CTS ESW-3128 Series User manual

ESW-3128 Series
24 PORTS 10/100/1000BASE-T RJ-45 WITH 4
COMBO PORTS (10/100/1000BASE-T,
100/1000BASE-X SFP) UPLINK MANAGEMENT
SWITCH
User’s Guide
Version 0.91

2
FCC Warning
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with this user’s guide, may cause harmful interference
to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to
correct the interference at their own expense.
CE Mark Warning
This is a Class A product. In a domestic environment, this product may cause
radio interference in which case the user may be required to take adequate
measures.
Trademarks
CTS is a registered trademark of Connection Technology Systems Inc
All trademarks belong to their respective proprietors.
Contents are subject to change without prior notice.
Copyright Statement
Connection Technology Systems Inc Copyright © 1998-2015
This publication may not be reproduced as a whole or in part, in any way
whatsoever unless prior consent has been obtained from Connection
Technology Systems Inc.

3
Revision History
Version
Date
Description
0.90
20150610
First release
0.91
20150720
Key Feature Rearrangement

4
Table of Contents
1. INTRODUCTION ...........................................................................................5
1.1 The Managed Switch................................................................................5
1.2 Key Features............................................................................................6
1.3 Front & Rear Panel...................................................................................7
1.4 Cable Specifications.................................................................................7
1.5 Network Management ..............................................................................8
2. INSTALLATION...........................................................................................10
2.1 Requirement...........................................................................................10
2.2 Checking the Package Contents ............................................................10
2.3 Install the Managed Switch..................................................................... 11
2.4 Power ON...............................................................................................12
2.5 Connect the Switch to network...............................................................14
3. OPERATION................................................................................................15
3.1 LED Definitions.......................................................................................15
4. MAINTENANCE ..........................................................................................16
4.1 Fault Identification ..................................................................................16
4.2 Hardware Replacement Procedures ......................................................18
4.3 Firmware Upgrade..................................................................................18

5
1. INTRODUCTION
The Managed Switch is designed to meet the emerging FTTX & Metro Ethernet
requirement. Its low profile appearance with 1U height and standard rack-
mount size achieves the highest density within a single rack. When massive
fiber ports need to be deployed, the Managed Switch provides the best
performance and price ratio.
1.1 The Managed Switch
This Managed Switch is compact 19-inch, rack mountable, has 24 ports
10/100/1000Base-T RJ-45 with 4 combo ports (10/100/1000Base-T,
100/1000Base-X SFP) in front panel. This Managed Switch provides high
performance store and forward switching capability plus other advanced
features such as QoS, VLAN, etc.
Clear, at-a-glance per-port LED indicators make users easier to control and
manage network status. Built-in management module also allows users to
configure, control and monitor the system locally via console or remotely via
SNMP based management system.
This Managed Switch is a typical suit for the Metro Ethernet application. Its
low profile appearance with 1U height achieves the highest density and can be
used in closet wiring or used as a desktop switch.

6
1.2 Key Features
19 inch, 1U high
24 x 10/100/1000Base-T ports
-IEEE 802.3/802.3u/802.3ab/802.3z compliance
-Support Auto-Sensing for fiber ports
-Support MDI/MDIX/Auto-Crossover
-RJ-45 Ports
4 x 10/100/1000Base-T ,100/1000Base-X Combo ports
-IEEE 802.3ab/802.3z
-Support Auto-Negotiation (RJ-45) and Auto-Sensing (SFP)
-Support MDI/MDIX/Auto-Crossover
-RJ-45 or SFP Slot
Switching Features
-Store & forward switching
-Non-blocking switching fabric : 56Gbps
-Mac address table:16K
-Memory buffer total 1536K bytes
-VLANs support up to 2K VLAN Groups
-Support jumbo frame on all ports up to 9K bytes size
-QoS classification based on IEEE802.1p, VID, TOS/DSCP, Ethertype
and L4 port.
-Q-in-Q VLAN double tag
-Rate limit control
-SNTP time server
-Static multicasting
-IGMP v1/v2 snooping
-IGMP fast leave
-IGMP filtering via filtering profile
-Multicast channel limitations per port
-Multicast VLAN Register (MVR) **
-DHCP snooping
-DHCP client and auto-provision
-DHCP relay agent with option 82
-Access Control List (ACL)
Management Functions
- Console
- Telnet
- Web
- RADIUS authentication
-SNMP v1/v2 and network management
-SNMP Power-Down Trap
-Private, RFC-1213, RMON MIBs
-Port mirroring
- FTP, TFTP, HTTP server and client firmware upgrade
**Coming Soon

