1. INTENDED USE
The LLS-2054BE is a 2054-style, smart, li-ion battery pack supplied by ST
Technologies
®
that is to be integrated into our premier LED Headlight product line.
2. WARNINGS
•NOTE: The batteries must be fully charged before first use.
•Upon initial receipt and before each use, inspect each battery for damage. Do not
attempt to charge a damage battery.
•Do not expose the battery to heat, fire, mechanical shock, or store in direct sunlight.
•Do not open or dismantle the battery
•Do not use this equipment in the presence of a mixture containing flammable anesthetic
and/or air or oxygen or nitrous oxide.
•Do not sterilize, immerse, or expose the battery to water, solvents, lubricants, or other
chemicals to clean the charger unless otherwise directed. Do not allow water to collect in
the battery contacts. Keep clean and dry.
•Do not short-circuit, crush, or shred the battery
•Do not store the batteries haphazardly in a box or drawer in which the batteries may
short circuit each other or be short-circuited by other metal objects.
•In the event of a battery leakage, do not allow the liquid to come in contact with skin or
eyes. If contact has been made, wash the affected area with copious amounts of water
and seek medical advice.
•Do not use any charger other than a smart battery charger supplied by ST
Technologies
®
.
•Ensure correct battery orientation is followed before placing into a device.
•Do not attempt to force a battery into a device.
•When possible, remove the battery from equipment when not in use.
•Do not store batteries for more than one month in a discharged state.
•Do not store batteries for more than one year without recharge.

LIT-234 CUDA
®
Surgical Rev. -
(English) Date of Revision: 01/26/18
Page 4 of 30
3. TECHNICAL SPECIFICATIONS
Item
Specification
Input 17.4V 2.17A max
Output 15V
3.2A nominal, 4.25A max.
Operating Temperature 32
⁰
F to 113
⁰
F (0
⁰
C to 45
⁰
C) while charging
-4⁰F to 140⁰F (-20⁰C to 60⁰C) while
discharging
Storage Temperature -4
⁰
F to 140
⁰
F (-20
⁰
C to 60
⁰
C) max.
-20⁰F to 25⁰F (-20⁰C to 77⁰C)
recommended
Contacts +, C, D, T, -
Dimension (without battery adaptor) (LxWxH) 3.4in x 3.0in x 0.9in
Weight (without battery adaptor) 0.53lbs
Regulatory Approvals UL listed, UN 38.3 and CE
Water Resistant Not Protected Equipment, IPX0
4. BATTERY OPERATION
Figure 1. The LLS-2054BE Battery
FUEL GAUGE: Each LLS-2054BE battery is equipped with a fuel gauge that displays
the relative charge state of the battery. To activate the fuel gauge, press the small
circular button next to the gauge. Each LED on the fuel gauge represents 25% of the
fully charged capacity. Below is the fuel gauge legend:
•All four LEDs illuminated – Capacity = 76 – 100%
•Three LEDs illuminated – Capacity = 51 – 75%
•Two LEDs illuminated – Capacity = 26 – 50%
•One LED illuminated – Capacity = 10 – 25%
•One blinking LED – Capacity < 10%
CHARGING: The LLS-2054BE should only be charged with ST Technologies
®
supplied
smart battery chargers. To charge, orient the battery to line up the charger and battery

LIT-234 CUDA
®
Surgical Rev. -
(English) Date of Revision: 01/26/18
Page 5 of 30
contacts, and place the battery into the slot. Do not force the battery into the slot. Refer
to the charger IFU for a detailed operation.
ABOUT SMBus and SBS: The Smart Battery System defines the parameters that are
stored by an SBS-compliant battery. These parameters include full battery status and
fuel gauging information. The System Management Bus is the language by which these
parameters are communicated between the battery, the charger and the host device.
NOTE: The LLS-2054BE no longer requires fuel gauge re-calibration.
5. CLEANING INSTRUCTIONS
•Remove the battery from the host device.
•Clean the exterior of the battery with a cloth that has been dampened (not dripping)
using a hospital disinfectant. Follow applicable hospital protocols during cleaning and
dry immediately.
6. USER SERVICE
The LLS-2054BE has no user or field serviceable components. It can only be serviced at
the factory by factory trained technicians.
7. REPLACEMENT PARTS
For replacement parts, additional or optional equipment :
Please call Customer Service @ 877-814-2237
8. LIMITED WARRANTY
Your battery carry a one year warranty from the date of shipment on workmanship and
all defects of material. Should your product prove to have such defects ST
Technologies
®
will repair or replace the product or component part without charge.
Please contact ST Technologies
®
for return authorization documentation.
You should carefully pack the unit in a sturdy carton and ship it to the factory. Please
include a note describing the defects, your name, telephone number and a return
address. Warranty does not cover equipment subject to misuse, accidental damage,
normal wear and tear or if transferred to a new owner without authorization from ST
Technologies
®
. This warranty gives you specific legal rights and you may also have
other rights that vary from state to state.
POST WARRANTY REPAIRS: You may return your product(s) for repair, shipping
prepaid to the factory. Your product will be inspected and an estimate of repair charges
will be submitted to you for approval. Payment must be received before repairs are
completed.
•In the U.S call: 877 814-2237 (toll free)
•Customer Service 904 208-2290
