Installation Instructions
Epicure®Range
Part No. 102187 Rev. J
THIS APPLIANCE HAS BEEN TESTED IN ACCORDANCE WITH THE LATEST EDITION
OF ANSI Z21.1 STANDARD FOR HOUSEHOLD GAS COOKING APPLIANCES.
For use with models ER30D, ER30D-C, ER30DSR

All specifications subject to change without notice.
Dacor®assumes no liability for changes to specifications.
© 2007 Dacor, all rights reserved.

1
Important Safety Instructions ..................................................1-3
Customer Service Information....................................................3
Planning the Installation...........................................................4-8
Electrical Requirements..............................................................4
Gas Supply Requirements..........................................................4
Product Dimensions.................................................................... 5
Cabinet Layout............................................................................7
Installation Instructions..........................................................8-20
Preparing for Installation.............................................................8
Electrical Connection ................................................................12
Gas Connection ........................................................................17
Final Installation........................................................................18
Installing the Burner Knobs ......................................................18
Cooktop Assembly ....................................................................19
Verifying Proper Operation .......................................................20
Installation Checklist .................................................................20
Table of Contents
About Safety Instructions
The Important Safety Instructions and warnings in this manual
are not meant to cover all possible problems and conditions
that can occur. Use common sense and caution when installing,
maintaining or operating this or any other appliance.
Always contact the Dacor Customer Service Team about problems
and conditions that you do not understand.
Safety Symbols in this Manual
DANGER
Immediate hazards that WILL result in severe personal injury or
death.
WARNING
Hazards or unsafe practices that COULD result in severe
personal injury or death.
CAUTION
Hazards or unsafe practices that COULD result in minor
personal injury or property damage.
Important Safety Instructions
IMPORTANT:
Installer• : In the interest of safety and to minimize problems, read these installation instructions completely and carefully before you
begin the installation process. Leave these installation instructions with the customer.
Customer• : Keep these installation instructions for future reference and the local building inspector’s use.
READ AND SAVE THESE INSTRUCTIONS
DANGER
IMPORTANT: If you smell gas:
Do not use or light any appliance.•
Do not touch any electrical switch or use any electrical•
devices, including the telephone, in your building.
From a neighbors phone, immediately call the gas supplier.•
Follow the gas supplier’s instructions.
If you cannot contact the gas supplier, call the fire•
department.
IMPORTANT: Do not store or use combustible, flammable or
explosive vapors and liquids (such as gasoline) inside or in the
vicinity of this or any other appliance. Also keep items that could
explode, such as aerosol cans, away from the burners and the
oven. Do not store flammable or explosive materials in adjacent
cabinets or areas.
IMPORTANT: Junked or abandoned appliances are dangerous
and can cause a child entrapment and suffocation hazard.
When taking an appliance out of service, immediately follow
the instructions below to help prevent accidents:
Take off the door.•
Leave the racks in place so children cannot easily climb•
inside.
Cut the prongs off the power cable plug and discard them.•
Cut the power cable off and discard it separately from the•
old appliance.
CALIFORNIA
PROPOSITION 65 WARNING
The burning of gas cooking fuel generates some by-products
that are on the list of substances which are known by the State
of California to cause cancer or reproductive harm. California
law requires businesses to warn customers of potential
exposure to such substances. To minimize exposure to these
substances, always operate this unit according to the use
and care manual, ensuring you provide good ventilation when
cooking with gas.
WARNING
WARNING – NEVER use this appliance as a space heater
to heat or warm the room. Doing so may result in carbon
monoxide poisoning and overheating of the appliance.
WARNING
WARNING – NEVER cover any slots, holes or passages on
the inside or outside of the range or cover an entire rack with
materials such as aluminum foil. Doing so blocks air flow
through the oven and may cause carbon monoxide poisoning.
Aluminum foil linings may also trap heat, causing a fire hazard.

