CTS ESW-5128 Series User manual

ESW-5128 Series
L2 Managed Switch with 24-port
10/100/1000Mbps Downlink and 4-port
1/10Gbps SFP+ Uplink
User’s Guide
Version: 1.0

ii
Revision History
Version
Date
Changes
1.0
08/17/2022
First release
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with this user’s guide, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at their own expense.
CE Mark Warning
This is a Class A product. In a domestic environment, this product may cause radio interference in
which case the user may be required to take adequate measures.
Trademarks
CTS is a registered trademark of Connection Technology Systems Inc.
All trademarks belong to their respective proprietors.
Contents subject to change without prior notice.
Copyright Statement
Connection Technology Systems Inc Copyright © 1998-2022
This publication may not be reproduced as a whole or in part, in any way whatsoever unless prior
consent has been obtained from Connection Technology Systems Inc.

iii
CTS Contact Information
▓Headquarters/Manufacturer:
Connection Technology Systems Inc.
18F-6, No.79, Sec.1, Xintai 5th Rd.,
Xizhi Dist., New Taipei City 221,
Taiwan(R.O.C.)
Tel: [phone]
Fax: [phone]
Sales Direct Line:[phone]
www.ctsystem.com
▓Global Offices:
Connection Technology USA
40538 La Purissima Way,
Fremont, CA 94539, USA
Tel: [phone]
Sales Direct Line: [phone]
E-mail:[email protected]
Connection Technology Systems Japan
Higobashi Bldg. No.3 R201, 1-23-13,
Edobori, Nishi-ku, Osaka 550-0002, Japan
Tel: [phone]
E-mail: [e-mail]
Connection Technology Systems NEAB
August Barks Gata 21,
421 32 Västra Frölunda, Sweden
Tel: [phone]
E-mail: [email protected]
Connection Technology Systems
Central Europe (COMPONET
Handels GmbH)
Hirschstettner Straße 19-21/Stiege I
A-1220 Vienna, Austria
Tel: [phone]
E-mail: [e-mail]

iv
Table of Contents
Revision History ...................................................................................................................................................... ii
CTS CONTACT INFORMATION..................................................................................................................... III
TABLE OF CONTENTS........................................................................................................................................IV
CHAPTER 1. INTRODUCTION......................................................................................................................... 2
1.1 OVERVIEW OF ESW-5128..........................................................................................................................................................2
1.2 KEY FEATURES ....................................................................................................................................................................................3
1.3 FRONT &REAR PANELS................................................................................................................................................................5
1.3.1 FRONT PANEL ...........................................................................................................................................................................5
1.3.2 REAR PANEL ..............................................................................................................................................................................7
1.4 LED DEFINITIONS.............................................................................................................................................................................8
1.5CABLE SPECIFICATIONS ............................................................................................................................................................... 10
CHAPTER 2. INSTALLATION ......................................................................................................................... 11
2.1 INSTALLATION REQUIREMENTS................................................................................................................................................ 12
2.2 CHECKING THE PACKAGE CONTENTS................................................................................................................................... 12
2.3 INSTALLING THE MANAGED SWITCH.................................................................................................................................... 13
2.3.1 DESKTOP INSTALLATION ................................................................................................................................................... 13
2.3.2 RACK INSTALLATION ........................................................................................................................................................... 14
2.3.2.1 INSTALL THE MANAGED SWITCH IN A RACK ............................................................................................ 14
2.3.3 WALL-MOUNTING INSTALLATION ............................................................................................................................... 15
2.4 GROUNDING THE MANAGED SWITCH................................................................................................................................. 17
2.5 POWERING ON THE MANAGED SWITCH ............................................................................................................................ 18
2.6 CONNECTING THE MANAGED SWITCH TO THE NETWORK ....................................................................................... 18
2.7 INSTALLING AND REMOVING SFP/SFP+ MODULES................................................................................................... 18
2.7.1 INSTALLING SFP/SFP+ MODULES............................................................................................................................. 18
2.7.2 REMOVING SFP/SFP+ MODULES.............................................................................................................................. 19
2.8 CONNECTING THE SWITCH TO CONSOLE PORT ............................................................................................................. 19
CHAPTER 3. OPERATION................................................................................................................................ 20
3.1 NETWORK MANAGEMENT ........................................................................................................................... 20
CHAPTER 4. MAINTENANCE ........................................................................................................................ 22
4.1 FAULT IDENTIFICATION .................................................................................................................................. 22

v
4.1.1 LOCAL CHECK ........................................................................................................................................ 22
4.1.2 REMOTE CHECK ..................................................................................................................................... 23
4.2 HARDWARE REPLACEMENT PROCEDURES .................................................................................................. 23
4.3 FIRMWARE UPGRADE.................................................................................................................................... 23

