Dacor HWC241 Series User manual

Tabl e of C o n t e n t s
Important Safety Instructions ................................................. 1
Getting to Know Your Wine Cellar .......................................... 3
Operating Your Wine Cellar.................................................... 4
Care and Cleaning................................................................. 7
Specifications and Installation................................................ 8
Troubleshooting..................................................................... 9
Warranty ..............................................................................11
Part No. 107939 Rev. E
Installation and User Manual
HWC241*
HWC242*
Wine Cellar
Important Safety Instructions

Wood slide-out racks, upper zone: Hold up to eight bottles
of wine.
Wood slide-out racks, upper zone: Hold up to seven bottles
of wine.
Wood slide-out racks, lower zone: Hold up to eight bottles of
wine each.
Bottom shelf (lower zone): Holds up to six bottles of wine
A wide temperature range: The unit has two separate
cooling compartments, or zones. Each zone has a wide
temperature adjustment range. You can set one zone to
store wine at low temperature for superb aging and set the
other to a higher temperature for serving wine lightly chilled.
High storage capacity: High storage capacity allows you
to preserve the flavor of your favorite wines. Your wine
cellar can store up to 45 bottles of wine (750 ml each}. The
capacity of the upper zone is 15 bottles. The lower zone can
hold up to 30 bottles.
Dual-Zone Wine Cellar
Single-Zone Wine Cellar
Single-Zone Wine Cellar
Low Vibration Cooling System and Storage: Wines
require a tranquil environment. The latest technology of
your wine cellar provides virtually vibration free cooling,
helping to preserve wine taste. In addition, the sliding
beech wood storage shelves also provide additional
vibration absorption.
Automatic defrosting system
Soft white LED interior lighting with on/off switch
Open-door and malfunction warning system
Double-layer, UV resistant, tempered glass door, shields
wines from UV rays harmful to wine.
Door lock
Models: HWC241L:
Models: HWC241R:
Models: HWC242L:
Models: HWC242R:
Dual-Zone Wine Cellar
The right environment for your wines...
A vine is an extremely sensitive plant. Grape quality is
dependent on three factors: light, air humidity and ambient
temperature. This sensitivity continues even after the wine is
bottled. To allow a wine's flavor to fully develop and to
preserve the excellent aroma, it has to be properly stored.
Your wine cellar offers the best storage environment.

Single-Zone Control Panel
4
Setting the Temperature
The temperature of both zones can be set between 41°F and
68°F (5°C and 20°C). The lower temperature zone is ideal for
storing white and red wine at a setting of 55° F to 68° F (13°C to
20°C). The upper temperature zone is suitable for storing
champagne and white wine at a setting of 41 ° F to 55° F (5°C to
13°C).
IMPORTANT: The unit is designed so that the temperature set
for the LOWER temperature zone will always be just as high or
higher than that in the UPPER temperature zone. For optimal
performance, the set temperature of the two zones should differ
by at least 8° F (4°C).
(for Single-Zone models)
(for Dual-Zone models)
Dual-Zone Control Panel
1
12345678

