Culligan High Efficiency Twin 9" Downflow Water Softener with Soft-Minder... User manual

Culligan
High
Efficiency
Twin
Automatic
Water
Softeners
Owners
Guide
©2019 Culligan International Company
01023052_RevL
DCO 190458 06/19

2
Attention
Culligan
Customer
The installation, service and maintenance of this equipment should be rendered by a qualified and
trained service technician. Your local independently operated Culligan dealer employs trained service
and maintenance personnel who are experienced in the installation, function and repair of Culligan
equipment. This publication is written specifically for these individuals and is intended for their use.
We encourage Culligan users to learn about Culligan products, but we believe that product knowledge is
best obtained by consulting with your Culligan dealer. Untrained individuals who use this manual assume
the risk of any resulting property damage or personal injury.
WARNING! Electrical shock hazard! Prior to servicing equipment, disconnect
power supply to prevent electrical shock.
NOTE: This system is not intended for use where water is microbiologically
unsafe or with water of unknown quality.
WARNING! If incorrectly installed, operated or maintained, this product can cause
severe injury. Those who install, operate, or maintain this product should be
trained in its proper use, warned of its dangers, and should read the entire
manual before attempting to install, operate, or maintain this product.
WARNING! This device complies with part 15 of the FCC rules subject to the
two following conditions: 1) This device may not cause harmful
interference, and 2) This device must accept all interference received
including interference that may cause undesired operation.
This equipment complies with Part 15 of the FCC rules. Any changes or modifications not expressly
approved by the manufacturer could void the user’s authority to operate the equipment. Changes or
modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
CAUTION! To reduce the risk of fire, use only No. 26 AWG or larger
telecommunications line cord.
CAUTION! This product is not to be used by children or persons with reduced
physical, sensory or mental capabilities, or lack of experience or
knowledge, unless they have been given supervision or instruction.
CAUTION! Children should be instructed not to play with this appliance.
CAUTION! If the power cord from the transformer to the unit looks or becomes
damaged, the cord and transformer should be replaced by a Culligan
Service Agent or similarly qualified person in order to avoid a hazard.
Products manufactured and marketed by Culligan International Company (Culligan) and its affiliates are
protected by patents issued or pending in the United States and other countries. Culligan reserves the
right to change the specifications referred to in this literature at any time, without prior notice. Culligan,
AquaSensor, Tripl-Hull, and SoftMinder are trademarks of Culligan International Company or its affiliates.
Culligan International Company
9399 West Higgins Road, Suite 1100
Rosemont, Illinois 60018
1-847-430-2800
www.culligan.com
01023052 L 06/19

3
Contents
01023052 L 06/19
About this Manual...................................................................................................................................... 4
Thank You.................................................................................................................................................. 5
Specications ............................................................................................................................................ 6
Introduction................................................................................................................................................ 8
How Your Water Conditioner Works .......................................................................................................... 9
The Culligan Process .............................................................................................................................. 10
Modes of Operation................................................................................................................................. 11
Salt Supply, Usage and Service .............................................................................................................. 13
Navigating the Menus and Keypad ......................................................................................................... 14
Set Date and Time................................................................................................................................... 15
Set Daylight Savings Time....................................................................................................................... 16
Information............................................................................................................................................... 17
Error Codes ............................................................................................................................................. 19
Regeneration........................................................................................................................................... 20
When and How to Bypass Your Water Softener...................................................................................... 22
Things to Check Before You Call for Service........................................................................................... 23
Performance Data Sheet Culligan High E󰀩ciency Twin
9” Downow Water Softener with Soft-Minder® Meter............................................................................ 24
Performance Data Sheet Culligan High E󰀩ciency Twin
9” Downow Water Softener with Aqua-Sensor® Sensing Device.......................................................... 25
Performance Data Sheet Culligan High E󰀩ciency
10” Twin Downow Water Softener with Soft-Minder® Meter ................................................................. 26
Performance Data Sheet Culligan High E󰀩ciency Twin
10” Downow Water Softener with Aqua-Sensor® Sensing Device........................................................ 27
Performance Data Sheet Culligan High E󰀩ciency Twin
9” Upow Water Softener with Soft-Minder® Meter ................................................................................ 28
Performance Data Sheet Culligan High E󰀩ciency Twin
9” Upow Water Softener with Aqua-Sensor® Sensing Device .............................................................. 29
Performance Data Sheet Culligan High E󰀩ciency
10” Twin Upow Water Softener with Soft-Minder® Meter ...................................................................... 30
Performance Data Sheet Culligan High E󰀩ciency Twin
10” Upow Water Softener with Aqua-Sensor® Sensing Device ............................................................ 31
Performance Data Sheet Culligan High E󰀩ciency Twin
12” Water Softener with Soft-Minder® Meter .......................................................................................... 32
Performance Data Sheet Culligan High E󰀩ciency Twin
12” Water Softener with Aqua-Sensor® Sensing Device ........................................................................ 33
Performance Data Sheet Culligan High E󰀩ciency Twin
14” Water Softener with Soft-Minder® Meter .......................................................................................... 34
Performance Data Sheet Culligan High E󰀩ciency Twin
14” Water Softener with Aqua-Sensor® Sensing Device ........................................................................ 35
Important Data on Your Water Softener .................................................................................................. 36
Parts List High E󰀩ciency Twin Control Valve Assembly (Indoor/Outdoor) .............................................. 37
Parts List Remote Display and Accessories............................................................................................ 40
Parts List Tank Assembly ........................................................................................................................................41
Parts List 16” and 18” Brine System........................................................................................................ 42
Parts List Brine Valve Assembly.............................................................................................................. 43
Parts List 24” Brine System..................................................................................................................... 44
Culligan Limited Warranty ....................................................................................................................... 45

