Cybex Arc Trainer 620A/629A
Owner’s Manual
Cardiovascular Systems
Part Number 5620A-4
www.cybexinternational.com

Cybex Arc Trainer 620A/629A
Owner’s Manual
Cardiovascular Systems
Part Number 5620A-4
Cybex®and the Cybex logo are registered trademarks of Cybex International, Inc. Polar®is a registered trademark of Polar®.
DISCLAIMER: Cybex International, Inc. makes no representations or warranties regarding the contents of this manual. We
reserve the right to revise this document at any time or to make changes to the product described within it without notice or
obligation to notify any person of such revisions or changes.
© 2006 Cybex International, Inc. All rights reserved. Printed in United States of America.
10 Trotter Drive Medway, MA 02053 • 800-766-3211 • 508-533-4300 • FAX [phone]
www.cybexinternational.com • [email protected] • [email protected] • 5620A-4 • September 2006

Page i
About This Manual
An Owner’s Manual is shipped with each unit. To purchase additional copies of this manual or
any other Cybex manual, please do one of the following:
• order online at www.cybexinternational.com
• fax your order to 508-533-5183
• contact Cybex Customer Service at 800-766-3211
• or contact Cybex Customer Service at 508-533-4300
To contact Cybex with comments about this manual you may send email to
[email protected].
Cybex Arc Trainer620A/629A Owner’s Manual
FCC Compliance Information
! WARNING: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception (which can be determined by
turning the equipment off and on) the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio TV technician for help.

DDEECCLLAARRAATTIIOONNOOFFCCOONNFFOORRMMIITTYY
This Declaration of Conformity is suitable to the European Standard EN 45014, “General criteria for
supplier’s declaration of conformity.”
We,
MMaannuuffaaccttuurreerr::Cybex International, Inc. EEUURReepprreesseennttaattiivvee::Cybex International UK
10 Trotter Drive Oaktree House
Medway, MA 02053 Atherstone Road
USA Measham
[phone] Swadlincote, Derbyshire DE12 7EL
United Kingdom
[phone]
declare under our sole responsibility that the product(s):
CCyybbeexx662200AAAArrccTTrraaiinneerr
CCyybbeexx662299AAAArrccTTrraaiinneerr
CCyybbeexx663300AAAArrccTTrraaiinneerr
CCyybbeexx663399AAAArrccTTrraaiinneerr
to which this declaration relates is in conformity with the EEC directives listed herein below
(including any and all relevant modifications):
7733//223
3//EEEECCLLoowwVVoollttaaggeeDDiirreeccttiivvee
8899//333366//EEEECCEElleeccttrroommaaggnneettiiccCCoommppaattiibbiilliittyy
22000022//9955//EECCRReessttrriiccttiioonnooffHHaazzaarrddoouus
sSSuubbssttaanncceess((RRooHHSS))DDiirreeccttiivvee
AArrttHHiicckkss
CChhiieeffOOppeerraattiinnggOOffffiicceerr
CCyybbeexxIInntteerrnnaattiioonnaall,,IInncc..
1100TTrrootttteerr
DDrriivvee
MMeeddwwaayy,,MMAA0022005533
Worldwide Headquarters 10 Trotter Drive + Medway, MA 02053, USA + t508.533.4300 + f508.533.5500
151 24th Avenue NW + Owatonna, MN 55060, USA + t507.455.0217 + f507.455.3446
Cybex Arc Trainer 620A/629A Owner’s Manual
Page ii
AAuugguusstt2244,,22000066

