D-Link DGS-1100-05PDV2 User manual

DGS-1100-05V2/05PDV2/08V2/08PV2
Manual
SMART MANAGED SWITCH
Ver. 1.00

Table of Contents D-Link Smart Managed Switch User Manual
i
i
Table of Contents
Table of Contents ............................................................................................................................................. i
About This Guide............................................................................................................................................. 1
Terms/Usage.................................................................................................................................................. 1
Copyright and Trademarks ............................................................................................................................ 1
1 Product Introduction ................................................................................................................................... 2
DGS-1100-05V2............................................................................................................................................. 2
Front Panel ................................................................................................................................................. 2
Rear Panel.................................................................................................................................................. 3
DGS-1100-05PDV2........................................................................................................................................ 3
Front Panel ................................................................................................................................................. 3
Rear Panel.................................................................................................................................................. 4
DGS-1100-08V2............................................................................................................................................. 4
Front Panel ................................................................................................................................................. 4
Rear Panel.................................................................................................................................................. 4
DGS-1100-08PV2 .......................................................................................................................................... 5
Front Panel ................................................................................................................................................. 5
Rear Panel.................................................................................................................................................. 6
LED Indicators................................................................................................................................................ 6
2 Hardware Installation .................................................................................................................................. 8
Step 1: Unpacking.......................................................................................................................................... 8
Step 2: Switch Installation.............................................................................................................................. 8
Desktop or Shelf Installation....................................................................................................................... 8
Wall-mount ................................................................................................................................................. 8
3 Getting Started........................................................................................................................................... 10
Management Options................................................................................................................................... 10
Using the Web-based Management Interface ............................................................................................. 10
Connecting to the Switch.......................................................................................................................... 10
Accessing the Web-based Management Interface .................................................................................. 10
Web-based Management............................................................................................................................. 11
D-Link Network Assistant (DNA).................................................................................................................. 11
4 Configuration ............................................................................................................................................. 12
Web-based Management............................................................................................................................. 12
Tool Bar > Save Menu ................................................................................................................................. 13
Save Configuration................................................................................................................................... 13
Tool Bar > Tool Menu .................................................................................................................................. 13
Reboot System ......................................................................................................................................... 13
Reset ........................................................................................................................................................ 13
Firmware Backup and Upgrade................................................................................................................ 13
Configuration Backup and Restore .......................................................................................................... 14
Tool Bar > Online Help................................................................................................................................. 14
Function Tree ............................................................................................................................................... 14
Device Information.................................................................................................................................... 15
System > System Information Settings > System Information................................................................. 15
System > System Information Settings > IPv4 Interface.......................................................................... 16
System > Port configuration > Port Settings ............................................................................................ 16
System > Port Configuration > Jumbo Frame.......................................................................................... 17
System > PoE > PoE System (DGS-1100-05PDV2/08PV2 only)............................................................ 17

