Culligan Good Water Machine H30 Series User manual

OWNERSGUIDE
H-30MODELSERIES

NOTICE: This system is intended for use on potable water
supplies or disinfected water containing cysts. Do not use where
water is microbiologically unsafe or with water of unknown
quality. If bacterial contamination is present, a recognized
method of water disinfection is required.
i
Check with your public works department for applicable local plumbing and
sanitation codes. Follow your local codes if they differ from the standards
used in this manual.
Operational, maintenance and replacement requirements are essential for this
product to perform properly. The Good Water Machine™contains replaceable
particulate and activated carbon filters. It also includes a replaceable reverse
osmosis membrane filter which is critical for the effective reduction of Total
Dissolved Solids. The filtered water should be tested periodically to verify that
the system is performing properly.
CULLIGAN INTERNATIONAL COMPANY
One Culligan Parkway
Northbrook, Illinois USA 60062-6209
847/205-6000
www.culligan.com

Safety/Warnings ...............................................ii
System Specifications ....................................... 1
Introduction
About Your System .............................. 2
ComponentDescription........................ 2
Certified Performance .......................... 3
How to Use Your System ...................... 4
Performance Check.............................. 4
Installation
Application Guidelines ......................... 5
Servicing Your System
Service Schedule ................................. 7
Filter Replacement ............................... 7
Parts List .......................................... 11
Service Log .................................................. 12
Warranty...................................................... 13
Table of Contents
GOODWATERMACHINE™
DRINKINGWATERSYSTEM
®

SYSTEM SPECIFICATIONS
System Flow Sequence...................... Particle/Activated Carbon Filter(s),
Reverse Osmosis Membrane Filter,
Storage Tank, Polishing Filter,
Dispensing Faucet
Particle/Activated Carbon Filter
H-30S-R .................................. Filter cloth wrapped activated carbon
block
Particle Filter, H-30PRV-C ................ 5 Micron Spun Polypropylene
Activated Carbon Filter, H-30PRV-C.. Cullar®G Activated Carbon
Reverse Osmosis Membrane Filter ..... Culligan®Aqua-Cleer®Thin Film
Composite
Production Rate1- H-30 Models ....... 30 gpd (114 L/day)
Ratio of Product to Flush Flow2......... 1:3 - 1:5
Polishing Filter ................................ Cullar G Activated Carbon
Dispensing Faucet ............................ Culligan Aqua-Cleer Faucet:
Rotary Operation, Stainless Steel
and Resin Flow Passages, with
Built-in Siphon Break
Colors ......................... Polished Chrome, White
Storage Capacity - Standard Tank ...... 2 gallons
- Medium Tank ....... 3 gallons
- Large Tank ........... 9 gallons
Dimensions - Filter Assembly
(H-30S-R) ............... 7"W x 4.3"D x 16.3"H
(H-30PRV-C)........... 15.8"W x 4.3"D x 16.3" H
- Storage Tank .............. 9" Diameter x 14" H
- Medium..................... 11"Diameter x 14" H
- Large......................... 15.5" Diameter x 24" H
1Rating at 50 psi, 77°F, 500 mg/L TDS Influent, Without Storage Tank
2May vary with pressure.
1

INTRODUCTION
Thank you for choosing a Culligan®Good Water Machine™drinking water
system. Your new system is designed to bring you years of healthful,
deliciously crystal-clear Culligan®water. With its special faucet installed on
your sink, it’s like getting bottled water straight from your kitchen tap.
2
Particle Filter (Model H-30PRV-C)
The particle filter screens out dirt, sand, rust, and other microscopic particles
15 times smaller than a grain of sand.
Activated Carbon Filter (Model H-30PRV-C)
The activated carbon filter gets rid of bad tastes and odors, including chlorine.
If present in your untreated water supply.
Particle/Activated Carbon Filter (Model H-30S-R)
The particle/activated carbon filter combines the filtration capabilities of
separate particle and activated carbon filters into one space efficient package.
Reverse Osmosis Membrane Filter
The reverse osmosis (RO) membrane filter squeezes out dissolved substances,
including lead, asbestos, and many others. These substances may not be in
your water. See Performance Data Sheet for list of substances and removal
percentages.
Storage Tank
The storage tank holds up to 2 gallons of triple-filtered Culligan®water under
pressure for rapid delivery. Optional three and nine-gallon tanks are available.
Polishing Filter
The Good Water Machine™includes a second activated carbon filter as added
assurance that your water will be crystal clear.
GOOD WATER MACHINE SYSTEM COMPONENTS
Refer to Figure 1, page 6
ABOUT YOUR SYSTEM
The reverse osmosis method of water treatment has long been regarded as one
of the most efficient and effective ways to reduce impurities. It’s the technology
we’ve used to build your new Culligan Good Water Machine. In addition, we’ve
incorporated activated carbon and fine particle filtration to bring you one of the
most effective systems available today.

