CYBEX 600T User manual

@
Cybex 600T Treadmill Service Manual
Cardiovascular Systems
Cybex and the Cybex logo are registered trademarks of Cybex International, Inc. Stableflex and the Stableflex logo are registered
trademarks
of Cybex International,Inc.Polar is aregistered trademark of Polar.
DISCLAIMER: Cybex International, Inc. makes no representations or warranties regarding the contents of this manual. We
reserve
the right to revise this document at any time or to make changes to the product described within it without notice or
obligation to notify any person of such revisions or changes.
©2000,Cybex International,Inc. All rights reserved. Printed in United States of America.
10 Trotter Drive Medway,MA 02053 •888-GO-CYBEX •888-462-9239 •508-533-4300 •
FAX [phone]
www.eCybex.com·[e-mail]·[email protected] •SM-15650 •September 2000

Cybex 600T Treadmill Service Manual
Read All Instructions &Warnings Before
Using Grounding Instructions
This treadmill is intended for commercial use. This treadmill must be grounded. If it should
malfunction
or break down, grounding provides apath of least resistance for electric current
to reduce the risk
of electric shock. This product is equipped with acord having an
equipment-grounding conductor and agrounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with all local codes
and ordinances.
!DANGER: Improper connection of the equipment-grounding conductor can result
in a risk of electric shock. Check with a qualified electrician or service
provider if you are in doubt as to whether the treadmill is properly
grounded. Seek a qualified electrician to perform any modifications to
the cord or plug. Cybex is not responsible for injuries or damages as a
result of cord or plug modification.
This treadmill is for use on anominal 115 VAG ±10%, 60 Hz and 20 amps or a220 VAG
±15%, 50 Hz/60 Hz and 15 amps grounded, dedicated circuit. Make sure that the treadmill is
connected
to an outlet having the same configuration as the plug. Do not use aground plug
adapter to adapt the power cord
to anon-grounded outlet.
115V
NEMA 5-20 Euro Plug
GEE 717
208/220V
NEMA 6-15
Pagei

Page ii
Cybex 600T Treadmill Service Manual
Important Safety Instructions
(Save These Instructions)
!DANGER: To reduce the risk of electric shock, always unplug this treadmill from
the electrical outlet immediately after using it and before cleaning it.
!WARNING: Serious injury could occur if these precautions are not observed. To
reduce the risk of burns, fires, electric shock, or injury:
•Obtain amedical exam before beginning any exercise program.
•Keep children away from the treadmill. Teenagers and disabled persons must be
supervised while using.
•Stop exercising if you feel faint, dizzy, or experience pain at any time while exercising
and consult your physician.
•Use the treadmill handrails for support and to maintain balance.
•Disconnect all power before servicing the treadmill.
•Use adedicated line when operating the treadmill.
•Connect the treadmill to aproperly grounded outlet only.
•
Do not operate electrically powered treadmills in damp or wet locations.
•Stop and place the treadmill at 0degrees incline (level) after each use.
•
Do not leave the treadmill unattended when plugged in and running. After turning off the
treadmill, don'tleave it until it comes to acomplete stop and is level.
To disconnect,
turn all controls to the
STOP or OFF position, and then remove the plug from the outlet.
•Inspect the treadmill for worn or loose components before each use. Do not use until
worn or damaged parts are replaced.
• Maintain and replace worn parts regularly. Refer to II Preventative Maintenance
ll
Section
of Owner'sManual.
• Do not operate the treadmill if the cord is damaged, if the treadmill is not working
properly, or if the treadmill has been dropped or damaged. Seek service from aqualified
technician.

