CyberPower OP650 User manual

User’s Manual
Office Series UPS
OP650
ADDITIONAL INSTALLATION TIPS CAN BE FOUND AT:
www.cyberpowersystems.com/FAQs.htm

TABLE OF CONTENTS
IMPORTANT SAFETY WARNINGS…………….……………………………………….………1
INSTALLING YOUR UPS SYSTEM…………………….………………………………….……2
-UNPACKING…… ………………………………………………………………..2
- HARDWARE INSTALLATION GUIDE…………………………………….……2
BASIC OPERATION…………………………………………...................................................2
- FRONT PANELAND REAR PANEL DESCRIPTION....................................2
BATTERY REPLACEMENT AND STORAGE………………………………………….…...….4
- BATTERY REPLACEMENT PROCEDURE……………………………...……4
TROUBLESHOOTING……………………………………………………….........................….6
TECHNICAL SPECIFICATIONS…………………………………………………….………..….7
DEFINITION FOR ILLUMINATED LED INDICATORS……………………………………..…8
LIMITED WARRANTY AND POWER CONTROL GUARANTEE……………………………9
Thank you for purchasing a CyberPower Systems Product. To enjoy all the features and
benefits of this Uninterruptible Power System (UPS), please read and follow all installation
and operation instructions completely. This UPS is designed to provide guaranteed power
protection for connected electronic equipment. The accompanying PowerPanel Plus™
software saves data, closes open applications and automatically shuts down your computer
system in an intelligent and orderly manner.

OP650
Guaranteed Uninterruptible Power System
IMPORTANT SAFETY WARNINGS
(SAVE THESE INSTRUCTIONS)
This manual contains important instructions that should be followed during installation and
maintenance of the UPS and batteries. Please read and follow all instructions carefully
during installation and operation of the unit. Read this manual thoroughly before attempting
to unpack, install, or operate.
CAUTION! UPS must be live parts inside can be energized by the battery, even when
AC outlet with fuse or circuit breaker protection. DO NOT plug unit into an outlet that is not
grounded.
CAUTION! DO NOT USE FOR MEDICAL OR LIFE SUPPORT
EQUIPMENT! CyberPower Systems does not sell products for life support or medical
applications. DO NOT use in any circumstance that
would affect operation or safety of any life support equipment, with any medical applications,
or patient care.
CAUTION! The battery can energize hazardous live parts inside even when the AC
input power is disconnected.
CAUTION! To prevent the risk of fire or electric shock, install in a temperature and
humidity controlled indoor area, free of conductive contaminants. (Please see specifications
for acceptable temperature and humidity range).
CAUTION! To reduce the risk of electric shock, do not remove the cover, except to
service the battery. No user serviceable parts inside, except for the battery.
CAUTION! To avoid electrical shock, turn off the unit and unplug it from the AC power
source before servicing the battery or installing a computer component.
CAUTION! DO NOT USE WITH OR NEAR AQUARIUMS! To reduce the risk of fire,
do not use with or near aquariums. Condensation from the aquarium can cause the unit to
short out.
1

INSTALLING YOUR UPS SYSTEM
UNPACKING
Inspect the UPS upon receipt. The box should contain the following:
(1) UPS Unit; (1) User’s Manual for UPS; (1) Warranty Registration Card;
(1) PowerPanel PlusTM Software Disk; (1) User’s Manual for PowerPanel PlusTM;
(1) Serial Interface Cable (DB-9); (1) Serial-to-USB cable; (1) Telephone Cable
HARDWARE INSTALLATION GUIDE
1. Connect the equipment to your UPS outlets. Items such as copiers, laser printers,
vacuums, space heaters, or other large electrical devices should not be connected to
the UPS. Please assure that the total loads of your equipments must be less than the
maximum total power load of your UPS.
2. Connect your UPS power cord into a two-pole, three-wire
grounding receptacle only. Please avoid using extension
cords and adapter plugs. (To maintain optimal battery
charge, leave the UPS plugged in at all times.)
3. Press the UPS power button to turn it on. The “Power On” indicator will be illuminated in
“Green”.
4. Install your optional software and accessories. To use the software, simply connect the
enclosed serial interface cable to the serial port on the UPS and an open serial port on
the computer.
BASIC OPERATION
FRONT PANEL AND REAR PANEL DESCRIPTION
2

