D-Link DSL-200 - 8 Mbps DSL Modem User manual

DSL-200ADSLUSB Modem
User s Guide
( Mar. 2004)
651AU2000055
Printed In China
RECYCLABLE

DSL-200 ADSL USB Modem User s Guide
i
Wichtige Sicherheitshinweise
1. Bitte lesen Sie sich diese Hinweise sorgf ltig durch.
2. Heben Sie diese Anleitung für den sp tern Gebrauch auf.
3. Vor jedem Reinigen ist das Ger t vom Stromnetz zu trennen. Vervenden Sie keine
Flüssig- oder Aerosolreiniger. Am besten dient ein angefeuchtetes Tuch zur Reinigung.
4.Um eine Besch digung des Ger tes zu vermeiden sollten Sie nur Zubehörteile verwenden,
die vom Hersteller zugelassen sind.
5. Das Ger t is vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Ger tes ist auf sichern Stand zu achten. Ein Kippen oder Fallen
könnte Verletzungen hervorrufen. Verwenden Sie nur sichere Standorte und beachten
Sie die Aufstellhinweise des Herstellers.
7. Die Belüftungsöffnungen dienen zur Luftzirkulation die das Ger t vor Überhitzung
schützt. Sorgen Sie dafür, daßdiese Öffnungen nicht abgedeckt werden.
8. Beachten Sie beim Anschlußan das Stromnetz die Anschlußwerte.
9. Die Netzanschlußsteckdose mußaus Gründen der elektrischen Sicherheit einen
Schutzleiterkontakt haben.
10.Verlegen Sie die Netzanschlußleitung so, daßniemand darüber fallen kann. Es sollete
auch nichts auf der Leitung abgestellt werden.
11.Alle Hinweise und Warnungen die sich am Ger ten befinden sind zu beachten.
12.Wird das Ger t über einen l ngeren Zeitraum nicht benutzt, sollten Sie es vom
Stromnetz trennen. Somit wird im Falle einer Überspannung eine Besch digung
vermieden.
13.Durch die Lüftungsöffnungen dürfen niemals Gegenst nde oder Flüssigkeiten in das
Ger t gelangen. Dies könnte einen Brand bzw. Elektrischen Schlag auslösen.
14.Öffnen Sie niemals das Ger t. Das Ger t darf aus Gründen der elektrischen Sicherheit
nur von authorisiertem Servicepersonal geöffnet werden.
15.Wenn folgende Situationen auftreten ist das Ger t vom Stromnetz zu trennen und von
einer qualifizierten Servicestelle zu überprüfen:
a –Netzkabel oder Netzstecker sint besch digt.
b –Flüssigkeit ist in das Ger t eingedrungen.
c –Das Ger t war Feuchtigkeit ausgesetzt.
d –Wenn das Ger t nicht der Bedienungsanleitung ensprechend funktioniert oder Sie mit
Hilfe dieser Anleitung keine Verbesserung erzielen.
e –Das Ger t ist gefallen und/oder das Geh use ist besch digt.
f –Wenn das Ger t deutliche Anzeichen eines Defektes aufweist.
16.Bei Reparaturen dürfen nur Orginalersatzteile bzw. den Orginalteilen entsprechende
Teile verwendet werden. Der Einsatz von ungeeigneten Ersatzteilen kann eine weitere
Besch digung hervorrufen.
17.Wenden Sie sich mit allen Fragen die Service und Repartur betreffen an Ihren
Servicepartner. Somit stellen Sie die Betriebssicherheit des Ger tes sicher.