Cybex 600T Treadmill Service Manual
• Do not place the cord near heated surfaces or sharp edges.
•
Do not use the treadmill outdoors.
•
Do not operate the treadmill around or where aerosol (spray) or where oxygen products
are being used.
•
Read and understand the Owner'sManual completely before using the treadmill.
•
Read and understand emergency stop procedures.
• Read and understand all warnings posted on the treadmill.
•Replace any warning label if damaged, worn or illegible.
•
Do not wear loose or dangling clothing while using the treadmill.
•Proper footwear should always be worn on or around exercise equipment.
•Keep all body parts, hair, towels, water bottles, and the like free and clear of moving
parts.
•Set up and operate the treadmill on asolid, level surface. Do not operate in recessed
areas or on pi ush carpet.
•Provide the following clearances: 39 inches
(1 m) at each side, 78 inches (2 m) at the
back, and enough room for safe access and passage at the front of the treadmill. Be
sure your treadmill is clear
of walls, equipment, and other hard surfaces.
• Do not attempt repairs, electrical or mechanical. Seek trained repair personnel when
servicing. Contact the nearest authorized Cybex dealer or other competent repair
service.
•Use Cybex factory parts when replacing parts on the treadmill.
• Do not modify the treadmill in any way.
• Do not use attachments unless recommended for the treadmill by Cybex.
•Report any malfunctions, damage or repairs to the facility.
•
Do not use the treadmill if you exceed 350 Ibs. (157 kg). This is the rated maximum user
weight.
Page iii

Pageiv
Cybex 600T Treadmill Service Manual
About This Manual
For your convenience, all measurements and voltage requirements are listed in both English
and metric units. English values are listed first, followed by metric units
in parentheses. For
example: 1" (2.54 cm).
An Owner's Manual is shipped with each 600T Treadmill. To purchase acopy of the Service
Manual contact Cybex Customer Service at 888-462-9239 or 508-533-4300.
To contact Cybex with comments about this manual you may send email to
[email protected].
Important Voltage Information
Before you assemble your 600T, check to make sure that the treadmill has the correct voltage
requirements for your area, and that you have the correct model.
To check for the correct model and voltage requirements, locate the serial number label and
voltage label. Your serial number can be found on the rear crossbar under the running deck.
The voltage of your treadmill can be found on alabel near the on/off (I/O) switch.
The power requirements for this treadmill
are 115 VAC ±10%, 60 Hz and 20 amps or a220
VAC ±15%, 50 Hz/60 Hz and 15 amps grounded, dedicated circuit.
!WARNING: Do not attempt to use this unit with avoltage adapter.
!WARNING: Do not attempt to use this unit with an extension cord.
FCC Compliance Information
!WARNING: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
This equipment has been tested and found to comply with the limits for aClass Adigital
device, pursuant to Part 15 of the FCC Rules. Operation is subject to the following
two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.

Cybex 600T Treadmill Service Manual
Declaration of Conformity
Treadmill
600T (220V)
Attention: European Sales Director
Room 1, Floor 3, Tredegar Chambers, 78 Bridge Street, Newport,
South Wales, NP204AQ Phone [phone]
We declare that to the best of our knowledge that the fitness
equipment listed below, and manufactured by:
Cybex International, Inc.
10 Trotter Drive
Medway MA, 02053, USA
Conforms to:
Directives: 73/23/EEC, 89/336/EEC
Standards: EN 957-1, EN60335-1, EN55022, EN55014, EN50082-1
Product Name:
Model Number:
European Contact:
NOTE: For European customers only.
Page v