Publication date: August 17, 2022
Revision 1.0 1
About this manual
In this user’s guide, it will not only clearly introduce CTS ESW-5128 Managed Switch but tell you
how to install this Managed Switch with detailed instructions.
Organization of the Manual
Chapter 1 “Introduction” describes the features of the Managed Switch
Chapter 2 “Installing the Managed Switch”
Chapter 3 “Operation”
Chapter 4 “Maintenance”

Introduction
Publication date: August 17, 2022
Revision 1.0
2
1
Introduction
CTS’s Managed Switch is designed to meet the emerging FTTX & Metro Ethernet requirements.
Besides the low profile appearance with 1U height and the standard rack-mounted size, the product
also achieves hassle-free monitoring and comprehensive management for any network operator
who desires to build up a reliable telecommunication network infrastructure. When it comes to FTTX
deployment, the Managed Switch provides the best performance and price ratio.
1.1 Overview of ESW-5128
The product is a 19-inch and rack mountable Managed Switch, equipped with 24 Gigabit Ethernet
ports (10/100/1000Base-T) and 4 SFP+ uplink ports (1/10GBase-R) on the front panel. This
Managed Switch provides high performance, store and forward switching capability plus other
advanced features such as QoS, VLAN, Spanning Tree, LACP and so on.
LED indicators located on the front panel ease the users’ effort to monitor and manage the network
status. The built-in management module also allows users to configure, control and monitor the
system locally via console or remotely via SNMP-based management system.
This Managed Switch is a typical SFP/SFP+ solution to FTTX service implementation. Besides, it
can be used as a stand-alone switch. With the height of 1U and the standard-size rack design in
appearance, the network switch can be used in closet wiring as well.

Introduction
Publication date: August 17, 2022
Revision 1.0 3
1.2 Key Features
19 inch, 1U high
24 x 10/100/1000Base-T ports
-IEEE 802.3/802.3u/802.3ab compliance
-Support Auto-Negotiation
-Support MDI/MDIX/Auto-Crossover
-RJ-45 Interface
4 x 1/10GBase-R SFP+ ports
-IEEE 802.3z compliance
-IEEE 802.3ae 10Gb/s Ethernet
-Support Auto-Speed for fiber port
-SFP+ Slot
Switching Features
-Store & forward switching
-Non-blocking switching fabric:128Gbps
-Mac address table:16K
-Packet buffer total 12Mbit
-VLANs support up to 4K VLAN Groups
-802.1Q Tunneling (QinQ)
-VLAN Translation
-Support jumbo frame on all ports up to 12K bytes size
-QoS classification based on IEEE802.1p, TOS/DSCP
-Rate limit control
-NTP client
-Static multicasting
-IGMP v1/v2/v3 snooping
-IGMP fast leave & query
-MLD v1/v2 snooping
-IGMP filtering via filtering profile
-Multicast channel limitations per port
-DHCP snooping
-DHCP client and auto-provision
-DHCP relay agent with option 82
-Access Control List (ACL)
-Rapid Spanning Tree Protocol (RSTP)
-Link Layer Discovery Protocol (LLDP)
-IEEE 802.1X Authentication
-IPv6 over Ethernet
-IPv6 Addressing Architecture
-IPv6 Dual Stack
-Storm Control
-MAC Limiter
-CPU temperature alarm notification
-L2PT (Layer 2 Protocol Tunneling)
-Sticky MAC Address function

Introduction
Publication date: August 17, 2022
Revision 1.0
4
-Support the internal power voltage monitoring for the system diagnostics
-Support MVR (Multicast VLAN Registration)
Management Functions
- Console
- Telnet & SSH/CLI
- Web (HTTP & HTTPS)
- RADIUS/TACACS+ for authentication
-SNMP v1/v2c/v3 and network management
-SNMP Power-Down Trap
-Private, RFC-1213, RMON MIBs
-Port mirroring
-FTP, TFTP, HTTP server and client firmware upgrade
Operation Environment
- Operating Temperature: 0ºC~50ºC
Power Requirement
- Input AC: 100V ~ 240V, 50/60Hz, 0.48 ~ 0.25A
- Input DC: 48V (Range: 44 ~ 52V), 0.5A
- Max. Power Consumption: 24W (81.8BTU/h)
Dimension & Weight
- Size: 440 x 231 x 44mm (W x D x H)
- Weight (Max.): 3.17kg
EMC/Safety
- FCC Class A, CE

