Cumberland Super-Saver XL HH-SS-250-XL User manual

4801-1020
Super-Saver XLTM Heater
Agricultural Building Heater 120V, 60 Hz, ETL
Owner’s Manual
4801-1020
Version: 4.0
Date: 05-08-19

24801-1020 Super-Saver XLTM Heater
All information, illustrations, photos and specifications in this manual are based on the latest
information available at the time of publication. The right is reserved to make changes at any
time without notice.
• Standing Pilot Ignition
• Wash-Down Design
• 120 Volt (only)
Model BTUH kW
HH-SS-250-XL 250,000 73.3

Table of Contents
4801-1020 Super-Saver XLTM Heater 3
Contents
Chapter 1 Safety .....................................................................................................................................................4
Safety Guidelines ...................................................................................................................................4
Cautionary Symbols Definitions .............................................................................................................5
Safety Cautions ......................................................................................................................................6
Safety Sign-Off Sheet ..........................................................................................................................11
Chapter 2 General Information ...........................................................................................................................12
Heater Dimensions ...............................................................................................................................13
Tools Required .....................................................................................................................................13
Minimum Clearances ...........................................................................................................................13
Specifications and Requirements .........................................................................................................13
Chapter 3 Installation ..........................................................................................................................................14
Hanging the Heater ..............................................................................................................................14
Directions for Leveling ..........................................................................................................................14
Installing the Dual-Flare Duct ...............................................................................................................14
Connecting the Gas Supply .................................................................................................................14
Chapter 4 User Instructions ................................................................................................................................15
Connecting Electrical Power ................................................................................................................15
Start-Up ................................................................................................................................................15
Shutting OFF Heater ............................................................................................................................16
Variable Heat Output Adjustment .........................................................................................................17
Chapter 5 Maintenance ........................................................................................................................................18
Chapter 6 Wiring Diagrams - SPI Model ............................................................................................................19
Component and Wiring Diagram ..........................................................................................................19
Ladder Type Schematic Diagram .........................................................................................................20
Chapter 7 Servicing Instructions: SPI Model ....................................................................................................21
Standing Pilot Ignition System .............................................................................................................21
Chapter 8 Pipe Sizing Guidelines .......................................................................................................................22
Calculating HVR and ELOP .................................................................................................................22
Directions for Reading Pipe Size from Tables .....................................................................................22
Chapter 9 Parts List .............................................................................................................................................25
250K BTU (SPI) ...................................................................................................................................25
Chapter 10 Warranty ............................................................................................................................................31

44801-1020 Super-Saver XLTM Heater
1. Safety
Safety Guidelines
Safety guidelines are general-to-specific safety rules that must be followed at all times. This manual is
written to help you understand safe operating procedures and problems that can be encountered by the
operator and other personnel when using this equipment. Read and save these instructions.
As owner or operator, you are responsible for understanding the requirements, hazards, and precautions
that exist and to inform others as required. Unqualified persons must stay out of the work area at all times.
Alterations must not be made to the equipment. Alterations can produce dangerous situations resulting in
SERIOUS INJURY or DEATH.
This equipment must be installed in accordance with the current installation codes and applicable
regulations,whichmustbecarefully followed inallcases. Authoritieshaving jurisdictionmustbe consulted
before installations are made.
When necessary, you must consider the installation location relative to electrical, fuel and water utilities.
Personnel operating or working around equipment must read this manual. This manual must be delivered
with equipment to its owner. Failure to read this manual and its safety instructions is a misuse of the
equipment.
ST-0001-4

1. Safety
4801-1020 Super-Saver XLTM Heater 5
Cautionary Symbols Definitions
Cautionary symbols appear in this manual and on product decals. The symbols alert the user of potential
safety hazards, prohibited activities and mandatory actions. To help you recognize this information, we
use the symbols that are defined below.
DANGER
WARNING
CAUTION
NOTICE
This symbol indicates an imminently hazardous situation
which, if not avoided, will result in serious injury or death.
This symbol indicates a potentially hazardous situation
which, if not avoided, can result in serious injury or death.
This symbol indicates a potentially hazardous situation which,
if not avoided, can result in minor or moderate injury.
This symbol is used to address practices not related to
personal injury.
This symbol indicates a general hazard.
This symbol indicates a prohibited activity.
This symbol indicates a mandatory action.
ST-0005-2

