave5
Sonnex Link 64-channel (48 utilized) digital audio with
embedded control, auto-discovery,
auto-negotiating
Power Requirements
Main Power
SWAMP-24X8 12 amps @ 120 volts ac, 50/60 Hz
SWAMPI-24X8 6 amps @ 220-240 volts ac, 50/60 Hz
Cresnet Power Usage None
Environmental
Temperature 41º to 104º F (5º to 40º C)
Humidity 10% to 90% RH (non-condensing)
Heat Dissipation 475 Btu/h (140 watts @ 8 ohms)
750 Btu/h (240 watts @ 4 ohms)
Enclosure
Chassis Metal with black finish, vented sides,
variable-speed fan-cooled
Front Panel Metal, black finish with polycarbonate label
overlay
Mounting Freestanding or 4U 19-inch rack-mountable
(feet and rack ears included)
(Continued on following page)

Sonnex Multiroom Audio System Crestron SWAMP(I)-24X8
10 •Sonnex Multiroom Audio System: SWAMP(I)-24X8 Operations Guide – DOC. 7049E
SWAMP(I)-24X8 Specifications (Continued)
SPECIFICATION DETAILS
Dimensions
Height 7.51 in (191 mm) with feet
6.97 in (178 mm) without feet
Width 19.00 in (483 mm) with ears
17.29 in (439 mm) without ears
Depth 18.47 in (470 mm)
Weight 60.0 lb (27.3 kg)
Available Models
SWAMP-24X8
Sonnex Multiroom Audio System
SWAMPI-24X8 Sonnex Multiroom Audio System –
International Version
Available Accessories
AIR Series AIR®Surface Mount Outdoor Speakers
ASPIRE Series Aspire®Speakers
AUD-EXT Audio Extenders
CBL Series Crestron Certified Interface Cables
DM-8G-CONN Cable Connector for DM-CBL-8G
DM-8G-CONN-WG Cable Connector with Wire Guide for
DM-CBL-8G
DM-8G-CRIMP Crimping Tool for DM-8G-CONN
DM-8G-CRIMP-WG Crimping Tool for DM-8G-CONN-WG
DM-CBL-8G High-Performance CAT5e Shielded
Twisted-Pair Cable
ESSENCE Series Essence®Speakers
EXCITE Series Excite® Speakers
S-EXT1-S Sonnex Link Over Fiber Extender
SAROS Series Saros®Speakers
SAT-70V/100V Sonnex Output Transformer
SWAMPE-4 Sonnex Multiroom Audio Expander, 4-Zone
SWAMPE-8 Sonnex Multiroom Audio Expander, 8-Zone
SWE-8 Sonnex Multiroom Audio Unamplified
Expander, 8-Zone
1. Feature enabled via control system program.
2. Typical of 24 stereo inputs.
3. Typical of up to eight amplified stereo zone outputs.
4. Typical of two digital stereo zone outputs.
5. If using Cresnet as the control system interface, system expansion is limited to one expander. Support
for more than one expander requires Ethernet as the control system interface.

Crestron SWAMP(I)-24X8 Sonnex Multiroom Audio System
Operations Guide – DOC. 7049E Sonnex Multiroom Audio System: SWAMP(I)-24X8 •11
Physical Description
This section provides information on the connections, controls, and indicators
available on the SWAMP-24X8.
SWAMP-24X8 Physical View (Front)
SWAMP-24X8 Physical View (Rear)

Sonnex Multiroom Audio System Crestron SWAMP(I)-24X8
12 •Sonnex Multiroom Audio System: SWAMP(I)-24X8 Operations Guide – DOC. 7049E
SWAMP-24X8 Overall Dimensions (Top)
18.47 in
(470 mm)
17.29 in
(439 mm) 19.00 in
(483 mm)

Crestron SWAMP(I)-24X8 Sonnex Multiroom Audio System
Operations Guide – DOC. 7049E Sonnex Multiroom Audio System: SWAMP(I)-24X8 •13
SWAMP-24X8 Overall Dimensions (Front and Back)
7.51 in
(191 mm)
6.97 in
(178 mm)
1 2 3 4 5 6
7 8 9 10 11 19 12 13
18
20
17
14
15
16
21
Connectors, Controls, and Indicators
# CONNECTORS,1
CONTROLS, AND
INDICATORS
DESCRIPTION
1 LCD Display and
BUTTONS
Green LCD alphanumeric, adjustable
backlight, 2 lines x 20 characters per line;
Displays source and zone setup, amplifier and
expander status, network and control
configuration, volume levels, and other
parameters;
(4) Push buttons for execution of LCD driven
functions
2 MENU (1) Push button, steps menu back one level
(Continued on following page)

Sonnex Multiroom Audio System Crestron SWAMP(I)-24X8
14 •Sonnex Multiroom Audio System: SWAMP(I)-24X8 Operations Guide – DOC. 7049E
Connectors, Controls, and Indicators (Continued)
# CONNECTORS,1
CONTROLS, AND
INDICATORS
DESCRIPTION
3 Up, Down (2) Push buttons, scroll up or down through
menu and adjust menu parameters
4 ENTER (1) Push button, executes highlighted menu
item or value
5 On/Off (1) Rocker switch, turns power amplifier on
and off and resets the unit
6 SOURCE (1-24)
Buttons and LEDs
(24) Push buttons and green LEDs, select
input source for routing and adjustment
7 COMPUTER
Pin 3 Pin 4
Pin 2 Pin 1
USB Type B female, USB computer console
port (6 ft cable included)
PIN DESCRIPTION
1
+5 Vdc
2
Data -
3
Data +
4
Ground
8 VOLUME (1) Continuous turn rotary encoder, adjusts
menu parameters, defaults to audio volume
9 ZONE (1-10)
Buttons and LEDs
(10) Push buttons and green LEDs, select
output zone for routing and adjustment
10 ANALOG SOURCES
L/R (1–16)
(32) RCA female comprising (16) unbalanced
stereo line level audio inputs;
Input Impedance: 10 kilohms;
Maximum Input Level: 2 Vrms
11 ANALOG SOURCES
BALANCED (13-16)
(4) 5-pin 3.5 mm detachable terminal blocks
Balanced stereo line level audio inputs
(mutually exclusive of corresponding
unbalanced inputs);
Input Impedance: 20 kilohms;
Maximum Input Level: 4 Vrms
(Continued on following page)
