Ctouch Leddura 2Share series Instruction Manual

HEYYOU,LETMEHELP!
INSTALLATION/USERMANUAL
Leddura 2Share
Share, inspire, have fun!
With CTOUCH by your side.

Leddura 2Share
32
Share, inspire, have fun!
With CTOUCH by your side. ctouch.eu
CONTENT
Important information...................................................................................................................................3
Important safety precautions....................................................................................................................4
Standard accessories......................................................................................................................................8
Vesa mount installation.................................................................................................................................9
Control panel .....................................................................................................................................................10
Connection panel............................................................................................................................................. 11
Connections ....................................................................................................................................................... 12
Remote control ................................................................................................................................................14
Basic operations .............................................................................................................................................. 15
OTA update .........................................................................................................................................................16
Operating the navigation menu...............................................................................................................17
Display menu .....................................................................................................................................................18
Troubleshooting............................................................................................................................................... 21
Specifications ................................................................................................................................................... 23
IMPORTANTINFORMATION
If the unit is not positioned in a stable location, it can be potentially hazardous due to falling. Many
injuries, particularly to children, can be avoided by taking simple precautions such as:
•Only use furniture that can safely support the unit.
•Ensure the CTOUCH interactive display is not hanging over the edge of the supporting furniture.
•Do not place the CTOUCH interactive display on tall furniture (for example, cupboards or
bookcases) without anchoring both the furniture and the CTOUCH interactive display to a
suitable support.
•Do not place cloth or other materials between the CTOUCH interactive display and supporting
furniture.
•Do not let children climb on furniture to reach the CTOUCH interactive display or its controls.
•Do not use immediately after moving from a low temperature to high temperature environment,
as this causes condensation, which may result in fire, electric shock, or other hazards.
•To avoid possible condensation it is recommended to not use the device within 24 hours after its
arrival, to avoid possible condensation.
Warning!
To prevent the spread of fire, keep candles or other open flames away from the CTOUCH
interactive display all the times.

