Dahua MXVR1004 Series User manual

Mobile Digital Video Recorder
User’s Manual
V1.0.0
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Dahua DHI-
MXVR1004-GC o cerca il tuo prodotto tra le migliori offerte di Videosorveglianza

Regulatory Information I
Regulatory Information
The regulatory information herein might vary according to the model you purchased. Some
information is only applicable for the country or region where the product is sold.
FCC Information
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
FCC conditions:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause
undesired operation.
FCC compliance:
This equipment has been tested and found to comply with the limits for a digital device,
pursuant to part 15 of the FCC Rules. This equipment generate, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the guide, may cause
harmful interference to radio communication.
For class A device, these limits are designed to provide reasonable protection against
harmful interference in a commercial environment. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
For class B device, these limits are designed to provide reasonable protection against
harmful interference in a residential installation. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.

Cybersecurity Recommendations II
Cybersecurity Recommendations
Mandatory actions to be taken towards cybersecurity
1. Change Passwords and Use Strong Passwords:
The number one reason systems get “hacked” is due to having weak or default passwords. It is
recommended to change default passwords immediately and choose a strong password whenever
possible.A strong password should be made up of at least 8 characters and a combination of
special characters, numbers, and upper and lower case letters.
2. Update Firmware
As is standard procedure in the tech-industry, we recommend keeping NVR, DVR, and IP camera
firmware up-to-date to ensure the system is current with the latest security patches and fixes.
“Nice to have” recommendations to improve your network security
1. Change Passwords Regularly
Regularly change the credentials to your devices to help ensure that only authorized users are able
to access the system.
2. Change Default HTTP and TCP Ports:
● Change default HTTP and TCP ports for systems. These are the two ports used to communicate
and to view video feeds remotely.
● These ports can be changed to any set of numbers between 1025-65535. Avoiding the default
ports reduces the risk of outsiders being able to guess which ports you are using.
3. Enable HTTPS/SSL:
Set up an SSL Certificate to enable HTTPS. This will encrypt all communication between your
devices and recorder.
4. Enable IP Filter:
Enabling your IP filter will prevent everyone, except those with specified IP addresses, from
accessing the system.
5. Change ONVIF Password:
On older IP Camera firmware, the ONVIF password does not change when you change the
system’s credentials. You will need to either update the camera’s firmware to the latest revision or
manually change the ONVIF password.
6. Forward Only Ports You Need:
● Only forward the HTTP and TCP ports that you need to use. Do not forward a huge range of
numbers to the device. Do not DMZ the device's IP address.
● You do not need to forward any ports for individual cameras if they are all connected to a recorder
on site; just the NVR is needed.
7. Disable Auto-Login on SmartPSS:
Those using SmartPSS to view their system and on a computer that is used by multiple people
should disable auto-login. This adds a layer of security to prevent users without the appropriate
credentials from accessing the system.
8. Use a Different Username and Password for SmartPSS:

Cybersecurity Recommendations III
In the event that your social media, bank, email, etc. account is compromised, you would not want
someone collecting those passwords and trying them out on your video surveillance system. Using
a different username and password for your security system will make it more difficult for someone
to guess their way into your system.
9. Limit Features of Guest Accounts:
If your system is set up for multiple users, ensure that each user only has rights to features and
functions they need to use to perform their job.
10. UPnP:
● UPnP will automatically try to forward ports in your router or modem. Normally this would be a
good thing. However, if your system automatically forwards the ports and you leave the credentials
defaulted, you may end up with unwanted visitors.
● If you manually forwarded the HTTP and TCP ports in your router/modem, this feature should be
turned off regardless. Disabling UPnP is recommended when the function is not used in real
applications.
11. SNMP:
Disable SNMP if you are not using it. If you are using SNMP, you should do so only temporarily, for
tracing and testing purposes only.
12. Multicast:
Multicast is used to share video streams between two recorders. Currently there are no known
issues involving Multicast, but if you are not using this feature, deactivation can enhance your
network security.
13. Check the Log:
If you suspect that someone has gained unauthorized access to your system, you can check the
system log. The system log will show you which IP addresses were used to login to your system and
what was accessed.
14. Physically Lock Down the Device:
Ideally, you want to prevent any unauthorized physical access to your system. The best way to
achieve this is to install the recorder in a lockbox, locking server rack, or in a room that is behind a
lock and key.
15. Connect IP Cameras to the PoE Ports on the Back of an NVR:
Cameras connected to the PoE ports on the back of an NVR are isolated from the outside world and
cannot be accessed directly.
16. Isolate NVR and IP Camera Network
The network your NVR and IP camera resides on should not be the same network as your public
computer network. This will prevent any visitors or unwanted guests from getting access to the
same network the security system needs in order to function properly.

