Dacor Preference Renaissance RGC304 Technical manual

PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: [phone]
Specifications are subject to change without notice.
See installation instructions for additional details. 4.11
RGC304, RGC365
30”, 36” Wide, Preference™
Renaissance Gas Cooktops
1/2
Revised
05/21/08
30"
(762 mm)
21"
(533 mm)
4" (102 mm)
Chassis height
1/4" (6 mm) Min.
to combustibles
below chassis
27 1/2"
(699 mm)
19 7/8" (505 mm)
3 1/8"
(79 mm)
7 1/2" (191 mm) Min.
to combustible
side wall above
the cooktop
(both sides)
Vertical
combustible
surface
Rear
wall
2"
(51 mm) Min.
25" (635 mm)
Min.
PRODUCT AND CUTOUT DIMENSIONS:
MODEL RGC304
36"
(914 mm)
21"
(533 mm)
19 7/8"
(505 mm)
33 3/4"
(857 mm)
4" (102 mm)
Chassis height
3 1/8"
(79 mm)
1/4" (6 mm) Min.
to combustibles
below chassis
7 1/2" (191 mm) Min.
to combustible
side wall above
the cooktop
(both sides)
Vertical
combustible
surface
Rear
wall
2"
(51 mm) Min.
25" (635 mm)
Min.
Axis2Axis2
PRODUCT AND CUTOUT DIMENSIONS:
MODEL RGC365
WARNING
1. Observe all governing codes and ordinances during planning
and installation. Contact your local building department for
further information.
2.
This appliance must be installed in accordance with the
accompanying installation instructions.
All tolerances +1/16” -0 (+1.6 mm, 0) unless
otherwise noted.

PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: [phone]
Specifications are subject to change without notice.
See installation instructions for additional details. 4.12
RGC304, RGC365
30”, 36” Wide, Preference™
Renaissance Gas Cooktops
2/2
Revised
05/21/08
13" Max.
(330 mm)
A
3 1/8" Min.
(79 mm)
18" Min.
(457 mm)
30" Min.
(762 mm)
Clearances to Combustibles
1/4” (6 mm)
Mimimum clearance
to combustible
surfaces
B
Under Cabinet Clearances
Model A: Minimum A: Recommended
RGC304 30” (762 mm) 36” (914 mm)
RGC365 36” (914 mm) 42” (1067 mm)
Model B: Minimum
RGC304 29” (737 mm)
RGC365 35 ¼” (895 mm)
All tolerances +1/16” -0 (+1.6 mm, 0) unless otherwise noted.
RGC304
RGC365
RGC304LP
RGC365LP
Total Connected
Load
0.25 Amps
(0.03 kW)
0.25 Amps
(0.03 kW)
Circuit
Requirement
120 Vac,
60 Hz, 15 Amp
120 Vac,
60 Hz, 15 Amp
Gas Type Natural LPG
Manifold
Pressure 5” Water Column 10” Water Column
Min. Gas Supply
Pressure 6” Water Column 11” Water Column
Power Cord
Length 40” (1016 mm) 10” (254 mm)
GAS AND ELECTRICAL REQUIREMENTS*
* The data above is for reference only. If the above data does not
agree with the product data label, use the data on the product data
label.
Front of Unit
Data Label
