Circuit breaker button is
projecting from the back of
the unit.
Circuit breaker has tripped due to an overload.
Turn the UPS off and unplug at least one piece of
equipment. Wait 10 seconds, reset the circuit breaker
by depressing the button, and then turn the UPS on.
The UPS does not perform
expected runtime.
Battery not fully charged.
Recharge the battery by leaving the UPS plugged in.
Please contact CyberPower Systems about
replacement batteries.
The UPS will not turn on.
The on/off switch is designed to prevent
damage from rapidly turning it off and on.
Turn the UPS off. Wait 10 seconds, and then turn the
UPS on.
The unit is not connected to an AC outlet.
The unit must be connected to a 120V 60Hz outlet.
Please contact CyberPower Systems about
replacement batteries.
Please contact CyberPower Systems.
PowerPanel®Personal
software is inactive (all
icons are gray).
The USB / serial cable is not connected.
Connect the USB / serial cable to the UPS unit and an
open USB / serial port on the back of the computer.
You must use the cable that came with the unit.
The USB / serial cable is connected to the
wrong port.
Check the back of the computer for an additional USB /
serial port. Move the cable to this port.
The unit is not providing battery power.
Shutdown your computer and turn the UPS off. Wait
10 seconds and turn the UPS back on. This should
reset the unit.
Additional troubleshooting information can be found under “Support” at www.cyberpowersystems.com
On-Battery Output Voltage
Max. Load for UPS Outlets (5 Outlets)
Max. Load for Full-Time Surge Protection outlets (9 Outlets)
On-Battery Output Wave Form
+ 32°F to 104°F / 0°C to 40°C
Operating Relative Humidity
3.9" x 9.0" x 10.2" (100 x 227.5 x 260mm)
Typical Battery Recharge Time
24 Hours to 90% from full load discharge
Sealed Maintenance Free Lead Acid Battery
UL1778(UPS), CSA C22.2 No 107.3, FCC/DoC Class B
*Runtime based on testing fully-charged, new batteries at normal operating conditions. Runtime curve is approximate and varies based on
battery age, level of charge at test, environment, and other variables.
SYSTEM FUNCTIONAL BLOCK DIAGRAM
TERMS AND CONDITIONS OF THE CYBERPOWER LIMITED WARRANTY
Please read the following terms and conditions carefully before using CyberPower products (the "CPS Product"). By using the CPS product,
you agree to be bound by the terms of this Limited Warranty (collectively the "Warranty"). IF YOU DO NOT AGREE TO THE WARRANTY
TERMS AND CONDITIONS, YOU MUST RETURN THE PRODUCT BEFORE USING, AND OBTAIN A FULL REFUND. THIS WARRANTY
GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM ONE PLACE TO ANOTHER.
YOUR ACCEPTANCE OF THIS WARRANTY MAY MODIFY OR WAIVE ANY OTHER RIGHTS YOU HAVE.
Cyber Power Systems (USA), Inc. ("CyberPower") provides this Limited Warranty.
WARRANTY COVERAGE
The warranty covers only the original purchaser and ends when the original purchaser no longer owns the CPS product. The warranty
covers defects in materials and workmanship in the CPS Product under normal use and to perform as designed, after correct installation
and under the operating conditions described in the User's Manual. Proof of purchase (receipt and / or invoice) is required for warranty
coverage.
The warranty period varies according to the type of product purchased. Please check our website at www.cyberpowersystems.com for
additional information on the applicable product.
For warranty claims:
Telephone:
USA (877) 297-6937
Latin America & Caribbean (800) 279-6580
Or write to us at:
Cyber Power Systems (USA), Inc.
4241 12th Ave. E., Suite 400
Shakopee, MN 55379
2. Toreplace the CPS Product, CyberPower will replace, at no additional cost, any CPS Product or Equipment at its sole discretion;
Through the network of distributors, wholesalers and representatives of CyberPower; And / or directly from the factory to the end user.
CyberPower, in its sole discretion, may replace the defective or damaged CPS Product with a new or reconditioned product, without prior
notice.
3. CyberPower covers shipping costs when CPS products are shipped to the end user. In the case of Latin America and the Caribbean,
CyberPower may choose to ship the replacement unit to the export agent or end-user load agent in the United States at no additional cost.
