1
Ceramic PTC Heater
Model No. HEA1896
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

2
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Ceramic PTC Heater
Model No. HEA1896
User Manual
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should always
be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
•Read and familiarise yourself with all operating
instructions before using this PTC Heater.
•Before plugging your unit into the mains, visually check
that the unit is intact and has not suffered any transit
damage.
•WARNING! In order to avoid overheating, do not cover
the heater.
•DO NOT install the appliance directly below an electrical
socket.
•DO NOT use this heater with a programmer, timer,
separate remote-control system or any other device that
switches the heater on automatically, since a fire risk
exists if the heater is covered or positioned incorrectly.
•DO NOT use this heater with an extension cable.
•Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
•Close supervision is required when using this appliance
near children.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or

3
Ceramic PTC Heater
Model No. HEA1896
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
•Children of less than 3 years should be kept away unless
continuously supervised.
•Children aged from 3 years and less than 8 years shall only
switch on/off the appliance provided that it has been
placed or installed in its intended normal operating
position and they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved.
•Children aged from 3 years and less than 8 years shall not
plug in, regulate and clean the appliance or perform user
maintenance.
WARNING! Some parts of this product can become very
hot and cause burns. Particular attention has to be given
where children and vulnerable people are present.
•DO NOT use this heater in the immediate surroundings of
a bath, a shower or a swimming pool.
•DO NOT immerse the appliance or its cord in water or any
other liquids.
•DO NOT leave the appliance unattended during use.
•DO NOT leave the appliance unattended whilst connected
to the mains supply.
•Always use this appliance on a solid, level, heat resistant
surface.
•DO NOT use this appliance outdoors.
•It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.

4
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Ceramic PTC Heater
Model No. HEA1896
User Manual
•Repairs to electrical appliances should only be performed
by a qualified electrician. Improper repairs may place user
at serious risk.
•DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
•Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
•If the power cable is damaged, it should only be replaced
by the manufacturer or a suitable qualified after-sales-
service in order to avoid a hazard
•DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
•DO NOT run the mains cable under carpets, rugs, etc.
•Allow the unit to cool before storage.
•Before cleaning, disconnect the appliance from the mains
supply and allow to cool.
•Never place the appliance near to flammable material or
high pressure containers. E.g. Paper, wood, petrol,
solvents, spray canisters.
•This appliance is intended for household use only and
should not be used for industrial purposes.
•DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
•DO NOT use this appliance for anything other than its
intended use.
•DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
•Ensure appliance is situated in an open area, do not allow
it to come in contact with Cupboards, Curtains, wall
coverings, clothing or other flammable materials.
•The appliance should not be installed in areas which have
a fire-risk, such as garages, stables or wooden sheds; this

5
Ceramic PTC Heater
Model No. HEA1896
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
is applicable also for rooms in which highly inflammable
gasses or dust can develop. Danger of fire!!
•Unplug after each use. Grasp the plug, not the cord.
CAUTION
Keep Hearth Rugs and other soft furnishings
away from the front of the heater. They could
obstruct the free flow of air from the fan and
damage both soft furnishings and heater.
The heater must stand on a solid, level non-
flammable surface such as stone, slate, ceramic
or concrete.
DO NOT Stand the heater on a carpet, rug or
other soft floor covering.
DO NOT COVER THE HEATER
This appliance has been ERP classified as a portable space heater and should
only be used for supplementary, secondary or temporary heating. It should not
be considered for primary permanent heating in a room or dwelling.
During the first few minutes of initial use, you may notice a slight odour
and a little smoke. This is normal and will quickly disappear, it is the coating
applied to the heating elements to prevent any corrosion during transit.

6
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Ceramic PTC Heater
Model No. HEA1896
User Manual
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable provisions
of the European Economic Area.
This symbol indicates that the heater is double insulated and
therefore does not require an Earth connection.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk enter your postcode to find out your
nearest recycling site.
This symbol provides useful additional information on the use of
this product.
This symbol indicates that the supply uses an alternating current
mains supply.
Safety Tip-Over Device
This heater is fitted with a safety tip-over device. The heater will not operate if
knocked over or placed on an uneven surface causing it to not stand upright.
If the safety tip-over device is triggered, unplug the heater from the mains and
check for any damage. If the heater is not damaged, place it on a solid, level,
nonflammable surface and ensure it is upright. Plug back into the mains and press
the Standby Button (4) to restart the heater.