Table of Contents D-Link Smart Managed Switch User Manual
i
ii i
System > PoE > PoE Configuration (DGS-1100-05PDV2/08PV2 only) .................................................. 18
System > PoE > PD Alive (DGS-1100-05PDV2/08PV2 only).................................................................. 20
Management > Password Access Control ............................................................................................... 20
Management > SNMP > SNMP Global Settings...................................................................................... 21
Management > SNMP > SNMP Community Table Settings.................................................................... 22
Management > SNMP > SNMP Host Settings......................................................................................... 22
Management > D-Link Discovery Protocol............................................................................................... 23
L2 Features > FDB > Static FDB > Unicast Static FDB ........................................................................... 23
L2 Features > FDB > Static FDB > Multicast Static FDB......................................................................... 24
L2 Features > FDB > MAC Address Table Settings ................................................................................ 24
L2 Features > FDB > MAC Address Table .............................................................................................. 25
L2 Features > VLAN > 802.1Q VLAN ...................................................................................................... 25
L2 Features > VLAN > Port-Based VLAN ................................................................................................ 26
L2 Features > VLAN > Management VLAN ............................................................................................. 27
L2 Features > VLAN > Asymmetric VLAN ............................................................................................... 27
L2 Features > VLAN > Surveillance VLAN .............................................................................................. 28
L2 Features > VLAN > Voice VLAN ......................................................................................................... 29
L2 Features > Spanning Tree > STP Global Settings.............................................................................. 30
L2 Features > Spanning Tree > STP Port Settings.................................................................................. 31
L2 Features > Loopback Detection .......................................................................................................... 32
L2 Features > Link Aggregation ............................................................................................................... 33
L2 Features > L2 Multicast Control > IGMP Snooping > IGMP Snooping Settings................................. 33
L2 Features > L2 Multicast Control > IGMP Snooping > IGMP Snooping Group Settings...................... 34
QoS > 802.1p/DSCP Default Priority ....................................................................................................... 34
QoS > Port Rate Limiting.......................................................................................................................... 35
Security > Traffic Segmentation ............................................................................................................... 36
Security > Storm Control .......................................................................................................................... 36
Security > Port Security............................................................................................................................ 37
OAM > Cable Diagnostics ........................................................................................................................ 37
Monitoring > Statistics > Port Counters.................................................................................................... 38
Monitoring > Mirroring Settings ................................................................................................................ 38
Green > EEE ............................................................................................................................................ 39
Ethernet Technology..................................................................................................................................... 40
Gigabit Ethernet Technology ....................................................................................................................... 40
Fast Ethernet Technology............................................................................................................................ 40
Switching Technology .................................................................................................................................. 40
PoE Passthrough ......................................................................................................................................... 41
Technical Specifications............................................................................................................................... 42
Regulatory Statements.................................................................................................................................. 44

About This Guide D-Link Smart Managed Switch User Manual
1
About This Guide
This guide provides step-by-step instructions on how install the D-Link DGS-1100-
05V2/05PDV2/08V2/08PV2 Smart Managed Switches, how to use the Web Utility, and how to perform web-
based management functions.
Note:
The model you have purchased may
appear slightly different from the illustrations
shown in the document. Refer to the Product
Introduction and Technical Specification sections
for detailed information about your switch, its
components, network connections, and technical
specifications.
This guide is mainly divided into four parts:
1. Hardware Installation: Step-by-step hardware installation procedures.
2. Getting Started: A startup guide for basic switch installation and settings.
3. Web Configuration: Information about the function descriptions and configuration settings via Web.
Terms/Usage
In this guide, the term “Switch” (first letter capitalized) refers to the Smart Managed Switch, and “switch” (first
letter lower case) refers to other Ethernet switches. Some technologies refer to terms “switch”, “bridge” and
“switching hubs” interchangeably, and both are commonly accepted for Ethernet switches.
A NOTE
indicates important information that
helps a better use of the device.
A CAUTION indicates potential property damage
or personal injury.
Copyright and Trademarks
Information in this document is subjected to change without notice.
© 2020 D-Link Corporation. All rights reserved.
Reproduction in any manner whatsoever without the written permission of D-Link Corporation is strictly
forbidden.
Trademarks used in this text: D-Link and the D-LINK logo are trademarks of D-Link Corporation; Microsoft
and Windows are registered trademarks of Microsoft Corporation.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the
marks and names or their products. D-Link Corporation disclaims any proprietary interest in trademarks and
trade names other than its own.

