DAP-3220
802.11b/g Access Point
Command Line Interface Reference Manual
First Edition (January 2006)
RECYCLABLE

Table of Contents
Using the CLI ....................................................................................................................................................................................................................................................... 1
Command Syntax ................................................................................................................................................................................................................................................. 5
Utility Commands ................................................................................................................................................................................................................................................ 7
Ethernet Commands ............................................................................................................................................................................................................................................ 8
Wireless Commands ............................................................................................................................................................................................................................................. 9
Multi SSID and VLAN Commands ................................................................................................................................................................................................................... 14
Access Control List Commands ......................................................................................................................................................................................................................... 17
Radius & Accounting Server Commands .......................................................................................................................................................................................................... 18
DHCP Server Commands .................................................................................................................................................................................................................................. 20
Rogue AP Detection Commands ........................................................................................................................................................................................................................ 21
Snmp Commands................................................................................................................................................................................................................................................ 22
Trap Commands ................................................................................................................................................................................................................................................. 24
Time Display & SNTP Commands .................................................................................................................................................................................................................... 25
Telnet & SSH Commands .................................................................................................................................................................................................................................. 26
System Log Command ....................................................................................................................................................................................................................................... 28
SMTP Commands ............................................................................................................................................................................................................................................... 29
First Time Configuration Examples ................................................................................................................................................................................................................. 30

802.11 b/g Access Point Command Line Interface Manual
1
1
USING THE CLI
The DAP-3220 can be accessed by Telnet. Using Microsoft Windows Operation system as example, open the Command Prompt on the computer that will be used for
configuring and managing the AP and enter telnet and IP address of DAP-3220 in the first line. Using the default IP address as example, enter telnet 192.168.0.50 to
cause the following screen to open:
Press Enter in the screen above. The following screen opens:

802.11 b/g Access Point Command Line Interface Manual
2
Type “admin” for the D-Link Access Point login username in the screen above and press Enter. The following screen opens:
Press Enter as there is no initial password.
The following screen opens to indicates you have successfully logged into the DAP-3220.
Commands are entered at the command prompt, D-Link Access Point wlan1 – >

802.11 b/g Access Point Command Line Interface Manual
3
There are a number of helpful features included in the CLI. Entering the “?” command and then pressing Enter will display a list of all of the top-level commands. The same
information can also be displayed by entering “help”.
Press Enter to see a list of all the available commands. Alternatively, you may enter “help” and the press Enter.

802.11 b/g Access Point Command Line Interface Manual
4
When you enter a command without all of its required parameters, the CLI will prompt you with a list of possible completions. For example, if “tftp” was entered, the
following screen opens:
This screen displays all the possible command completions for “tftp”
When you enter a command without a variable or value that needs to be specified, the CLI will prompt you with further information about what is needed to complete the
command. For example, if “snmp authtrap” was entered, the following screen opens:
The missing value for the “snmp authtrap”command, “enable/disable,” is displayed in the screen above.

802.11 b/g Access Point Command Line Interface Manual
5
2
COMMAND SYNTAX
The following symbols are used to describe how command entries are made and values and arguments are specified in this manual. The online help contained in the CLI
and available through the console interface uses the same syntax.
Note: All commands are case-insensitive.
<angle brackets>
Purpose Encloses a variable or value that must be specified.
Syntax set login <username>
Description In the above syntax example, you must specify the username.
Do not type the angle brackets.
Example Command set login accounting
[square brackets]
Purpose Encloses a required value or set of required arguments. One
value or argument can be specified.
Syntax get multi-authentication [index]
Description In the above syntax example, you must specify an index to be
created. Do not type the square brackets.
Example Command get multi-authentication 2

802.11 b/g Access Point Command Line Interface Manual
6
: colon
Purpose Separates two or more mutually exclusive items in a list, one of
which must be entered.
Syntax set antenna <1:2:best>
Description In the above syntax example, you must specify either 1,2 or
best. Do not type the colon.
Example Command set antenna best