401023052 L 06/19
This manual:
• Familiarizes the operator with the equipment
• Explains installation and setup procedures
• Provides basic programming information
• Explains the various modes of operation
• Gives specifications and troubleshooting information
Read this Manual First
Before you operate the Culligan High Efficiency Twin Automatic Water Softener, read this manual to
become familiar with the device and its capabilities.
Safe Practices
Throughout this manual there are paragraphs set off by special headings.
Notice (or Note) is used to emphasize installation, operation or maintenance information which is
important, but does not present any hazard. For example,
NOTICE The nipple must extend no more than 1 inch above the cover plate.
Caution is used when failure to follow directions could result in damage to equipment or property.
CAUTION! Disassembly while under water pressure can result in flooding.
Warning is used to indicate a hazard which could cause injury or death if ignored.
WARNING! Electrical shock hazard!
Unplug the unit before removing the timer mechanism or cover plates!
The CAUTION and WARNING paragraphs are not meant to cover all possible conditions and situations that
may occur. Understand that common sense, caution, and careful attention are conditions which cannot be built
into the equipment. These MUST be supplied by the personnel installing, operating, or maintaining the system.
Be sure to check and follow the applicable plumbing codes and ordinances when installing this
equipment. Local codes may prohibit the discharge of sanitizing or descaling solutions to drain.
Use protective clothing and proper face or eye protection equipment when handling chemicals or tools.
NOTE: The Culligan High Efficiency Twin Softener is not intended for use
with water that is microbiologically unsafe or of unknown quality
without adequate disinfection either before or after the system.
NOTE: Check with your public works department for applicable local
plumbing and sanitation codes. Follow local codes if they differ from
the standards used in this manual. To ensure proper and efficient
operation of the Culligan High Efficiency Twin Softener to your full
satisfaction, carefully follow the instructions in this manual.
About this
Manual

5
01023052 L 06/19
Thank You
Welcome To Your New World of Better Living with Culligan Water.
The Culligan HE Twin Water Softeners with Soft-Minder® Meter and Aqua-Sensor®
sensing device are tested and certified by the WQA against NSF/ ANSI Standard
372, CSA B483.1, and NSF/ANSI Standard 44 for the effective reduction of hardness
(calcium and magnesium), barium and radium 226/228, as verified and substantiated by
test data.
The Culligan HE Twin Water Softeners with Soft-Minder® Meter and Aqua-Sensor®
sensing device are certified by the IAPMO R&T against NSF/ ANSI Standard 372, CSA
B483.1, and NSF/ANSI Standard 44 for the effective reduction of hardness (calcium and
magnesium), barium and radium 226/228, as verified and substantiated by test data.
The Culligan HE Twin Water Softeners with Soft-Minder®Meter and Aqua-Sensor®sensing device
are registered for sale with the State of California and the State of Iowa.
For installations in Massachusetts, Massachusetts Plumbing Code 248 CMR shall be adhered
to. Consult your licensed plumber for installation of this system. This system and its installation
must comply with state and local regulations. The use of saddle valves is not permitted.
The Culligan HE 1” Twin water softener requires the use of a Culligan connector,
P/N 01023290 (plastic) or P/N 01021077 (copper).
The Culligan HE 1” Twin NC model has not been tested or certified by WQA or IAPMO R&T
and does not include the Culligan connector.
The Culligan HE Twin water softener outdoor controller enclosure complies
with the UL 50/50E standards for an IP 46 Rating.
If this is your first experience having soft, conditioned water in your home, you’ll be amazed at the
marvelous difference it makes. We promise that you’ll never want to be without it again.
Congratulations, too, on selecting one of the “first family” of water conditioners in the prestigious
Culligan High Efficiency Water Softeners. With Culligan’s many years of knowledge and experience in
water treatment, you can be confident that the model you selected has been designed and engineered
to provide years of service with a minimum of care and attention.
Some localities have corrosive water. A water softener cannot correct this problem and so its printed
warranty disclaims liability for corrosion of plumbing lines, fixtures or appliances. If you suspect
corrosion, your Culligan Dealer has equipment to control the problem.
NOTICE Sodium Information: Water softeners using sodium chloride for regeneration add
sodium to the water. Persons who are on sodium restricted diets should consider
the added sodium as part of their overall sodium intake.
Serial Numbers
The control valve serial number is located on the back of the enclosure.
The media tank serial number is located on the top surface of the tank.
NOTE: DO NOT remove or destroy the serial number.
It must be referenced on request for warranty repair or replacement.