Page vi
Cybex 600T Treadmill Service Manual

Cybex 600T Treadmill Service Manual
Table of Contents
iRead All Instructions and Warnings
ii Important Safety Instructions
iv About This Manual
Important Voltage Information iv
FCC Compliance Information iv
VDeclaration of Conformity
vii Table of Contents
1Safety
Warning Decals 1-1
Caution Decals 1-2
2Technical Specifications
Specifications 2-1
3Preventative Maintenance
Regular Maintenance Activities 3-1
Running Belt Maintenance 3-3
4Troubleshooting
Test
Mode 4-1
LED Functions 4-1
Key Functions
4-2
Error Codes 4-2
Speed Sensor Adjustments 4-3
5Removal &Replacement
Running
Deck 5-1
Running Belt
5-5
Front Roller 5-5
Drive Belt 5-5
Rear Roller
5-6
Drive Motor . . . . . . . . . . ... . . .. . . . . 5-7
Motor Brush 5-1 0
Elevation
Motor 5-13
Lower Control Board .5-15
Power Cables 5-16
Line Filter 5-17
Power Switch 5-17
Power Cord Inlet 5-18
Display Board 5-18
Heart Rate Board 5-20
Lower Display Board 5-21
Polar Board 5-21
Upper Display Cable 5-22
Lower Display Cable 5-24
Display Overlays 5-25
6Diagrams
Parts List 6-1
Exploded View
6-3
600T Schematic 6-4
7Customer Service
Contacting Service 7-1
Serial Number &Voltage 7-1
Return Material Authorization (RMA)
.. 7-1
Damaged Parts 7-2
8Index 8-1
Page vii

Warning decals indicate apotentially hazardous situation,which, if not avoided,
could result
in death or serious injury. The warning decal used on the BOOT is
shown below.
Cybex 600T Treadmill Service Manual
1- Safety
Carefully read and understand the following before using the BOOT treadmill:
•Warning Decals
•Caution Decals
Warning Decals
1.Obtain a medical exam before beginning anyexerciseprogram.
2.Keep ch
il dren away. Teen agers and disabled must be supervised.
3.Obtaininstruction before usi
ng .
4.Stop exercisi
ng ifyou feelfaint,dizzy,orexpe ri ence painatany
time wh
il eexercisi ng a nd consult your physician.
5.Reada
nd understa nd all wa rn ings posted on thetreadmill.
6.Readand under
st and emergen cy stopprocedur es .
7.DO NOT wearlooseor dang
li ng cl othing wh il eusi ng .
8.Keepa
ll body pa rt s,towels,waterbottles,a nd the likefree a nd
clear ofmovingpa rt s.
9.Use thetr
ea dmill handra il sfor support a nd to maintain balance.
10.Stopandpla
ce th etreadmill to 0 d eg reesincline (l e ve l) after ea ch use.
11 . DO NOTuse thetreadmill if you exceed 350 Ibs.(157 kg).Thisisthe
rated maximum user weig
ht.
12.Replace any warninglabelif dam ag ed,worn orill eg ible.
13.Report any malfunctions,damageor repai
rs to thefaci li ty.
Table of Contents
i Read All Instructions &Warnings
ii Important Safety Instructions
ivAbout This Manual
ImportantVoltage Information .iv
FCC Compliance Information. iv
VDeclaration of Confoonity
vii Table of Contents
1Safety
Warning DecaJs. .... . .. . .. 1-1
Caution DecaJs ......... .. 1-2
2Technical Specifications
Specifications . . . . ...... .. 2-1
3Preventative Maintenance
Regular Maintenance ktivities 3-1
Running Belt Maintenance. .3-3
4Troubleshooting
Test Mode 4-1
LED Functions " 4-1
Key Functions ... . .... . .. 4-2
Error Codes .... . . . . . .... 4-2
Speed Sensor Adjustments.4-3
5Removal &Replacement
Running Deck ... . . . . . .... 5-1
Running Belt ........... .. 5-5
Front Roller ... . . . . . . . . .
.. 5-5
Drive Belt. .... . ..........5-5
Rear Roller 5-6
Drive Motor ,5-7
Motor Brush ...... . . . .
.. 5-10
Elevation Motor 5-13
J.: Lower Control Board 5-15
Power Cables 5-16
Une Riter 5-17
Power Switch 5-17
Power Cord Inlet 5-18
Display Board 5-18
Heart
Rate Board 5-20
Lower Display Board
5-21
Polar Board 5-21
Upper Display Cable 5-22
Lower Display
Cable 5-24
Display
Overtays 5-25
6Diagrams
Parts Ust ............ .
.. 6-1
Exploded VieW 6-3
600T Schematic 6-4
7Customer Service
Contacting Service . . . . .. . .7-1
Serial Number &Voltage. . .. 7-1
Return Material Authorization
(RMA) 7-1
Damaged Parts... . . . .. . .. 7-2
8Index 8-1
Page 1-1