Introduction
Publication date: August 17, 2022
Revision 1.0 5
1.3 Front & Rear Panels
1.3.1 Front Panel
The interfaces on the front panel of the Managed Switch are described below:
1. 24 x 10/100/1000Base-T RJ-45 downlink ports (Ports 1-24)
2. 4 x 1/10GBase-R SFP+ uplink ports (Ports 25-28)
3. Console Port:
An asynchronous serial console port supports the RS-232 electrical specification.
The console port can be used to manage the device, and the serial console port
settings should be configured as 9600, 8, n, 1.
4. Digital Input (Dry Contact):
A voltage-free connector that is used to decide whether the trigger occurs or not by
detecting its open/close status. The configuration is as follows:
- Open: Logic Level 0
- Close: Logic Level 1
5. Reset Button:
Press the reset button for 5~10 seconds, then release it to restart the system.
Press the reset button for more than 10 seconds, then release it to reset the
Managed Switch. The settings will be back to the factory defaults and restart the
system.
4
1
3
Figure 1-1. The Managed Switch Front Panel
5
6
1
2

Introduction
Publication date: August 17, 2022
Revision 1.0
6
6. LEDs:
Includes Power LEDs, COM LED, Status LED, LEDs of TP 1~24 ports and LEDs of
SFP+ 25~28 ports. For more details on LEDs description, please refer to Section
1.4 LED Definitions.

Introduction
Publication date: August 17, 2022
Revision 1.0 7
1.3.2 Rear Panel
The Managed Switch provides one fixed power module or two fixed power modules for redundancy
purpose. Depending on your physical environment requirements, the type of power module is
selectable and could be eitherAC input or DC input.
The interface on the rear panel of the Managed Switch is described below:
7. Power module and Connector:
AC power connection: 100V ~ 240V, 50/60Hz, 0.48 ~ 0.25A
DC power connection: 48V (Range: 44 ~ 52V), 0.5A
8. Ground Screw (For more information, please refer to Section 2.4)
Figure 1-2. The Managed Switch Rear Panel
7
6
8

Introduction
Publication date: August 17, 2022
Revision 1.0
8
1.4 LED Definitions
The Managed Switch is Plug & Play compliant. The real-time operational status can be monitored
through a set of LED indicators located on the front panel.
Figure 1-3. LEDs of the Managed Switch
Power A/B LED
The power status of the Managed Switch is indicated by the Power A/B LED on the front panel of
the device.
LED
Color
Operation
Power A/B
OFF
No fixed-in power module exists or power is off.
Green
Lit when power module is in normal operation.
Orange
Fixed-in power module is no longer receiving power or
DC output fails.
Status LED
The Managed Switch status is indicated by the Status LED on the front panel of the device.
LED
Color
Operation
Status
Green
Lit when the device is in normal operation.
Orange
Lit when the device is booting up or press the Reset
button for 5~10 seconds and then release to restart the
system.
Blinking when pressing the Reset button for more than
10 seconds and then release to reset (return to factory
default settings) and restart the system. The LED
indicator will blink in orange color for three times.
Figure 1-3. LEDs of FOS-5128 Managed Switch

Introduction
Publication date: August 17, 2022
Revision 1.0 9
COM LED
The console status is indicated by the COM LED on the front panel of the device.
LED
Color
Operation
COM
OFF
Either the console port is not activated or no session exists.
Green
Lit when the console port is activated and the session exists.
TP 1~24 Port LEDs
LED
Color
Operation
Link/ACT/
Speed
OFF
No connection exists.
Green
Lit when the 10/100Mbps port link is up.
Blinking when the port is receiving and transmitting data at the
speed of 10/100Mbps.
Orange
Lit when the 1000Mbps port link is up.
Blinking when the TP port is receiving and transmitting data at
the speed of 1000Mbps.
SFP+ 25~28 Port LEDs
LED
Color
Operation
Link/ACT/
Speed
OFF
No connection.
Orange
Lit when the 1Gbps port link is up.
Blinking when the port is receiving and transmitting data at
the speed of 1Gbps.
Blue
Lit when the 10Gbps port link is up.
Blinking when the port is receiving and transmitting data at
the speed of 10Gbps.

Introduction
Publication date: August 17, 2022
Revision 1.0
10
1.5 Cable Specifications
The following table contains various cable specifications for the Managed Switch. Please make sure
that you use the proper cable when connecting the Managed Switch.
Cable Type
Description
100BASE-FX
Multi-mode fiber module(2km) / Single-mode fiber
module
1000BASE-SX
Multi-mode fiber module (550m)
1000BASE-LX
Single-mode fiber module (10km)
1000BASE-LH
Single-mode fiber module (30km/50km)
1000BASE-ZX
Single-mode fiber module (80km)
SFP Transceiver
SFP Transceiver for 1000BASE-SX Multi-mode fiber
module (550m)
SFP Transceiver for 1000BASE-LX Single-mode fiber
module (10km)
SFP Transceiver for 1000BASE-LH Single-mode fiber
module (30km/50km)
SFP Transceiver for 1000BASE-ZX Single-mode fiber
module (80km)
10GBASE-SR
Multi-mode fiber module (26m or 400m)
10GBASE-LR
Single-mode fiber module (10km)
10GBASE-ER
Single-mode fiber module (40km)
10GBASE-LRM
Multi-mode fiber module (220m)