802.11 b/g Access Point Command Line Interface Manual
7
3
UTILITY COMMANDS
Help Command: Function Syntax
help Display CLI Command List help or ?
Ping Command: Function Syntax
ping Ping ping <xxx.xxx.xxx.xxx>
Restart and Exit Commands:
Function Syntax
set factorydefault Restore to Default Factory Settings set factorydefault
reboot Reboot Access Point. It is necessary to reboot the AP after making
configuration changes for those changes to take effect. reboot
quit Logoff quit
Version Display Command: Function Syntax
version Displays the currently loaded firmware version version
System Status Command: Function Syntax
get cpuloadlimit Get CPU load limit get cpuloadlimit
get cpuloadperiod Get CPU load period get cpuloadperiod
set cpuloadlimit Set CPU Load Limit set cpuloadlimit [0-100]
set cpuloadperiod Set CPU Load Period set cpuloadperiod [0-100]
Addminstration Command: Function Syntax
get uptime Display UpTime get uptime
get login Display Login User Name get login
set login Modify Login User Name set login <username>
set password Modify Password set password
get systemname Display Access Point System Name get systemname
set systemname Specify Access Point System Name set systemname <name>
get ifping Display Ping control status get ifping
set ifping Set ping Allowed to enable or disable set ifping
get wlanManage Display manage AP with WLAN Mode get wlanManage
set wlanManage Set manage AP with WLAN Mode set wlanManage [disable: enable]

802.11 b/g Access Point Command Line Interface Manual
8
4
ETHERNET COMMANDS
Get Command: Function Syntax
get hostipaddr Display Host IP Address get hostipaddr
get ipaddr Display IP Address get ipaddr
get ipmask Display IP Network/Subnet Mask get ipmask
get gateway Display Gateway IP Address get gateway
get lcp Display Link Integrate state get lcp
get lcplink Display Ethernet Link State get lcplink
get dhcpc Display DHCP Client State of enabled or disabled get dhcpc
Set Command: Function Syntax
set ipaddr Set IP Address set ipaddr <xxx.xxx.xxx.xxx>
Explanation: <xxx.xxx.xxx.xxx> is IP address
set ipmask Set IP Network/Subnet Mask set ipmask < xxx.xxx.xxx.xxx>
Explanation: <xxx.xxx.xxx.xxx> is Network mask
set gateway Set Gateway IP Address set gateway <xxx.xxx.xxx.xxx>
Explanation: <xxx.xxx.xxx.xxx> is IP address
set dhcpc Set DHCP Client State of enable or disabled set dhcpc [0:1]
Explanation: 0=disable:1=enable

802.11 b/g Access Point Command Line Interface Manual
9
5
WIRELESS COMMANDS
Fundamental
Config Commands: Function Syntax
config wlan Select WLAN Adapter to configure. DWL-3220AP only WLAN 1 is
available for configuration. This command is not necessary. config wlan [0:1]
Find Commands:
find bss Perform Site Survey, Wireless service will be disrupted find bss
find channel Channel spanning to select the Preferred Channel find channel
find all Perform Site Survey including Super G and Turbo, Wireless service will
be disrupted find all
IGMP Command: Function Syntax
igmp state Display IGMP snooping state igmp state
igmp enable Enable IGMP snooping igmp enable
igmp disable Disable IGMP snooping igmp disable
igmp dump Display IGMP MDB dump list igmp dump
igmp getrssi Display IGMP snooping rssi threshold igmp getrssi
igmp setrssi Set IGMP snooping rssi threshold igmp setrssi <0 - +>
igmp getportagingtime Display IGMP snooping port aging time igmp getportagingtime
igmp setportagingtime Set IGMP snooping port aging time igmp setportagingtime <0 - +>
Get Command: Function Syntax
get apmode Display current AP Mode get apmode
get ssid Display Service Set ID get ssid
get ssidsuppress Display SSID Suppress Mode as enabled or disabled get ssidsuppress
get station Display Client Station Connection Status get station
get wdsap Display WDS Access Point List get wdsap
get remoteAp Display Remote AP's Mac Address get remoteAp
get association Display Association Table that indicates the information of associated
client devices get association
get autochannelselect Display state of Auto Channel Selection feature (enabled, disabled) get autochannelselect
get frequency Display Radio Frequency (MHz) get frequency
get channel Display Radio Frequency (MHz) and Channel Designation get channel