Foreword IV
Foreword
Models
MXVR1004 Series
Safety Instructions
The following categorized signal words with defined meaning might appear in the Guide.
Signal Words
Meaning
DANGER
Indicates a high potential hazard which, if not avoided, will result in
death or serious injury.
WARNING
Indicates a medium or low potential hazard which, if not avoided,
could result in slight or moderate injury.
CAUTION
Indicates a potential risk which, if not avoided, could result in
property damage, data loss, lower performance, or unpredictable
result.
TIPS
Provides methods to help you solve a problem or save you time.
NOTE
Provides additional information as the emphasis and supplement
to the text.
Terms
To simplify descriptions, frequently cited functions and names in this manual have the following
meanings:
Unless otherwise specified, “Device” in this document refers to “MXVR1004 series
products”.
“Remote devices” in this manual refer to NVR, IPC, speed domes connected with the
devices through network.
“Smart module” in this manual means smart cards installed on devices.
“IP host” in this manual refers to hosts configured with IP addresses. PC, NVR, IPC, and
speed domes are all IP hosts.
To keep the devices safe, IP addresses, MAC addresses, and serial numbers cited in this
manual have all been modified.
Revision History
No.
Version
Revision Content
Release Date
1
V1.0.0
First release
January 2019

Important Safeguards and Warnings V
Important Safeguards and Warnings
The following section describes how to use this product correctly and how to prevent dangers
and property loss in using it. Before using this product, read this Manual carefully and comply
with it strictly. Keep this Manual properly after reading.
Requirements
Do not place or install the device near a heat source or where there is direct sunshine.
Do not install the device in a humid, dusty, or smoggy place.
Install the device horizontally or in a stable place. Take measures to prevent it from falling.
Do not drip or splash liquid onto the device. Make sure that the device does not bear any
objects filled with liquid to prevent liquid from flowing into the device.
Prevent foreign objects from entering the Device, which might result in damage.
Install the device in a place with good ventilation. Do not clog the air vents of the device.
Use the device only within the rated input and output range.
Do not dismantle the device without permission.
Do not transport the Device with the front panel on the bottom.
Transport, use and store the Device under the allowed humidity and temperature
conditions.
Do not expose the Device to water or excessive moisture when washing the car.A failure
to follow this instruction might result in short circuit, fire, or other malfunctions.
The dust on the circuit board will cause short circuit, which affect the normal operation of
the Device and even damage the Device.To make the Device work stably for a long time,
please regularly use the brush to remove the dust from components, including circuit board,
connectors, and chassis.
Keep the Device installed horizontally and make sure the internal anti-vibration
components work properly.
Unlock before plugging or unplugging the SD card; otherwise it might cause damage to the
device.
After all the cables are connected, tie up the cables to avoid the dangers such as short
circuit, heat and electric shock resulted from loose cables.
When a device is connected with a car mount display, mount the camera at least 2m away
from the display. If the camera and display are too close, tune down the volume of the car
mount display to avoid squeal.
Power Requirements
Use the battery exactly as prescribed; otherwise, the battery might catch fire or explode!
Always replace with the same type of batteries!
Use the wires (power cords) recommended for the region where the device is used within
the specified range of specifications!
The appliance coupler is a disconnection device. Keep a convenient angle when using it.

Important Safeguards and Warnings VI
Take care to complete the circuit connection. A failure to follow this instruction might result
in Device damage.
Prevent short circuit from occurring on all external wiring parts.
After all the lines connections are completed, you can start connecting power cable.
Ensure the project is well grounded to avoid interference to video and audio signals and
avoid electrostatic or induced voltage to damage the Device.
Unplug the power cable before you remove the audio/video signal cable, RS-232 or
RS-485 cable; otherwise these ports might be damaged.