2
Important Safety Instructions
General Safety Precautions
To reduce the risk of fire, explosion, electric shock, serious injury or death when installing or using this appliance, follow basic safety
precautions, including the following:
Read the accompanying use and care manual completely before operating this appliance.•
Keep packaging materials away from children. Plastic sheets and bags can cause suffocation.•
If you receive a damaged product, immediately contact your dealer or builder.• Do not install or use a damaged appliance.
This range must be properly installed by a qualified installer according to these installation instructions prior to use. The installer•
must show the customer the location of the gas shut off valve and the circuit breaker panel or fuse box so that they know where
and how to turn off the gas supply and electric power to the range.
If the back wall is made of combustible materials do not operate the range without a backguard or raised vent in place. A fire may•
result.
Do not install, repair or replace any part of the range unless specifically recommended in the literature accompanying it. A•
qualified service technician should perform all other service.
Do not connect this range to the gas supply without the supplied gas pressure regulator installed.•
Before performing any type of service or installation, make sure that the gas supply and electric power to the range are off.•
NEVER block or cover any slots, holes or passages anywhere inside the oven or on the outside of the range or cover an oven•
rack with materials such as aluminum foil. See the Getting to Know Your Range section of the use and care manual for the
location of the various air holes (slots).
Only use the range for cooking tasks expected of a home appliance as outlined in the literature accompanying it. This range is•
not intended for commercial use.
DO NOT TOUCH THE SURFACES OF THE OVEN OR COOKTOP DURING OR IMMEDIATELY AFTER USE• .
Do not climb on any part of the appliance.•
Never leave this appliance unattended when in use.•
Do not leave children or pets alone or unattended in the area around the range. Do not allow children to play with the controls,•
pull on the handle, or touch other parts of the range.
Do not store items of interest to children on top of or above the range. Children could be burned or injured while climbing on the•
appliance.
Do not attempt to use this appliance in the event of a power failure.•
Do not tamper with the controls. Do not adjust or alter any part of the range unless specifically instructed to do so in these•
instructions.
To prevent the unit from tipping forward and to provide a stable installation, this range must be secured in place with the anti-tip•
device as specified in these instructions.
Clean the cooktop thoroughly before operating it for the first time.•
Keep flammable items, such as paper, cardboard, plastic and cloth away from the burners and other hot surfaces. Do not place•
such items in the oven. Do not allow pot holders to touch hot surfaces or gas burners.
Do not wear loose or hanging apparel while using the range. Do not allow clothing to come into contact with the interior of the•
oven or the cooktop and surrounding areas during and immediately after use.
To avoid a fire hazard, do not hang flammable or heat sensitive objects over the range. If the range is near a window, do not use•
long curtains as window treatment. The curtains could blow over the cooktop and create a fire hazard.
Do not use the oven for storage.•
Do not touch the burner assembly, grates or surrounding surfaces (including the backguard) or the interior surfaces of the oven•
during use. After use, make sure these surfaces have had sufficient time to cool before touching them.
Do not touch the outside surfaces of the range during the self-clean cycle. They will be hot. Venting from the oven may cause the•
cooktop and backguard to become hot.
Make sure that all the cooktop parts are dry before lighting a burner.•
Turn the knobs to the• OFF position prior to removing them from the valve stems.
Do not operate the cooktop without the knobs and trim rings in place.•
For your safety, do not use the oven to cook without the convection filter installed. When the filter is not installed, the spinning fan•
blades at the back of the oven are exposed.
Non-stick coatings, when heated, can be harmful to birds. Remove birds to a separate, well-ventilated room during cooking.•
WARNING

3
Important Safety Instructions
To prevent damage, remove the meat probe from the oven when it is not being used.•
Do not line the oven with aluminum foil or other materials. These items can melt or burn up during self-cleaning and cause•
permanent damage to the oven.
Do not leave metal objects, such as aluminum foil, the meat probe, cookie sheets, etc. on the bottom of the oven. Objects left on•
the bottom of the oven could damage the bake element. In addition, the objects themselves could be damaged.
The bake and broil elements are behind glass panels on the floor and ceiling of the oven chamber. Do not cover these glass•
panels with cookie sheets, aluminum foil, pots, pans, etc. Covering them could cause the heating elements to over-heat,
damaging the oven.
Do not expose the knobs or trim rings to direct flame, hot utensils or other sources of heat.•
Always ensure that the light fixture lens covers are in place when using the oven. The lens covers protect the light bulbs from•
breakage caused by high oven temperatures or mechanical shock.
CAUTION
Customer Service Information
If you have questions or problems with installation, contact your
Dacor dealer or the Dacor Customer Service Team. For repairs
to Dacor appliances under warranty, call the Dacor Distinctive
Service line. Whenever you call, have the model and serial
number of the appliance ready. The serial number and rating
labels can be seen through the grill below the control panel, on
the right side.
Dacor Customer Service
Phone: [phone] (U.S.A. and Canada)
Monday — Friday 6:00 a.m.to 5:00 p.m.Pacific Time
Web site: www.Dacor.com
Dacor Distinctive Service (for repairs under warranty only)
Phone: [phone] (U.S.A. and Canada)
Monday — Friday 6:00 a.m.to 4:00 p.m.Pacific Time
Model Identification
* Applies only to free standing models. All units with self-rimming
option are equipped for use in the U.S.A. and Canada.
Model and Serial Number Location
Serial number
and rating labels
located inside
unit, behind grill
ER30DSR-C-SCH/NG/H
SIZE (inches)
TRIM TYPE
COUNTRY CODE*
GAS TYPE
ALTITUDE
SR = Self-rimming option
No character = Free standing
C = Equipped for use in Canada
No character = Equipped for use in U.S.A.
NG = Natural gas
LP = Liquid petroleum (propane)
H = Equipped for high altitude operation,
4000 ft. (1219 m) and up
No character = Equipped for low altitude operation