(for Single-Zone models)
(for Dual-Zone models)
5

6

7
To purchase a new filter,
contact a local service agent.

8

9

10

CERTIFICATE OF WARRANTY ON DACOR
WINE CELLAR - UNITED STATES:
FULL TWO-YEARS WARRANTY
This warranty covers any defects in materials or work-
manship in the Dacor-branded new appliance purchased
from a Dacor Authorized Dealer or other seller authorized
by Dacor.
This full warranty runs for two years starting from the date
of original retail purchase receipt or closing date for new
construction, whichever period is longer. Dacor will repair or
replace your product.
LIMITED WARRANTY
Cosmetic Defects. In addition, for 60 days from the
date of purchase, your product is warranted to be free
from cosmetic defects in material and workmanship (such
as scratches of stainless steel, paint/porcelain blemishes,
chip, dents, or other damage to the finish). Color varia
-
tions are excluded, and display, floor-model, “as-is” or
refurbished products are specifically excluded.
COVERAGE LIMITATIONS
Service will be provided by a Dacor designated service
company during regular business hours. Please note
service providers are independent entities and are not
agents of Dacor.
The owner must provide proof-of-purchase or a closing
statement for new construction upon request. All Dacor
products must be accessible for service.
Warranty will be null and void on product that has
altered, defaced, or missing serial numbers and tags.
Warranty is null and void if non-CSA approved product is
transported from the U.S.A.
United States - Warranty
Warranty
Service fees for travel to
islands and remote areas,
which include but are not
limited to, ferries, toll roads,
or other travel expenses.
Consequential or incidental
damage, including but not
limited to: food or medicine
loss, time away from work, or
restaurant meals.
Due to differences in painted
parts, kitchen lighting, product
placement, and other factors;
this warranty does not apply
to color variation.
Service calls to educate the
customer on proper use and
care of the product.
Replacement of house fuses,
fuse boxes, or resetting of
circuit breakers.
Damage caused by accident,
fire, flood, power, interruption
power surges, or acts of God.
Liability or responsibility for
damage to surrounding
property including cabinetry,
floors, ceilings and other
structures or objects.
Breakage, discoloration
or damage to glass, metal
surfaces, plastic components,
trim, paint, or other cosmetic
finish caused by improper
usage, care, abuse, or neglect.
Except as noted above,
consumable parts such as
filters and light bulbs are not
covered and are the
responsibility of the purchaser.
WHAT IS NOT COVERED
Commercial, business, or rental
use, or any application other
than residential consumer use.
Failure of the product caused
by improper product installation.
THE REMEDIES PROVIDED IN THE ABOVE EXPRESS
WARRANTIES ARE THE SOLE AND EXCLUSIVE REMEDIES.
THEREFORE, NO OTHER EXPRESS WARRANTIES ARE
MADE, AND OUTSIDE THE FIFTY STATES OF THE UNITED
STATES AND CANADA, ALL IMPLIED WARRANTIES,
INCLUDING BUT NOT LIMITED TO, ANY IMPLIED WAR-
RANTY OF MERCHANTABILITY OR FITNESS FOR A PAR-
TICULAR USE OR PURPOSE, ARE LIMITED IN DURATION
TO ONE YEAR FROM THE DATE OF ORIGINAL PURCHASE.
IN NO EVENT SHALL DACOR BE LIABLE FOR INCIDENTAL
EXPENSE OR CONSEQUENTIAL DAMAGES. IN THE EVENT
DACOR PREVAILS IN ANY LAWSUIT, DACOR SHALL BE
ENTITLED TO REIMBURSEMENT OF ALL COSTS AND
EXPENSES, INCLUDING ATTORNEY’S FEES, FROM THE
DACOR CUSTOMER. NO WARRANTIES, EXPRESS OR
IMPLIED, ARE MADE TO ANY BUYER FOR RESALE.
Some states do not allow limitations on how long an
implied warranty lasts, or do not allow the exclusion or
limitation of inconsequential damages, therefore the
above limitations or exclusions may not apply to you. This
warranty gives you specific legal rights, and you may also
have other rights that vary from state-to-state.
Warrantor: Samsung Electronics America, Ridgefield Park,
NJ, 07660
Customer Service
Customer Service
Before you request help or schedule service:
1. Try the Solutions offered in the Problem—Solution
table in the “Troubleshooting” section.
2. Become familiar with the warranty terms and condi-
tions of your product.
3. If none of these tips or suggestions resolves your
problem, visit dacor.com or call our Customer Service
center at:
[phone] (United States)
[phone] (Canada)
After the Full Warranty period has ended, this product is
warranted against defects in materials or workmanship
reported to us during the applicable warranty periods as
follows:
11

