1. Introduction
The chapter gives short overview of this guide
This user guide describes the first steps how to use the MB91460 emulation system. It describes also the
software and hardware installation procedure.
Further information can be found in the following manuals:

software
-
-91460-evaluation board SK-91460-MAIN and its
jumpers and options.
-91F467D--91F467D-208PFV
and its jumpers and options.
-91467D- for information about the probe cable PB-91467D-208PFV and its jumpers
and options.
The MB91460 emulation system allows the designer immediately to start with the software development before
his own final target system is available.

FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A 6
2. Hardware Requirements
The chapter lists the required hardware for the MB91460 emulation system.
The MB91460 emulator system consists of
The emulator MB2198-01 incl. 16 V DC power supply
The DSU-FR cable MB2198-10
The MB91V460 adapter board (MB2198-300) incl. 16 V DC power supply
And an evaluation board, e.g.
The evaluation board SK-91460-MAIN V1.2 incl. 9 V DC power supply
Or
The evaluation board SK-91F467-208PFV V1.1 incl. 9 V DC power supply and
The probe cable PB-91467-208PFV or the probe cable PB-91467-LS-208PFV

FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A 7
3. Software Installation
This chapter describes the software installation procedure
This installation procedure is valid for Windows XP/2000/NT 4.0. For other operating systems and for further
details, please refer to the Softune Workbench installation manual for V6 and to the hardware manual of the
Emulator MB2198-01
3.1 Softune Workbench
Please install the Softune Propack 911s FRSTAPACK600007FME02
Execute FRSTAPACK600007FME02 and follow installation process.
This file presents the styles that are available in a chapter file for a Reference Design Guide. Styles are located
in the Styles and Formatting bar.
(Leave blank Body paragraph marker here to add space between opening sentences and main content of
chapter.)
Rule 1: To install the software under Windows XP/2000/NT 4.0, the user requires administration authority.

FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A 8
4. Installation of the Emulation System
This chapter describes, what should be considered and checked before power-up the emulation system. Also the
start-up procedure of the emulation system is described.
In order to properly install the emulation system, please follow the following steps.
4.1 Providing a Clock Source
The adapter board can be equipped with two clocks, a main and a sub clock. The following figure depicts who to
install the crystal and the capacities for the main clock in connector SC30. The same applies analogously for the
sub clock in connector SC31.
Figure 4-1. Installing the crystal for the main clock
The crystal for the main clock has a frequency of 4 MHz and the crystal for the sub clock has a frequency of 32
kHz. The capacity of the capacitor should be 22 pF.
4.2 Checking the Jumpers
Rule 2: To prevent damages, check all jumpers and switches before powering up the emulation system.
Jumpers of the MB91V460 adapter board (MB2198-300) and all jumpers of the evaluation board SK-91460-
MAIN V1.2 or SK-91F467D-208PFV and the probe cable PB-91467D-208PFV influencing the adapter board are
described in chapter 5.

Installation of the Emulation System
FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A 9
4.3 Connecting the Emulation System
The following connections have to be established:
4.3.1 Cabling the Emulator MB2198-01
There are some connections necessary for the emulator MB2198-01. The following lists each step.
1. Connect the emulator MB2198-01 (1) e.g. with the USB-Cable (2) to the USB port of the PC. (Analogously
for other connection types. Please also refer to chapter 7.
2. Plug the DSU-FR Cable MB2198-10 (3) into the port labeled 
and port is marked with arrows.
3. Finally, connect the 16 V DC power supplies 
the emulator is switched off.
Figure 4-2 illustrates the necessary connections of the emulator MB2198-01.
Figure 4-2. Connections of the Emulator MB2198-01