Table of Contents VII
Table of Contents
Regulatory Information............................................................................................................................. I
Cybersecurity Recommendations.......................................................................................................... II
Foreword..................................................................................................................................................IV
Important Safeguards and Warnings.....................................................................................................V
1 Introduction............................................................................................................................................ 1
Product Overview.......................................................................................................................... 11.1 Functions....................................................................................................................................... 11.2
2 Dimension and Installation .................................................................................................................. 3
Out-of-box Audit............................................................................................................................ 32.1 Device Structure............................................................................................................................ 32.2 2.2.1 Front Panel ......................................................................................................................... 3
2.2.2 Rear Panel.......................................................................................................................... 4
2.2.3 Interface definitions............................................................................................................. 5
2.2.4 Dimensional Drawing.......................................................................................................... 8
Installation..................................................................................................................................... 82.3 2.3.1 Installing SIM Card and SD Card....................................................................................... 8
2.3.2 Installing Antenna ............................................................................................................... 9
2.3.3 Fixing the Device.............................................................................................................. 12
2.3.4 Connecting to Power Cables............................................................................................ 12
Audio and Video Output Connection........................................................................................... 142.4 Alarm Input and Output Connection............................................................................................ 152.5 2.5.1 Alarm Input Type............................................................................................................... 16
2.5.2 Alarm Input Port................................................................................................................ 16
3 Boot up the Device.............................................................................................................................. 18
4 Local Configurations .......................................................................................................................... 19
Initializing Device ........................................................................................................................ 194.1 Logging into the Device .............................................................................................................. 214.2 Quick Configuration .................................................................................................................... 224.3 4.3.1 Configure IP address........................................................................................................ 22
4.3.2 Configuring General Settings........................................................................................... 24
4.3.3 Configuring Remote Devices............................................................................................ 26
4.3.4 Configuring Record Settings............................................................................................. 30
4.3.5 Set up the storage plan .................................................................................................... 31
Common Operations................................................................................................................... 344.4 4.4.1 Live View........................................................................................................................... 34
4.4.2 Video Search.................................................................................................................... 43
Alarm Configuration .................................................................................................................... 494.5 4.5.1 Alarm.................................................................................................................................49
4.5.2 Configuring Video Detection Settings............................................................................... 65
4.5.3 Configuring Alarm Events Settings................................................................................... 66
4.5.4 Abnormality....................................................................................................................... 67

Table of Contents VIII
4.5.5 Configuring Alarm Output Settings................................................................................... 69
4.5.6 Searching Alarm Log ........................................................................................................ 70
System config.............................................................................................................................. 70
4.6 4.6.1 Configuring Camera.......................................................................................................... 70
4.6.2 Network Parameters Configuration.................................................................................. 75
4.6.3 Configuring platform ......................................................................................................... 85
4.6.4 Setting Device Storage..................................................................................................... 88
4.6.5 Setting user info................................................................................................................ 92
4.6.6 Set up system services..................................................................................................... 97
4.6.7 Configuring display output................................................................................................ 99
4.6.8 Configuring RS-232 port function................................................................................... 102
4.6.9 Configuring Vehicle Settings...........................................................................................103
System Update..........................................................................................................................1064.7 4.7.1 Viewing system version..................................................................................................106
4.7.2 Upgrading System..........................................................................................................107
System Maintenance ................................................................................................................1094.8 4.8.1 Requirement for Maintenance........................................................................................ 109
4.8.2 Maintaining password..................................................................................................... 109
4.8.3 Querying log ....................................................................................................................112
4.8.4 Review status information ...............................................................................................113
4.8.5 Auto Maintain...................................................................................................................115
4.8.6 Backing Up and Restoring...............................................................................................117
4.8.7 Restored to the Default Settings .....................................................................................119
4.8.8 Network packet capturing...............................................................................................120
4.8.9 Shutdown........................................................................................................................120
5 Web Operations................................................................................................................................. 122
Initializing Device ......................................................................................................................1225.1 Logging into the Device ............................................................................................................1235.2 Quick configuring ......................................................................................................................1245.3 5.3.1 Configure IP address......................................................................................................124
5.3.2 Configuring General Settings......................................................................................... 126
5.3.3 Configuring Remote Devices..........................................................................................128
5.3.4 Configuring Record Settings........................................................................................... 133
5.3.5 Set up the storage plan ..................................................................................................134
Common operations.................................................................................................................. 1375.4 5.4.1 Live View.........................................................................................................................137
5.4.2 Video playback ............................................................................................................... 147
5.4.3 Configuring Alarm Events Settings.................................................................................154
System Settings........................................................................................................................1555.5 5.5.1 Configuring lens parameter............................................................................................155
5.5.2 Network Parameters Configuration................................................................................162
5.5.3 Set alarm information .....................................................................................................174
5.5.4 Managing storage device ...............................................................................................182
5.5.5 Configuring system settings ........................................................................................... 183
5.5.6 Safety.............................................................................................................................. 191
5.5.7 Configuring Vehicle Settings...........................................................................................197
System Update..........................................................................................................................2015.6

