CYBEX 13260 User manual

VR1®Leg Extension/Leg Curl
Medical Owner’s Manual
Strength Systems
Part Number 13260-888-4 A
www.cybexinternational.com

VR1®Leg Extension/Leg Curl
Medical Owner’s Manual
Strength Systems
Part Number 13260-888-4 A
Cybex® and the Cybex logo are registered trademarks of Cybex International, Inc.
VR1®and its mark are registered trademarks of Cybex International, Inc.
DISCLAIMER: Cybex International, Inc., makes no representations or warranties regarding the contents of this manual. We reserve the right to
revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such
revisions or changes.
© Copyright 2010, Cybex International, Inc. All rights reserved.
Printed in the United States of America.
10 Trotter Drive Medway, MA 02053 • 508-533-4300 • FAX [phone]
www.cybexinternational.com • [email protected] • [email protected] • 13260-888-4 A • March 2010
NOTE: This product meets or exceeds applicable ASTM, EN and Medical Standards.

1 Safety
Safety ......................... 1-1
Safety Guidelines and Practices . . . . 1-3
Warning/Caution Decals .......... 1-4
Regular Maintenance Activities..... 1-6
Using Proper Form . . . . . . . . . . . . . . 1-6
2 Exercises
Intended Use . . . . . . . . . . . . . . . . . . 2-1
Instructions . . . . . . . . . . . . . . . . . . 2-2
3 Customer Service
Contacting Service .............. 3-1
4 Maintenance
Daily Procedures ................ 4-1
Weekly Procedures .............. 4-2
Yearly Procedures ............... 4-4
Environment. . . . . . . . . . . . . . . . . . . 4-4
Storage . . . . . . . . . . . . . . . . . . . . . . 4-4
Table of Contents
Page i

Cybex VR1 13260 Leg Extension/Leg Curl Medical Owner’s Manual
Safety
Page 1-1
Safety
1 - Safety
This product complies with the Eurpoean Medical Directive 93/42/EEC.
Read the Owner’s manual carefully before using or servicing the equipment.
It is the responsibility of the facility owner and/or owner of the equipment to instruct users on proper operation of
the equipment and review all labels.
Warning: Serious injury could occur if these safety precautions are not observed:
User Safety Precautions
Follow advice of medical staff prior to beginning an exercise program.
•
If a user has special needs (such as medical rehabilitation or disability) it is essential that the owner (person•
with legal responsiblity) conducts a specific risk assessment to determine safe use and if necessary trained
staff are available to supervise the activity.
Injuries to health may result from incorrect or excessive training.
•
Read and understand warning labels and user manual prior to exercising. Obtain instruction prior to use.•
Keep body and clothing free from and clear of all moving parts.•
Inspect machine prior to use.• DO NOT use if it appears damaged or inoperable.
DO NOT
• attempt to fix a broken or jammed machine. Notify floor staff.
Use this machine only for the intended use.
• DO NOT modify the machine.
Be sure that the weight pin is completely inserted. Use only the pin provided by the manufacturer. If unsure,• seek assistance.
Never pin the weights in an elevated position.
• DO NOT use the machine if found in this condition. Seek
assistance from floor staff.
The intended use is not for children. Keep all children (12 and under) away. Teenagers (13 and over) must
•
be supervised.
DO NOT• use if guards are missing or damaged.
DO NOT
• use dumbbells or other incremental weights, except those provided by the manufacturer.
Inspect all cables and belts and connections prior to use.• DO NOT use if any components are worn, frayed
or damaged.
DO NOT
• remove any labeling from equipment. Replace any damaged labels
Stop exercising if you feel faint, dizzy or experience pain at any time while exercising and consult your• physician.

