Daewoo CALLISTO SDA1993 User manual
Important Safeguards
When using electrical appliances, basic safety precautions
should always be followed. These instructions should be
saved for future reference:
• Read and familiarise yourself with all operating instructions
before using this blender
• Before plugging your unit into the mains, visually check that
the unit is intact and has not suered any transit damage.
• Do not use this blender with an extension cable.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before connecting
the appliance to the mains power supply.
• Close supervision is required when using this appliance near
children.
• Never leave this appliance within reach of children. Keep the
appliance and its cord out of reach of children.
• This appliance shall not be used by children.
• Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have given supervision or
instruction concerning use of the appliance in a safe way and
understand the hazards involved.
• Children shall not play with the appliance.
• Children less than 3 years should be kept away unless
continuously supervised.
• Do not immerse the appliance or its cord in water or any
other liquids.
• Do not leave the appliance unattended during use.
• Do not leave the appliance unattended whilst connected to
the mains supply.
• Always use this appliance on a solid, level, non-ammable
surface.
• Do not use this appliance outdoors.
• It is imperative to unplug the power cord after the appliance
has been used, before it is cleaned and whilst being repaired.
• Repairs to electrical appliances should only be performed
by a qualied electrician. Improper repairs may place user at
serious risk.
• Do not operate this appliance with a damaged plug or cord,
after a malfunction or after being dropped or damaged in any
way.
• Regular, periodic checks should be carried out on the power
cord to ensure no damage is evident. Should there be any
signs of damage the appliance should not be used.
• If the power cord is damaged, it should only be replaced by
the manufacturer or a suitable qualied after-sales-service in
order to avoid a hazard.
• Do not allow the power cord to hang over sharp edges or
come in contact with hot surfaces.
• Allow the unit to cool before storage.
• Always disconnect the carving knife from the supply if it is left
unattended and before assembling, disassembling or
cleaning.
• This appliance is intended for household use only and should
not be used for industrial purposes.
• Do not use any accessories or attachments with this
appliance other than those supplied or recommended by the
supplier.
• Do not use this appliance for anything other than its intended
use.
• Do not push objects into any openings as damage to the
appliance and/or electric shock may occur.
• Switch o the appliance and disconnect from the supply
before changing accessories or approaching parts that move
in use.
• Grasp the plug, not the cord.
• Do not touch the blades whilst the blender is connected to the
mains.
• Wash the blades in warm soapy water, rinse and dry
thoroughly.
• CAUTION: the blades on this blender are very sharp;
extreme caution should be taken when cleaning.
1
2
4
3
Description of parts
5
6
1. Measuring cup
2. Jug lid
3. Glass jug
4. Water proof seal
5. Blade assembly
6. Blade base
7. Motor housing
8. Pulse and 4 speed dial
7
8
Please read these operating instructions thoroughly and keep
them in a safe place for future reference.
Remove all packing and dispose of responsibly.
It is recommended to wash all parts except the motor housing in
warm soapy water, rinse and dry thoroughly.
Never immerse the motor in water or other liquids.
CAUTION: the blades inside the jug are NOT removable
and are very sharp; extreme caution should be taken whilst
cleaning the inside of the jug.
•
CAUTION: Always assemble the blender before connecting
to the mains supply. Do not operate the blender until it is
fully assembled.
1. Turn the glass jug (3) upside down onto a soft cloth.
2. Place the waterproof seal (4) onto the neck of the glass jug.
3. Place the blade assembly (5) into the neck of the glass jug.
4. Place the blade base (6) onto the neck of the glass jug and
turn clockwise until it is tight.
5. Place the motor housing (7) onto a at stable surface.
6. Place the jug (3) onto the motor housing (7).
7. Place the measuring cup (1) into the jug lid (2) and turn
clockwise to lock into place.
8. Place the lid (2) with the measuring cup (1) onto the glass jug
(3).
Note: Always remove the jug when adding liquid to prevent
spillages onto the base unit. It is recommended to ll the jug
(food and liquid) to no more than 1/3(500ml) - 2/3 (1000ml)of
the amount of the jug’s capacity. Do not exceed the maximum
capacity of the jug (1000ml) on the jug as some foods expand
during blending.
Before using the blender for the rst time
Assembling the blender
Using the blender
P0
2
1
3
4
P0
2
1
3
4
When blending large quantities to max level, it is advised to place
one hand on top of the lid this will prevent the lid from popping
out due to excessive pressure.
• To prepare for blending, cut the food into chunks
approximately 15mm square and place them into the Jug (3),
add the required amount of liquid using the measuring gauge
on the jug. Place the Lid (2) onto the Jug (3).
• Make sure the speed dial is in the ‘0’ position and insert the
mains plug into the socket.