This Limited Warranty covers only those Products
supplied and distributed in Canada by us and delivered
new, in the original carton or packaging, to the original
consumer purchaser that are purchased from an autho-
rized reseller or distributor, except as otherwise stated
herein. Except where prohibited by applicable provincial
law, only the original consumer purchaser of the Product
has any rights under this Limited Warranty and this
Limited Warranty may not be transferred or assigned.
Any additional statements such as dealer advertising or
presentation, whether oral or written, that make addi-
tional warranties or modifications to this Limited Warran-
ty do not constitute warranties by us and should not be
relied upon.
1. WHAT IS COVERED AND FOR HOW LONG
We warrant to the original purchaser (“Purchaser”) that
your Dacor wine cellar purchased from an authorized
reseller or distributor in Canada (the “Products”) is free
from defects in material and workmanship encountered in
normal use for the warranty period identified below,
effective as of the date of purchase or closing date for
new construction, whichever period is longer.
Canada - Warranty
Warranty
purchase, the Product is warranted to be free from
cosmetic defects in material and workmanship (such as
scratches of stainless steel, paint/porcelain blemishes,
chip, dents, or other damage to the finish). Color varia-
tions are excluded, and display, floor-model, “as-is” or
refurbished products are specifically excluded.
2. COVERAGE LIMITATIONS
If the Product fails to operate according to the Product’s
specifications during the applicable warranty period and
the failure is due to improper workmanship or defective
material, we will repair or replace, at our sole option, and
without charge to the Purchaser, the Product or any
defective component part of the Product. We may, at our
sole option, use rebuilt, reconditioned, or new parts or
components when repairing any Product. If the same
model Product or part is not available for replacement, we
may, at our sole option, replace the Product or part with
any rebuilt, refurbished, reconditioned or new Product
or part of similar utility and value to the Product or part
being replaced.
We expressly reserve the exclusive right, at our sole
option, and in lieu of any service, repair or replacement of
Dacor Product or Part
Warranty Period
and Warranty Coverage
Wine Cellar Two (2) Years: Parts and
Labour
a Product under this Limited Warranty, to offer the
purchaser a partial refund of the original purchase price
paid by the Purchaser for that Product (a “Partial Refund”).
The amount of any Partial Refund to be offered shall be
determined in our discretion based on the fair market
value of the Product given its age and condition. If
Purchaser accepts that offer of a Partial Refund, the
Purchaser shall be deemed to have released us from any
claim or liability whatsoever under this Limited Warranty
or under any other applicable express or implied warranty
or condition in respect of that Product.
All repaired parts or replaced Products will be warranted
for a period equal to the remainder of the original Limited
Warranty on the original Product or for 90 days, whichever
is longer.
CERTIFICATE OF WARRANTY ON DACOR
WINE CELLAR - CANADA:
Cosmetic Defects. For sixty (60) days from the date of
3. WHAT IS NOT COVERED
Further, this Limited Warranty does not cover: (i) any
Product or part from which the serial number has been
removed or on which the serial number has been made
illegible. Removing the serial number on any Product or
rendering it illegible on any Product will immediately void
the Limited Warranty for that Product; (ii) any damage
whatsoever that occurs during shipment of the Product
once the Product has been accepted by the Purchaser; (iii)
any damage whatsoever resulting from any failure to
follow operating, maintenance or environmental instruc-
tions contained in any instruction booklet or owner’s
manual available in connection with the Product; (iv)
service fees for travel to islands and remote areas, which
include but are not limited to, ferries, toll roads, or other
travel expenses; (v) replacement of house fuses, fuse
boxes, or resetting of circuit breakers; (vi) liability or
responsibility for damage to surrounding property includ-
ing cabinetry, floors, ceilings and other structures or
objects; (vii) the cost of service calls for instructions, for
the correction of installation errors, for customer adjust
The remedies provided for in this Limited Warranty are
available only within Canada.
This Limited Warranty does not cover any defect, malfunc-
tion, failure or damage caused by or resulting from any of
the following:
(a) removal, installation, re-installation, maintenance, or
service of the Product that was not authorized by us; (b)
accident, fire, flood, power interruption, power surges,
incorrect line voltage or supply or electrical current, fuses,
house wiring, circuit breakers, connectors not supplied by
us, unusual electrical or electromechanical stress, acts of
God, or acts of nature; (c) misuse, abuse, neglect,
mishandling, misapplication, alteration or modification of
the Product or any part of the Product; (d) use of the
Product in conjunction with products, equipment, utilities,
services, parts, supplies, accessories, applications, exter-
nal wiring, connectors, or ancillary or peripheral equip-
ment not supplied or authorized by us; (e) uses for which
the Product was not intended.
12