Installation of the Emulation System
FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A 10
4.3.2 Mounting the Evaluation MCU
1. Press down the top of the IC socket. Take care when you press the IC socket; Hold the board against the
pressure not to bend the board.
2. Confirm that the hook is open, and put the evaluation MCU on the socket. The index shows the A1 pin of the
evaluation MCU.
3. Release the socket slowly and confirm that the evaluation MCU is fastening to the socket.
The following figure shows the socket of the evaluation MCU MB91V460.
Figure 4-3. Mounting the Evaluation MCU
4.3.3 Connecting and Cabling the Adapter Board to the Evaluation Board
Depending on the evaluation board, a probe cable is required or not. The following sections describe the
connection of the adapter board to the evaluation board SK-91460-Main or to the evaluation board SK-91F467D-
208PFV with the probe cable PB-91467D-208PFV or PB-91467D-LS-208PFV.
4.3.3.1 Connecting the Adapter Board to the SK-91460-MAIN
1. Connect both boards. Be aware, that the boards are tight connected.
Figure 4-4 shows the connected boards.
Figure 4-4. Connected Adapter Board and Evaluation Board

Installation of the Emulation System
FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A 11
After connecting both boards together it is necessary to connect the DSU-FR Cable MB2198-10 and the power
supplies.
2. Connect the DSU-FR Cable MB2198-10 to the evaluation board.
3. is
off.
4. Provide the 9 V DC power supply and connect it to 230 V. The following figure shows the correct
polarization. Do not power up the evaluation board by connecting the power supply yet
Figure 4-5. The Correct Polarization of the 9 V DC Power Supply
Figure 4-6 shows the cabling of the adapter and evaluation boards.
Figure 4-6. Cabling the Adapter Board and Evaluation Board
4.3.3.2 Connecting the Adapter Board to the SK-91F467D-208PFV
1. Connect the adapter board with the probe cable. Be aware, that the boards are tight connected.
2. Unscrew the YQ-PACK of the SK-91F467D-208PFV and remove carefully the microcontroller from the
socket.
3. Connect the probe cable PB-91467D-208PFV to the SK-91F467D-208PFV and tighten the screw.
The same procedure applies for the probe cable PB-91467D-LS-208PFV.
9 V
GND

Installation of the Emulation System
FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A 12
Figure 4-7 shows the connected boards.
Figure 4-7. Connected Adapter Board, Probe Cable and Evaluation Board
After connecting the boards it is necessary to connect the DSU-FR Cable MB2198-10 and the power supplies.
4. Connect the DSU-FR Cable MB2198-10 to the evaluation board.
5. Connect 
off.
6. Provide the 9 V DC power supply and connect it to 230 V. The following figure shows the correct
polarization. Do not power up the evaluation board by connecting the power supply yet.
Figure 4-8. The Correct Polarization of the 9 V DC Power Supply
9 V
GND

Installation of the Emulation System
FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A 13
The following figure shows the cabling of the boards.
Figure 4-9. Cabling the Adapter Board, Probe Cable and Evaluation Board
4.4 Power up the Emulation System
To avoid damages, please always follow this procedure to power up the emulation system.
1. Switch on the main switch at the back of the emulator MB2198-
have to be illuminated.
2. Power on the MB91V460 Adapter Board (MB2198-
illuminated.
3. Power on the evaluation board SK-91460-MAIN V1.2
Rule 3: To power down the emulation system, please follow the procedure reversely.

FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A 14
5. Jumpers and Switches
This chapter describes the jumpers and switches which can be modified on the MB91V460 adapter board
(MB2198-300). Also the jumpers of the evaluation board SK-91460-MAIN V1.2 influencing the adapter board are
explained. The default settings are mentioned.
5.1 Jumpers of the MB91V460 Adapter Board (MB2198-300)
5.1.1 V-Chip Options
Some options of the V-chip can be enabled or disabled.
Jumper
Setting
Description
S1
ALARM_SEL
EN X
Old alarm comparator
X DIS
New alarm comparator
S2
ADC_SEL
EN X
5V ADC is enabled
X DIS
3V ADC is enabled
S3
HWWDG_KILL
EN X
Hardware watchdog is disabled
X DIS
Hardware watchdog is enabled
S4
FIX_ENX
EN X
Fixed Mode / Reset Vector is enabled
X DIS
Fixed Mode / Reset Vector is disabled
S5
CSV_KILL
EN X
Clock supervisor is disabled
X DIS
Clock supervisor is enabled
S6
SRAM_SFX
EN X
Flash Mode
X DIS
SRAM Mode
S7
FSC_DISABLE
EN X
Disable flash security of emulation flash
X DIS
Enable flash security of emulation flash
Default: S1 = XDIS S2 = ENX S3 = X-DIS
S4 = ENX S5 = XDIS S6 = XDIS S7 = ENX
Note:
1. ALARM_SEL: The 91V460 is equipped with two different alarm comparators. The devices 91F467D and
91461 are equipped with the new alarm comparator.
2. ADC_SEL: Depending on the voltage supply the respective ADC have to be selected.
3. HWWDG_KILL: The hardware watchdog has to be enabled also in the Softune workbench.
(Debug Mode: Setup-> Dev. Environment-> Dev. Environment-> Execution-> watchdog)

