Cuckoo CP-P011 User manual

CP-P011
User Manual
WATER
PURIFIER
온수
잠금
HOT
LOCK
ROOM
COLD

2
온수
잠금
HOT
LOCK
ROOM
COLD
Dear customers,
Thank you for purchasing CUCKOO Water Purier.
Please keep this manual (including the Warranty).
This manual will be of great help when you have any question or when the
functions do not work properly.
Product Benets
Characteristics and Merits of CUCKOO Water Purier
This manual includes the warranty.
Please read this User manual before using the product. After reading this manual, keep it in a place that is easily
accessible to the user for future reference.
Caution : This product is for household use, and other uses (industrial, experimental, etc.) are prohibited.
In order to use this product for a long time without malfunction, please read this User Manual.
Nanopositive Filtering System
The Nanopositive ltering system provides clean and healthy mineral water.
Direct Flow Water Purier for Clean Water
This water purier does not contain a storage tank, instead it employs instantaneous heating and cooling methods to
provide hot, cold, or room temperature water immediately after the water has been ltered.
A Sophisticated Water Purier with Multiple Functions and Slim Design
The slim, compact and sophisticated design allows for efficient use of space without sacrificing the most important
functions of a water purier.
Electrolytic Sterilization System
This product employs an electrolytic sterilization system to ensure constant hygiene. You can sterilize the product
anytime you want.
Economical and Eco-Friendly Water Filtration System
By using the Nano Positive Filter we have created a highly economical, eco-friendly and zero waste water filtration
system.
Button Lock / Functional Lock
The product features a button lock and functional lock to prevent misuse by children or the elderly.
Water Leak Prevention System
The product is made to detect/block water leaks during use to ensure safe use of the Water Purier.
Non-Stop Flow Function
You can continuously dispense cold water, hot water, and room temperature water.
Fixed Quantity Dispensing
Highly Convenient function allowing you to dispense a xed quantity of a single cup (around 150cc(5.1oz)) or a half cup
(around 110cc(3.7oz)) of cold water, hot water or room temperature water.

온수
잠금
HOT
LOCK
ROOM
COLD
Characteristics and Merits of CUCKOO Electric
Water Purier
Safety Warnings
Cautions for Safe Use
Part Names/Accessories
Filtration Circuit / Water Filtration System
Details to Check before Use
How To Use
How To Clean Tray / How To Clean Main Body
How To Replace the Filters
Expected Filter Replacement Cycle /
Recommendations / Filter Arrangement
Please check before asking for Support
Product Specications
2
4 ~ 7
8 ~ 9
10 ~ 11
12
13
14 ~ 25
26 ~ 27
28
29
30 ~ 31
32
Before Use
During Use
Before Asking for
Support
Service Guide
CONTENTS

온수
잠금
HOT
LOCK
ROOM
COLD
온수
잠금
HOT
LOCK
ROOM
COLD
4
Do not use an attachable
multi-power outlet.
•It may cause a fire or electric shock.
About the Power Supply
!
Warning (Prohibited)
Safety Warnings
● Please comply with the ‘Warnings for Safe Use’ as they are provided to ensure safe and proper use of the device and
prevent accidents and dangerous situations.
● The ‘Warnings for Safe Use’ section is divided into ‘Warning’ and ‘Caution,’ which are defined as follows:
!
!
!
Warning
!
Caution
• This symbol indicates a potentially dangerous situation under
specific circumstances.
• Please read the details carefully and follow the instructions to
avoid dangerous situations.
• This symbol is used to indicate actions that are 'prohibited'.
• This symbol is used to indicate 'instructed' actions.
Potentially dangerous situation that can cause
serious injuries or death if not avoided.
Potentially dangerous situation that can cause
minor injuries if not avoided.
•If you use it with a lot of products, it may cause a fire or an electric
shock.
•Please check the power outlet regularly.
•If it is not properly grounded, it may cause electric shock due to short
circuit.
•If there is a foreign substance or moisture on the Power Plug, wipe it
thoroughly before use.
Please use the product
only with a Power Outlet
exclusively for 120V with
at least a rating of 15A and
when properly grounded.
Do not plug multiple devices
into the same Power Outlet
simultaneously.
•If the sheath of the Power Cord is peeled off or chopped during use
due to negligence, it may cause a fire or electric shock. Thus, please
check the state of the Power Cord, Power Plug and Power Outlet
frequently.
•To prevent dangerous situations arising from the damage of the
Power Cord or the Power Plug, please contact the manufacturer,
distributor or certified technician (servicemen) for replacement.
•We strongly recommend that the damaged parts be repaired at a
designated service center.
•It may cause electric shock, short circuit, and fire.
If a Power Cord or a Power
Plug is damaged or when
the Power Outlet is shaky,
stop using the product
and contact our Customer
Service Center.
•It may cause electric shock or fire.
Please check the Power Plug frequently.
If there is any moisture, dust,
or foreign substances on the
Power Plug, remove them
with a dry cloth.
•It may cause a fire or electric shock.
If you use a movable
extension cord, use only
a single product for an
extension cord of 15A of
current capacity and ensure
that it is properly grounded.
Do not bend, tie or pull the
Power Cord by force.
•Due to electric shock or short
circuit,
it may cause electric shock or fire.
Please check the Power Plug frequently.