802.11 b/g Access Point Command Line Interface Manual
10
get availablechannel Display available Radio channels get availablechannel
get rate Display current Data Rate selection. Default is best. get rate
get beaconinterval Display Beacon Interval get beaconinterval
get dtim Display Delivery Traffic Indication Message Beacon Rate get dtim
get fragmentthreshold Display Fragment Threshold in bytes get fragmentationthreshold
get rtsthreshold Display RTS/CTS Threshold get rtsthreshold
get power Display Transmit Power Setting: Full, half, quarter, eighth, min get power
get targetPower Display Target Power Setting get targetPower
get controlPower Display Control Power Setting get controlPower
get swPower Display Software Power Setting get swPower
get SuperG Display SuperG Feature Status of enabled or disabled get SuperG
get wlanstate Display Wireless LAN state status (enabled or disabled) get wlanstate
get shortpreamble Display Short Preamble Usage state: enabled or disabled get shortpreamble
get wirelessmode Display Wireless LAN Mode (11b or 11g) get wirelessmode
get 11gonly Display 11g Only Mode operational state of enabled or disabled get 11gonly
get antenna Display Antenna Diversity of 1, 2, or best get antenna
get sta2sta Display wireless STAs to wireless STAs connect state get sta2sta
get eth2sta Display ethernet to wireless STAs connect state get eth2sta
get eth2wlan Display Eth2Wlan Broadcast packet filter state get eth2wlan
get macaddress Display Mac Address get macaddress
get config Display Current AP Configuration Settings get config
get countrycode Display Country Code setting get countrycode
get hardware Display Hardware Revisions of WLAN Components get hardware
get diap Display DIAP State get diap
get aging Display Aging Interval in seconds get aging
get ratecontrol Display supported data rate state get ratecontrol
get supportrate Display supported data rate get supportrate
Set Command: Function Syntax
set apmode Set AP Mode to Normal AP, Point to Point Bridge, Point to Multipoint
Bridge. set apmode [ap:p2p:p2mp:p2pwithoutap: p2mpwithoutap]
set ssid Set Service Set ID set ssid <SSID>
SSID should be less than 33 strings.
set ssidsuppress Set SSID Suppress Mode enable or disable set ssidsuppress [disable: enable]
set autochannelselect Set Auto Channel Selection to enable or disable set autochannelselect [disable:enable]
set frequency Set Radio Frequency (MHz) set frequency <24xx>
set rate Set Data Rate set rate [best:1:2:5.5:6:9:11:12:18:24:36:48:54]