601023052 L 06/19
Culligan High Efficiency Twin Water Conditioners with
Aqua-Sensor®Device or Soft-Minder®Meter—Downflow Regeneration
Model 9" Model 10" Model 12" Model 14" Model
Control Valve 1” Reinforced Thermoplastic w/ HE Circuit Boards
Overall Conditioner Ht 56 in 62 in 60 in 73 in
Media Tank Design Quadra-Hull™
Media Tank Dimensions
(Dia x Ht) 9 x 48 in 10 x 54 in 12 x 52 in 14 x 65 in
Salt Storage Tank
Dimensions (Dia x Ht) 18 x 43 in 18 x 43 in 18 x 43 in 24 x 42 in
Exchange Media, Type
and Quantity Cullex® Media, 1.0 ft3 Cullex Media, 1.5 ft3 Cullex Media, 2.0 ft3 Cullex Media, 3.0 ft3
Underbedding, Type and
Quantity
Cullsan®
Underbedding, 12 lb
Cullsan
Underbedding, 15 lb
Cullsan
Underbedding, 20 lb
Cullsan
Underbedding, 25 lb
Exchange Capacity
@ Salt Dosage Per
Recharge (per tank)
17,854 gr @ 4.0 lb 26,781 gr @ 6.0 lb 31,352 gr @ 7.0 lb 51,726 gr @ 12 lb
27,108 gr @ 8.0 lb 40,662 gr @ 12.0 lb 48,458 gr @ 16.0 lb 75,582 gr @ 24 lb
31,736 gr @ 12.0 lb 47,604 gr @ 18.0 lb 59,267 gr @ 24.0 lb 88,549 gr @ 36 lb
Efficiency rated dosage1
(per tank)
4,463 gr/lb @ 4 lb
salt dosage
4,463 gr/lb @ 6 lb
salt dosage
4,479 gr/lb @ 7 lb
salt dosage
4,310 gr/lb @ 12 lb
salt dosage
Freeboard to Media2 14.5 in 14.5 in 16 in 25 in
Freeboard to
Underbedding3 44.5 in 47.5 in 46 in 59 in
Salt Storage Capacity 375 lb 375 lb 375 lb 600 lb
Rated Service Flow @
Pressure Drop 9.0 gpm @ 11 psi 9.4 gpm @ 12 psi 10.0 gpm @ 10 psi 10.6 gpm @ 11 psi
Auxiliary Flow Rate4 10.8 gpm @ 15 psi 11.0 gpm @ 15 psi 12.6 gpm @ 15 psi 12.8 gpm @ 15 psi
Total Hardness, Maximum 75 gpg 99 gpg 99 gpg 99 gpg
Total Iron, Maximum 5 ppm
Hardness to Iron Ratio,
Minimum 8 gpg to 1 ppm
Operating Pressure 20-125 psi (138–862 kPa)
Operating Pressure
(Canada) 20-90 psi (138–621 kPa)
Operating Temperature 33-120°F (0–49°C)
Electrical Requirements 24V/60 Hz
Electrical Power
Consumption, Min/Max 8.4 watts/21.6 watts
Drain Flow, Maximum5 2.5 gpm 2.5 gpm 3.0 gpm 5.3 gpm
Recharge Time, Average6
Recharge Water 78 minutes 67 minutes 62 minutes 76 minutes
Consumption, Average6 47 gallons 45 gallons 67 gallons 155 gallons
1The efficiency rated dosage is only valid at the stated salt dosage and is efficiency rated according to NSF/ANSI Standard 44.
2Measured from top of media to top surface of tank threads (backwashed and drained).
3Measured from top of underbedding to top surface of tank threads.
4Auxiliary flow rates do not represent the maximum service flow rate used for determining the softener’s rated capacity and efficiency and
that continuous operation at these flow rates greater than the maximum service flow rate may affect capacity and efficiency performances.
5Backwash at 120 psi.
610 minute backwash, 4 lb. 9” model, 6 lb. 10” model, 7 lb. 12” model, or 12 lb. 14” model salt dosage.
Specifications