1. Safety
64801-1020 Super-Saver XLTM Heater
Safety Cautions
Use Personal Protective Equipment
Eye
Protection
Hearing
Protection
Hand
Protection
Head
Protection
Respiratory
Protection Foot
Protection
Fall
Protection
• Use appropriate personal protective equipment:
• Wear clothing appropriate to the job.
• Remove all jewelry.
• Tie long hair up and back.
ST-0004-1
Follow Safety Instructions
• Warning: If the information in the manual is not followed exactly, a
fire or explosion can result, causing property damage, personal
injury or loss of life.
• Carefully read all safety messages in this manual and safety signs
on your machine. Keep signs in good condition. Replace missing
or damaged safety signs. Be sure new equipment components and
repair parts include the current safety signs. Replacement safety
signs are available from the manufacturer.
• Learn how to operate the machine and how to use controls
properly. Do not let anyone operate without instruction.
• If you do not understand any part of this manual or need
assistance, contact your dealer.
• Retain these instructions for future reference.
ST-0025-3

1. Safety
4801-1020 Super-Saver XLTM Heater 7
Sharp Edge Hazard
• This product has sharp edges, which can cause serious injury.
• To avoid injury, handle sharp edges with caution and always
use proper protective clothing and equipment.
ST-0036-2
Maintain Equipment and Work Area
• Do not attempt maintenance or repairs on the heater unless you
are competent to do so. Understand service procedures before
doing work.
• Use only genuine Cumberland/AP parts when maintaining the
heater. Use of other non-genuine parts is a misuse and may
lead to dangerous situations.
• Heater should be inspected before each use and at least
annually by a qualified service person.
• Be aware that the heater may operate under automatic control
and may start without warning.
• Do not service the heater without first disconnecting and
locking-out power.
• Keep area clean and dry.
• Keep hands, feet, and clothing away from moving parts.
• Keep the heater in proper working condition. Replace worn or
broken parts immediately.
• Keep the heater clean. Do not allow debris to collect around
motor, blower wheel, burner or controls. Burner orifice and hot
surface igniter must be kept clean and free of carbon build up.
• Be sure that all electrical enclosures and guards are closed and
locked before re-starting the heater.
• Igniter must be cool before wash-down. Heater must not be
operated for one hour following wash-down.
ST-0067-1

1. Safety
84801-1020 Super-Saver XLTM Heater
ST-0069-1
Install and Operate Electrical Equipment Properly
• The electrical connections and grounding of the appliance shall be in
compliance with the National Electric Code ANSI/NFPA 70 for the
United States or the Canadian Electrical Code for Canada, as well as
all local and state codes.
• This appliance is equipped with a three prong (grounding) plug for your
protection against electrical shock and should be plugged directly into
a properly grounded three-prong receptacle. Failure to use a properly
grounded receptacle can result in electric shock, personal injury
or death.
• If permanently connected to power supply, make sure a circuit breaker
or similar cutoff device is provided to permit disconnection of power for
servicing.
• Electrical equipment must be installed by a qualified electrician.
• Lock-out power source before making adjustments, cleaning, or
maintaining equipment.
Lifting Hazard
• Single person lift can cause injury.
• Use a mechanical lifting device to lift or move the equipment
during installation.
ST-0021-2
For Your Safety
• If you smell gas:
1. Open windows.
2. Don’t touch electrical switches.
3. Extinguish any open flames.
4. Immediately call your gas supplier.
• Do not store or use gasoline or any flammable vapors and liquids in
the vicinity of this or any other appliance.
ST-0064-1

1. Safety
4801-1020 Super-Saver XLTM Heater 9
Install and Operate Gas-Fired Equipment Properly
• Gas-fired equipment should be installed by a qualified pipe fitter and
must conform with local codes.
• For Canada: The equipment shall be installed in accordance with the
Natural Gas and Propane Installation Code, CSA B149.1, or the
Propane Storage and Handling Code, CSA B149.2, or applicable
provincial regulations, which should be carefully followed in all
cases. Authorities having jurisdiction should be consulted before
installations are made.
• For the United States: The equipment shall be installed in
accordance with the National Fuel Gas Code ANSI Z223.1/
NFPA 54.
• Check all connections for gas leaks.
• Do not operate heater with door open or panels.
• Do not move or handle heater while it is operating, hot, or connected
to power supply.
• Adequate ventilation is required. Combustion and ventilation air
must not be obstructed.
ST-0068-1
General Hazard Warning
• Failure to comply with precautions and instructions provided with
this heater can result in death, serious bodily injury and property
loss or damage from hazards of fire, explosion, burn,
asphyxiation, carbon monoxide poisoning, and/or electrical
shock.
• If you need assistance or heater information such as an
instruction manual, labels, etc. contact the manufacturer.
ST-0065-1