4
Planning the Installation
WARNING
IMPORTANT: Observe all governing codes and ordinances
during planning and installation. Contact your local building
department for further information.
Electrical Requirements
IMPORTANT: The information below applies only to freestanding
units equipped for use in the U.S.A. and units with the self-
rimming option.
It is the owner’s responsibility to ensure that the electrical
connection of this appliance is performed by a licensed electrician.
The electrical installation, including minimum supply wire size and
grounding, must be in accordance with the National Electric Code
ANSI/NFPA 70-1993* (or latest revision) and local codes and
ordinances. A copy of this standard may be obtained from:
National Fire Protection Association
1 Batterymarch Park
Quincy, Massachusetts 02269-9101
The correct voltage, frequency and amperage must be•
supplied to the appliance from a separate, grounded, circuit
that is protected by a properly sized circuit breaker or time
delay fuse. Refer to the ratings on the range rating label.
ER30D/ER30DSR ELECTRICAL SPECIFICATIONS
Circuit Required Total Connected Load
240 Vac, 60 Hz, 30 Amp. 5.6 kW (24.2 Amp.)
The ratings above are for reference only - refer to the range
rating label (see page 3).
Consult local building codes for the type and minimum wire•
gauge to use for the power requirements listed on the rating
label.
Suggested wiring color code: black, white, red and green.•
The wiring needs to be long enough to allow the range•
to be pulled out from the wall for service, while remaining
connected. See page 12 for further details.
The wiring to the range must:•
Have a minimum rating of 250 Volts @ 30 Amp.◊
Include a strain relief◊
Be terminated by tinned leads, closed loop terminals or◊
open ended spade lugs with upturned ends
Where local code permits, a three (3) or four (4) wire•
appliance cord may be used. The appliance cord must:
Be UL listed type SRD or SRDT◊
Be equipped with a NEMA 14-50P 4 wire plug or, where◊
local code permits, a NEMA 10-50P 3 wire plug
Prior to range installation, have a licensed electrician install a•
conduit junction box or electrical receptacle according to the
type of wiring used.
Electrical Requirements
Freestanding Units for Use in Canada
It is the owner’s responsibility to ensure that the required•
4 wire electrical outlet is installed by a licensed electrician
as specified below prior to range installation. The electrical
outlet installation, including minimum supply wire size and
grounding, must be in accordance with all governing codes
and ordinances.
The correct voltage, frequency and amperage must be•
supplied to the appliance from a separate, grounded, circuit
that is protected by a properly sized circuit breaker or time
delay fuse. Refer to the ratings on the range rating label.
ER30D/ER30DSR ELECTRICAL SPECIFICATIONS
Circuit Required Total Connected Load
240 Vac, 60 Hz, 30 Amp. 5.6 kW (24.2 Amp.)
The ratings above are for reference only - refer to the range
rating label (see page 3).
Freestanding ranges equipped for use in Canada come pre-•
wired with a 4 wire appliance
cord and NEMA 14-50P plug.
Do not modify the factory•
wiring. The plug is designed
to plug directly into a NEMA
14-50R electrical receptacle
installed by a licensed
electrician according to the
above specifications.
Gas Supply Requirements
(All units)
Check your local building codes for the proper method of•
installation. In the absence of local codes, this appliance
should be installed in accordance with the National Fuel Gas
Code ANSI Z223.1.
Be certain that the appliance being installed is correct for•
the gas service provided (natural gas or LP gas). Also, if
operating the range at an altitude above 4000 ft. (1219 m)
make sure it is equipped for high altitude operation. Refer to
the range rating label and the table on page 3 to determine
the correct model.
See the table below for gas supply pressure requirements.•
The regulator inlet accommodates a 3/4” gas line. The range•
ships with a 1/2” to 3/4” adapter connected to the regulator.
GAS SUPPLY PRESSURE REQUIREMENTS
Gas
Type
Manifold
Pressure* (WC)
Min. Gas Supply
Pressure (WC)
Max. Input
Pressure
Natural 5 6 1/2 p.s.i.
LP 10 11 1/2 p.s.i.
The ratings above are for reference only - refer to the range rating
label (see page 3).
NEMA 10-50P PlugNEMA 14-50P Plug
NEMA 14-50R Receptacle

5
Planning the Installation
B
Gas
inlet
A
C
7/8” (22 mm) Dia. electrical
connection hole in bottom*
D
Range electrical access,
cover removed
1 1/16” (27 mm)
26 5/16” (668 mm)
27 5/16” (694 mm)
28 13/16” (732 mm)
24 1/4” (616 mm)
3” (76 mm)
Backguard*
6” (152 mm)
Backguard**
** Optional
Standard
*
37 7/8”
(962 mm)
to
35 3/4”
(908 mm)
46 1/4” (1175 mm)
Width at front panel:
29 7/8” (758 mm)
Finished side panel
9” (229 mm)
1 9/16”
(40 mm)
Backguard**
1 1/16” (27 mm) to cooking
surface (top of grates) from
top of trim
Product tolerances: ±1/16” (±1.6 mm), unless otherwise stated
Product Dimensions
NOTE: Models ER30D and ER30D-C are NOT
designed for use with self-rimming installations or
raised vents. Use model ER30DSR for self-rimming
and raised vent installations.
Gas and Electrical Dimensions - All Models
Freestanding Models: ER30D and ER30D-C
GAS - ELECTRICAL ACCESS DIMENSIONS
A B C D
4 7/8”
(124 mm)
21 3/4”
(552 mm)
8 5/8”
(219 mm)
10 3/16”
(259 mm)
* When using an appliance cord, the hole size must
be increased to 1 1/8” by removing the conduit bracket
inside the range electrical access box.