7
01023052 L 06/19
Culligan High Efficiency Twin Softener—Upflow Regeneration
Model 9" Model 10" Model
Control Valve 1” Reinforced Thermoplastic with HE Circuit Board
Overall Conditioner Height 56 in 62 in
Media Tank Design Quadra-Hull™
Media Tank Dimensions (Dia x Ht) 9 x 48 in 10 x 54 in
Salt Storage Tank Dimensions (Dia x Ht) 18 x 43 in
Exchange Media, Type and Quantity Cullex® Media, 1.0 ft3 Cullex Media, 1.5 ft3
Underbedding, Type and Quantity Cullsan® Underbedding, 12 lb Cullsan Underbedding, 15 lb
Exchange Capacity @ Salt Dosage Per Recharge (per
tank)
9,792 gr @ 2.0 lb 30,081 gr @ 6.0 lb
17,366 gr @ 4.0 lb 47,726 gr @ 12.0 lb
27,306 gr @ 8.0 lb 54,975 gr @ 18.0 lb
Efficiency Rated Dosage (per tank)1 4,896 gr/lb @ 2 lb salt dosage 5,014 gr/lb @ 6 lb salt dosage
Proportional Brining Efficiency Rating (per tank)25,760 gr/lb @ 2 lb salt dosage 5,898 gr/lb @ 6 lb salt dosage
Freeboard to Media314.5 in 14.5 in
Freeboard to Underbedding444.5 in 47.5 in
Salt Storage Capacity 375 lb
Rated Service Flow @ Pressure Drop 9.0 gpm @ 11 psi 9.4 gpm @ 12 psi
Auxiliary Flow Rate510.8 gpm @ 15 psi 11.0 gpm @ 15 psi
Total Hardness, Maximum 30 gpg
Total Iron, Maximum 2 ppm
Hardness to Iron Ratio, Minimum 8 gpg to 1 ppm
Operating Pressure 20-125 psi (138–862 kPa)
Operating Pressure (Canada) 20-90 psi (138–621 kPa)
Operating Temperature 33-120°F (0–49°C)
Electrical Requirements 24V/60 Hz
Electrical Power Consumption, Min/Max 8.4 watts/21.6 watts
Drain Flow, Maximum62.2 gpm 2.3 gpm
Recharge Time, Average7Recharge Water 68 minutes 57 minutes
Consumption, Average7(Evaluated by WQA) 33 gallons 35 gallons
Consumption, Average8 (Not evaluated by WQA) 25.5 gallons 27.5 gallons
1The efficiency rated dosage is only valid at the stated salt dosage and 5-minute backwash. It is efficiency rated according to NSF/ANSI 44.
2The Proportional Brining Efficiency Rating assumes a 20 percent reserve capacity at the time of regeneration that is typical of what the
manufacturer expects under real-world operation. Proportional brining is not measured by NSF/ANSI 44, and so this claim is not, and can
not, be rated to NSF/ANSI 44.
3Measured from top of media to top surface of tank threads. (backwashed and drained).
4Measured from top of underbedding to top surface of tank threads.
5Auxiliary flow rates do not represent the maximum service flow rate used for determining the softener’s rated capacity and efficiency and
that continuous operation at these flow rates greater than the maximum service flow rate may affect capacity and efficiency performances.
6Backwash at 120 psi (830 kPa).
75-minute backwash, 2 lb. 9” model, 6 lb. 10” model salt dosage. These values have been tested and certified by WQA.
82-minute backwash, 2 lb. 9” model, 6 lb. 10” model salt dosage. These values are based on the manufacturer recommended backwash time.

801023052 L 06/19
Introduction It’s All So Easy, So Economical, So Efficient, So Enjoyable!
Kind To Skin And Complexion
Soft water will help prevent red, itchy or dry skin because there are no hardness impurities to cause
soreness, no soap curd to coat the skin. Shaving is easier, smoother—either with a blade or electric shaver.
Bathing And Showering
You’ll use far less soap with conditioned water. Use your soap very sparingly—not as you did before soft
water. Just a quick rinse removes all lather, leaving your skin pleasantly smooth and silky because now
it’s free of sticky soap curd and film.
Saves Washing Costs. Helps Control Environmental Pollution
Soft water washes whiter and cleaner with less soap or detergent. Because the hardness impurities are
reduced, your soap can concentrate solely on washing. People usually find that they can reduce the
amount of soap they use substantially. If you normally use a cup per wash load with hard water, try using
1/3 cup depending on the size of your wash load and the degree of soil. Different amounts are required, but
you can use less with softened water. An added bonus is the fact that your washable fabrics will last longer.
Super Hair Conditioning
Soft water is great for scalp and hair care. No insoluble deposits are formed. Hair is shinier, softer,
more manageable. Reduce the amount of shampoo you have normally used.
Dishes Are A Delight
Washed by hand or in a dishwasher, glassware, dishes and silver wash cleaner, easier.
Follow your dishwasher manufacturer’s instructions. Soft water promotes sanitation
because no greasy hard water film can form to collect or harbor bacteria.
Easier Housekeeping, Gleaming Fixtures
You’ll be amazed at the marvelous difference. Just a swish of the cloth, and the bathtub or shower and
fixtures are clean and sparkling. Imagine, no scouring! No hard water scum to cause rings, streaks, spots
and stains. To keep their gleaming luster, simply wipe fixtures with a towel after use. Formica, tile, walls,
floors, woodwork surfaces clean easier, stay clean longer. You’ll save on cleaning aids and save on time.
Saves Water-Heating Energy, Helps Water-Using Appliances
Soft water reduces the formation of rock-like hard water scale that encrusts water heaters, hot water pipes,
shower heads, and water-using appliances. This scale can cause premature maintenance and failure.
Elimination of hard water also provides substantial energy savings because scale acts as an insulator,
wasting electricity or gas used to heat water.
Water For Lawns And Household Plants
If possible, lawn sprinkling faucets should be supplied with hard water primarily because it is not
economical to soften so much water.
Household plants are much more sensitive than lawns with respect to the kind of water which is best.
First, because they receive no rainfall and, second, there is little or no drainage of the soil. Preferably
they should be watered with rainwater or water which is low in mineral content such as distilled or
demineralized water. Softened water is not recommended for house plants because a build-up of sodium
in the soil may interfere with efficient absorption of water by the plant root system. Additional information
may be obtained from your independently operated Culligan dealer.