DSL-200 ADSL USB Modem User s Guide
ii
Limited Warranty
Hardware:
D-Link warrants its hardware products to be free from defects in workmanship and
materials, under normal use and service, for the following periods measured from date of
purchase from D-Link or its Authorized Reseller:
Product Type Warranty Period
Complete products One year
Spare parts and spare kits 90 days
The one-year period of warranty on complete products applies on condition that the
product's Registration Card is filled out and returned to a D-Link office within ninety (90)
days of purchase. A list of D-Link offices is provided at the back of this manual, together
with a copy of the Registration Card. Failing such timely registration of purchase, the
warranty period shall be limited to 90 days.
If the product proves defective within the applicable warranty period, D-Link will provide
repair or replacement of the product. D-Link shall have the sole discretion whether to
repair or replace, and replacement product may be new or reconditioned. Replacement
product shall be of equivalent or better specifications, relative to the defective product, but
need not be identical. Any product or part repaired by D-Link pursuant to this warranty
shall have a warranty period of not less than 90 days, from date of such repair, irrespective
of any earlier expiration of original warranty period. When D-Link provides replacement,
then the defective product becomes the property of D-Link.
Warranty service may be obtained by contacting a D-Link office within the applicable
warranty period, and requesting a Return Material Authorization (RMA) number. If a
Registration Card for the product in question has not been returned to D-Link, then a proof
of purchase (such as a copy of the dated purchase invoice) must be provided. If Purchaser's
circumstances require special handling of warranty correction, then at the time of
requesting RMA number, Purchaser may also propose special procedure as may be suitable
to the case.
After an RMA number is issued, the defective product must be packaged securely in the
original or other suitable shipping package to ensure that it will not be damaged in transit,
and the RMA number must be prominently marked on the outside of the package. The
package must be mailed or otherwise shipped to D-Link with all costs of
mailing/shipping/insurance prepaid; D-Link will ordinarily reimburse Purchaser for
mailing/shipping/insurance expenses incurred for return of defective product in accordance
with this warranty. D-Link shall never be responsible for any software, firmware,
information, or memory data of Purchaser contained in, stored on, or integrated with any
product returned to D-Link pursuant to this warranty.
Any package returned to D-Link without an RMA number will be rejected and shipped back
to Purchaser at Purchaser's expense, and D-Link reserves the right in such a case to levy a
reasonable handling charge in addition mailing or shipping costs.
Software:
Warrantyservice for software products maybe obtained bycontacting a D-Link office within the applicable
warrantyperiod. Alist of D-Link offices is provided at the back of this manual, together with a copyof the
Registration Card. If a Registration Card for the product in question has not been returned to a D-Link office,
then a proof of purchase (such as a copyof the dated purchase invoice) must be provided when requesting
warrantyservice. The term"purchase"in this software warrantyrefers to the purchase transaction and resulting
license to use such software.
D-Link warrants that its software products will performin substantial conformance with the applicable product
documentation provided byD-Link with such software product, for a period of ninety(90) days fromthe date of

