CrimeStopper SP-402 User manual

SP-402
Combo Alarm& RemoteEngineStarting System
OPERATING INSTRUCTIONS
INTRODUCTION
CONGRATULATIONS onyourchoice of theSP-402 by Crimestopper Security Products Inc. Thisbooklet containsthe
informationnecessaryfor operatingyoursystem.If anyquestions arise, contactyourinstallationdealer or
Crimestopper Security Products Inc.
CONTACTINFORMATION:
TECHNICAL SUPPORT(800)-998-6880
Monday- Friday8:00am- 4:30pmPacific
Website: www.crimestopper.com
CRIMESTOPPER
SECURITYPRODUCTS, INC.
1770 S. TAPO STREET
SIMI VALLEY, CA.93063
REV 09-2012
ThisdevicecomplieswithFCC Rulespart15.Operation issubject
tothe followingtwoconditions:1)Thisdevicemaynotcause
interference,and (2)thisdevicemustacceptanyinterferencethat
maybe received,including interferencethatmaycauseundesired
operation.The manufacturerisnotresponsibleforanyradioorTV
interferencecausedbyunauthorized modification tothis
equipment. Suchmodification couldvoidtheuser'sauthorityto
operatethe equipment.

2
USINGTHEREMOTETRANSMITTER
VEH
NOTE:TheVEHbuttoncanbeusedtokeepremotecontrol fromaccidentallyoperatingyourvehicle.
See Page 17 foradditionalinformation on howtouseyourremotetooperateasecond vehicle
VEH1=Blue
LED
VEH2=RedLED
R
emoteAUXOutpu
ts
AUX1= Trunk+ Lock
AUX2= Trunk+ Unlock
AUX3= Trunk+ Start
AUX4= Lock + Start
Lock / Arm
Unlock / Disarm
TrunkRelease
VehicleSelect
RemoteStart

3
QUICK CHART BUTTONFUNCTIONS
Button Button
Functions Button Options Button Button FunctionsButton Options
Lock Doors &Arm
System
PressandHold2
SecondsforPanic
Mode
VEH
Selects between
Vehicle#1and
Vehicle#2
Press and Holdfor2
seconds
Unlock Doors&
DisarmSystem Press twicefor seconddoorunlock
VEH
Used toDisable
RemoteControl
Press and Holdfor2
seconds
Trunk Pop
Aux#1
PressandRelease
forTrunkPop Aux#1
Activates
Aux#1
thru
Data DataModuleSliding
Door
StartorStopengine Press forRemote Start. Threeoptions
available
Activates
Aux#2
thru
Dataorwire
SteadyMomentary
or DataModule
SlidingDoor
SilentArm/ Disarm NoArm/ Disarm ChripfromSirenor
Horn
Activates
Aux#3
thru
Dataorwire Momentary, Timed
orLatchedOutput
Valet ServiceSensor
ON/ Off
Valet Mode when
Disarmed.Sensor
On/Off when Armed
Activates
Aux#4
thru
Dataorwire Momentary, Timed
orLatchedOutput
Plus
Plus
Plus
Plus
Plus