7
Ceramic PTC Heater
Model No. HEA1896
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts –General
Description of Parts –Control Panel
1
4
2
3
1.Mains Switch (Rear)
2.Control Panel
3.Air Outlet
5
6
7
8
9
4. On/Off/Standby Button
5. Increase ᴧButton
6. Digital Display
7. High Heat Indicator
8. Power Indicator
10
11
12
13
14
15
16
9. Eco Mode Indicator
10.Low Heat Indicator
11.Timer Button
12.Heat Mode Button
13.Decrease ᴠButton
14.Timer Mode Indicator
15.Oscillate Indicator
16.Oscillate Button

8
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Ceramic PTC Heater
Model No. HEA1896
User Manual
Before first use of Your PTC Fan Heater
Remove all packing materials and discard responsibly.
Operating Instructions
Ensure the heater is placed on a solid, level non-
flammable surface as described above and the
heater is vertical.
1.Ensure that the Mains Switch (1) on the rear of the
unit is in the OFF ‘O’position.
2.Insert the mains plug into the mains socket.
3.Press the Mains Switch (1) on the rear of the unit to
the ON ‘I’position, the unit will beep and the Digital
Display (6) will show the unit is in standby as below:
Powering Up
1. Press the On/Off/Standby Button (4) to
switch on the fan heater.
2. Once powered up the Digital Display (6)
will light to show the default set
temperature (30⁰C), the Power Indicator
(8) and the High Heat Indicator (7) will
also illuminate as shown right:

9
Ceramic PTC Heater
Model No. HEA1896
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Setting the Heat Mode Press the Heat Mode Button (12) to select from:
a. High Heat (1500W) –the High Heat Indicator (7)
will illuminate.
b. Low Heat (750W) –the Low Heat Indicator (10)
will illuminate.
c. Eco Mode –the Eco Mode Indicator (9) will
illuminate.
In Eco mode the heater will vary the power
between 750W and 1500W automatically whilst
keeping the ambient temperature at 20⁰C.
Setting the Temperature
1.Press the Increase ᴧ(5) and Decrease ᴠ(13)
buttons until the desired set temperature (in ⁰C),
is shown on the Digital Display (6).
2.Once the room has reached the set temperature,
the internal fan and oscillation mode (if selected)
will stop. The heater will restart when the
temperature has dropped below the set
temperature, this is quite normal.
Powering Off
Press the On/Off/Standby Button (4) to
switch the fan heater off and back into
standby.
After switching off the heater, there will
be a delay of 60 seconds whilst the internal
fan continues running to cool the unit down
before finally switching off.
If the heater is not to be used for a while or it
is to be left unattended, press the Mains
Switch (1) to the off (O) position to fully
switch the unit off as shown right:

10
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Ceramic PTC Heater
Model No. HEA1896
User Manual
Oscillation Mode
Press the Oscillate On/Off button (16) to
enable the heater to rotate left and right and
disperse heat over a larger area. The
Oscillate Indicator (15) (Swing) will
illuminate. Press the button again to stop the
unit oscillating, the Oscillate Indicator (15)
(Swing) will go out.
Using the Timer
The timer is used to switch the heater on or off after a time period of up to 12
hours. Ensure that the Mains Switch (1) on the rear of the heater is in the on ‘I’
position for the Timer to operate.
Setting the Timer to Power OFF the heater
1.Press the Timer Button (11) whilst the heater is on, the Timer Mode Indicator
(14) will illuminate, the Digital Display (6) will show the timer display (in hours)
flashing as below left:
2.Press the Timer Button (11-arrowed above) repeatedly to select the number of
hours (in 1 hour increments) up to a maximum of 12 hours –above right:
3.The Digital Display (6) will flash for 10 seconds after setting the timer and return
to showing the set temperature.
4.After the set time has passed the heater will switch off.
5.As the timer counts down, the time remaining can be checked on the Digital
Display (6) by pressing the Timer Button (11) once.
11