OP650
Guaranteed Uninterruptible Power System
◆ Power Switch
Press the power button to turn the UPS ON or OFF
◆ Power On Indicator
This LED is illuminated when the utility condition is normal and
the UPS outlets are providing “clean power”, free of surges and
spikes
◆ Using Battery Indicator
This illuminates during utility failure, indicating that the battery is
supplying power to the battery-power supplied outlets.
◆BOOST Indicator This LED indicates that the UPS is operating in automatic
voltage regulation mode. When the led is flashed in rotation, it
indicates that the UPS unit boosts input voltage.
◆Buck Indicator This LED indicates that the UPS is operating in automatic
voltage regulation mode. When the led is illuminated
continuously, it indicates input over-voltage and the UPS unit
bucks the voltage.
◆ Battery Backup and Surge Protection Outlets
Provides three battery powered and surge protected outlets for
connected equipment to insure temporary uninterrupted
operation during a power failure and against surges and spikes.
◆ Surge Protection Outlets
Provides three surge protected only outlets for connected
equipment against surges and spikes
◆ Wiring Fault Indicator
This LED indicator will illuminate to warn the user that a wiring
problem exits with the AC outlet, such as bad ground, miss
ground or reversed wiring. If this is illuminated, the user is
advised to disconnect all electrical equipment from the outlet
and have an electrician check the outlet to insure proper wiring.
3

◆ Circuit Breaker Reset for Overload Protection
Circuit breakers provide optimal overload protection. When overload
occurs, the circuit breaker will switch to battery mode. You will need to
reset the circuit breaker so UPS will provide the power from utility.
◆ Serial Port to PC
This port allows connection and communication from the DB-9 serial or
USB port on the computer to the UPS unit. The UPS communicates its
status to the PowerPanel Plus™ software. This interface is also
compatible with the UPS service provided by Windows NT, 2000 and XP.
◆ Ethernet (RJ-45) Network Protection Ports
These ports are the protection for your computer network cable, modem
or telephone.
BATTERY REPLACEMENT AND STORAGE
Contact your dealer or call the number in this manual for information on battery replacement.
The order numbers for the battery are as follows:
BA-OP650 for OP650
CAUTION! Read and follow the IMPORTANT SAFETY INSTRUCTIONS before servicing
the battery. Service the battery under the supervision of personnel knowledgeable of
batteries and their precautions. Keep unauthorized personnel away from batteries.
CAUTION! Use only the specified type of battery. See your dealer for replacement
batteries.
CAUTION! The battery may present the risk of electrical shock. Do not dispose of batteries
in a fire, as it may explode. Follow all local ordinances regarding proper disposal of
batteries.
CAUTION! Do not open or mutilate the batteries. Release electrolyte is harmful to the skin
and eyes and may be toxic.
CAUTION! Abattery can present a high risk of short circuit current an electrical shock. Take
the following precautions before replacing the battery:
1. Remove all watches, rings or other metal objects.
2. Only use tools with insulated handles.
3. DO NOT lay tools or other metal parts on top of battery or any battery terminals.
4. Wear rubber gloves and boots.
5. Determine if the battery is inadvertently grounded. If inadvertently grounded, remove
source of ground. CONTACT WITH A GROUNDED BATTERY CAN RESULT IN
ELECTRICAL SHOCK! The likelihood of such shock will be reduced if such grounds
are removed during installation and maintenance (applicable to a UPS and a remote
battery supply not having a grounded circuit).
4

OP650
Guaranteed Uninterruptible Power System
BATTERY REPLACEMENT PROCEDURE:
1. Turn off and unplug all connected equipment.
2. Turn the UPS off and unplug it from the AC power source.
3. Turn the UPS upside down.
4. Remove the 4 retaining screws and remove the cover.
5. Remove the battery from the compartment.
6. Disconnect the battery wires from the battery.
7. Install the replacement battery by connecting the red wire to the
positive (+) terminal of the battery and connecting the black
wire to the negative (-) terminal of the battery.
8. Slide the battery back into the compartment.
9. Replace the cover and the 4 retaining screws.
10. Recharge the unit for 4 – 8 hours to ensure the UPS performs
expected runtime
REMINDER: Batteries are consider HAZARDOUS WASTE and must be disposed of
properly. Contact your local government for more information about proper disposal and
recycling of batteries.
STORAGE:
First turn off your UPS and disconnect its power cord from the wall outlet. Disconnect all
cables connected to the UPS to avoid battery drain. To store your UPS for an extended
period, cover it and store with the battery fully charged. Recharge the battery every three
months to insure battery life. If the battery remains uncharged for an extended period of time,
it may suffer permanent loss of capacity. 5