Leddura 2Share
54
Share, inspire, have fun!
With CTOUCH by your side. ctouch.eu
IMPORTANTSAFETYPRECAUTIONS
CAUTION
RISKOFELECTRICSHOCK
DO NOT OPEN THE DISPLAY
This symbol indicates dangerous voltage may pose a risk of electric shock for
your CTOUCH interactive display. This label is located on the back of your CTOUCH
interactive display.
This symbol indicates that important operating and maintenance instructions are contained in
the literature accompanying your CTOUCH interactive display.
Electricity may cause personal injuries and property damage if handled improperly. The CTOUCH interactive display has been
engineered and manufactured with the highest priority on safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRIC SHOCK
OR FIRE HAZARD. In order to prevent potential danger, please observe the following instructions when installing, operating and
cleaning the product. To ensure your safety and prolong the service life of your CTOUCH interactive display, please read the following
precautions carefully before using the product.
1. Read these instructions - All operating instructions must be read and understood before the product is used.
2. Keep these instructions - These safety and operating instructions must be kept in a safe place for future reference.
3. Note all warnings - All warnings on the product and in the instruction manual must be observed closely.
4. Follow all instructions - All operating instructions must be followed.
5. Attachments - Only use attachments/accessories specified by the manufacturer. Do not use attachments which are not
recommended by the manufacturer. Use of improper attachments can result in accidents.
6. Power source - This product is intended to be supplied with a listed power supply indicated on the marking label. If you are not
sure of the type of power supply at your location, consult your product dealer or local power company. For added protection for
this product during a lightning storm, or when it is left unattended and unused for a long period of time, unplug it from the wall
outlet and disconnect the cable system.
7. Power cord protection - Protect the power cord from being walked on or pinched particularly at plugs, wall outlet, and the
point where they exit from the device.
NOTE: Where the mains plug or an appliance coupler is used as the disconnected device, the disconnected device shall remain
readily operable.
8. Overloading - Do not overload wall outlets, extension cords, or convenience receptacles on other equipment as this can result
in a risk of fire or electric shock.
9. Entering of objects and liquids - Never insert an object into the product through vents or openings. High voltages are present in
the product and inserting an object can cause electric shock and/or short circuit internal parts. For the same reason, do not spill
water or liquid on the product.
10. Servicing - Refer all servicing to qualified service personnel. Servicing is required when the device has been damaged in any
way, such as the power-supply cord or plug is damaged, liquid has been spilled, objects have fallen into the device, the device
has been exposed to rain or moisture, does not operate normally or has been dropped.
11. Damage requiring service - If any of the following conditions occurs, unplug the power cord from the AC outlet and request a
qualified service technician to perform repairs.
a. When the power cord or plug is damaged.
b. When liquid is spilled on the product or when objects have fallen into the product.
c. When the product has been exposed to rain or water.
d. When the product does not operate properly as described in the operating instructions.
Do not touch the controls other than those described in the operating instructions. Improper adjustment of controls not
described in the instructions can cause damage, which often requires extensive adjustment work by a qualified technician.
e. If the product has been dropped or the cabinet has been damaged in any way.
f. When the product displays an abnormal condition or exhibits a distinct change in performance. Any noticeable abnormality in
the product indicates that the product needs servicing.
12. Replacement parts - In case the product needs replacement parts, make sure that the service person uses replacement
parts specified by the manufacturer, or those with the same characteristics and performance as the original parts. Use of
unauthorized parts can result in fire, electric shock and/or other danger.
13. Safety checks - Upon completion of service or repair work, request the service technician to perform safety checks to ensure
that the product is in proper operating condition.
14. Wall or ceiling mounting - When mounting the device on a wall or ceiling, be sure to install the product according to the method
recommended by the manufacturer. This is a safety issue.
15. Stand - Use only with the trolley stand or wall mount specified by the manufacturer, or sold with the device. Do not place the
product on an unstable trolley stand or wall mount. Placing the product on an unstable base can cause the product to fall,
resulting in possible serious injuries as well as damage to the device. When mounting the product on a wall, be sure to follow the
manufacturer’s instructions. Use only the mounting hardware recommended by the manufacturer.
Make sure you use all 4 bolts when placing a CTOUCH display on the Wallom2 lifts.
16. Careful move - When a trolley is used, be cautious when moving the trolley/device combination to avoid injury from the device
tipping over. Sudden stops, excessive force and uneven floor surfaces can cause the product to fall from the trolley.
Careful move and be careful please, point of strength should not in display screen. Never attempt to move the CTOUCH
interactive display unless the AC power cord has been disconnected.
17. Do not use this device near water - for example near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement or
near a swimming pool. The device should not be exposed to dripping or splashing liquids and that no objects filled with liquids,
such as vases, shall be placed on the device.Do not use immediately after moving from a low temperature to high temperature
environment, as this causes condensation, which may result in fire, electric shock, or other hazards.
18. Clean only with damp cloth - Unplug the device from the power before cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a soft cloth for cleaning. Please contact your dealer for our cleaning material or look at support.ctouch.eu for our cleaning
recommendations.
19. Ventilation - Do not block any ventilation openings. Install the CTOUCH interactive display in accordance with the manufacturer
instructions. The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these vents and
openings since insufficient ventilation can cause overheating and/or shorten the life of the product. This product is not designed
for built-in installation; therefore do not place the product in an enclosed space such as a bookcase or rack, unless proper
ventilation is provided or the manufacturer’s instructions are followed.
It should have interspace around the product and the wider it has the heat dissipation is better. Suggest up>10cm, around>10cm
and back >2.5cm.
20. Heat sources - Do not install near any heat sources such as radiators, heat registers, stoves, or other device (including amplifiers)
that produce heat.
21. Panel protection - The display panel used in this product is made of glass. Therefore, it can break when
the product is dropped or impacted upon by other objects. Be careful not to be injured by broken glass
pieces in case the display panel breaks.
Do not use hard or sharp object to take place of special pen when write in the screen.
Wipe the screen from one side to the other carefully till it looks completely clean.
Do not flailing in all directions.
22. Pixel defect - The display panel is a very high technology product, giving you fine detailed pictures. Occasionally, a few
non-active pixels may appear on the screen as a fixed point of blue, green or red. Please note that this does not affect the
performance of your product.
Warning! For continued safety, device with class I construction shall be connected to a mains socket outlet with a protective
earthing connection.