Cybex VR1 13260 Leg Extension/Leg Curl Medical Owner’s Manual
Safety
Page 1-2
Facility Safety Precautions
Read the Owner’s Manual carefully before assembling, servicing or using the equipment.
•
Securely anchor each machine to the floor using the anchor holes provided in each• machine.
Make sure that each machine is set up and operated on a solid level surface.
• Do not install
equipment on an uneven surface.
Make sure that all users are properly trained on how to use the equipment and proper supervision based on
•
individual indication is provided.
Make sure there is enough room for safe access and operation of the equipment.
• NOTE: At least one meter
around machine when in exercise position.
Perform mandatory safety inspections. Perform regular maintenance checks on the equipment. Also pay• close attention to all areas most susceptible to wear, including (but not limited to) cables, pulleys, belts and
grips.
Immediately replace worn or damaged components. If unable to immediately replace worn or
• damaged components, then remove from service until the repair is made.
Use only Cybex supplied components to maintain/repair the equipment.
•
Keep a repair log of all maintenance activities.•
Inspect all cables and belts and connections prior to use.• DO NOT use if any components are worn, frayed
or damaged.
NOTE: It is the sole responsibility of the user/owner or facility operator to ensure that regular
maintenance is performed.
NOTE: These machines do not have range limiting devices. Check range of movement of patient carefully before
using equipment. Select resistance according to the individual indication. If you are unsure then start at
lowest level. Perform exercises using smooth controlled movements.
NOTE: Cybex is not responsible for the actual anchoring of equipment. Consult with a
professional contractor.
NOTE: Use fasteners having a minimum of 2,220 newtons tensile capacity.
NOTE: If legs/frame does not contact surface, DO NOT pull down with anchors. Shim any leg or
frame not in contact with surface using flat washers.

Cybex VR1 13260 Leg Extension/Leg Curl Medical Owner’s Manual
Safety
Page 1-3
Cybex recommends that all training equipment be used in a supervised area. It is recommended that the
equipment be located in an access controlled area. Control is the responsibility of the owner. The extent of
control is at the discretion of the owner.
It is the responsibility of the purchaser/user of Cybex products to read and understand the owner’s manual, and
warning labels; as well as instruct all individuals, whether end users or supervising personnel, on proper usage
of the equipment.
Proper Usage:
Use machine only as described in the manual. Failing to follow proper instructions may result in injury.
Do Not Lean Against or Pull On the framework, weight stack, or any component, whether machine is at rest or
in use. Inappropriate or improper use may result in injury to users or third parties (bystanders).
Do not use machine if it is not located on a solid level surface or is improperly installed.
Provide an adequate safety perimeter between the machine, walls and other equipment to ensure that the facility
has the proper clearance for usage and training.
Securing Equipment:
The machine has holes in the feet, which allow for ease in anchoring to the floor. Cybex strongly recommends
that, to eliminate rocking, tipping or falling over due to incorrect usage and misuse, equipment be secured to a
solid, level surface.
1. The solid, level surface should not deviate more than 1/8” over a 10’ distance or as defined and required by
local building and architectural codes.
2. Anchoring of equipment must be completed by a qualified licensed contractor.
3. Anchoring holes are provided on the feet of the frame. All anchoring locations must be used when anchoring
the equipment to the floor.
4. Due to the wide variation of flooring on which machines may be anchored or installed, verify anchoring
method and anchoring fasteners with a qualified and licensed contractor.
5. A minimum pull out force of 220 lbs/100 kgs is required for each anchor position.
6. Do not use machine until it is properly anchored.
Maintenance:
Preventative maintenance allows proper equipment operation and reduces the risk of injury. Perform the mainte-
nance requirements as specified in the manual.
Standard Compliance:
Cybex products meet or exceed applicable ASTM and EN Standards.
Safety Guidelines and Practices

Cybex VR1 13260 Leg Extension/Leg Curl Medical Owner’s Manual
Safety
Page 1-4
4605-381-4 A
A
Personal injury may occur.
CAUTION
4000Y316-4
Keep away from moving
parts to avoid injury.
B
C
Arm will drop when
knob is pulled.
CAUTION
Support handle of
arm while adjusting
arm position to
avoid injury.
4510-321-4
D
Warning decals indicate a potentially hazardous situation, which, if not avoided, could result in death or serious
injury.
Caution decals indicate a potentially hazardous situation, which, if not avoided, could result in minor or moderate
injury.
The warning and caution decals are shown on the following page. The diagrams following the decals show where
each decal is located.
Warning/Caution Decals