DSL-200 ADSL USB Modem User s Guide
iii
purchase fromD-Link or its Authorized Reseller. D-Link warrants the magnetic media, on which D-Link
provides its software product, against failure during the same warrantyperiod. This warrantyapplies to
purchased software, and to replacement software provided byD-Link pursuant to this warranty, but shall not
applyto anyupdate or replacement which maybe provided for download via the Internet, or to anyupdate which
mayotherwise be provided free of charge.
D-Link's sole obligation under this software warrantyshall be to replace anydefective software product with
product which substantiallyconforms to D-Link's applicable product documentation. Purchaser assumes
responsibilityfor the selection of appropriate application and system/platformsoftware and associated reference
materials. D-Link makes no warrantythat its software products will work in combination with anyhardware, or
anyapplication or system/platformsoftware product provided byanythird party, excepting onlysuch products
as are expresslyrepresented, in D-Link's applicable product documentation as being compatible. D-Link's
obligation under this warrantyshall be a reasonable effort to provide compatibility, but D-Link shall have no
obligation to provide compatibilitywhen there is fault in the third-partyhardware or software. D-Link makes no
warrantythat operation of its software products will be uninterrupted or absolutelyerror-free, and no warranty
that all defects in the software product, within or without the scope of D-Link's applicable product
documentation, will be corrected.
LIMITATION OF WARRANTIES
IF THE D-LINK PRODUCT DOES NOT OPERATE AS WARRANTED ABOVE, THE
CUSTOMER'S SOLE REMEDY SHALL BE, AT D-LINK'S OPTION, REPAIR OR
REPLACEMENT. THE FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND
ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, EITHER IN FACT
OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. D-LINK NEITHER
ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER
LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION MAINTENANCE OR USE OF
D-LINK'S PRODUCTS
D-LINK SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND
EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT
EXIST OR WAS CAUSED BY THE CUSTOMER'S OR ANY THIRD PERSON'S MISUSE,
NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO
REPAIR, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY
ACCIDENT, FIRE, LIGHTNING OR OTHER HAZARD.
LIMITATION OF LIABILITY
IN NO EVENT WILL D-LINK BE LIABLE FOR ANY DAMAGES, INCLUDING LOSS OF DATA,
LOSS OF PROFITS, COST OF COVER OR OTHER INCIDENTAL, CONSEQUENTIAL OR
INDIRECT DAMAGES ARISING OUT THE INSTALLATION, MAINTENANCE, USE,
PERFORMANCE, FAILURE OR INTERRUPTION OF A D- LINK PRODUCT, HOWEVER
CAUSED AND ON ANY THEORY OF LIABILITY. THIS LIMITATION WILL APPLY EVEN IF D-
LINK HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
IF YOU PURCHASED A D-LINK PRODUCT IN THE UNITED STATES, SOME STATES DO
NOT ALLOW THE LIMITATION OR EXCLUSION OF LIABILITY FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
D-Link Offices for Registration and WarrantyService
The product's Registration Card, provided at the back of this manual, must be sent to a
D-Link office. To obtain an RMA number for warranty service as to a hardware product, or
to obtain warranty service as to a software product, contact the D-Link office nearest you.
An addresses/telephone/fax list of D-Link offices is provided in the back of this manual.

DSL-200 ADSL USB Modem User s Guide
iv
Trademarks
Copyright 2003 D-Link Corporation.
Contents subject to change without prior notice.
D-Link is a registered trademark of D-Link Corporation/D-Link Systems, Inc.
All other trademarks belong to their respective proprietors.
Copyright Statement
No part of this publication may be reproduced in any form or by any means or used to make
any derivative such as translation, transformation, or adaptation without permission from
D-Link Corporation/D-Link Systems Inc., as stipulated by the United States Copyright Act
of 1976
FCC Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-Consult the dealer or an experienced radio/TV technician for help.
CE Mark Warning
This is a Class B product. In a domestic environment, this product may cause radio
interference in which case the user may be required to take adequate measures

Table of Contents
OVERVIEWOFTHE USER S GUIDE...........................................................................................................................6
OPERATING SYSTEMS ..............................................................................................................................................7
üUSB Port.....................................................................................................................................................7
MICROFILTERS AND SPLITTERS................................................................................................................................7
Microfilters.........................................................................................................................................................8
Line Splitter........................................................................................................................................................8
ADSL Service......................................................................................................................................................8
ADSL Service......................................................................................................................................................9
Network Protocol and the Software Driver........................................................................................................9
Encapsulation Method........................................................................................................................................9
Modulation Technique........................................................................................................................................9
2 INTRODUCTION......................................................................................................................................11
WHAT IS ADSL?...................................................................................................................................................11
MODEM DESCRIPTION AND OPERATION ................................................................................................................11
PRODUCT FEATURES .............................................................................................................................................12
Rear Panel........................................................................................................................................................12
Front Panel.......................................................................................................................................................13
LED Indicators.................................................................................................................................................13
3 MODEMINSTALLATION.......................................................................................................................14
Connect the ADSL............................................................................................................................................14
4 SOFTWARE INSTALLATION................................................................................................................15
WHAT DRIVER TO INSTALL....................................................................................................................................15
INSTALL THE SOFTWARE DRIVER ..........................................................................................................................16
Install the Driver..............................................................................................................................................16
Verify the ADSL Connection.............................................................................................................................23
Desktop Monitoring........................................................................................................................................................23
LED Indicators................................................................................................................................................................23
CONNECT TO THE INTERNET.....................................................................................................................24
Dial-Up Connection (WAN Driver Only).........................................................................................................24
CONNECTTO INTERNET - LAN DRIVER USERS .....................................................................................................26
Windows 98 or Windows Me (LAN Driver)......................................................................................................26
Windows 2000 or Windows XP (LAN Driver)..................................................................................................27
5 MONITORING THE MODEM................................................................................................................28
CHANGING MODEMCONFIGURATION...................................................................................................30
7 UNINSTALLING THE MODEM.............................................................................................................32
Using the Uninstall Program............................................................................................................................32
6 TECHNICAL SPECIFICATIONS............................................................................................................35

