Cypress CY8CKIT-042 User manual

CY8CKIT-042 QUICK START GUIDE
Download and Install the latest kit software and examples from
www.cypress.com/go/CY8CKIT-042
Connect the board to
your computer using
the provided USB cable
Blue LED Blinks
Design with PSoC®CreatorTM
PIONEER KIT
1
3
4
2

© 2013 Cypress Semiconductor Corporation. All rights reserved.
All trademarks or registered trademarks referenced herein are the properties of their respective owners.
Doc.#: 001-86373 Rev.**
USB Connector (J10)
CapSense®
Slider
RGB LED
PSoC 4
Power Supply
Jumper (J13)
PSoC 4
44 TQFP
ArduinoTM
Compatible
I/O Header (J3)
ArduinoTM
Compatible
I/O Header (J4)
PSoC 4 Reset Button
Power LED
System Power
Supply Jumper (J9)
PSoC 5LP I/O
Header (J8)
Digilent®PmodTM
Compatible
I/O Header (J5)
PSoC 5LP
Programmer
and Debugger
ArduinoTM
Compatible
I/O Header (J1)
ArduinoTM
Compatible
I/O Header (J2)
Push Button
Switch
PSOC 4 Pioneer Kit Details
CY8CKIT-042 QUICK START GUIDE
For the latest information about this Kit and to download Kit Software and Hardware les,
visit http://www.cypress.com/go/CY8CKIT-042
PSoC 4 External
Program Header (J6)
Status LED
PIONEER KIT