The record importer (customer) is responsible for complying with all applicable US Export Laws and requirements, as well as your specific
country import process. CyberPower may require the customer to return the warranty unit to a local dealer, or back to CyberPower, or to
destroy and / or dispose of a damaged unit locally. The customer covers shipping costs only if necessary and is required to return the CPS
product to CyberPower.
4. In the event that CyberPower determines that a warranty unit can not be replaced by an equal or equivalent product, CyberPower may
reimburse the end user for the purchase price of the product, including taxes, up to a maximum of the suggested MSRP,plus applicable
taxes. The refund can be processed in US dollars converted into local currency at the time of purchase. The end user must provide valid
receipts and purchase documentation for an approved channel to validate the claim.
5. MEXICO - Cyber Power Systems (USA), Inc., under the CyberPower brand, markets products that are designed and marketed for use
primarily in the United States. CyberPower may provide a Connected Equipment Guarantee (CEG) for certain products. THE
CONNECTED EQUIPMENT GUARANTEE IS ONLY VALID FOR PRODUCTS INSTALLED IN THE UNITED STATES, AND IS NOT VALID
IN OTHER COUNTRIES, UNLESS SPECIFIED. Any reference to Connected Equipment Guarantee in documentation, packaging, or
warranty isonly valid for equipment installed in the United States. Products marketed or otherwise installed in Mexico are only covered by a
manufacturer's Guarantee Policy and are not covered by a connected equipment warranty.
Cyber Power Systems S.A. Of C.V. (CyberPower): Provides a limited warranty, depending on the product model, from the date of purchase
in all its parts and labor, against any manufacturing defect, under the following CONDITIONS:
To make this guarantee effective, you must present this policy stamped by the establishment that sold it and / or the original invoice, without
violating the seal of warranty, together with the product at the place of purchase or at the address:
Aniceto Ortega #634, Col. Del Valle
Del. Benito Juárez, C.P. 03100,
Ciudad de México, México
Tel: (0155) 4622-8654
Return transportation costs, once repaired and resulting from their compliance, will be covered by CyberPower.
The repair time, in no case, will be more than 30 days from the date the equipment is received at the Service Center.
At the end of this warranty, spare parts, parts and accessories for this product can be purchased directly from CyberPower.
THIS WARRANTY SHALL NOT BE EFFECTIVE IN THE FOLLOWING CASES:
If the equipment has been used in conditions other than normal.
If the equipment has not been operated following the instructions in the instruction manual.
If the equipment has been modified, opened or repaired by unauthorized personnel.
CyberPower product registration facilitates the management of warranty claims and also allows notifications of product enhancements,
updates and other announcements. We suggest you create a user account on the CyberPower page according to the instructions given
here:
Please contact our technical support department for installation assistance, technical support and general product questions.
(877) 297-6937
(800) 279-6580
Telephone:
USA
Latin America & Caribbean
Email:
Input
Normal Mode
Battery Mode
Output This Guarantee does not cover any:
Software that has been corrupted or needs to be replaced due to product failure or any data lost as a result of failure, or restoring data or
records, or reinstalling software;
Use, misuse, modification, performance or storage outside the environmental limits of the CPS product, or equipment connected to it, nor
for damage while in transit or in storage. Products that should not be used with the CPS Product, such as laser printers, aquarium
appliances, medical or life support devices, etc.;
Defects or damages due to: accidents, fires, floods, lightning, vandalism, acts of God, neglect, abuse or misuse among others: in shipping,
storage, installation, application, and operation or maintenance not in With industry-standard recommendations and practices.
System batteries and all other peripheral products and accessories not supplied by CyberPower (including components and software) or
the installation, operation, maintenance or service of such accessories;
And, the reimbursement of labor, pressure washing, access, removal, installation, employee expenses, or any other expenses you may
incur in connection with the repair or replacement of the product, the accessories supplied with the product: cables, user manual, CD, etc.;
Any product that the serial number printed and attached to the product has been: removed, disfigured, changed, altered, or manipulated.
Advanced Energy-Saving Patented Bypass Technology
CyberPower’s patented GreenPower UPS™ with Bypass Technology reduces UPS energy costs by up to 75% compared
to conventional UPS models. Even when utility power is normal, conventional UPS models constantly pass power through
a transformer. By contrast, under normal conditions the advanced circuitry of a GreenPower UPS™ bypasses the
transformer. As a result, the power efficiency is significantly increased while decreasing waste heat, using less energy,
and reducing energy costs.