About This User
s Guide
This user’sguide tells you how to install your DSL-200 ADSL USB Modem and use it to
connect to the Internet.
ADSL services are provided by, and sold by avariety of businesses. Your ADSL service
provider may be your telephone company, an Internet service provider (ISP), abusiness that
specializes in providing network services or acombination of any of these. This guide uses
the generic terms DSL service provider and network service provider,to refer to any business
or agent that provides DSL service.
Overviewof the User s Guide
♦ Chapter 1 –Introduction provides a brief description of ADSL technologyand a general description of the
Modemand its features.
♦ Chapter 2 -Modem Installation provides instructions for the physical installation of the Modemand cable
connections.
♦ Chapter 3 Software Installation is a step-by-step description of the installation of the software driver
needed for Modemoperation.
♦ Chapter 4 –Monitoring the Modem describes the various status monitoring functions available with the
Modem.
♦ Appendix A –Technical Specifications is a list of specifications for the Modem.
♦ Appendix B –Uninstalling the Modem describes the steps necessaryto uninstall the Modemand its driver.

Before You Start
In addition to the Modem hardware and software drivers, you will to gather information
before you begin to install the device. Your DSL service provider will giveyou information
required for asuccessful ADSL connection. You will use this information when you decide
which driver to install and when you configure the Modem. In order to avoid problems
please read this section and make sure you understand all the prerequisites for proper
installation of your new Modem.
Operating Systems
The D-Link DSL-200 can be used with PCs running Microsoft®Windows 98, Windows 98
Second Edition, Windows 2000, Windows Millennium Edition or Windows XP.
ü USB Port
In addition to the Windows OS, you will need aUSB (Universal Serial Bus) type Bport on
your computer. These are commonly installed on newer computers, however older PCs may
require an additional installation.
Microfilters and Splitters
Most ADSL clients will be required to install asimple device that prevents the ADSL line
from interfering with regular telephone services. These devices are commonly referred to as
microfilters or sometimes called (inaccurately) line splitters. They are easy to install and use
standard telephone connectors and cable.
Some DSL service providers will send atelecommunications technician to modify the
telephone line, usually at the point where the phone line enters the building. If atechnician
has divided or split your telephone line into two separate lines -one for regular telephone
service and the other for ADSL –then you do not need to use any type of filter device. Follow
the instructions given to you by your DSL service provider about where and how you should
connect the Modem to the ADSL line.

Microfilters
Note: Do not install the microfilter between the Modem and the telephone jack.
Microfilters are only intended for use with regular telephones, Fax machines and other
regular telephone devices.
Line Splitter
If you are instructed to use a “line splitter”,you must install the device between the Modem
and the phone jack. Use standard telephone cable with standard RJ-11 connectors. The
splitter has three RJ-11 ports used to connect to the wall jack, the Modem and if desired, a
telephone or telephone device. The connection ports are typically labeled as follows:
Line - This port connects to the wall jack.
ADSL –This port connects to the Modem.
Phone –This port connects to a telephone or other telephone device.
DSL “Splitter”Device
This diagramillustrates howa line
splitter should be installed.
In-Line Microfilter
Unless you are instructed to use a
“line splitter”(see be
low), it will be
necessaryto install amicrofilter (low
pass filter) device for each telephone
or telephone device (answering
machines, Faxes etc.) that share the
line with the ADSL service.
Microfilters are easy-to-install, in-
line devices, which attach
to the
telephone cable between the
telephone and wall jack. Microfilters
that install behind the wall plate are
also available. Atypical in-
line
microfilter installation is shownin
the diagramto the right.