802.11 b/g Access Point Command Line Interface Manual
11
set beaconinterval Modify Beacon Interval 20-1000 set beaconinterval [20-1000]
set dtim Set Delivery Traffic Indication Message Beacon Rate. Default is 1 set dtim <1-255>
set fragmentthreshold Set Fragment Threshold set fragmentationthreshold <xxxx>
set rtsthreshold Set RTS/CTS Threshold in bytes set rtsthreshold <xxxx>
set power Set Transmit Power in predefined increments set power [full:half:quarter:eighth:min]
set SuperG Enable or Disable Super G Features set SuperG [disable: enable]
set wlanstate Select the operational state of wlan: enabled or disabled set wlanstate [disable: enable]
set shortpreamble Set Short Preamble set shortpreamble [disable: enable]
set wirelessmode
Used to select the wireless mode of operation for the AP: 11b, 11g, 108g
set wirelessmode [11b:11g:108g]
set 11gonly Only 802.11g clients will be Allowed to connect to this BSS set 11gonly [disable:enable]
set antenna Set Antenna selection of 1, 2, or best set antenna [1:2:best]
set aging Set Aging Interval set aging <seconds>
set channel Select Radio Channel of Operation set channel [1:2:3:4:5:6:7:8:9:10:11]
set diap Enable or Disable DIAP set diap [disable:enable]
set eth2wlan Enable or Disable the Eth2Wlan Broadcast packet filter feature set eth2wlan [0:1]
Explanation: 0=disable:1=enable
set sta2sta Set wireless STAs to wireless STAs connect state (WLAN Partition) set sta2sta [disable: enable]
set eth2sta Set ethernet to wireless STAs connect state set eth2sta [disable: enable]
set ratecontrol Enable/Disable supported data rate set ratecontrol [disable:enable]
set supportrate Modify supported data rate(bit mask) set supportrate
Security
Del Command: Function Syntax
del key Delete Encryption key del key [1-4]
Get Command: Function Syntax
get encryption Display (WEP) configuration state (enabled or disabled) get encryption
get authentication Display Authentication Type get authentication
get cipher
Display Encryption cipher type
Explanation:
Response WEP for choosing WEP
Response Auto for choosing WPA-Auto
Response AES for choosing WPA-AES
Response TKIP for choosing WPA-TKI
get cipher

802.11 b/g Access Point Command Line Interface Manual
12
get keysource
Display Source Of Encryption Keys:
Explanation:
Response Flash Memory for static key
Response Key Server for dynamic key
Response mixed for mix static and dynamic key
get keysource
get key Display specified WEP encryption Key get key [1-4]
get keyentrymethod Display Encryption Key Entry Method ASCII or Hexadecimal get keyentrymethod
get passphrase Display WPA Passphrase get passphrase
get groupkeyupdate Display WPA Group Key Update Interval (in Seconds) get groupkeyupdate
Set Command: Function Syntax
set encryption Enable or Disable Encryption Mode set encryption [disable:enable]
set authentication Set Authentication Type set authentication [open-system:shared-key:auto:WPA: WPA-PSK:
WPA2: WPA2-PSK:WPA-AUTo:WAP2-AUTP-PSK]
set cipher Set Cipher of wep, aes, tkip, or auto negotiate set cipher [wep:aes:tkip:auto]
set groupkeyupdate Set Group Key Update Interval (in Seconds) for TKIP set groupkeyupdate <seconds>
set key Used to set the specified wep key value and size set key [1-4] default
set key [1-4] [40:104:128] < value>
set keyentrymethod Select Between ASCII or HEX encryption key format set keyentrymethod [asciitext : hexadecimal]
set keysource Select Source of Encryption Keys: static(flash), dynamic (server), mixed
set keysource [flash:server:mixed]
set passphrase Modify Passphrase set passphrase
WMM
Get Command: Function Syntax
get wmm Display WMM mode status (enabled or disabled) get wmm
get wmmParamBss ac Display WMM EDCA parameters used by STA in this BSS get wmmParamBss
get wmmParam ac Display WMM EDCA parameters used by this AP get wmmParam
Set Command: Function Syntax
set wmm Enable or Disable WMM Features set wmm [disable:enable]
set wmmParamBss ac Set WMM (EDCA) parameters used by STAs in this BSS
set wmmParamBss ac [AC number] [logCwMin] [logCwMax] [aifs]
[txOpLimit] [acm]
Explanation:
AC number: 0->AC_BE
1->AC_BK
2->AC_BK
3->AC_BK
Example:
set wmmParamBss ac 0 4 10 3 0 0

802.11 b/g Access Point Command Line Interface Manual
13
set wmmParam ac Set WMM (EDCA) parameters used by this AP
set wmmParamBss ac [AC number] [logCwMin] [logCwMax] [aifs]
[txOpLimit] [acm] [ack-policy]
Expanation:
AC number: 0->AC_BE
1->AC_BK
2->AC_BK
3->AC_BK

