CTS WAS-2006 Series User manual

Trademarks
CTS is a registered trademark of Connection Technology Systems
Inc. Contents subject to revision without prior notice.
All other trademarks remain the property of their owners.
Copyright Statement
Copyright Connection Technology Systems Inc.
This publication may not be reproduced as a whole or in part, in
any way whatsoever unless prior consent has been obtained from
Connection Technology Systems Inc.
FCC Warning
WAS-2006 Series Ethernet Switches have been tested and found
to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These standards are designed to
provide reasonable protection against harmful interference when
these devices are operated in a commercial environment. These
devices generate, use, and can radiate radio frequency energy and
may cause harmful interference to radio communications unless
installed in accordance with this User’s Guide. Operation of these
devices in a residential area is likely to cause harmful interference
which will make the user responsible for the appropriate remedial
action at his / her own expense.
CE Mark Warning
These are Class A products. In a domestic environment these
products may cause radio interference in which case the user will
need to consider adequate preventative methods.
1. Checklist
The package should contain the following items:
-
WAS-2006 Ethernet Switch
-
User’s Guide
-
Installation Guide
Please notify your sales representative immediately if any item is
missing or damaged.
As for power adapters, please refer to Section 7 for more detailed
information.
2. Overview
WAS-2006 Series Ethernet Switches are designed to meet the
massive needs for Fast Ethernet network deployments and aim at
industrial applications that demand wide range of operating
temperature. WAS-2006 Ethernet Switches are fully compliant with
IEEE802.3, 802.3u and 802.3x standards. Via single mode fiber
cable, they are able to extend a copper-based network to a
maximum distance up to 100KM.
Besides, redundant AC and DC power supplies are both offered on
WAS-2006 Series Ethernet Switches for users to create a reliable
and stable network in the event of power failure. They can also
be mounted on the wall or onto 35mm DIN rail using DIN rail clip
on the Ethernet switch. The installation and operation procedures
are simple and straightforward. Operation status can be locally
monitored through a set of diagnostic LED indicators located on
the front panel.
Major Features:
3. Network Installation
Please follow the steps described below and refer to Figure 1 and
2 to complete the network installation.

Attach fiber cable from WAS-2006 to the fiber network.

Attach a UTP cable from the 10/100Base-TX network to the
RJ-45 port on WAS-2006.

Connect the power adapter to WAS-2006 and the Power LED
will light up. The Link/ACT/Speed and F/O Link/ACT LEDs will
light up as soon as all the cable connections are satisfactory.
Figure 1. Network Installation for WAS-2006FX Models
Figure 2. Network Installation for WAS-2006WDM/SFP Models
4. Terminal Block
TB1 and TB2 Power Supply: There are two pairs of contacts on
the terminal block connector for power redundancy purpose. You
can use both pairs of power supply for redundancy purpose or use
either one pair of power supply on the terminal block and AC
external power supply to create redundant setup. The redundant
power supply will take over seamlessly when one power source is
down to protect your device or network from the loss of power.
When you use only one power supply (no redundant power is
available), the Power/Port Status LED will light up in orange to alert
the user.
Figure 3. Terminal Block Front and Top View
Port Fault Alarm: One pair of port fault connection on the
terminal block is used to connect alarm devices such as speakers
or LEDs to alert users when the F/O port link is disconnected.
-
Auto-Negotiation in TP port
-
Store and Forward Switching Mechanism
-
Support Full/Half duplex mode operation
-
Support MDI/MDIX Auto-Crossover
-
Support Flow Control
-
Support alarms for power and F/O port failure
-
Support 2K MAC address table
-
Support 80K bytes Memory Buffer
-
Support wide range of operating temperature (-20oC~60oC)
-
Support DIN Rail and Wall Mounting
-
Support redundant AC and DC power supply
Connect to
100BASE-FX
Fiber Network
Connect to
10/100BASE-TX
Network
Use flat-head
screwdriver to
loosen and tighten
the screw.
Insert positive or
negative wire as
indicated.
TX/RX
Connect to
10/100BASE-TX
Network
Connect to SC/ST
100BASE-FX
Fiber Network
TX
RX