온수
잠금
HOT
LOCK
ROOM
COLD
온수
잠금
HOT
LOCK
ROOM
COLD
5
About the Power Supply
!
Warning (Prohibited)
ENG
Safety Warnings
When unplugging the
product, make sure to hold
the Power Plug, not the
Power Cord.
•Applying force to the Power Cord may cause electric shock or fire.
Please check the Power Plug and the Power Cord frequently.
Use only one for the
altemating current voltage
of 120V.
•It may cause electric shock or fire.
•The product will not work properly.
•Please check the Power Plug and the Power Cord frequently.
When inserting or pulling
out the Power Plug to and
from the Power Outlet, first
remove any moisture on
your hands and then put in
or pull out the Power Plug by
holding the Power Plug.
•Pulling out the Power Plug with wet hands can cause electric shock.
•Pulling the power cord by excessive force can damage the Power
Cord, causing a short circuit or electric shock.
•Please check the Power Plug and the Power Cord frequently.
When you do not intend to
use the product for a long
time, first close the Tap
Water Supply Valve, and
pull out the Power Plug.
•To reuse, first operate the Immediate Sterilization function and then
use the product.(Refer to page 18)
•Before reuse, refer to the 'Details To Check before Use.' (page 13)
If water enters the power
supply area, unplug
the product and dry it
completely before use.
•It may cause electric shock or fire.
Please check the Power Plug and the Power Cord frequently.
In case of water leaks or
cleaning, first close the Tap
Water Supply Valve, and
then pull out the Power
Plug.
•There is a risk of electric shock or malfunction.
Please check the Power Plug and the Power Cord frequently.
Make sure the Power Cord
is not under a heavy object
or near sharp objects.
Take special caution to
ensure that it is not easily
damaged by your pet.
•If you do not do so, it may cause damage to the Cord, leading to
electric shock or fire.
Please check the Power Cord frequently.
Please also unplug the
product before inspection,
repair or replacement of its
parts.
•There is a risk of malfunction
or electric shock.
Please check the Power Plug and the Power Cord frequently.

온수
잠금
HOT
LOCK
ROOM
COLD
온수
잠금
HOT
LOCK
ROOM
COLD
6
Do not install the product near the bathroom.
Do not place it in an uneven
or slanted area. Please avoid
placing it on a rug, cushion or
laminated floor.
•It may cause malfunction, unwanted noise or injury.
Please check the product regularly if it is working properly.
•It may cause product damage and fire.
•The Purifier is a fixed product, so please use it fixed.
Cooling
Water
16.4 feet or less
8” or longer
8” or longer
Avoid direct sunlight and high
temperature.
•It may cause color changes or
discoloration.
•Please check the Power Cord frequently.
Cooling
Water
16.4 feet or less
8” or longer
8” or longer
Cooling
Water
16.4 feet or less
8” or longer
8” or longer
Cooling
Water
16.4 feet or less
8” or longer
8” or longer
Cooling
Water
16.4 feet or less
8” or longer
8” or longer
Make sure that the length of
Tap Water Supply Tube
doesn’t exceed 16.4 feet
from the Tap Water Supply
Valve.
•If the tube is longer than 16.4 feet,
it may cause poor performance of the product.
Cooling
Water
16.4 feet or less
8” or longer
8” or longer
Install the product on a firm
and flat floor with a distance
of 8 inch or longer from the
wall.
Do not place it in an area
where there’s a risk of a gas
leak or near a heating device.
Always use the installed
plumbing for the tap water
and install the Tap Water
Supply Valve near the
Cooling Water Pipe.
Avoid places where the
temperature goes below 41℉
and the outdoors.
Cooling
Water
16.4 feet or less
8” or longer
8” or longer
Do not install where it may
be exposed to moisture,
excessive dust, and
splashing water.
•Install the product in a clean environment.
•It may cause a malfunction, electric shock or fire. •If you do not do so, it may cause poor performance of the product.
•There is a risk of explosion or fire.
•Do not use water sources other than the tap water, such as ground
water.
•Filter change cycle can vary according to the region and capacity of
water use.
•Connecting the valve to the hot water pipe may cause damage to the
filter or breakdown of the product.
•It may cause the filter, tubing or any other
components to freeze, causing malfunction of the product.
•The temperature of environment for using the product should be
41~104℉.
Cooling
Water
16.4 feet or less
8” or longer
8” or longer
Installation Guide
Safety Warnings
!
Warning (Prohibited)