6
Planning the Installation
Self-Rimming Model ER30DSR
with Standard Trim
Self-Rimming Model ER30DSR
with Optional Raised Vent Trim Kit (ATK30SR) Installed
1 9/16”
(40 mm)
23 1/8” (587 mm)
23 5/8” (600 mm)
26 11/16” (678 mm)
35 3/4”
(908 mm)
to
37 7/8”
(962 mm)
28 3/16” (716 mm)
45 5/8” (1159 mm)
Rear of front panel to
back of chassis
Rear of front panel /oven door
Front panel
Front edge of bullnose
Front of handle
Front of open door
25 11/16” (652 mm)
Width at front panel:
29 7/8” (758 mm)
1 5/16” (33 mm) to cooking
surface (top of grates) from
bottom of trim
1 9/16”
(40 mm)
23 1/8” (587 mm)
24 1/8” (613 mm)
27 3/16” (691 mm)
35 3/4”
(908 mm)
to
37 7/8”
(962 mm)
28 11/16” (729 mm)
46 1/8” (1172 mm)
Rear of front panel to
back of chassis
Rear of front panel /oven door
Front panel
Front edge of bullnose
Front of handle
Front of open door
26 3/16” (665 mm)
Width at front panel:
29 7/8” (758 mm)
1 5/16” (33 mm) to cooking
surface (top of grates) from
bottom of trim
Product tolerances: ±1/16” (±1.6 mm), unless otherwise stated
Product Dimensions (continued) NOTE: Self-rimming models are designed to allow the trim to
overlap the countertop when configured to the dimensions on
page 8.
NOTE: Self-rimming models are not compatible with Dacor
integral backguards.

7
Planning the Installation
Cabinet Layout
Carefully check the location where the range is to be•
installed. For best performance, the range should be placed
away from drafts that may be caused by doors, windows and
heating and air conditioning outlets.
To reduce the risk of personal injury and to reduce•
accumulated smoke in the room, Dacor strongly recommends
installing a range hood. A range hood should project
horizontally a minimum of five (5) inches beyond the face of
the cabinets.
All maximum and minimum dimensions and clearances•
shown in the diagram below and on page 8 (as applicable)
must be maintained for safe operation.
In the freestanding configuration, the range may be installed•
flush to the rear wall. For all installations, Dacor highly
recommends installing a non-combustible material on the rear
wall above the range and up to the vent hood or installation
of a backguard. It is not necessary to install non-combustible
materials behind the range below the countertop height.
Any openings in the wall behind the appliance or in the floor•
underneath it must be sealed.
Gas and Electrical Service
The shaded area shown denotes the location of the gas•
inlet and the electrical junction box/receptacle. This is the
recommended location. For replacement purposes, the
location of the existing utilities may be utilized provided they
do not interfere with the sides or rear of the range. Check
local building codes for permissible gas valve locations.
An external manual shut-off valve must be installed between•
the gas inlet and the range for the purpose of turning on or
shutting off gas to the appliance.
The installation must allow for the following:
Access to the gas shut-off valve when the unit is installed.•
Access to the remote circuit breaker panel or fuse box, when•
the range is in place.
The gas supply piping, gas shut-off valve and the electrical•
junction box or receptacle must be located so they do not
interfere with the range when it is installed.
The junction box and gas shut off valve must be located•
so that the range can be pulled out for service while the
appliance remains connected.
Freestanding Cabinet Cutout Dimensions -
Models ER30D and ER30D-C
Note 2
F
G
2Cabinet/countertop depth is at discretion of customer but
cabinet face MUST NOT protrude further than rear of front
panel, see product dimensions.
3Consult local code for exact location requirements.
1Vertical to combustible surface from range grate level; if
installing an overhead vent hood, also check the hood
specifications for minimum required clearances.
Non-combustible
surface along
back wall
recommended
10” (254 mm) Min.
to combustible side
walls above the range
(both sides)
30” (762 mm)
Min.1
36 1/2”
(927 mm)
Max.
13” (330 mm)
Max.4
18” (457 mm)
Min.1, 4
Suggested
location of
utilities 3
4Not applicable for cabinets more than a horizontal
distance of 10” (254 mm) from the edge of the range.
Cutout tolerances: +1/16” (+1.6 mm), -0
FREESTANDING CUTOUT
DIMENSIONS
F G
36” (914 mm)*
30” (762 mm)** 30 1/16” (764 mm)*
* Recommended
** Minimum
See following page for self-rimming cutout
dimensions.
WARNING
Do not operate the range without the backguard in place if the
back wall is made of combustible materials. A fire may result.