As a result of test reports and their evaluation by accredited laboratories, we are in possession of the
following certificates for products which carry this marking:
Canada, USA CAN/CSA-C22.2 No.601.1-M90
UL Std. No. 60601-1 Medical
FCC Part 15, Subpart B Class B
EN 55011, Group 1, Class B
EN 60601-1-2
Worldwide CB Scheme IEC60601-1
European Union 73/23/EEC, 89/336/EEC,
References of harmonized standards on which this declaration of conformity is based:
EENN6600660011--11--11Medical electrical equipment - Part 1-1: General requirements for safety - Collateral
standard: Safety requirements for medical electrical systems
EENN6611000000--44--22(1995) Electromagnetic compatibility (EMC): Testing and measurement techniques -
Electrostatic discharge immunity test
EENN6611000000--44--33(1996) Electromagnetic compatibility (EMC): Testing and measurement techniques -
Radiated, radio-frequency, electromagnetic field immunity test
EENN6611000000--44--44(1995) Electromagnetic compatibility (EMC): Testing and measurement techniques -
Section 4: Electrical fast transient/burst immunity test.
EENN6611000000--44--55(1995) Electromagnetic compatibility (EMC): Testing and measurement techniques -
Surge immunity test
EENN6611000000--44--66(1996) Electromagnetic compatibility (EMC): Testing and measurement techniques -
Immunity to conducted disturbances, induced by radio-frequency fields
EENN6611000
000--44--88(1993) Electromagnetic compatibility (EMC): Testing and measurement techniques - Power
frequency magnetic field immunity test
Worldwide Headquarters 10 Trotter Drive + Medway, MA 02053, USA + t508.533.4300 + f508.533.5500
151 24th Avenue NW + Owatonna, MN 55060, USA + t507.455.0217 + f507.455.3446
Cybex Arc Trainer 620A/629A Owner’s Manual
Page iii

EENN6611000000--44--1111(1994) Electromagnetic compatibility (EMC): Testing and measurement techniques -
Voltage dips, short interruptions and voltage variations immunity tests
EENN6611000000--33--22(2000) Electromagnetic compatibility (EMC): Limits - Limits for harmonic current
emissions (equipment input current <= 16A per phase)
EENN6611000000--33--33(1995/1997) Electromagnetic compatibility (EMC): Limits - Limitation of voltage
changes, voltage fluctuations and flicker in public low-voltage supply systems, for equipment with
rated current <= 16 A per phase and not subject to conditional connection
EENN995577--11Stationary Training Equipment. General Safety Requirements and Test Methods
EENN995577--99Stationary training equipment – Elliptical trainers. Additional specific safety requirements
and test methods.
AASSTTMMFF22227766--General Fitness Equipment Standard
AASSTTMMFF11774499--9966Standard Specification for Fitness Equipment and Fitness Facility Safety Signage and
Labels
FFCCCCPPaarrtt1155,,SSuubbppaarrttBB– Class B Emissions
CCAANN//CCSSAA--CC2222..22NNoo..660011..11--MM9900––Medical Electrical Equipment – Part 1: General Requirements for
Safety
UULL--6600660011--11Medical Electrical Equipment, Part 1: General Requirements for Safety
Worldwide Headquarters 10 Trotter Drive + Medway, MA 02053, USA + t508.533.4300 + f508.533.5500
151 24th Avenue NW + Owatonna, MN 55060, USA + t507.455.0217 + f507.455.3446
Cybex Arc Trainer 620A/629A Owner’s Manual
Page iv