ADSL Service
In order to use the Modem you must first haveADSL service established with aDSL service
provider.
There are four standards used for ADSL connections known as ANSI T1.413 issue 2, G.Lite,
G.dmt and G.hs. The standards differ somewhat as to data transfer speed or bit rate. For
user convenience, the Modem supports the G.hs Auto-handshake ADSL standard. This
allows the Modem to operate with either type of connection.
Network Protocol and the Software Driver
The protocol used for your ADSL service will determine the particular software driver to be
installed. You will need to select one driver to operate the Modem. Ask your DSL service
provider to assist you in selecting either the LAN (Local Area Network) or WAN (Wide Area
Network) driver to operate the Modem.
If your ADSL service uses PPP (Point-to-Point Protocol) to establish the connection, you will
install the WAN driver. Using aPPP connection will be familiar to anyone who has used a
conventional dial-up analog modem for Internet connection. PPP is used to verify the user’s
identity and to control access to the network. APPP session requires that auser name and
password be given before gaining access to network services. PPP sessions are ended when
you log-off and terminate your connection to the service provider’snetwork. Specifically, if
your ADSL service uses the protocol defined by RFC2364, PPP over ATMAdaptation Layer 5,
or RFC2516, PPP over Ethernet, install the WAN driver.
If the protocol used for your ADSL service is defined by RFC2684, Multiprotocol
Encapsulation over ATMAdaptation Layer 5(Bridged Ethernet),then you will need to install
the LAN driver. LAN driver users may be required to manually configure your IP settings.
Your DSL service provider will tell you if you need to configure your PCs IP settings.
The drivers are fundamentally different in the way they relate to operating system of the
computer. The computer/Modem relationship can be summarized as follows:
WANdriver –To your computer, the Modem appears as aconventional dial-up modem
device, the Modem employs the same Microsoft Dial-Up Networking software. There is
no actual dialing or any activity in the voice band frequencies on the telephone line,
but you must still provide a user name and password to log-on.
LANdriver –To your computer, the Modem appears as an Ethernet device.
Connection is automatic, similar to a connection to an Ethernet device.
Encapsulation Method
It may be necessary to use an encapsulation method that is different from the default
method. The protocol used for your connection, and thus the driver you use will determine
which encapsulation method is used. If your DSL service provider does not specify, use the
default encapsulation method.
Modulation Technique
It may be necessary to use a modulation method that is different from the default method. If
your DSL service provider does not specify, use the default modulation method called
Multimode.

Use the tables provided here to record the information you need to install the Modem.
SETTINGS TABLE (all users)
VPI: VCI:
Software Driver:
The driver used depends on the connection protocol used for your networkservices.
Ø Select the WAN driver ifyour connection is a PPP connection. That is ifyou
are using RFC 2364 PPP over ATM or RFC 2516 PPPoE PPP over Ethernet.
Ø Select the LAN driver ifyou are using RFC 2684 Ethernet over ATM.
Encapsulation Method: (choose one)
WAN Driver:
RFC 2364 PPPoATM NULL Encapsulation
RFC 2364 PPPoATM LLC Encapsulation
RFC 2516 PPPoE Encapsulation
LAN Driver:
RFC 2684 IPoATM Bridged LLC Encapsulation
RFC 2684 IPoATM Bridged VC Encapsulation
RFC 2684 IPoATM Routed LLC Encapsulation
RFC 2684 IPoATM Routed VC Encapsulation
Modulation Method: (choose one)
T1.413
Multimode
G.Lite
G.DMT
ACCOUNT INFORMATION (WAN driver users only)
User Name:
Password:
IP CONFIGURATION (LAN driver only)
IP Address:
Subnet Mask:
Gateway:
DNS Host Name:
DNS Domain:
DNS Server:

1
2 INTRODUCTION
ADSL modem technology is a relatively new technology and may be unfamiliar to the reader.
In this section, we introduce you to ADSL technology and giveabrief description of its key
attributes. We also giveageneral description of the D-Link DSL-200 USB Modem and its
main features.
What is ADSL?
Asymmetric Digital Subscriber Line (ADSL) is an access technology that utilizes ordinary
copper telephone lines to enable broadband high-speed digital data transmission and
interactivemultimedia applications for business and residential customers. Using existing
phone lines avoids the need for adding expensive new cable.
ADSL modems use digital coding techniques that greatly increase the bandwidth capacity of
telephone lines without interfering with regular telephone services. For the ADSL modem
user, this means much faster data communications. ADSL modems make it possible to
enjoy benefits such as high-speed Internet access, telecommuting, collaborativecomputing,
distance learning, movies on demand and multi-player video gaming without experiencing
any loss of quality or disruption of voice/fax telephone capabilities.
ADSL provides a dedicated service over a single telephone line operating at speeds of up to 8
Mbps downstream (to the user) and up to 640 Kbps upstream, depending on the type of
service and local telephone line conditions. These conditions are ideal for many user
applications. Asecure point-to-point connection is established between the user and the
central office of the local telephone company. The user is always connected, thus
eliminating dial-up time and simplifying connectivity issues.
D-Link ADSL devices incorporate the recommendations of the ADSL Forum (www.adsl.com)
regarding framing, data format, and upper layer protocols.
Modem Description and Operation
The DSL-200 ADSL USB Modem is easy to install and use. Please note that you must first
install the software driver for the device by following the instructions in Chapter 3. Once the
driver has been installed you can connect the Modem to your computer. The Modem
connects directly to any functional USB port on a PC with standard USB cable.
Software drivers for D-Link ADSL USB Modems can be fully upgraded by simply loading
newer versions onto your PC. This will allow you to update the modem and use new features
and enhancements as they are developed and standardized. Online information regarding
the latest downloadable software and improvements can be found at
http://tsd.dlink.com.tw.

Product Features
The D-Link DSL-200 Modem provides the following features:
Ø G.hs compliant (Auto-handshake)
Ø G.dmt full rate compliant
Ø G.lite compliant
Ø RFC 2684 (Bridged Ethernet) compliant
Ø RFC 2364 PPP over ATM compliant
Ø RFC 2516 PPP over Ethernet compliant
Ø Compatible with all T1.413 issue 2 (full rate DMTover analog POTS), and CO DSLAM equipment
Ø Compliant with USB Specification Revision 1.1
Ø USB interface to PC host
Ø Plug and Playinstallation
Ø Easyto upgrade software
Ø GUI based configuration and diagnostic tool
Ø Supports up to sixteen simultaneous ATM virtual connections
Rear Panel
Connect both the ADSL cable and the USB cable at the rear of the Modem.

Front Panel
LED Indicators
There are two LED indicators on the Modem:
♦ Power - Indicates the Modemis powered on when lit.
♦ ADSL Link –Indicates a valid ADSL link has been established when lit.

2
3 MODEM INSTALLATION
Before you connect the USB cable, you must install the driver. See the next chapter for
driver installation instructions. The only cable you should connect initially is the ADSL
cable.
Place the Modem in alocation so that you are able to view the LEDs. It should be placed in
an area that is clean, dry and ventilated. Make certain it is not placed near a heat source.
Connect the ADSL
You can begin installing the Modem by performing the following steps:
1. Insert the Installation CD into the CD-ROM drive.
2. Insert one end of the ADSL cable (26 AWG twisted-pair telephone cable) into the
telephone wall jack (RJ-11 port).
3. Insert the other end of the ADSL cable into the ADSL port (RJ-11 port) on the Modem.
4. Follow the software installation instructions in Chapter 3.
DO NOT CONNECT THE USB CABLE!
You must install the software driver before you connect the device to your
computer via the USB cable. You will be prompted to connect the device
during the installation. Connecting the USB cable at this point will initiate the
Found New Hardware process.