8
Installation Instructions
Non-combustible
rear wall recommeded
Countertop Height: Min: 35 5/8” (905 mm) Max: 37 3/8” (949 mm)
Combustible side
wall above range
countertop opening
29 1/2” (749 mm)
30” (762 mm)
cabinet opening
below countertop
below countertop
Cabinet face
Notch countertop
overhang to width of
cabinets
1/4” Min. (6 mm)
Countertop
overhang
10” Min.
(254 mm)
both sides
Countertop front
H J K
rear wall recommended
Non-combustible
countertop opening
cabinet opening
below countertop
29 1/2” (749 mm)
27 1/2” (699 mm)
30” (762 mm)
2 3/8” (60 mm)
Combustible side
wall above range
10” Min.
(254 mm)
both sides
Countertop Height: Min: 35 5/8” (905 mm) Max: 37 1/4” (946 mm)
Notch countertop
overhang to width of
cabinets
3/8” Min. (10 mm)
Countertop
overhang
below countertop
Cabinet face
raised vent opening
H J K
Countertop front
Planning the Installation
Notes For All Self-Rimming Installations:
On installations without a raised vent (see above), when•
sliding the range into position, it will stop when the rear of
the control panel contacts the notches toward the front of the
countertop. The range trim will partially cover the overhang in
back.
On installations with a raised vent (see above right), install•
Dacor trim kit ATK30SR. When sliding the range into position,
it will stop when the rear of the control panel contacts the
notches toward the front of the countertop. The range trim will
partially cover the front of the raised vent chassis in back.
ER30DSR with H J K
no side panels no
raised vent
23 1/2”
(597 mm)
23 1/2”
(597 mm)
24” to
25 9/16”
3-inch side panels*
and no raised vent
20 1/2”
(521 mm)
20 1/2” to
23 1/2”
21” to
25 9/16”
no side panels and
raised vent
24”
(610 mm)
24”
(610 mm)
24 1/2” to
26 1/16”
3-inch side panels
and raised vent
21”
(533 mm) 21” to 24” 21 1/2” to 26 1/16”
* Optional side panels (PN ARSP3) cover unfinished chassis sides
when the cabinet face is recessed behind back of control panel.
Parts List
2 grates•
1 small stack burner cap•
1 small stack burner ring•
2 large stack burner caps•
2 large stack burner rings•
1 crown burner cap•
1 crown burner ring•
1 crown burner head•
1 GlideRack™ oven rack•
Preparing for Installation
WARNING
If the gas or electric service provided does not meet the•
product specifications, do not proceed with the installation.
Call the dealer, the gas supplier or a licensed electrician.
Before installing the range, you must locate and secure the•
anti-tip bracket to the floor.
Be sure that the unit is not connected to gas or power•
before proceeding with the following sections.
IMPORTANT: Within the Commonwealth of Massachusetts, this
appliance must be installed by a licensed plumber or gas fitter.
NOTE: When installing a backguard, always install it before
sliding the range into place. See page 9.
Unpacking the Range
Unpack the range and verify that all required parts have been
provided. If any item is missing or damaged, please contact
your dealer immediately. Do not install a damaged or incomplete
appliance. The customer must report cosmetic issues within 30
days of installation.
2 standard size racks•
4 knobs•
Anti-tip bracket w/screws•
Meat probe•
Griddle•
Wok ring•
Stainless steel cleaner•
Literature kit•
Broiler pan/grill•
See the use and care manual for a list of optional accessories.
Cabinet Layout (continued)
Top View - Model ER30DSR - Counter/Cabinet Cutout
Dimensions for Self-Rimming Installation
APPROVED RAISED VENT MODELS: Use only Dacor model
ERV30 or PRV30.
Top View - Model ER30DSR - Counter/Cabinet Cutout
Dimensions - Self-Rimming Installation with Raised Vent

9
Installing the ATK30SR Raised Vent Trim Kit
(model ER30DSR only)
To install the optional raised vent with self-rimming model
ER30DSR, you must install the optional raised vent trim kit.
To change the trim on model ER30DSR:
Remove and retain the seven (7) chrome screws that hold1.
the existing trim pieces in place.
Slide the existing trim pieces off the range.2.
Slide the new trim pieces onto the range.3.
Fasten the new trim pieces in place using the existing screws.4.
Installing the ARSP3 3-Inch Side Panel Kit
(model ER30DSR only)
For self-rimming installations with non-standard countertop
depths, installation of the optional side panel kit may be necessary
to cover the sides of the range that protrude from the cabinet.
To install the side panel kit:
Open the oven door. Remove and retain the two (2) screws1.
on the top of the kick panel. The screws are accessed
through the space between the door and the oven opening.
Changing the Backguard (models ER30D
and ER30D-C only)
Models ER30D and ER30D-C come standard with a 3” backguard
installed. The 6” and 9” backguards are optional.
To change the backguard:
Remove and retain the three (3) chrome screws on the front1.
of the existing backguard.
Remove and retain the two (2) upper screws on the back of2.
the side panels.
Slide the existing backguard off the unit.3.
Place the new backguard over the back of the range.4.
Fasten the backguard using the five (5) existing screws.5.
Installation Instructions
Continued...
New backguard,
height varies
Space between
door and oven
opening Remove and
retain screws