Cybex 600T Treadmill service Manual
Caution Decals
Caution decals indicate apotentially hazardous situation, which, if not avoided, may result in
minor or moderate injury. The caution decals used on the GOOT are shown below.
Page 1-2
DISCONNECT
POWER
BEFORE
SERVICING.
DEBRANCHEZ VOR CORTE LA
L'ALIMENTATION SERVICEAR- ENERGIA
AVANT DE FAIRE BEITEN ELECTRICA
L'ENTRETIEN NETZSTECKER ANTES
DE
ZIEHEN. REPARAR .
~1I~~O)ijTIC
.~:a
tJJ:>-Cl'c~ \o
DE-15880

Cybex 600T Treadmill Service Manual
2-Technical Specifications Table
of Contents
i Read All Instructions &Warnings
ii Important Safety Instructions
ivAbout This Manual
Important Voltage Information. iv
FCC Compliance Information . iv
VDeclaration of Conformity
vii Table of Contents
1Safety
Warning Decals. ........ .. 1-1
Caution Decals .. . . . . ... .. 1-2
2 Technic:aI Specificatior as
Specifications .. . . . . .... .. 2-1
3Preventative Maintenance
Regular Maintencn:ektivities 3-1
Running Belt Maintenance.. 3-3
4Troubleshooting
Test Mode 4-1
LED Functions.. . . . . .....4-1
Key Functions 4-2
Error Codes. .......... .. 4-2
Speed
Sensor Adjustments. 4-3
5 Removal &Replacement
Running Deck . . . . . . . . . . .. 5-1
Running Belt . . . . .........5-5
Front
Roller 5-5
Drive Belt. .... . .. . ..... .. 5-5
Rear Roller . .. . . .. . . . . . . .. 5-6
Drive Motor .. . . . . . . . . . . .. 5-7
Motor Brush
.. .. ..... . .. 5-10
Elevation Motor 5-13
Lower Control Board 5-15
Power Cables 5-16
Une Riter 5-17
Power Switch 5-17
Power Cord Inlet 5-18
Display Board 5- 18
Heart Rate Board 5-20
Lower Display Board 5-21
Polar Board 5-21
Upper Display Cable 5-22
Lower Display Cable 5-24
Display Over1ays 5-25
6Diagrams
Parts Ust ....... . ..... .. 6-1
Exploded VIeW 6-3
600T Schematic 6-4
7Customer Service
Contacting Service ... . . . .. 7-1
Serial Number&Voltage.... 7-1
Retum Material Authorization
(RMA) 7-1
Damaged Parts 7-2
8Index 8-1
I
I
83
11
(211 cm)
33
11
(84 cm)
20" x60
11
(51 cm x152.4 cm)
450 Ibs. (203 kg)
0.5 to 10.0 mph (0.8 to 16.1 kph) in 0.1 mph or 0.1
kph increments
oto 15% grade
15 per program
Yes
I ....... ~----- 83" (211 cm)---------. .. I
-I t oe ~ I
J ~~ ~~ I
!:'-; rrr
33"
~
~ )
(84!cm) \ L ~ "
~ o r ~
Length:
Width:
Running Area:
Weight
of Product:
Speed Range:
Programs: Manual, Hills, Endurance, Sport,
Heart Rate Control (requires optional Polar receiver)
Optional: Contact Heart Rate
Standard Accessories: Accessory holder, bottle holder
Connectivity: CSAFE
Chassis Construction: 10-gauge uni-welded steel
Deck Material: Lubricated wood composite
Power Requirement: 115
VAC ±10%, 60 Hz and 20 amps or a220 VAC
±15%, 50 Hz/60 Hz and 15 amps grounded,
dedicated circuit
Motor: 2.5 hp,
DC. continuous duty
Emergency Stop: Pull the emergency stop key (lanyard)
Languages: English, French, German, Japanese, Spanish
Maximum User Weight: 350 Ibs. 159
kJJ}
Incline Range:
Levels of Difficulty:
Manual Mode:
Specifications
Page 2-1

