Operating Instructions for
MODEL C WITH CSR
(Controlled Screen Return)
The Da-Lite Difference.

1
WALL MOUNTING
TO OPEN SCREEN
Pull down on pull bail until desired picture area is obtained. Lock into position as on a window shade. Be sure surface is
locked before releasing.
NOTE: This screen will not lock into position in the upper portion of its travel.
1. Select fasteners of proper type for wall or ceiling involved.
2. Insert fasteners through proper openings provided in back side of end caps.
3. Attach screen securely to studding or other solid surface - never to plaster only.
4. MAKE SURE SCREEN IS MOUNTED LEVEL.
YOU HAVE MADE A WISE SELECTION…
in choosing a Da-Lite projection screen, designed and engineered to produce the sharpest,
most pleasing pictures with maximum convenience.
CEILING MOUNTING
1. Heavy screw hooks may be installed into wood joists. Other types of hooks or chain may be used for other ceilings or
for stage installations.
2. Insert hooks or chain through proper openings provided in sides of end caps. Screen must hang so that flat back of
case is perpendicular to floor.
3. MAKE SURE SCREEN IS MOUNTED LEVEL.
TO RE-ROLL YOUR PICTURE SURFACE
The Model C operates on the same principle as a window shade. Pull down about 4 inches to disengage the locking dog
and start the fabric up firmly and quickly.
Large picture surfaces are heavy and will start up too slowly to prevent the locking dog from catching unless help is
provided, so keep picture surface moving briskly.
Should the locking dog catch, pull the picture surface down about 4 inches and start the surface up rapidly.
The CSR feature of this screen will allow the screen to stop, as normal, in the bottom portion of its travel. The screen will
not stop in the top portion of its travel, but will continue slowly and gently into the case.
To view an online Model C with CSR retraction tutorial, please visit http://www.da-lite.com/products/product_flash/modelc_csr/.
PROTECT YOUR SCREEN
Before re-rolling surface into case, examine both front and back of surface to be sure they are free of foreign matter.
Model C with CSR (Controlled Screen Return) is a
feature offered exclusively by Da-Lite to assist the quiet
controlled return of the screen into the case.

2
SUGGESTED METHODS OF INSTALLATION
MODEL C EXCLUSIVE FEATURES
• EasilyInstalled
• Multi-PurposeEndCapsFormSturdyBracketsforWall/CeilingInstallation
• LargeScreensHaveAluminumSlatSaddletoDistributeUniformTensiononPictureSurface
• HeavyDutyGroovedMetalRollerAssuresPermanentFasteningofPictureSurface
• NylonandBallBearingRollerMounting
• Handsome,Rugged,PowderCoatedSteelCase
• FloatingMountingBrackets
Ceiling Trim Kit
(optional at extra cost)
FOR WALL
FOR
CEILING
WALL MOUNTED
PICTURE SURFACE
PICTURE SURFACE
CEILING HANGING
PICTURE SURFACE
USE No. 6 BRACKETS TO HANG
BEHIND BEAM OR VALANCE
SURFACE
CONCEALED
(ALLOW ROOM FOR ACCESS)
HANGING BRACKETS
(Optional at extra cost)
No. 11 Wall Bracket
Non-Adjustable permits
screen to extend 10" or
14" from wall.
No. 6 Wall Bracket
Non-Adjustable permits
screen to extend 6"
from wall.

3
TROUBLESHOOTING
SYMPTOM
1. Screen is retracting too slowly. Over
8 seconds retracting from the bottom
into the case.
2. Screen is retracting too fast. Under 3
seconds retracting from the bottom
into the case.
3. Screen is retracting too slowly, and
then slams the case when adjusted
counterclockwise.
4. Screen does not retract.
5. Screen does not stay down.
CAUSE
(a) The CSR adjustment is not correct.
(a) The CSR adjustment is not correct.
(a) The CSR unit (shock absorber) is too
strong.
(a) Retraction procedure*.
(b) The CSR has been over adjusted
counterclockwise.
(c) The roller tube is bent and binding.
(a) Locking procedure.
(b) Dog is not locking.
SOLUTION
(a) Retract screen completely, and then
rotateCSRshaft1/2turnatatime
counterclockwise.
(a) Retract screen completely, and then
rotateCSRshaft1/2turnatatime
clockwise.
(a) Reset the CSR unit. Call Da-Lite (800-
622-3737) for detailed instructions.
(a) Pull the screen down, and then
retract firmly and quickly.
(b) The CSR unit is jammed. Reset or
replace the CSR unit. Call Da-Lite
(800-622-3737) for detailed
instructions.
(c) Replace the screen.
(a) Pull the screen down, and then
slowly retract until it locks.
(b) Retract screen completely, and then
rotateCSRshaft1/2turn
counterclockwise.
Printed in U.S.A. 80162 Rev. 10/09
DA-LITE IS MORE THAN PROJECTION SCREENS
Da-Lite Tripod, Wall and
Ceiling and Electric Screens
Da-Lite Lecterns
Da-Lite
Project-O-Stands
and Easels
Da-Lite
Mounting Systems