4
OPERATINGINSTRUCTIONS-ALARM
ARMING / LOCKING
Press theLockButton ontheremotecontrol.The Systemwill armemitonesiren chirp,onelightflash,and
the LEDwill begintoflash.Power lockswill lock(ifequipped).Starter disablecircuitwill turn on.The 2-Way
LCD Pagerwill beeponcewhiledisplaying aLocking symbol.Afterashortdelaytoallowthe vehicleand
electronics tosettle,thesystemwill becompletelyarmed.
DISARMING / UNLOCKING
Press theUnlockButtonontheremotecontrol.TheSystemwill disarmandconfirmwithtwosiren chirps,two
lightflashes,and the LEDwill turn off. Powerlockswill unlockand InteriorDomelightwill turnon (ifinstalled
withtheseoptionalfeatures). The2-WayLCD Pagerwill beep twicewhiledisplayinganUnlocksymbol.
SELECTIVE SILENTARMING/ DISARMING
ToArmor Disarmthesystemwithoutsiren chirps,press and releaseboththeUnlockand Start
Buttonatthe sametime.The Systemwill Armor Disarmwithoutsiren chirps.Flashing lightsand
LEDwill be the onlyindicatorsofArm/Disarmstatus.The LCD will Displayamusicalnotewithan“Ø”when
the systemisarmedordisarmed without achirp.
DRIVER’SDOORPRIORITYUNLOCK:Optionalconnectionrequired
Thisoptionseparatesunlockofthe driver’sdoorfromthe passenger doorswiththe remotecontrol.The first
pressofunlockbutton will unlockjustthe driver’sdoor.Pressingthe unlockbutton a2
nd timewithin12
secondswill unlockthepassenger doors.
DISARMING WHILETRIGGERED
Disarmingthe Systemwhileitistriggering requiresTWOpressesofthe Unlock Button.The firstpress Resets
the alarmcycleonly(systemstill armed)whileasecondpress will disarm/unlockthe system.
SELECTIVE SHOCK SENSORDISABLE
Toarmthe alarmandbypass shocksensor protection,pressthe LockButton asnormalthen
pressand releasetheLock&UnlockButtontogether within2seconds.Youwill hear3extrasiren
chirpsindicating the shocksensorbypass forthisarming cycleonly.Thisisfeature usefulwhenparking near
railroadtracks,airports,or areaswithexcessiveloudmachineryor noisetopreventthe nuisanceof
unnecessaryfalsealarms.
Plus

5
OPERATINGINSTRUCTIONS-ALARM
ALARMTRIGGERS
Ifthereisanintrusionintothevehicle,ahard impacttothebodyortheignition isturned on,the alarmwill
soundand flashthe lightsfor1minute.After 1minute,thetrigger cyclewill automaticallystop and alarmwill
remainarmed tocontinue protectingthevehicle.If adoor isleft openafter anintrusionthentheunitwillcycle
amaximumof2minutesandcontinuetoprotect the otherun-tampered orunopened zones.
LCD REMOTEPAGING / ZONEVIOLATIONS
When the systemistriggered,thealarm sendsapagingsignaltothe remote.If youarewithinrange,youwill
receiveapaging signalthatwill lightup the LCD Screen Red. The displaywill showan iconofwhat caused
the violation.The pagingremotewill alsovibrateand beep tonotifyyouthe vehiclehasbeentamperedwith.
OPENDOORALERT/BYPASS
Uponarming,thissystemwillwarn you5-60secondslaterifadoorisleft open.The LCD pagerwill vibrate
and beep(5X’s)alongwithdisplayingthe open zoneonyourLCD screen.Thiszonewill be bypasseduntil the
doorisclosed;otherwise, thealarmwillcontinuetoprotectall otherzones.
PRE-WARNINGSHOCK PROTECTION
The Pre-Warning (Warn-A-Way)featurewill activatewhenalow-levelshockor vibration isdetected bythe
system’sshocksensor.The alarmwill chirp the siren 5timesandflashthelightsoncetohelpdeterany
furthertampering withthevehicle.Thepager/ remotewill beepand showaHammer Icon.
PASSIVE ARMING MODE(Programmable)
Passive(automatic)Armingoccurs30 secondsafterthe ignition isturned off andthelastdoor isclosed.
Uponclosingthelastdoor,theunitwill flashthelightstwiceand LEDwillbeflashingrapidlytoconfirmpassive
countdown.Ifadoorisre-opened withinthe 30-secondperiod,thecountdownstopsandbeginsagainwhen
the door isclosed.Passivearmingprovidesfailsafeprotectionincaseyouforget toarmthesystem.
PASSIVE LOCKING(Programmable)
The systemcanbeprogrammed topassivelylockthedoorswhen thesystem passivelyarmsorrearms.The
defaultsetting isOFF becausepassivelocking increasesthe riskoflocking the keysinthevehiclewhen the
systemarms/lockspassively,withoutyou pressingtheremote.