온수
잠금
HOT
LOCK
ROOM
COLD
온수
잠금
HOT
LOCK
ROOM
COLD
7
• It may cause a water leak.
Close the Tap Water Supply
Valve when replacing the filters.
(Tap Water Supply Valve is
normally under a sink)
잠금
원수차단밸브
Please be careful when
dispensing the hot water.
•Do not allow hot water
to come in contact
with the hands, and supervision
is required when the appliance
is being used by children or the
elderly.
고객상담실
고객상담실
고객상담실
고객상담실
Safety Warnings
During Use
Do not place any heating
devices such as a microwave
oven, electric oven or toaster,
or other inflammables such
as candles, gas containers,
and lighters on top of the
product.
Do not pull the Power Cord
or hose, nor grab the Faucet
when moving the product.
•There is a risk of fire, electric shock or accidents.
•It may cause damage to the product.
Do not place chemicals,
water bottles or small
metal materials on top of
the product.
Do not disassemble or
remodel the product.
•They could fall into the product and
potentially cause a fire or damage the product.
•It may cause a fire or electric shock.
•Do not let anyone else other than
our service technicians to disassemble or collect the product.
!
Warning (Prohibited)
고객상담실
고객상담실
If water leaks from the inside
of the product or water has
gathered around the product,
close the Tap Water Supply
Valve, turn off the power
supply, pull out the Power
Plug, and then contact our
Customer Service Center
If you smell burning or see
smoke arising from the
product, unplug it immediately
and close the Tap Water
Supply Valve. After that,
please contact our Customer
Service Center
The product should be installed and removed by our
service technicians through the Customer Service Center.
Prevent the air intake hole, air discharge hole, and other
gaps from being blocked or having foreign substances
such as a needle, cleaning pin and metals stuck inside.
•If you do not do so, it may cause an electric shock or fire.
If you rub the veggie water valve with a brush
or scrubber, the plating may be damaged and
it may cause mineral adherence.
•There is a risk of electric shock. •It may cause a fire.
!
Caution (Instruction)
Pay attention to children or anyone who controls the
Control Panel, make sure they don’t use it improperly.
•It may cause a disorder of the product and accidents.
Close
ENG

온수
잠금
HOT
LOCK
ROOM
COLD
8
온수
잠금
HOT
LOCK
ROOM
COLD
If you have not used the
product for a long time, first
operate the Immediate
Sterilization Function once
before use.
•You can conveniently clean the
ducts and the cooling water tank by using the Immediate Sterilization
Function. (Refer to page 18)
Replace the Filters according
to the replacement cycle.
•If you do not do so, it may cause
poor filter performance or bad odor.
•Refer to page 29 for the filter
replacement cycle.
When gas or propane leaks,
do not pull out the Power
Cord of the product but
immediately open the
windows to ventilate.
•It may cause a fire or electric shock.
Make sure the Cooling Water
Tank Cover inside the
product and the Top Cover
are completely closed
before use.
•It’s also to keep foreign material away.
Please avoid using the dispensed water for filling a fish
bowl or an aquarium.
•The room water may not be suitable for breeding fish.
They could die depending on the circumstances.
Do not clean the product
using benzene or thinner.
•There is a risk of damage to the product.
During use, do not pull out
the Hose on a rear side of
the product.
•It may cause a water leak, leading
to a malfunction of the product.
Do not move the product while
operating the product.
•Do not move or shake the product
when it’s turned on. It may cause the
connecting tube to be separated, leading
to a malfunction of the product and water leak.
Do not lean the product at a 30-degree angle or more
when moving the product.
•It may cause poor performance of the product.
Must not use NON-Cuckoo Water Purifier filters.
•If you use a filter other than an authentic CUCKOO filter, it may cause
a lowered water-purifying performance, abnormal taste of water,
water leak, and malfunction of the product.
Cautions for Safe Use
!
Caution (Instruction)
!
Warnings (Prohibited)