1. Safety
10 4801-1020 Super-Saver XLTM Heater
Improper Use Warning
• The intended use of this appliance is the heating of agricultural
animal confinement buildings.
• Not for home or recreational vehicle use. Installation of this heater
in a home or recreational vehicle may result in a fire or explosion,
property damage, personal injury or loss of life.
• Heater is not recommended for heating human living quarters.
• Keep solid combustibles, such as building materials, paper,
cardboard, feathers, straw and dust a safe distance away from
the heater as recommended by the instructions.
• Never use the heater in spaces which contain or may contain
volatile or airborne combustibles, or products such as gasoline,
solvents, paint thinner, dust particles, or unknown chemicals.
Failure to follow these instructions may result in a fire or
explosion, property damage, personal injury or loss of life.
ST-0066-1
Maintain Proper Gas Pressure
• Proper gas pressure must be provided to the inlet of the
appliance. Refer to the rating plate for proper gas supply
pressure.
• Gas pressure in excess of the maximum inlet pressure can cause
fires or explosions, leading to serious injury, death, building
damage or loss of livestock.
• Gas pressure below the minimum inlet pressure can cause
improper combustion leading to asphyxiation or carbon monoxide
poisoning, causing serious injury or death.
ST-0041-1

1. Safety
4801-1020 Super-Saver XLTM Heater 11
Safety Sign-Off Sheet
Below is a sign-off sheet that canbe used to verify that all personnel have read and understood the safety
instructions. This sign-off sheet is provided for your convenience and personal record keeping.
Date Employee Name Supervisor Name
ST-0007

12 4801-1020 Super-Saver XLTM Heater
2. General Information
1. Installation must conform with local, state, and national codes, or in the absence
of local codes, with the Standard for the Storage and Handling of Liquefied
Petroleum Gases, in accordance with ANSI/NFPA 58 and/or the National Fuel
Gas Code, ANSI Z223.1, as applicable.
2. Follow safety, maintenance, and test firing instructions packaged with Heater.
3. Refer to model specifications label for gas type (LP or Natural Gas).
4. Check all connections for gas leaks.
5. Gas supply and regulator must be installed outside building.
6. The hose assembly should be protected from traffic, building materials, and any
contact with hot surfaces both during and while in storage.
7. Do not open heater doors, or remove a heater panel, or move or handle the
heater while it is operating, hot, or connected to power supply.
8. Turn power OFF before servicing. (Heater may start at any time if power is
connected.)
9. Heater is not recommended for heating human living quarters.
10. Not to be used for heating where flammable liquids and vapors are stored or
used.
11. Inadequate gas volume and (or) pressure will directly influence the combustion
efficiency of the heater. Adequate gas volume and (or) pressure is the
responsibility of the installer.
12. Adequate ventilation is required.
13. Combustion and ventilation air must not be obstructed.
14. Not for use with duct work other than types provided by manufacturer.
15. Position heater properly before use. Heater must be level and in accordance with
minimum clearances.
16. For safety, this heater is equipped with air flow proving switch and manual reset
high limit switch.
17. Keep temperature of fuel containers below 100°F (37.8°C). Containers must be
installed outside building.
18. Heater must not be operated for one hour following wash-down.