3
CERTIFIED PERFORMANCE
The Culligan®Good Water Machine Model H-30S-R and
H-30PRV-C Drinking Water Systems have been tested and
certified to ANSI/NSF International Standard 58 for effective
reduction of TDS, Asbestos, Barium, Cadmium, Hexavalent and
Trivalent Chromium, Copper, Cysts, Fluoride, Lead, Mercury,
Radium 226/228, and Selenium.
Average removal percentages are as follows:
Asbestos 99.6% Fluoride 96.4%
Barium 90.1% Lead 98.6%
Cadmium 98.9% Mercury 83.1%
Chromium III 97.9% Radium 226/228* 80.0%
Chromium VI 82.6% Selenium 94.5%
Copper 98.9% TDS/SodiumChloride 91.3%
Cysts (including 99.99%
Cryptosporidium, Giardia
Lamblia and Entamoeba Histolytica)
*Minimum removal based on approved testing methods with Barium as
surrogate.
The substances removed by this system are not necessarily in your untreated
water. See Performance Data Sheet for exact percentages of contaminant
removal.
Faucet
The special drinking water faucet mounts conveniently on your kitchen sink.
A simple twist of the handle is all it takes to enjoy refreshing Culligan drinking
water.

HOW TO USE YOUR SYSTEM
With the Good Water Machine™, you’ll get a continuous supply of clear,
refreshing water for drinking and cooking. But Culligan improves a lot more
than just water. Crystal clear Culligan®water is ideal for:
• coffee • recipes • pasta
• tea • baby formula • ice cubes
• soup • houseplants • steam irons
• juice • pets • drink mixes
• everything you make with water
PERFORMANCE CHECK
To check the performance of your Good Water Machine, it is necessary to
measure the total dissolved solids (TDS) level of the filtered water. This simple
test can be done quickly by your dealer.
The Good Water SentryTM Water Quality Monitor is another way to keep track
of your system’s performance. This optional accessory checks your drinking
water each time you use the special faucet, and signals when the membrane
filter may need to be replaced.
If the water quality of your system seems to have declined, drain the storage
tank and allow the system to refill. If the problem persists, call your Culligan
Man for service.
4

INSTALLATION
This Owner’s Guide provides visual assembly reference only. Since specialized
skills are required in the assembly of the drinking water system, we recom-
mend that you contact your local independently operated Culligan dealer to
complete this installation.
APPLICATION GUIDELINES
The Good Water Machine™is designed for use on potable water supplies
meeting the guidelines outlined in Table 1. The system should be installed on
your home’s cold water line. The flushing stream should discharge through
an approved siphon break as illustrated in Figure 1. Installation of this system
must comply with state and local laws and regulations.
5
TABLE 1
Influent Water Characteristic
Pressure 40 - 120 psi (280 - 827 kPa)
Temperature 33 - 100°F (1 - 38°C)
Total Dissolved Solids (TDS)10 - 4000 ppm ( 0 - 4000 mg/L)
pH 5 - 10
Chlorine20 - 3 ppm ( 0 - 3 mg/L)
Chloramine 0 - 3 ppm ( 0 - 3 mg/L)
Turbidity 0 - 10 NTU
Iron 0 - 1 ppm (0 - 1 mg/L)
Bacterial Quality Potable
1See the Technical Manual for all applications where TDS exceeds 1000 ppm (1000 mg/L).
A booster pump is strongly recommended.
2The reverse osmosis membrane filter used in this system may be damaged by chlorine.
This system includes activated carbon which protects this element by reducing chlorine.
Influent chlorine should not exceed 3 mg/L.

6
Fig. 1
1. Particle Filter*
2. Activated Carbon Filter*
3. Reverse Osmosis Membrane Filter
4. Polishing Filter
5. Tubing Tee
6. Storage Tank
7. Faucet
8. Cold Water Line
9. Water Shutoff
*Combined Particulate/Activated Carbon Filter on Model H-30S-R

SERVICING YOUR SYSTEM
FILTER REPLACEMENT
Culligan recommends that you have your Good Water Machine serviced by
your local Culligan Man. You can rely on his or her experience and expertise
to keep your system in top operating condition.
If you wish to service your system, the filters are available from your Culligan
dealer. See the Parts List at the end of this section for replacement numbers.
Cartridge Conditioning
The activated carbon, reverse osmosis, and polishing filter cartridges must be
conditioned as follows prior to installation into the Good Water Machine.
Your Culligan Man can do these important procedures at the time of
purchase.
Activated Carbon Cartridge - 5 gallon flush to remove carbon dust
RO Membrane Filter - 6 hour flush to remove preservative solution
Polishing Filter - 2 gallon flush to remove carbon dust
7
SERVICE SCHEDULE
When properly maintained, your Good Water Machine™will give you years of
dependable service. Use the following as a guide to get the most out of your
system. Service frequency may vary depending on your local water condi-
tions. High sediment, chlorine, turbidity, or hardness levels may require more
frequent service. Refer to Figures 4 & 5, on page 9.
At Least Once Per Year
Replace:
• Particle/Activated Carbon Filter(s)
• Polishing Filter
Check:
• RO Membrane Filter
- TDS Reduction Performance
- Flow Rates
• Capillary Assembly
Sanitize the System.
Use the convenient chart inside the back cover of this booklet to keep track
of your system’s maintenance.