온수
잠금
HOT
LOCK
ROOM
COLD
온수
잠금
HOT
LOCK
ROOM
COLD
9
ON
OFF
식수
ON
OFF
Drinking
Water
ON
OFF
식수
ON
OFF
식수
ON
OFF
식수
ON
OFF
식수
This product is exclusively for 120V, so always use a Power Outlet exclusively for 120V while being properly
grounded.
When you use an extension cord (such as a multi-power outlet), do not simultaneously connect any other product.
Failure to ground may cause electric shock due to short circuit. Be sure to only use the product after grounding.
❶
In case of a power outlet with a grounding terminal
When there is a grounding terminal, you can immediately use the power outlet without any extra work.
❷
In case of a power outlet with no grounding terminal
First, check if an earth leakage breaker is installed. If there is no earth leakage breaker, install one before using the
product. If there is no earth leakage breaker, it may cause a fire.
During Use
Cautions for Safe Use
Keep packing materials such
as Styrofoam and vinyl away
from children's reach.
Do not connect to anything
other than the Tap Water
(Drinking Water) Supply
Pipe.
Avoid damaging the
Refrigerant Circuit.
Do not randomly connect an apparatus to reduce a
pressure to the Hot Water Apparatus Pipe.
•It may cause a malfunction of the product.
Prevent children from
climbing or hanging on the
product.
Do not install the product in
places listed below:
Do not repeatedly operate
the Hot Water Outflow and
the Stop functions.
•It may cause suffocation.
•Water other than the tap water
(drinking water) may cause diseases.
•It may cause a malfunction or
a reduced lifespan of the product.
•It may cause a malfunction of the product.
•It may cause the product to fall down,
leading to injury of the children.
•Outdoors
•A place exposed to direct sunlight
•Near a bathroom
•In front of a cooler or a heater
•A slanted place
•It may cause a malfunction of the product. In particular, it may cause
steam.
!
Caution (Instruction)
ENG

온수
잠금
HOT
LOCK
ROOM
COLD
온수
잠금
HOT
LOCK
ROOM
COLD
10
< Front & Back >
Part Names
Part names
<Top Side>
SELECT MODE SELECT
LOCK
(3SEC) ENERGY SAVE/
SETTING
(3SEC)
HALF
CUP
ONE
CUP
NON-
STOP
HOT
TEMP.
TIME/
STERILIZE
(3SEC)
FILTER
RESET
(3SEC)
HOT
LOCK
ROOM
COLD
Function Operation
and Display
Cold Water /
Hot Water /
Room Water Select
and Outflow button
External Faucet end plug
Power Cord
Drain
Tap Water Supply
Faucet

온수
잠금
HOT
LOCK
ROOM
COLD
온수
잠금
HOT
LOCK
ROOM
COLD
11
Name of Parts
Accessories
<Details of Display Panel>
Water Purifying
SELECT MODE SELECT
LOCK
(3SEC) ENERGY SAVE/
SETTING
(3SEC)
HALF
CUP ONE CUP NON- STOP HOT TEMP. TIME/ STERILIZE
(3SEC)
FILTER
RESET
(3SEC)
HOT
LOCK
ROOM
COLD
User Manual Service Card External Valve (Optional) Sterilizing Cup
(If it is lost, contact to Customer
Service Center to purchase a
new one.)
Room Water (Outflow Light : WHITE) &
Cold Water (Outflow Light : BLUE)
Select Button
Outflow button
Hot Water (Outflow Light : RED)
Select Button
Faucet
Time Display
Half Cup Button
One Cup
Button
Non-Stop button Hot Temp Button
Select/Energy Save/
Setting Button
Filter Reset button
Time/Sterilize Button
Select Mode/Lock button
ENG

온수
잠금
HOT
LOCK
ROOM
COLD
온수
잠금
HOT
LOCK
ROOM
COLD
12
Filtration Circuit / Filtration System
Filtration Circuit
Electrolytic
Sterilization
Module
Water
Supply
Valve Water
Sensor
Motor
Sensor
Cold
Water
Tank
Cooling
Water
Supply Ball
Valve
Film
Heater
Hot Outlet Valve
tank Drain External Valve
External
Faucet
Room Water Outflow Valve
Cold Water Outflow Valve
Level Stir
Temperature Sensor
Tap Water
External
Valve
4INCH 4INCH 4INCH
①②③
Flow
Meter
Filter Door Lock Lever
Set Step Name Filter Function
1
1
Sedi Carbon Composite Removes rust, floating matter, residual chlorine and heavy metals (lead)
2Natural Plus Removes fine particles, general germs, residual heavy metals
(mercury, iron, aluminum), and norovirus.
3Nano Positive Provides a mineral infusion to create a healthy alkaline water.
2
1
Pre Carbon 2.0 Removes particulate matter and residual chlorine
2Nano Positive Provides a mineral infusion to create a healthy alkaline water.
3
Alkali-Mineralizer Generates alkali and mineral water, improve water taste
※ Using a NON-Cuckoo filter or other unauthorized filter for a long time may result in diminished filter performance.
Step 1 Step 2 Step 3
Filtration System

