D-Link KVM-222 User manual

USER MANUAL
KVM-222
VERSION 1.0

2D-Link KVM-222 User Manual
Table of Contents
Product Overview ........................................................ 4
Package Contents ................................................... 4
System Requirements ............................................. 4
Features ..................................................................5
KVM Installation ........................................................... 6
Hardware Installation ...............................................6
Hardware Overview ................................................. 7
Windows Installation ................................................8
MAC Installation ......................................................9
KVM Operation ........................................................... 10
Accessing the KVM - Windows .............................. 10
Accessing the KVM - MAC .................................... 11
Accessing the KVM - Linux .................................... 12
Troubleshooting ........................................................ 13
Troubleshooting .....................................................13
Appendix A - Technical Specications ................... 14
Technical Specications ........................................ 14

3D-Link KVM-222 User Manual
D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to
notify any person or organization of such revisions or changes.
Manual Revisions
Trademarks
D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in
the United States or other countries. All other company or product names mentioned herein are trademarks or
registered trademarks of their respective companies.
Copyright © 2010 by D-Link Systems, Inc.
All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written
permission from D-Link Systems, Inc.
Revision Date Description
1.0 May 17, 2010 KVM-222 Revision A1 with rmware version 1.00
Preface

4D-Link KVM-222 User Manual
Product OverviewProduct Overview
If any of the above items are missing, please contact your reseller.
KVM-222 Installation Guide CD-ROM
Package Contents
System Requirements
Windows 2000 / XP / Vista / 7
Linux
Mac OS (10.3 and higher)

5D-Link KVM-222 User Manual
Product Overview
Features
Access two PCs using a single console
Saves space and saves money
Select PCs by using Remote Control button or Hot key commands or AP
Support SVGA, VGA, XGA, WXGA, UXGA, WUXGA, QXGA and multi-sync
monitors (resolutions of up to 2048*1536)
Remote control
Audio support

6D-Link KVM-222 User Manual
KVM InstallationKVM Installation
Hardware Installation
Note:
This KVM Switch will not detect whether a computer is on or off if the “Power On”
function is set in the BIOS. If you switch to a computer that is turned off, nothing will be
displayed on the monitor.
Please follow the diagram below to connect the KVM switch to your workstation computers. Speakers are optional.

7D-Link KVM-222 User Manual
KVM Installation
Hardware Overview
AUDIO CONNECTOR
Connects to PC audio port
AUDIO PORT
Connects to speakers
VGA CONNECTOR
Connects to monitor cable
USB CONNECTOR
Connects to PC USB Port
USB PORTS
Connect to keyboard and mouse
REMOTE SWITCH
Toggles between PCs

8D-Link KVM-222 User Manual
KVM Installation
1. Please insert the installation CD-ROM into your
computers optical drive.
2. When the USB KVM setup Wizard appears, click Next.
3. Please follow the installation steps on the screen.
4. Click Finish to complete the installation and launch the
KVM software.
5. When the installation is completed, a green sphere
icon will appear in the taskbar area indicating the ready
status of the connected computer.
Task bar area:
Windows Installation

9D-Link KVM-222 User Manual
KVM Installation
1. Please insert the installation CD-ROM into your
computers optical drive and click USB KVM.pkg.dmg.
2. Please follow the installation steps on the screen.
3. Click Close to complete the installation and launch to
the KVM software.
4. When the installation is completed, a green sphere
icon will appear in the doc area indicating the ready
status of the connected computer.
Doc Area:
MAC Installation

10D-Link KVM-222 User Manual
KVM OperationKVM Operation
Software Settings
Right-click on the green taskbar icon and select Setting.
The following options are available:
a. KVM Switch: This hotkey will switch between PCs but maintain the audio feed
of the original computer.
b. Audio Switch: This hotkey will switch the audio of the other PC, but maintain
control of the original computer.
c. All Switch: This hotkey will switch between PCs, including audio.
You may choose a number for each hotkey. Please choose different numbers for
each setting.
Remote Control Switching
Push the remote control button to switch between computers.
The green and orange LEDs indicate the selected PC.
Hot key Switching
Press the Scroll Lock key two times to switch between PCs, including audio.
Press the Caps Lock key two times to switch between PCs but maintain the audio feed of the original computer.
Software Switching
a. Left-click on the taskbar icon to switch between PCs.
b. You may also use a specied keyboard hotkey to switch between PCs. See the instructions below.
Accessing the KVM - Windows

11D-Link KVM-222 User Manual
KVM Operation
Remote Control Switching
Push the remote control button to switch between computers.
The green and orange LEDs indicate the selected PC.
Software Switching
a. Click on the taskbar icon to switch between PCs.
b. You may also use a specied keyboard hotkey to switch between PCs.
See the instructions below.
Software Settings
Click and hold on the green taskbar icon for 3 seconds and select Setting.
The following options are available:
a. KVM Switch: This hotkey will switch between PCs but maintain the
audio feed of the original computer.
b. Audio Switch: This hotkey will switch the audio of the other PC, but
maintain control of the original computer.
c. All Switch: This hotkey will switch between PCs, including audio.
You may choose a number for each hotkey. Please choose different
numbers for each setting.
Accessing the KVM - MAC

12D-Link KVM-222 User Manual
KVM Operation
Accessing the KVM - Linux
Remote Control Switching
Push the remote control button to switch between computers.
The green and orange LEDs indicate the selected PC.

13D-Link KVM-222 User Manual
TroubleshootingTroubleshooting
Troubleshooting
When turning the computer on, the keyboard is not detected, or a keyboard / mouse error message is
displayed.
If the computer's BIOS does not support USB boot-up, the system may be unable to detect the mouse and keyboard
during startup. Please ensure that your PC BIOS supports USB boot-up, and upgrade your PC's rmware if
necessary.
The computer's BIOS is correctly congured but the computer is still unable to detect the mouse and
keyboard.
Be sure to directly connect the USB KVM switch to USB port on the PC's motherboard rather than through a port on
a PCI card, Card Bus, or USB Hub.
When switching to PC2, the computer still displays PC1.
The KVM switch may not function correctly while a computer is powered off or still booting up. Ensure that the
second PC is powered on and use the hot key or remote control button to switch between computers.
How do I set a hot key in Mac 10.6?
Please CTRL + click or right-click on the green taskbar icon and click on Setting to open the settings menu to set a
hotkey.

14D-Link KVM-222 User Manual
Appendix A - Technical Specications
Technical Specications
Appendix A - Technical Specications
Ports
2 x PC Port
2 x USB Port
Cable Length
KVM Cable - 1.8 m
Port Selection
Remote Control Button
Hot key commands
AP Selection
Cable Connection (PC1 & PC2)
PC:
USB Type A Male
Monitor:
HDB - 15 Male
Audio:
3.5 mm Mini-Phone Stereo Jack Male (green)
KVM Connector
Keyboard - 1 x USB Type A Female
Mouse - 1 x USB Type A Female
Monitor - 1 x HDB-15 Female (Blue)
Audio - 1 x 3.5 mm Mini-Phone Stereo Jack
Female (green)
Remote control - 1 x 2.5 mm 4 Pin Phone Jack
(Female)
Operating Voltage - 5 V DC
Resolution
2048 x 1536 (QXGA)
1920 x 1440 (WUXGA)
System Requirements
Windows 2000 / XP / Vista / 7
Linux
Mac OS (10.3 and higher)
Weight
193 g
Dimensions (L x W x H)
78 x 56 x 21.5 mm