1Product Introduction D-Link Smart Managed Switch User Manual
2
1 Product Introduction
Thank you and congratulations on the purchase of your new D-Link Smart Managed Switch.
D-Link's next generation Smart Managed switch series blends plug-and-play simplicity with exceptional
value and reliability for small and medium-sized business (SMB) networking. All models are housed in a
robust metal case with easy-to-view front panel diagnostic LEDs.
Flexible Port Configurations. The DGS-1100 series is the new generation of Smart Managed Switches,
featuring 5 to 8 10/100/1000 Mbps.
D-Link Green Technology. The DGS-1100 Series features D-Link Green Technology which helps
conserve power without sacrificing operational performance. Using IEEE 802.3az Energy Efficient Ethernet
(EEE), the DGS-1100 Series saves power by automatically putting inactive ports into a sleep mode.
Extensive Layer 2 Features. Designed as comprehensive L2 devices, these switches support a variety of
functions such as FDB, VLAN, Spanning Tree, and Loopback Detection to enhance performance and
network resilience.
Traffic Segmentation and QoS.The switches support 802.1Q VLAN standard tagging to enhance network
security and performance. The switches also support 802.1p priority queues, enabling users to run
bandwidth-sensitive applications such as streaming multimedia by prioritizing that traffic in network. The
Surveillance VLAN will place the video traffic from pre-defined IP surveillance devices to an assigned VLAN
with higher priority, so it can be separated from normal data traffic.
Network Security. Storm Control can help to keep the network from being overwhelmed by abnormal
traffic. Meanwhile, Port Security provides administrators with an additional layer of security to prevent
unauthorized users from accessing the network.
Versatile Management. The DGS-1100-05V2/05PDV2/08V2/08PV2 feature an intuitive, web-based
management interface that allows administrators to remotely control their network down to the port level.
The D-Link Network Assistant (DNA) easily allows administrators to discover multiple D-Link Smart
Managed Switches within the same L2 network segment and display them on-screen for instant access.
With this utility, users do not need to change the IP address of their PC. This allows for simultaneous
configuration and basic setup of all discovered devices, including password changes and firmware
upgrades.
DGS-1100-05V2
5-Port 10/100/1000Mbps Smart Managed Switch.
Front Panel
Figure 1.1 – DGS-1100-05V2 Front Panel
Power LED: The Power LED lights up when the Switch is connected to a power source.
Link/Act/Speed LED (Ports 1-5): 10/100/1000 Mbps ports to connect Ethernet devices to the switch.
CAUTION: The equipment power supply cord shall be connected
to a socket-outlet with earthing connection.
Le cordon d'alimentation de l'équipement doit être branché
sur une prise de courant dotée d'une connexion à la terre.

1 Product Introduction D-Link Smart Managed Switch User Manual
3
3
Rear Panel
Figure 1.2 – DGS-1100-05V2 Rear Panel
Power: Input for a 5V/1A AC adapter.
Reset: Press the Reset button for 1 to 5 seconds to reboot the Switch. Press the Reset button for 6 to10
seconds to reset the Switch back to the default settings. The LED will light up solid amber for 2 seconds.
When pressing the Reset button for longer than 10 seconds, the device will enter loader mode and the LED
will light up solid green for 2 seconds. If the device cannot reboot, it will automatically enter loader mode.
Alternatively, you can press Reset to power up the device and enter loader mode.
Kensington Lock: This is used to attach a physical Kensington security lock.
GND: This is used to connect the Switch to ground.
DGS-1100-05PDV2
2-Port 10/100/1000Mbps PoE and 3-Port 10/100/1000Mbps with 1 PD port Smart Managed Switch.
Front Panel
Figure 1.3 – DGS-1100-05PDV2 Front Panel
Power LED: The Power LED lights up when the Switch is connected to a power source. If the Power LED is
Blinking, PoE Pass Through is Off.
Link/Act/Speed LED (Ports 1-5):
Flashing: Indicates a network link through the corresponding port.
Blinking: Indicates that the Switch is either sending or receiving data to the port.
Green: Indicates that the port is running at 1000M.
Amber: Indicates that the port is running at 10/100M.
Light off: No link.
PoE PSE LED (Port 1-2):
Solid Green: PD device insert and power feeding.
Solid Amber: PD device insert but failure occurs.
Light off: No PD device insert.
PoE PD (Port 5):
Solid Green: Receiving power from PSE per 802.3at.
Solid Amber: Receiving power from PSE per PSE.
Light off: No link.
Reset: Press the Reset button for 1 to 5 seconds to reboot the Switch. Press the Reset button for 6 to10
seconds to reset the Switch back to the default settings. The LED will light up solid amber for 2 seconds.
When pressing the Reset button for longer than 10 seconds, the device will enter loader mode and the LED
will light up solid green for 2 seconds. If the device cannot reboot, it will automatically enter loader mode.
Alternatively, you can press Reset to power up the device and enter loader mode.
CAUTION: This equipment can
be connected only to PoE
networks without routing to the outside plant.

