CYBEX 772A User manual

Cybex 772A/772AT Arc Trainer®
Cybex GO Monitor, Owner’s Manual
Cardiovascular Systems
Part Number 5772-4 A
www.cybexintl.com

2
Cybex Owner’s Manual
Cybex® and the Cybex logo are registered trademarks of Cybex International, Inc. Polar®is a registered trademark of Polar Electro Inc. iPOD®is
registered trademark of Apple.
DISCLAIMER: Cybex International, Inc., makes no representations or warranties regarding the contents of this manual. We reserve the right to revise
this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such revisions or
changes.
© Copyright 2014, Cybex International, Inc. All rights reserved. Printed in the United States of America.
10 Trotter Drive Medway, MA 02053 • 508-533-4300 • FAX [phone] • www.cybexintl.com • 5772-4 A • November 2014
FCC Compliance Information ............. 3
Safety
Ground and Voltage Information........... 4
Important Safety Instructions ............. 4
Warning and Caution Decals ............. 6
Label Placement....................... 8
Assembly
Specications - 772A ................... 9
Specications - 772AT ................. 10
Environment and Storage............... 11
Choosing and Preparing Site . . . . . . . . . . . . 11
Electrical Power Requirements .......... 11
772A Assembly Procedure .............. 12
772AT Assembly Procedure ............. 25
Cybex GO Setup ..................... 41
Equipment Setup ..................... 48
Testing Operation ..................... 50
Operation
Intended Use ........................ 51
Terms Used ......................... 51
User Control Symbols Used ............. 52
CardioTouch Symbols Used ............. 53
CardioTouch Screen and User Controls.... 55
Cybex GO Console and User Controls..... 56
Cybex GO Console Log In or Sign Up . . . . . 57
Mount and Dismount .................. 58
Emergency Dismount .................. 58
Range of Motion ...................... 58
Quick Operation Guide................. 60
Detailed Operation Guide............... 60
Workout Selection .................... 62
Data Readouts . . . . . . . . . . . . . . . . . . . . . . . 63
Heart Rate Indicator ................... 63
Fan Control.......................... 64
iPod/iPhone/iPad Functions ............. 64
Maintenance
Warnings ........................... 65
Cleaning Unit ........................ 66
Preventive Maintenance Activities ........ 66
Remove Access Cover ................. 67
Drive Belts .......................... 68
Attach Access Cover .................. 68
Cybex GO Monitor .................... 69
Recommended Service Schedule ........ 70
Statistics ............................ 71
Customer Service
Product Registration................... 72
Contacting Service .................... 72
Ordering Parts ....................... 72
Return Material Authorization (RMA) ...... 73
Damaged Parts....................... 73
Appendix - Workout Overviews
Weight Loss - Hill Climb ................ 74
Weight Loss - Speed Bump ............. 75
Strength - High Low ................... 76
Strength - Bursts...................... 77
Strength - Interval..................... 78
Fitness (Mens) , Shaping (Womens)
- Total Leg ......................... 79
Fitness (Mens) - Target: Hip,
Shaping (Womens) - Glute Camp ....... 80
Cardio - Hill Interval ................... 81
Cardio - Wave........................ 82
Cardio - Interval ...................... 83
Cardio - Heart Rate Control ............. 84
Power - Constant Power................ 84
Power - Adaptive Power ................ 84
Table of Contents

3
Cybex Owner’s Manual
FCC Compliance Information
Changes or modications to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment!
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.

Cybex Owner’s Manual
4
Safety
Read all instructions and warnings before using.
Ground and Voltage Information
WARNING: Shock and electrocution hazard.
• Connect unit to a grounded outlet.
• Do not use voltage adapter or extension cord.
Cybexisnotresponsibleforinjuriesordamagesasaresultofcordorplugmodication.
• Verify voltage requirements of unit match local voltage requirements.
• Verify unit outlet is the same conguration as the plug.
115 VAC Euro Plug UK 230 VAC Japanese Danish Australia
NEMA 5-15 CEE 7/7 BS 1363 JIS 8303 107-2-D1 AS/NZS 3112
Important Safety Instructions
(Save These Instructions)
WARNING: Shock and electrocution hazard.
• Unplug unit and let sit 10 minutes before cleaning or performing maintenance.
• Electrical charge can remain in unit after unplugging.
• Keep water and liquids away from electrical parts.
User Safety Precautions
Prior to use:
• Obtain a medical exam before beginning any exercise program.
• Obtain instruction before using.
• Read and understand warning labels.
• Keep foot plate surface clean and dry.
• Maximum user weight is 400 lbs. (180 kg).