온수
잠금
HOT
LOCK
ROOM
COLD
온수
잠금
HOT
LOCK
ROOM
COLD
13
❺
❹
Empty the tray on a regular basis.
❶
Open the Tap Water Supply Valve.
▶ Open the Tap Water Supply Valve, and check if there is water leak
on each connection part.
• Tap Water Supply Valve and the Tap Water Input and the Exterior of the
product.
Open
Details to Check before Use
Details to Check before Use
Plug in the product.
▶ This product exclusively uses 120V 60Hz. Please make sure to
plug it into the proper power outlet.
❸
AC 120V
Switch the Filter Door Lock on the left of the product
towards the close sign. (to let the tap water flow
internally)
• When the Filter door lock is closed, water is supplied to the product.
❷
Filter
Door
Lock
Lever
Close
Please clean and replace the Filters on a regular
basis.
▶Please clean and replace the filters regularly so that you can
always enjoy pure and clean water.
▶ Refer to page 29 for the filter replacement cycle.
ENG

온수
잠금
HOT
LOCK
ROOM
COLD
온수
잠금
HOT
LOCK
ROOM
COLD
14
❶
Waiting Mode
▶ It is an Outflow Waiting mode to dispense cold water, room temperature water, and hot water. The Display
on the front are turned ON according to the selected function such as either cold water or room temperature
water.
❷
User Setting Mode
▶ You can set the function by pressing the [Energy Save/Setting] button for three seconds While in the waiting
status.
User Setting Mode
When pressing [Select Mode/Lock] once Filter replacement alarm setting
When pressing [Select Mode/Lock] twice Sterilization alarm setting
When pressing [Select Mode/Lock] three times Single Cup Outflow Setting Function
When pressing [Select Mode/Lock] four times Half Cup Outflow Setting Function
When pressing [Select Mode/Lock] five times Voice Volume Setting Function
When pressing [Select Mode/Lock] six times Mood Lamp ON/OFF Function
When pressing [Select Mode/Lock] seven times Automatic Filter Cleaning Function
When pressing [Select Mode/Lock] eight times Current Time Setting Function
When pressing [Select Mode/Lock] nine times Language Setting Function
❸
Fixed Quantity Outflow
▶ Press the [Outflow] button once and then the water of the selected fixed quantity will be dispensed.
▶ Select the [Half Cup] button and press the [Outflow] button for 110cc(3.7oz) of water to be dispensed.
▶ Select the [One Cup] button and press the [Outflow] button for 150cc(5.1oz) of water to be dispensed.
▶ Select the [Non-Stop] Flow button and press the [Outflow] button for the water to be dispensed continuously.
❹
Manual Outflow
▶ The water is dispensed while you are pressing the [Outflow] button.
▶ Press the [Outflow] button for two seconds, and the product will be converted into the Manual Outflow
status. And the water will be dispensed while you are pressing the [Outflow] button.
How To Use
How to Set Functions

온수
잠금
HOT
LOCK
ROOM
COLD
온수
잠금
HOT
LOCK
ROOM
COLD
15
How To Use
How to Set Cold Water Function
HOT
LOCK
ROOM
COLD
※ You can dispense the cold water in about one hour after you have turned ON the Cold Water function.
※ The function is set to be ON as the default setting of the product.
❶
If the Cold Water function is turned OFF, press the [Room/
Cold]button for three seconds to turn ON the Cold Water
function.
▶ While you are pressing the [Room/Cold] button, the Voice Guide will say
“Selecting Cold water function.”
▶When the Cold Water function is turned ON, the word “ON” will be
displayed, and the Voice Guide will say “Cold water function selected.”
❷
If you do not want to use the cold water, turn OFF the Cold
Water function by pressing the [Room/Cold] button for three
seconds while the Cold Water function is ON.
▶ While you are pressing the [Room/Cold] button, the Voice Guide will say “Canceling
Cold water function.”
▶ When the Cold Water function is turned OFF, the word “OFF” will be displayed, and the Voice Guide will
say “Cold water function Cancelled.”
▶ If you press the [Room/Cold] button while the Cold Water function is turned OFF, the Voice Guide will say
“Cold water function off,” “Please turn on cold water function before use.”
ENG
How To Dispense Cold Water
❶
Press the [Room/Cold] button to select cold water.
▶ The Voice Guide will say "Cold Water."
❷
In order to use the fixed quantity outflow,
▶ Select the desired quantity from among the buttons of [Half Cup], [One Cup] and
[Non-Stop].
▶ Press the [Outflow] button once. The cold water will be dispensed.
▶ When the selected quantity of water is completely dispensed, the water dispensing will end.
▶ If you press the [Outflow] button or any other button while the product is dispensing the selected quantity of
water, the water dispensing process will end.
❸
If you want to operate the Manual Outflow,
▶ Press the [Outflow] button. The cold water will be dispensed.
▶ If you press the [Outflow] button for two seconds or longer, the status of
the product will be changed into the Manual Outflow status.
▶ The Voice Guide will say "Water dispensing during pressing."
▶ If you stop pressing the [Outflow] button during the Manual Outflow, the water dispensing will end.
❹
While the cold water is being dispensed, the Blue Mood light on the Faucet will be turned
ON. (When the Mood function is turned OFF, the light will not be turned ON.)
HOT
HOLD
SELECT MODE SELECT
LOCK(3SEC) ENERGY SAVE/
SETTING(3SEC)
HALF
CUP
ONE
CUP
NON-
STOP
HOT
TEMP.
TIME/
STERILIZE(3SEC)
FILTER
RESET(3SEC)
ROOM
COLD
HOT
LOCK
ROOM
COLD