1Product Introduction D-Link Smart Managed Switch User Manual
4
L’équipement est conçu pour une installation dans un
bâtiment et ne doit pas être connecté à des réseaux exposés
(installations extérieures), notamment des environnements de
campus, et l’ITE doit être connecté uniquement à des réseaux
PoE sans acheminement vers une installation extérieure." ou
équivalent.
CAUTION: This unit is supplied by POE through an UL Listed
ITE.
Cet appareil est fourni par POE via un ITE répertorié UL.
Rear Panel
Figure 1.4 – DGS-1100-05PDV2 Rear Panel
Power: Use RJ45 to connect the PD port (port 5) and Power over Ethernet Adapter Kit.
Kensington Lock: This is used to attach a physical Kensington security lock.
GND: This is used to connect the Switch to ground.
NOTE: The power budget is 18 Watts with 802.3at and 8 Watts with
802.3af for DGS-1100-05PDV2.
DGS-1100-08V2
8-Port 10/100/1000Mbps Smart Managed Switch.
Front Panel
Figure 1.5 – DGS-1100-08V2 Front Panel
Power LED: The Power LED lights up when the Switch is connected to a power source.
Link/Act/Speed LED (Ports 1-8): 10/100/1000 Mbps ports to connect Ethernet devices to the switch.
CAUTION: The equipment power supply cord shall be connected
to a socket-outlet with earthing connection.
Le cordon d'alimentation de l'équipement doit être branché
sur une prise de courant dotée d'une connexion à la terre.
Rear Panel
Figure 1.6 – DGS-1100-08V2 Rear Panel

1 Product Introduction D-Link Smart Managed Switch User Manual
5
5
Power: Input for a 5V/1A AC adapter.
Reset: Press the Reset button for 1 to 5 seconds to reboot the Switch. Press the Reset button for 6 to10
seconds to reset the Switch back to the default settings. The LED will light up solid amber for 2 seconds.
When pressing the Reset button for longer than 10 seconds, the device will enter loader mode and the LED
will light up solid green for 2 seconds. If the device cannot reboot, it will automatically enter loader mode.
Alternatively, you can press Reset to power up the device and enter loader mode.
Kensington Lock: This is used to attach a physical Kensington security lock.
GND: This is used to connect the Switch to ground.
DGS-1100-08PV2
8-Port 10/100/1000Mbps PoE Smart Managed Switch.
Front Panel
Figure 1.7 – DGS-1100-08PV2 Front Panel
Power LED: The Power LED lights up when the Switch is connected to a power source.
Reset: Press the Reset button for 1 to 5 seconds to reboot the Switch. Press the Reset button for 6 to10
seconds to reset the Switch back to the default settings. The LED will light up solid amber for 2 seconds.
When pressing the Reset button for longer than 10 seconds, the device will enter loader mode and the LED
will light up solid green for 2 seconds. If the device cannot reboot, it will automatically enter loader mode.
Alternatively, you can press Reset to power up the device and enter loader mode.
Link/Act/Speed LED (Ports 1-8):
Flashing: Indicates a network link through the corresponding port.
Blinking: Indicates that the Switch is either sending or receiving data to the port.
Green: Indicates that the port is running at 1000M.
Amber: Indicates that the port is running at 10/100M.
Light off: No link.
PoE MAX. LED:
Light up: Indicates the power output to PDs is over 57W. No additional PDs can be powered for
safety consideration.
Blinking: Indicates if the user unplugged certain PDs and made the PoE power budget left over 7W,
the PoE MAX LED will blink 5 seconds.
Light off: Indicates the power budget is using less than 57W.
PoE LED (Ports 1-8):
Green: Indicates the PoE powered device (PD) is connected and the port supplies power
successfully.
Red: The PoE port has failed, possibly due to:
1. PoE total power budget shortage.
2. Over current: Exceeds the power current of powered device's classification.
3. Short circuit: Short circuit has been performed on a powered device.
Light off: Indicates no Powered Device (PD) connected.
PoE Mode LED (Port 1-8):
Solid Green: PD device insert and power feeding.
Solid Amber: PD device insert but failure occurs.
Light off: No PD device insert.

