Embedded Multi-Screen Controller
User's Manual
V2.0.0

Cybersecurity Recommendations
Mandatory actions to be taken for basic device network security:
1. Use Strong Passwords
Please refer to the following suggestions to set passwords:
The length should not be less than 8 characters.
Include at least two types of characters; character types include upper and lower case
letters, numbers and symbols.
Do not contain the account name or the account name in reverse order.
Do not use continuous characters, such as 123, abc, etc.
Do not use overlapped characters, such as 111, aaa, etc.
2. Update Firmware and Client Software in Time
According to the standard procedure in Tech-industry, we recommend to keep your
device (such as NVR, DVR, IP camera, etc.) firmware up-to-date to ensure the system
is equipped with the latest security patches and fixes. When the device is connected
to the public network, it is recommended to enable the “auto-check for updates”
function to obtain timely information of firmware updates released by the
manufacturer.
We suggest that you download and use the latest version of client software.
"Nice to have" recommendations to improve your device network security:
1. Physical Protection
We suggest that you perform physical protection to device, especially storage devices. For
example, place the device in a special computer room and cabinet, and implement well-done
access control permission and key management to prevent unauthorized personnel from
carrying out physical contacts such as damaging hardware, unauthorized connection of
removable device (such as USB flash disk, serial port), etc.
2. Change Passwords Regularly
We suggest that you change passwords regularly to reduce the risk of being guessed or cracked.
3. Set and Update Passwords Reset Information Timely
The device supports password reset function. Please set up related information for password
reset in time, including the end user’s mailbox and password protection questions. If the
information changes, please modify it in time. When setting password protection questions, it is
suggested not to use those that can be easily guessed.
4. Enable Account Lock
The account lock feature is enabled by default, and we recommend you to keep it on to
guarantee the account security. If an attacker attempts to log in with the wrong password
several times, the corresponding account and the source IP address will be locked.
5. Change Default HTTP and Other Service Ports
We suggest you to change default HTTP and other service ports into any set of numbers
between 1024–65535, reducing the risk of outsiders being able to guess which ports you are
using.
6. Enable HTTPS

We suggest you to enable HTTPS, so that you visit Web service through a secure
communication channel.
7. MAC Address Binding
We recommend you to bind the IP and MAC address of the gateway to the device, thus
reducing the risk of ARP spoofing.
8. Assign Accounts and Privileges Reasonably
According to business and management requirements, reasonably add users and assign a
minimum set of permissions to them.
9. Disable Unnecessary Services and Choose Secure Modes
If not needed, it is recommended to turn off some services such as SNMP, SMTP, UPnP, etc., to
reduce risks.
If necessary, it is highly recommended that you use safe modes, including but not limited to the
following services:
SNMP: Choose SNMP v3, and set up strong encryption passwords and authentication
passwords.
SMTP: Choose TLS to access mailbox server.
FTP: Choose SFTP, and set up strong passwords.
AP hotspot: Choose WPA2-PSK encryption mode, and set up strong passwords.
10. Audio and Video Encrypted Transmission
If your audio and video data contents are very important or sensitive, we recommend that you
use encrypted transmission function, to reduce the risk of audio and video data being stolen
during transmission.
Reminder: encrypted transmission will cause some loss in transmission efficiency.
11. Secure Auditing
Check online users: we suggest that you check online users regularly to see if the
device is logged in without authorization.
Check device log: By viewing the logs, you can know the IP addresses that were used
to log in to your devices and their key operations.
12. Network Log
Due to the limited storage capacity of the device, the stored log is limited. If you need to save
the log for a long time, it is recommended that you enable the network log function to ensure
that the critical logs are synchronized to the network log server for tracing.
13. Construct a Safe Network Environment
In order to better ensure the safety of device and reduce potential cyber risks, we recommend:
Disable the port mapping function of the router to avoid direct access to the intranet
devices from external network.
The network should be partitioned and isolated according to the actual network needs.
If there are no communication requirements between two sub networks, it is
suggested to use VLAN, network GAP and other technologies to partition the network,
so as to achieve the network isolation effect.
Establish the 802.1x access authentication system to reduce the risk of unauthorized
access to private networks.
Enable IP/MAC address filtering function to limit the range of hosts allowed to access
the device.
.