Table of Contents IX
5.6.1 View system version....................................................................................................... 201
5.6.2 Upgrading System Firmwares........................................................................................ 201
System Maintenance ................................................................................................................201
5.7 5.7.1 Requirement for Maintenance........................................................................................ 201
5.7.2 System Information......................................................................................................... 202
5.7.3 Auto Maintain..................................................................................................................203
5.7.4 Backing Up and Restoring.............................................................................................. 205
5.7.5 Network packet capturing...............................................................................................207
6 Operating by DSS.............................................................................................................................. 208
7 FAQ ..................................................................................................................................................... 209
Mouse Operations ........................................................................................................... 213Appendix 1 Storage Capacity Calculation......................................................................................... 215Appendix 2 Technical parameters...................................................................................................... 216Appendix 3

Introduction 1
1 Introduction
Product Overview1.1
Based on the new generation platform, the MXVR1004 series products are onboard video
monitoring products that integrate video capturing, locating, and drive recording.
Features:
Up to 4-channel coaxial video input and 1-channel remote video input; Maximum 400W
resolution.
Compatible withAHD, TVI, and CVBS video signals.
The use of H.265 encoding ensures high encoding efficiency and saves storage space.
Netcom wireless network modules (3G, 4G and Wi-Fi modules are optional) are built in
after full consideration of network application needs of car mount products.
The use of professional car-mount design in standard size features low power
consumption and novel shape.
Wide power voltage range adapts to various car mount power supply.
This product can be widely used for car mount monitoring in public transportation, long-range
passenger transport, police patrol, urban management patrol, cash carriers, hazardous goods
transport, and logistics transport, or video monitoring in harsh environments.
Functions1.2
Function
Description
Storage
Stores the data in the dedicated format which cannot be falsified and
ensure the data security.
Compression
Supports multi-channel audio and video signals, and each channel
signal supports real-time compression by independent hardware to
realize the sync between sound and image.
Backup
Plug in a USB storage device (such as USB flash disk and mobile

HDD) to back up
You can back up the data by downloading the files from the SD

card through the network.
Video playback
Every channel supports real-time and independent recording, and

you can play backward, monitor on Internet, query and download
recordings
Supports several playback modes: Slow playback, fast playback,

backward playback, and frame-by-frame playback.
Displays the accurate time when the event occurred during

playback.
Operation through
Network
Supports remote operations through network, such as real-time remote
monitoring, recorded video search and playback, and PTZ control

Introduction 2
Function
Description
Alarm linkage
Provides six routes of electric level alarm inputs that can connect

to signals such as car door signal, cornering lamp signal, reversing
and braking signal, to give an indication and take a record
Supports one route of electric level alarm output to realize easy

alarm linkage
Supports protective circuit for alarm input port and alarm output

port, which protect the Device from damage.
Communication
interfaces
Offers RS-485 interfaces to connect with external devices

Offers standard Ethernet ports that support remote network

accessing
Smart operations
Mouse operations

The same settings in the menu can be quickly copied and pasted

Satellite
positioning
Supports positioning function and recording linkage. Recording search
can be linked with vehicle moving track
3G/4G, Wi-Fi
networks
Adopts the latest wireless communication technology, which has
improved the manageability of the Device.
Dual stream
To cope with the low-bandwidth and instability of wireless network, the
Device adopts the dual stream technology (respectively encode the
real-time video and encode video in network transmission) to optimize
the coding of network transmission, which improves the control
capability of wireless network transmission
Rollover and
collision detection
The integrated G-sensor supports rollover and collision detection and
timely releases alarms through the platform

