Dahle 20606 C User manual

20600 SERIES
OFFICE SHREDDERS
20606 C
20606 EC
20612 C
20612 EC
20614 EC
20630 EC
20634 EC
OPERATION MANUAL
20606.90.0881 - 09/2007

2
Congratulat ons on your purchase of a DAHLE Paper Shredder We here at
DAHLE North America are dedicated to providing rugged and dependable pro-
ducts for the large, and not so large office. We are sure your new DAHLE Paper
Shredder will meet or exceed your expectations of quality and service
If you have any questions regarding your new DAHLE paper shredder, call your
sales representative, or call DAHLE Customer Service, toll free, at (800) 995-
1379 between 8:30 am and 5:00 pm Monday through Friday, EST.
Check off the model and record the serial number for your records in the space
provided below.
Serial Number:________________________
DIAGRAM KEY
1. Main Plug
1.1 Main Switch
2. Feed Opening
3. Light Barrier
4. Bag Full Indicator
5. Door Ajar Indicator
6. Paper Jam Indicator
7. Forward Switch (electronic models)
7a. Reverse Switch (electronic models)
8. Power Switch (electronic models)
8a. On/Off/Reverse (manual models)
9. Shred Bag
10. Waste Bin
11. Door Handle
12. Door
20606 C 20606 EC 20612 C 20612 EC
20614 EC 20630 EC 20634 EC
READ ALL INSTRUCTIONS BEFORE OPERATING YOUR SHREDDER

3
ALWAYS TURN SHREDDER OFF IF IT WILL BE UNATTENDED FOR LONG PERIODS OF TIME
SAFETY INSTRUCTIONS
Read the operating instructions carefully before operating your shredder
Do not use in the vicinity of flammable liquids or gases.
Do not use in the vicinity of corrosive materials.
Do not expose to water or wet conditions.
Do not let children operate this, or any other, office equipment.
Do not operate the shredder for a period of more than 5 minutes in no-load
operation (operation without paper).
Keep hair clear of machine.
Keep neckties clear of machine.
Keep bracelets, or any other jewelry, clear of machine.
Power connection must be accessible at all times.
Disconnect from power supply before servicing.
The safety devices must not be disabled or removed.
Product is not intended for use by children.
BEFORE YOU SHRED
Remove Transport Bolts with wrench provided.
Record the Model and Serial Number in the space provided inside the front
cover.
Be sure the electrical outlet provides the proper power for your shredder (see
rating label on rear of shredder).
Install Shred Bag (see: “CHANGING THE SHRED BAG”).
TURNING ON YOUR SHREDDER
20606 C 20612 C
1. ON, OFF and REVERSE are controlled by the black
Rocker Switch (8a) on the top of the shredder.
2. Moving the switch to the “I” (ON) position
activates the shredding mechanism.
3. Moving the switch to the center or “O” (OFF)
position turns the shredder off.
4. The REVERSE position “R” will be discussed
in “CLEARING A PAPER JAM”.

4
20606 EC 20612 EC 20614 EC 20630 EC 20634 EC
1. ON/OFF is controlled by the main switch (1.1) and the green
push button (8) found on top of the shredder.
2. Pressing these buttons (main switch (1.1) first) turns
the shredder on and places it in the stand-by mode.
3. Pressing these buttons again turns the
shredder off.
SHREDDING
20606 C 20612 C
Turn shredder on. Insert paper squarely into
Feed Opening (3). Continue feeding paper into
Feed Opening until the shredding mechanism
begins to draw the paper in. At this point,
allow the paper to feed into shredder on its
own. When shredding is complete, turn
shredder off.
20606 EC 20612 EC 20614 EC 20630 EC 20634 EC
Turn shredder on. Insert paper squarely into
Feed Opening (3). A light barrier will auto-
matically activate the shredding mechanism.
Continue feeding paper into the Feed Opening
until the shredding mechanism begins to
draw the paper in. At this point, allow the paper
to feed into the shredder on its own. Once the
paper has passed completely through the shredding
mechanism, the electronic controls will automatically stop the
machine.
To shred a piece of paper too small to break the light barrier, press the FOR-
WARD button (7) once to override the auto ON/OFF function. The shredder will
continue to run until the FORWARD button is pressed again.
Microfiche and transparencies can also be shredded in the same manner as
paper, however, you should shred a piece of paper after every 8 or 10 sheets of
plastic. This helps clean plastic particles out of the shredding mechanism.
REMEMBER TO LUBRICATE YOUR SHREDDER ACCORDING TO INSTRUCTIONS

5
IT IS NOT RECOMMENDED RUNNING SHREDDERS AT MAXIMUM CAPACITY
CAPACITY
Capacity is the number of sheets of 81/2”x” paper that can be shredded at one
time. These figures are approximate and machines may vary slightly due to various
conditions. It is not recommended that you try to run your shredder at maximum
capacity, as this increases the chance of a paper jam.
Model 20 Lb. Bond 16 Lb. Bond
20606 C 32 38
20606 EC 32 38
20612 C 14 17
20612 EC 14 17
20614 EC 20 25
20630 EC 7 9
20634 EC 6 8
CCLLEEAARRIINNGG AA PPAAPPEERR JJAAMM
If too many sheets of paper are fed into your shredder at one time, it may cause
a paper jam. Running your shredder at maximum capacity increases the chance
of a paper jam. If a paper jam occurs, it is easy to clear by following these simple
steps:
20606 C 20612 C
1. Turn shredder off using ON/OFF/REVERSE switch (8a).
2. Firmly pull on paper sticking out of Feed Opening while holding
ON/OFF/REVERSE switch in the REVERSE (R) position.
3. After paper has been removed from the Feed Opening, move the
ON/OFF/REVERSE switch back to the ON (I) position.
4. Separate some of the sheets and continue shredding.