Foreword IV
Foreword
General
This User’s Manual (hereinafter referred to as the “Manual”) introduces functions, installations,
operations, and maintenance of the Embedded Multi-Screen Controller (hereinafter referred to
as the “Controller”).
Safety Instructions
The following categorized signal words with defined meaning might appear in the Manual.
Signal Words
Meaning
CAUTION
Indicates a potential risk which, if not avoided, could result in
property damage, data loss, lower performance, or unpredictable
result.
NOTE Provides additional information as the emphasis and supplement
to the text.
Revision History
No.
Version
Revision Content
Release Date
1 V1.0.0 First Release. December 20, 2017
2 V1.1.0 Eight channel fine pixel
LED sending
card.
June 15, 2018
3 V2.0.0 Revised DSCON3000-M base line. Octobor 15, 2018
Privacy Protection Notice
As the device user or data controller, you might collect personal data of other such as face,
fingerprints, car plate number, Email address, phone number, GPS and so on. You need to be
in compliance with the local privacy protection laws and regulations to protect the legitimate
rights and interests of other people by implementing measures include but not limited to:
providing clear and visible identification to inform data subject the existence of surveillance
area and providing related contact.
About the Manual
The Manual is for reference only. If there is inconsistency between the Manual and the
actual product, the actual product shall prevail.
We are not liable for any loss caused by the operations that do not comply with the Manual.
The Manual would be updated according to the latest laws and regulations of related
regions. For detailed information, see the paper manual, CD-ROM, QR code or our official
website. If there is inconsistency between paper manual and the electronic version, the
electronic version shall prevail.

ForewordV
All the designs and software are subject to change without prior written notice. The product
updates might cause some differences between the actual product and the Manual. Please
contact the customer service for the latest program and supplementary documentation.
There still might be deviation in technical data, functions and operations description, or
errors in print. If there is any doubt or dispute, please refer to our final explanation.
Upgrade the reader software or try other mainstream reader software if the Manual (in PDF
format) cannot be opened.
All trademarks, registered trademarks and the company names in the Manual are the
properties of their respective owners.
Please visit our website, contact the supplier or customer service if there is any problem
occurred when using the device.
If there is any uncertainty or controversy, please refer to our final explanation.

Important Safeguards and Warnings VI
Important Safeguards and Warnings
This Chapter describes the contents covering proper handling of the Device, hazard prevention,
and prevention of property damage. Read these contents carefully before using the Device,
comply with them when using, and keep it well for future reference.
Operation Requirement
Do not place or install the Device in a place exposed to sunlight or near the heat source.
Keep the Device away from dampness, dust or soot.
Keep the Device installed horizontally on the stable place to prevent it from falling.
Do not drop or splash liquid onto the Device, and make sure there is no object filled with
liquid on the Device to prevent liquid from flowing into the Device.
Install the Device in a well-ventilated place, and do not block the ventilation of the Device.
Operate the device within the rated range of power input and output.
Do not dissemble the Device.
Transport, use and store the Device under the allowed humidity and temperature
conditions.
Electrical Safety
Improper battery use might result in fire, explosion, or inflammation.
When replacing battery, make sure the same model is used.
Use the recommended power cables in the region and conform to the rated power
specification.
Use the power adapter provided with the Device; otherwise, it might result in people injury
and device damage.
The power source shall conform to the requirement of the Safety Extra Low Voltage (SELV)
standard, and supply power with rated voltage which conforms to Limited power Source
requirement according to IEC60950-1. Please note that the power supply requirement is
subject to the device label.
Connect the device (I-type structure) to the power socket with protective earthing.
The appliance coupler is a disconnection device. When using the coupler, keep the angle
for easy operation