6
OPERATINGINSTRUCTIONS-ALARM
REMOTEPANICPROTECTION
Tosoundthealarminan emergencyortodrawattention toyour vehicle,pressand holdthe Lockbutton for at
least3secondsuntil thesiren/hornsounds.Press the Unlockbutton toresetpanicmode.The LCD display
will flashmostof the iconsand emit 10beepswhenthePanicMode istriggered.
TRUNK / HATCH POP(Optional, RemoteAUX.1Output)
Thisfeatureisdesigned tointerfacewithexisting Factorypower trunkor power hatchreleasesystemsand
mayrequire additionalpartsand/orlaborcharges.Toeliminatethepossibilityofaccidentallyopeningthe
trunk,there are (3) optionsfor button press selection.Thisoptionwill allowyou tochange whether theRemote
starter andTrunkreleaseactivatebya:
1.Doublebutton ½secondpresses.
2.Single½second press. *Default=Single½secondpress*
3.Press andHold2seconds. Thisoutputstayson untiltrunkbuttonisreleased.
REMOTEAUX.1thruDatamoduleforslidingdoorsonly
Thisfeature requiresaDatabusmoduletooperate.
Press TrunkplusLockat sametimetoactivateAux1.
REMOTEAUX.2Output(Optional,requires specialprogramming)
Thissystemcontainsa2
nd Auxiliaryoutputtoactivateotheraccessoriesordevices.This
momentaryoutputwill stayactiveaslong asthe remotebutton ishelddown.There isnoLCD /
PagerconfirmationforAux. 2output. Toactivatethe2nd Auxiliaryoutput:
PresstheTrunkandUnlockbuttonfor more than2seconds.
REMOTEAUX.3Output(Optional,requires specialprogramming)
Thissystemcontainsa3rd Auxiliaryoutputtoactivateother accessoriesordevices.Thisoutput
isprogrammableforamomentary,timedorLatchoutput. Toactivatethe3rd auxiliaryOutput:
Press theTrunkand Start Buttonatthe sametime.
REMOTEAUX.4Output(Optional,requires specialprogramming)
Thissystemcontainsa4th Auxiliaryoutputtoactivateother accessoriesordevices.Thisoutput
isprogrammableforamomentary,timed orLatchoutput. Toactivatethe4th auxiliaryOutput:
Press theLockand Start Buttonatthesametime.
Plus
Plus
Plus
Plus

7
OPERATINGINSTRUCTIONS-ALARM
PRIORINTRUSIONALERT
Thissystemwill notifyyouifthealarmwastriggeredwhileyouwereaway.Upon disarming,there will befour
additionalsiren chirpsafterthetwonormaldisarmchirps.Checkyour vehicleforanysignsofabreakinor
tampering. Also, seeLEDDiagnostics (page 17)todetermine thecauseof thetrigger.
DOMELIGHTILLUMINATION(Optional)
Thisfeaturewill turnonthe vehicle’sdomelightupondisarmingfor30secondsoruntil the keyisinsertedand
turnedon. Thiswill provide illuminated entrytoyour vehicleindimlylitareasforsafetyandsecurity.
EMERGENCYOVERRIDE(Disarm)
Ifyou havelostthetransmitter or itstopsworking for anyreason andtheAlarmisarmed,youwill haveto
disarmthe systemmanually.Open thedoorwiththekey[alarmwill sound], turn the ignitionon,and press the
override/programbutton for about5seconds.TheAlarmwill disarmand allowyoutousethe vehicleuntil you
can repair/replacethe remote. Valet ModealsopreventsPassiveArming.
VALETMODE(SolidBlueLED)
Disablesalarmsystemandremoteenginestarting forvehicleservicing.Thealarmsystemmustbedisarmed
toenterValetMode.
1. To ActivateValet ModeManually: Turn theignition onand press the Valet/overridebutton[about5-6
seconds]until youhear (3) siren chirpsand the LEDturnson solid.Repeatthe process toexitVALET
mode.
2. To Activate ValetModewiththeRemote: Press and holdboththe LockandUnlockButton
together for about3secondsuntil 3chirpsare heard.Repeatthissteptoexitviatheremote
transmitter.Lock/Unlockand AUXfeatureswill still operateinVALETMode however;RemoteStart
andAlarmfunctionsare inhibited.