Cybex Owner’s Manual
4 5
• Inspect unit. If damaged, notify oor staff. DO NOT USE.
• Do not remove this label. Replace if damaged or illegible.
During Use:
• Do not use for stretching and do not attach straps or other devices.
• Do not allow children 12 or younger to be on or near machine.
• Stop exercise if feeling faint, dizzy, or have pain.
• Use the handrails for support and to maintain balance.
• Keep all body parts, clothing, and accessories, clear of moving parts.
• Wait until foot plates come to a complete stop before getting off.
• Do not remove this label. Replace if damaged or illegible.
Facility Safety Precautions
It is the sole responsibility of the user/owner or facility operator to ensure that regular maintenance is
performed.
• Enforce all user and safety precautions.
• Read and understand the Owner’s Manual completely before assembling, servicing or using unit.
• Verify all users are properly trained on using the equipment.
• Do not use unit outdoors.
• Verify that each unit is setup, leveled and operated on a solid level surface. Do not install equipment
on an uneven surface.
• Verify there is enough room for safe access and operation of unit.
• Use Cybex AC power adapters only.
• Do not use the optional power adapter in damp or wet locations.
• Do not use the unit if: (1) the unit is plugged into an optional power adapter that has a damaged
cord; (2) the unit is not working properly or (3) if the unit has been dropped or damaged. Seek
service from a qualied technician.
• EQUIPMENT is not suitable for use in the presence of aerosol (spray), FLAMMABLE
ANAESTHETIC MIXTURE WITH AIR or WITH OXYGEN or NITROUS OXIDE.
• Perform regular maintenance checks on unit. Performance level can be maintained only if
examined regularly. Pay close attention to all areas most susceptible to wear, including (but not
limited to) cables, pulleys, belts and grips.
• Replace any warning labels if damaged, worn, or illegible.
• Immediately replace worn or damaged components. If unable to immediately replace worn or
damaged components, then remove unit from service until repair is made.
• Do not attempt electrical or mechanical repairs. Seek qualied repair personnel when servicing. If
you live in the USA, contact Cybex Customer Service at 888-462-9239. If you live outside the USA,
contact Cybex Customer Service at 508-533-4300.
• Use only Cybex supplied components to maintain/repair unit.
• Keep a repair log of all maintenance activities.
• Disconnect the optional power adapter before servicing unit.
• Do not use attachments unless recommended for the unit by Cybex.
• The unit may generate electromagnetic or other forms of interference, or it may be affected by
interference from other equipment nearby. If this is suspected, take precautions by separating the
equipment or otherwise shielding it to avoid such interference.