Front Pages
About this Manual .................. i
FCC Compliance Information ......... i
Declaration of Conformity ............ ii
Table of Contents .................. v
1 Safety
Important Voltage Information......... 1-1
Grounding Instructions............... 1-1
Important Safety Instructions ......... 1-2
Warning Decals .................... 1-5
Warning Decals For Units with AC
Power Kit ........................ 1-7
Caution Decals .................... 1-8
Explanation of Symbols Used ......... 1-9
2 Technical Specifications
Specifications ..................... 2-1
3 Operation
Terms and Symbols Used ............ 3-1
Intended Use ...................... 3-2
Quick Operation Guide .............. 3-3
Detailed Operation Guide ............ 3-3
Stopping the Arc Trainer 620A/629A ... 3-6
Control During Operation ............ 3-6
Data Readouts ..................... 3-7
Displaying Heart Rate ............... 3-8
Heart Rate LED .................... 3-8
Use of Programs ................... 3-9
Manual Mode ...................... 3-10
The Workout Profile ................. 3-10
Range of Motion ................... 3-10
Hill Interval ........................ 3-12
Interval ........................... 3-14
Weight Loss ....................... 3-16
Cardio ........................... 3-18
Strength .......................... 3-20
Manual ........................... 3-22
Table of Contents
4 Preventive Maintenance
Warnings ......................... 4-1
Regular Maintenance Activities ........ 4-1
Cleaning Your Arc Trainer 620A/629A . . 4-2
Drive Belt Maintenance .............. 4-3
Lubrication ........................ 4-5
Environment ....................... 4-5
Storage .......................... 4-5
Service Schedule ................... 4-6
Rechargeable Battery ............... 4-7
5 Setup and Assembly
Warnings/Cautions ................. 5-1
Choosing and Preparing a Site ........ 5-1
Electrical Power Requirements ........ 5-2
Assembling the Arc Trainer
620A/629A ....................... 5-2
Testing the Operation ............... 5-9
Setting Operation Options ............ 5-10
6 Customer Service
Contacting Service ................. 6-1
Serial Number and Voltage ........... 6-1
Return Material Authorization (RMA).... 6-2
Damaged Parts .................... 6-3
Ordering Parts ..................... 6-3
PartList - Main Assembly............. 6-4
Exploded Views - Main Assembly.......6-5
Parts List - Console Assembly ........ 6-12
Exploded View - Console Assembly.... 6-13
Parts List - Front End Assembly ....... 6-14
Exploded View - Front End Assembly... 6-15
Schematic ........................ 6-17
Page v
Cybex Arc Trainer 620A/629A Owner’s Manual

1 - Safety
IMPORTANT: Read all instructions and warnings before using the unit.
NOTE: The power cord is available with the optional AC power kit.
! WARNING: Do not plug unit into wall outlet without an approved medical power cord.
Before plugging the power cord into an electrical outlet, verify that the voltage requirements for your
area match the voltage of the unit that you have received.
This unit must be grounded. If it should malfunction or break down, grounding provides a path of least
resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord
having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with all local codes and
ordinances.
AW-19522 EW600005 AW-19587 AW-19521
115 VAC 220 VAC 100 VAC 230 VAC
! DANGER: Improper connection of the
equipment grounding conductor can result
in a risk of electric shock. Check with a
qualified electrician or service provider if
you are in doubt as to whether the unit is
properly grounded. Seek a qualified
electrician to perform any modifications to
the cord or plug. Cybex is not responsible
for injuries or damages as a result of cord
or plug modification.
Make sure that the unit is connected to an
outlet having the same configuration as the
plug. Do not use a ground plug adapter to
adapt the power cord to a non-grounded
outlet.
Cybex Arc Trainer 620A/629A Owner’s Manual
Safety
Page 1-1
Important Voltage Information
Grounding Instructions

(Save These Instructions)
! DANGER: To reduce the risk of electric shock, always unplug this unit from the electrical outlet
immediately after using it and before cleaning it.
! WARNING: Serious injury could occur if these precautions are not observed. To reduce the risk
of burns, fires, electric shock, or injury:
User Safety Precautions
• Keep children away. Teenagers and disabled must be supervised.Tenez les enfants éloignés. Les
adolescents et les handicapés doivent être surveilles.
• Obtain instruction before using. Lisez les instructions avant l’utilisation.
• Wait until foot plates come to a complete stop before dismounting. Attendre l’arret complet des
reposes pieds avant de descendre.
• Obtain a medical exam before beginning any exercise program.
• Stop exercising if you feel faint, dizzy, or experience pain.
• Read and understand the Owner’s Manual and all warnings posted on the unit before using.
• DO NOT wear loose or dangling clothing while using.
• Keep all body parts, towels, and the like free and clear of moving parts.
• Use the handrails for support and to maintain balance.
• DO NOT use the unit if you exceed 400 lbs. (180 kg). This is the rated maximum user weight.
• Replace any warning labels if damaged, worn or illegible.
• Report any malfunctions, damage or repairs to the facility.
• Wait until foot plates come to a complete stop before dismounting.
• All maintenance activities shall be performed by qualified personnel. Failure to do so could result in
serious injury.
• DISCONNECT POWER BEFORE SERVICING.
• Moving parts. Keep hands away when in use.
• For connection to a Medical Grade outlet only to ensure proper grounding. Rated 100-240 VAC~
50/60 Hz 0.75 A.
Safety
Page 1-2
Cybex Arc Trainer 620A/629A Owner’s Manual
Important Safety Instructions