8
REMO REMOTEENGINECONTROLTEENGINECONTROL
REMOTESTART&TrunkRelease–ButtonPress Selection(Option#8)
Toeliminatethepossibilityofaccidentallyopening the trunkor startingthevehicle,thereare (3)optionsfor
button press selection.Thisoptionwillallowyoutochange whether the Remotestarter andTrunkrelease
activatebya:
4.Doublebutton press.
5.Single½second press.
6.Press andHold2seconds.
*Default=Single½secondpressandrelease*
REMOTEENGINESTARTING
1)Press remotestartbuttonontheremotetransmitter.Systemwill chirp 3timesfor audibleconfirmation.
(Chirpscan be programmed on or off-See installationmanual.)
2)Parking lightsflashonce,then turnonsolid,Ignition/Accessorycircuitsturnon.
3)After afewseconds,StarterMotor engages, Parking lightsandAccessorycircuitsturnoffwhilecranking.
4)EngineStartsandRuns. Parking LightsandAccessoryturnbackon, DoorsLock.
5)Enginewill remainrunningfor programmed run timeuntil resetwithBrakepedal.Ifneeded,theenginecan
be turnedoffwithremotetransmitter.
REMOTEENGINESTARTING –LCDPAGER-REMOTE:
When requestingaremotestart the LCDpagerremotewill confirmwithanIgnition Iconalongwith3beeps.
Oncethevehiclehassuccessfullystarted the remotewill confirmbackwith3beepsand vibration, aKeyIcon
andsmokecomingfromcar. TheLCDscreen will displaythe remainingenginerun timeeveryminute.
AFTER
IGN
3
STARTER
THEN
FLASH1X
SOLID
SOLID
SEC.
PRESS START

9
REMOTEENGINECONTROL
UNSUCCESSFULREMOTESTART
Inthe eventthatthe enginedoesnotstartonthe firstattempt, thesystemshutsdownforafewseconds,then
attemptstorestarttheenginea2nd and3rd time.For hard starting engines,the unitwill allowastarter crank
timeofup to4secondsmaximum.Thisshouldprovideamplecranking timefor difficultstarts,butislimited to
4secondstohelppreventdamagetothe starterfromovercranking.
1)Ifenginestartson2nd or 3rd attempt, seesteps4&5(onlastpage) under"SuccessfulStart".
2)IfThirdattemptfailstostartengine,thesystemwill turnoff and doorswill remainlocked.NOFURTHER
ATTEMPTSWILL BE MADEAUTOMATICALLYUNLESS YOUPRESS THEREMOTESTARTBUTTON
AGAIN.
TURNING OFFYOUR REMOTESTARTEDENGINE(VIARemoteControl)
1)EngineisrunninginRemoteStart(Parking lightsON).
2)Press RemoteStartbutton onremotetransmitter.
3)Engine&parking lightsturn OFF,Doorsremainlockedorwill re-lockif applicable.
ENGINE& LIGHTSOFF
PRESS START
ENTERINGYOUR REMOTESTARTEDVEHICLE
1)Withengine running,useremotetoUnlock/Disarmsystem(If armed)oropendoorwithkey.
2)Entervehicleandbecarefulnottostep on brakepedal!(RemoteStart Reset)
3)Turn Ignition toON/RUNposition, then pressbrakepedal toreset the RemoteStarter&Shift outof park.
4)Remotestarter will resetinstantlywhenthe brakeispressed.Parking lightswill turn off and theignition key
isnowcontrollingyour vehicle.

10
IDLEDOWNMODE
IDLEDOWNMODE(Option#26 –10, 20,30minutesorInfinityRun)
Thismode allowsthe unittotakeover operationofyour idling,parked vehiclewhiletheignition keyis
removedandyouexitthe vehicle. Thevehicleisputintoaremoterunningconditionbeforeyouexitanditwill
remainrunning fortheprogrammedruntime, until youreturn, oruntil theremotestartbuttonispressed.
Example:
You pull uptoaconveniencestoreforaquick stop,"IdleDown"modekeepsenginerunningwhen you
exitthevehicle,(withkeysinhand)remotelock/armalarm.Whenyoureturn,unlock/disarmalarm,turn
ignitionONand driveaway.
IDLEDOWNMODE-Exiting TheVehicle:
1)Withenginerunning,pressRemoteStartbuttonon remotetransmitter.Sirenwill chirp3timesfor
confirmation.
2)Parking Lightswill turnON.
3)Doorswill unlock, orifbrakepedalisbeing depressedthendoorswill unlockwhenit isreleased.
4)Turn OFFIgnition andremovekey.Engine shouldremainrunning.
5)Exitvehicle,thenarmsystemwithremoteifdesired.Lockingdoorsa2nd timeabortsremotestart.
6)Enginewill remainrunning forprogrammed run time, until youreturn, orpressthe remotestartbutton.
IGN
SOLID
OFF
UNLOCK
PRESS START
IDLEDOWNINFINITYRUNMODE
IdleDowncanbeprogrammedfor INFINITYRUN.Thisallowsthevehicleenginetoremainrunning
INDEFINITELY without theignitionkeyinthe switch.Theparking lightscontinuouslyflashinthismode.This
mode can bebeneficialtolawenforcementorcommercialtrucksthatneedtoremainrunningunattendedfor
long periodsof time.

