Daewoo HEA1139 User manual

1
Flat Fan Heater
Model No. HEA1139
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
User Manual

2
Flat Fan Heater
Model No. HEA1139
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
•Read and familiarise yourself with all operating
instructions before using this Fan Heater.
•Before plugging your unit into the mains, visually check
that the unit is intact and has not suffered any transit
damage.
•WARNING! In order to avoid overheating, DO NOT
COVER the heater.
•Ensure appliance is situated in an open area, DO NOT
allow it to come in contact with Cupboards, Curtains, wall
coverings, clothing or other flammable materials.
•DO NOT install the appliance directly below an electrical
socket.
•DO NOT use this heater with a programmer, timer,
separate remote-control system or any other device that
switches the heater on automatically, since a fire risk
exists if the heater is covered or positioned incorrectly.
•DO NOT use this heater with an extension cable.
•Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.

3
Flat Fan Heater
Model No. HEA1139
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
•Close supervision is required when using this appliance
near children.
•DO NOT leave this appliance within reach of children.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
•Children of less than 3 years should be kept away unless
continuously supervised.
•Children aged from 3 years and less than 8 years shall
only switch on/off the appliance provided that it has
been placed or installed in its intended normal operating
position and they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children aged from
3 years and less than 8 years shall not plug in, regulate
and clean the appliance or perform user maintenance.
•WARNING! Some parts of this product can become
very hot and cause burns. Particular attention has to be
given where children and vulnerable people are
present.
•DO NOT use the Fan Heater in the immediate
surroundings of a bath, shower or a swimming pool.
•DO NOT use this heater in small rooms when they are
occupied by persons not capable of leaving the room on
their own, unless constant supervision is provided.
•DO NOT immerse the appliance or its cord in water or
any other liquids.
•DO NOT leave the appliance unattended during use.
•DO NOT leave the appliance unattended whilst
connected to the mains supply.

4
Flat Fan Heater
Model No. HEA1139
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
•Always use this appliance on a solid, level, non-
flammable surface.
•DO NOT use this appliance outdoors.
•It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
•Repairs to electrical appliances should only be performed
by a qualified electrician. Improper repairs may place
user at serious risk.
•DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
•Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
•If the supply cord is damaged it must be replaced by the
manufacturer or service agent.
•DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
•DO NOT run the mains cable under carpets, rugs, etc.
•Allow the unit to cool before storage.
•Before cleaning, disconnect the appliance from the mains
supply and allow to cool.
•DO NOT place the appliance near to flammable material
or high pressure containers. (E.g. Paper, wood, petrol,
solvents, spray canisters etc.)
•This appliance is intended for household use only and
should not be used for industrial purposes.
•DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
•DO NOT use this appliance for anything other than its
intended use.
•DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.

5
Flat Fan Heater
Model No. HEA1139
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
•The appliance should not be installed in areas which have
a fire-risk, such as garages, stables or wooden sheds; this
is applicable also for rooms in which highly inflammable
gasses or dust can develop. Danger of fire!!
•Unplug after each use. Grasp the plug, not the cord.
This appliance has been ERP classified as a portable space heater and should
only be used for supplementary, secondary or temporary heating. It should not
be considered for primary permanent heating in a room or dwelling.
During the first few minutes of initial use, you may notice a slight odour
and a little smoke. This is normal and will quickly disappear, It is the coating
applied to the heating elements to prevent any corrosion during transit.

6
Flat Fan Heater
Model No. HEA1139
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable provisions
of the European Economic Area.
This symbol indicates that the heater is double insulated and
therefore does not require an Earth connection.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk enter your postcode to find out your
nearest recycling site.
This symbol provides useful additional information on the use of
this product.
This symbol indicates that the supply uses an alternating current
mains supply.
WARNING!
This designates a hazard with moderate risk, which may result
in severe injury if not adhered to.