Page 2-2
Cybex 600T Treadmill Service Manual

Cybex 600T Treadmill Service Manual
3-Preventative Maintenance
Regular Maintenance Activities
Cleaning Your Treadmill- When cleaning your treadmill spray amild*
cleaning agent, such as awater and dishsoap solution, on aclean cloth first,
and then wipe the treadmill with the damp cloth.
!CAUTIONS: Do not spray cleaning solution directly on the treadmill.
Direct spraying could cause damage to the electronics
and may void the warranty.
*Using a non-recommended cleaning solution can cause
damage to your treadmill. Do not use an alkaline cleaner
to clean your treadmill. Read the label on the cleaning
product before you use it. If the ingredients list alcohol or
say "
no
t recommended for aluminum II do not use that
product.
!WARNING: To prevent electrical shock, be sure that power is shut off
and the treadmill is unplugged from the electrical outlet
before performing any cleaning or maintenance
procedures.
Use the following routine to help insure your treadmill's long life:
After Each Use -Wipe up any liquid spills immediately. After each
workout, use adamp cloth to wipe up any remaining perspiration from the
handrails and painted surfaces.
Be careful not to spill or get excessive moisture between the edge of the
display panel and the console, as this might create
an electrical hazard or
cause failure of the electronics.
!WARNING: Keep wet items away from inside parts of the treadmill.
Electrical shock could occur even if the treadmill is
unplugged.
Every Month -Vacuum any dust or dirt that might accumulate under or
around the
600T. Motors are especially susceptible to dust and dirt, and
restricted airflow can prevent adequate cooling that could shorten
motor life.
To clean the motor components, you must remove the two Phillips head
screws that hold the motor cover
in place. Lift the cover, and put it and the
screws aside. Use avacuum attachment or hand vacuum
to clean the
exposed elevation assembly, drive motor, lower electronics and the
Table of Contents
i Read All Instructions &Warnings
ii Important Safety Instructions
iv AboutThis Manual
Important Voltage Information. iv
FCC Compliance Infonnation .iv
VDeclaration of Conformity
vii Table of Contents
1Safety
Warning Decals 1-1
Caution Decals . .. ... .. 1-2
2Technical Specifications
Specifications .. . .. .. .. ... 2-1
3Preventative Maintenance
ReglD'Mai1teI18I1Ce ktMties 3-1
Running Belt Maintenance .. 3-3
4Troubleshooting
Test Mode 4-1
LED Functions. . . . . . . . . .. 4-1
Key Functions .. . . . .... .. 4-2
Error Codes. ... . . . .... .. 4-2
Speed Sensor Adjustments. 4-3
5 Removal &Replacement
Running Deck . . ........ .. 5-1
Running Belt .... . . . . . . . .. 5-5
Front Roller 5-5
Drive Belt...... . ....... .. 5-5
Rear Roller. .. . . . . . .. . . . . . 5-6
Drive Motor . . . . ........ .. 5-7
Motor Brush . . . . . .. . . . .. 5-10
Elevation Motor 5-13
Lower Control Board 5-15
PowerCables 5-16
Une Riter 5-17
Power Switch 5-17
Power Cord Inlet 5-18
Display Board 5-18
Heart Rate Board 5-20
Lower Display Board 5-21
Polar Board 5-21
Upper Display Cable 5-22
Lower Display Cable 5-24
Display Ovet1ays 5-25
6Diagrams
Parts Ust . . ......... . . .. 6-1
Exploded View 6-3
600T Schematic 6-4
7 Customer Service
Contacting Service . . .... .. 7-1
Serial Number&Voltage .... 7-1
Retum Material Authorization
(RMA) 7-1
Damaged Parts. . . ... . . . .. 7-2
8Index 8-1
Page 3-1