3
4 SOFTWARE INSTALLATION
The DSL-200 can be used with the following operating systems:
♦ Microsoft Windows 98
♦ Microsoft Windows 98 Second Edition
♦ Microsoft Windows 2000
♦ Microsoft Windows Millennium Edition
♦ Microsoft Windows XP
The procedures for each system are slightly different so be sure to follow the instructions
provided for your PC’s operating system.
The Microsoft Plug and Play feature will automatically detect the modem after it has been
installed. A new window will appear for each step of the installation.
Once you havethe driver installed and the Modem is connected, you should verify that the
ADSL service is working.
If you wish uninstall the Modem see Appendix B for instructions.
What Driver to Install
You will need to select one driver (see Step 5) to operate the Modem. Which driver you use
will depend on the particular protocol used to provide your ADSL service. Ask your DSL
service provider to assist you in selecting either the WAN or LAN driver to operate the
Modem. Only one driver should be installed.
For PPP connections, install the WAN driver. RFC 2364, PPP over ATM, and RFC 2516, PPP
over Ethernet installations must use the WAN driver.
If the protocol used for your ADSL service is defined by RFC 2684, Multiprotocol
Encapsulation over ATMAdaptation Layer 5(Bridged Ethernet),then you will need to install
the LANdriver.

Install the Software Driver
Install the software driver on acomputer using the Windows 98, Windows 98 Second
Edition, Windows 2000 or Windows Millennium Edition (Windows Me) operating system.
There are two different drivers, the LAN (Local Area Network) or WAN (Wide Area Network)
driver. The instructions in this chapter can be used for either the LAN or WAN driver, the
installation procedure is identical for both. If you are not sure which driver you should
install, see the previous section What Driver to Install for more information.
Install the Driver
Before starting the software setup process, close all windows and quit any application
programs you are running. The installation procedure presented here is the same for
Windows 98, 98SE, Me, 2000, XP* operating systems.
* For Windows XP installations, please read the Read Me file on the Installation CD-ROM.
Follow these steps to install the software driver for the Modem:
1. Insert the DSL-200 Installation CD into the CD-ROM drive. The system should
detect the installation program and run the program automatically. If installation
does not begin automatically after afew seconds, find the start.exe icon located
on the CD and double-click it. To view the contents of the CD, open My Computer
from the desktop, and right-click on your CD-ROM. Select the “Explore”option
and this will reveal the folders and files on the CD.
2. Click the Driver Install button. Anotification message will appear indicating that
the setup process has begun.

3. The Welcome window will appear. Make sure you havequit all other programs
and click Next.
4. In the SelectService Provider window, select “Other Service Provider”and click
Next.

5. In the SelectDriverType window, choose the driver that best suits your ADSL
connection, and then click Next.
6. In the CommunicationSettings window you must provide the PVC settings,
Encapsulation method and Modulation method for configuring the Modem. Type
in the VPI and VCI values in their respective fields.
]

7. In the same window, select the appropriate Encapsulation method from the
drop-down menu. You will select the encapsulation setting that is appropriate for
the driver you are installing.
Note: At this point you must choose the Encapsulation method and Modulation
technique used for your ADSL connection. Be sure to havethe correct
information available. Refer to the Settings Table ifyou have it completed.
§ For RFC 2516 PPPoE, select RFC 2516 PPPoE Encapsulation.
§ If you using RFC 2364 PPPoATM and your service provider has not specified an
encapsulation setting, use RFC 2364 PPPoATM NULL Encapsulation.
If you are using the LAN driver, select the appropriate RFC 2684 encapsulation setting. If
your service provider has not specified an encapsulation setting, use RFC 2684 IPoATM
Bridged LLC Encapsulation.
8. Again in the same window, select the proper Modulation settings using the drop-
down menu. Your service provider will giveyou the appropriate Modulation
settings. Choose T1.413, Multimode, G.Lite or G.DMT.If your service provider
has not specified a modulation setting, use Multimode. Click Next to continue.
