75286 Rev. 10/03
POWER
PRESENTATION PRODUCTS
The
In
Installation Operating
Instructions For
Tilt-Lock™
DA-LITE SCREEN COMPANY, INC.
3100 North Detroit Street
Post Office Box 137
Warsaw, Indiana 46581-0137
Phone: 574/267-8101
800-622-3737
Fax: 574/267-7804
http:// www.da-lite.com
e-mail: [email protected]
DA-LITE IS MORE
THAN PROJECTION SCREENS
Da-Lite Tripod, Wall and
Ceiling and Electric Screens
Da-Lite Lecterns
Da-Lite
Project-O-Stands
and Easels
Da-Lite
Monitor Mounts
PROTECT YOUR SCREEN by keeping it
rolled in its protective case when not in
use. Always examine both front and back
of surface before re-rolling into case to make
certain screen is free of dust, dirt or other
foreign matter. Use a very soft duster brush
gently to remove foreign particles.
WALL BRACKETS
FOR KEYSTONE ELIMINATION
1. Lock projection screen in down position.
2. Secure screen pull cord to hook with knot at
approximate desired location.
3. Pull projection screen back by cord and
place flat of magnet against wall in such a
way that pull cord and hook are
perpendicular to wall. Mark this position on
wall. See diagram.
Remove protective paper from adhesive
surface of wall plate. Place on marked
position on wall and press firmly. Be sure
wall plate is pressed securely onto wall.
If necessary, readjust hook on cord by
adjusting the knot for desired angle of
screen surface. Then tighten knot on hook.
Close hook with pliers. See diagram.
4. To release projection screen for closure,
pull hook from wall plate with slight twisting
motion.
Care in mounting and care in correct operation
will mean a long and satisfactory life for wall
type screens.
WALL BRACKETS
Da-Lite No. 6 and No. 11 Non-adjustable wall
brackets and No. 23 adjustable extension wall
brackets are ideal for keystone elimination,
chalkboard clearance, or corner mounting. The
screen brackets should be fastened to the
studding or other solid surface and not in the
plaster only. Suspend screen from “D” rings.
No. 23 ADJUSTABLE
WALL BRACKETS
Screen can be extended
181⁄4", 20" or 24" from
wall by wing nut and
bolt adjustment.
No. 11 WALL BRACKETS
Screen can be extended
10" or 14" from wall by
changing position of
bracket.
No. 6 WALL BRACKETS
Screen can be extended
6" from wall.
TILT LOCK
For Keystone Elimination
Magnet holds back bottom of screen in tilted
position to eliminate keystoning.