5. LED Description
6. Technical Specifications
Standards
IEEE 802.3, 802.3u, 802.3x
Interface
5 X Shielded 10/100Base-TX RJ45
1 X 100Base-FX
LED
PWR, PW T1, PW T2, F/O Link/ACT
PWR/Port Status , Link/ACT/Speed
Power
DC Input Voltage: 12/48VDC
DC Power Jack x 1; DC Terminal Block x 2
Shipping Weight
0.4KG
Dimensions
105mm(W)X93mm(D)X61mm(H)
Temperature
Operating: -20oC~60oC; Storage: -20oC~70oC
Humidity
5%~90% RH non-condensing
EMC Safety
FCC Part 15 Class A, CE
Media
TP:
EIA/TIA-568 CAT 5e
Fiber:
50/125, 62.5/125um multi-mode fiber
9/125, 10/125um single-mode fiber
7. Optional Accessory
Power Adapters:
MODEL
Connector Type
Volt/Watt
WAP-POWER-12J18
DC Jack
12V/18W
WAP-POWER-48J90
DC Jack
48V/90W
WAP-POWER-48D75
Terminal Block
48V/75W
WAP-POWER-48D240
Terminal Block
48V/240W
Fiber Transceiver Information
100M
Multi-Mode
TYPE
BTFC
BTFT
Connector Type
SC
ST
Wavelength
1310nm
1310nm
Typical Distance
2Km
2Km
Min TX PWR
-20.0dBm
-20.0dBm
Max TX PWR
-14.0dBm
-14.0dBm
Sensitivity
-31.0dBm
-31.0dBm
Link Budget
11.0dB
11.0dB
Single-Mode
TYPE
BTFC
(SM-30)
BTFC
(SM-50)
BTFC
(SM-80)
BTFC
(SM-100)
Connector Type
SC
SC
SC
SC
Wavelength
1310nm
1310nm
1310nm
1550nm
Typical Distance
30Km
50Km
80Km
100Km
Min TX PWR
-15.0dBm
-5.0dBm
0dBm
-5.0dBm
Max TX PWR
-8.0dBm
0dBm
5.0dBm
0dBm
Sensitivity
-34.0dBm
-35.0dBm
-36.0dBm
-35.0dBm
Link Budget
19.0dB
30.0dB
36.0dB
30.0dB
Wave-Length WDM
TYPE
W2A
(SM-20)
W2B
(SM-20)
W2A
(SM-40)
W2B
(SM-40)
Connector Type
SC
SC
SC
SC
TX Wavelength
1310nm
1550nm
1310nm
1550nm
RX Wavelength
1550nm
1310nm
1550nm
1310nm
Typical Distance
20 Km
20 Km
40 Km
40 Km
Min TX PWR
-14.0dBm
-14.0dBm
-8.0dBm
-8.0dBm
Max TX PWR
-8.0dBm
-8.0dBm
0dBm
0dBm
Sensitivity
-31.0dBm
-31.0dBm
-34.0dBm
-34.0dBm
Link Budget
17.0 dB
17.0 dB
26.0 dB
26.0 dB
NOTE: Specifications may change without prior notice.
Contact Information
Connection Technology Systems INC (CTS)
18F-6, No.79, Sec.1, Xintai 5th Rd., Xizhi Dist.,
New Taipei City 221, TAIWAN, R.O.C.
TEL: [phone] FAX: [phone]
E-Mail: [email protected]
WAS-2006 Series
5 Ports 10/100Base-TX
and 1 Port 100 Base-FX
Uplink Fast Ethernet
Switch with Extended
Operating Temperature
User’s Guide
Version 1.4
LED
Color
Function
PWR
Green
AC or DC power is available.
PW T1
Green
Terminal Block 1 powers up.
PW T2
Green
Terminal Block 2 powers up.
F/O
Link/ACT
Green
F/O link is up.
Blinking
Green
F/O is receiving and transmitting data.
PWR/Port
Status
Orange
F/O link is down.
Blinking
Orange
Redundancy system is abnormal (only one
power source is available).
Link/ACT/
Speed
Off
Link is down or TP works in 10M.
Green
TP link is up and works in 100M
Blinking
Green
TP is receiving and transmitting data.