Facility Safety Precautions
• Make sure all user and safety precautions are observed.
• Read and understand the Owner’s Manual completely before using the unit.
• Make sure all users are properly trained on how to use the equipment.
• Make sure that each machine is setup and operated on a solid level surface. Do not install
equipment on an uneven surface.
• Make sure there is enough room for safe access and operation of the equipment.
• Perform regular maintenance checks on the equipment. Also pay close attention to all areas most
susceptible to wear, including (but not limited to) cables, pulleys, belts and grips.
• Immediately replace worn or damaged components. If unable to immediately replace worn or
damaged components then remove from service until the repair is made.
• Do not attempt repairs, electrical or mechanical. Seek qualified repair personnel when servicing. If
you live in the USA, contact Cybex Customer Service at 800-766-3211. If you live outside the USA,
contact Cybex Customer Service at 508-533-4300.
• Disconnect the optional power adapter before servicing the unit.
• Keep a repair log of all maintenance activities.
• Use only Cybex supplied components to maintain/repair the equipment.
• Do not use attachments unless recommended for the unit by Cybex.
• Do not use the unit if: the unit is plugged into an optional power adapter that has a damaged
cord; (2) the unit is not working properly or (3) if the unit has been dropped or damaged. Seek
service from a qualified technician.
• Do not use the optional power adapter in damp or wet locations.
• EQUIPMENT not suitable for use in the presence of a FLAMMABLE ANAESTHETIC MIXTURE WITH
AIR or WITH OXYGEN OR NITROUS OXIDE.
• Do not use the unit outdoors.
• The 620A/629A may generate electromagnetic or other forms of interference, or it may be affected
by interference from other equipment nearby. If this is suspected, take precautions by separating
the equipment or otherwise shielding it to avoid such interference.
NOTE: It is the sole responsibility of the user/owner or facility operator to ensure that regular
maintenance is performed.
Arc Trainers containing the A/V options
• Devices connected to Cybex equipment must comply with appropriate safety standards. This
includes but not limited to: (UL-60601, IEC/EN 60601-1) for medical equipment.
• There must be adequate mechanical mounting of the device in all combinations
(configurations).
Cybex Arc Trainer 620A/629A Owner’s Manual
Safety
Page 1-3

Safety
Page 1-4
Cybex Arc Trainer 620A/629A Owner’s Manual
• The device must be stable on the unit in all configurations.
• Risk and leakage current of the final combinations must comply with IEC/EN 60601-1-1 and is the
responsibility of the end user to ensure compliance.
• Electromagnetic emissions and immunity of all configurations must conform to IEC/EN 60601-1-2.
• All added devices must have a compatible interface.
• All devices must be used for their intended purpose.
• Signal or mains isolation devices and additional protective earth may be needed to assure
compliance with IEC/EN 60601-1-1.
• Do not power the entire system from a single outlet or power strip. If the unit is used with the
optional power supply, ensure that this power supply is plugged in to a separate outlet than any
connected device, to prevent exceeding the allowable leakage current of the system.
• End user of a system shall ensure that interruption and restoration of the power supply to any
equipment or non-medical equipment of the system shall not result in a safety hazard other than
interruption or cessation of its intended function.

