CYP CPCD-3A User manual

PC/Component
Distributor
with Audio
CPCD-3A
Operation Manual

Introduction
Cypress CPCD-3A is a high performance PC/Component distributor
with stereo audio. It is designed to connect one PC or HDTV signal source
with audio to 3 PC or HDTV displays.
Features
* Supports either PC (RGB) or HDTV (YPbPr) input signal.
* Accepts one PC or HD component input and split it into 3 buffered and
identical outputs.
* Supports stereo audio input and split it to 3 identical
outputs via 3.5mm mini-stereo connector.
* High video signal bandwidth (480MHz/-3dB) supports PC/HDTV
resolution up to UXGA/1080p.
* Ideal for presentation and home theater application.
* Plug and play, easy to install.
Operation Controls and Functions
OUTPUT
AUDIO OUTPUT INPUT
DC 5V 1A
AUDIO
123
PC
CPCD-3A PC distributor up to 1080P/UXGA
PC 3/ YPbPr 3PC 2/ YPbPr 2PC 1/ YPbPr 1
5
4 3 2 1
1. Power Input: Plug the supplied 5VDC power supply into the unit
and the LED will illuminate when it is connected.
2. Video input: Connect to the video output of your source devices such as
PC or DVD player by using the HD-15 to HD-15 cable or
HD-15 to 3 RCA cable.
3. Audio input: Connect to the audio output of your source devices such as
PC or DVD player by using the 3.5mm phone jack audio cable
or 3.5mm phone jack to 2 RCA audio cable.
4. Audio outputs: Connect the audio cables from these ports to the audio input
of the speaker systems.
5. Video outputs: Connect each of the PC/HD output to the input
of the PC or HD display.

* PC Input * 1：RGB 0.7Vp-p 75 ohm HV 5Vp-p 10K ohm
* PC Output * 3：RGB 0.7Vp-p HV 5Vp-p 10K ohm; or Y : 1Vp-p, PbPr: 0.7Vp-p 75 ohm
* Audio Input * 1：2Vrms max 47K ohm
* Audio Output * 3：2Vrms max 47K ohm
* Video Bandwidth：480MHz (-3db)
* Compatibility: VGA upto UXGA/1080p in RGBHV, RGBs, RGsB, YPbPr formats.
* Differential gain：0.05%
* Differential phase：0.05 degree
* Power：5V 2A
* Accessories: 5V power supply, HD-15 to HD-15 video cable,
Stereo audio cable.
* Dimension (WxHxD)：141 x 38 x 105mm
Specification
Connection and Installation
PC Connection
OUTPUT
AUDIO OUTPUT INPUT
DC 5V 1A
AUDIO
123
PC
CPCD-3A PC distributor up to 1080P/UXGA
PC 3/ YPbPr 3PC 2/ YPbPr 2PC 1/ YPbPr 1
PC Monitor
HDTV Connection
OUTPUT
AUDIO OUTPUT INPUT
DC 5V 1A
AUDIO
123
PC
CPCD-3A PC distributor up to 1080P/UXGA
PC 3/ YPbPr 3PC 2/ YPbPr 2PC 1/ YPbPr 1
LCD TV, Projector, or Plasma
DVD
Speaker
Speaker 3 Speaker 2 Speaker 1
Audio/Video in
D-sub to 3 RCA
adaptor cable