Table of Contents VII
Table of Contents
Cybersecurity Recommendations ........................................................................................................II
Foreword...............................................................................................................................................IV
Important Safeguards and Warnings..................................................................................................VI
1 Overview ..............................................................................................................................................1
1.1 Brief Introduction.........................................................................................................................1
1.2 Parameter ...................................................................................................................................1
1.3 Functions.....................................................................................................................................2
1.3.1 Features............................................................................................................................3
1.3.2 Structure............................................................................................................................3
1.3.3 Hardware...........................................................................................................................4
1.3.4 Software............................................................................................................................4
1.4 Introducing Boards......................................................................................................................5
1.5 Device and Ports.........................................................................................................................6
1.5.1 Main Device Cabinet.........................................................................................................6
1.5.2 Motherboard......................................................................................................................7
1.6 Function Boards..........................................................................................................................7
1.6.1 VI0401HD-DC3000 DVI Capture Card..............................................................................8
1.6.2 VI3201FB-DC3000 CVBS Capture Card...........................................................................8
1.6.3 VI0201UH-DC3000 HDMI Ultra High Definition Capture Card..........................................9
1.6.4 VI0801HH-DC3000 Capture Card...................................................................................10
1.6.5 VI0401HS-DC3000 3G-SDI Capture Card......................................................................10
1.6.6 VO0801HH-DS3000 HDMI Output Card.........................................................................11
1.6.7 VO0401HS-DC3000 3G-SDI Output Card ......................................................................11
1.6.8 LSC0801HN LED Sending Card .....................................................................................12
2 Unpacking the Box and Wiring.........................................................................................................13
2.1 Checking after Unpacking .........................................................................................................13
2.2 Installation Key Points...............................................................................................................13
2.3 Wiring........................................................................................................................................14
3 WEB Operations................................................................................................................................15
3.1 Network Connection..................................................................................................................15
3.2 Logging in the WEB...................................................................................................................15
3.3 Screen.......................................................................................................................................17
3.3.1 Adding Screens...............................................................................................................17
3.3.2 Signal Configuration........................................................................................................18
3.3.3 Adding Devices ...............................................................................................................22
3.3.4 Scheme Management.....................................................................................................22
3.3.5 Window Management .....................................................................................................23
3.3.6 Block/Window Splitting....................................................................................................24
3.3.7 Refreshing the Video Wall...............................................................................................26
3.3.8 Eagle-Eye Map................................................................................................................26
3.3.9 Screen Management.......................................................................................................27

Table of Contents VIII
3.3.10 Advanced Functions......................................................................................................33
3.4 Setting.......................................................................................................................................39
3.4.1 System Configuration......................................................................................................39
3.4.2 Network Setting...............................................................................................................50
3.4.3 Event Management.........................................................................................................55
3.4.4 Signal Management ........................................................................................................55
3.4.5 Display Management ......................................................................................................65
3.4.6 Scalability Configuration..................................................................................................82
3.5 Information ................................................................................................................................83
3.5.1 About the Controller ........................................................................................................83
3.5.2 Help.................................................................................................................................87
3.6 Exit............................................................................................................................................87
4 DSS Operations.................................................................................................................................88
5 FAQ.....................................................................................................................................................89
5.1 FAQ...........................................................................................................................................89
5.2 Operations and Maintenance ....................................................................................................90

Overview 1
1 Overview
1.1 Brief Introduction
The Controller, the latest multi-screen image processing equipment, is based on the Advanced
Telecommunications Computing Architecture (ATCA). With several patented technologies, the
Controller enables more than one video screens to be zoomed in, zoomed out or overlayed;
and enables more than one videos to be displayed in real time on multiple screens.
The Controller is designed for video processing that requires high performance, reliability, and
scalability. It is applicable to fields like education, scientific research, government
announcement, publishing, administrative management, exhibition, surveillance, and appliance
sale. Figure 1-1 Appearance
1.2 Parameter
Parameters Name Description
Model Embedded Multi-Screen Controller
System
configuration
Main processor Intel X86 Braswell processor
Operating methods
Controlled by Web interface through browsers.
Card slot
Supports four function boards.
System minimum
configuration Outputs images and signals of four channels.
System maximum
configuration Inputs and outputs 1080p images and signals of 32 channels.
Video
parameters
Video output 8 HDMI ports.

8 RJ-45 ports.
Numbers of video
screens output At most 32 video screens.
Numbers of video
channels output At most 32 videos channels.
Video resolution 1024×768@60Hz–1080p@60Hz, 24-bit true color.
DVI input Four DVI-I ports on a single board.
Resolution of videos
captured by DVI 1080P@60Hz, downward compatible.
VGA input Four DVI-I ports on a single board.
Resolution of videos
captured by VGA
1080P@60Hz, downward compatible.
HDMI ultra high
Two HDMI ports on a single board.

