Apple iPod, iPhone Upgrade Kit 625CR
Kit Number KAX-25114 Installation Instructions
This instruction sheet describes how to install the Apple upgrade kit for Cybex bike models 625C and
625R.
Tools Required
• Phillips screwdriver
• Utility knife
• ESD (Electrostatic Discharge) grounding strap
Read and understand all instructions thoroughly before installing this kit.
Verify the kit contents shown.
1
2
3
4
5
68
9
10 11
7
Description Qty.
1iPod assembly,
AX-24137
1
2Screw, 6-19 x 0.50”,
HS-18320
4
3Cable, iPod, 30 pin,
AW-23768
1
4Cable, GFX to MCC,
AW-23300
1
5Cable, Headphone
jack jumper,
AW-23298
1
6PCA, Headphone jack
board, AD-23332
1
7Decal, Headphone
jack, DE-23399
1
8Screw, 4 x 3/8”,
HS-20553
2
9Gasket, HX-23441 1
10 Screw, #8-32 x 0.50”,
HS-21672
2
11 Bracket, grounding,
FS-23440
1

Page 2 of 7 www.cybexintl.com
Disconnect optional external power source
Unplug the unit from the power outlet.
WARNING: Shock and electrocution hazard
• Unplug unit and let sit 10 minutes before cleaning or performing maintenance
• Electrical charge can remain in unit after unplugging
• Keep water and liquids away from electrical parts
NOTICE: Component damage
Wear an ESD grounding strap during this procedure. Connect ESD grounding strap to
frame bolts or unpainted metal of frame. If ESD grounding strap is not available, touch
frame bolts or unpainted metal of frame before handling any electronics.
Remove back cover
Remove the four screws securing the back cover to the console assembly using a Phillips
screwdriver.
3
2
1
Description Qty
1Console Assembly 1
2Back Cover 1
3Screws 4
Remove console assembly
1. Remove the six screws securing the console assembly to the console suport using a Phillips
screwdriver.
3
1
2
Description Qty
1Console Assembly 1
2Console support 1
3Screws 6

Page 3 of 7 www.cybexintl.com
2. Unplug cables by pinching latch and make sure it releases connector. Pull connector out.
Latch Pull Straight Out
From Connector
DO NOT PULL
CONNECTOR OUT
BY THE WIRES!
Install headphone jack board
1. Remove the blank decal from the headphone jack cover using a utility knife.
1
2
Description Qty
1Blank decal 1
2Headphone jack cover 1
2. Install the two 4 x 3/8” screws securing the headphone jack board to the headphone jack cover
using a Phillips screwdriver.
2
3
1
Description Qty
1Headphone jack board 1
2Screws, 4 x 3/8” 2
3Headphone jack cover 1

Page 4 of 7 www.cybexintl.com
3. Install the headphone jack decal to the headphone jack cover.
1
2
Description Qty
1Headphone jack decal 1
2Headphone jack cover 1
4. Plug the headphone jack cable into the headphone jack board.
1
2
Description Qty
1Headphone jack board 1
2Plug cable in here 1
Install grounding bracket
1. Remove the grounding tab and screw using a Phillips screwdriver.
12
Description Qty
1Grounding tab 1
2Screw 1
2. Remove the backing from the gasket and apply to the grounding bracket.
1
4
2
3
Description Qty
1Grounding tab 1
2Screws, 8-32 x 0.50” 2
3Gasket 1
4Grounding bracket 1

Page 5 of 7 www.cybexintl.com
3. Install the grounding bracket, grounding tab, and 8-32 x 0.50” screws to the console as shown
using a Phillips screwdriver.
Install iPod board
1. Remove the screw securing the clamp as shown using a Phillips screwdriver.
1
2
34
Description Qty
1Console front 1
2Clamp 1
3Screws 4
4iPod board 1
2. Install the iPod board, four screws, and clamp as shown using a Phillips screwdriver.
3. Plug the GFX to MCC cable into the iPod board.
Connect console cables
Install console cables to MCC board.
1 2 3
5 64 7 8 9
Description
1CSAFE (optional)
2Display
3E3 View monitor
4A/V
5Headphone jack
6iPod
7Heart rate
8Handset membrane
9iPod board assembly

Page 6 of 7 www.cybexintl.com
Install console assembly
1. Install the six screws securing the console assembly to the console suport using a Phillips
screwdriver.
3
1
2
Description Qty
1Console Assembly 1
2Console support 1
3Screws 6
Install back cover
1. Route the iPod cable through the notch in the console assembly.
1
2
Description Qty
1Console Assembly 1
2Notch 1
2. Install the four screws securing the back cover to the console assembly using a Phillips
screwdriver.
3
2
1
Description Qty
1Console Assembly 1
2Back Cover 1
3Screws 4

Cybex® and the Cybex logo are registered trademarks of Cybex International, Inc.
iPod and iPhone are trademarks of Apple Inc., registered in the U.S. and other countries.
10 Trotter Drive Medway, MA 02053
508-533-4300 • FAX [phone] • www.cybexintl.com
Copyright © 2014, Cybex International, Inc. All rights reserved • LT-25116-4 A • July 2014
Page 7 of 7 www.cybexintl.com
Complete installation
1. Plug the optional power cord into the power inlet.
2. Begin pedaling the unit until the console lights up.
3. Operate the unit at all levels to verify proper operation.