Cybex Owner’s Manual
6
Warning and Caution Decals
To replace any worn or damaged decals do one of the following: Visit www.cybexintl.com to shop
for parts online, fax orders to 508-533-5183 or contact Cybex Customer Service at 888-462-9239. If
you are located outside of the USA, call 508-533-4300. For location or part number of labels, see the
parts list and exploded-view diagram on the Cybex web site at www.cybexintl.com.
Warning decals indicate a potentially hazardous situation that could result in death or serious injury if
the precautions are not observed.
Caution decals indicate a potentially hazardous situation, which, if not avoided, could result in minor
or moderate injury.
The diagram following the decals show where each decal is located.
Canadian Canadian
DECAL, CAUTION ENGLISH
DE000004 -
NOTE: See Engineering Drawing DE000004-X
125
1:1
OWATONNA
MFG. APPR.
TECH. PUBS. APPR. DATE
DATE
REV.
DWG. NO.
SCALE
SIZE
CHECKED BY
DWG. BY
TITLE:
FINISH:
MATERIAL:
B
SHEET
OF
EXCEPT AS NOTED
GENERAL
TOLERANCES:
2 DECIMALS ± .03
3 DECIMALS ± .015
ANGLES ± 1°
FEATURES SHOWN
PERPENDICULAR OR
PARALLEL SHALL BE
SO WITHIN ± 1°
REMOVE ALL BURRS
BREAK SHARP EDGES
.005/.010 R
SURFACE FINISH
INDICATED PER
ANSI B46.1-1985
GENERAL
MACHINING
DIMENSIONS
IN INCHES
DATE
DATE
REMOVE CARBURIZATION
AND SCALE FROM LASER
AND PLASMA CUT EDGES
ALL MATERIAL MUST COMPLY TO
EUROPEAN UNION DIRECTIVE
2002/95/EC RoHS (RESTRICTION
OF HAZARDOUS SUBSTANCES)
11
125
1:1
OWATONNA
MFG. APPR.
TECH. PUBS. APPR. DATE
DATE
REV.
DWG. NO.
SCALE
SIZE
CHECKED BY
DWG. BY
TITLE:
FINISH:
MATERIAL:
B
SHEET
OF
EXCEPT AS NOTED
GENERAL
TOLERANCES:
2 DECIMALS ± .03
3 DECIMALS ± .015
ANGLES ± 1°
FEATURES SHOWN
PERPENDICULAR OR
PARALLEL SHALL BE
SO WITHIN ± 1°
REMOVE ALL BURRS
BREAK SHARP EDGES
.005/.010 R
SURFACE FINISH
INDICATED PER
ANSI B46.1-1985
GENERAL
MACHINING
DIMENSIONS
IN INCHES
DATE
DATE
REMOVE CARBURIZATION
AND SCALE FROM LASER
AND PLASMA CUT EDGES
ALL MATERIAL MUST COMPLY TO
EUROPEAN UNION DIRECTIVE
2002/95/EC RoHS (RESTRICTION
OF HAZARDOUS SUBSTANCES)
DE-17155-4
DECAL, WARNING
ENGLISH
1 1 C
RHG 6-3-13
NOTES:
1. WARNING FONT - ARIAL BOLD 18 BOLD.
2. TEXT FONT - ARIAL REGULAR 6, 8, AND 10 POINT.
Black - Text
White - Background
Orange - Pantone 152C
NOTE: SEE ENGINEERING DRAWING 750A-372-X FOR SPECIFICATIONS.
2” W X 1“ H X .19” R