9
01023052 L 06/19
How Your
Water
Conditioner
Works
Why Water Gets Hard And How It Is Softened
All of the fresh water in the world originally falls as rain, snow, or sleet. Surface water is drawn
upward by the sun, forming clouds. Then, nearly pure and soft as it starts to fall, it begins to collect
impurities as it passes through smog and dust-laden atmosphere. And as it seeps through soil and
rocks it gathers hardness, rust, acid, unpleasant tastes and odors.
Water hardness is caused primarily by limestone dissolved from the earth by rainwater. Because of this,
in earlier times people who wanted soft water collected rainwater from roofs in rain barrels and cisterns
before it picked up hardness from the earth.
Some localities have corrosive water. A softener cannot correct this problem and so its printed warranty
disclaims liability for corrosion of plumbing lines, fixtures or appliances. If you suspect corrosion, your
Culligan Man has equipment to control the problem.
Iron is a common water problem.
The chemical/physical nature of iron found in natural water supplies is exhibited in four general types:
1. Dissolved Iron—Also called ferrous or “clear water” iron. This type of iron can be removed
from the water by the same ion exchange principle that removes the hardness elements,
calcium and magnesium. Dissolved iron is soluble in water and is detected by taking a sample
of the water to be treated in a clear glass. The water in the glass is initially clear, but on
standing exposed to the air, it may gradually turn cloudy or colored as it oxidizes.
2. Particulate Iron—Also called ferric or colloidal iron. This type of iron is an undissolved particle
of iron. A softener will remove larger particles, but they may not be washed out in regeneration
effectively and will eventually foul the ion exchange resin. A filtering treatment will be required
to remove this type of iron.
3. Organic Bound Iron—This type of iron is strongly attached to an organic compound in the
water. The ion exchange process alone cannot break this attachment and the softener will not
remove this type of iron.
4. Bacterial Iron—This type of iron is protected inside a bacteria cell. Like the organic bound
iron, it is not removed by a water softener.
When using a softener to remove both hardness and dissolved iron it is important that it regenerates more
frequently than ordinarily would be calculated for hardness removal alone. Although many factors and
formulas have been used to determine this frequency, it is recommended that the softener be regenerated
when it has reached 50–75 percent of the calculated hardness alone capacity. This will minimize the
potential for bed fouling. (Iron removal claims have not been verified by the Water Quality Association.)
If you are operating a water softener on clear water iron, regular resin bed cleaning is needed to
keep the bed from coating with iron. Even when operating a softener on water with less than the
maximum of dissolved iron, regular cleanings should be performed. Clean every six months or
more often if iron appears in your conditioned water supply. Use resin bed cleaning compounds
carefully following the directions on the container.
CAUTION! Do not use where the water is microbiologically unsafe or with water of
unknown quality without adequate disinfection before or after the unit.