10
ARSP3 Side Panel Kit Installation (cont.)
Close the door. Remove and retain the two screws from the2.
back of the kick panel as shown below. Pull the kick panel
free from the front of the unit.
Remove the left end cap retaining screw from under the rim3.
of the control panel and remove the end cap.
Hold the left side panel in position on the side of the range.4.
Locate the center mounting hole. Remove and retain the
screw attached to the chassis beneath it.
Installation Instructions
Insert the tabs on the trim piece into the slots on the range.5.
Use the hex head screw (83023) removed from the side, a6.
Torx head screw removed from the kick panel and the hex
screws from the kit to attach the side panel to the range.
Three (3) hex head screws attach the side. One (1) Torx head
screw (83709) inserts through the end cap hole to attach
the top of the side panel. One (1) Torx head screw (83709)
inserts through a hole in the front panel to attach the bottom
of the side panel.
Reinstall the end cap.7.
Repeat steps 3 to 7 for the right side panel.8. NOTE: There is
an additional hex screw (83023) in the kit for the right side
panel because the center mounting screw is not reused as
with the left side (do not perform step 4).
Kick panel
Remove and
retain screw,
both sides
End cap
Side panel
Center mounting
hole
Left side only:
Remove and
reuse this screw.
Side panel
Hex screw
Hex screw
Hex screw Torx screw
Front panel
Torx screw

11
With the door closed, reattach the kick panel to the range9.
by snapping the ball studs on the back of the panel into the
holes on the front panel of the range.
Open the door and reattach the kick panel top screws10.
removed in step 1.
Installing a Raised Vent (Optional)
Install the ERV30 or PRV30 raised vent before final installation
of the range. See the raised vent installation instructions, part no.
65335.
IMPORTANT: The ERV30 or PRV30 raised vent attaches to the
narrow back portion of the raised vent/range cutout. It is self-
supporting in the cutout and does not actually attach to the range
itself.
Level and Adjust the Range Height
Raise or lower the range to prepare for final installation:
For model ER30D and ER30D-C, adjust the height until the•
top edge of the trim around the edge of the of the cooktop is
slightly higher than the countertop.
For model ER30DSR, raise the range until the bottom edge•
of the trim around the edge of the of the cooktop is 1/8”
higher than the countertop.
Install the Anti-Tip Bracket and Foot
Locate the anti-tip foot and lower it until it is 1/16” (2 mm) off1.
the floor.
Locate the anti-tip bracket included in the parts box.2.
Install the anti-tip bracket on the floor using the four (4)3.
included screws. See the diagram above for location.
ANTI-TIP BRACKET PLACEMENT
A6 5/8” (168 mm)
B6 3/8” (162 mm)
Installation Instructions
Anti-tip
foot
Back of
range
Space between
door and oven
opening Reattach kick panel
with existing screws
up
down
Back of range
2 1/8” *
* Distance to floor:
2 7/16” to 4 9/16”
Rear leg
B
Right side
of range
Back of
range
Top view
Bracket
A

12
Installation Instructions
Removing the Oven Door
WARNING
Do not attempt to disengage the hinge catches with the•
door removed from the oven. The hinge springs could
release causing personal injury.
Do not lift or carry the oven door by the handle.•
To make the range easier to move, remove the door to reduce
weight.
Open the door to its fully opened position.1.
Rotate the catch over the retaining arm on each hinge.2.
Lift the oven door to about a 15° angle from the vertical3.
position.
Hold the door with both hands just below the handle and pull4.
it away from the oven while continuing to lift.
Electrical Connection
WARNING
Wire the range only in compliance with local ordinances.•
Do not turn on power to the range until instructed to do•
so in the Verifying Proper Operation section of these
instructions.
Improper connection of the electrical wiring can cause an•
electric shock hazard and damage the appliance. Dacor
is not responsible for damages resulting from improper
installation.
The ground terminal (or lead) on the appliance must be•
connected to a grounded, metallic, permanent wiring
system or grounding conductor.
Do not use an extension cord with this appliance. Such use•
may result in fire, electric shock or other personal injury.
Do not install a fuse in the neutral or ground circuit. A fuse•
in the neutral or ground circuit may result in an electric
shock hazard.
NOTE: Freestanding model ER30D-C is wired for use in Canada
and comes from the factory pre-wired. If installing a pre-wired
range, skip to Gas Supply Connection on page 17.
IMPORTANT:
Make sure that the conduit or appliance cord is long enough•
to allow the range to be pulled out for service without
disconnecting it from power.
Do not disconnect any of the wires inside the range electrical•
box unless instructed to do so.
Catch
Retaining arm
Put slack in
electrical wiring
and gas line
Door Gripping Points
Back of range
Electrical access cover