2. General Information
4801-1020 Super-Saver XLTM Heater 13
Heater Dimensions
Tools Required
1. Adjustable Wrench
2. Pipe Glue
3. Gas Leak Testing Solution
4. 1/4" (7 mm) Nut Driver
NOTE: Install screw hooks with hammer or drill.
Be Sure to Check Delivery
Locate packing slip and make sure all of the listed parts are enclosed. If not, call your Distributor
immediately.
Minimum Clearances
The heater must be located a minimum of 12" (305 mm) from the ceiling, a minimum of 12" (305 mm) from
the wall on the sides and back, a minimum of 20" (508 mm) from the ground, and positioned such that
livestock and combustible materials are unable to come in contact with the heater or within 10' (3 m) of the
hot air discharge. (See Figure 3A on Page 14.)
Specifications and Requirements
NOTE: Refer to heater ratings plate for unit voltage, amperage, and frequency ratings.
Models 250K BTU Universal Mount
Weight 153 lbs.
Height 32" (81 cm)
Width 27-1/2" (70 cm)
Depth 19-1/4" (49 cm)
Model # Maximum Input Ventliation
(Air required to support combustion)
HH-SS-250-XL 250,000 BTUH (73.3 kW) 1200 CFM (2039 m3/hr)
LP/Propane
Gas
Maximum 14" W.C. (34.8 mbar) and minimum 12-1/2" W.C. (31.1 mbar) inlet gas supply pressure
acceptable at gas regulator connection. Burner manifold pressure 10" W.C. (24.9 mbar) at maximum
input. Gas pressure should be checked by a certified gas technician while heater is in operation.
Natural
Gas
Maximum 14" W.C. (34.8 mbar) and minimum 6" W.C. (14.9 mbar) inlet gas supply pressure
acceptable at gas regulator connection. Burner manifold pressure of 4" W.C. (9.9 mbar) at maximum
input. Gas pressure should be checked by a certified gas technician while heater is in operation.

14 4801-1020 Super-Saver XLTM Heater
3. Installation
Hanging the Heater
Chain Suspension
Mount the heater with chain hooks and chains so that the back of the heater is at least 12" (305 mm) from
the ceiling and wall. The heater must be a minimum of 20" (500 mm) from floor, and located so that
livestock and combustible materials are unable to come in contact with heater or within 10' (3 meters) of
the hot air discharge.
Cable Suspension
If frequent height adjustment is required, use cables and pulleys. Main line cable would be connected to
a winch.
Directions for Leveling
Adjust cables or chains as required to level the heater. Use a carpenter’s level to check that the heater
is level.
Installing the Dual-Flare Duct
Fold Dual-Flare duct (1) to shape as shown in Figure 3A. Install Dual-Flare duct to heater exhaust as
shown with sheet metal screws (3) provided. This provides a multi-directional heat flow (2) that may be set
by bending flaps.
Figure 3A
Connecting the Gas Supply
For gas connection, attach the regulator (2) to the High Pressure Line (3) at the outside of the building as
shown in Figure 3B. Connect flexible hose (1) to low pressure end of the regulator with special brass
coupling. Refer to table on Page 13 for LP and natural gas requirements.
Figure 3B
1
3
2
Ref # Description
1Flare Duct
2 Adjust flap to direct heat flow.
3Attach flare duct to heater with sheet
metal screws.
2
3
1
Ref # Description
1Flexible Hose
2 Gas Regulator
3High Pressure Line

4801-1020 Super-Saver XLTM Heater 15
4. User Instructions
Before turning ON gas, check main supply valve to be sure it is open. (See Figure 4A.) Be sure to check
all connections for leaks with a Gas Leak Testing solution. (soap and water work well.) Check to see if gas
valve knob is in the ON position. If not, turn counterclockwise until knob “clicks” into the ON position.
(This may not apply to all units.) Turn ON gas by turning the ball valve handle into vertical position.
Figure 4A
Connecting Electrical Power
Make sure a circuit breaker or similar cutoff device is provided to permit disconnection of
electrical power to heater for service and cleaning. All electrical work should be performed by a
certified electrician. If no adjustments are made, the heater will operate every time power is supplied and
theON/OFFswitch isactivated.Ifan externalthermostat istobeused(see componentandwiring diagram
on Page 19), the heater will operate only when power is supplied, the ON/OFF switch is activated, and the
thermostat indicates a call for heat.
Start-Up
Before turning ON gas, verify that the main supply valve is open. Check all connections for leaks with a
soap and water gas leak testing solution. Verify the gas valve knob is in the ON position. If not, turn
counterclockwise until knob “clicks” into the ON position. (This may not apply to all units.) Turn ON gas by
turning ball valve handle into vertical position.
IMPORTANT: Heater installation must be performed by a qualified gas heater service personnel.
Follow the below steps to light the pilot and position the gas valve control for use.
NOTE: Do not supply power to the heater during this start-up. Supplying power to the heater at this stage
could cause the blower to start which will make lighting the pilot difficult.
1. Open all manual gas supply valves and check all connections for gas leaks.
2. Position the gas shut off valve (1) to the pilot position.
3. Fully depress the red pilot button, located on the gas valve, while applying a flame to the pilot light
burner. If the red pilot button cannot be depressed the gas shut off knob (1) is not in the PILOT (3)
position.
4. After the pilot light is lit, keep the red pilot button depressed for approximately 30 seconds to heat the
thermocouple.
1
2
3
Ref # Description
1Gas Valve “ON” Position
2ToGasSupply
3To Heater