10 01023052 L 06/19
The Culligan
Process
Your Culligan water conditioner consists of three basic components,
(A) the Control Valve, (B) the Mineral Tank, and (C) the Brine System.
A. Control Valve
The exclusive Culligan control valve automatically
performs a variety of tasks that are necessary for the
proper operation of your water conditioner. These tasks,
commonly referred to as cycles or operating positions,
are Service, Regeneration, and Brine Refill.
1. Service: While the control valve is in the
service cycle, hard water is directed down
through the column of Cullex®resin where
hardness minerals are removed from the
water. The softened water is then directed into
your household plumbing lines. The ability of
the Cullex resin to remove hardness minerals
needs to be periodically replenished; this is
referred to as Regeneration.
2. Regeneration: While the control valve is in
the regeneration cycle, water is first directed
up through the column of Cullex resin to flush accumulated sediment out of the resin and
down the drain. Then, the regenerant brine solution is slowly drawn from the bottom of the
salt storage tank of the Brine System and is directed down through the column of Cullex
resin, restoring the ability of the resin to remove hardness minerals from your water supply.
Once completed, the regeneration cycle is followed by Brine Refill.
3. Brine Refill: While the control valve is in the brine refill cycle, a predetermined amount of
water is directed to the salt storage tank of the Brine System so that additional salt can be
dissolved to provide the brine solution that will be needed for the next regeneration cycle.
B. The Mineral Tank
The Mineral Tank contains the Cullex resin column, Cullsan® underbedding, and an outlet
manifold (the Culligan Municipal also includes carbon media for chlorine taste & odor reduction).
The number of gallons of hard water that can be softened by the Cullex resin column before it
needs regeneration is called the “capacity” of the resin column, and depends upon the amount
of hardness minerals in each gallon of water (expressed as grains per gallon) and upon the
amount of regenerant brine solution (expressed as pounds of salt) passed through the resin
column during regeneration.
Your Culligan service person, taking into account the hardness of your water and the amount
of softened water your household may reasonably expect to use each day, has carefully established
how often the softener will regenerate and how much salt will be used for each regeneration.
This will ensure that all of your soft water needs will be fulfilled without using an excessive amount of salt.
C. The Brine System
The Brine System consists of a salt storage container and hydraulic Dubl-Safe™ valve.
The salt storage container holds the salt that is used to make the regenerant brine solution.
The hydraulic Dubl-Safe valve limits the amount of water that is returned to the salt storage tank
during the brine refill cycle.
Because a predetermined amount of salt is dissolved with each brine refill cycle, the salt must be
periodically replenished in order to maintain efficient operation. Your Culligan service person will be
able to tell you about how often salt must be added to the salt storage container.
A
B
C

11
01023052 L 06/19
Modes of
Operation
Water Meter Mode
In water meter mode, the controller keeps track of the quantity of water that has flowed through the resin bed.
Based on the influent water hardness and the hardness capacity of the resin bed, a service life expectancy
in the quantity of softened water is calculated and programmed into the control. When the set point is
reached, regeneration is triggered. If the delayed regeneration is selected, the regeneration will start at time
of regeneration. In immediate mode the regeneration starts as soon as the regeneration signal is provided.
If time clock backup is set and the capacity has not been exhausted but the days since last regen is greater
than time clock backup, setting the softener will immediately regenerate.
Aqua-Sensor® Mode
The Aqua-Sensor is a conductivity probe that senses when the hardness front passes through the resin bed. It
functions independently of the influent water hardness so therefore, is useful in conditions when the influent water
hardness varies throughout the year. It provides for the most efficient mode of operation. In addition to sensing
when a resin bed is exhausted, it can also be used to determine when the brine solution is rinsed from the resin
bed during the Brine Draw/Slow Rinse cycle triggering the control to move to fast rinse. This patented feature
provides water savings by optimizing the amount of rinse water required to completely rinse out the resin bed.
Smart Brine Tank Probe
The smart brine tank probe monitors conditions inside the brine tank. It predicts when salt needs to be added
to the brine tank, detects the presence of salt-bridging, eductor line plugging and brine tank overfilling.
Wireless Remote Control
The wireless remote control displays the current status of the water softener or filters and
allows for remote control. It can be located up to 200 feet away from the softener (depending
upon building construction materials). The wireless remote displays information about softener
performance, problems, days of salt remaining and allows remote control for regeneration.
The wireless remote control is designed to communicate at 915 MHz and to work without
interference with other 915 MHz devices such as cordless telephones and baby monitors.
Modem
The modem allows for the system to be remotely monitored detecting problems before they occur,
to schedule salt delivery when it is needed and to keep the system software up to date with the latest advances.
Manual Regeneration
Manual regeneration can be initiated via the softener control valve or wireless remote display.
Manual regeneration can be initiated to begin regeneration immediately or that night.
To immediately initiate regeneration, press and hold for at least ten (10) seconds.
To cancel a delayed regeneration, press and hold for at least five (5) seconds.
Predict Mode
The Predict Mode is used with the flow meter to determine the optimum regeneration point.
Before the regeneration starts, the control will compare the remaining capacity value with the
average daily water use. If the average daily water usage is less than the reserve capacity, the
controller will wait 24 more hours before regeneration. If the reserve capacity is less than the
average daily water usage, the control will initiate regeneration. This works in delay mode only.
At any time, if the total capacity value is reached, the control will initiate an immediate regeneration.
Pre-Rinse Mode
The Pre-rinse mode is used to pre-rinse the softener resin bed or filter media. The pre-rinse in flow
meter mode will occur after the control has sensed that no water has flowed through the control for
a period of X hours (can be set through the programming menu). When the control is in this mode,
once the X amount of hours have elapsed the control will cycle to the fast rinse position for the pre-
set length of minutes and then return to the home or service position.