13
Installation Instructions
Connecting the Wiring to the Range
Refer to the range rating label (see page 3) for power
requirements.
There are four possible ways to wire the range:
4 wire conduit•
3 wire conduit (where local codes permit)•
4 wire appliance cord (where local codes permit)•
3 wire appliance cord (where local codes permit)•
The sections below and on the following pages give directions for
connecting each type of wiring harness.
WARNING
Do not connect the green appliance wire to the neutral (white)
supply wire unless local building codes permit.
Connecting Conduit to the Range
NOTE: See pages 16 and 17 for instructions to connect an
appliance cord to the range.
Remove the range electrical access cover from the back of1.
the range.
If using a 4 wire connection, loosen the grounding screw and2.
remove the neutral to ground jumper link.
Remove the nut from the conduit strain relief (not included).3.
Slide the wires and the end of the strain relief into the hole on4.
the bottom of the range electrical box.
Before connecting the wires, slide the strain relief nut over5.
the wires and thread it onto the conduit strain relief inside the
box. Tighten into place.
Connect the white wire to the neutral terminal in the box.6.
Connect the black wire to the L1 power supply terminal.7.
Connect the red wire to the L2 power supply terminal.8.
If using a 4 wire connection, connect the green wire to the9.
grounding screw inside the box.
Replace the range electrical access cover.10.
L1 terminal
L1 terminal
L2 terminal
L2 terminal
Black wire
Red wire
White wire
Green wire
Red wire
White wire
Black wire
Conduit strain
relief nut
Conduit strain
relief nut
Neutral terminal
Neutral terminal
Jumper link
Link removed
Grounding screw
3 Wire Conduit Connection -
Where Local Code Permits
4 Wire Conduit
Connection
Bare wire
connections
Loop and
spade terminal
connections

14
Electrical Connection (Continued)
Connecting the Conduit to the House
Electrical Junction Box
WARNING
Do not ground the appliance to a gas supply pipe or hot•
water pipe.
Do not turn on power to the appliance until the range is•
permanently grounded.
A grounded cold water pipe must have metal continuity to•
electrical ground and must not be interrupted by insulating
materials. Any insulating materials must be jumpered with a
length of No. 4 copper wire securely clamped to bare metal
at both ends.
IMPORTANT: The power supply must be properly polarized.
Reverse polarity will result in continuous sparking of the
electrodes, even after flame ignition. If there is any doubt as to
whether the power supply is properly polarized or grounded, have
it checked by a licensed electrician.
With the range positioned directly in front of the cabinet1.
cutout, feed the appliance wires into the junction box.
Depending upon local codes, utilize one of the three (3)
methods shown to connect the appliance to the junction box.
Connect the white wire from the appliance to the neutral2.
(white) supply wire in the junction box.
Connect the black wire from the appliance to the black (L1)3.
power supply wire in the junction box.
Connect the red wire from the appliance to the red (L2) power4.
supply wire in the junction box.
If using a 4 wire connection, connect the green wire to a5.
grounded supply wire in the junction box or to a grounded
cold water pipe. If connecting to a grounded cold water pipe:
Use a separate copper grounding wire (No. 10 minimum)◊
to connect to the cold water pipe by means of a clamp
and an external grounding connector screw.
If there are any materials that isolate the cold water pipe◊
from ground, jumper it with a No. 4 copper wire, clamped
on both ends.
Replace the junction box cover.6.
Installation Instructions
RED
RED
GREEN
WHITE
WHITE
BLACK
BLACK
GREEN
Connection to
power supply
Connection to
power supply
Wire nut
3 places
Wire nut
4 places
Junction box
Junction box
3 Wire Conduit Connection
to Junction Box
4 Wire Conduit Connection
to Junction Box
Connection to appliance
(Page 13)
Connection to appliance
(Page 13)

15
Installation Instructions
Connection to
power supply
Meter
Fasten clamp tightly
on pipe
Wire nut
4 places
Bare
metal
Metal
water pipe
Clamps
Junction box
4 Wire Conduit Connection to Junction Box
with External Ground
Insulated Pipe Jumper
Connection to appliance
(Page 13)
Separate No. 10 (minimum)
copper grounding wire
No. 4
copper wire

16
Electrical Connection (Continued)
Appliance Cord Connections - Where
Local Code Permits
WARNING
Do not connect the green appliance wire to the neutral (white)
supply wire unless local building codes permit.
Remove the range electrical access cover from the back of1.
the range.
If using a 4 wire connection, loosen the grounding screw and2.
remove the neutral to ground jumper link.
Remove the conduit bracket from the bottom of the range3.
electrical box.
Disassemble and remove the strain relief from the appliance4.
cord (not included). Insert the tabs on the two parts of
the strain relief into the hole on the bottom of the box and
reassemble it so that the tabs are below the box and the
strain relief itself is inside the box.
Slide the end of the appliance cord into the strain relief from5.
the bottom of the box.
Connect the white (neutral) wire to the neutral terminal in the6.
box.
Connect the L1 wire to the L1 power supply terminal in the7.
box.
Connect the L2 wire to the L2 power supply terminal in the8.
box.
If using a 4 wire connection, connect the ground wire to9.
the grounding screw inside the box using a loop or spade
terminal.
Tighten the strain relief so that the appliance cord is held10.
snuggly in place.
Replace the range electrical access cover.11.
Installation Instructions
L1 terminal
L2 terminal
L1 wire
White wire
L2 wire
Strain relief
Neutral terminal
Jumper link
3 Wire Appliance Cord
Connection -
Where Local Code Permits
Remove link on
4 wire installations
Remove conduit
bracket before strain
relief installation
Strain relief
Reassemble with tabs
below and clamp above
Bottom of range
electrical box
L1
Neutral
L2
10-50P Plug