1Product Introduction D-Link Smart Managed Switch User Manual
6
CAUTION: The equipment power supply cord shall be connected
to a socket-outlet with earthing connection.
Le cordon d'alimentation de l'équipement doit être branché
sur une prise de courant dotée d'une connexion à la terre.
Rear Panel
Figure 1.8 – DGS-1100-08PV2 Rear Panel
Power: Input for a 54V/1.574A AC adapter.
Kensington Lock: This is used to attach a physical Kensington security lock.
GND: This is used to connect the Switch to ground.
NOTE: The power budget is 64 Watts for DGS-1100-08P.
LED Indicators
The Switches feature LED indicators for Power and Link/Act for each port. The following shows the LED
indicators for the DGS-1100-05V2/05PDV2/08V2/08PV2 switches along with an explanation of each
indicator.
Figure 1.9 –LED Indicators on DGS-1100 series
Location Indicator LED Color Status Description
Per Device
Power Green
Solid Light The device is powered on.
Blinking
PoE Pass Through Off (DGS-1100-
05PDV2 only)
Light off The device is powered off.
PoE Max.
(Only DGS-1100-
08PV2)
Red
Solid Light
When the power output to PDs is over
57W. No additional PDs can be
powered for safety consideration.
Blinking
If the user unplugged certain PDs and
made the PoE power budget left over
7W, the PoE MAX LED will blink 5
seconds.
Light off When the power budget is using less
the 57W.
LED Per
10/100/1000
Mbps Port
Link/Act/Speed Green/Amber
Solid Green Indicates there is a 1000 Mbps
connection on this port.
Blinking
Green
Indicates data is being processed on
this port at 1000 Mbps.

1 Product Introduction D-Link Smart Managed Switch User Manual
7
7
Solid Amber
Indicates there is a 10/100 Mbps
connection on this port.
Blinking
Amber
Indicates data is being processed on
this port at 10/100 Mbps.
Light off
Indicates there is no active link on this
port.
LED Per PoE Port PoE Status Green/Amber
Solid Green PD device insert and power feeding.
Solid Amber
PD device insert but failure occurs.
(PSE can’
t provide power to PD due to
PD error or power budget is not
enough.)
Light off No PD device inserts.
LED Per PD Port
(DGS-1100-
05PDV2 only)
PD Status Green/Amber
Solid Green Receiving power from PSE per 802.3at
Solid Amber Receiving power from PSE per PSE.
Light off No link.

2Hardware Installation D-Link Smart Managed Switch User Manual
8
2 Hardware Installation
This chapter provides unpacking and installation information for your D-Link DGS-1100-
05V2/05PDV2/08V2/08PV2 Smart Managed Switch.
Step 1: Unpacking
Open the shipping carton and carefully unpack its contents. Please consult the packing list below to make
sure all items are present and undamaged.
One DGS-1100-05V2/05PDV2/08V2/08PV2 Smart Managed Switch
One AC external power adapter
Four rubber feet
Wall-mount kit
Quick Installation Guide
CD (User manual)
If any item is found missing or damaged, please contact the local reseller for replacement.
Step 2: Switch Installation
For safe switch installation and operation, it is recommended to you:
Visually inspect the power cord to see that it is secured fully to the AC power connector.
Make sure that there is proper heat dissipation and adequate ventilation around the switch.
Do not place heavy objects on the switch.
Desktop or Shelf Installation
The DGS-1100 series switches come with a strip of four adhesive rubber pads that can be placed on the
bottom of the device to prevent the device from damaging the desktop or shelf it is places on. To attach the
rubber pads, simply remove them from the adhesive strip and stick one pad on each corner on the bottom
panel of the Switch.
Figure 2.1 – Attach the adhesive rubber pads to the bottom
Wall-mount
The Switch can be mounted on a wall. Two mounting slots are provided on the bottom of the switch for this
purpose.
Please refer to the instructions below on how to complete the wall-mounting process.
Mounting on a cement wall
Step 1: Drill two holes that align with the keyholes on the back of the Switch in the wall where you want to
mount the device, and place the two indluded nylon screw anchors into the drilled holes.
Step 2: Drive the included screws into the nylon screw anchors.
Step 3: Hook the mounting keyholes on the back of the Switch onto the screws to secure the device to
the wall.
Mounting on a wood wall
Step 1: Drive the included screws into a wood wall.