온수
잠금
HOT
LOCK
ROOM
COLD
온수
잠금
HOT
LOCK
ROOM
COLD
16
How To Use
How To Dispense Room Water
How to Set Hot Water Lock Function
This function prevents children from randomly operating the product and
getting burnt. If this function is selected, the [Hot/Lock] button won't work.
❶
If you press the [Hot/Lock] button for three seconds in the Waiting
status, the Hot Water Lock will be selected.
▶ If you press the [Hot/Lock] button in the Hot Water Lock status, “Loc_”will be
displayed and the Voice Guide will say “Child lock on.”
▶ If you press the [Hot/Lock] button for three seconds in the Hot Water Lock
status, “Un_Loc_” will be displayed and the Hot Water Lock will be released.
HOT
LOCK
ROOM
COLD
❶
Press the [Room/Cold] button to select room water.
▶The Voice Guide will say “Room Temperature Water.”
❷
In order to use the fixed quantity outflow,
▶ Select the desired quantity from among the buttons of [Half Cup], [One Cup] and
[Non-Stop].
▶ Press the [Outflow] button once. The room water will be dispensed.
▶ When the selected quantity of water is completely dispensed, the water dispensing will end.
▶ If you press the [Outflow] button or the selected fixed quantity button again while the product is dispensing
the fixed quantity of water, the water dispensing will be ended.
❸
If you want to operate the Manual Outflow,
▶ Press the [Outflow] button. The room water will be dispensed.
▶ If you keep pressing the [Outflow] button for two seconds or longer,
the product will be changed into the Manual Outflow status.
▶ The Voice Guide will say “Water dispensing during pressing.”
▶ If you stop pressing the [Outflow] button during the Manual Outflow, the water dispensing will end.
❹
While the room water is being dispensed, the Green Mood Light on the Faucet will be
turned ON. (When the Mood function is turned OFF, the light will not be turned ON.)
HOT
HOLD
SELECT MODE SELECT
LOCK(3SEC) ENERGY SAVE/
SETTING(3SEC)
HALF
CUP
ONE
CUP
NON-
STOP
HOT
TEMP.
TIME/
STERILIZE(3SEC)
FILTER
RESET(3SEC)
ROOM
COLD
HOT
LOCK
ROOM
COLD
To use hot water after installation
❶
Press the [Hot/Lock] water button and press the [Outflow] button.
▶“Start water input installation check” voice will follow
▶Water outflow will stop when product check is done
▶“Product installed successfully” voice will follow
❷
Hot water can be used after product installation is completed.
HOT
LOCK
ROOM
COLD

