CrimeStopper CS-2000DPII TW2 User manual

CS-2000DPII TW2
With2-Way Data PortTechnology
2-WAY REMOTECONTROLALARMSYSTEM
INSTALLATION&OPERATINGINSTRUCTIONS
INTRODUCTION
CONGRATULATIONSon yourchoiceofan “On-Guard”RemoteAlarm SystembyCrimestopperSecurity
ProductsInc.Thisbookletcontainsthe information necessaryforinstalling,using,and maintaining youralarm
system.If anyquestionsarise,contactyourinstallation dealerorCrimestopperSecurityProductsInc.atthe
TechSupportnumberbelow.
*IMPORTANTINFORMATION:Primaryand OptionalFeatures:
-PRIMARY:Thesearefeaturesthatmustbe connected inorderforthe systemtooperateproperly;i.e.the
Siren,L.E.D., +12VPower,Ground,Doorpin,Flashing lightsOverride/Program/ValetButton etc.
-OPTIONAL:Thesearefeaturestobe connected ifdesired oragreed upon bythe installing dealer.These
featuresmayalsorequireadditionalpartsand/orlaborfees.Consultwithyourinstallerbeforehand;i.e.Door
Locks,Starterdisable,Hood/Trunktrigger,and AuxiliaryRemoteOutputsetc.
Thisinstallation bookisdesignedfortheinstallerorindividualwithanexisting understanding ofautomotive
electricalsystems,along withtheabilitytotestand connectwires forproperoperation.To ease installation,
wesuggestthatyou READ THISMANUALbeforebeginning yourinstallation.Thisbookisprovidedas a
GENERALGUIDLINEand theinformation containedhereinmay differfromyourvehicle.
TECH SUPPORT
Mon-Fri8:00 AM-4:30 PMPacificTime
[phone]
REV.C2-07-2007
ThisdevicecomplieswithFCC Rulespart15.Operation issubjectto
the following twoconditions:1)Thisdevicemaynotcauseinterference,
and (2)thisdevicemustacceptanyinterferencethatmaybe received,
including interferencethatmaycauseundesired operation.The
manufacturerisnotresponsibleforanyradioorTVinterferencecaused
byunauthorized modification tothisequipment. Suchmodification
couldvoidthe user'sauthoritytooperatethe equipment.

2
TABLEOFCONTENTS
Installation Cautions&Warnings..…….……………………………….……………………………………….……2
ControlModule&ComponentMounting ……………...……………………..……………………….…….…..…..3
Wiring (LED,PROGRAMBUTTONAND SHOCK SENSORpage5-6)…………………..………….….…..….3-6
PowerDoorLock Wiring……………………………………………………….………………………….…...….…6-7
DataPortDiagram………………………………………………………………………………………………….……8
TransmitterProgramming (2nd Vehicleprogramming)..……………………………………………….…….....…9
Option Programming…………………………………………….…….………………….…….…………...….…10-12
ProgrammableOption Reset………………………………….…………………………….……………...……..…13
CustomPersonalOverrideCode…………..………………….…………………………….…………….……..…13
Operating Instructions(Sidekick Remoteand 2-Way LCD Quick guideFunctionspage15-16).…...14-19
CarJack Protection Features .…………..……………………………………………...…………………..…….…20
AntennaDiagram..………………………………………………..……………………………..……………..………21
Wiring Diagram..…………………………………………………..……………………………..……………..………22
LowBatterywarning.. …….……………………………………..……………………………..……………..………23
INSTALLATIONCAUTIONS&WARNINGS
BEFOREBEGINNING,check all vehiclemanufacturercautionsand warningsregarding electricalservice(AIR
BAGS,ABS BRAKES,ENGINECOMPUTERS,BATTERYetc.).
WERECOMMEND the useofaVOLT/OHMMETERtotestand verifywiring circuits.Testlightsorilluminated
probescan causedamage toon-boardcomputerorengine managementsystems.
DONOTexceedmaximumoutputratings.
WERECOMMEND thattheMAINSYSTEMFUSE beREMOVEDbeforejumpstarting,using abattery
charger,orchanging the battery.Avoltage surge orhigh boostcondition coulddamage alarm circuits.
DONOTROUTEANYWIRINGTHATMAYBECOMEENTANGLEDwithbrake,and gaspedals,steering
column,oranyothermoving partsinthe vehicle.