7
1.3 Front & Rear Panel
Front Panel
The front panel is configured as follows:
1. 24 x 10/100/1000Base-T RJ-45 ports (Ports 1-24)
2. 4 x Gigabit combo ports (Ports 25-28) :
4 x 10/100/1000Base-T RJ-45 ports, or
4 x 100/1000Base-X SFP ports
3. Reset Button:
Pressing reset button for 2 seconds then release to restart the
system.
Pressing reset button for 10 seconds then release to reset the
Managed Switch back to factory settings and restart the system.
4. Console port:
An asynchronous serial console port supporting the RS-232
electrical specification. The console port can be used to
manage the device and the interface should be configured to
9600 , N , 8 ,1
5. LED:
Please refer to chapter 3.1 LED Definitions
Rear Panel
The Managed Switch provides one fixed power module or two power modules
for redundancy purpose. Depending on your physical environment
requirements, the type of power module is selectable and could be either AC
input or DC input.
The rear panel is configured as follows:
Power module and Connector:
AC power connection: 100-240V , 50/60Hz
DC power connection: 48VDC
Please refer to chapter 3.1 LED Definitions
1.4 Cable Specifications
The following table contains various cable specifications for the Managed
Switch. Please make sure that you use the proper cable when connecting the
Managed Switch.
1
2
3
4
5

8
Cable Type
Description
10Base-T
UTP Category 3, 4, 5 (100 meters max.)
EIA/TIA- 568 150-ohm STP (100 meters max.)
100Base-TX
UTP Cat. 5 (100 meters max.)
EIA/TIA-568 150-ohm STP (100 meters max.)
1000Base-T
UTP Cat. 5e (100 meters max.)
UTP Cat. 5 (100 meters max.)
EIA/TIA-568B 150-ohm STP (100 meters max.)
100BASE-FX
Multi-mode fiber module(2km) / Single-mode fiber module
1000BASE-SX
Multi-mode fiber module (550m)
1000BASE-LX
Single-mode fiber module (10km)
1000BASE-LH
Single-mode fiber module (30km/50km)
1000BASE-ZX
Single-mode fiber module (80km)
Mini-GBIC
SFP Transceiver for 1000BASE-SX Multi-mode fiber module (550m)
SFP Transceiver for 1000BASE-LX Single-mode fiber module (10km)
SFP Transceiver for 1000BASE-LH Single-mode fiber module
(30km/50km)
SFP Transceiver for 1000BASE-ZX Single-mode fiber module (80km)
1.5 Network Management
This Managed Switch is Plug & Play compliant. Real-time operational status
can be monitored through a set of LED indicators located in the front panel.
Built-in management module also allows users to configure, control and monitor
the system remotely.
Following is a list of management options available in this Managed Switch:
Local Console Management
Telnet Management
SNMP Management
Web Management
Local Console Management
Users may connect a Terminal or PC with Terminal Emulation program, to the
Managed Switch RJ-45 port directly via RS-232 cable to configure, control and
monitor the system. This is often referred as Out-Of-Band management.
Console management is useful when there is no network connection to the
Switch, for instance configuring the Managed Switch for the first time.
Telnet Management
Telnet is done through the network. Once there is a network connection to the
Managed Switch, users can use Telnet to configure, control and monitor the
system. Using network connection to manage is often referred to In-Band-
Management.