Cybex Owner’s Manual
6 7
525AT-400
NOTES:
1. WARNING FONT - ARIAL BOLD 18 BOLD.
2. TEXT FONT - ARIAL REGULAR 6, 8, AND 10 POINT.
English - French - German - Spanish
4” W X 3“ H X .19” R
DECAL, DISCONNECT POWER,
ENG, FRE, GER, SPA
RHG 6-3-13
125
1:1
OWATONNA
MFG. APPR.
TECH. PUBS. APPR. DATE
DATE
REV.
DWG. NO.
SCALE
SIZE
CHECKED BY
DWG. BY
TITLE:
FINISH:
MATERIAL:
B
SHEET
OF
EXCEPT AS NOTED
GENERAL
TOLERANCES:
2 DECIMALS ± .03
3 DECIMALS ± .015
ANGLES ± 1°
FEATURES SHOWN
PERPENDICULAR OR
PARALLEL SHALL BE
SO WITHIN ± 1°
REMOVE ALL BURRS
BREAK SHARP EDGES
.005/.010 R
SURFACE FINISH
INDICATED PER
ANSI B46.1-1985
GENERAL
MACHINING
DIMENSIONS
IN INCHES
DATE
DATE
REMOVE CARBURIZATION
AND SCALE FROM LASER
AND PLASMA CUT EDGES
ALL MATERIAL MUST COMPLY TO
EUROPEAN UNION DIRECTIVE
2002/95/EC RoHS (RESTRICTION
OF HAZARDOUS SUBSTANCES)
B
2 2
Black - Text
White - Background
Orange - Pantone 152C
NOTE: SEE ENGINEERING DRAWING 525AT-400-X FOR SPECIFICATIONS.
525AT-401
NOTES:
1. WARNING FONT - ARIAL BOLD 18 BOLD.
2. TEXT FONT - ARIAL REGULAR 6, 8, AND 10 POINT.
English - Japanese - Russian
4” W X 3“ H X .19” R
DECAL, DISCONNECT POWER,
ENG, JAP, RUS
RHG 6-3-13
125
1:1
OWATONNA
MFG. APPR.
TECH. PUBS. APPR. DATE
DATE
REV.
DWG. NO.
SCALE
SIZE
CHECKED BY
DWG. BY
TITLE:
FINISH:
MATERIAL:
B
SHEET
OF
EXCEPT AS NOTED
GENERAL
TOLERANCES:
2 DECIMALS ± .03
3 DECIMALS ± .015
ANGLES ± 1°
FEATURES SHOWN
PERPENDICULAR OR
PARALLEL SHALL BE
SO WITHIN ± 1°
REMOVE ALL BURRS
BREAK SHARP EDGES
.005/.010 R
SURFACE FINISH
INDICATED PER
ANSI B46.1-1985
GENERAL
MACHINING
DIMENSIONS
IN INCHES
DATE
DATE
REMOVE CARBURIZATION
AND SCALE FROM LASER
AND PLASMA CUT EDGES
ALL MATERIAL MUST COMPLY TO
EUROPEAN UNION DIRECTIVE
2002/95/EC RoHS (RESTRICTION
OF HAZARDOUS SUBSTANCES)
B
2 2
Black - Text
White - Background
Orange - Pantone 152C
NOTE: SEE ENGINEERING DRAWING 525AT-401-X FOR SPECIFICATIONS.
525AT-402
NOTES:
1. WARNING FONT - ARIAL BOLD 18 BOLD.
2. TEXT FONT - ARIAL REGULAR 6, 8, AND 10 POINT.
English - Dutch - Swedish - Danish
4” W X 3“ H X .19” R
DECAL, DISCONNECT POWER,
ENG, DUT, DAN, SWE
RHG 6-3-13
125
1:1
OWATONNA
MFG. APPR.
TECH. PUBS. APPR. DATE
DATE
REV.
DWG. NO.
SCALE
SIZE
CHECKED BY
DWG. BY
TITLE:
FINISH:
MATERIAL:
B
SHEET
OF
EXCEPT AS NOTED
GENERAL
TOLERANCES:
2 DECIMALS ± .03
3 DECIMALS ± .015
ANGLES ± 1°
FEATURES SHOWN
PERPENDICULAR OR
PARALLEL SHALL BE
SO WITHIN ± 1°
REMOVE ALL BURRS
BREAK SHARP EDGES
.005/.010 R
SURFACE FINISH
INDICATED PER
ANSI B46.1-1985
GENERAL
MACHINING
DIMENSIONS
IN INCHES
DATE
DATE
REMOVE CARBURIZATION
AND SCALE FROM LASER
AND PLASMA CUT EDGES
ALL MATERIAL MUST COMPLY TO
EUROPEAN UNION DIRECTIVE
2002/95/EC RoHS (RESTRICTION
OF HAZARDOUS SUBSTANCES)
B
2 2
Black - Text
White - Background
Orange - Pantone 152C
NOTE: SEE ENGINEERING DRAWING 525AT-402-X FOR SPECIFICATIONS.

Cybex Owner’s Manual
8
Label Placement
4
3
2
1
5
1770A-331-4 Label, Warning, Access tray, Left
1770A-331-E Label, Warning, Access tray, Left, Canadian
2770A-332-4 Label, Warning, Access tray, Right
2770A-332-E Label, Warning, Access tray, Right, Canadian
3DE000004-4 Decal, Caution Moving Parts
4DE-17155-4 Label, Warning, Hot ywheel
5525AT-400 Label, Warning, Disconnect Power
5525AT-401 Label, Warning, Disconnect Power
5525AT-402 Label, Warning, Disconnect Power

9
Cybex Owner’s Manual
Assembly
Specifications - 772A
Classification S (Studio)
Accuracy A
Length 76.25” (194 cm)
Width 32” (81 cm)
Height: 62.5” (159 cm)
Weight of
Product 404 lbs (183 kg)
Shipping
Weight 429 lbs (195 kg)
Incline Levels 0-20
Resistance
Levels 0-100
Stride Length 24” (61 cm) xed length.
Workouts Quick Start, ve workout groups, seven workouts, four heart rate workouts, and two
power workouts
Console
Features
Upper console: Cybex GO Monitor.
Displays Cal/Hr, Distance, Strides per Minute, Calories, Watt, MET, and BPM.
Lower console: Two numeric displays for incline, time, resistance and level.
Fan, iPod connector, CardioTouch screen, accessory trays and water bottle holder
Heart Rate
Features
Built-in 5 KHz wireless heart rate receiver (transmitter not included) and contact
heart rate monitoring.
Resistance
Range 0-900 watt.
Maximum
User Weight 400 lbs. (181 kg).
Power Rating Self powered or 100 - 240 VAC~, 50/60 Hz, 1.8A, 1-phase.
The dimensions stated in the installation instructions are the recommended minimum dimensions as
set forth by the manufacturer. The actual area for access and passage shall be the responsibility of
the facility and should take into account any required local codes or regulations.