Safety
Page 1-5
SERIOUS INJURY
COULD OCCUR IF
THESE PRECAUTIONS
ARE NOT OBSERVED
Keep children away. Teenagers and
disabled must be supervised.Tenez
les enfants éloignés. Les
adolescents et les handicapés
doivent être surveilles.
Obtain instruction before using.
Lisez les instructions avant
l'utilisation.
Wait until foot plates come to a
complete stop before dismounting.
Attendre l'arret complet des
reposes pieds avant de descendre.
Obtain a medical exam before
beginning any exercise program.
Stop exercising if you feel faint,
dizzy, or experience pain.
Read and understand the Owner's
Manual and all warnings posted on
the unit before using.
DO NOT wear loose or dangling
clothing while using.
Keep all body parts, towels, and the
like free and clear of moving parts.
Use the handrails for support and
to maintain balance.
DO NOT use the unit if you exceed
400 lbs. (180 kg). This is the rated
maximum user weight.
Replace any warning labels if
damaged, worn or illegible.
Report any malfunctions, damage
or repairs to the facility. 610A-349-4
WARNING
Warning decal part number
610A-349-4
Cybex Arc Trainer 620A/629A Owner’s Manual
Carefully read and understand the following before using the unit:
NOTE: To replace any worn or damaged decals do one of the following: Visit www.cybexinternational.
com to shop for parts online, fax your order to 508-533-5183 or contact Cybex Customer Service at
800-766-3211. If you live outside of the USA, call 508-533-4300.
Warning decals indicate a potentially hazardous situation, which, if not avoided, could result in death or
serious injury. The warning decals are shown below.
Warning Decals

Cybex Arc Trainer 620A/629A Owner’s Manual
High voltage is present under
this shield. This shield should
only be removed by a qualified
service technician.
Keep wet items away from
inside parts.
High voltage may still be present
even if the unit is unplugged.
SERIOUS INJURY COULD OCCUR
IF THESE PRECAUTIONS
ARE NOT OBSERVED
WARNING
DE-17155-4
Hot flywheel! Wait until it
cools before servicing.
Underneath
Access Cover
Warning decal part number - DE-19592-4
Shield part number
630A-316
Warning battery
DE-19586
Located on
battery bracket
Warning decal part number
DE-17155-4
Safety
Page 1-6

For connectionto a Medical Grade
outlet only to ensure proper grounding.
Voltage: 100-240VAC~50/60Hz
DE-19547-4
WAR NI NG
For connection to a Medical Grade
outlet only to ensure proper grounding.
Voltage: 100-240 VAC~
50/60Hz
0.75 Amps
1-Phase
DE-19547-4
WARNING
Cybex Arc Trainer 620A/629A Owner’s Manual
CM000240
ОТКЛЮЧИТЕ
ПИТАНИЕ,
ПРЕЖДЕ ЧЕМ
ПРИСТУПАТЬ
К ОБСЛУЖИВАНИЮ.
ПРЕДУПРЕЖДЕНИЕ
Warning decal part number
CM000240
Warning decal part number
DE-19547-4
Safety
Page 1-7
Warning Decals for Units with AC Power Kit

DE-17219-4
CAUTION
Moving parts.
Keep hands away
when in use. Caution decal part number
DE-17219-4
Caution decals indicate a potentially hazardous situation, which, if not avoided, may result in minor or
moderate injury. The caution decals are shown below.
NOTE: This decal is located on both sides of the unit in a total of two locations.
Safety
Page 1-8
Caution Decal
Cybex Arc Trainer 620A/629A Owner’s Manual

BF
Safety
Page 1-9
Explanation of Symbols Used
Class II Equipment - Classifies equipment as Class II with double insulation.
Type BF Applied Part - Classifies equipment as Type BF, providing protection
against electric shock.
CE - The CE (Conformitè Europèenne) mark is a European Union approval indicating
that a product complies with a European Directive.
Pause/End - Press to pause program.
Quick Start - Press to skip Program Setup Mode and enter Manual Mode.
Up Triangle - This key adjusts Time, Level or Weight up.
Down Triangle - This key adjusts Time, Level or Weight down.
Up Arrow - This key adjusts Incline up.
Down Arrow - This key adjusts Incline down.
Level Plus - This key adjusts Level up.
Level Minus - This key adjusts Level down.
Cybex Arc Trainer 620A/629A Owner’s Manual

Safety
Page 1-10
Cybex Arc Trainer 620A/629A Owner’s Manual
This page intentionally left blank