Overview 2
Parameters Name Description
definition input
Resolution of videos
captured by HDMI
4K2K@30Hz, downward compatible.
HDMI high definition
input
Eight HDMI ports on a single board, and these ports
can gather signals from eight
HDMI/DVI signal
sources.
Resolution of videos
captured by HDMI
1080P@60Hz, downward compatible; can gather
1080I signals.
3G-SDI input Four BNC ports on a single board.
Resolution of videos
captured by SDI
1080P@30Hz, downward compatible; and the
transmission rate is 1.485 G.
CVBS input
Two DVI-D ports on a single board. Need to be
connected to braided wires. Every port has 16
channels.
Resolution of videos
captured by CVBS
D1, 960H.
Ports
USB port
One USB2.0 port and two USB3.0 ports.
Ethernet port Two RJ-
45 ports, automatically adapt to
10M/100M/1000M Ethernet Networking interfaces.
RS-232
Two RJ-45 ports to control external matrices and
display screens.
RS-232 One DB-9 port, for programs debugging and central
control.
RS-485 One RS-485 port, reserved.
Normal
specification
Power supply 115V–230V, 47Hz–
63Hz, redundant power supply
(optional)
Power consumption
Minimum configuration is 90W. Full configuration is
360W.
Working
environment –10℃to +55℃
Working humidity 10%–90%
Barometric pressure 86kpa–106kpa
Dimension 19 inches standard industrial cabinet.
Weight Full equipment about 12.5kg.
Installation method Rack installation; Desk-top installation
Working hours
7×24h
1.3 Functions
The Field-programmable gate array (FPGA) and PCI Express are used in the Controller, which
enables all capture cards and output cards share the same slots. Signal sources can be input
through different input modes (VGA, DVI, HDMI, SDI, CVBS, and more) and be output through
DVI, HDMI, and RJ45 modes.
The Controller is compatible with various common resolutions (≤4k) under the VESA standard,
and the Controller enables users to set custom resolution for fine pixel LEDs. The Controller

Overview 3
has multiple image processing functions like ultra high definition data acquisition, dynamic
background image display, OSD overlay, and virtual LED. It has various management functions
like multi-level user rights, preset, tour, log, maintenance, smart temperature control, giving
alarms for malfunctions, and redundant power supply.
1.3.1 Features
Supports bandwidth of 32 channels of 1080P signal.
It receives various analog and digital signals (VGA, RGB, YPbPr, DVI, HDMI, and data rate)
at the same time.
The highest resolution of video signals that the Controller outputs is 1920×1200@60Hz
(meets the VESA standard). Users can customize uncommon resolution settings to 1080P
at most.
The Controller can divide, zoom in, zoom out, roam, and superimpose multiple screens.
The Controller can do fixed splitting to blocks and windows, and lock or unlock windows.
The input and output video signals can be superimposed through OSD method.
Video signals can be displayed on virtual LED screen of the Controller.
When video signals are displayed on full screen, and different screens display the same
signals synchronously.
Video signals from 32 channels can be displayed on a single screen. And network signals
from 32 channels can be displayed.
Video signals can be copied, and one video signal can be displayed on two windows.
Video signals can be displayed through peer-to-peer computing in Background image
form.
Video signals can be reviewed.
Monitors can be turned on or off at any time, and they can also be turned on or off at fixed
time.
Several display areas can be controlled at the same time.
Matrices can be controlled collaboratively.
The Controller can be controlled through serial ports of the third platform’s central control
systems.
The Controller can be controlled through various clients like DSS and SmartPSS.
Supports SVAC/MPEG4/H.264/MJPEG/H265 video standard.
The three output ports on the motherboard can decode and display 1080P@30 network
signals from at most 16 channels; and can decode and display 4K (3840×2160) network
signals from four channels.
The decode board can output five channels of network signal with 1080P@25.
1.3.2 Structure
The Controller has 19 inches standard industrial cabinet, which makes the installation more
convenient.
Advanced Telecommunications Computing Architecture (ATCA) is adopted to enhance the
Controller’s reliability and serviceability.
The Controller has more than one sets of fans, smart temperature regulation device, and
special structure to ensure the temperature balance inside the cabinet.