10
Cybex Owner’s Manual
Specifications - 772AT
Classification S (Studio)
Accuracy A
Length 76.25” (194 cm)
Width 36.28” (92 cm)
Height: 62.5”(159 cm)
Weight of
Product 412 lbs. (187 kg.)
Shipping
Weight 437 lbs. (198 kg.)
Incline Levels 0-20
Resistance
Levels 0-100
Stride Length 24” (61 cm) xed length.
Workouts Quick Start, ve workout groups, seven workouts, four heart rate workouts, and two
power workouts
Console
Features
Upper console: Cybex GO Monitor.
Displays Cal/Hr, Distance, Strides per Minute, Calories, Watt, MET, and BPM.
Lower console: Two numeric displays for incline, time, resistance and level.
Fan, iPod connector, CardioTouch screen, accessory trays and water bottle holder.
Heart Rate
Features
Built-in wireless heart rate receiver (transmitter not included) and contact heart rate
monitoring.
Resistance
Range 0-900 watt.
Maximum
User Weight 400 lbs. (181 kg).
Power Rating Self powered or 100 - 240 VAC~, 50/60 Hz, 1.8A, 1-phase.
Other iPod/iPhone/iPad compatibility.
The dimensions stated in the installation instructions are the recommended minimum dimensions as
set forth by the manufacturer. The actual area for access and passage shall be the responsibility of
the facility and should take into account any required local codes or regulations.

11
Cybex Owner’s Manual
Environment and Storage
Humidity and Static Electricity
The unit is designed to function normally in an environment with a relative humidity range of 30% to
75%. The unit can be shipped and stored in a relative humidity range of 10% to 90%.
Dry air may cause static electricity. During workout, user may experience a shock due to build-up
of static electricity on the body and the discharge path of the unit. If static electricity is experienced,
increase humidity to a comfortable level through the use of a humidier.
Do not install, use, or store the unit in an area of high humidity, such as in the vicinity of a steam
room, sauna, indoor pool or outdoors. Exposure to extensive water vapor, chlorine and/or bromine
could adversely affect the electronics as well as other parts of the unit.
Temperature
The unit is designed to function normally in an environment with an ambient temperature range of 50°
F (10° C) to 104° F (40° C). The unit can be shipped and stored in an environment with an ambient
temperature range of 32° F (0° C) to 140° F (60° C).
Choosing and Preparing Site
Before assembling the unit, verify chosen site meets the following criteria:
• Area is well lit and well ventilated.
• Surface is structurally sound and properly leveled.
Place a 3/4” (1.9 cm) thick wood base under unit to protect carpeting.
Area allows for ample access and passage clearance around unit or for emergency dismount.
Minimum clearance is 19.7 inches (0.5 meters) on at least one side of unit and also behind unit.
Minimum clearance fo 12” (30 cm) between units for proper wireless heart rate signal operation.
Electrical Power Requirements
The Cybex GO Monitor is supplied with a power cord, The AC power kit is optional.
• Verify unit is connected to an outlet having the same conguration as the plug.
• Verify connection is a grounded circuit.
• Do not use a ground-plug adapter to adapt the 3-prong power cord to a non-grounded electrical
outlet.
• Use Cybex supplied optional AC power kit only. Consult an electrician with any questions.

12
Cybex Owner’s Manual
• Ensure outlets used by this product meet all local and federal building codes.
772A Assembly Procedure
Tools Required
• Phillips screwdriver
• Stubby Phillips screwdriver
• 3/16” Allen wrench (supplied)
• 7/32” Allen wrench (supplied)
• 9/16” Open end wrench (2)
The words “left” and “right” denote the user’s orientation.
Two people will be required for this procedure.
Read and understand all instructions thoroughly before assembling this unit. Check all items
carefully. If there is damage, see the Customer Service section of this manual for proper procedure to
return, replace, or reorder parts.
Item Description Part Number Quantity
1 Base assembly Varies 1
2Console assembly Varies 1
3Foot pad 12090-322 2
4Handle, Right - 1
5Handle, Left - 1
6Base, Accessory tray 770A-316 1
7Cover, Top, Accessory tray 770A-317 1
8Cover, Bottom, Accessory tray 770A-318 1
9Cover, Rear, Top, Right 770A-322 1
10 Cover, Rear, Outer, Right 770A-323 1
11 Cover, Rear, Inner, Right 770A-324 1
12 Cover, Rear, Top, Left 770A-319 1
13 Cover, Rear, Inner, Left 770A-321 1
14 Cover, Rear, Outer, Left 770A-320 1
15 Hardware pack - 1
16 Owner’s Manual 5772-X 1
17 Assembly poster 771A-404 1
18 Commercial Arc warranty sheet 770A-415 1
19 Consumer Arc warranty sheet 770A-416 1
20 Bracket, Lower, Display mount 770A-310 1
21 Cable, Coax, 6’ 770A-427 1
22 Coupler, Ethernet, Sheilded OCN-24895 1
23 Cable, Ethernet, 7’ OAW-24892 1