2 Hardware Installation D-Link Smart Managed Switch User Manual
9
9
Step 2. Hook the mounting keyholes on the back of the Switch onto the screws to secure the device to
the wall.
Figure 2.2 – Wall mount installation
Metal screw (M7 type; Length 16 mm, Number of screws *2) for DGS-1100-05V2/05PDV2/08V2/08PV2
Vis métallique (type M7 ; longueur 16 mm, nombre de vis *2) pour DGS-1100-05V2/05PDV2/08V2/08PV2

3Getting Started D-Link Smart Managed Switch User Manual
10
3 Getting Started
This chapter introduces the management interface of D-Link Smart Managed Switch.
Management Options
The D-Link Smart Managed Switch can be managed through any port on the device by using the web-based
management interface, or the D-Link Network Assistant (DNA).
Each switch must be assigned its own IP address, which is used for communication with the web-based
management interface or a SNMP network manager. The PC should have an IP address in the same range
as the Switch. Each Switch allows up to four users to access the web-based management interface
concurrently.
However, if you want to manage multiple D-Link Smart Managed Switches, the D-Link Network Assistant
(DNA) is a more convenient choice. By using the D-Link Network Assistant (DNA), you do not need to
change the IP address of your PC, making it easier to simultaneously initialize multiple D-Link Managed
Switches.
Please refer to the following installation instructions for the Web interface and the D-Link Network Assistant
(DNA).
Using the Web-based Management Interface
After successfully installing the Switch, you can configure and monitor the Switch through the web-based
management tool using any compatible web browser such as Internet Explorer, Google Chrome, Firefox,
Opera, or Safari.
Connecting to the Switch
The access the web interface you will need the following equipment:
1. A PC with a RJ45 Ethernet port.
2. A standard Ethernet cable
Connect on end of the Ethernet cable to any of the ports on the front panel of the Switch and connect the
other end of Ethernet cable to the Ethernet port on the PC.
Figure 3.1 – Connected Ethernet cable
Accessing the Web-based Management Interface
In order to access the management interface, the PC must have an IP address in the same subnet as the
Switch. For example, if the Switch has an IP address of 10.90.90.90, the PC should have an IP address of
10.x.y.z (where x/y is a number between 0 ~ 254 and z is a number between 1 ~ 254), and a subnet mask of
255.0.0.0. To launch the web interface, simply open any compatible web browser and enter 10.90.90.90 (the
factory-default IP address) in the address bar. Then press <Enter>.

3 Getting Started D-Link Smart Managed Switch User Manual
1
11 1
Figure 3.2 –Enter the IP address 10.90.90.90 in the web browser
NOTE: The Switch’s factory default IP address is
10.90.90.90 with a subnet mask of 255.0.0.0 and
a default gateway of 0.0.0.0.
This will automatically load the web configuration in your web browser.
When prompted to log in, enter the default password admin and press ok to continue.
Figure 3.3 – Logon Dialog Box
Web-based Management
Please refer to Chapter 4 Configuration for detailed instructions.
D-Link Network Assistant (DNA)
D-Link Network Assistant (DNA) is a program that is used to discover switches which are in the same Layer
2 network segment as your PC. You can download the DNA App from the Chrome web store and install it in
a Chrome web browser.
1. Go to the Chrome web store at: https://chrome.google.com/webstore, and search the store for
Network Assistant.
Figure 3.4 – D-LINK Network Assistant
2. Click ‘ADD TO CHROME’ button on the right hand side of the search results.
3. Click ‘Add app’ button in the pop-up window to install the D-Link Network Assistant in Chrome.
4. When the installation process has finished:
(Option 1) Click the ‘LAUNCH APP’ button in the upper-right corner of the window to start DNA.
(Option 2) Click the ‘Apps’ icon in the upper-left corner of the Chrome browser and click the DNA icon
to start the app.