Leddura 2Share
76
Share, inspire, have fun!
With CTOUCH by your side. ctouch.eu
ABOUT LOCATION / ENVIRONMENT
Do not use in hot and cold rooms (locations)
•When the unit is used in rooms (locations) with low temperature, the picture may leave trails or
appear slightly delayed. This is not a malfunction. The unit will recover when the temperature
returns to normal.
•Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to
direct sunlight to near a heater or in high humidity, as this may cause the cabinet to deform and
the screen to malfunction and affect the CTOUCH interactive display’s performance.
•Environment condition:
- Operating temperature: 5°C – 35°C
- Operating humidity: 20% – 80% (no moisture condensation)
- Storage temperature: -15°C – 45°C
- Storage humidity: 10% – 80%
- Atmospheric pressure: 86 kPa ~106 kPa
ABOUT AFTER-IMAGE
The extended use of fixed image program material can cause a permanent after-image on the
screen. This background image is viewable on normal programs in the form of a stationary fixed
image. This type of irreversible screen deterioration can be limited by observing the following
steps:
A. Reduce the brightness/contrast setting to a minimum viewing level.
B. Do not display the fixed image for extended periods of time.
C. Turn the power off when the display is not in actual use.
Important Information Regarding Use of Video Games, Computers, Captions or Other Fixed
Image Displays.
•Do not allow a still picture to be displayed for an extended period of time, as this can cause a
permanent after-image to remain on the screen. Examples of still pictures include logos, video
games, computer images, teletext and images displayed in 4:3 mode.
Cautions!
•The permanent after-image on the screen resulting from fixed image use is not an operating
defect and as such is not covered by the warranty.
•This product is not designed to display fixed images for extended periods of time.
•It is not advised to put the screen in portrait mode because this will affect the warranty.
Cleaning and Maintenance
To clean this unit, wipe with a soft, dry cloth. Clean the cabinet with a soft, lint-free cloth. If the
cabinet is especially dirty, moisten a soft, lint-free cloth in a weak detergent Solution, squeeze the
excess moisture from the cloth, then wipe the cabinet with the cloth.
•Use a clean cloth to dry the cabinet.
•Use eyeglass cleaner to remove stubborn dirt from the screen.
•Never use alcohol, paint thinner or benzine to clean this device.
Carrying or Moving the CTOUCH interactive display
•When you move the CTOUCH interactive display, hold the frame of the CTOUCH interactive
display .
•Be aware of the danger or harm which may be caused by carrying or moving the CTOUCH
interactive display, as the bezel is very thin.
•When transporting, do not subject the unit to shocks or vibration, or excessive force.
Environmental Protection
The CTOUCH display should not be disposed of with household waste. Please recycle where
facilities exist. Or contact CTOUCH to return your CTOUCH display free of charge.