Page 3-2
surrounding areas.
Also use adry cloth for the areas that you canItreach with the vacuum cleaner. If the
machine has not been used for some time or is excessively dirty, use adry cloth to wipe
all exposed areas. Replace the cover and screws when finished.
Four Times Per Year -Clean the belt and the deck surfaces to minimize the effect of
friction between the wood deck and the running belt. Clean the underside of the running
belt and the top of the running deck surface by wiping them with aclean dry towel. Th is
should be done four times per year to prevent premature wear of the deck, running belt,
and the drive motor system.
As Needed -The running belt may become loose and slip on the drive roller with each
foot plant.
To Re-tension the Belt: While holding down any key on the console, turn the treadmill on;
this brings you into Test Mode. Press Speed ... to increase the belt speed to 5mph
(8 kph). Rotate both of the rear roller tension bolts 1/4 of aturn clockwise. If the belt
tracks off center, to either side, the running deck will become visible. If this occurs, it will
be necessary to adjust the running belt back to the center. See Figure
1.
Figure 1
!CAUTION: Be careful not to over tighten the belt. Over tightening the belt can
create excessive tension on the front
and rear rollers.
To Re-center the Belt: Use awrench to tighten the rear roller bolt on the side of the
treadmill towards which the belt
is moving. For example: If the belt moves to the right and
the deck becomes exposed on the left, use awrench to tighten the rear roller bolt on the
right side
of the frame, tighten about 1/2 of aturn (clockwise) and wait 30 seconds. If the
belt does not move back to the center
of the treadmill, make another adjustment to the
same bolt. Once the running belt has been adjusted closer to the center of the treadmill
use about 1/4 of aturn until the belt has been stabilized.
!CAUTION: While centering the belt choose one bolt to adjust. Do not adjust both
bolts.
After the belt has been centered, check the belt tension. Make sure the running belt tension is
tight enough so that the belt does not slip or hesitate when stepped on. Walk on the treadmill
at 3.5-4 mph (5.6-6.4
kph) and every 4th to 5th step throw your weight into your step to feel if
the belt is slipping. If the belt does slip, use awrench to equally tighten both rear roller
-- - ~

Cybex 600T Treadmill service Manual
adjustment bolts 1/2 of aturn (clockwise). Adjust the belt until no further
slipping is felt.
Running Belt Maintenance
The running belt and deck should be checked periodically for any excessive
wear. The belt may need minor adjustments. Use the following section
to help
keep your
BOOT operating properly.
Checking the Belt and Deck Surfaces -In an effort to make sure that the
running belt operates properly, visually inspect the belt on aweekly basis to
make sure that there are no tears
or fraying in the belt material.
To inspect the edges of the belt, it is necessary to remove the plastic side rails.
Follow these steps:
1. Turn the power off.
A. Turn the main power switch on the front panel to the off (0) position.
B. Unplug the treadmill from the power outlet.
!WARNING: When removing or installing the side rails be sure to wear
work gloves to protect against any sharp edges.
2. Remove the plastic end caps and side rails.
A. Remove the Phillips head screws that fasten each of the plastic end
caps
in place and set aside. See Figure 2.
B. Grab the side rail and firmly slide it out towards the back of the
treadmill.
Figure 2
Table of Contents
i Read All Instructions &Warni ngs
ii Important Safety Instructions
iv About This Manual
Important Voltage Information . iv
FCC Compliance Information . iv
VDeclaration of Conformity
vii Table of Contents
1Safety
Warning DecaJs. .. . ..... .. 1-1
Caution
DecaJs . . . . ..... .. 1-2
2 Technical Specifications
Specifications ....... . . ... 2-1
3Preventative Maintenance
Regulcw' Mai1tenance Activities 3-1
Running Belt Maintenance .. 3-3
4Troubleshooting
Test Mode . . . . . . . . . . ....4-1
LED Functions. . . .. . . . .
.. 4-1
Key Functions 4-2
Error Codes. . ...... . . . .. 4-2
Speed Sensor Adjustments. 4-3
5 RemovaJ &Replacement
Running Deck . . . . . . . . . . ..5-1
Runn ing Belt .... . . . . . . . .. 5-5
Front Roller . . . ...... . . . .. 5-5
Drive Belt .. . ...... . . . . . .. 5-5
Rear Roller. . . . ...... . . ... 5-6
Drive Motor ............ .. 5-7
Motor Brush ... . ........ 5- 10
Elevation Motor 5-13
Lower ControlBoard 5- 15
Power Cables 5-16
Une
Filter 5- 17
Power Switch 5-17
Power Cord Inlet 5-18
Display Board 5-18
Heart Rate Board 5- 20
Lower Display Board 5-21
Polar Board 5-21
Upper Display Cable 5-22
Lower Display Cable 5-24
Display CNer1ays 5-25
6Diagrams
Parts Ust ............. .. 6-1
Exploded
VieW .•. .•.•. •.. 6-3
SOOT Schematic 6-4
7CustomerSeMce
Contacting SeMce ... . . . ..7-1
SeriaJ Number &Voltage.. . .7-1
Return Material Authorization
(RMA) 7-1
Damaged Parts. ........ .. 7-2
8Index 8-1
Page 3-3