4Configuration D-Link Smart Managed Switch User Manual
12
4 Configuration
The features and functions of the D-Link Smart Managed Switch can be configured through the web-based
management interface.
Web-based Management
After a successful login you will see the screen below:
Figure 4.1 – Web-based Management
The three main areas are the Tool Bar on top, the Function Tree on the left, and the Main Configuration
Screen.
The Tool Bar provides a quick and convenient way for accessing essential functions such as firmware
upgrades and basic settings.
Clicking on a section or subsection in the function tree will display all the settings of that section in the main
configuration screen. The main configuration screen will show the current status of your Switch by clicking
the model name on top of the function tree.
In the upper-right corner of the screen the username and current IP address will be displayed.
Under the username is the Logout button. Click this to end this session.
NOTE:
If you close the web browser without
clicking the Logout button first, then it will be seen
as an abnormal exit and the login session will still
be occupied.
By clicking on the D-Link logo in the upper-left corner of the screen you will be redirected to the local D-Link
website.

4 Configuration D-Link Smart Managed Switch User Manual
1
13 3
Tool Bar > Save Menu
The Save Menu provides Save Configuration and Save Log functions.
Figure 4.2 – Save Menu
Save Configuration
By clicking Apply, the current device configuration will be saved on the device’s flash memory.
Figure 4.3 – Save Configuration
Tool Bar > Tool Menu
The Tool Menu provides basic functions such as Reset, Reset System, Reboot Device, Configuration
Backup and Restore, Firmware Backup and Upgrade.
Figure 4.4 – Tool Menu
Reboot System
This option provides a safe way to reboot the system. Click Yes or No to decide to save the settings does
this really reset to factory default settings or does it just discard the most recent unsaved changes. Click
Reboot to restart the switch.
Figure 4.5 – Tool Menu > Reboot System
Reset
Provide a safe reset option for the Switch. Depending on the chosen reset option, some or all configuration
settings stored in the device’s flash memory will be reset to factory default.
Figure 4.6 – Tool Menu > Reset
Select a suitable reset option and click Apply to make the configurations take effect.
Firmware Backup and Upgrade
This functions allows you to create a backup of the device’s current firmware, or upgrade the firmware using
a compatible firmware file.
Figure 4.7 – Tool Menu > Firmware Backup and Upgrade

4Configuration D-Link Smart Managed Switch User Manual
14
Click Backup to save the firmware to your disk.
Click Upgrade to upgrade the firmware. After clicking, the device will enter boot-loader mode and the
following page will be displayed:
Figure 4.8 – Tool Menu > Firmware Backup and Upgrade - Upgrade
Click Choose File to browse for a compatible firmware file on your hard drive.
Click Upgrade to update the device’s firmware using the selected firmware file.
Click Reboot to cancel the firmware upgrade and reboot the device.
NOTE:Do not disconnect the PC or remove the
power cord from device until the upgrade
completes. The Switch may crash if the firmware
update is interrupted.
Configuration Backup and Restore
Allow the current configuration settings to be saved to a file, and if necessary, you can restore the
configuration settings from this file.
Figure 4.9 – Tool Menu > Configure Backup and Restore
Backup current settings to file: Specify to back up the current settings of the Switch with or without the
password, and click Backup.
Restore saved settings from file: Click Choose File to browse your inventories for a saved backup
settings file. And click Restore to backup settings file you want to restore.
Note: Switch will reboot after restore, and all
current configurations will be overwritten.
Tool Bar > Online Help
The Online Help provides two ways of online support: D-Link Support Site will lead you to the D-Link
website where you can find online resources such as updated firmware images; User Guide can offer an
immediate reference for the feature definition or configuration guide.
Figure 4.10 – Online Help
Function Tree
All configuration options of the switch are accessed through the function menu on the left side of the screen.
Click on the setup item that you want to configure. The following sections provide a more detailed description
of each feature and function.