802.11 b/g Access Point Command Line Interface Manual
14
6
MULTI-SSID AND VLAN COMMANDS
Get Command: Function Syntax
get vlanstate Display Vlan State status (enabled or disabled) get vlanstate
get vlanManage Display manage AP with VLAN Mode get vlanManage
get nativevlan Display Native Vlantag get nativevlan
get Vlanpristate Display Vlan Priority State (enabled or disabled) get Vlanpristate
get Vlantag Display Primary SSID Vlantag get Vlantag
get VlantagType Display Primary SSID Vlantag Type get VlantagType
get ethnotag Display Primary SSID Ethernet without tag State get ethnotag
get Vlanpri Display Primary SSID Vlan Priority get Vlanpri
get multi-state Display Multi-SSID Mode (enabled or disabled) get multi-state
get multi-ind-state [index] Display Individual Multi-SSID State get multi-ind-state [index]
get multi-ssid [index] Display SSID of the specify Multi-SSID get multi-ssid [index]
get multi-ssidsuppress [index]
Display SSID Suppress Mode of the specify Multi-SSID get multi-ssidsuppress [index]
get multi-wmm [index] Display WMM mode of specify Multi-SSID get multi-wmm [index]
get multi-authentication [index]
Display Authentication Type for Multi-SSID get multi-authentication [index]
get multi-cipher [index] Display Encryption cipher for Multi-SSID get multi-cipher [index]
get multi-keyentrymethod Display Encryption Key Entry Method for Multi-SID get multi-keyentrymethod [index]
get multi-vlantag [index] Display Vlan tag for Multi-SSID get multi-vlantag [index]
get multi-vlantagtype [index] Display Vlan-Tag Type for Multi-SSID get multi-vlantagtype [index]
get multi-ethnotag [index] Display Individual Multi-SSID Ethernet without tag Mode get multi-ethnotag [index]
get multi-vlanpri [index] Display Vlan-Priority for Multi-SSID get multi-vlanpri [index]
get multi-key [index] Display Encryption Key for Multi-SSID get multi-key [index]
get multi-keysource [index] Display Key Source for Mulit-SSID get multi-keysource [index]
get multi-config [index] Display AP Configuration for Multi-SSID get multi-config [index]
get multi-passphrase [index] Display Passphrase for Multi-SSID get multi-passphrase [index]
get multi-acct-state Dislay Accounting State for Multi-SSID (enabled or disabled) get multi-acct-state
get multi-idv-acct-sta [index] Dislay Individual Accounting State for Multi-SSID get multi-idv-acct-sta [index]
get multi-idv-acct-srv [index] Dislay Individual Accounting Server for Multi-SSID get multi-idv-acct-srv [index]