Fig. 3
Fig. 2
Tubing Connectors
The Good Water Machine™system features two simple types of tubing
connectors. Tubing can be connected easily as follows:
Push-in type (Fig. 2)
To connect, lubricate the tubing end with water and push the tubing into the
connector until it bottoms out. Be sure the tubing is smooth and free of
scratches, otherwise a leak my result.
To disconnect, hold the collar against the fitting body and pull the tube from
the fitting.
Threaded type (Fig. 3)
To connect, assemble the fitting parts onto the fitting, leave the nut loose, and
push the tubing firmly into the fitting until it bottoms out. Hand-tighten the
nut.
To disconnect, loosen the nut and pull the tubing from the fitting.
8

Filter Replacement and Sanitizing Procedure
Use the following procedure and reference in Fig. 1, 4 & 5 when servicing
the Good Water Machine™.
NOTICE: You may want to fill a pitcher with drinking water before beginning
service as it will take several hours for the system to refill after servicing.
The Good Water Machine may be sanitized with either 5-1/4% liquid chlorine
bleach or a fresh bottle of consumer grade hydrogen peroxide.
NOTICE: The reverse osmosis membrane filter used in this system may be
severely damaged by chlorine. The membrane filter must be removed from
the system if chlorine bleach is to be used for sanitizing.
NOTICE: Hydrogen peroxide should not be used if iron is present in the
supply water as the RO membrane filter may be damaged.
Cleanliness is essential in the filter replacement procedure. Be sure to wash
your hands thoroughly before handling filters. The use of surgical gloves is
strongly recommended.
9
Fig. 4 Fig. 5

10
1. Locate the system’s supply valve and turn off the system’s water supply.
2. Open the dispenser faucet and drain the storage tank.
3. Place the filter assembly in a dish pan or similar container to catch any
dripping water.
4. Relieve the pressure in the system by loosening the threaded tubing
connector at the bottom of the RO membrane filter housing. Retighten
the fitting.
5. Pull the u-clip from the top of the particle prefilter housing. (Fig. 4)
6. Push the top cap into the housing to free the o-ring seal, then pull the
top cap from the housing.
7. Remove the particle prefilter element from the housing and discard.
8. Clean the inside of the housing and top cap.
9. Lubricate the new particle prefilter cartridge o-ring with water and
insert the new filter cartridge into the top cap. Note: If Model H-30S-R,
do not install particulate/carbon filter at this time.
10.Pour two tablespoons liquid chlorine bleach or 3 ounces hydrogen
peroxide into the particle prefilter housing.
11.Assemble the housing, the top cap and the u-clip.
12.Repeat steps 5-8 and remove the activated carbon cartridge and, if
using chlorine bleach, the RO membrane filter.
NOTICE: If the RO membrane filter is to be reused, place it in a new
plastic bag to keep it clean.
13.Assemble the empty housings and replace the u-clips. Make sure all
tubing is connected properly.
14.Turn on the supply valve and allow the system to fill with water. Once
water begins to drip or flow from the faucet, close the faucet and allow
the tank to fill.
15.Turn off the supply valve and allow the system to sit for ten minutes.
16.Open the dispenser faucet and drain the storage tank.
17.Repeat steps 4, 5, 6, 9, and 11 for replacement of the activated carbon,
particulate/activated carbon (Model H-30S-R) and RO membrane filter
cartridges.
18.If using hydrogen peroxide, disconnect the storage tank tube from the
tubing tee. With an eyedropper or similar device, inject one tablespoon
of hydrogen peroxide into the tube and reconnect it to the tee.
19.Note the direction of flow and disconnect the tubing from the
polishing filter. Fig. 5.
20.Note the direction of flow and install the new polishing filter.
21.Replace the filter assembly into its mounting location.
22.Repeat step 14.
23.After the storage tank has filled (3-4 hours), open the faucet and drain
the storage tank to flush the new polishing filter and any remaining
sanitizing solution from the system.
24.Allow the system to refill. Your system is now ready for use.
25.Record your service on the chart at the end of this booklet.