9
SNMP Management
SNMP is also In-Band-Management and requires a network connection to the
Managed Switch. The Managed Switch private Management Information Bases
(MIB) is provided for SNMP-based network management program to configure,
control and monitor the system.
Web Management
Web Management is done over the network. Once the Managed Switch is
available on the network, you can login and monitor the status of it through a
web browser remotely or locally. Local console-type Web management,
especially for the first time use of the Managed Switch to set up the needed IP,
can also be done through one of the 10/100/1000Base-T 8-pin RJ-45 ports
located on the front panel of the Managed Switch. Direct RJ-45 LAN cable
connection between a PC and the Managed Switch is required for this
management.
Please refer to the Network Management User’s Manual for the detailed
management functions and required installation and operation procedures.

10
2. INSTALLATION
To properly install the Managed Switch, please follow the procedures listed
below. These procedures are described below in separate sections.
Installation Requirements
Unpacking the Managed Switch
Installing the Managed Switch
Power on the Managed Switch
Connecting the Managed Switch to the network
2.1 Requirement
Basic requirements for installation are as follows:
Environmental conditions
-One power outlet
-Proper ventilation
-Proper isolation to electrical noise, radio, etc.
-UTP cables should not run in the same duct with power and
phone line cables
Required SFP Transceiver or UTP cables
Rack mounting tools
2.2 Checking the Package Contents
Unpack the package carefully and check the package contents. The package
should contain the following items:
Standard
-One Managed Switch
-Mounting kit: 2 mounting brackets and screws (Fixed in the
Managed Switch when shipped)
-Four rubber feet with adhesive backing
-Console RS-232 cable with RJ-45 connector
-Documentation CD
-AC power cord (For AC power module only)

11
If any item is found missing or damaged, please contact your local sales
representative for support or replacement.
2.3 Install the Managed Switch
CAUTION
To prevent any damage or failure of the Managed Switch, please DO
NOT block the ventilation FAN holes.
Use the following guidelines when choosing a place to install the Switch:
Firm and steady flat surface.
Proper power outlet location, not too far from the device.
Visually inspect the power cord and see that it is secured to the AC
power connector.
Make sure that there is proper heat dissipation from and adequate
ventilation around the switch. Do not place heavy objects on the
Managed Switch.
Desktop Installation
The switch can be placed in any flat and steady surface with proper air
ventilation. Four rubber feet with adhesive backing are provided for installation.
Procedure
1. Attach rubber feet on the bottom at each corner of the device.
2. Select a flat and steady surface and place the switch.
3. Allow adequate space for ventilation between the device and the
objects around it.
Rack Installation
WARNING!
Please mount the Switch firmly in rack otherwise it may be fall and
cause the system damage and possible injury to personnel.

12
The Managed Switch can be mounted in an EIA standard-sized, 19-inch rack,
which can be placed in a wiring closet with other equipment. Rack mounting
brackets are provided to mount the Switch.
Procedure
1. Plan the rack position.
2. Attach the mounting bracket on the switch’s side panels (one on each
side) and secure them with the screws provided.
3. Align the Switch with mounting bracket into the selected mounting rail
position.
4. Then, use the screws provided with the equipment rack to mount the
switch into the selected mounting rails position carefully and firmly.
5. Please ensure that the ventilation holes are not blocked.
2.4 Power ON
The Managed Switch can be used with AC power supply 100-240 VAC, 50 –60
Hz or DC power supply 48V. The power switch is located at the rear of the unit
adjacent to the power connector.
After the Managed Switch is turned on, the Power LED indicators should light in
green and the FAN should spin.

13
Power Failure
In the event of power failure, unplug the power that is plugged into the switch at
the back of the device. When power is resumed, plug the power back to the
switch.