802.11 b/g Access Point Command Line Interface Manual
15
get multi-idv-acct-port [index] Dislay Individual Accounting Server Port for Multi-SSID get multi-idv-acct-port [index]
Set Command: Function Syntax
set vlanstate Enable or Disable VLAN set vlanstate [disable:enable]
Note: Must Enable Multi-SSID firstly
set vlanManage Set manage AP with VLAN Mode set vlanManage [disable: enable]
set nativevlan Set Native Vlan Tag set nativevlan
set Vlanpristate Set Vlan Priority State set Vlanpristate [disable:enable]
set Vlantag Set Primary SSID VLAN Tag set vlantag <tag value>
set VlantagType Modify Primary SSID Vlantag Type set VlantagType [1:2]
Explanation: 1=
Manual : 2=
Dynamic
set ethnotag Enable or Disable Primary SSID Ethernet without Tag State set ethnotag [disable:enable]
set Vlanpri Modify Primary SSID Vlan Priority set Vlanpri <0-7>
set multi-state Enable or Disable Multi-SSID Features set multi-state [disable:enable]
set multi-ind-state Enable or Disable specifically Mulit-SSID set multi-ind-state [disable:enable] [index]
set multi-ssid Set Service Set ID for Multi-SSID set multi-ssid [index] <ssid name>
set multi-ssidsuppress Enable or Disable to broadcast SSID of Multi-SSID set multi-ssidsuppress [disable:enable] [index]
set multi-wmm Enable or Disable WMM mode of Multi-SSID set multi-wmm [disable:enable] [index]
set multi-authentication Set Authentication Type for Multi-SSID set multi-authentication [open-system:shared-key:wpa:wpa-
psk:wpa2:wpa2-psk:wpa-auto:wpa-auto-psk] [index]
set multi-cipher Set Cipher for Multi-SSID set multi-cipher [wep:aes:tkip:auto] [index]
set multi-encryption Set Encryption Mode for Multi-SSID set multi-encryption [disable:enable] [index]
set multi-keyentrymethod Select Encryption Key Entry Method for Multi-SSID set multi-keyentrymethod [hexadecimal:asciitext] [index]
set multi-vlantag Set VLAN Tag for Multi-SSID set multi-vlantag <tag value> [index]
set multi- vlantagtype Set Vlan-Tag Type for Multi-SSID set multi- vlantagtype [1:2] [index]
Explanation: 1=
Manual : 2=
Dynamic
set multi-ethnotag[index] Enable or Disable Individual Ethernet without Tag State set multi-ethnotag [disable:enable] [index]
set multi-vlanpri [pri value]
[index] Set Vlan-Priorityi for Multi-SSID set multi-vlanpri <0-7> [index]
set multi-key default Set Default Encryption Key set multi-key default [key index] [multi-ssid index]
set multi-passphrase Set PassPhrase for Multi-SSID set multi-passphrase [index] <passphrase>
set multi-acct-state Enable or Disable the Accounting Feature of Mulit-SSID mode set multi-acct-state [disable:enable]
set multi-idv-acct-sta Enable or Disable the Individual Accounting Feature of Mulit-SSID mode
set multi-idv-acct-sta [disable:enable] [index]
set multi-idv-acct-srv Set Individual Accounting Server of Mulit-SSID mode set multi-idv-acct-srv [index] < acct-srv name>
set multi-idv-acct-port Set Individual Accounting Server port of Mulit-SSID mode set multi-idv-acct-port [index] <port number>

802.11 b/g Access Point Command Line Interface Manual
16
Routing Commands (Spanning Tree Protocol)
Set Command: Function Syntax
rstp setstate Enable or Disable Spanning Tree Protocol supporting in VLAN / Multi-
SSID rstp setstate [0:1] Explanation: 0=disable:1=enable
rstp getstate Show Spanning Tree State rstp getstate
rstp setstp Modify Spanning Tree Settings
rstp setstp maxage [6 – 40]
rstp setstp hellotim [1-10]
rstp setstp forwarddely [4-30]
rstp setstp priority [0-61440], (note: 0 is the highest)
rstp setstp version [1:2], (note: 1 is stp and 2 is rstp)
rstp setstp txholdcount [1-10]
rstp setstp fbpdu[0-:1], (note: 0 is disduble and 1 is enable)
rstp getstp Show Spanning Tree Settings rstp getstp
rstp setport Modify STP Port Settings
, includes cost , priority, edge, p2p and state
parameters rstp setport
rstp getport Show STP Port Settings rstp getport
rstp setdefault Set Factory Default rstp setdefault