4 Configuration D-Link Smart Managed Switch User Manual
1
15 5
Figure 4.11 –Function Tree
Device Information
The Device Information provides an overview of the Switch, including essential information such as firmware
and hardware information, and IP address.
Figure 4.12 – Device Information
System > System Information Settings > System Information
The System Information allows the user to configure the basic system information of the Switch. By entering
the system information, the device can more easily be recognized from other Smart Managed devices on the
network.
Figure 4.13 – System > System Information Settings > System Information
The fields that can be configured for System Information are described below:
Item Description
System name Specify the system name of the Switch.

4Configuration D-Link Smart Managed Switch User Manual
16
System Location Specify the system location of the Switch.
System Contact Specify the system contact of the Switch.
Web Session Timeout
(60-36000)
The Web Session Timeout controls the idle time-out period for
security purposes, when there is no
activity in the web
interface within the specified time-out period
. If the current
session times out (expires), the user is required to log into the
web management interface again. Selective range is from 60
to 36000 seconds, and the default setting is 180 seconds.
Table 4.1
Click Apply to make the configurations take effect.
System > System Information Settings > IPv4 Interface
The IPv4 Interface allows the user to configure the IP address and the basic system information of the
Switch.
Figure 4.14 – System > System Information Settings > IPv4 Interface
The fields that can be configured for IP Settings are described below:
Item Description
IP Settings
There are two ways for the Switch to obtain an IP address:
Static and DHCP (Dynamic Host Configuration Protocol).
When using static mode, the IP Address, Mask, Gateway and
DHCP Retry Time can be manually configured. When using
DHCP mode, the Switch will first look for a DHCP server to
provide it with an IP address (including network mask and
default gateway) before using the default or previously entered
settings.
IP Address
Specify the IPv4 address. By default, the IP address is
10.90.90.90
Mask Specify the subnet mask of IP address. By default, the subnet
mask is 255.0.0.0
Gateway Specify the gateway of IP address. By default, the gateway is
0.0.0.0
DHCP Retry Time (5-
120)
Specify the
number of attempts to assign an IP address
through a DHCP server. Selective range is from 5to 120 times,
and the default setting is 7times.
Table 4.2
Click Apply to make the configurations take effect.
System > Port configuration > Port Settings
In the Port Setting page, the status of all ports can be monitored and configured.

4 Configuration D-Link Smart Managed Switch User Manual
1
17 7
Figure 4.15 – System > Port Configuration > Port Settings
The fields that can be configured for Port Settings are described below:
Item Description
From Port / To Port Select a range of ports to be configured.
State Enable or disable the specified ports.
Speed
Copper connections can operate in Forced Mode settings 1000
Mbps (full-duplex), 100 Mbps (full/half-duple
x), 10 Mbps
(full/half-duplex), Auto, or Disabled. The default setting for all
ports is Auto.
Flow control
You can enable this function to mitigate traffic congestion.
Ports configured for full-duplex use 802.3x flow control, half-
duplex ports use backpressure flow control. The default setting
is Disabled.
Description Specify a description for the chosen ports
Capability Advertised When the Speed is set to Auto
, these capabilities are
advertised during auto-negotiation.
Table 4.3
Click Apply to make the configurations take effect.
Click Refresh button to update the port status information.
NOTE:
Be sure to adjust port speed settings
appropriately after changing the connected cable
media types.
System > Port Configuration > Jumbo Frame
D-Link Smart Managed Switches support jumbo frames (frames larger than the Ethernet frame size of 1536
bytes) of up to 9216 bytes (tagged). This function is disabled by default. Select Enabled then click Apply to
turn on the jumbo frame support.
Figure 4.16 – System > Port Configuration > Jumbo Frame
System > PoE > PoE System (DGS-1100-05PDV2/08PV2 only)
The PoE System page will display the PoE status including System Budget Power, Support Total Power,
Remainder Power, and the ratio of system power supply.