Jumpers and Switches
FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A 15
4. SRAM_SFX: Depending on the connected emulation memory, the respective mode has to be selected. By
default a SRAM is connected.
5.1.2 Emulator Interface
The emulator interface can be terminated if the in-circuit-emulator (ICE) is not used.
Jumper
Setting
Description
S14
INITX
USER INITX
INITX is controlled by the evaluation board
INITX ICE
INITX is controlled by the emulator
S15
TRSTX
USER TRSTX
TRSTX is controlled by the evaluation board
TRSTX ICE
TRSTX is controlled by the emulator
S16
ICD3
PD_OFF ICD3
Disconnect pull-down resistor to ICD3
ICD3 PD_ON
Connect pull-down resistor to ICD3
S17
ICD2
PD_OFF ICD2
Disconnect pull-down resistor to ICD2
ICD2 PD_ON
Connect pull-down resistor to ICD2
S18
ICD1
PD_OFF ICD1
Disconnect pull-down resistor to ICD1
ICD1 PD_ON
Connect pull-down resistor to ICD1
S19
ICD0
PD_OFF ICD0
Disconnect pull-down resistor to ICD0
ICD0 PD_ON
Connect pull-down resistor to ICD0
S20
BREAK
PD_OFF BREAK
Disconnect pull-down resistor to BREAK
BREAK PD_ON
Connect pull-down resistor to BREAK
Default: S14 = INITXICE S15 = TRSTXICE S20 = OFF-BREAK
S16 = OFFICD3 S17 = OFFICD2 S18 = OFFICD1
S19 = OFFICD0
Note:
1. If the in-circuit-emulator (ICE) is used, the default settings have to be used.

Jumpers and Switches
FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A 16
5.1.3 External Emulation Memory
The size of the external emulation memory and the emulation memory width is selectable.
Jumper
Setting
Description
S13
D32_D16SL
D32 X
External emulation memory is used in a 32 bit width
X D16
External emulation memory is used in a 16 bit width
Jumper
MDENS2
MDENS1
MDENS0
Size
S10 MDENS1
S11 MDENS0
S12 MDENS2
1
1
1
8 MByte
1
1
0
4 MByte
1
0
1
2 MByte
1
0
0
1 MByte
0
1
1
512 kByte
0
1
0
Prohibited
0
0
1
Prohibited
0
0
0
0 Byte
Default: S13 = D32-X
MDENS0 = 0 MDENS1 = 0 MDENS2 = 0

Jumpers and Switches
FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A 17
5.1.4 Clock Control
The source of the main and the sub clock is selectable between the adapter board and the evaluation board.
MCLKI and MCLKO of the external bus interface can be connected to the evaluation board or can be shorten on
the adapter board.
Jumper
Setting
Description
S22
EML X0
Main clock provided from adapter board
X0 - USER
Main clock provided from evaluation board
S23
EML X1
Main clock provided from adapter board
X1 - USER
Main clock provided from evaluation board
S24
EML X0A
Sub clock provided from adapter board
X0A - USER
Sub clock provided from evaluation board
S25
EML X1A
Sub clock provided from adapter board
X1A - USER
Sub clock provided from evaluation board
S30 / S31
MCLKI /
MCLKO
EVA MCLKI
EVA MCLKO
MCLKI and MCLKO are not connected to evaluation board. MCLKI
and MCLKO are shorten
MCLKI USER
MCLKO USER
MCLKI and MCLKO are connected to evaluation board. MCLKI and
MCLKO are not shorten
Default: S22 = EML-X0 S23 = EML-X1 S24 = EML-X0A
S25 = EML-X1A
S30 = MCLKI-USER S31 = MCLKO-USER
By default the clocks are provided from the adapter board.
By default MCLKI and MCLKO are connected to the evaluation board.

