Crowcon Gas-Pro User manual

H2S
CO
CH4
Gas-Pro
Quick Start Guide
Gas-Pro
Multi-Gas Confined Space Monitor
M07998/Eng
Issue 2 Jan 2015
IN USE
+ve Safety™
+ve Safety™ (Positive Safety) provides
positive conrmation of detector status prior
to deployment in the eld or on return from
site. The front mount tri-colour LED gives
the Safety Manager or Supervisor unrivalled
visibility of the status of the Operator’s
detector.
Charging
• To charge, insert the charger connected into the socket at the back of
the Gas-Pro.
• The display will show the battery lling and RED LED’s will ash red
until the battery is full, when they will ash green.
Gas Testing
Crowcon recommends regular gas tests (also known as bump tests) to
conrm sensor operation. A number of exible and simple solutions are
available:
Q-Test Quick and simple in-led gas test and calibration solution.
I-Test Intelligent wall or desk mount, powered data management
solution.
S-Test Service and maintenance solution for up to 5 detectors.
If congured to do so, test and calibration can also be completed manually
by using the non-pumped ow plate and following prompts on the screen. If
a test should fail or calibration is due and the Gas-Pro has been manually
zeroed in the last 15 minutes a calibration can also be completed.
See the Gas-Pro User and Operator manual for details.
Safety Information
• Gas-Pro is a hazardous area certied gas detector and as such must
be operated and maintained in strict accordance with the instructions,
warnings and label information.
• Read and understand all instructions in the operation section of “Gas-Pro
User & Operator Manual”, P/N M07995 prior to use.
• The Gas-Pro re-chargeable battery must only be charged in non-
hazardous (safe) areas.
• Gas-Pro is certied for use in ambient temperatures in the range -20°C to
+55°C (-4 to 131°F).
Certication Information
IECEx: Ex d ia IIC T4 Gb Tamb -20°C to +55°C
IECEx ULD 11.0004X
ATEX: II 2 G Ex d ia IIC T4 Gb Tamb -20°C to +55°C
DEMKO 11 ATEX 1031772X
UL: Gas detector use in hazardous locations Class 1 Division 1, Groups A,
B, C and D only as to intrinsic safety.
Contact Crowcon:
UK: 172 Brook Drive, Milton Park, Abingdon, Oxfordshire OX14 4SD
Tel: [phone] Email: [email protected]
US: 1455 Jamike Ave, Suite 100, Erlanger, KY 41018
Tel: [phone] Email: [email protected]
NL: Vlambloem 129, 3068JG, Rotterdam, Netherlands
Tel: [phone] Email: [email protected]
SG: Block 194 Pandan Loop, #06-20 Pantech Industrial Complex,
Singapore, 128383
Tel: [phone] Email: [email protected]
CN: Unit 316, Area 1, Tower B, Chuangxin Building, 12 Hongda North Road, Beijing
Economic & Technological Development Area, Beijing, China 100176
Tel: [phone] Email: [email protected]
www.crowcon.com
5 6

SET-UP
Prior to use
Before use, the Gas-Pro should always be checked for any signs of physical
damage.
i Read and understand the User and Operator manual prior to use.
Gas-Pro orientation
Figure 1: Gas-Pro
À D-ring à Operator button Æ+ve Safety™ indicator É Charging cable
Á Alarm bars Ä Sensor apertures Ç Dual colour LCD display Certication label
 Sounder Å Pump inlet/outlet È Alligator clip
DISPLAY
Home Screen
• Gas-Pro simultaneously displays up
to 5 gases.
• The dual colour backlight aids
recognition of alarm events.
• The home icon will invert to show normal operation.
• The backlight is green and changes to red during an alarm highlighting
the gas in alarm.
Â
Å
À
Æ
Ä
Ç
Ã
ÁÈ
É
OPERATION
Switching On/Off
• In clean air turn on the Gas-Pro by holding down the operator button
for 3 audible blips. The Gas-Pro will warm up, going through a series of
automatic processes.
• To turn off, press and hold the operator button. During the 4 second
countdown hold the button down until the countdown has nished.
Quick View
• A momentary press of the operator button allows the user to see the gas
type and unit, battery level, user and +ve Safety™ status.
Alarms
• Gas-Pro offers audible, visual and vibrate alarms as standard.
• Each gas has 2 instantaneous alarms and toxics also have TWA alarms.
• When in alarm the display backlight will change from green to red and
highlight the gas in alarm.
• When the Gas-Pro warns of a low battery, the sounder will emit an audible
double blip every 5 seconds and the +ve Safety™ LED will go red. This
means the battery has at least 30 minutes of battery life remaining. After 30
minutes the Gas-Pro will enter full alarm state and the battery icon will ash
empty as shut down is imminent.
Backlight
• The backlight is congurable but set as standard to come on at the press
of the operator button or during alarm.
Pump
• If the internal pump option has been chosen, the pump is activated by
attaching the pumped ow plate.
• Ensure the gasket is clean and undamaged prior to placement.
• The pump test will activate every time the ow plate is attached the user
will be prompted to cover the inlet to ensure a tight seal. Gas-Pro will
indicate a pass or fail, if failed the ow plate should be removed, checked
and reapplied.
USER MENU
• Access the user menu by double clicking the operator button, then
scroll through the menu using single clicks. Once the correct function
is highlighted, double click to choose.
Zero
• During start-up the operator has the option to perform an autozero, or
leave the countdown if an autozero is not required/possible.
• A manual zero can be performed at any time following start up and is
needed less than 15 minutes prior to running a manual calibration.
Time Weighted Average (TWA)
• This function allows the 8 hour TWA to be reviewed.
Pre-Entry Check (PEC)
• This function is intended for sampling air of unknown quality before
gaining access to it (e.g. going under ground through a manhole
cover) thereby avoiding unnecessary exposure.
Peak Review
• This function allows the highest level of each gas detected to be
reviewed during the last 8 hours, 12 hours or since turned on.
Settings
User setting: Up to 5 different users can be loaded into Gas-Pro using
the Portables-Pro PC application.
Pump setting: This function, which is only present if the Gas-Pro has
an internal pump, allows authorised users to turn the pump on or off.
Sounder volume: This function allows authorised users to change the
sounder volume between 2 levels.
2 3 4