Leddura 2Share
98
Share, inspire, have fun!
With CTOUCH by your side. ctouch.eu
STANDARDACCESSORIES VESAMOUNTINSTALLATION
1. Contact a professional for assistance when wall mounting the CTOUCH interactive display.
We are not responsible for any damage to the product or injury to yourself, if you mount the
CTOUCH interactive display on your own.
2. Do not wall mount the CTOUCH interactive display while the CTOUCH interactive display is
turned on. It may cause personal injury due to electric shock.
3. Use standard M8 x 25 mm screws (4 pieces) to mount the CTOUCH interactive display.
Warning!
•Always be sure to ask a qualified technician to carry out set up. Incorrect fitting may cause
equipment to fall, resulting in injury and product damage. Any damage resulting from not having
a professional installer mount your unit will void your warranty.
•When any optional accessories or wall hanging brackets are used, always ensure that the
instructions provided are followed fully.
•Do not mount the unit directly below ceiling lights (such as spotlights or halogen lights) which
typically give off high heat. Doing so may warp or damage plastic cabinet parts.
•Take care when fixing wall brackets to the wall. Wall mounted equipment shall not be grounded
by metal within the wall. Always ensure that there are no electrical cables or pipes in the wall
before hanging bracket.
600mm (65"/75")
800mm (86")
400mm (65"/75")
600mm (86")
Depth of screw:
Minimum 22 mm
Maximum 25 mm
Screw for fixing the CTOUCH interactive
display onto the wall-hanging bracket.
(View from the side)
Unpacking
The following items are included in your product box.
CTOUCH interactive display
HDMI Cable
Remote Control
USB CableTouch pen pen
Quick Start Guide
AC Power Cord
Warranty Card
UK AC Power Cord
Welcome Letter
Note! the illustrations may differ slightly from the items shipped with your products.

Leddura 2Share
1110
Share, inspire, have fun!
With CTOUCH by your side. ctouch.eu
7
6
4
5
2
1
3
8 9
CONTROLPANEL CONNECTIONPANEL
NO. DESCRIPTION
1USB(2.0)(for camera) This port is for connecting a camera.
Notes!
1. Please open the dust cover before being used.
2. It can perfectly support camera’s up to 720p.
2Microphone Voice input.
3SCREEN CAST module Insert a SCREEN CAST module (Optional).
4OPS module slot Insert an OPS module (Optional).
5
CTOUCH Button
Power LED Red: In standby mode.
Blue: In power on mode.
Remote control sensor To control the display with the remote, aim it to this sensor.
Power Press to switch the CTOUCH interactive display on or off.
Note: When the CTOUCH interactive display is turned on, press the button in middle to show the main menu.
Press the button for about 2 seconds and the screen will go into stand-by mode.
6USB Connect USB devices to these ports.
7AC IN Plug the AC cord into this jack and into a power outlet.
(AC 100-240V 50/60Hz)
8Fuse 10A 250V
9Power Switch Push ( I ) to turn on the power, push (O) to cut off the power.
Note! Don’t cover the power switch.
1
2
3
4
5
4
6
7
8 9 10 113
NO. DESCRIPTION
1LAN 2(PoE+) LAN port for external devices (placed on the small VESA mount).
2USB 2.0 Connect USB devices to this port.
3TOUCH OUT 1/2 Output for external devices connected to HDMIx, DP or VGA ports which support touch
systems.
4HDMI1/2/3 INPUT Connect an HDMI device to this HDMI port.
HDMI3(ARC): Connect an ARC-enabled device to this HDMI port.
5USB 3.0 Connect USB devices to this port.
Note! The function differs depending on the model you have.
6DP(DisplayPort) INPUT Connect a DP device to this DP port.
7VGA INPUT Connect a VGA device to this VGA port.
8LAN 1 Connect a LAN cable to this LAN port.
9RS-232C For remote control.
10 S/PDIF digital audio output Connect a digital sound system to this S/PDIF jack.
11 Connect headphones to this jack.
Note! The current selected source is audible and internal speakers will be disabled.
Note! If the CTOUCH display is on the VGA source and does not get any signal, it will go into
stand-by mode after two minutes. When the CTOUCH display is on others sources and
does not get any signal, it will go into stand-by mode after 10 minutes.