11
TIMEDSELF STARTINGMODE
TIMEDSELFSTARTMODE
Thismodeallowsthevehicletobeprogrammed toself-startevery4hoursandrun forthe programmedrun
time.Thiscan behelpfulduringextremelycoldconditionswhereengineorfluidfreeze-up isaconcern. !!THE
VEHICLEMUSTBE OUTDOORSORINAWELL VENILATEDAREA!!
TIMEDSELF-STARTMODE–Exiting theVehicle:
1)Haveenginerunning withtheKey,thenpress the Startbuttononthe transmitter.
2)Within10 secondspressthevalet/programbuttononce.
3)Parking Lightswill turnOFFforabout 5seconds, and doorswill unlock.
4)Turn Ignition switchOFF,removekeyand exit the vehicle. Engineshouldremainrunning.
5)Press the remotestartbuttonagaintoturn off the engine.The parkinglightswill flash4TIMES asa
confirmationthattheunit isinTimed Self-StartMode.
6)The Vehiclewill Start byitselfevery4hours, oruntil driven withkeyor startedviaremotecontrol.
IGN
SOLID
OFF
UNLOCK
PRESS1X
WITHIN10SEC.
LIGHTSOFF 5SEC.
FLASH4X
LOCK
PRESS START
PRESSSTART
RESETTINGTIMEDSELFSTARTMODE
Toreset the timed self-start mode,startvehicleusingtheignitionkeyorthe remotecontrol.

12
TURBOTIMERMODE
TURBOTIMERMODE(Option#31)
The optionalTurboTimer modeallowsthe CoolStartsystemtokeepaTurbo orTurbo Dieselvehiclerunning
for 1,3or5minutes[selectively]after you removethekeyandexitthevehicle.Thisishandyfor turbo cool-
downwithouttheneedfor expensiveturbotimers.The Default=OFF.
To ActivateTurboTimer:
Withthe engine running bykey, pressRemoteStartButtonwithbrakepedal depressed. Asyou release
the brakepedal,theParking Lightsand StatusLEDwillblinkthenumberof minutesfor the TurboTimer
setting. Thedoorsunlockafterconfirmation.
REMOVEKEY
FLASH 1-5X
EXIT VEH.
PRESS
AND HOLD
BRAKE
RUNNING RELEASE
BRAKE
LIGHTS
RUNNING
REMAIN
1-5MIN.
PRESS START

13
MANUAL TRANSMISSIONMODE
MANUALTRANSMISSIONEXITPROCEDURE(Option#15-1,15-3and 15-4)
ThissystemfeaturesaManualTransmission Mode.When exitingthe vehicle, thereissafetycheckout
procedurerequiredfor themanualtransmission mode towork. Thereare3choicesofoperation,
1. Option15-1: Withenginerunningand vehicleinneutral,setparking brake,then press “KEY” Iconon
transmitter. Theremotestarterwill turnon andtakeoveroperationof the vehicle.
2. Option15-3: Withenginerunningand vehicleinneutral,setparking brake,the remotestarterwill turn
on andtakeoveroperationof the vehicle.
a. Removekey,exitvehicle(remotestarter unitmust“SEE”dooropened,thenclosedwithengine
running).
b. Press Lockbutton within10 secondsofclosing door to“ArmwithIdleDown” (engine stays
running).Press Locka2
nd timetocancel“IdleDown”(engine turnsoff)and setup Manual
TransmissionMode.
c. Press Lockbuttonafter 10 secondstoArmsystem,lockthe doorsandshutdownthe engine.
Fromthispoint, youcanwill remotestart theengine unless adoorisopened.
d. Press the RemoteStartButtonafter closing door tosetup ManualTransmission Modewithout
Arming AlarmSystem.
3.Option15-4: Withenginerunningand vehicleinneutral,setparking brake,the remotestarterwill turn
on andtakeoveroperationofthevehicle.RemoveKeyand exitvehicle. When the lastdoor ofvehicleis
closed,the engine will turnoff in2secondsand setupManualTransmissionMode.Youcanarmthe
alarmsystemtolockdoorsand protectvehicle.
NOTE: Passivearming doesnotworkinManualTransmissionMode.Thissystemcan be programmed tolock
the doorswhenremotestartaborts(engine turnsoff).
TURBOTIMERinManualTransmission Mode:
For TurboTimer,press brakepedalbeforesetting parking brakeorpressing the RemoteStartIcon (requires
TurboTimer Option#31).After exitingvehicle,press lockbutton tosetManualTransmissionMode.The
engine will remainrunning for the Turbo Timesetting(1,3or 5minutes).TurboTimer doesnotworkwith
option15-4selected.