7
Flat Fan Heater
Model No. HEA1139
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Controls
1. Air Intake
2. Thermostat Control
3. Indicator
4. On/Off/Fan/Heat Switch
5. Air Outlet
6. (Inset) Horizontal Mounting Position
Before the first time you use your Fan Heater
Remove all packing materials and discard responsibly.
Operating Instructions –heat settings
•Place the heater on a solid, level non-flammable surface in either the vertical
or horizontal position (see above).
•Ensure that the On/Off/Fan/Heat Switch (4) is in the off (O) position
•Insert the mains plug into the mains socket.
•For the low heat setting, rotate the On/Off/Fan/Heat Switch (4) to the low
heat position ( ).
•For the high heat setting, rotate the On/Off/Fan/Heat Switch (4) to the high
heat position ( ).
•Rotate the Thermostat Control (2) clockwise to increase the room
temperature and anticlockwise to decrease the room temperature as desired.
The Indicator (3) will illuminate and extinguish indicating that the set
temperature is being maintained, this is quite normal.
•Return the On/Off/Fan/Heat Switch (4) to the (O) position to switch off the
heater.
1
4
2
5
3
6

8
Flat Fan Heater
Model No. HEA1139
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Hint on setting the correct temperature
•Set the heater to the desired heat setting as above.
•Rotate the Thermostat Control (2) to the maximum position and allow the
room to warm up. Once the desired room temperature has been reached turn
the Thermostat Control (2) anticlockwise until the heater just clicks off then
turn it back up clockwise very slightly. The Thermostat Control (2) will now
maintain the room temperature, if necessary, further increasing or decreasing
the Thermostat Control (2) may be required to ‘fine tune’ the ideal room
temperature.
•Return the On/Off/Fan/Heat Switch (4) to the (O) position to switch off the
heater.
Fan Only Mode
•Rotate the On/Off/Fan/Heat Switch (4) to the fan only position ( ) to enable
the fan to operate for cool air output.
The Thermostat Control (2) will need to be rotated to the fully clockwise
position for the fan to operate.
Care and Use of your Fan Heater
•Always disconnect the heater from the mains power supply and allow to cool
before cleaning.
•Clean outside of the heater with a clean damp cloth. Never clean with harsh or
abrasive cleaners.
•DO NOT submerge any part of the heater in water or any other liquids.
•DO NOT WRAP THE MAINS CABLE AROUND THE APPLIANCE.
Safety Cut –Out
This appliance is fitted with a built in safety cut-out, if the cut-out
is activated the unit stops working, unplug the heater from the mains and check
that the air intake area is not blocked or covered.
Leave for an hour to cool and reset before plugging back into the mains.
Technical Data
Rated Voltage
220-240V ~ 50Hz
Rated Power
1800-2000W
Model Number
HEA1139
Dimensions
245mm (H) x 240mm (W) x 120mm (H)
Weight
1.1kg
Protection Class
II
WARNING!

9
Flat Fan Heater
Model No. HEA1139
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse need replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). If in doubt, consult a qualified
electrician who will be pleased to do this for you. If you need to remove the plug
– DISCONNECT FROM THE MAINS – and then cut it off the mains lead and
immediately dispose of it safely. Never attempt to reuse the plug or insert it into a
socket outlet as there is a danger of electric shock.
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling
facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling
facilities.
Dispose of non-recyclable plastics in the appropriate plastics
collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk enter your postcode to find out your
nearest recycling site.

10
Flat Fan Heater
Model No. HEA1139
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
HEA1139

11
Flat Fan Heater
Model No. HEA1139
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof of
purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the discretion
of the retailer.
The guarantee is subject to the following provisions:
• The product must be correctly installed and operated in accordance with the requirements
contained in the instruction manual.
• The product must beused solely for domestic purposes.
• It does not cover general wear and tear, damage, misuse or any consumable parts.
• The guarantee will berendered invalid if the product is re-sold or has been damaged through
inexpert repair.
• The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and covers
the main body and housing). If you do not register your product within 28 days of the original
purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28 days
of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Imported by Eurosonic Group Ltd. M3 1JS UK
EU Rep: Euromagppie Ireland Ltd. D05 X006
Produced under licence by ESG Ltd
www.esgltd.com