ments that are explained in the Product owner’s manual,
or where the Product operates according to the Product’s
specifications. There may be a service charge for service
calls made for issues not covered under this Limited
Warranty; (viii) breakage, discoloration or damage to
glass, metal surfaces, plastic components, trim, paint, or
other cosmetic finish caused by improper usage, care,
abuse, or neglect; (ix) except as noted above, consum-
able parts such as filters and light bulbs are not covered
and are the responsibility of the Purchaser; (x) commer-
cial, business, or rental use, or any application other than
residential consumer use; (xi) colour variation due to
differences in painted parts, kitchen lighting, product
placement, and other factors;
We do not warrant or guarantee uninterrupted or
error-free operation of the Product.
4. WHAT ARE THE LIMITATIONS ON IN-HOME
WARRANTY SERVICE?
In-home service is subject to availability, and it is not
available in all areas of Canada. In-home service will only
be provided if the Product is unobstructed and easily
accessible from floor level to service personnel. If repair
cannot be completed during in-home service or if
in-home service is not available in your area, you may be
directed to deliver the Product to a Dacor Authorized
Service Center for warranty service. The cost of transpor-
tation of the Product to and from a Dacor Authorized
Service Centre shall be paid by the Purchaser unless we
elect to provide that transportation at our discretion.
To receive in-home service, the Purchaser must first
contact Dacor Customer Care for problem determination
and service procedures. All in-home warranty repairs
must be performed by a Dacor Authorized Service Center.
Valid proof of purchase must be presented to us at the
time that service is requested and before warranty
services are rendered.
When in-home service is not available, the Purchaser
must return the Product to a Dacor Authorized Service
Center for analysis. Assistance on where to deliver the
Product can be obtained by contacting our Customer
Service center. The cost of transporting the Product to or
from the Authorized Service Center must be paid by the
Purchaser.
5. WHAT ARE THE LIMITS OF OUR LIABILITY?
EXCEPT AS EXPRESSLY SET FORTH IN THIS LIMITED
WARRANTY, OUR LIABILITY IS SUBJECT TO THE
FOLLOWING LIMITATIONS:
(A) THE PURCHASER TAKES THE PRODUCT “AS IS” AND
WE MAKE NO WARRANTY OR REPRESENTATION OF ANY
KIND WHATSOEVER WITH RESPECT TO THE PRODUCT.
13
ments that are explained in the Product owner’s manual,
or where the Product operates according to the Product’s
specifications. There may be a service charge for service
calls made for issues not covered under this Limited
Warranty; (viii) breakage, discoloration or damage to
glass, metal surfaces, plastic components, trim, paint, or
other cosmetic finish caused by improper usage, care,
abuse, or neglect; (ix) except as noted above, consum-
able parts such as filters and light bulbs are not covered
and are the responsibility of the Purchaser; (x) commer-
cial, business, or rental use, or any application other than
residential consumer use; (xi) colour variation due to
differences in painted parts, kitchen lighting, product
placement, and other factors;
We do not warrant or guarantee uninterrupted or
error-free operation of the Product.
4. WHAT ARE THE LIMITATIONS ON IN-HOME
WARRANTY SERVICE?
In-home service is subject to availability, and it is not
available in all areas of Canada. In-home service will only
be provided if the Product is unobstructed and easily
accessible from floor level to service personnel. If repair
cannot be completed during in-home service or if
in-home service is not available in your area, you may be
directed to deliver the Product to a Dacor Authorized
Service Center for warranty service. The cost of transpor-
tation of the Product to and from a Dacor Authorized
Service Centre shall be paid by the Purchaser unless we
elect to provide that transportation at our discretion.
To receive in-home service, the Purchaser must first
contact Dacor Customer Care for problem determination
and service procedures. All in-home warranty repairs
must be performed by a Dacor Authorized Service Center.
Valid proof of purchase must be presented to us at the
time that service is requested and before warranty
services are rendered.
When in-home service is not available, the Purchaser
must return the Product to a Dacor Authorized Service
Center for analysis. Assistance on where to deliver the
Product can be obtained by contacting our Customer
Service center. The cost of transporting the Product to or
from the Authorized Service Center must be paid by the
Purchaser.
5. WHAT ARE THE LIMITS OF OUR LIABILITY?
EXCEPT AS EXPRESSLY SET FORTH IN THIS LIMITED
WARRANTY, OUR LIABILITY IS SUBJECT TO THE
FOLLOWING LIMITATIONS:
(A) THE PURCHASER TAKES THE PRODUCT “AS IS” AND
WE MAKE NO WARRANTY OR REPRESENTATION OF ANY
KIND WHATSOEVER WITH RESPECT TO THE PRODUCT.
Warranty
(B) THERE ARE NO CONDITIONS, EXPRESS OR IMPLIED,
STATUTORY OR OTHERWISE, WITH RESPECT TO THE
PRODUCT.
(C) IN PARTICULAR, AND WITHOUT LIMITING THE GEN-
ERALITY OF THE FOREGOING PARAGRAPHS (A) AND (B),
WE MAKE NO WARRANTY, CONDITION OR REPRESENTA-
TION AS TO ANY OF THE FOLLOWING: (i) THE MER-
CHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR
ANY PARTICULAR PURPOSE OR USE; (ii) TITLE OR
NON-INFRINGEMENT; (iii) DESIGN, CONDITION, QUALITY,
OR PERFORMANCE OF THE PRODUCT; (iv) THE WORK-
MANSHIP OF THE PRODUCT OR THE COMPONENTS CON-
TAINED THEREIN; (v) COMPLIANCE OF THE PRODUCT
WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFI-
CATION OR CONTRACT PERTAINING TO THE PRODUCT.
(D) NOTHING CONTAINED IN ANY INSTRUCTION MANUAL
OR OWNER’S MANUAL SHALL BE CONSTRUED TO CREATE
AN EXPRESS WARRANTY OF ANY KIND WHATSOEVER
WITH RESPECT TO THE PRODUCT.
THE PROVISIONS FOUND IN PARAGRAPHS (E) AND (F)
BELOW DO NOT APPLY IN CIRCUMSTANCES WHERE THIS
LIMITED WARRANTY IS GOVERNED BY THE LAWS OF THE
PROVINCE OF QUEBEC.
(E) ALL IMPLIED WARRANTIES AND CONDITIONS THAT
MAY ARISE BY OPERATION OF LAW, INCLUDING ANY
APPLICABLE IMPLIED WARRANTY OR CONDITION OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, ARE HEREBY LIMITED TO THE SAME DURATION
OF TIME AS THIS LIMITED WARRANTY.
SOME PROVINCES PROHIBIT LIMITATIONS ON HOW LONG
AN IMPLIED WARRANTY LASTS, AND THE LIMITATION ON
THE DURATION OF THE IMPLIED WARRANTY WILL NOT
APPLY TO THE EXTENT THAT THE LIMITATION IS PROHIB-
ITED BY APPLICABLE PROVINCIAL LAW.
(F) WE SHALL NOT BE LIABLE FOR DAMAGES OF ANY
KIND (INCLUDING, WITHOUT LIMITATION, ANY INCIDEN-
TAL, SPECIAL, CONSEQUENTIAL OR SIMILAR DAMAGES)
THAT RESULT OR ARISE DIRECTLY OR INDIRECTLY FROM
ANY OF THE FOLLOWING: (i) THE PURCHASE, USE, OR
MISUSE OF THE PRODUCT; (ii) ANY LOSS OF USE OF THE
PRODUCT OR INABILITY TO USE THE PRODUCT; (iii) ANY
BREACH OF THE EXPRESS WARRANTY; (iv) ANY LOSS OF
ANTICIPATED PROFITS OR BENEFITS; (v) ANY LOSS OF
FOOD OR CONSUMABLES; (vi) ANY TORT (INCLUDING
NEGLIGENCE OR GROSS NEGLIGENCE) OR FAULT COM-
MITTED BY US, ITS AGENTS OR EMPLOYEES; (vii) ANY
BREACH OF CONTRACT; (viii) ANY CLAIM BROUGHT
AGAINST THE PURCHASER BY ANY OTHER PARTY. SOME
PROVINCES PROHIBIT THE EXCLUSION OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, AND THE
ABOVE EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES WILL NOT APPLY TO THE EXTENT THAT THE