Leddura 2Share
1312
Share, inspire, have fun!
With CTOUCH by your side. ctouch.eu
CONNECTIONS
CAUTIONS BEFORE CONNECTING
•When connecting an external device to the CTOUCH interactive display, make sure that the
CTOUCH and the external device are turned off.
•Check the plugs at the ends of the cables to make sure that they are the correct type before
plugging them into the jacks on the CTOUCH interactive display.
•Make sure that all plugs are securely inserted into the jacks. Loose connections can result in
image or color problems.
•The illustration of the external device may be different depending on your model.
•Refer to the operating manual of the external device as well.
A
A
C
C
B
B
Before using headphones,
adjust the device volume
to avoid excessive volume,
as hearing damage may
result
PC, etc.
VGA devices
Connect TOUCH OUT
with USB cable to PC
USB port. (A)
Connect TOUCH OUT with USB cable to PC USB port.
Connect PC with VGA cable, HDMI cable or DP cable. Please choose the proper
method of connection based on your device.
Note! After installation of the driver, it can control the external computer by
native touch control. (Only for PC, HDMI, DP signal)
A
A
USB devices
USB cable
Network cable
USB cable
HDMI cable
HDMI device
USB device
Network with PoE connection
USB cable
USB
cable
HDMI cable
DP cable
VGA cable
Audio cable
Headphone cable Audio input devices
Digital sound system
Network connection
Computer,
etc.
S/PDIF cable
Serial port cable
Network cable
HDMI cable HDMI devices
DP devices

Leddura 2Share
1514
Share, inspire, have fun!
With CTOUCH by your side. ctouch.eu
Switch the CTOUCH interactive
display power on or off
Confirm or enter a sub-menu
or toggle between options
during menu operation
Home page of the CTOUCH
interactive display
Display or exit the setting
menu screen
Mute the sound
Freeze the current picture
Volume down
Display or exit input source
menu
Use Arrow buttons to navigate
in on-screen menu
Return to previous menu or exit
the on-screen menu
Turn off the picture on the
CTOUCH interactive diaplay and
listen to the program audio only
Volume up
Freeze the current picture
REMOTECONTROL BASICOPERATIONS
TURNING THE CTOUCH INTERACTIVE DISPLAY ON OR OFF
1. Plug the power cord into an AC power outlet.
2. Switch the Power Switch on, to turn the CTOUCH interactive display on.
3. The display is in standby mode now. Wait a moment until the power indicator lights up, then
press to turn on the CTOUCH interactive display.
Note! Be sure to wait for a few seconds before pressing button. If you promptly press the
CTOUCH interactive display may act wrongly or not respond at all.
4. Press button again to put the display in standby mode.
5. Switch the Power Switch off to cut off the power completely.
Note! If the CTOUCH display is on the VGA source and does not get any signal, it will go into
stand-by mode after two minutes. When the CTOUCH display is on others sources and
does not get any signal, it will go into stand-by mode after 10 minutes.
FIRSTTIMEINSTALLATION
When turning on the CTOUCH display for the first time, the below shown installation menu pages
will appear on the screen.
WIRED
Plug the LAN-cable into the LAN-port on the bottom or side of the CTOUCH display, to connect to
the internet.
Select the desired menu
language. Press START to go to
the next page.
Select your location and press
NEXT to go to the next page.
Select your required Energy
Saving Mode and press NEXT
to finish the installation.

Leddura 2Share
1716
Share, inspire, have fun!
With CTOUCH by your side. ctouch.eu
OTAUPDATE
When you connect your display to thg internet, a notification will appear when a new firmware
update is available.
Note! A LAN-connection is required to update the display via OTA. If you do not have a LAN-cable
available, you can update the display by using a USB device. Please contact your dealer for
the USB update method firmware file.
Select the option you like.
Yes = See next photo.
No = The notification will
not appear again until
the next firmware
update.
Later = The next time you
turn on the display the
notification will appear
again.
Press on ‘Download’ to
download the firmware
update. After the download is
complete, the installation will
start automatically. This will
take about 10 minutes.
OPERATINGTHENAVIGATIONMENU
Slide up from the bottom of the screen center by two fingers or long press on the screen by five
fingers to call the Navigation Menu.
Display menu
Source menu
User Manual
Switch to HDMI
Display Setting menu,
here you can turn on or
off the Human Presence
Detection function.
Volume bar
Switch to default
application
Backlight mute function