Installation
Publication date: August 17, 2022
Revision 1.0 11
2
Installation
To properly install the Managed Switch, please follow the procedures listed below. These
procedures will be respectively described in detail in the following sections.
Installation Requirements
Checking the Package Contents
Installing the Managed Switch
Grounding the Managed Switch
Powering on the Managed Switch
Connecting the Managed Switch to the Network
Installing and Removing SFP/SFP+ Modules
Connecting the Switch to Console Port

Installation
Publication date: August 17, 2022
Revision 1.0
12
2.1 Installation Requirements
Basic requirements for installation are as follows:
Environmental conditions
One power outlet
Proper ventilation
Proper isolation to electrical noise, radio, etc.
Required SFP/SFP+ Transceiver
Rack mounting tools
2.2 Checking the Package Contents
Unpack the package carefully and check the package contents. The package should contain the
following items:
One set of the Managed Switch
19-inch rack-mount kit (fixed onto the Managed Switch when shipped)
- Two pieces of rack ears
- Eight pieces of M3 x 4mm flat head screws
Four rubber feet with adhesive backing
Console RS-232 cable with RJ-45 connector
Documentation CD
AC power cord (for AC power module only)
If any item is found missing or damaged, please contact your local sales representative for support
or replacement.

Installation
Publication date: August 17, 2022
Revision 1.0 13
2.3 Installing the Managed Switch
You can install the Managed Switch on a flat surface or mount it in a standard 19-inch network
equipment rack.
CAUTION
To prevent any damage or failure of the Managed Switch, please DO NOT block
the ventilation holes.
Use the following guidelines when choosing a place to install the switch:
Firm and steady flat surface.
Proper power outlet location, not too far from the device.
Visually inspect the power cord and see that it is secured to the AC power connector.
Make sure that there is proper heat dissipation from and adequate ventilation around the
switch. Do not place heavy objects on the Managed Switch.
Note:
The product appearance in the following diagrams might differ from the actual device as different equipment
is used to showcase the installation examples.
2.3.1 Desktop Installation
The switch can be placed in any flat and steady surface with proper air ventilation. Four rubber feet
with adhesive backing are provided for this kind of installation.
Procedures
➊Attach rubber feet on the bottom at each corner of the device.
➋Select a flat and steady surface to place the switch.
➌Allow adequate space for ventilation between the device and the objects around it.

Installation
Publication date: August 17, 2022
Revision 1.0
14
2.3.2 Rack Installation
In the following section, we will take a Managed Switch for example to install a 19-inch switch in a
standard 19-inch network equipment rack.
WARNING!
Please mount the Switch firmly in rack, otherwise it may fall and cause the
system damage and possible injury to personnel.
2.3.2.1 Install the Managed Switch in a Rack
The Managed Switch can be mounted in an EIA standard-sized, 19-inch rack, which can be placed
in a wiring closet with other equipment. Rack mounting brackets are provided to mount the Switch.
Just follow the procedures listed below for step-by-step instructions to install your switch in this rack
space:
Step 1. Plan the rack position.
Step 2. Align the mounting holes in the brackets with the desired holes in the rack, and insert
suitable screws (not provided along with the Managed Switch) through each bracket and
into the rack. (See Figure 2-1)
Step 3. Then, tighten the screws with the screwdriver to secure mounting brackets to the rack.
Step 4. Please ensure that the ventilation holes are not blocked.
Figure 2-1. Switch Rack-mounting

Installation
Publication date: August 17, 2022
Revision 1.0 15
2.3.3 Wall-Mounting Installation
Besides the aforementioned methods, to mount the Managed Switch on the wall is quite easy,
please also follow the procedures listed below for step-by-step instructions.
Step 1. Remove the supplied rack mounting brackets from the switch:
1.1. Unscrew the screws from each bracket at both sides of the switch. (See Figure 2-2)
Step 2. Attach the supplied rack mounting brackets to the switch in the direction shown on the
figure 2-3:
2.1. Refer to the figure 2-3 to attach the supplied rack mounting bracket to one side of the
switch that you would like to install on the wall.
2.2. Also refer to the figure 2-3 to attach the supplied rack mounting bracket to the other
side of the switch.
Step 3. Insert the M3 x 4mm flat head screws provided in the rack-mount kit through each
bracket and into the bracket mounting holes in the switch. (See Figure 2-3)
Figure 2-2. Remove brackets for the Managed Switch Wall-mounting