14
2.5 Connect the Switch to network
Connect to Network
The Managed Switch has 24 RJ-45 and 4 combo ports in front panel. These 24
RJ-45 ports can be plugged with 10/100/1000Base-T UTP connector. Uplink
combo ports 25-28 can be plugged with 155Mbps, 1.25Gbps SFP Fiber
transceiver or 10/100/1000Base-T UTP connector. The connection of the fiber
port must be matched, i.e. Transmitter to Receiver and vice versa.

15
3. OPERATION
The Managed Switch is Plug & Play compliant. Real-time operational status
can be monitored through a set of LED indicators located in the front panel. A
built-in management module provides users flexible interfaces to configure,
control and monitor the complete system remotely.
3.1 LED Definitions
Front Panel
Power A/B LED
The Power A/B has two LED indicators. The upper one is for internal Power A
and lower one is for internal power B.
LED
Color
Operation
PWR A/B
Off
Without fixed-in power module or power is off.
Green
Power module is in normal operation.
Orange
Fixed-in Power module is no longer receiving power or DC output
fails.
Status LED
The Managed Switch status is indicated by the Status LED on the front panel of
the device.
LED
Color
Operation
Status
Green
The device is in normal operation.
Orange
The device is booting up.
Press the Reset button for 5 seconds and then release to restart the
system. The LED indicator will blink in green for three times.

16
Orange Blinking
Press the Reset button for 10 seconds and then release to reset
(back to factory settings) and restart the system. The LED indicator
will blink in orange for three times.
COM LED
The console status is indicated by the Console LED on the front panel of the
device.
LED
Color
Operation
COM
Off
Out-of-band management via console port is activated.
Green
When Console port is connected.
Port LED 1~24
LED
Color
Operation
Link/ACT/Speed
Off
No connection
Green
The link is up and the speed is in 10 or 100Mbps
Orange
The link is up and the speed is in 1000Mbps.
Blinking
Green/Orange
Traffic is present.
TP & F/O LED 25~28
LED
Media
Type
Color
Operation
Link/ACT/Speed
TP
Off
No connection or the port link speed is in 10Mbps.
Green
The link is up and the speed is in 100Mbps.
Orange
The link is up and the speed is in 1000Mbps.
Blinking
Green/Orange
Traffic is present.
F/O
Off
No connection.
Green
The link is up and the speed is in 100Mbps.
Orange
The link is up and the speed is in 1000Mbps.
Blinking
Green/Orange
Traffic is present.
4. MAINTENANCE
This Managed Switch is easy to maintain. The procedures are suggested when
you want to identify faults, perform hardware replacement and Firmware
upgrade.
4.1 Fault Identification
Identifying faults can greatly reduce the times required to find problem and
solution. Users may perform local check or remote check to find the problems.
Local Check
Users can perform local check by observing LED indicators status or check
system setup and configuration through console connection.

17
When the whole system fails to function,
1. Check Power LED status
2. Check Power connection
3. Reset power
When certain network link fails to function,
1. Locate the port of the switch
2. Check LINK/ACT/Speed LED of the port
3. Check Status LED of the port
4. Check cable connection between the port and the connected device
5. Reset power
When local Console fails to function,
1. Check COM LED status
2. Check Console port connection
3. Check Console configuration
4. Reset power
Remote Check
Users may check the Managed Switch through SNMP manager remotely. For
detailed procedures, please refer to the network management User’s Manual.

18
4.2 Hardware Replacement Procedures
WARNING!
The Managed Switch contains no user-serviceable parts. DO NOT,
UNDER ANY CIRCUMSTANCES, open and attempt to repair it.
Failure to observe this warning could result in personal injury or death
from electrical shock.
Failure to observe the above warning will immediately void any
Warranty.
4.3 Firmware Upgrade
This Managed Switch may perform Firmware upgrade when required. New
Firmware can be obtained from your sales representative. Please check the
Network Management User’s Manual for the detailed upgrade procedures.
