D-Link DGL-4300 - GamerLounge Wireless 108G Gaming... User manual

DGL-4300
1
FEATURES
Wireless 108G Gaming Router
TM
The D-Link DGL-4300 GamerLounge Wireless Gaming Router is an award-winning high-
performance router designed for today and tomorrow's gamers network. Powered by a high-
TM
performance CPU, D-Link cutting-edge GameFuel Priority Technology, multiple Gigabit ports
and up to 108Mbps wireless speed, this 802.11g standard router pushes the limits of basic
networking technology to let you experience the evolution in networking and stay competitive
in your on-line games.
TM
Fit for the True Online Gamer. Equipped with D-Link GameFuel Priority Technology and fine-
tuned software, the DGL-4300 Wireless Gaming Router provides the uninterrupted and
latency-free gaming experience serious on-line gamers expect. This router is customized with
game-centric features for maximum performance and configuration flexibility. It intelligently
manages and automatically prioritizes network traffic to better execute bandwidth-sensitive
multimedia applications. Ports are pre-configured to accommodate up to 256 policies for
games and applications. Customizable settings allow you to add or modify new applications
or game configurations.
Powerful Hardware. The DGL-4300 Wireless Gaming Router's hardware is designed for
game intimidation. This includes enhanced wireless technology for optimal range and
connectivity up to 108Mbps and a 5dBi high-gain antenna for exceptional wireless signal
coverage. A high-performance CPU supports thousands of concurrent connections for P2P
applications and multi-player interactivity and enables multi-tasking between other
applications without degradation in game connection. One Fast Ethernet 10/100Mbps WAN
port connects the router to broadband Internet, and four Gigabit LAN ports provide
bottleneck-free bandwidth to game stations.
Play Your Games, Protect Your Network. The DGL-4300 Wireless Gaming Router protects
your wireless data with support for both Wi-Fi Protected Access (WPA) and 128-bit Wired
Equivalent Privacy (WEP) data encryption. In addition, integrated Stateful Packet Inspection
(SPI) and Network Address Translation (NAT) firewall help protect your network against
hackers, war drivers, and other unauthorized users. You can create access control policies to
control network access based on time, date, web sites, and/or applications. Disable SSID
Broadcast and MAC Filtering features protect your router against unauthorized access from
your wireless network. Virtual Private Network (VPN) pass-through is supported to allow
remote users to create secure connections to your network.
Gigabit-Speed
For On-Line Streaming Video Games
108Mbps Turbo Wireless Speed
High-Gain Antenna for Exceptional Wireless Signal Coverage
Multiple Built-in Gigabit Ports
High-Performance CPU for Thousand Concurrent Connections/Multi-Player
Interactivity
Uninterrupted/Latency-Free Gaming Effects
Prioritized Network Traffic Optimized for Games
High-Speed Wireless Connection
802.11g Wireless Standard
Up to 54Mbps Wireless Data Transfer Rates
D-Link 108G Technology for Greater Speeds
5dBi High-Gain Antenna
Powerful Hardware
10/100Mbps WAN Port
4 Built-in Gigabit LAN Ports
CPU Supports Thousands of Concurrent Connections
Advanced Software
TM
GameFuel Priority Technology
Customizable Settings for Games and Applications
QoS Prioritized Network Traffic
Policy-Based Configuration Settings
Enhanced Security
64/128-bit WEP Data Encryption
WPA Personal
WPA Enterprise
MAC Address Filtering
SPI/NAT Firewall Protection
VPN Pass-Through
* Maximum wireless signal rate derived from IEEE Standard
802.11g specifications. Actual data throughput will vary.
Network conditions and environmental factors, including
volume of network traffic, building materials and construction,
and network overhead, lower actual data throughput rate.