3
CONTROLMODULE&COMPONENTMOUNTING
DONOTMountthecontrolmoduleintheenginecompartmentorwherethewiring harness can
becomeentangledwithmoving partssuchas brake/gas/clutchpedals,orthesteering column!The
alarm controlmoduleshouldbe mounted inaconcealed location.The Placementofthe modulewill affectthe
distancefromwhichthe remotetransmittercan controlthe unit. The antenna wireshouldbe routed awayfrom
anymetalifpossible.Donotalterthe lengthofthe antenna wireorrouteitwithotherwires.Donotground
the antenna wire.Fasten the moduletoabracketorwireharness using the cabletiesprovided.Underdash
Mounting:If you arelocating the controlunitunderdash,mountitashigh aspossible,noteasilylocated byan
intruder.Driver’sSide Underdashmounting providesan easy location forwiring mostofthe system’s
connections,howeverthisisacommon location foran intrudertocheck foran alarm afterbreaking intothe
vehicle.
SIREN:Mountthe siren underthe hood toan innerfender-well,wheel-well,orotherbodysurfacewiththe
open end facing downward.Run the red siren wirethrough the firewall using arubbergrommet. Ground the
sirensblack wiretometalnearthe siren oryou can useone ofthe siren’smounting screwsforaground.
LED:Mountthe blue LEDinavisiblelocation on the dashboardorconsole.
Shock Sensor:Mountthe included shock sensorwithwiretiestoan underdashwireharness orfasten with
screwstofirewall orside paneling.Usethe adjustmentknob tosetthe sensitivityofthe sensor.The
adjustmentknob adjustsbothPre-Warnand alarm trigger.
Valet/Programming Button:Mountthe Valet/Override/Programpush-button inahidden butaccessible
location.It isREQUIREDforemergency disarm,programming featuresand entering orexiting ValetMode.
WIRING
GREENWIRE:(-) NEGATIVE DOORTRIGGER
Identifythe wirethatreadsground when anydoorisopen and 12 voltswhen all doorsareclosed.Some
vehiclesmayhaveisolated doortriggers.Inthiscaseyou mayneed torun additionalwiresfromotherdoors
orgo directlytothe wirethattriggersthe vehicle’sinteriordomelight. Sometimesnewervehiclescontaina
separatebodycontrolmodule(BCM) wherethe doortriggercircuitcan be located.One vehiclewill not
requirethe useofBOTHNegativeand Positivedoortriggerwires.
VIOLETWIRE:(+)POSITIVE DOORTRIGGER
Sameasthe GREENwireaboveexceptthiswireisused forvehiclesthatshowapositivevoltage (12 volts)
when the doorisopen and aground when doorsareclosed asinmanyFord,Lincoln,and Mercuryvehicles.

4
WIRING
BLACK WIRE:SYSTEMCHASSISGROUND
The Black wireMUSTbe connected tothe CHASSISMETALofthe vehicle.Scrape awayanypaintordebris
fromthe connection pointand useastarwashertoensureagood connection.Keep the ground wireshort.
YELLOWWIRE:IGNITIONSWITCHED“ON”AND “START”+12 VOLTS
Connecttoan IGNITIONwire(orfuseinthe fusebox)thatshows+12 Voltswhen the keyisinboth“On”and
“Start”(WHENCRANKING)positions.
GRAYWIRE:(-) NEGATIVE AUXREMOTEOUTPUT1(Optional, may requirearelay)
Connecttothe Negativetrunkreleasecircuitortothe activation circuitofan auxiliarymoduleordevice.If the
circuitrequires+12V,then arelayisrequired.RELAY WIRING: Connectthe Graywiretoterminal85,connect
relayterminals86 and 87 to+12Vconstantpower.Connectterminal30 ofthe relaytothe +12Vpositive
device/circuittobe activated.
BLUEWIRE:(-) NEGATIVE HOOD/TRUNK TRIGGER(Optional)
Inputtriggerforagrounding hood ortrunkpinswitch.Connecttoexisting hood and trunkpinswitchesthat
read ground when open.If no existing switchesareavailable,install newpinswitchesifdesired.Note:DO
NOTmountnewpinswitchesinwaterpathways.
BLACK/WHITEWIRE:(-) NEGATIVE DOMELIGHTILLUMINATIONOUTPUT(Optional, requires arelay)
Thiswireprovidesa(-) negativeground when the systemisdisarmed toactivateavehiclesdomelightcircuit.
Werecommend the useofarelayforthisconnection.ConnectBlack/Whitetoterminal#85 ofrelay.Connect
terminal#86 tofused constant+12V.Connectterminal#87 toa+12Vconstantorground sourcedepending
on the type ofdomelightcircuitinthe vehicle.ConnectTerminal#30 tothe domelightcircuitinthe vehicle.
BROWN/WHITEWIRE:(-) NEGATIVE HORN PULSE /CHIRPOUTPUT(Optional, may requirearelay)
Connecttothe NegativeHornTriggerwireusuallylocated nearthe steering column.If the vehiclehorncircuit
requires+12V,then arelayisrequired.
ORANGEWIRE:(-) NEGATIVE ARMEDOUTPUT(500mAGround,Optional)
ThiswirebecomesaconstantGround outputwhen systemisarmed.Thisoutputcan be used toactivate
optionaldevicessuchasextrasensors,LED’s,windowroll-up modules,voicemodulesetc.
WHITE/REDWIRE:(-) NEGATIVE AUXREMOTEOUTPUT2(Optional, may requirearelay)
Thiswireconnectsthe samewayasRemoteOutput1see GRAY WIREdescription above.