1 Faucet - Chrome 01-0004-42
- White 01-0022-53
2 Polishing Filter 01-0000-79
3 Plastic Ball Valve 01-0027-85
4 Storage Tank - Std. 01-0050-95
- Medium 01-0047-76
- Large 01-0047-65
5 Particle Filter Element (Model H-30 PRV-C) 00-4015-38
Particulate/Activated Carbon Element
(Model H-30S-R) 01-0008-27
6 Capillary Assembly 01-0090-27
7 Reverse Osmosis Membrane Element H-30 01-0074-02
8 Activated Carbon Element (Model H-30 PRV-C) 01-0000-78
* Icemaker Tee - 1/4 x 1/4 x 1/4 01-0024-66
* Tubing, Blue - 1/4" O.D. 00-4021-84
* Good Water Sentry™Monitor 01-0039-45
* Aqua-Cleer®Booster Pump 01-0093-34
* Not Illustrated
ItemItem
ItemItem
Item DescriptionDescription
DescriptionDescription
Description PP
PP
Part Numberart Number
art Numberart Number
art Number
PARTS LIST
11

CULLIGAN®GOOD WATER MACHINE™
SERVICE LOG
DATE
SERVICED SANITIZED
POLISHING
FILTER
PARTICULATE
FILTER
FILTER(S) CHANGED
MODEL SERIAL NO.
DATEINSTALLED
FOR SERVICE CALL CULLIGAN AT: ( ) -
ACTIVATED
CARBON
FILTER
RO
MEMBRANE
FILTER
12

Cat. No. 01-8820-30 ©1997 Culligan International Company Printed in USA (Rev. 8/97)
CULLIGAN LIMITED WARRANTY
GOOD WATER MACHINE™ H-30 MODEL SERIES
You have just purchased one of the finest drinking water systems made. As an expression of
our confidence in Culligan products, your drinking water system is warranted to the original
end-user, when installed in accordance with Culligan International Company specifications,
against defects in material and workmanship from the date of original installation, as
follows:
CULLIGAN INTERNATIONALCOMPANY
One Culligan Parkway
Northbrook, Illinois 60062
If a part described above is found defective within the specified period, you should notify
your independently operated Culligan dealer and arrange a time during normal business
hours for the dealer to inspect the drinking water system on your premises. Any part found
defective within the terms of this warranty will be repaired or replaced by the dealer. You
pay only freight from our factory and local dealer charges.
Damage caused by accident, fire, flood, freezing, Act of God, misuse, misapplication,
neglect, alteration, installation or operation contrary to our printed instructions, or by the use
of accessories or components which do not meet Culligan specifications, is not covered by
this warranty.
Our product performance specifications are furnished with each drinking water system. TO
THE EXTENT PERMITTED BY LAW, CULLIGAN DISCLAIMS ALL IMPLIED WARRANTIES
INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY AND FIT-
NESS FOR PARTICULAR PURPOSE; TO THE EXTENT REQUIRED BY LAW, ANY SUCH
IMPLIED WARRANTIES ARE LIMITED IN DURATION TO THE ONE-YEAR PERIOD SPECI-
FIED ABOVE FOR THE PARTS DESCRIBED IN THIS LIMITED WARRANTY. As manufac-
turer, we do not know the characteristics of your water supply or the purpose for which you are
purchasing a drinking water system. Please understand that the quality of water supplies may
vary seasonally or over a period of time, and that your water usage rate may vary as well.
Water characteristics can also change considerably if your drinking water system is moved to
a new location. For these reasons, we assume no liability for the determination of the proper
equipment necessary to meet your requirements, and we do not authorize others to assume
such obligations for us. Further, we assume no liability and extend no warranties, express or
implied, for the use of this product on a non-potable water source. OUR OBLIGATIONS
UNDER THIS WARRANTY ARE LIMITED TO THE REPAIR OR REPLACEMENT OF THE
FAILED PARTS OF THE DRINKING WATER SYSTEM, AND WE ASSUME NO LIABILITY
WHATSOEVER FOR DIRECT, INCIDENTAL, CONSEQUENTIAL, SPECIAL, GENERAL, OR
OTHER DAMAGES, WHETHER FROM CORROSION OR OTHER CAUSES.
CONSUMERS:
Some states do not allow limitations on how long an implied warranty lasts, so the above
limitation may not apply to you. Similarly, some states do not allow the exclusion of
incidental or consequential damages, so the above limitation or exclusion may not apply to
you. This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state. Consult your telephone directory for your local independently-
operated Culligan dealer, or write Culligan International Company, for warranty and service
information.
The entire reverse osmosis water conditioning unit,
EXCLUDING THE EXPENDABLE FILTER CARTRIDGES
AND REVERSE OSMOSIS MEMBRANE FILTER USED
IN THIS UNIT.
The Culligan brand reverse osmosis membrane filter.
For a period of
FIVE YEARS
For a period of ONE YEAR