Dimension and Installation 3
2 Dimension and Installation
This introduces how to install the hardware of the Device. Before installing the hardware, you
need to know the device information, such as front and rear panels, physical dimensions, and
interface definition.After obtaining a sufficient understanding, you can install the SIM card, SD
card, antenna, and the device itself as needed.
Out-of-box Audit2.1
When you receive the Device, unpack the box for checks.
Firstly, check if there is any damage on the Device appearance (although the packing materials
are specially selected for protecting the Device from most of accidental hit during
transportation). Secondly, open the accessory box to check if the accessories are complete
against the packing list.
Instructions about front panel, rear panel, and labels:
The functions of indicator lights and ports are described in the later chapter of the Manual.
The labels on the Device are very important for our after-sales service. To ensure the
after-sales service, keep the labels well, and do not tear or throw away. You need to
provide the serial number of the product when calling the after-sales service.
Device Structure2.2
2.2.1 Front Panel
Describes the functions of the indicators and interfaces of the front panel.
Front PanelFigure 2-1
Table 2-1 Descriptions of interfaces and indicators
No.
Name
Descriptions of interfaces and indicators
1
USB interface
For mouse access or USB data backup.
2
Lock switch (Device
switch)
To plug or unplug the SD card, the Device must be

unlocked. In this case, the Device will shut down
automatically if powered on.
To protect SD card, the Device cannot be powered on if

unlocked. Lock the Device before powering on.

Dimension and Installation 4
No.
Name
Descriptions of interfaces and indicators
3
SD card interface
Hold at most 2 SD cards.
4
PWR
The red light is always on when the Device is powered on,
and off when the Device is powered off
5
REC
Recording status indicator. The blue light is always on when
recording, and off when not
6
IR
Receives infrared signal from remote control.
2.2.2 Rear Panel
Describes the interface functions of the rear panel.
Figure 2-2 shows the rear panel of the Device. Refer to Table 2-2 for interface function
description, and “2.2.3 Interface definitions” for interface definitions.
Rear panelFigure 2-2
Table 2-2 Descriptions of rear panel interfaces
No.
Name
Function
1
Wi-Fi antenna
port
Connects to Wi-Fi antenna and receives Wi-Fi signals.
NOTE
This function is supported on the Device with Wi-Fi module.
2
3G/4G antenna
port
Connects to 3G/4G antenna for receiving 3G/4G signals.
NOTE
This function is supported on the Device with 3G/4G modules.
3
Positioning
antenna port
Connects with positioning antenna for receiving satellite
positioning signals
NOTE
This function is supported on the Device with positioning module
4
AV OUT port
Connects to the display with audio function on the vehicle for
simultaneously video and audio data output. For details, see “2.4
Audio and Video Output Connection.”

Dimension and Installation 5
No.
Name
Function
5
CH1-4
Connects to HDCVI or analog mobile camera, such as CVBS, TVI,
and AHD.
NOTE
Different devices corresponds to different number of channels
6
SIM card
interface
Plug SIM card
7
ETH interface
The aviation port can be converted to an RJ45 interface through a
adapter cable.
Access to PoE power switch to realize IPC remote access.

Connects to the network to realize the login and Web

interface operation of the Device.
8
ALARM
Alarm input/output port: Includes alarm input/output port,
grounding, and 12V output port. For details, see “2.5Alarm Input
and Output Connection.”
9
EXTEND port
See “EXTEND Port” introduction.
10
485
Controls the PTZ
11
External pickup
port
Connects to external pickup. For details, see “External pickup
port” introduction.
12
Power cable
Connects to 6V DC–36V DC power for power supply from vehicle
battery.
The red end with fuse is the anode of the power supply

(always-live wire)
The black wire is the ground wire

The orange one is the ACC signal (key starting wire)

2.2.3 Interface definitions
NOTE
This Manual only describes functions of all jacks of each interface. You can follow these
descriptions to prepare cables or contact our sales staff for purchasing cables.
2.2.3.1 CH1-4 Port
CH1-4 portFigure 2-3
Table 2-3 Port description
No.
Description
1
12V power supply to camera.
2
Grounding port.