온수
잠금
HOT
LOCK
ROOM
COLD
온수
잠금
HOT
LOCK
ROOM
COLD
17
How To Use
How to Use Hot Water
❶
Select the hot water function by pressing the [Hot/Lock] button.
▶ The Voice Guide will say “Hot Water.”
❷
In order to use the fixed quantity outflow,
▶ Select the desired quantity from among the buttons of [Half Cup], [One Cup] and
[Non-Stop]
▶ Press the [Outflow] button once. After preheating, the hot water will be dispensed.
▶ When the selected quantity of water is completely dispensed, the water dispensing will end.
▶ If you press the [Outflow] button or any other button while the product is dispensing the chosen quantity of
water, the water dispensing will end.
❸
If you want to operate the Manual Outflow,
▶ Press the [Outflow] button. Hot water will be dispensed.
▶ If you press the [Outflow] button for two seconds or longer, the
product will be set to Manual Outflow status.
▶ The Voice Guide will say “Water dispensing during pressing.”
▶ If you stop pressing the [Outflow] button during the Manual Outflow, the water dispensing will be ended.
❹
While the hot water is being dispensed, the Red Mood Light on the Faucet will be
turned ON. (When the Mood function is turned OFF, the light will not be turned ON.)
※ There is risk of burns due to spattering of water from the product. Thus, please put the cup near the Faucet.
※ After the product is installed and you dispense the first cup of hot water, lukewarm water will be dispensed.
(After the first cup, hot water will be dispensed.)
HOT
HOLD
SELECT MODE SELECT
LOCK
(3SEC) ENERGY SAVE/
SETTING
(3SEC)
HALF
CUP
ONE
CUP
NON-
STOP
HOT
TEMP.
TIME/
STERILIZE
(3SEC)
FILTER
RESET
(3SEC)
ROOM
COLD
HOT
LOCK
ROOM
COLD
How To Set Hot Water Temperature (Custom Hot Water)
▶ Each time you press the [Hot Temp] button, the temperature of hot water will be
changed by around 18℉.
104℉ → 122℉ → 140℉ → 158℉ → HOT (Maximum Temperature)…
[40℃ → 50℃ → 60℃ → 70℃ → HOT (Maximum Temperature) …]
▶ Select the [Non-Stop] button and press the [Outflow] button,
and then the selected temperature of hot water will be dispensed.
▶ If you press the [Outflow] button or any other button while the product is
dispensing hot water, the water dispensing will end.
❶
HOT
HOLD
SELECT MODE SELECT
LOCK
(3SEC) ENERGY SAVE/
SETTING
(3SEC)
HALF
CUP
ONE
CUP
NON-
STOP
HOT
TEMP.
TIME/
STERILIZE
(3SEC)
FILTER
RESET
(3SEC)
ROOM
COLD
HOT
LOCK
ROOM
COLD
ENG

온수
잠금
HOT
LOCK
ROOM
COLD
온수
잠금
HOT
LOCK
ROOM
COLD
18
❶
If the [Time/Sterilize] Button Display Light is turned
ON in the Waiting status, the Sterilization Preset
function is set to be used.
❷
Press the [Time/Sterilize] Button while the [Time/
Sterilize] Button Display Light is turned OFF.
▶ The Voice Guide will say “Auto Sterilization Reservation Set-up Completed.”
▶ The Sterilization/Preset Button Display Light will be turned ON.
❸
Select the desired preset time by pressing the [Time/Sterilize] Button.
▶ Each time you press the [Time/Sterilize] Button, the preset time will be changed by one hour.
(After one hour → After two hours → … → After 10 hours → After one hour → …)
❹
After selecting the desired Sterilization Preset time, save the preset time by pressing
the [Energy Save/Setting] button.
(When you use the Sterilization Preset function, always mount the Sterilizing Cup.)
How To Use the Sterilization Preset function
HOT
HOLD
SELECT MODE SELECT
LOCK(3SEC) ENERGY SAVE/
SETTING(3SEC)
HALF
CUP
ONE
CUP
NON-
STOP
HOT
TEMP.
TIME/
STERILIZE(3SEC)
FILTER
RESET(3SEC)
ROOM
COLD
❶
Place the Sterilizing Cup.
❷
Press the [Time/Sterilize] Button for about three
seconds in the Waiting status.
▶ The product will immediately start the sterilization, and the Voice
Guide will say “Start Auto Sterilization.”
▶ The [Time/Sterilize] Button Display Light will be turned ON, and the sterilization progress will be displayed.
❸
In order to cancel the sterilization operation, press the [Time/Sterilize] Button while
the product is operating the sterilization.
▶ The Voice Guide will say “Auto Sterilization Cancelled” and the sterilization cancellation will be operated.
▶ The Display Panel will show the sterilization cancellation status.
※ After the operation is completed. remove the Sterilizing Cup.
※ Sterilizing water is not drinking water. Prevent anyone from drinking the sterilizing water.
How To Use the Immediate Sterilization function
HOT
HOLD
SELECT MODE SELECT
LOCK(3SEC) ENERGY SAVE/
SETTING(3SEC)
HALF
CUP
ONE
CUP
NON-
STOP
HOT
TEMP.
TIME/
STERILIZE(3SEC)
FILTER
RESET(3SEC)
ROOM
COLD
How To Use
When Sterilization Recommended Alarm is prolonged.
❶
Sterilization function unused for a prolonged amount of time will indicate condition
via [Time / Sterilize] button indicator.
▶ If you do not use sterilization for a long time, The button indicator flashes three times.