12 01023052 L 06/19
Down Flow Regeneration
Water and regenerate flow downward through the media tank.
Up Flow Regeneration
Water flow is downward and regenerate flow is upward through the media tank. The significance of
this is that regeneration will be most effective in those parts of the resin bed which are treated with the
freshest regenerate solution. There will tend to be less hardness leakage with up-flow regeneration.
Proportional Brining
The control monitors your softened water usage making only enough brine to regenerate that part of the
resin bed that has been exhausted. In this way the amount of salt used relates directly to the amount of
softened water used, making it more efficient and cost effective. Proportional brining can only be used
with upflow regeneration. The Aqua-Sensor or meter can be used to initiate a regeneration.

13
01023052 L 06/19
Salt Supply,
Usage and
Service
Salt is the mineral used to “recharge” your water conditioner. A brine solution is automatically
made up in the bottom of the salt storage container, the Cullex® resin beads in the mineral
tank are flushed with the brine solution as a step in the recharging process.
Your Culligan Water Conditioner has been carefully designed to get the greatest amount of softening
capacity from the salt it uses. Here is some pertinent information about salt usage, types and service.
Salt Economizer
This control is set at the time of installation, and determines salt usage according
to the water hardness, number of persons in the household, and water usage.
What Kind of Salt is Best
All Culligan Water Conditioners are designed to use any water conditioner salt
of good quality, including rock, pellet, solar, or “evaporated” types.
All rock salt, regardless of source, contains insoluble material which collects
at the bottom of the salt storage tank and requires periodic clean-out.
If purified salt products are used, the salt storage compartment will require
less frequent clean-out, but you must check more frequently for “bridging.”
Regardless of what type of salt is used, we recommend Culligan Brand Salt
as suggested by your Culligan Dealer. He or she is the expert and can provide
you with the best product for your Culligan Water Conditioner.
Automatic Salt Delivery Service
Ask your Culligan Dealer for details about salt delivery service. You can have your salt supply
replenished on a regular basis. Whether you have automatic delivery service or pick up salt
from your Culligan Dealer, you will be getting quality salt packaged according to rigid Culligan
specifications. Using Culligan Brand Salt will help assure continued efficiency and trouble-free
operation of your water conditioner.
The modem allows for the system to be remotely monitored, detecting problems
before they occur, to schedule salt delivery when it is needed and to keep the system
software up to date with the latest advances.
NOTICE Sodium Information: Water softeners using sodium chloride for regeneration add
sodium to the water. Persons who are on sodium restricted diets should consider
the added sodium as part of their overall sodium intake.

14 01023052 L 06/19
Navigating the
Menus and
Keypad
DOWN button
CHECK MARK
or OK button
UP button
CANCEL (X) button
UP ARROW button: scrolls up the menu
Controller
Remote
DOWN ARROW button: scrolls down the menu
CHECK MARK button: selects the highlighted
option, opens a new screen, or accepts a
changed setting
CANCEL or Xbutton: returns to the previous
screen or cancels a changed setting
Hold down or to quickly scroll through the setting without repeatedly pressing the button.

15
01023052 L 06/19
Set Date
and Time
Follow this procedure to update the date or time.
NOTE: The HE Twin Controller must initialize
and return to the HOME screen if settings are changed.
Screen Display Range Setting Description
SOFTENING
JAN-01-18 12:01P N/A
1. From the HOME screen,
press to view the main menu.
>1)INFORMATION
2)MANUAL MODE
1–6 2. The screen displays the main menu.
Press to select 3)SET DATE/TIME.
Set Month
SET MONTH
>JAN
Jan–
Dec
The screen displays the month setting.
Press or and then to change the setting.
Set Day
SET DAY
>1 1–31 The screen displays the day setting.
Press or and then to change the setting.
Set Year
SET YEAR
>2018
2009–
2030
The screen displays the year setting.
Press or and then to change the setting.
Set Clock Type
CLOCK TYPE
> 12 HR
12 HR,
24 HR
The screen displays the clock type setting.
Press or and then to change the setting.
Set Hour
SET HOUR
> 12PM
12PM–
11AM,
0–23
The screen displays the hour setting.
Press or and then to change the setting.
Set Minutes
SET MINUTES
>1 0–59 The screen displays the minutes setting.
Press or and then to change the setting.

16 01023052 L 06/19
Set Daylight
Savings Time Screen Display Range Setting Description
DAYLIGHT SAVING
YES
Yes,
No
The screen displays the Daylight Savings
Time setting. Press or
and then to change the setting.
2)MANUAL MODE
>3)SET DATE/TIME
The screen displays the main menu.
Press to save the changes and initialize the system.
SOFTENING
JAN-01-18 12:01P 3. The screen displays the home screen.