5
WIRING
BLUE/WHITEWIRE:NOTUSED
BROWNWIRE:(+)SIRENOUTPUT(3AmpMax.)
ConnecttoREDsiren wirefromthe Siren inthe engine compartment.
WHITEWIRE:+12VFLASHINGPARKINGLIGHTOUTPUT
Connecttothe switched parking lightwireatback oflightswitch.If thisisnotpossible,connectdirectlytoone
ofthe parking lightsatthe frontofthe vehicle.European vehiclesrequireseparaterightand left circuits.Use
adualrelayor2diodestoseparatethe outputsignal.
REDWIRE:+12VPOWERINPUT(15 ampfuse)
Connectto+12 Voltsourcewithsupplied fuse&holder.Recommended location forthisconnection isatthe
vehiclebatterypositiveterminal.
WIRING:PROGRAM/OVERIDESWITCH AND LED
PROGRAM/OVERRIDESWITCH:2PINPLUG(REQUIREDFORPROGRAMMING&LEARNING
REMOTES)
Thisswitchisused forprogramming features,transmitters,valetmode,and tooverride the optionalstarter
disable(ifinstalled)inthe eventofanon-operating remotecontrol.
LED:2PINPLUG
The LEDisused asaVALET/PROGRAMMINGindicatorand itwill alsoFLASHforuseassecuritydeterrent
when RemotelyLocking the door.
VALET/PROGRAMSWITCH
STATUSLED

6
WIRING:SHOCK SENSOR
4PINSENSORPLUG/HARNESS (BLUE):
WhiteWire:NegativeTrigger
Blue Wire:NegativeWarn-away
Black Wire:SensorGround
Red WireSensorPower
SHOCK SENSOR:The sensorsupplied
withthissystemdoesnotrequireany
additionalwiring.Simplymountthe
sensorinasuitablelocation,plug itin,
and adjustthe sensitivity.Thereare2
LED’son the shock sensortoassistyou
inadjusting sensitivity.The Green LED
indicatesthe “WarnAway”leveland the
Red LEDindicatesafull alarm shock
sensorviolation.
POWERDOORLOCK WIRING
3PINDOORLOCK PLUG(Optional):
GREEN:(-) NegativepulseforLOCK
RED:+12VCoil Powerforusing relays.
BLUE:(-) NegativepulseforUNLOCK
Hint: Determine the type oflocking systemthe vehiclehasbeforeconnecting anywires.Incorrectconnection
couldresultindamage tothe alarm and/orthe vehicle’slocking system.Somevehiclesareequipped with
Class 2DATAdoorlocks systemswhichrequireabypass moduletocontrolthe doorlocks.Pleasereferto
vehiclewiring colorchartwhichissupplied viaTechWeb (basicservice)forauthorized dealers.
GREENLED
REDLED
PRE-WARN
TRIGGER
GROUND
12 VOLTS
WHITE
BLUE
BLACK
RED
SENSITIVITY
ADJUSTMENT
(Trigger)
(Pre-Warn)
SENSORADJUSTMENT
Clockwise =HigherSensitivity
CounterClockwise =LowerSensitivity
1)Startadjustmentbyturning sensitivtyat
minimum.

7
POWERDOORLOCK WIRING
NEGATIVE TRIGGERDOORLOCK WIRINGPOSITIVE TRIGGERDOORLOCK WIRING
GREEN
GREENFUSED
RED+12VREDBLUE+
BLUE
86
858685 8787 3087A30
87A
FACTORY
FACTORY
LL
POWER
POWERLOCKING
LOCKING
ULUL
RELAYS RELAYS
REVERSE POLARITYDOORLOCK WIRING
GREEN
GREENFUSED
FUSEDRED
RED+12V
+12VBLUE
BLUE+
+
86858685
86858685 8787
8787 3087A3087A
3087A3087A
+L
CUT
UL
CUT
MASTER
SWITCH
AFTERMARKETMOTOR/DOORLOCK WIRING

8
DATAPORTDIAGRAM
DatabusSystems:DataControlleddoorlocks,FactorySecurityand manyaccessories
ThisunitincludesDPTechnologyitwill allowyou toplug ourmoduleswhichoperateDatacontrolDoorlocks,
accessories,and Bypass Factorysecuritysystemsdirectlyintothe unitbyviaDataPort. The modulecable
plugsdirectlytothe Dataporton the side ofthe unit. PleaserefertoDatabusmodulemanualfordetail
instructions.
Option #16 controlsthe DataPortProtocolfor1-Way(OFAmodules)or2-Way(SLmodules).The defaultis
setfor2-WayProtocol.Thisoption hasno effecton conventionalwiring ofBypass modules.
DATALINKCABLE
DataPort
ModuleNotIncluded
Data
Bypass
Module
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
BCM
OBDconnector
Datawire
AntennaPlug