2
Product Specifications
Physical & Environmental
Awards
DGL-4300
Minimum System Requirements Wireless Signal Rates Wireless Security
Cable or DSL modem with Ethernet port (With automatic fallback) 64/128-bit WEP data encryption
To change default settings: D-Link 108G 108Mbps, 54Mbps, 48Mbps, 36Mbps, 24Mbps, MAC address filtering
Computer with 1.2GHz processor 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps, 5.5Mbps, 2Mbps, WPA Personal (WPA-PSK using TKIP or AES)
256MB memory 1Mbps WPA Enterprise (WPA-EAP using TKIP)
CD-ROM drive Broadcast SSID control
Ethernet adapter with TCP/IP protocol installed Antenna Automatic channel selection
Windows XP, 2000, ME or MacOS X v.10.3, v.10.2, v.10.1 5dBi detachable dipole antenna (reverse SMA connector)
Internet Explorer v.6 or Netscape Navigator v.7 Diagnostic LEDs
Software Features Power
TM
Standards WAN
GameFuel Priority Technology
IEEE 802.11g WLAN
Up to 256 firewall port configurations
IEEE 802.11b LAN
Access control policies (parental controls)
IEEE 802.3 Internal and external system logging
IEEE 802.3u Static/Dynamic Routing
Oversized NAT table
Hardware Interface Email alerts
4 10/100/1000Mbps auto-sensing Gigabit LAN ports
10/100Mbps auto-sensing Ethernet WAN port
802.11g WLAN supporting 108Mbps Turbo mode speed
Power Input Requirement Safety
DC 5V, 2.5A UL
TUV
Power Supply
Through external power adapter Package Contents
DGL-4300 Wireless Gaming Router
Dimensions Detachable antenna
190.5 (L) x 116.84 (W) x 35 (H) mm Cat. 5 Ethernet cable
(7.5 x 4.6 x 1.375 inches) External power adapter
Mounting kit
EMI Vertical stand
FCC Class B CD-ROM with User's Manual
CE Quick Installation Guide
C-Tick
* Maximum wireless signal rate derived from IEEE standard 802.11g specifications.
Actual data throughput will vary. Network conditions and environmental factors,
including volume of network traffic, building materials and construction, and
network overhead, can lower actual data throughput rate.
9 Out of 10 Rating
December 2004
Editor's Choice
January 2005
DGL-4300
GameSpot
Editor's Choice
April 2005
Firing Squad
Editor's Choice
April 2005
PC Enthusiast Magazine
Editor's Choice
2005
PC Gamer
Editor's Choice
2005
Xbox Solution
Editor's Choice
April 2005
AeA High Tech Awards
2005 Product of the Year
Finalist
ExtremeTech APPROVED
Award 2005
Phoronix
Editor's Choice
March 2005
Viperliar
Editor's Choice
March 2005
Computer Gaming World
Editor's Choice
February 2005
Team Xbox
Editor's Choice Gold Award
February 2005
GameFirst!
Five Out of Five Stars Rating
January 2005
GameIllustrated
Editor's Choice
2005
CPU
Editor's Choice
2005
* ExtremeTech APPROVED Award Logo is a trademark of Ziff Davis Publishing Holdings Inc.
Used under license. All other logos and trademarks are properties of their proprietors.

3
Rev. 01 (May 2005)
Specifications subject to change without prior notice.
D-Link is a registered trademark and GamerLounge and GameFuel are trademarks of D-Link Corporation/D-Link System Inc. All other trademarks belong to their proprietors.
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone] #350
FAX: [phone]
FAX: [phone]
FAX: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
TEL: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
FAX: [phone]
U.S.A
Canada
Europe (U. K.)
Germany
France
Netherlands
Belgium
Italy
Sweden
Denmark
Norway
Finland
Spain
Portugal
Czech Republic
Switzerland
Greece
Luxemburg
Poland
Hungary
Singapore
Australia
India
Middle East (Dubai)
Turkey
Egypt
Israel
LatinAmerica
Brazil
South Africa
Russia
China
Taiwan
Headquarters
D-Link Worldwide Offices
Wireless 108G Gaming Router
DGL-4300
Wireless
Gaming Adapter
Wireless
Gaming Adapter
Wireless
Gaming Adapter
Gigabit
Games Stations
DGL-4300
Wireless 108G
Gaming Router
RR TM
Connecting PlayStation 2, Xbox and GameCube Consoles and Gigabit Games Stations
