CYCMOTOR B Series User manual

User Manual
B-Series
ebike Battery packs
(B-36 ; B-52 ; B-52L)

00 TABLE OF CONTENTS
01 SAFETY & PRECAUTION
General Safety
Before the Ride
Installation & Use
Disclaimer
06 TERMS & CONDITIONS
Warranty
Contact Information
05 MAINTENANCE
General Maintenance
04 CHARGE INFORMATION
Charging Instructions
Warnings
03 INSTALLATION
Required Tools
Operating Notice
Battery Mount & Battery Pack
Wiring & Connection
Method #1: Strapping on battery pack.
Method #2: Bolting battery pack directly on frame
02 SPECIFICATIONS
Description
General Specications
B-36
B-52
B-52L
B-36
B-52
B-52L
Battery Mount
Features
Package Inclusions
Dimensions

01 SAFETY & PRECAUTION
General Safety Before the Ride
Kindly read through the entire user manual. This manual contains
important information to reduce user risk as well as instructions for this
product’s proper use. Do not discard the manual but keep it for reference.
Note that the user’s personal safety remains the user’s responsibility and
that the user must contact CYCMotor Ltd or their ocial product dealer
directly for any further guidelines or assistance.
This product is an electrical system that is dangerous for children and
must always be handled by an adult. Small components and accessories
may also present a choking hazard. Keep this product and its accessories
out of reach from children.
Keep all electrical wires secured as exposed wires could lead to serious
injury or product damage. Also inspect the condition of the wires
regularly for any damage.
Never interfere with the parts or attempt to disassemble the internal
parts of the battery when the battery is connected or switched on. This
could result in serious injury or damage to the product.
All components and accessories may only be replaced with identical
components directly supplied by CYCMotor Ltd or an ocial product
dealer. CYCMotor Ltd cannot be held liable for any damages as a result of
using unapproved parts.
Ensure that the battery mount is fastened securely to the frame and that
the battery is secured to the mount. Incorrect mounting could cause the
system to move its position and result in injury while riding. Inspect the
mounting position regularly.
Ensure that all wiring is dry before connecting it to the motor system.
When connecting the battery, make sure that it is properly connected.
Faulty connection could result in a short circuit and damage the motor
system and/ or battery.
Secure all wires properly. Make sure that no loose wires are dangling from
the bike that could be jammed into any moving parts.
Inspect electrical wires and plugs regularly for any damage.
1

01 SAFETY & PRECAUTION
Installation & Use Disclaimer
Follow the installation guidelines provided in this manual to t your
battery pack securely to your bicycle frame. This product is manufactured
to be used as an electric bicycle battery pack for powering the CYCMotor
Ltd mid-drive motor product line. Using this battery for anything other
than its intended use, is not recommended and will not be supported
CYCMotor Ltd.
The installation guidelines also provide you with clear instructions on
usage and charging. Kindly be mindful when using and charging this
product.
The B-Series ebike battery packs are intended to be mounted on a
standard bicycle frame using the steel battery mount and the 3x straps
provided. This user manual includes instructions for two common and
recommended mounting positions for your reference. Kindly note that
mounting positions where all 3x straps are not used, is up to the user’s
own discretion and risk.
The battery unit will be activated and deactivated by switching on your
kit’s display once all the components are installed and connected
accordingly. Do not attempt to alter this method.
Do not install anything other than the parts and accessories that came
with the battery unit. Doing so could damage the product.
Be sure to familiarize yourself with the product warnings provided in this
user manual.
If you require any more information or have any questions about the user
manual disclaimer or the content provided, please feel free to contact us
via email at [e-mail] or call [phone].
All the information contained in this user manual is published in good
faith and for general informational purposes only. CYCMotor Ltd does not
make any warranties about the completeness of this information and
encourages further inquiries as stated above if needed. CYCMotor Ltd will
not be held liable for any losses and/or damages in connection with the
use of this product. The use of this product is at the user’s own risk and
disgretion.
Keep this manual, along with other documents that were included with
your battery, for future reference. All content in this manual is subject to
change without notice. Please be sure to visit cycmotor.com to view and
download the latest version.
Note that this manual is not intended as a detailed user, service, repair or
maintenance manual. Your insurance policies may not provide coverage
for accidents involving the use of this product.
Notice: Please contact CYCMotor Ltd if you are unsure about the assembly
instructions or for any further assistance as CYCMotor Ltd will not be held
liable for any losses and/ or damages caused by the assembly.
PLEASE USE RESPONSIBLY.
2