17
01023052 L 06/19
Information
The following information can be displayed at the control valve or remote display. These settings are
read-only. Press or to scroll through the settings. Press to view the previous setting.
Screen Display Range Setting Description
SOFTENING
JAN-01-18 12:01P N/A
1. From the HOME screen,
press to view the main menu.
>1)INFORMATION
2)MANUAL MODE
1–6 2. The screen displays the main menu.
Press to select 1)INFORMATION.
SALT TANK LEVEL
OK OK,
Low
3. If a Smart Brine Tank Probe is installed, this
screen displays the salt level. The status is OK
unless the SBT probe detects low salt level. If
the screen displays LOW a subsequent screen
displays APPROX DAYS OF SALT REMAINING.
Press to select the next information screen.
REMAIN CAPACITY
100% 0–100
4. The screen displays the softening capacity
remaining, displayed as a percentage of the total
capacity. During manually initiated regeneration,
assume 0 percent remaining capacity.
Press to select the next information screen.
REMAIN CAPACITY
740 GAL
0–no
limit
5. The screen displays the softening capacity
remaining, measured in gallons (liters).
Press to see the next information screen.
CURRENT FLOWRATE
0.0 GPM
0–no
limit
6. The screen displays the current flow rate,
measured in gallons (liters) per minute.
Press to see the next information screen.
TODAY’s USAGE
0 GAL
0–no
limit
7. The screen displays today’s water usage,
measured in gallons (liters).
Press to see the next information screen.
AVERAGE DAILY
300 GAL
0–no
limit
8. The screen displays average water usage for
this configuration. Press to see the next
information screen.

18 01023052 L 06/19
Screen Display Range Setting Description
NEXT REGEN ON
JAN-03 N/A
9. The screen displays the date
of the next regeneration, based
on average daily water usage.
Press to see the next information screen.
TOTAL WATER USED
1000 GAL
0–no
limit
10. The screen displays the total water used
for this configuration. Whole numbers are
displayed above 100 gallons.
Press to see the next information screen.
EXT FILT CAP REM
20000 GAL
0–no
limit
11. If an external filter is used, the screen
displays the remaining capacity of the filter.
When the remaining capacity reaches zero,
the system triggers the External Filter Alarm.
Press to return to the main menu.
>1)INFORMATION
2)MANUAL MODE
The screen displays the main menu.
Press to exit to the home screen.
SOFTENING
JAN-01-18 12:01P 12. The screen displays the home screen.

19
01023052 L 06/19
Error Codes
The HE Twin Controller, as well as the Remote Display (if connected), may display the following errors.
PROBLEM FOUND
APR-01-18 10:01A
When the HE Twin Controller identifies an error, it is programmed
to attempt to correct the error without user input. If the problem
persists, the HOME SCREEN displays PROBLEM FOUND.
Press to display the first error present.
Pos Sensor Err Press to display any additional errors present.
-->CLEAR ERRORS
Press and to view action: CLEAR ERRORS,
GO TO MENU, or EXIT. If you select CLEAR ERRORS,
the controller checks the error status and attempts to clear
the error. If the error still exists, the home screen displays PROBLEM
FOUND. If the error no longer exists the screen displays SYSTEM OK.
-->GO TO MENU 10. Contact your local Culligan dealer.

20 01023052 L 06/19
Regeneration There are several conditions that will cause the HE Twin Controller to trip a regeneration. The screen
displays REGEN Tonite when the control has signaled for a regeneration. Regenerating is displayed
while the control is in regeneration. The following are conditions that will call for regeneration:
1. When the Soft-Minder® meter has recorded the passage of a predetermined number of gallons.
2. When the Aqua-Sensor® Probe senses the hardness in the Cullex Media.
3. At the preset time, when the number of days without a regeneration is equal to the
regeneration interval (timeclock backup) setting.
4. At the preset time, when Regen Tonite is selected. The screen displays Regen Tonite.
5. Immediately, when the Regen Now is selected. The screen displays Regenerating.
6. Immediately, if power to the unit has been off for more than three hours
and the time of day has been restored.
7. At the preset time based on “Day-of-Week” Regeneration setting.
Follow either procedure to initiate a regeneration.
Delayed Regeneration
Screen Display Range Setting Description
SOFTENING
JAN-01-18 12:01P
N/A 1. From the HOME screen, press and hold for at
least five (5)seconds.
REGEN TONITE
JAN-01-18 12:01P
Regen
Tonite
2. The screen displays the regeneration status
on the first line of the display. The system will
regenerate at a scheduled time.
REGEN OFF
JAN-01-18 12:01P
Regen
Off
3. To cancel a delayed regeneration,
press and hold for at leave five (5) seconds.
The screen displays the new status.
Immediate Regeneration
Screen Display Range Setting Description
SOFTENING
JAN-01-18 12:01P
N/A 1. From the HOME screen, press
and hold for at least ten (10) seconds.
REGEN NOW
JAN-01-18 12:01P
Regen
Now
2. The screen displays the regeneration status
on the first line of the display. The softener
will initiate an immediate regeneration.
REGENERATING
JAN-01-18 12:01P
N/A 3. The first line of the screen displays
REGENERATING.