Leddura 2Share
1918
Manual CTOUCH Wallom2 wall lift
Share, inspire, have fun!
With CTOUCH by your side. ctouch.eu
Picture Mode Select picture mode
Contrast Adjust the contrast
Brightness Adjust the brightness
Hue Adjust the image hue (Only for NTSC system)
Sharpness Adjust the sharpness
Saturation Adjust the color saturation
Backlight Set up the overall brilliance of the screen
Energy Save Mode The backlight brightness is decreased
VGA Screen Adjust
Clock Adjust the screen size
Phase Adjust the focus of stable images
H-Position Move the image right or left
V-Position Move the image up or down
Auto Adjust Automatically adjust the image settings such as position and phase
Blue Light Filter Set the blue light filter
Blue Light Level Set the blue light level
Color Temperature Select the color temperature
If you select User, you can set the level of the red/green/blue as your desired
Zoom Mode Select the aspect ratio (display proportions) according to your video signal type or
personal preference
OverScan Adjust the reproduction ratio, you may activate this function to obtain a cleaner picture
DISPLAYMENU
ADJUSTING PICTURE MODE ADJUSTING SOUND MODE
Sound
JBL® Sound Mode Select sound mode
Bass Adjust Bass (low sounds)
Treble Adjust Treble (high sounds)
Balance Adjust volume level of right and left speakers
AVC Select [On] to equalize overall volume levels across all channels
Select [Off] to turn off the auto volume control
JBL® LiveStage Turn the surround sound effect on or off
SPDIF Output Turn on or off
SPDIF Mode Select the digital audio output mode for S/PDIF
Select [RAW] to output audio signal as its original format
Select [PCM] to output audio signal by PCM format
SPDIF Volume Adjust SPDIF volume

Leddura 2Share
2120
Manual CTOUCH Wallom2 wall lift
Share, inspire, have fun!
With CTOUCH by your side. ctouch.eu
Setting
Auto Switch Source Select On to automatically recognition source
Color Range Select color range (Only for HDMI mode)
HDMI EDID Version Select HDMI EDID Ver.
HDMI ARC Select On to turn on enable HDMI ARC
Menu Timeout Select OSD menu display time
Date & Time Set current date and time
Off Timer Set Off Timer to switch the CTOUCH to standby at a specified day and time
On Timer Set On Timer to turn on the CTOUCH automatically to source at a certain day and time
Human Presence Detection (HPD) Turn HPD on or off. Note! to be able to use HPD the off timer should be scheduled first
Sleep Timer Set the duration of time until the monitor automatically goes into Standby mode [Off] /
[10 Minutes] / [20 Minutes] / [30 Minutes] / [60 Minutes] / [90 Minutes] / [120 Minutes] /
[180 Minutes] / [240 Minutes]
Set Password Password settings
Set Language Select on-screen language
Home Option Set the behavior of Home button
Edit Input
Rename Source Select the input source you want to label
Label Edit the label of the selected input source
Reset Reset labels to defaults
Touch Out 1 To Touch Out is there to define which touch signal output belongs to which input. E.g. if
Touch Out 1 is set to HDMI1 it means the touch signal output from Touch Out 1 belongs to
the input from HDMI1. When both ports are connected Touch Out 2 has priority by default
Touch Out 2 To
Embedded OS OTA Update Update COS system by OTA
Reset Display Menu Reset all Display Menu settings to factory defaults
DISPLAYMENU
ADJUSTING SETTING MODE
TROUBLESHOOTING
For contact information and full warranty conditions refer to support.ctouch.eu . If, after reading
these operating instructions, you have additional questions related to the use of your CTOUCH
interactive display, please check the symptoms below and follow the suggested solutions. If you still
have further questions, please visit support.ctouch.eu or call the services center in your local area.
PROBLEM POSSIBLE SOLUTION
Remote control does not operate • Make sure the CTOUCH interactive display is switched on
• Check the direction of the batteries
• The batteries could be low. Replace the batteries
PROBLEM POSSIBLE SOLUTION
No picture (screen not lit) and no
sound • Make sure the power cord is plugged in
• Press POWER on the CTOUCH interactive display or on the remote control
• Test another source
Dark, poor or no picture
(screen lit) but good sound • Select a proper picture mode
• Adjust the brightness in the video setting
• Test another source
No colour, dark picture or abnormal
colour • Adjust the colour saturation in the video setting
Good picture but no sound • The sound may be muted. Press MUTE again to cancel
• Verify if sound should output and/or test another source
Audio noise • Communication problems may occur if infrared communication equipment (e.g.,
infrared cordless headphones) is used near the CTOUCH interactive display. Move
the infrared communication equipment away from the CTOUCH until the noise is
eliminated
Remote Controle
Video and Audio