14
ANTI CARJACK PROTECTION
CARJACK PROTECTION(Option 32-1)
Thisoptionalfeaturerequiresinstallation ofahiddenmomentarybuttonoranOn/OffswitchforCarjack
protection.Carjackprovidesprotectionwhiledrivingyour vehicle.IfaCarjacker opens,anydoorwiththe
ignitionon,the systemarms. When thedoorcloses,the parking lightswill flash2timesandtheLEDwill begin
toflashrapidlytoconfirmthe beginning ofaCarjackcountdown.30 Secondslater,theunitwill begina
CarjackCycleconsisting of20 secondsofpre-warning chirpsturning intoafull systemactivationwithsiren,
hornsand flashinglightsfor up to5min.TurningtheIgnitionoff during aCarjacktrigger will stopthesirenand
lightsand hornbutCarjackprotection isstill active.Ifthe Carjacker triestoturn the IgnitionbackON,the
vehiclewill not start and theSirenandLightsand horn will resumefor 5minutesoruntil the ignition turnsoff.
ToResetCarjackDuringCountdown: PresstheUNLOCKbuttononthe remotecontrol,thesirenwill chirp
onceand the LEDwill stopflashing.
To ResetCarjack afterTrigger: Withthe ignition keyon,press andholdtheoverridebuttonfor atleast5
seconds.
HIDDENSWITCH-CONTROLLEDCARJACK
Thisconfigurationwill enablethe vehicleownertoactivateaCarjackcountdownbypressingahiddenpush-
button(notincludedwithkit)duringaCarjacksituation.ACarjackcountdownwill beginunderthefollowing
conditions:IgnitionisON(vehicleisrunning),the push-button ispressed,andthe door opens/closes.Upon
thesethreeevents,inthatorder,the alarmwill startaCarjackcountdown.After adelayof30 seconds,the
systemwill beginchirping for20secondsthentriggerintoafull cycleforupto5minutes.
SWITCH-CONTROLLED&FULLTIMECARJACK
Thisisthe recommendedmethod.Ahidden on/off switchisinstalledonthePinkCarjackwire.For Carjack
protection,simplyturnon the switch.Turn offthe switchtodisableCarjackprotection.Youcan leavethe
switchonforfull timeprotection.Justremembertopresstheunlockbuttoneverytimethe door isopened
whiledriving.

15
ALARMTRIGGERDIAGNOSTICS
Thissystemsincludesdisarmdiagnostics, throughtheLEDlight, that will helpindeterminingwhat caused the
last trigger ofthealarmsystem. Thisisavaluabletoolindetermininghowthevehiclewastampered withor if
there isafalsealarmproblem, inwhichcaseyoucanmakethe necessaryadjustmentstocorrect the problem.
When the systemisdisarmed withthe remote, youwill hearthe normal2chirps, then 4quickchirpsthat
indicatethealarmwastriggeredwhileyou wereaway. Checkthe LEDlight forasequenceof flashes:
1LEDFlash=ShockSensorViolation
2LEDFlashes=DoorViolation
3LEDFlashes=Hood Violation
4LEDFlashes=IgnitionViolation
5LEDFlashes=TrunkViolation
Diagnosticswill resetwhen theIgnitionisturnedonorwhenthesystemisre-armed.
REMOTESTART DIAGNOSTICS
Thesystemhasbuilt-InRemote StartDiagnostics.IfRemoteStartfails,theStatusLEDandParking
Lights flashonetoseventimestoindicate anerrorcode.TheLEDwill continueflashing theerror
codeuntiltheignitionisTurnedOn;itmeansthefollowing:
1ParkingLightFlash(1LEDFlash)=ProblemwithBrakeSwitch.
2ParkingLightFlashes(2LEDFlashes) =ProblemwithHoodSwitch.
3ParkingLightFlashes(SolidLED)=ValetServiceMode.
5ParkingLightFlashes(5LEDFlashes) =TachProblem(Ignition OnbeforeRemoteStart).
7ParkingLightFlashes(7LEDFlashes) =ManualTransmissionError.
Note:InManualTransmissionMode,theLEDwill Flash3timesiftheparkingparkisnotset.
Thissystemincludesdisarmdiagnostics, throughtheBLUELEDlight,thatwill helpindetermining
7ParkingLightFlashes=ManualTransmissionModeError.