17
Gas Connection
WARNING
Make sure the gas supply valve is off and that the power to•
the range is turned off at the circuit breaker or fuse box prior
to connecting the gas line.
Do not apply excessive pressure when tightening gas•
connections and fittings.
Do not use Teflon tape or plumber’s putty on gas flex line•
connections.
Check for gas leaks as instructed below before using the•
appliance. Do not use a flame to check for leaks.
For LP installations, the LP gas tank must have its own•
high pressure regulator. This is in addition to the pressure
regulator provided with the range.
The maximum gas supply pressure to the regulator must•
never exceed 1/2 pound per square inch (p.s.i.) or 3.5kPa.
The range and shut-off valve must be disconnected from the•
gas supply piping during any pressure testing exceeding 1/2
p.s.i. (3.5 kPa).
The range must be isolated from the gas supply piping by•
closing the shut-off valve during any pressure testing at or
below 1/2 p.s.i. (3.5 kPa).
Be careful not to damage the wires inside the chassis while•
pushing the gas line through the access holes.
NOTE: The gas pressure regulator is pre-set at the factory for
the type of gas intended for use with the appliance. To verify that
the appliance is compatible with the type of gas available, check
the range rating label (see page 3 for location). Ranges intended
for use with LP gas will have “LP” as a part of the model number.
Consult your dealer if the range is not compatible with the type of
gas supplied.
Make sure the gas supply valve is in the off position and1.
power to the range is off.
Connect a flexible gas supply line to the gas shut-off valve2.
previously installed on the stub out. The gas line needs to be
long enough to allow the range to be pulled out for service.
Slide the gas line up through the access holes in the chassis3.
and up to the regulator. Move the wires around inside the
access holes to prevent them from catching on the gas line
as you push it up.
Connect the gas line to the regulator.4.
Turn all cooktop5.
control valves to the
OFF position.
Turn on the gas6.
supply and check all
lines and connections
for leaks using a soap
and water solution.
Turn the gas shut-7.
off valve to the OFF
position.
Installation Instructions
OFF Icon
Bare wire
connections
Loop and
spade terminal
connections
L1 terminal
L2 terminal
L2 wire
Green wire
White wire
Strain relief
Neutral terminal
Link removed
Ground screw
4 Wire Appliance
Cord Connection
L2
Neutral
Ground
L1
14-50P Plug
L1 wire
Gas
line
Regulator
connection
Access
holes
Back of range

18
Installation Instructions
Final Installation
Peel the protective plastic coating off of the range, including1.
the range door.
Carefully slide the range into position in the cutout. The rear2.
anti-tip leg should engage the anti-tip bracket.
On self-rimming installations, reach under the range and3.
adjust the legs, lowering the range until the trim just makes
contact with the countertop on all three sides.
Use a level to make sure that the range does not tilt front to4.
back or side to side. Readjust the legs if necessary.
Re-installing the Oven Door
WARNING
To avoid personal injury or damage to the door from it falling off
its hinges:
Make sure that the notch on the bottom of each hinge rests•
on top of the lower lip of each hinge receptacle before
attempting to open the oven door.
Rotate the hinge locks toward the front of the range•
immediately after installation of the door.
Grasp the oven door on opposite sides and hold it at a 15°1.
angle from the front of the oven. Slide the hinges into the
hinge openings, resting the bottom of the hinge arms on the
hinge receptacles. Continue to hold the door at a 15° angle
with one hand while pushing in on each of the bottom corners
of the door. Push until the notch on the bottom of each hinge
slips over the lower lip of each hinge receptacle.
Lower the door to the fully opened position.2.
Rotate the two hinge locks toward the oven.3.
Slowly and carefully open and close the door completely to4.
ensure that it is properly installed.
Remove any packaging from inside the oven.5.
Installing the Burner Knobs
CAUTION
Installing the range knobs in the wrong position may result in
damage to the griddle included with the range. The knobs for
the right burners are marked with the maximum griddle settings.
There are two (2) different types of knobs supplied with the range.
The knobs for the right burners have the words “MAX GRIDDLE”
on them.
NOTE: When installing the knobs, align the “D-shaped” opening
on the back of the knob with the end of the valve shaft. Carefully
push the knob on until it stops.
Put the knobs with the words “• MAX GRIDDLE” on them onto
the right valve shafts.
Put the remaining knobs on the left valve shafts.•
Door Installation
Lower lip
of hinge
receptacle
Notch on bottom
of hinge
Icons on Left Burner Knobs
Icons on Right Burner Knobs