14
EXCLUSION IS PROHIBITED BY APPLICABLE PROVINCIAL
LAW.
(G) THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS,
WHICH VARY FROM PROVINCE TO PROVINCE. THIS
LIMITED WARRANTY STATES THE PURCHASER’S EXCLU-
SIVE REMEDY. EXCEPT WHERE PROHIBITED BY APPLICA-
BLE PROVINCIAL LAW, THIS LIMITED WARRANTY IS NOT
TRANSFERABLE WITHOUT OUR EXPRESS CONSENT.
(H) IF ANY PORTION OF THIS LIMITED WARRANTY IS
HELD ILLEGAL OR UNENFORCEABLE BY REASON OF ANY
LAW, SUCH PARTIAL ILLEGALITY OR UNENFORCEABILITY
SHALL NOT AFFECT THE ENFORCEABILITY FOR THE
REMAINDER OF THIS LIMITED WARRANTY.
If the Product is purchased from a non-authorized reseller
or distributor or purchased outside of Canada, this
Limited Warranty does not apply except that the above
limitations specified in Sections 5(A) through 5(I) shall
apply.
Warrantor in Canada: Samsung Electronics Canada Inc.,
Mississauga, ON, L5N 0B9 Canada
Warranty
OUTSIDE THE UNITED STATES AND CANADA:
LIMITED FIRST YEAR WARRANTY
If your Dacor product fails to function within one year of
the original date of purchase due to a defect in material
or workmanship, Dacor will furnish a new part, F.O.B.
factory to replace the defective part.
All delivery, installation, labor costs, and other service
fees are the responsibility of the purchaser.

Notes
15

Contact Dacor
If you have any questions or comments relating to Dacor appliances, please contact the Dacor Customer Service Center.
CountryContact CenterWeb Site
U.S.A1-833-353-5483www.dacor.com
CANADA1-844-509-4659www.dacor.com