02 SPECIFICATION
Description
General Specications
This product is a lithium electric bicycle (ebike) battery pack designed to complement the CYC product line. The B-Series eBike Battery is an ecient,
long-lasting energy source with fast charging capabilities. It is equipped with a Battery Management System (BMS) that ensures safe operating and reliable
data. This is the ideal power solution for users of the CYC product line.
Rated Battery Voltage
Cell
Battery Capacity
Maximum Charge Current
Maximum Continuous Discharge Current
Weight of battery pack
B-36
36V (2p10s)
10Ah (360Wh)
Original Samsung
50e 21700
3A
30A
2.2 kg
0.1 kg
*** Compatible with all CYC motor systems
52V (2p14s)
B-52
2.9kg
4A
Original Samsung
50e 21700
10Ah (520Wh)
30A
0.2kg
Original Samsung
40T 21700
52V (2p14s)
B-52
2.9 kg
4A
8Ah (416Wh)
70A
0.2 kg
52V (3p14s)
B-52L
4.3 kg
4A
12Ah (624Wh)
Original Samsung
40T 21700
70A
0.3 kg
52V (3p14s)
B-52L
4.3 kg
4A
15Ah (780Wh)
Original Samsung
50e 21700
45A
0.3 kg
3
Weight of battery mount

All parts listed are included in the package with every purchase. Should
you be missing a part, kindly contact [e-mail] along with
your order number as reference.
Thank you.
02 SPECIFICATION
High discharge BMS with short circuit protection
Weather & impact resistant
Stealthy & compact bag-like design
Original high quality Samsung 21700 cells
Ice-blue battery level indicators
Package Inclusions
High impact polycarbonate battery case
(with Samsung 40T/ 50E cell module, Battery Management
System (BMS), & line out with spark proof XT90-S connection encased in
ABS+PC)
Lithium ebike battery charger
Velcro mounting strap x 4pcs
(B-36, B-52, & B-52L includes 2x 20*250mm mounting straps &
2x 25*350mm mounting straps)
Battery mount with padding pre-assembled to battery case with M5 bolts
Features
Secure & versatile dual-mounting solution
Quick removal for portability
Bolts
B-36: M5*10 x 4, spacer x 4, spring washer x 4
B-52: M5*10 x 4, spacer x 4, spring washer x 4
B-52L: M5*10 x 6, spacer x 6, spring washer x 6
Brochure
Zip ties
B-36: 4 pcs
B-52: 6 pcs
B-52L: 8 pcs
4

199mm (L) X 81mm (W) X 104mm (H) 259mm (L) X 81mm (W) X 104mm (H) 364mm (L) X 81mm (W) X 104mm (H)
02 SPECIFICATION
Dimensions
B-36 B-52 B-52L
119mm (L) X 66.74mm (W) X 17mm (H) 171mm (L) X 66.74mm (W) X 17mm (H) 276mm (L) X 66.74mm (W) X 17mm (H)
5

03 INSTALLATION
Required Tools
Operating Notice
3mm Allen Key / Hex Key
RIGHT-HAND and LEFT-HAND sides are determined by the bike handle;
Right-hand corresponds to the right handle & vice versa.
6
L R