802.11 b/g Access Point Command Line Interface Manual
17
7
ACCESS CONTROL LIST COMMANDS
Del Command: Function Syntax
del acl Delete specified Access Control List entry del acl [1-16]
del wdsacl Delete specified WDS ACL entry: 1-8 del wdsacl [1-8]
Get Command: Function Syntax
get acl Display Access Control Setting of Enabled or disabled get acl
get wdsacl Display WDS Access Control List get wdsacl
Set Command: Function Syntax
set acl enable Select ACL restricted access to specified MAC addresses set acl enable
set acl disable Select Unrestricted access set acl disable
set acl allow Add specified MAC address to the allow ACL set acl allow <xx:xx:xx:xx:xx:xx>
set acl deny Add specified MAC address to the deny ACL set acl deny <xx:xx:xx:xx:xx:xx>
set acl strict Select Restricted Access, only clients with authorized MAC will
communicate set acl strict
set acl keymap Add WEP Encryption Key mapping for MAC Address set acl keymap <xx:xx:xx:xx:xx:xx> [1-4] set acl keymap <xx:xx:xx:xx:xx:xx> default
set acl keymap <xx:xx:xx:xx:xx:xx> [40:104:128] < value>
set wdsacl allow Add MAC Address to WDS List set wdsacl allow <xx:xx:xx:xx:xx:xx>
IPfilter Command: Function Syntax
ipfilter state Display or Set Remote IP Acl State ipfilter state
ipfilter state [on:off]
ipfilter add Add a IP Range Entry ipfilter add <xxx.xxx.xxx.xxx> <xxx.xxx.xxx.xxx>
ipfilter del Del a IP Range Entry ipfilter del <xxx.xxx.xxx.xxx> <xxx.xxx.xxx.xxx>
ipfilter clear Clear IP Pool ipfilter clear
Ipfilter list Display IP Pool ipfilter list

802.11 b/g Access Point Command Line Interface Manual
18
8
RADIUS &ACCOUNTING SERVER COMMANDS
Get Command: Function Syntax
get radiusname Display RADIUS server name or IP address get radiusname
get radiusport Display RADIUS port number get radiusport
get radiussecret Display RADIUS shared secret get radiussecret
get radius2ndstate Display the second RADIUS Mode (enabled or disabled) get radius2ndstate
get radiusname2nd Display the second RADIUS server name or IP address get radiusname2nd
get radiusport2nd Display the second RADIUS port number get radiusport2nd
get radiussecret2nd Display the second RADIUS shared secret get radiussecret2nd
get radiuscfgid Display the configuration of radius now get radiuscfgid
get accountingstate Display Accounting Mode (enabled or disabled) get accountingstate
get accountingname Display Accounting server name or IP address get accountingname
get acountingport Display Accounting port number get acountingport
get accounting2ndstate Display the second Accounting Mode (enabled or disabled) get accounting2ndstate
get accounting2ndname Display the second Accounting server name or IP address get accounting2ndname
get accounting2ndport
Display the second Accounting port number get accounting2ndport
get accountingcfgid Display the configuration of Accounting now get accountingcfgid
Set Command: Function Syntax
set radiusname Set RADIUS Server name or IP address set radiusname <DNS name::xxx.xxx.xxx.xxx>
Explanation: <xxx.xxx.xxx.xxx> is IP address
set radiusport Set RADIUS port number set radiusport <xxxxx>
Explanation: <xxxxx> is port number, default value is 1812
set radiussecret Set RADIUS shared secret set radiussecret
set radius2ndstate Enable or Disable the second RADIUS function set radius2ndstate [disable:enable]
set radiusname2nd Set the second RADIUS name or IP address set radiusname2nd <DNS name::xxx.xxx.xxx.xxx>
Explanation: <xxx.xxx.xxx.xxx> is IP address
set radiusport2nd Set the second RADIUS port number set radiusport2nd <xxxxx>
Explanation: <xxxxx> is port number, default value is 1812
set radiussecret2nd Set the second RADIUS shared secret set radiussecret2nd
set accountingstate Enable or Disable Accounting server function set accountingstate [disable:enable]
set accountingname Set Accounting server name or IP address set accountingname <DNS name::xxx.xxx.xxx.xxx>
Explanation: <xxx.xxx.xxx.xxx> is IP address