4. User Instructions
16 4801-1020 Super-Saver XLTM Heater
5. With the pilot light lit and once the thermocouple is warmed, move the gas shut off knob (1) to the
ON position (2).
Figure 4B
6. Supply power to the heater by either plugging the power cord into an approved outlet, a piggy back
thermostat, or moving the thermostat to a desired temperature above room temperature if the heater
has been wired with this type of thermostat.
7. During the first start-up for a new heater installation or if the heater gas has been shut off, it may take
longer to purge the air from the lines before the pilot will light.
8. Once the heater is running for the first time, verify the inlet and manifold pressures match those on
the Danger label (listed under Acceptable Pressures) on the outside of the heater. This should be
done only by a qualified gas installer. Operating the heater at a pressure too high or too low will
adversely affect the operation of the heater and will void all warranties.
NOTE: If the pilot light extinguishes, allow a five minute complete shut off period before attempting to
relight the pilot.
Shutting OFF Heater
Shut off main gas supply valve, close ball valve, and disconnect electrical power.
Ref # Description
1Gas Shut Off Knob
2ON
3Pilot
4OFF
5Pilot Button
Limiting Excess Carbon Dioxide (CO2 )
In order to prevent hazardous accumulation of CO2 gases, the heater must
operate ONLY in a properly ventilated room.
Ventilation requirements are given in Specifications and Requirements Section
on Page 13.
Both installer and operator must ensure that the building’s ventilation rate never
drops below the noted limits.

4. User Instructions
4801-1020 Super-Saver XLTM Heater 17
Variable Heat Output Adjustment
1. Some models of propane (LP) gas or natural gas heaters have a throttle valve (1) located between
the gas control valve (2) and gas manifold assemblies (3) which is used for varying the heat output.
NOTE: THIS IS NOT A MANUAL GAS CUT OFF VALVE.
2. The throttle valve (1) can be adjusted to deliver either minimum heat or maximum heat. When the
throttle valve handle is parallel to the gas flow, the valve is completely open to deliver maximum heat
output. Refer to Figure 4C. The throttle valve (1) may be adjusted to minimum heat output by turning
the handle 90° to the gas flow or any position between the maximum and minimum settings.
Refer to Figure 4D.
Figure 4C
Figure 4D
Ref # Description
1Throttle Valve
2 Gas Control Valve
3Gas Manifold
Maximum Heat
Minimum Heat
90% of Maximum
75% of Maximum

18 4801-1020 Super-Saver XLTM Heater
5. Maintenance
1.The appliance area should be kept clear and free from combustible materials, gasoline and other
flammable vapors, and liquids.
2. The flow of combustion and ventilation air must not be obstructed.
3. Your Super Saver XLTM Heater should be inspected before each use, and at least annually by a
qualified service person.
4.The hoseshould bevisually inspectedpriortoeachuseof theheater. Ifit isevident thereis excessive
abrasion or wear or the hose is cut, it must be replaced prior to the heater being put into operation.
The replacement hose assembly shall be that specified by the manufacturer. (Refer to parts list on
on Pages 25-30.)
5. Inspect heater and gas connections periodically for gas leaks with an approved gas leak testing
solution; applying a soapy water mixture to gas connections works well. Bubble formation indicates
a leak.
6. Keep heater clean at all times.
a. Open doors and blow out dust with high pressure air hose. Be sure interior of burner and flared
end are kept clean.
b. Burner orifice and pilot ignition assembly must be kept clean and free of carbon build-up.
c. Check blower wheel regularly for dust accumulation and clean periodically for maximum airflow.
d. Thermostat coils must be kept clean to assure proper temperature control.
e. Pilot assembly must be cool before wash-down. Do not operate heater for one hour following
wash-down.
DISCLAIMER
This appliance rating is based on the use of ANSI LC-2 test gases including LP (2500 BTU/ft3,
93.15 MJ/m3) and natural gas (1075 BTU/ft3, 40 MJ/m3). Cumberland makes no guarantees regarding
the proper operation of this appliance when these conditions are not met.

4801-1020 Super-Saver XLTM Heater 19
6. Wiring Diagrams - SPI Model
Component and Wiring Diagram

6. Wiring Diagrams - SPI Model
20 4801-1020 Super-Saver XLTM Heater
Ladder Type Schematic Diagram