11
Ceramic PTC Heater
Model No. HEA1896
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Setting the Timer to Power ON the heater
Ensure that the heater is off, i.e. the On/Off/Standby Button (4) has been pressed
to switch the fan heater off into standby.
Press the Timer Button (11), the Timer Mode Indicator (14) will illuminate, the
Digital Display (6) will show the timer display (in hours) flashing as below:
6.Press the Timer Button (11-arrowed above) repeatedly to select the number of
hours (in 1 hour increments) up to a maximum of 12 hours.
7.The Digital Display (6) will flash for 10 seconds after setting the timer and return
to showing the set temperature.
8.After the set time has passed the heater will switch on.
9.As the timer counts down, the time remaining can be checked on the Digital
Display (6) by pressing the Timer Button (11) once.
Whilst using the heater in timer mode, due consideration must be given to the
fact that the heater may come on whilst unattended.
Safety Tip-Over Device
This heater is fitted with a safety tip-over device. The heater will not operate if
knocked over or placed on an uneven surface causing it to not stand upright.
If the safety tip-over device is triggered, unplug the heater from the mains and
check for any damage. If the heater is not damaged, place it on a solid, level,
nonflammable surface and ensure it is upright. Plug back into the mains and press
the Standby Button (4) to restart the heater.
Care and Use of your Ceramic PTC Heater
•Always disconnect the heater from the mains power supply and allow to cool
before cleaning.
•Clean outside of the heater with a clean damp cloth. Never clean with harsh or
abrasive cleaners.
•Do not submerge any part of the heater in water or any other liquids.
•DO NOT WRAP THE MAINS CABLE AROUND THE APPLIANCE.

12
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Ceramic PTC Heater
Model No. HEA1896
User Manual
Safety Cut –Out
WARNING:This appliance is fitted with a built in safety cut-out, if the cut-out is
activated the unit stops working, unplug the heater from the mains and check that
the air intake area is not blocked or covered.
Leave for an hour to cool and reset before plugging back into the mains.
Technical Specification
Rated Voltage
220-240V AC ~ 50Hz
Rated Power
1500W
Model Number
HEA1896
Dimensions
285mm (H) x 215mm (W) x 135(D)
Weight
1.9kg
Protection Class
II
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse need replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse cover
missing. If in doubt, consult a qualified electrician.
If you need to remove the plug – DISCONNECT FROM THE MAINS – and then cut it
off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk enter your postcode to find out your
nearest recycling site.

13
Ceramic PTC Heater
Model No. HEA1896
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

14
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Ceramic PTC Heater
Model No. HEA1896
User Manual
ErP Data
Table VI:
Model identifier for electric local space heaters
Model number:
For HEA1896
Item
Symbol
Value
Unit
Heat output
Nominal heat out-put
Pnom
1,5
kW
Minimum heat output (indicative)
Pmin
0
kW
Maximum continuous heat output
Pmax,c
1,5
kW
Auxiliary electricity consumption
At nominal heat output
elmax
N/A
kW
At minimum heat output
elmin
N/A
kW
In standby mode
elSB
0,00042
kW
Type of heat input, for electric storage local space heaters only (single select)
manual heat charge control, with integrated thermostat
Yes No
manual heat charge control with room and/or outdoor temperature feedback
Yes No
electronic heat charge control with room and/or outdoor temperature feedback
Yes No
fan assisted heat output
Yes No
Type of heat output/room temperature control (single select)
single stage heat output and no room temperature control
Yes No
Two or more manual stages, no room temperature control
Yes No
with mechanic thermostat room temperature control
Yes No
with electronic room temperature control
Yes No
electronic room temperature control plus day timer
Yes No
electronic room temperature control plus week timer
Yes No
Other control options (multiple selections possible)
room temperature control, with presence detection
Yes No
room temperature control, with open window detection
Yes No
with distance control option
Yes No
with adaptive start control
Yes No
with working time limitation
Yes No
with black bulb sensor
Yes No
Contact details

15
Ceramic PTC Heater
Model No. HEA1896
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Notes

16
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Ceramic PTC Heater
Model No. HEA1896
User Manual
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in addition to your 1 year
guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
• The product must becorrectly installed and operated in accordance with the
requirements contained in the instruction manual.
• The product must beused solely for domestic purposes.
• It does not cover general wear and tear, damage, misuse or any consumable parts.
• The guarantee will berendered invalid if the product is re-sold or has been damaged through
inexpert repair.
• The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