Jumpers and Switches
FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A 18
5.1.5 Power Settings
The voltage sources are selectable.
Jumper
Setting
Description
S26
SHDNSEL
UVCC5 SHDNSEL
Keep watching VCC5 of evaluation board
SHDNSE UVCC3
Keep watching VCC3 of evaluation board
S27
VCCC3SEL
3.3V VCCC3SEL

VCCC3SEL 3.5V
3.5V is supplied to VCC3 of MB91V460
S28
VCC5
UVCC3 VCC5
Connect VCC3 of the adapter board to VCC3 of evaluation board
VCC5 UVCC5
Connect VCC5 of the adapter board to VCC5 of evaluation board
S29
UVCC3H
UVCC5 UVCC3H
VCC5H is generated from VCC5 by adding +1 V
UVCC3H UVCC3
VCC5H is generated from VCC3 by adding +1 V
S8
C
VCC3 C
Connect to VCC3 of MB91V460
C VCC3C
Connect to the C terminal of the evaluation board
Default: S26 = SHDNSELUVCC3 S27 = VCCC3SEL3.5V
S28 = VCC5UVCC5 S29 = UVCC3HUVCC3
S8 = VCC3 C
Note:
1. SHDNSEL: VCC3 or VCC5 can be supervised. If the selected voltage fails, the power supply of the
evaluation chip will be cancelled.
5.1.6 Signal Routing
Some signal can be routed depending on the application of the evaluation board.
Jumper
Setting
Description
S21
P10_7
PULLDOWN 
P10_7
Pull-down resistor is connected to P10_7
P10_7 PULLUP
Pull-up resistor is connected to P10_7
S32/S33
P224/P242
P224 CN2_B68
P242 CN3_A6
P22_4 is connected to CN2_B68
P24_2 is connected to CN3_A6
P224 CN3_A6
P242 CN2_B68
P22_4 is connected to CN3_A6
P24_2 is connected to CN2_B68
S34/S35
P225/P243
P225 CN2_B67
P243 CN3_A5
P22_5 is connected to CN2_B67
P24_3 is connected to CN3_A5
P225 CN3_A5
P243 CN2_B67
P22_5 is connected to CN3_A5
P24_3 is connected to CN2_B67
Default: S21 = PULLDOWN P10_7
S32 = P224 CN2_B68 S33 = P242 CN3_A6
S34 = P225 CN2_B67 S35 = P243 CN3_A5

Jumpers and Switches
FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A 19
5.1.7 Default Jumper Settings
In Figure 5-1 the default jumper settings of the adapter board are marked. The resistor can be removed, beside
of R71, R74 and R75.
Figure 5-1. Default Jumper Settings of the Adapter Board

Jumpers and Switches
FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A 20
5.2 Jumpers of the evaluation board SK-91460-MAIN V1.2
In this section only the jumpers, influencing the adapter board are explained. Please refer to the user guide of the
evaluation board SK-91460-MAIN V1.2 for the other jumpers and switches.
5.2.1 Analogue Power Supply Voltage
The power supply for the ports of the adapter board is generated by the evaluation board. The voltage is
selectable between 3.6 V and 5 V.
Jumper
Setting
Description
SL260
closed
The microcontroller interface is powered with 3,3V
open
The microcontroller interface is powered with 5V
SL262
closed
Power supply MCU_Vcc is connected
open
Power supply MCU_Vcc is disconnected
ST370
closed
3,3V is supplied to UVCC3
open
3,3V is not supplied to UVCC3
ST371
closed
3,3V is supplied to VCC3C
open
3,3V is not supplied to VCC3C
Default: SL260 = open SL262 = closed
ST370 = closed ST371 = closed
By default, the I/O-ports are supplied by 5 V.
Note:
1. The Jumper S28 of the adapter board selects UVCC3 or MCU_VCC (UVCC5) as power supply for the I/O-
port. By default this Jumper selects MCU_VCC (UVCC5).