Overview 4
The redundant power supply ensures the continuity of the Controller’s work and the
security of the data.
The Controller has blade capture card.
1.3.3 Hardware
The Intel X86 processor.
X4 PCI-E gen2 cards and the 12V DC power supply.
Hot swapping buttons on the capture card and the indicators help users know the
scalability of the system and the state of the capture card.
Ports on the capture card like USB, serial ports, Ethernet Networking interfaces, HDMI,
BNC and DVI provide more functions and make it more convenient for users and
technicians to operate and debug the Controller.
Every capture card works independently so that every part of the system takes load evenly.
Double high speed non-blocking backplane enables the Controller to transmit large
capacity of audio and video data.
1.3.4 Software
The embedded Linux operating system is safe, reliable, steady, efficient, and easy to develop
and maintain.
Network Functions
Two 1000Mbps Ethernet ports.
Supports TCP/IP, TCP, UDP, RTP and RTSP.
The Controller can acquire system logs remotely.
Analog videos and digital videos can be displayed on screens in turn through remote
management softwares. In addition, the Controller can be controlled through keyboards.
Users can acquire and configure parameters remotely. Specifically, the Controller can be
rebooted remotely, and parameters can be exported and imported remotely, too.
Video Management
High definition and standard definition video matrix are used so that after streaming videos
are digitized, therefore there is no need to decode and compress streaming videos. As a
result, the image quality decline is avoided.
Users can select to play high definition videos or standard definition videos.
Users can customize schemes, and save and maintain them.
Switch matrix of digital video with different specifications are formed according to different
the combinations of printed circuit boards.
HDMI and DVI-I interfaces are applicable to the video capture card. The highest resolution
of videos the Controller captured is 4K (4096×2048).
Operators are allowed to cyclically play images from video source materials, set preset
positions, and switch images in batch.

Overview 5
Users can customize the groups of video signals to make the management of signal
sources more convenient.
More functions
Complete operation, alarm, malfunction and log records make users and technicians
maintain the Controller more easily.
User rights management makes the Controller more user-friendly.
The system can be upgraded both locally and remotely so that the system can meet the
ever changing market requirements.
More than one users can log in the system through different clients so that users can
regulate and manage the layout of videos on the screen anytime anywhere.
Programmers can do secondary development to the Controller because the software
development kit (SDK) is provided.
The Controller can be controlled by both DSS platform and PSS platform.
Users can restore the Controller to factory settings by only pressing one button.
1.4 Introducing Boards
Table 1-1 About the printed Circuit Boards
No.
Name
Mode
Categorization
Descriptions of interfaces
Notes
1 Main
device Splicing controller
Main device of the
Controller

One main device
cabinet,
and four
function boards.
One motherboard.
One built-
in power
adapter.
Standard
accessory
(redundant
power
supply is
optional)
2
Input
Modul
e
VI0401H
D-DC300
0 DVI capture card
There are four DVI-
I video
input ports, and these ports
can input DVI, VGA, and
HDMI signals.
Optional
3 VI3201F B-DC300
0 CVBS capture card
There are two DVI-
D video
input ports, and these ports
can input CVBS signals
from 32 channels by
connecting braided wires.
Optional
4 VI0201U H-DC300
0
HDMI u
ltra high
definition capture
card
There are two HDMI video
input ports, and these ports
can input HDMI V1.4
signals.
Optional
5 VI0801H H-DC300
0 HDMI capture card
There are eight HDMI video
input ports, and these ports
can input DVI and HDMI
signals.
Optional

Overview 6
No.
Name
Mode
Categorization
Descriptions of interfaces
Notes
6 VI0401H S-DC300
0
3G-
SDI capture
card

There are four 3G-SDI
video input ports.
There are four 3G-SDI
video loop output ports.
Optional
7
Output
modul
e
VO0801
HH-DC30
00
HDMI output card
There are eight HDMI
output ports. Optional
8 VO0401 HS-DC30
00
3G-
SDI capture
card
There are four 3G-SDI
video output ports.

There are four copy
output ports.
Optional
9 LSC0801
HN LED sending card There are eight RJ45 output ports. Optional
1.5 Device and Ports
1.5.1 Main Device Cabinet
The 19-inch main device cabinet of the Controller includes slots for different boards, power
supply ports, and smart temperature controlling fans. SeeFigure 1-2.
Figure 1-2 Appearance of the main device cabinet
The front panel, displays the working state of the Controller.
Table 1-2 Details about the front panel
It is the on/off button of the Controller. When the Controller is
plugged in, the button turns blue.
It is the power supply indicator light. When the Controller is not
plugged in, the indicator light is out; after the Controller is plugged in,
the indicator light stays red.
It is the system state light. If the Controller works normally after it is
booted, the light stays yellow.
See at the back of the device cabinet, the air inlet is on the left, and the air outlet is on the
right. The air inlet is with dust-proof net, clean it every two months.
There’s one set of smart temperature control fans, and users can use hot swapping.