Page 3-4
Cybex 600T Treadmill Service Manual
C. Remove the other side rail and set aside.
3.
Check belt condition.
A. Run your hand under the belt on the top of the deck surface. If you notice any
excessive ridges, furrowing or cracks
in the deck or if the deck feels very rough,
the surface may have worn down to apoint where it could start to cause excessive
wear to the undersurface of the running belt. For running belt replacement
information see Running Belt
in the Removal and Replacement chapter.
4. Replace the side rails and plastic end caps.
A. Slide the two side rails back
on being sure to catch the rail guides.
B. Attach the plastic end caps with the Phillips screwdriver.
NOTE: For running belt replacement information see Running Belt in the Removal and
Replacement chapter.
!CAUTION: Do not use a running belt made for a different model treadmill. The
belts are specific for each treadmill and may be torn up or cause
excessive current and damage the electronics if used in combination
with another deck.
Rotating the Deck - You may rotate the deck but do not flip the deck. The wax surface
is only on the top side of the deck.
Do not rotate the belt. The belt is directional. See
Running Belt and Running Deck
in the Removal and Replacement chapter.
Belt and Deck Surfaces - To minimize the effect of friction between the deck and the
running belt, Cybex recommends cleaning the underside
of the running belt and the top
on the running deck surface by wiping them with aclean, dry towel. This simple
procedure should be done approximately four times ayear to prevent premature wear of
the deck, running belt and the drive motor system.

