Cumberland PNEG-1096 User manual

2.66" INSIDE STIFFENED FLAT BOTTOM TANKS
2.66" OUTSIDE STIFFENED FLAT BOTTOM TANKS
4.00" INSIDE STIFFENED FLAT BOTTOM TANKS
4.00" OUTSIDE STIFFENED FLAT BOTTOM TANKS
2.66" COMMERCIAL HOPPER TANKS
4.00" FARM-COM HOPPER TANKS
ASSEMBLY MANUAL FOR
LADDERS,
SAFETY CAGES,
& PLATFORMS
Owner's Manual
Manual#PNEG-1096
PRINTED:2/2004
PNEG-1096

3
PNEG-1096 Ladder, Safety Cage, & Platforms
2.66" INSIDE STIFF. LADDER SAFETY CAGE & PLATFORM INSTR.
LADDER PLACEMENT/PLATFORM SUPPORT ASSEMBLY
EXTENSION RAILS/EAVE ADJUSTABLE BRACES
PLATFORM & HANDRAIL ASSEMBLY/EAVE SAFETY CAGE
2.66" INSIDE STIFFENED TANK LAYOUT
2.66" LADDER OFFSET CHART
SAFETY CAGE BELL SECTIONS
REST PLATFORM OFFSET LOCATION
INSIDE LADDER PLACEMENT AND SUPPORTS
2.66" OUTSIDE STIFF. LADDER SAFETY CAGE & PLATFORM INSTR.
LADDER PLACEMENT/PLATFORM SUPPORT FOR 2-POST/3-PANEL
LADDER PLACEMENT/PLATFORM SUPPORT FOR 3-POST/3 & 4-PANEL
EXTENSION RAILS/EAVE ADJUSTABLE BRACES
PLATFORM & HANDRAIL ASSEMBLY/EAVE SAFETY CAGE AND EXTENSION
2.66" OUTSIDE STIFFENED TANK LAYOUT
2.66" LADDER OFFSET CHART
SAFETY CAGE BELL SECTIONS
INSIDE LADDER PLACEMENT AND SUPPORTS
4.00" INSIDE STIFF. LADDER SAFETY CAGE & PLATFORM INSTR.
LADDER PLACEMENT/PLATFORM SUPPORT ASSEMBLY
EXTENSION RAILS/EAVE ADJUSTABLE BRACES
PLATFORM & HANDRAIL ASSEMBLY/EAVE SAFETY CAGE AND EXTENSION
4.00" INSIDE STIFFENED TANK LAYOUT
4.00" LADDER OFFSET CHART
SAFETY CAGE BELL SECTIONS
REST PLATFORM OFFSET LOCATION
INSIDE LADDER PLACEMENT AND SUPPORTS
4.00" OUTSIDE STIFF. LADDER SAFETY CAGE & PLATFORM INSTR.
LADDER PLACEMENT/PLATFORM SUPPORT ASSEMBLY FOR TANKS 4 - 9 RINGS
EXTENSION RAILS/EAVE ADJUSTABLE BRACES
PLATFORM & HANDRAIL ASSEMBLY/EAVE SAFETY CAGE AND EXTENSIONS
INSIDE LADDER PLACEMENT AND SUPPORTS
LADDER PLACEMENT/PLATFORM SUPPORT ASSEMBLY FOR TANKS 10 - 14 RINGS
EXTENSION RAILS/EAVE ADJUSTABLE BRACES
PLATFORM & HANDRAIL ASSEMBLY
4.00" OUTSIDE STIFFENED TANK LAYOUT AND LADDER OFFSET CHART
EAVE SAFETY CAGE & BELL SECTIONS
REST PLATFORM OFFSET LOCATION
INSIDE LADDER PLACEMENT AND SUPPORTS
2.66" COMM. HOPPER TANKS (NCHT)
2.66" (NCHT) TANK LAYOUT AND LADDER OFFSET CHART
LADDER SUPPORTS
ACCESS TO SIDEWALL DOOR AND CONNECTED TO HOPPER COLUMNS
2.66" OUTSIDE STIFF. OPTIONAL EXTENTED PLATFORM
LADDER PLACEMENT
PLATFORM PACKAGE LS-6683
PLATFORM PACKAGE LS-6683 CONNECTED TO HOPPER COLUMNS
400" FARM-COM HOPPER TANKS (FCHT)
4.00" (FCHT) TANK LAYOUT AND LADDER OFFSET CHART
LADDER PLACEMENT
ACCESS TO SIDEWALL DOOR AND CONNECTED TO HOPPER COLUMNS
TABLE OF CONTENTS
10-12
13
14-15
16
17
18
19
20-21
22-23
24-25
26
27-29
30
31
32
33-34
35-37
38
39-40
41
42
43
44
45-46
47-49
50
51-52
53-54
55-56
57
58
59
60-61
62
63-64
65-66
67
68
73-74
75
76
69-70
71
72