6
20606 EC 20612 EC 20614 EC 20630 EC 20634 EC
The Auto-Reverse feature, built into the electronic versions of the General Office
Shredders, helps prevent paper jams. If the Auto-Reverse feature is activated an
audible alarm sounds and the Paper Jam Indicator (6) lights up. If this situation
occurs, follow these simple steps:
1. Remove paper from Feed Opening. The REVERSE button (7a) may be used
if excess paper remains in the Feed Opening. Clear shredding mechanism by
pressing the FORWARD button (7).
2. Separate some of the sheets and continue shredding.
CHANGING THE SHRED BAG
When the Shred Bag (10) is full, the shredder will automatically shut down. On the
electronic models an LED indicator will light and an audible alarm will sound.
Changing the Shred Bag is quick and easy if you follow these simple directions.
1. Turn shredder off
2. Open Door (12) using Door Handle (11) to expose Waste Bin (10) and Shred
Bag (9).
3. Pull the Waste Bin and full Shred Bag out of the shredder.
4. Dispose of full Shred Bag.
5. Install new Shred Bag in Waste Bin, draping end of Shred Bag over edge of
Waste Bin.
6. Push Waste Bin, with new Shred Bag installed, back into shredder.
7. Close Door.
8. Turn on shredder and continue shredding.
NOTE: SHREDDER WILL NOT OPERATE UNLESS DOOR IS COMPLETELY CLOSED

7
Model 20634 is prepared
for the application of the
optional automatic oiling system.
Further information can be found in the
operating instructions for the Oiler. Call your
local Dealer for more details.
Using the automatic oiler will help maintain a
permanent cutting quality and will aid in
keeping your shredder running at full capacity.
DAHLE Shredder Oil is the only lubricant you should use in your paper shredder.
It has been specially formulated so as not to leave any residue that could attract
dust and clog the shredding mechanism. You can order DAHLE Shredder Oil from
your local dealer.
Repairs on your paper shredder should only be performed by qualified technici-
ans. If you need service, contact your local dealer, or you can contact DAHLE
North America Customer Service between 8:30 am and 5:00 pm EST at (800) 995-
1379.
ALWAYS TURN SHREDDER OFF IF IT WILL BE UNATTENDED FOR LONG PERIODS OF TIME
CARING FOR YOUR SHREDDER
Clean covers with a clean dry cloth. Do not use water or solvents. Make sure you
disconnect your shredder from its power source before cleaning.
Paper shredders, like all mechanical equipment, need proper maintenance to
ensure efficient operation. Periodic lubrication of the cutting blades is important to
offset the friction generated within the cutting head. Frequency of lubrication will
vary depending on the shred size and the amount of usage. A strip-cut shredder
receiving light use (1 – 2 hours per week) will require lubrication only once or twice
a month, while the same machine used 1 – 2 hours per day will require lubrication
weekly. A cross-cut shredder should be lubricated every 1/2hour of shredding time
to maintain maximum capacity and efficiency.
The procedure for lubricating your shredder is simple, and can be performed by
any operator. The oil is packaged in a squeeze bottle and is applied directly to the
cutting blades through the feed opening (3). Run a fine stream of lubricant from
one side of the feed opening to the other. Run the shredder in REVERSE for a few
seconds to help distribute the lubricant evenly. You can now continue shredding as
usual.

8
READ ALL INSTRUCTIONS BEFORE OPERATING YOUR SHREDDER
Installat on of the automat c o l ng system
1. Be certain shredder is off and unplugged.
2. Remove protective caps (1) from mounting holes and secure Automatic Oiler to shredder
using supplied screws (3).
3. Push oil suppl tube (6) full over brass hose barb (7).
4. Place white n lon hose clamp over suppl hose and position it near the bottom of
suppl tube where it covers the hose barb. Squeeze clamp to tighten.
5. Insert open end of oil suppl tube into gre hose fitting (5) being sure it is full inserted.
Gentl pull hose to check that it is seated properl . Hose can be removed b pressing
gre collar in and pulling on hose.
6. Remove red protective cover (8) from female DIN connector (9) and insert male DIN
plug (10) from the oiler. Connector is ke ed to ensure proper alignment. Secure using
screw-in flange.
7. Fill reservoir (2) with Dahle 740 Shredder Oil.
8. Prime s stem b moving silver plunger up and down until suppl tube is filled with oil.
9. Plug shredder into outlet and begin shredding.
NOTE:
WHEN OIL LEVEL DROPS BELOW
MINIMUM THE SHREDDER WILL STOP,
THE BAG-FULL INDICATOR WILL LIGHT
AND AN AUDIBLE ALARM WILL SOUND.

9
1. ON/OFF switches set
to wrong position
2. Unit unplugged
3. Outlet dead
4. Door not fully closed
5. Waste Bin full
1. Cutting blades dry
Move switches
to “I” (on) position
Connect to outlet
Reset circuit breaker
Close Door
Empty Waste Bin
Lubricate cutting blades
according to instructions.
IF ANY OTHER PROBLEMS OCCUR. CALL YOUR AUTHORIZED DAHLE SERVICE DEALER
BEFORE YOU CALL FOR SERVICE
DAHLE SHREDDER SUPPLIES AND ACCESSORIES
Shred Bags (100 per box)
Item No. Models
701 Personal & 20300 Series
704 20400, 20500 & 20600 Series
705 20800 Series
706 High Capacity Models
Waste B n
605 20600 Series
Shredder O l (All Models)
740 Box of 4 16oz. Bottles
740G Box of 4 1gal Bottles
Automat c O l ng System
SAO-110 1,5 Liter
SAO-120 4 Liter
SYMPTOM POSSIBLE CAUSES SOLUTION
No Power
Low capacity

10