Overview 7
There are four slots of port boards on the function boards, and every slot is marked with
numbers so that the rear port board can be installed more easily.
Slots of port boards on the motherboard are marked with “M”.
With dual power modules, and 220V power modules can be used.
1.5.2 Motherboard
1.5.2.1 Decsriptions of ports
Figure 1-3 Motherboard
Table 1-3 Ports and buttons on the motherboard
No
Name
No
Name
No
Name
1 Butto
n for restoring
to the factory
settings 2
Power indicator light
on the motherboard
System state light.
PCI-E state light
3 USB port
4 HDMI output port 5
Voice communication
input port (reserved)
6 Voice communication
output port
7 Ethernet port 8 Alarm clearance button 9
Two alarm input ports,
one alarm output port,
and an RS-
485 port
(reserved)
10
RS-232 port for
screen control 11 RS-232 serial port – –
1.5.2.2 Features
Any two of the three HDMI output ports on the motherboard can be configured to output 4K
(3840×2160) signals; and any one of the three output ports can output signals whose
resolution are≤1080P.
Signals of the three HDMI output ports can not be integrated to form new signals, and
signals of one or two of the three HDMI output ports can not be integrated to form new
signals.
1.6 Function Boards
Blade-shaped module is used to design the boards. The boards have functions like inputting
and outputting analog and digital images, and image processing.

Overview 8
1.6.1 VI0401HD-DC3000 DVI Capture Card
Figure 1-4 DVI capture card
Description
There are four DVI-I video input ports, and these ports can input DVI, VGA, and HDMI
signals.
There are four operating indicators.
High speed data connector includes x4 PCI-E gen2, 12V DC power supply.
Function
Inputs videos whose resolutions are ≤1080P and meet VESA standard. Specifically, the
resolutions are 1920×1080@60Hz, 1680×1050@60Hz, 1440×900@60Hz,
1400×1050@60Hz, 1366×768@60Hz, 1280×1024@60Hz, 1280×960@60Hz,
1280×800@60Hz, 1280×720@60Hz, 1152×864@60Hz, 1024×768@60Hz, and
800×600@60Hz.
VI0401HD DVI capture card can remove black bars of videos captured through VGA
connectors.
VI0401HD DVI capture card can regulate brightness, contrast, and saturability.
Time and titles in OSD channel can be superimposed, and positions where they can be
superimposed can be configured.
VI0401HD DVI capture card can see through fogs.
The indicator keeps on, and the port flickers normally.
Output modes of the ATI video card include 1680×1050, 1440×900, 1280×1024, 1280×960,
1280×800, 1280×768, 1024×768, 1152×864, and 800×600. Video signals captured through
DVI channels might have black bars. The occurrence of black bars is related to the setting of
output sources. Specifically, because the “Using GPU zoom” function is selected. To remove
black bars, do the following procedures:
Click the right button on the computer desktop, select Screen Resolution > Advanced
Settings > Catalyst Control Center > ATI Catalyst Control Center > My Digital Flat Panel >
Attribute (Digital Flat Panel) > Using GPU Zoom, and then do not select the function.
1.6.2 VI3201FB-DC3000 CVBS Capture Card
Figure 1-5 CVBS capture card

Overview 9
Description
The CVBS capture card needs to be connected by braided wires, and it can input video
signals from 32 channels.
There are two RS-485 ports (temporarily reserved).
There are two operating indicatos.
High speed data connector includes x4 PCI-E gen2, and 12V DC power supply.
Function
Resolutions of signals the CVBS can input: CIF, D1, and 960H.
Specifications of videos input and output by each channel can be retrieved individually.
1.6.3 VI0201UH-DC3000 HDMI Ultra High Definition Capture
Card
Figure 1-6 HDMI ultra high definition capture card
Description
There are two HDMI video input ports, and these ports can input HDMI signals.
There are two operating indicators.
There are two audio loop output ports.
High speed data connector includes x4 PCI-E gen2, and 12V DC power supply.
Function
Inputs videos whose resolutions are≤4K×2K and meet VESA standard. Specifically, the
resolutions are 4096×2160@24fps, 3840×2160@30Hz, 2560×1600@30Hz,
2048×1536@30Hz, 1920×1080@60Hz, 1680×1050@60Hz, 1440×900@60Hz 、,
366×768@60Hz, 1280×1024@60Hz, 280×960@60Hz, 1280×800@60Hz,
1280×720@60Hz, 1152×864@60Hz, 1024×768@60Hz, and 800×600@60Hz.
You can customize non-standard resolution
Time and titles in OSD channel can be superimposed.
The indicator keeps on, and the port flickers normally.