When an abnormal power condition occurs, the GreenPower UPS™ automatically runs power through its transformer to
regulate voltage and provide “safe” power. Since utility power is normal over 88% of the time, the GreenPower UPS™
operates primarily in its efficient bypass mode.The GreenPower UPS™ is also manufactured in accordance with the
Restriction on Hazardous Substances (RoHS) directive making it one of the most environmentally-friendly on the market today.
FCC Compliance Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help"
Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the
equipment.
Canadian Compliance Statement: CAN ICES-3 (B)/NMB-3(B)
The only and exclusive remedies of the client are those provided by this Guarantee.
TO THE EXTENT PERMITTED BY LAW, THIS WARRANTY AND THE ESTABLISHED REMEDIES ARE EXCLUSIVE AND REPLACE ALL
OTHER WARRANTIES, REMEDIES, AND CONDITIONS; WHETHER ORAL, WRITTEN, STATUTORY, EXPRESS OR IMPLIED.
CYBERPOWER DISCLAIMS ALL STATUTORY AND IMPLIED WARRANTIES; INCLUDING WITHOUT LIMITATION, WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE AND WARRANTIES AGAINST HIDDEN OR LATENT DEFECTS,
TO THE EXTENT PERMITTED BY LAW. CYBERPOWER LIMITS THE DURATION AND THE RESOURCES OF SUCH WARRANTIES TO
THE DURATION OF THIS LIMITED WARRANTY AND, AT CYBERPOWER'S OPTION, THE REPAIR OR REPLACEMENT SERVICES
DESCRIBED ABOVE. SOME STATES (COUNTRIES AND PROVINCES) DO NOT ALLOW LIMITATIONS AS TO THE TIME WHICH CAN
LAST AN IMPLIED WARRANTY (OR CONDITION), SO THE ABOVE LIMITED LIMITATION MAY NOT APPLY TO YOU.
Regardless of the basis on which you are entitled to claim damages against CyberPower; IN NO EVENT SHALL CYBERPOWER BE
LIABLE TO YOU FOR INJURY OR DAMAGE CAUSED TO BUSINESS, PROFITABILITY, RESULTS, REVENUE, TRADEMARK, GOOD
FAITH, OR FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, EVEN IF YOU HAVE BEEN
ADVISED OF THE RISK AND POSSIBILITY OF SUCH DAMAGES.
In addition, the product and the equipment connected to it must have been used properly in a suitable, appropriate environment and in
accordance with any license, the instructions in the brochure or warnings provided with the product, and the equipment connected to it.
Without limiting the foregoing:
1. This Warranty is not valid unless the CPS Product and connected equipment are connected to properly grounded outlets (including
compliance with the electrical and safety codes of the most recent electrical code) without the use of adapters or other connectors of any
kind.
2. The CPS product must be connected directly to the power source and equipment directly connected to the CPSproduct.
3. The product must be directly connected to the CPS Product; Must not be connected "in series" with extension cables, another product or
device similar to the CPS product, surge suppressor or power supply: this type of installation voids thewarranty.
4. The CPS product and the connected equipment must have been used correctly in a suitable environment and in accordance with any
applicable license, instruction manual and manufacturer's warnings.
5. The CPS Product must have been used at all times within the limitations in the voltage capacity of the CPSProduct.
6. The product is not for use in high risk activities or connected to aquariums. The product is not intended for use in hazardous
environments requiring fail-safe operation, or for any circumstance where failure of the product could lead directly to death, personal injury,
or serious physical or material damage affecting the operation or The safety of any medical or life support device (collectively, "High Risk
Activities"). CyberPower expressly disclaims any express or implied warranty of fitness for high risk or aquarium activities. Such use is
improper and voids this warranty.
Cyber Power Systems (USA), Inc.
4241 12th Ave E., Suite 400
Shakopee, MN 55379
(877) 297-6937
Telephone:
USA
Latin America & Caribbean
Email:
Latin America & Caribbean
Sales:
CYBERPOWER GREENPOWER UPS™ TECHNOLOGY
Limited Warranty and Connected Equipment Guarantee
If the connected equipment can tolerate more power events (example: unstable power
often associated with stormy weather), select Low Sensitivity and the UPS will go to
Battery Mode less often.
The UPS will go to Battery Mode if the power is unstable.
If the connected equipment is more sensitive to power events, select High Sensitivity
and the UPS will go to Battery Mode more often.