03 INSTALLATION
Method #1: Strapping on battery pack
Select a mounting position on your bike frame that will
provide a 3-point support for the straps.
Step 1
-Thread 2x 25*350mm straps through the mounting bracket &
1x 20*250mm through the side bracket. Note that the above
image is for reference only. Straps can be placed as needed.
Step 2
-
Wrap the straps around the frame and secure them tightly for stability.
Zip ties can be added for extra security.
Step 3
-Plug in the conncector by the XT90-S port to the motor system’s
battery port.
Step 4
-
7

Thread 2x 25*350mm straps through the mounting bracket &
1x 20*250mm through the side bracket. Note that the above
image is for reference only. Straps can be placed as needed.
Plug in the conncector by the XT90-S port to the motor system’s
battery port.
03 INSTALLATION
Method #2: Bolting battery pack on frame
Select a mounting position on your bike frame that ts over the bottle
cage mount inserts.
Step 1
-Unscrew the 4x M5 mounting bracket bolts with a
3mm Allen Key.
Step 2
-
Secure the battery mount into position by fastening bottle cage
mount insert screws.
Step 3
-
Step 4
-Secure the battery pack with the bolts in Step 2. Make sure to
include a spacer and a spring washer in between each bolt
and metal hook for best securing. Add straps if needed. 8

03 INSTALLATION
Battery Connector: XT-90 (female)
Wire: 10 AWG (red wire to positive pole & black wire to negative pole)
Wiring & Connection
Battery Connector: XT-90 (female)
Controller Connector: XT-90 (male)
Plug in the conncector by the XT90-S port to the motor system’s
battery port.
Step 5
9
-
Bolt on through water bottle mounting:

04 CHARGE INFORMATION
Charging instructions
B-36
Charger Type: 36V 4A XT90
Charge Time: 3.5 hours until fully charged
Charge Cycles: 600
Plug the charger into the wall socket.
Connect the battery to the charger at the XT90 connector side.
Leave until fully charged (approx. 2 - 4 hours from empty).
Unplug after fully charged for safety precautions.
Warnings
Refrain from charging the battery pack outdoors
Unplug the battery pack after it is fully charged; do not leave it
connected to the charger for a long period of time.
Do not interfere with the wires or connectors while charging.
The battery can stay mounted on the bike or be taken o for charging.
Charge the battery pack fully every 2 months if not used regularly.
B-52L
Charger Type: 58.8V 4A XT90
Charge Time: 3 - 4 hours until fully charged
Charge Cycles: 600
B-52
Charger Type: 58.8V 4A XT90
Charge Time: 2 - 2.5 hours until fully charged
Charge Cycles: 600
10

Keep away from children.
05 MAINTENANCE
General Maintenance
Do not reverse or short the positive and negative terminals of
the battery pack.
Do not place the battery pack in high temperatures, such as
near re.
Do not place the battery pack in water, acid, alkaline or salty
liquids, avoid submersion.
Do not open the battery without special instruction.
Do not invert the battery module inside the pack.
Please place the battery pack in a cool and dry environment
if you do not use it for a long time; charge for 2 hours every
month when stored.
Use the designated lithium battery charger when charging.
11

06 TERMS & CONDITIONS
Warranty Contact Information
CYCMotor Ltd oers a one year warranty for the battery pack and charger.
Man-made failure and other parts are excluded from our warranty.
Any attempts to modify this product will void warranty.
For any replacement parts, please visit the CYCMotor Ltd ocial online
store at www.cycmotor.com/shop or contact an ocial product dealer.
email to:
For customer support, including
[e-mail]
email to:
phone to:
[e-mail]
[phone]
shipping;
quotes, and
sales
For technical support, including
Oce Hours
Monday to Friday
9am - 6pm
Hong Kong Time
build assistance;
recommendations;
troubleshooting, and
product related queries
Certications
This product complies with UN38.3, IEC62133, RoHS, FCC, & CE standards.
12

NOTES

https://www.cycmotor.com/