• To start blending, turn the speed dial to the desired setting
between 1 and 4. The speed can be changed at any time
during blending. If you wish to add more ingredients, switch
the dial to ‘0’ and turn the measuring cup (1) anti-clockwise
and remove it. Add the ingredients through the hole in the lid
and replace the measuring cup (1) Do not operate for more
than 30 seconds and allow the blender to rest for 1 minute
between cycles. Repeat until the desired results are reached,
to nish blending turn the dial to ‘0’.
• Once the ingredients are blended, return the speed dial to ‘0’
and remove the mains plug. Hold the motor housing, grasp
the jug handle, turn anticlockwise and lift upwards o the
base, remove the lid and pour out the contents.
• Using the Pulse: For quick sharp bursts of power, turn the
speed anti-clockwise to the ‘P’.
Note: Do not allow the blender to work with thick mixtures or
heavy foods which will not let the motor run freely. If the motor
does not run freely, stop the blender and add liquid or reduce the
contents of the jar.
When blending ice,
1. Take the ice from the freezer and allow it to rest on the work
top for ve minutes.
2. Fill the jug about a third way with ice cubes. Leave plenty of
free space in the blender so the ice cubes can move around.
Add a little water or fruit juice to speed up the process, this
also helps to prevent any damage to the motor.
3. Place the lid on the jug and ‘Pulse’ the blender ve to seven
times in quick, two-second bursts. If the ice sticks to sides
remove the jug and shake it for 15 to 30 seconds.
4. Once you are satised the motor will not struggle, set
the blender to a medium setting (2 or 3) until the desired
consistency is reached.
CAUTION:
• DO NOT PROCESS HOT LIQUIDS OR INGREDIENTS.
ALLOW TO COOL BEFORE PLACING THEM IN THE
GLASS JUG.
• Do not operate when the blender is empty.
• Do not operate without liquid.
• Do not blend and crush dry fruit.
• Do not ll the glass jug above the max level on the jug.
Some mixtures increase in volume during blending and
create pressure in the jug.
CAUTION: the blades inside the jug are NOT removable
and are very sharp; extreme caution should be taken whilst
cleaning inside the jug.
1. Always unplug from the mains socket before cleaning.
2. Do not remove the jug until the blade has completely stopped.
3. Do not immerse the motor housing in water, wipe with a soft
cloth.
4. Wash all parts in warm soapy water, rinse and dry thoroughly.
5. Store in a cool dry place.
6. Store away from children.
Technical Data
Voltage :220-240V ~ 50/60Hz
Rated power :600 W
Capacity :1.5L
Model :SDA1993
Protection Class :Class II
Care and use
Electrical Connections
This appliance is tted with a fused three-pin plug to BS 1363.
If the plug has to be removed, it should be cut o and carefully
disposed of immediately. To avoid a possible shock hazard, do
not insert the discarded plug into a mains socket.
Fitting a new plug
If for any reason you need to t a new plug, the exible mains
lead must be connected as shown below. The wires in the mains
lead tted to this appliance are coloured in accordance with the
following code:
If colours of the wires in the mains lead of this appliance do not
correspond with the coloured marking identifying the terminals in
your plug, proceed as follows:
The wire which is coloured Blue must be connected to the
terminal which is marked with the letter N or coloured Black. The
wire which is coloured Brown must be connected to the terminal
which is marked with the letter L or coloured Red. Before retting
the plug cover check that there are no cut or stray strands of wire
inside the plug. Use a 5 Amp BS 1362 fuse, only BSI or ASTA
approved fuses should be used. If you are in any way unsure
which plug or fuse to use, always refer to a qualied electrician.
Brown wire = Live (L)
Blue wire = Neutral (N)
Connect Blue
to Neutral (N)
Connect Brown
to Live (L)
Ensure the outer sheath
is securely held by the
cord clamp
Daewoo is a registered trademark.
Produced and imported under licence by ESG Ltd
ESG Ltd
Manchester M3 1JS
www.esgltd.com
GUARANTEE
This product is guaranteed for 2 years from the date of original purchase. If any defect should occur due to faulty
materials or workmanship, please return it to the store it was purchase from.
You will need to have your receipt of purchase to hand. The guarantee is subject to the following provisions:
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer for recycling advice.
• It is only valid within boundaries of the country of purchase.
• The product must be correctly installed and operated in accordance with the instructions contained in the User
Manual.
• The product must be used solely for domestic purposes.
• The guarantee will be rendered invalid if the product is re-sold or has been damaged by inexpert repair.
• The manufacturer disclaims any liability for incidental or consequential damages.
• The guarantee is in addition to, and does not diminish, your statutory or legal right.