Dimension and Installation 6
No.
Description
3
Grounding port.
4
Video input port to receive video signal from camera.
When your camera is the kind which outputsAHD, TVI or CVBS video signal, the
Recorder can only receive the video signal and cannot receive the audio signal；
when your camera is the kind which outputs CVI video signal, the Recorder can
receive both the video and audio signal.
2.2.3.2 Power input
Power input interfaceFigure 2-4
Table 2-4 Power input interfaces (left to right)
Cable color
Pins
Orange
ACC signal input
Red
Anode input
Black
Ground
2.2.3.3 EXTEND port
EXTEND portFigure 2-5
Name
Function
+5
USB +5V (upper line)
+5
USB +5V (upper line)
-
USB data- and USB data+ that connect to USB port.
+
IR
Remote control signal indicator. Receives signals from remote control.

Dimension and Installation 7
Name
Function
+12
+12V/1A output.
Ground
VO
AV video output
RX
RS-232 serial port sender and receiver that connects to RS-232 port
TX
2.2.3.4 External pickup port
External pickup portFigure 2-6
Name
Function
+12
+12V output
Ground
Mic In that can connect to pickup.
For external amplifier.

Dimension and Installation 8
2.2.4 Dimensional Drawing
Physical Dimensions (mm)Figure 2-7
Installation2.3
When you receive the Device, unpack the box to check the Device appearance and structures,
and then install SIM card, SD card, and other items according to your network situation and
storage requirement.
NOTE
Before the installation is complete, make sure the Device is disconnected from power, and do
not plug or unplug components when the power is connected.
2.3.1 Installing SIM Card and SD Card
By default, the Device is delivered without the SIM card and SD card. Install them as you need.
To connect the Device to Internet through dial-up connection, you need to purchase and
install a SIM card.
NOTE
Only supports normal SIM card.
To store recording data, you need to purchase and install an SD card.
Preconditions

Dimension and Installation 9
Make sure the power supply is disconnected. If it is not, the Device automatically shuts down
when the door lock switch is opened.
Steps
If the SIM card slot is on the rear panel of the Device, plug the card directly.
If the SD card slot is inside the device, do the following to install the SD card.
Use a pass key to open the electronic locker.Step 1 Remove the SD card stopper.Step 2 Insert the SD card into the slot with SD marking.Step 3 Take back the SD stopper, and lock the electronic locker.Step 4
2.3.2 Installing Antenna
The device antenna is installed to connect the device to the network and to locate the position
of the vehicle.
2.3.2.1 Installation of Mobile Network Antenna
CAUTION
When installing sticking antenna, make sure there is no metal material below the sticking spot.
The large sucker antenna needs to be attached vertically to the metal. In special cases, when
the material of the adsorption position is not metal, it can be fixed by double-sided 3M
adhesive or gluing.
For installation of mobile network antenna, see0. Flat antennas and large sucker antennas are
recommended to be attached vertically and closely to the vehicle windshield (e.g., on the
dashboard, under the windshield) or hidden in the dashboard.
Install the mobile network antenna outside the vehicle. See 0. Large sucker antenna is attached
to the roof of the vehicle, the upper of the trunk, or other positions.
Inside installationof Mobile Network Antenna

Dimension and Installation 10
Outside installationof Mobile Network Antenna
2.3.2.2 Installation of GPS Antenna
Positioning methods include the currently mainstream GPS positioning, Beidou positioning,
with corresponding GPS antenna and Beidou antenna.
In this document, GPS antenna is used as an example to illustrate the installation steps of
locating antennas. The installation process of other locating antenna is identical.
2.3.2.2.1 Outside Installation
Place the GPS antenna on the left front of the roof. See Figure 2-8.Step 1 The antenna is magnetically attached to the roof of the vehicle. Glue can be applied to
four sides of the antenna to fix more reliably.
NOTE
To make the sensitivity and accuracy of positioning free of interference, ensure that
there is no high-power electrical or electronic interference source (such as a fan or AC
compressor) or obstacles within 1 meter around the GPS antenna.
Insert the GPS antenna lead wire into the antenna lead hole on the roof of the vehicleStep 2 and connect to the GPS antenna port inside the vehicle.
The requirements of the GPS antenna lead hole are as follows.
The inner radius is at least 10mm.
It must be waterproof.
Easy to replace and maintain the antenna.
