Daewoo SDA1714 User manual

1
1.6L Soup Maker
Model No. SDA1714
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
1.6L Soup maker
User Manual

2
1.6L Soup Maker
Model No. SDA1714
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
Whilst using electrical appliances, basic safety precautions should
always be followed.
•Read and familiarise yourself with all operating
instructions before using this Soup maker.
•Before plugging your unit into the mains, visually check
that it is intact and has not suffered any transit damage.
•Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
•DO NOT use this product with a programmer, timer,
separate remote-control system or any other such device.
•DO NOT immerse this appliance in water or any other
liquids.
•Close supervision is required when using this appliance
near children.
•Never leave this appliance within reach of children.
•This appliance shall not be used by children from 0 to 8
years.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved.
•Children shall not play with the appliance.
•Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised.

3
1.6L Soup Maker
Model No. SDA1714
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
•Keep the appliance and its cord out of reach of children
less than 8 years.
•Cleaning and user maintenance shall not be made by
children.
•DO NOT leave the appliance unattended during use.
•DO NOT leave the appliance unattended whilst connected
to the mains supply.
•Always use this appliance on a solid, level, non-flammable
surface.
•DO NOT use this appliance outdoors.
•It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
•Regular, periodic checks should be carried out on the
supply cord to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
•If the supply cord is damaged it is to be replaced by
qualified personnel in order to avoid a hazard.
•DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
•DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
•This appliance is intended for household use only and
should not be used for industrial purposes.
•DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
•DO NOT use this appliance for anything other than its
intended use.
•DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
•CAUTION: The blade assembly is extremely sharp, handle
with care. When handling the blade lid assembly always
hold by the handle.

4
1.6L Soup Maker
Model No. SDA1714
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
•DO NOT ATTEMPT TO SHARPEN THE BLADES
•DO NOT use the appliance if the blade assembly is bent or
damaged.
•DO NOT overfill past the max mark.
•This appliance includes a heating function.
•DO NOT operate the appliance whilst it is empty.
•CAUTION: Use the handles on the appliance to lift or
move the jug. Use heat protective/oven gloves when
handling the jug.
•Always remove the plug and lid when serving from the
jug.
•DO NOT touch hot surfaces. The outer surfaces are
liable to get hot during use. Always use the handles
and knobs.
•Unplug after each use. Grasp the plug, not the cord.
•CAUTION: If the Soup maker is overfilled, boiling liquid
may be ejected.
THIS APPLIANCE MUST BE EARTHED

5
1.6L Soup Maker
Model No. SDA1714
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, enter your postcode to find out your
nearest recycling site.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
This symbol indicates that the surface gets hot and care must be
taken.

6
1.6L Soup Maker
Model No. SDA1714
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
Before the first time you use Your Soup maker
•Remove all packing materials and dispose of responsibly.
•Ensure appliance is situated in an open area, do not allow it to come in contact
with cupboards, curtains, wall coverings, clothing or other flammable materials.
•lift off the lid and wash the inside of the jug in a mild detergent and then rinse
and dry thoroughly before use.
•Do not immerse the jug in water or any other liquids.
CAUTION:the lid housing contains extremely sharp blades and should be
handled with care at all times.
1. Lid handle
2. Control Panel
3. Jug Handle
4. Stainless Steel jug
5. Power Socket
6. Smooth Function Indicator
7. Chunky Function Indicator
8. Juice Function Indicator
9. Blend Function Indicator
10. LED Display
11. Mode Button
12. Select/ On-Off Button
13. Mains Cable
8
9
1
4
7
2
3
5
6
10
11
12
13

7
1.6L Soup Maker
Model No. SDA1714
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
LED Display (10) Description
The LED Display (10 above) has four different status functions which are
described as follows:
Completed - the display will also show the static
pattern shown right once the programme has
been completed but the timer will show ‘0’.
These two digits
display the
remaining
programme time
These two digits display the current
status of the Soup maker: Heating,
Blending, Resting or Completed as
described below.
Heating - the display will scroll
from bottom to top as shown right
to show the Soup maker is heating
the ingredients.
Blending - the display will show the alternating
pattern shown right to show the Soup maker is
blending the ingredients.
Resting - the display will show the static pattern
shown right to show the Soup maker is resting
between heating and blending the ingredients.
Whilst switching from heating to blending a
single beep will be heard.