4PNEG-1096 Ladder, Safety Cage, & Platforms
SAFETY GUIDELINES
DANGER indicatesanimminentlyhazardoussituation
which,if not avoided,willresult in deathorserious injury.
This is the safety alert symbol. It is used to alert you
to potential personal injury hazards. Obey all
safety messages that follow this symbol to avoid
possible injury or death.
WARNING indicatesapotentiallyhazardous situation
which,if not avoided,couldresult in deathorserious injury.
NOTEindicates informationabouttheequipment that you
shouldpay special attentionto.
Thismanual containsinformationthat isimportantforyou,the owner/operator,toknow andunder-
stand.Thisinformation relates to protecting personal safety and preventing
equipment problems.Itis theresponsibilityofthe owner/operatortoinform anyone
operatingorworkingin the area of this equipmentofthesesafetyguidelines. Tohelp you
recognizethisinformation, we usethesymbols that aredefinedbelow.
Pleasereadthe manual and payattentiontothese sections. Failure toreadthismanual
andit’ssafety instructions is a misuseoftheequipmentand may lead to seriousinjuryordeath.
CAUTIONindicates a potentiallyhazardoussituation
which,if not avoided,mayresult in minorormoderate injury.
CAUTION usedwithoutthe safety alertsymbolindicatesa
potentiallyhazardous situationwhich,if notavoided,may
resultin property damage.
Safety

5
PNEG-1096 Ladder, Safety Cage, & Platforms
Safety
FOLLOW SAFETY INSTRUCTIONS
Carefully read all safety messages in this
manual and safety signs on your equipment.
Keep signs in good condition. Replace missing
or damaged safety signs. Be sure new equip-
ment components and repair parts include the
current safety signs. Replacement safety signs
are available from the manufacturer.
Neverwork alone.
If you do not understand any part of this manual
and need assistance, contact your dealer. Read ALL Safety Information.
INSTALL EQUIPMENT PROPERLY
This equipment shall be installed in accordance
with the current installation codes and
applicable regulations which should be carefully
followed in all cases. Authorities having
jurisdiction should be consulted before
installations are made.
Follow
Building
Codes.
STAY CLEAR OF HOISTED EQUIPMENT
Always use proper lifting/hoisting
equipment when assembling or
disassembling equipment.
Do not walk or stand under hoisted equipment.
Always use sturdy and stable supports when
neededfor installation.
Crush
Hazard.

6PNEG-1096 Ladder, Safety Cage, & Platforms
Safety
WEAR PROTECTIVE CLOTHING
Wear close fitting clothing and safety equipment
appropriate to the job. Keep hair, loose clothing, &
shoestrings away from rotating & moving parts.
Safety glasses should be worn at all times to
protect eyes from debris.
Wear gloves to protect your hands from sharp
edges on plastic or steel parts.
A respirator may be needed to prevent breathing
potentially toxic fumes and dust.
Wear hard hat and steel toe boots to help protect
your head and toes from falling debris.
Eye Protection
Gloves
Steel Toe
Boots
Respirator
Hard Hat
PREPARE FOR EMERGENCIES
Make sure someone is nearby who is aware of
the proper emergency procedures in the event of
an accident or emergency.
Be prepared if fire starts.
Keep a first aid kit and fire extinguisher handy.
Keep emergency numbers for doctors, ambu-
lance service, hospital, and fire department near
yourtelephone. Have Emergency
Equipment Ready.

7
PNEG-1096 Ladder, Safety Cage, & Platforms
Roof Disclaimer
Roof Damage Warning and Disclaimer
THE MANUFACTURER DOES NOT
WARRANTANY ROOF DAMAGE
CAUSED BY EXCESSIVE VACUUM
OR INTERNAL PRESSURE FROM
FANS OR OTHER AIR MOVING
SYSTEMS. ADEQUATE VENTILATION
AND/OR "MAKEUP AIR" DEVICES
SHOULD BE PROVIDED FOR ALL
POWERED AIR HANDLING SYSTEMS.
THE MANUFACTURER DOES NOT
RECOMMEND THE USE OF
DOWNWARD FLOW SYSTEMS
(SUCTION). SEVERE ROOF DAMAGE
CAN RESULT FROM ANY BLOCKAGE
OF AIR PASSAGES. RUNNING FANS
DURING HIGH HUMIDITY/COLD
WEATHER CONDITIONS CAN CAUSE
AIR EXHAUST OR INTAKE PORTS TO
FREEZE.

8PNEG-1096 Ladder, Safety Cage, & Platforms
Safety Decal
ATTENTION: The decal shown below should be present on the inside of the two ring door cover, 24"
portholedoorcoverandtheroofmanwaycover. If adecal has been damaged or is missingin any of these
locationscontactthe manufacturerfor afreereplacementdecal.
DECALS
P.O. BOX 20
ASSUMPTION, IL. 62510-0020
[phone]

9
PNEG-1096 Ladder, Safety Cage, & Platforms
ATTENTION: The decal shown below should be present on the outside of the two ring door cover, 24”
porthole door cover and roof manway cover. If a decal has been damaged or is missing in any of these
locations contact the manufacturer for a free replacement decal.
DECALS
P.O.BOX20
ASSUMPTION,IL.62510-00020
(217)-226-4421
Safety Decal

10 PNEG-1096 Ladder, Safety Cage, & Platforms
2.66 INSIDE STIFFENED
THIS SECTION
FOR 2.66"
CORRUGATED
GRAIN BINS
INSIDE STIFFENED