TROUBLESHOOTING
Problem Possible Cause Solution
Batteries are not fully charged. Recharge the battery by leaving the
UPS plugged in.
The UPS does not
perform expected
runtime. Battery is slightly worn out. Contact CyberPower Systems at
[e-mail]
The on/off switch is designed to
prevent damage by rapidly turning
it off and on.
Turn the UPS off. Wait 10 seconds
and then turn the UPS on.
The unit is not connected to an AC
outlet. The unit must be connected to a 110/120v 60Hz outlet.
The battery is worn out. Contact CyberPower Systems at
[e-mail]
The UPS will not
turn on.
Mechanical problem. Contact CyberPower Systems at
[e-mail]
Circuit breaker is tripped due to
overload Turn the UPS off and unplug at least one piece of equipment. Wait 10
seconds, reset the circuit breaker
and then turn the UPS on.
Batteries are discharged Allow the unit to recharge for at least
4 hours.
Outlets do not
provide power to
equipment
Unit has been damaged by a
surge or spike. Contact CyberPower Systems at [e-mail]
The serial cable is not connected. Connect the serial cable to the
UPS unit and an open serial
port on the back of the
computer. You must use the
cable that came with the unit.
The serial cable is connected to
the wrong port. Check the back of the computer
for an additional serial port.
Move the cable to this port.
The unit is not providing battery
power. Shutdown your computer and turn the UPS off. Wait 10
seconds and turn the UPS back
on. This should reset the unit.
PowerPanel Plus™
is inactive (all icons
are gray).
The serial cable is not the cable
that was provided with the unit. You must use the cable that was included with the unit for
the software and the unit to be
able to communicate.
6

OP650
Guaranteed Uninterruptible Power System
TECHNICAL SPECIFICATIONS
Model OP650
Capacity (VA) 650VA
Capacity (Watts) 350W
Input
Input Voltage Range 85Vac – 145Vac
Frequency Range 47 – 63 Hz
Output
On Battery Output Voltage Simulated Sine Wave at 120Vac +/- 5%
On Battery Output Frequency 60 Hz +/- 1%
Transfer Time (Typical) 4ms
Overload Protection On Utility: Circuit Breaker, On Battery: Internal Current Limiting
Surge Protection and Filtering
Lightning / Surge Protection Yes
Internet Ready (DSL / Phone /
FAX / Modem Protection) RJ11/RJ45 (One In/One Out)
Physical
Total # of UPS Receptacles 3
Maximum Dimensions 28.3cm*9.1cm*16.4cm
Weight 6.4kg
Battery
Sealed Maintenance Free Lead
Acid Battery 12V / 7AHx1
User Replaceable Yes, Hot Swappable Battery Pack
Typical Recharge Time 8 Hours
Warning Diagnostics
Indicators Power On, Using Battery, Boost, Buck
Audible Alarms On Battery, Low Battery, Overload
Environmental
Operating Temperature +32°F to 95°F ( 0°C to 35°C )
Operating Relative Humidity 0 to 95% NON-CONDENSING
Communication
PowerPanelTM Software Windows 95/98/ME/NT/2000/XP
Management
Self-Test Yes
Auto-Charger Yes
Auto-Restart Yes
USB Yes
7

DEFINITIONS FOR ILLUMINATED LED INDICATORS
Power
On
Using
Battery
Wiring
Fault
Boost Buck
Circuit
Breaker Alarm
Condition
On Off Off Off Off Set Off Normal
On Off Off Flash Off Set Off
Max. boost 15% of input
voltage for output
regulation while input
voltage is from 8% to
30% under nominal.
On Off Off Off Flash Set Off
Max. buck 15% of input
voltage for output
regulation while input
voltage is from 8% to
26% over nominal.
Off On On/Off Off Off Set
Two
Beeps
Utility Failure- The UPS is
providingbatterypower to
theBattery-Power Supplied
outlets.
Off On On/Off Off Off Set
Rapid
Beeps
Utility Failure- The UPS is
providingbatterypower.
The rapid beeps indicatethe
battery will run outof charge
withina few minutes.
Off On Off Off Off Up
Two
beeps or
rapid
beeps
Overload- Occurs in the
Full-timeSurgeProtection
Outlets. Turn the UPS off
and unplugat least one
piece of equipment from the
UPS. Wait 5 seconds,
reset the circuitbreaker and
turnthe UPSon.
Off On/Off On/Off
On/Off/
Flash
On/Off/
Flash Set Long
Beep
Overload- Occurs in the
Battery-powerSupplied
Outlets. Turn the UPS off
and unplugat least one
piece of equipment from the
UPS. Wait 5 seconds,
reset the circuitbreaker and
turnthe UPSon.
On/Off On/Off On On/Off/
Flash
On/Off/
Flash Set/Up None
ElectricalWiring Fault- This
indicates a wiringa problem
such as abad ground,
missed ground or reversed
wiring within the AC outlet.
User is advised to
disconnect all electrical
equipmentfromthe outlet
andhavethe outletchecked
byanelectrician.
8