13
Cybex Owner’s Manual
9
10
13
11
14
12
7
2
3
6
45
15
16 17 18 19
20
21
22
23
1
8

14
Cybex Owner’s Manual
Verify contents of hardware pack
See hardware pack listings and hardware pack contents. See Customer Service for contact
information if any parts are missing.
Item Description Part Number Quantity
24 7/32” Allen Wrench BK030204 1
25 BHSCS .375-16 x 2.50” HC700430 4
26 Grommet, Nylon HF540200 1
27 Locknut, .375-16 Nylon HN704901 4
28 Tap Sc 10-12 x 2.00 Pn Hd Phil HT592526 4
29 Screw, Pan Head Phillips, #6 x .50” HT532512 2
30 Screw, Pan Head Phillips, 8-16 x .50” HT552512 19
31 Screw, Pan Head Phillips, 10-24 x .75” HT572515 8
772A Hardware
24
28
25
30
26
1:1
31
27 29

15
Cybex Owner’s Manual
9
10
13 11
14
29
28
25
20
30
31
30
31
30
30
30
27
26 31
12
7
2
3
6
430
31
30
31
5
1
8

16
Cybex Owner’s Manual
Lift and move unit
1. Remove large bolts and shipping supports. Keep package material on linkage arms at this
time. This will protect the paint from scratching during assembly.
2. Grasp each rear support leg rmly and lift with one person on each side.
3. Lift the lower rear support legs using proper lifting methods so the front transport wheels are
able to roll on floor.
4. Move unit to intended location.
5. Lower rear support legs.
Install 772A console assembly.
1. Place the console into position on the frame. Do not pinch cables while lowering the console.
Upper Display
Cable
Console
Locknuts (4)
Bolts (4)
Lower
Bracket
Frame
Lower Display
Cable
2. Insert (from underneath) the lower bracket and four bolts into the frame and console.
3. Thread the four locknuts onto the bolts by hand.
4. Tighten the four bolts and locknuts with a 7/32” Allen wrench and a 9/16” open-end wrench.
5. Plug the upper display cable into the lower display cable.

17
Cybex Owner’s Manual
Install coax cable and ethernet cables
1. Plug the coax cable connectors into each other and tighten threaded connector.
Ethernet cable
connectors
Coax cable connectors
2. Plug the ethernet cable connectors into each other.
Install accessory tray base
Install the four screws using a stubby Phillips screwdriver.
Frame
Screws
(4)
Accessory
Tray Base

18
Cybex Owner’s Manual
Install accessory tray top
Install the two screws using a stubby Phillips screwdriver.
Screws (2)
Accessory
Tray Top
Accessory
Tray Base
Install accessory tray bottom
1. Install the grommet to the frame.
Frame
Grommet

19
Cybex Owner’s Manual
2. Install the accessory tray bottom to the accessory tray base with three screws using a Phillips
screwdriver.
Screws (2) Screw
Accessory
Tray Base
Accessory
Tray Bottom
Installhandrails.
1. Remove three locknuts from the left support leg using two 9/16” open end wrenches. Keep the
two spacers in place.
Locknuts (3)
Spacers (2)
Left Handle
2. Install the left handle and three locknuts using two 9/16” open end wrenches.

20
Cybex Owner’s Manual
3. Install the left inner rear cover with two screws using a Phillips screwdriver.
Screws (2)
Left Inner
Rear Cover
4. Install the left outer rear cover with ve screws using a Phillips screwdriver.
Screws (2)
Screws (3)
Left Outer
Rear Cover
5. Install the left top rear cover with ve screws using a Phillips screwdriver.
Screws (5)
Left Top
Rear Cover