Cybex 600T Treadmill Service Manual
4 - Troubleshooting
Test Mode
To enter Test Mode press and hold down any key on the display and turn the
power switch on
(I). "TEST" and "rx. Xx "will now be displayed on the main
screen to show software revision.
NOTE:
If Test Mode occurs without holding any keys, akey may be stuck
closed.
If "KEY" and anumber is displayed you can determine
which key
is stuck closed by referring to the diagram below. You
may need to replace the upperand/orlower display overlay
depending on which key
is stuck closed. See Figure 1.
Upper
Overlay
Figure 1
LED Functions
Endurance LED Brush sense status. Off =OK, On =sense activated
Sport
LED E-stop status. Off =relay closed, On =relay open
Hills
LED Speed sense
Heart
LED Heart rate signal
Manual
LED Salutron (on if present, blinking off)
Age
LED Receive CSAFE data
Target
LED Transmit CSAFE data
Incline
LED 0% switch (off =<0%, on >0%)
Table of Contents
i Read All Instructions &Warnings
ii Important Safety Instructions
ivAbout This Manual
Important
Voltage Information. iv
FCC Compliance Information . iv
VDeclaration of Conformity
vii Table of Contents
1Safety
Warning Decals. . . . .. . . . .. 1-1
Caution Decals ... . . . . . . .. 1-2
2 Technical Specifications
Specifications . . . . . . . . . .
.. 2-1
3Preventative Maintenance
ReguIcr' Mai'1tencn:e .Activities 3-1
Running Belt Maintenance.. 3-3
4Troubleshooting
Test Mode .......... . . .. 4-1
LED Functions. ........ .. 4-1
Key Functions 4-2
Error
Codes. .... . . . . . . .. 4-2
Speed Sensor Adjustments. 4-3
5 Removal &Replacement
Running Deck ........ . . .. 5-1
Running Belt ........... .. 5-5
Front Roller . .. .. .. .. .. ... 5-5
Drive Belt. . . . . . . . . . . . . . .. 5-5
Rear Roller. ... . . . . . . ... .. 5-6
Drive Motor . . ... . ... . .. .. 5-7
Motor Brush ... . ......
.. 5-10
Elevation Motor 5-13
Lower Control Board 5-15
Power Cables 5-16
Une Filter 5-17
Power Switch 5-17
Power
Cord Inlet 5-18
Display Board 5-18
Heart Rate Board 5-20
Lower Display Board 5-21
Polar Board 5-21
Upper Display Cable 5-22
Lower Display Cable 5-24
Display Over1ays 5-25
6Diagrams
Parts Ust .......... . . . .. 6-1
Exploded VIeW 6-3
600T Schematic 6-4
7Customer Service
Contacting Service .... . . .. 7-1
Serial Number& Voltage .... 7-1
Return Material Authorization
(RMA) 7-1
Damaged Parts. .. .. . .. 7-2
8Index 8-1
Page 4-1

Cybex 600T Treadmill Service Manual
Key Functions
While in Test Mode press the following keys for desired information:
Start
End
Hills
Endurance
Sport
Manual Key
Incline •
Incline ~
Speed.
Speed ~
Distance
Pace
Scan
Watts
Calories
Heart
Enter
Error Codes
Starts the belt at 1.0 mph (1.6 kph)
Exits diagnostics
to 'Dormant'
Lights each
LED segment as key is pressed again.
Lights each
LED digit as key is pressed again.
Lights all
LEOs on console.
Toggles E-Stop
relay. Confirm by pulling the E-Stop key off to hear the
relay click off, then replacing it
to hear it click on.
Run elevation motor up.
Run elevation motor down.
Increase drive motor speed.
Decrease drive motor speed.
Press once for odometer information
(DST) to appear in the speed
window.
Press twice for hourmeter information
(HRS) to appear in the speed
window.
Press three times for number
of starts information (USES) to appear in the
speed window.
Press four times for brush wear mileage up
to 100 miles since activated
or
"--" if it has not been activated (BRUSH).
Displays and cycles through error log, up
to 32 errors can be stored.
Clears error log when pressed twice while
in error log mode.
Value
of motor loads in AID counts. The number range is relative to motor
current and goes from 0-225.
Displays motor pulse width (PWM) value. Range
is 0-143.
Displays the number
of starts per program
Press twice to run calibration when PWM
is displayed. Also required to
save setup values.
Page 4-2
NOTE:
born
bAdO
bAd1
A processor upset can cause any of bAdO through 4. If the chip is
misprogrammed the display typically wonItrun at all. Try turning the treadmill to
the
off (0) position and back on (I). If bAdO through 4still occurs you may need
to replace the upper display board. See Upper Display Board in the Removal and
Replacement section.
uninitialized EEPROM (loads defaults &enters test mode). Only displayed
on initial power up of anew display board.
EPROM checksum failure
Faulty microprocessor reset