온수
잠금
HOT
LOCK
ROOM
COLD
온수
잠금
HOT
LOCK
ROOM
COLD
19
How To Use the Sterilization Preset function
How To Use the Immediate Sterilization function
How To Use the Energy Save function
This is a function to save energy by reducing the brightness of the Display
Lights.
❶
Press the [Energy Save/Setting] button while the
[Energy Save/Setting] Display Light is turned OFF.
▶ The [Energy Save/Setting] Display Light will be turned ON, and in
one second, all Display Lights will be dark.
▶ The Voice Guide will say “Energy-Eye Function Selected.”
▶ While the Energy Save function is working, if you press the button, the Display Lights will be bright. (if the
button is not pressed for a certain time, the Display Lights will be dark again.)
❷
If you press the [Energy Save/Setting] button while the [Energy Save/Setting] Display
Light is turned ON, the Energy Save function will be canceled.
▶ The [Energy Save/Setting] Display Light will be turned OFF, and in one second, all Display Lights will be
bright.
▶ The Voice Guide will say “Energy-Eye Function Cancelled.”
How To Use the Button Lock function
This is a function to prevent the random control by children, etc. and to clean
the product.
If this function is selected, the input of all the buttons will be blocked.
❶
If you press the [Lock] button for three seconds in the
Waiting status, the Button Lock will be selected.
▶If you press a button in the Button Lock status, “Loc_” will be
displayed and the Voice Guide will say“Button is being locked.”
▶ If you press the [Lock] button for three seconds in the Button
Lock status, “Un_Loc_” will be displayed and the Button Lock will
be released.
HOT
HOLD
SELECT MODE SELECT
LOCK(3SEC) ENERGY SAVE/
SETTING(3SEC)
HALF
CUP
ONE
CUP
NON-
STOP
HOT
TEMP.
TIME/
STERILIZE(3SEC)
FILTER
RESET(3SEC)
ROOM
COLD
HOT
HOLD
SELECT MODE SELECT
LOCK(3SEC) ENERGY SAVE/
SETTING(3SEC)
HALF
CUP
ONE
CUP
NON-
STOP
HOT
TEMP.
TIME/
STERILIZE(3SEC)
FILTER
RESET(3SEC)
ROOM
COLD
How To Use
When Sterilization Recommended Alarm is prolonged.
ENG

온수
잠금
HOT
LOCK
ROOM
COLD
온수
잠금
HOT
LOCK
ROOM
COLD
20
❶
Notification of Time to Replace Filters through Three-Colored LEDs (Mood lights) on
the Faucet
▶LED OFF →Sky-Blue → Yellow →Purple
(As the use volume of filters increases, the color changes consecutively.)
❷
Notification of Time to Replace Filters through the [Filter Reset] button Display Light
▶ When you press the [Filter Reset] button while the [Filter Reset] button Display Light is ON, the Voice Guide
will say, “Filter replacement is required.”
❸
Notification of Time to Replace Through Voice in Case of Outflow
▶ When water is being dispensed, the Voice Guide will say, “Filter replacement is required.”
e.g.) In case of the first outflow, the Voice Guide will say so only once a day.
※ When the Voice for replacing a filter is emitted, contact our Natural Manager to replace the filter.
How to check lter usage level
❶
Press the [Filter Reset] button for three seconds
While in the Waiting status.
▶ The Voice Guide will say, “Start reset.”
❷
After the Reset is completed, the Voice Guide
will say, “Reset completed,” and “Start auto filter
cleaning,” and the product will clean the filters.
▶ The Display Panel will show the cleaning time.
▶ Manually open the water valve or ball valve. If the water valve does not open “Please open the Veggie water
lever.” voice guide will follow.
▶ Filter cleaning in progress “Please lock the Veggie water lever”. Voice guide will function Manually close
the water valve or the ball valve.(See How to clean the filter, page 24)
❸
When the cleaning process is done, the voice guidance “Auto filter cleaning
completed” will follow, the products will be ready for water outflow.
❹
To cancel the filter cleaning function, press the [Outflow] button during filter cleaning.
▶ “Auto filter cleaning stopped” voice guide will function.
❺
The time required for filter cleaning depends on the water pressure of the raw water, it
takes about 10~15 minutes.
▶ When cleaning filters, Open the water lever and the Voice Guide will sound
“Please open the Veggie water lever.” then Switch the Filter Door Lock lever towards the “Close” direction.
To Use the Filter Reset Function
HOT
HOLD
SELECT MODE SELECT
LOCK(3SEC) ENERGY SAVE/
SETTING(3SEC)
HALF
CUP
ONE
CUP
NON-
STOP
HOT
TEMP.
TIME/
STERILIZE(3SEC)
FILTER
RESET(3SEC)
ROOM
COLD
How To Use