8
1.6L Soup Maker
Model No. SDA1714
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Using Your Soup maker - Programme Descriptions
Function
Description
Program
Time
Smooth
Select the Smooth programme to produce a hot,
thorough mix and blend of ingredients. This is ideal
for such classic dishes as Tomato and Basil Soup.
21 Minutes
Chunky
Select Chunky to make hot, thick, chunky soups using
thick chunks of meat and veg. This programme will
only heat the contents and does not blend.
Therefore, ensure to chop the ingredients to your
preferred size, the smaller the chunks the better the
spread of heat throughout the dish.
28 Minutes
Juice
Select the Juice programme to make smoothies or
milkshakes. The ingredients are not heated so all
kinds of cold drinks can be made.
NOTE Do not place Ice Cubes into the Soup maker
2 Minutes
Blend
Additional blending. The Blend programme allows a
further blend if required. This function does not heat
but allows pulse blending of the ingredients.
To enable this function after cooking, reset the Soup
maker by unplugging from the mains and then
plugging it back in. After selecting Blend, press the
Select/ On-Off button (12) to pulse blend the
ingredients.
N/A
It is recommended that blending time is carried out in 30 second intervals in
order to preserve the life of the motor.
Using Your Soup maker
1.First Pre-wash any vegetables, fruit etc. required for your recipe.
2.Chop the ingredients no larger than 1.5 –2.5cm square.
3.Place the ingredients into the Stainless Steel Jug (4) adding water to top up if
necessary.
4.Ensure the ingredients are above the ‘MIN’ mark on the jug but do not exceed
the ‘MAX’marking.
5.Place the Lid on the jug.
6.Ensure the Soup maker is placed on a solid, level, non-flammable surface.
7.Plug the Soup maker into the nearest mains socket, the unit will emit a long
beep to confirm that it is connected to the mains.
8.The function indicators 6, 7, 8 & 9 will flash alternately.

9
1.6L Soup Maker
Model No. SDA1714
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
9.Using the table above press the Mode Button (11) to select from Smooth (hot
soup), Chunky (hot soup) or Juice (cold smoothies, cold soups, milkshakes,
etc.). The function indicator above chosen program will light continuously.
10.Press the Select/On-Off button (12) to start the Soup maker on the selected
programme. The LED Display (10) will show the programme time and the
current status of the unit.
11.Once the programme has finished, the Soup maker will beep for 60 seconds
and the screen will display the ‘completed’ icon (see above), the four
function Indicators 6, 7, 8 & 9 will also flash.
12. Unplug the Soup maker from the mains.
13.Remove the lid using the Lid Handle (1) being careful to avoid any steam
emitted. (use of oven gloves is recommended).
14.Hold the Soup maker by the Jug Handle (3) pour and serve.
If the consistency of the blend is not satisfactory, select Blend using the Mode
Button (11). Press the Select/On-Off Button (12) to pulse blend food to the
desired consistency. Switch the unit off, by pressing and holding the Select/On-
Off Button (12).
Care and maintenance of Your Soup maker
•Always disconnect the Soup maker from the mains power supply before
cleaning.
•Rinse the jug out carefully and dry thoroughly.
•Clean the Lid housing by wiping with a clean damp cloth and dry thoroughly.
•Clean outside of the Soup maker with a clean damp cloth.
•Use a small brush to remove particles lodged around the blades. Care must be
taken when cleaning the blades as they are sharp.
•Do not submerge the either the lid housing or the jug in water or any other
liquids.
•Never clean any part of the Soup maker with harsh chemicals or abrasive
cleaners.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse needed replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse cover
missing. If in doubt, consult a qualified electrician.
If you need to remove the plug -DISCONNECT FROM THE MAINS- and then cut it
off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.

10
1.6L Soup Maker
Model No. SDA1714
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Technical Data
Model Number
SDA1714
Rated Voltage
220-240V~ 50/60Hz
Rated Power
Motor 140-160W, Heating 800-1000W
Protection Class
I (This appliance must be earthed)
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
Recipes for You To Try……..
1. Broccoli and Potato Soup
Ingredients
•200g cheddar cheese
•4 garlic cloves
•1 medium onion, cut into 2.5cm pieces
•60ml extra virgin olive oil
•500g peeled potatoes
•350g broccoli, stems peeled and florets separated
•60ml sherry
•800ml hot vegetable stock
•1 ½ tsp lemon zest
•Seasoned to taste
Instructions
•Place all ingredients in the jug, plug in the Soup maker and select either Chunky or
Smooth soup modes as desired.
•Taste and adjust seasoning accordingly.