Leddura 2Share
2322
Manual CTOUCH Wallom2 wall lift
Share, inspire, have fun!
With CTOUCH by your side. ctouch.eu
TROUBLESHOOTING SPECIFICATIONS
PROBLEM POSSIBLE SOLUTION
Some items can not be accessed • If a setting option appears in grey, this indicates that the settings option is unavailable
in current input mode. Some display menu items may be different when the unit
works in different sources
Remote control command is not
working in some cases • During the timing of USB device detection (i.e. when the CTOUCH interactive display is turned on with USB device connected, or when you plug in USB device during the
working of the CTOUCH), the display may not react on remote control buttons in such
case. Wait a moment before the remote control should function again
Control buttons do not operate • Disconnect the power cord and wait for a few seconds. Then re-plug the power cord
and turn on the unit again
Touch does not work • If you use an Apple-device, please download the Mac-driver from our website
Fog appear on the screen • For the safety of screens, adding stalinite out of the screens. It is need to keep certain
space between two layers for reserving air passages generate cross-ventilation and
for insuring heat dissipation. Fog mainly comes from the temperature difference
between the screen and the external. Moisture streaks congeal when hot air meets
the low temperature glass surface The fog does not impact the normal use and it
disappears after several-hour usage
Screen puts itself in stand-by mode
as external device or Easy Air PC
goes in sleeping mode
• Change the energy settings/sleeping-mode of the external device or Easy Air PC
MODEL NO. CL2X-65UHD CL2X-75UHD CL2X-86UHD
Visible screen size 65 inch (diagonal) 75 inch (diagonal) 86 inch (diagonal)
Power Source AC 100-240V, 50/60Hz AC 100-240V, 50/60Hz AC 100-240V, 50/60Hz
Current Max. 1.7 A 2.8 A 3.6 A
Power Consumption 93 W 150 W 189 W
Standby condition * ≤ 0.5 W ≤ 0.5 W ≤ 0.5 W
Number of pixels
(Display panel )
3840×2160 3840×2160 3840×2160
Dimensions
(W×H×D) (Unit: mm)
1525×912×113 1745×1036×113 1991×1173×113
Weight 57 kg 70 kg 103 kg
Operating conditions Operating temperature: 5°C - 35°C, Storage temperature: -15°C - 45°C, Storage humidity:
10% - 80%
Operating humidity: 20 % - 80 % (no moisture condensation), Atmospheric pressure:
86kPa ~ 106kPa
CONNECTION TERMINALS OF THE CTOUCH INTERACTIVE DISPLAY
PC IN 1
HDMI Input 3
DP Input 1
USB 5
EARPHONE 1
LAN 1
LAN( PoE+) 1
TOUCH OUT 2
RS-232C 1
S/PDIF OUT 1
General
Note! If your problem is not solved, turn off your unit and then on again.
Cautions! Never attempt to repair a defective CTOUCH interactive display yourself.
Notes!
1. Design and specifications are subject to change without notice.
2. Weight and dimensions shown are approximate.
3. Specifications and external appearance may be changed for the sake of improvement.
*Due to different standby conditions, the standby power consumption of some models could be higher than 0.5W.
Changes or modifications void any warranty and exclude any liability. This user manual includes detailed instructions for your product. Figures
and illustrations in this user manual are provided for reference only and may differ from actual equipment appearance. Equipment design and
specifications may be changed without notice.
CTOUCH Europe BV - Achtseweg zuid 153 R, 5651 GW Eindhoven, The Netherlands

1315V190903_EN
ctouch.eu
Share, inspire, have fun!
With CTOUCH by your side.