Overview 10
1.6.4 VI0801HH-DC3000 Capture Card
Figure 1-7 HDMI capture Card
Description
There are eight HDMI video input ports, and these ports can input DVI and HDMI signals.
There are eight operating indicators.
High speed data connector includes x4 PCI-E gen2, and 12V DC power supply.
Function
Inputs videos whose resolutions are≤1080P and meet VESA standard. Specifically, the
resolutions are 1920×1080@60Hz, 1680×1050@60Hz, 1440×900@60Hz,
1400X1050@60Hz, 1366×768@60Hz, 1280×1024@60Hz, 1280×960@60Hz,
1280×800@60Hz, 1280×720@60Hz, 1152×864@60Hz, 1024×768@60Hz, and
800×600@60Hz.1080I@60HZ,1080I@50HZ
Time and titles in OSD channel can be superimposed, and positions where they can be
superimposed can be configured.
The indicator keeps on, and the port flickers normally.
1.6.5 VI0401HS-DC3000 3G-SDI Capture Card
Figure 1-8 3G-SDI capture card
Description
There are four 3G-SDI video input ports, and four 3G-SDI video loop output ports.
From left to right, port 1, 3, 5 and 7 are input ports; port 2, 4, 6, and 8 are output ports.
There are two RS-485 ports.
There are four operating indicators.
High speed data connector includes x4 PCI-E gen2, and 12V DC power supply.
The two RS-485 ports are used to control SDI speed domes. COM1 should be connected
to input ports 1, 2, 3, and 4; COM2 should be connected to input ports 5, 6, 7, and 8.
Port A and B of cameras should be connected to A and B of RS-485.
Function

Overview 11
Specifications of videos input and output by each channel can be retrieved individually. The
specifications that can be retrieved include resolution, frame rate, and image quality.
Conforms to SMPTE 24M standard, and the network speed can reach 2.97Gbit/s.
The 3G-SDI capture card can input and output signals of 1080P@60/50//25, 1080i@60/50,
and 720P60/50/30/25.
1.6.6 VO0801HH-DS3000 HDMI Output Card
Figure 1-9 HDMI output card
Description
There are eight HDMI output ports that comply with DVI 1.0 and HDMI 1.3.
There are eight operating indicators.
High speed data connector includes x4 PCI-E gen2, and 12V DC power supply.
Functions
Outputs videos whose resolutions are ≤ 1920×1080 @60Hz and meet VESA standard.
Currently only cameras with multiple output functions and cameras whose resolutions are
1080P and bellow are applicable to the Controller.
Each output port displays videos from 32 channels.
1.6.7 VO0401HS-DC3000 3G-SDI Output Card
Figure 1-10 3G-SDI output card
Description
There are four 3G-SDI video output ports, and four copy output ports.
From left to right, port 1, 3, 5 and 7 are input ports; port 2, 4, 6, and 8 are output ports.
There are four operating indicators.
High speed data connector includes x4 PCI-E gen2, and 12V DC power supply.
Functions

Overview 12
Specifications of videos input and output by each channel can be retrieved individually. The
specifications that can be retrieved include resolution, frame rate, and image quality.
Complys with SMPTE 24M standard, and the network speed can reach 2.97Gbit/s.
The output card can output signals of 1080P@60/50/30Hz and 720P@60Hz.
1.6.8 LSC0801HN LED Sending Card
Figure 1-11 LSC0801HN LED sending card
Description
There are eight RJ-485 ports, and comply to the RGMII standard.
There are eight operating indicators, and eight data indicators.
High speed data connector includes x4 PCI-E gen2, and 12V DC power supply.
Functions
A single Ethernet Networking interface can load at most 648000 pixel points. A single
capture card can load 5.2 million pixels.
You can set custom resolution for the output video signals of the single Ethernet
Networking interface, the maximum width is 3840, and the maximum height is 3840 (can
load at most 648000 pixel points).