16
TRANSCEIVER/ REMOTECONTROL PROGRAMMING
Note: All transmittercodes must belearnedat timeofprogramming!Thissystemlearnsup to4
differenttransmittercodes.
1.Turn ignition keytothe ONposition.
2.Press Programmingbutton4times,thenafterafewsecondstheunit flashesthe parkinglights4times.
3.Press button#1ofthe firsttransmitter.Youshouldget1lightflashconfirming theremoteiscoded,then
pressbutton#1ofasecondtransmitter,theunitwill flash2timesconfirming the remoteiscoded andso
on.Ifall 4codesare learned,theunitwill automaticallyexitcode learning mode,otherwiseturnkeyoff.
See diagrambelow.
IGN
OFF
WAITFOR
4FLASHES
PRESS4X's
FLASH2,3,or4X's
IGN
OFF
COMPLETE
PRESSLOCK

17
2VEHICLEOPERATION
2VEHICLECONTROL
AsingleRemote Controlcancontroltwodifferentvehicles.
Tosetupthe 2-Vehicleoperation youmustfirstprogramyour remotestoVehicle#2.Followthe“Transmitter
Programming”steps(Pg.12)atthe secondvehicleandlearnYOURremote,alongwithvehicle#2’sexisting
remotes.
VEH
Tochangefromvehicle1tovehicle2,pressthe VEH button onremotefor about2seconds.TheLEDon
remotewill changefrom BluetoRed.The VEHbuttoncan beusedtokeepremotecontrolfromaccidentally
operating yourvehicle.
Note:Use canuseVehicle2Modetoturnoff remote ifthereisnosysteminstalledina2nd vehicle
VEH1=Blue
LED
VEH2=RedLED

18
BATTERYREPLACEMENT
To Replace theBattery:
The RemoteControlusestwoCR-2025Lithium3Volt Batteries. SimplyremovethePhillipsscrewlocated
behind keyring(see diagrambelow).The top cover snapsapart fromthe backcover. Slideoldbatteriesout
andremoveplasticcover.Insert thenewbatteriesintoplasticcoverand slide intoplacewiththe(+)endfacing
up. Theplasticcover keepsthe batteriesfromshortingoutagainstthesideofmetalhousing.
VEH CR2025
Remove
Screw

19
2-WayDataPort
Mostnewvehiclesrequire aDatabusModuletoBypass thefactoryImmobilizer andoperatethekeylessentry
Databusmodulesareused tocommunicatewiththevehiclescomputerat theOBD2Dataconnectoror
Canbuswires. Thisreducesinstallationerror. CrimestopperSystemswithDPSerieshaveadirectDataPort
Plug-Infor theDatabusbypass module. ThiseliminatesconventionalwiringbetweentheAlarm/Remote
Starter andthebypass interfacemodule.
Features Include
•TransponderImmobilizer.
•PassLockImmobilizer.
•O.E.M.AlarmControl.
•R.A.P. Shutdown.
•PowerDoor Locks.
•PriorityUnlock.
•Sliding Doors.
•TrunkRelease.
•Parking Lights.
•CourtesyLights.
•Tachometer.
•Heated Seats.
•RearDefrost.
•Driver1and2Memorypresets.
The actualfeaturescontrolleddepend on the vehicleandDatabusmodule.

20
Crimestopper SecurityProductsInc.
1770So.TapoStreet
SimiValley, CA93063
[phone]
www.crimestopper.com
©2012Crimestopper SecurityProducts
ONLINETECHNICALSUPPORT
www.crimestopper.com