9
TRANSMITTERPROGRAMMING
NOTE:All transmittersmustbe learned atthe timeofprogramming.Thissystemcan learnup to4remotes.
1.Turnkeytothe ONposition and press programbutton 4times.
2.Afterashortdelay,the unitwill flashthe parking lights4times,Siren 4times,Horn4timesand status
LEDwill be on solid.
3.Press the Button #1 (Lock)AND Button #2 (Unlock)togetheron the remoteyou wishtoprogram.
4.You shouldget2lightflashes,2siren chirpsand 2hornhonks (optional)indicating the unitiswaiting for
the second code tolearn.Press button #1 and #2 togetherofasecond transmitter,the unitwill flash3
times,3siren chirpsand 3hornhonks.Press the lock and unlock button on a3rdor4thtransmitterforup
to4total.Note:The unitwill notflashthe lightswhen learning the 4thcode.Turnkeyoff toexit
programming mode.
IGN
OFF
WAITFOR
4FLASHES
PRESS 4X'sFLASH2,3,or4X's
IGN
OFF
PRESS LOCK &UNLOCK
LIGHTS
SLNT
CrimeStopper
AUX
4HONKS
4CHIRPS
2VEHICLETRANSMITTERPROGRAMMING
PROGRAMMINGSECOND VEHICLE:
See diagramon page 14 on howtouseyourremoteforvehicle#2 operation.Tosetup yourremote,follow
the “TransmitterProgramming”steps1and 2(above)Instep #3 press the side button on YOUR remotefirst,
for2-waypress and holdforside button until the “2”Icon showon the remote,then press the Lock and Unlock
button.Yourlightsshouldflashindicating the remoteisprogramming.Turnkeyoff toexitprogramming
mode.Yourvehicleshouldnowbe programmed forthe second vehicle.
NOTE:Youroriginaltransmittersmustbe learned atthe timeofprogramming forsecond vehicle.Thissystem
can learnup to4remotes.

10
OPTIONPROGRAMMING
1.Turnthe Ignition ONand press the Override/Programbutton 5times.
2.Afterashortdelay,the parking lightswill flash5times,Siren 5times,Horn5timesand statusLEDwill be on solid.
3.Withinthe nextfewseconds,press the Override/Programbutton [again]the numberoftimesthatcorrespondsto
the optionschartbelow.Siren and/oroptionalhornshouldchirpforeachpress.
4.When you gettothe desired option number,quicklypress the appropriatebutton on the remotecontrolaccording to
the chartbelow.The systemwill provide 1chirp/flashforButton 1(Lock Symbol)and 2chirps/flashesforbutton 2,
3forButton #3 and 4forbutton #4.(See Chartbelowforoption descriptionsand values.)
5.TurnIgnition off. Systemchirpsand flashesthe lights3timeson exit. When you arefinished customizing options,
check operation.
PROGRAMMINGOPTIONSCHART*=DefaultSetting
Option
#Option Description BUTTON1 LOCK BUTTON2 UNLOCK BUTTON3 AUXBUTTON4 SILENT
1.FactoryHornChirps/PulsesPulsewithtrip
onlyArm/Disarm Chirps &Pulsewithtrip*Arm/Disarm/Warn Chirp&Pulsew/trip*
2.PassiveArming ON&OFF
PassiveChirpCountdownIgnition & LastDoor*OFF*Ignition &LastDoorw/
ChirpCountdownLastDoor Only
3.PassiveLock /Cust. Override ON*OFF*CustomOverride
4.Ignition controlled Locks *ON*OFF Ignition Lock Only
5.5/60 Sec.DoorOpen Warning 5Seconds*60 Seconds*
6.ActiveRe-Arm (30 Sec.)*ON*OFF
7.DoubleUnlock Pulse*OFF*ON
8.SilentArm/Disarm
(ChirpDefeatw/button 1or2)*OFF*ON
9.Parking Lightson withdisarm *ON*OFF
10.Disarm withtrunkpop OFF *ON*
11.N/AN/AN/A
12.DoorLock PulseTime*0.7Sec.*3Sec.
13.Type ofCarjack Protection *ACTIVE*PASSIVE FULL-TIME
14.Carjack Enable/Disable*Disable*Enable
15.L/ULorArm/Disarm w/IGNON*Lock/Unlock *Arm/Disarm
16.DataPortProtocol
1-Way =OFA,2-Way =SL*2-Way*1-Way
