Dahua IPC-KW10 User manual

HD Cube Network Camera User’s Manual
HD Cube Network Camera User’s Manual
Version 1.1.0
Zhejiang Dahua Technology CO., LTD

HD Cube Network Camera User’s Manual
i
Welcome
Thank you for purchasing our network camera!
This user’s manual is designed to be a reference tool for your system.
Please read the following safeguard and warnings carefully before you use this series product!
Please keep this user’s manual well for future reference!

HD Cube Network Camera User’s Manual
ii
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited
power source is rated 12V DC or 24V AC in the IEC60950-1. (Refer to general introduction) Please
note: Do not connect two power supplying sources to the device at the same time; it may result
in device damage!
We assume no liability or responsibility for all the fires or electrical shock caused by improper handling
or installation.
We are not liable for any problems caused by unauthorized modification or attempted repair.
2．Transportation security
Heavy stress, violent vibration or water splash are not allowed during transportation, storage and
installation.
3．Installation
Do not apply power to the camera before completing installation.
Please install the proper power cut-off device during the installation connection.
Always follow the instruction guide the manufacturer recommended.
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted repair.
5．Environment
This series network camera should be installed in a cool, dry place away from direct sunlight,
inflammable, explosive substances and etc.
Please keep it away from the electromagnetic radiation object and environment.
Please make sure the CCD (CMOS) component is out of the radiation of the laser beam device.
Otherwise it may result in CCD (CMOS) optical component damage.
Please keep the sound ventilation.
Do not allow the water and other liquid falling into the camera.
Thunder-proof device is recommended to be adopted to better prevent thunder.
The grounding studs of the product are recommended to be grounded to further enhance the reliability
of the camera.
6. Daily Maintenance
Please shut down the device and then unplug the power cable before you begin daily maintenance
work.

HD Cube Network Camera User’s Manual
iii
Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens
surface.
Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to
dilute the mild detergent first and then use it to clean the device. Finally use the dry cloth to clean the
device.
Please put the dustproof cap to protect the CCD (CMOS) component when you do not use the camera.
Dome enclosure is the optical component, do not touch the enclosure when you are installing the
device or clean the enclosure when you are doing maintenance work. Please use professional optical
clean method to clean the enclosure. Improper enclosure clean method (such as use cloth) may result
in poor IR effect of camera with IR function.
7. Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are included.
Contact your local retailer ASAP if something is broken in your package.
Accessory Name
Amount
Network Camera
1
Quick Start Guide
1
Installation Accessories Bag
1
CD
1
Warranty Card and Certificate
1

HD Cube Network Camera User’s Manual
iv
Table of Contents
1General Introduction ..................................................................................................................1
1.1 Overview........................................................................................................................1
1.2 Features.........................................................................................................................1
1.3 Specifications................................................................................................................2
2Framework...................................................................................................................................6
2.1 Device Components.....................................................................................................6
2.2 Dimensions....................................................................................................................8
2.3 Bidirectional talk............................................................................................................8
2.3.1 Device-end to PC-end..........................................................................................8
2.3.2 PC-end to the Device-end....................................................................................8
2.4 Alarm ..............................................................................................................................9
3Device Installation ....................................................................................................................11
4Quick Configuration Tool.........................................................................................................13
4.1 Overview......................................................................................................................13
4.2 Operation .....................................................................................................................13
5Web Operation..........................................................................................................................15
5.1 Network Connection...................................................................................................15
5.2 Login and Main Interface...........................................................................................15
6FAQ ............................................................................................................................................17
Appendix Toxic or Hazardous Materials or Elements ...............................................................19

HD Cube Network Camera User’s Manual
1
1General Introduction
1.1 Overview
This series network camera integrates the traditional camera and network video technology. It adopts
video data collection, transmission together. It can connect to the network directly without any auxiliary
device.
This series product uses standard H.264 video compression technology, G.711a audio compression
technology and etc, which maximally guarantees the video quality.
It supports PIR function to detect human body movement. It can activate the white light at the same to
enable the record function at night. This series product supports real-time listening function when it is
in real-time monitor mode. It supports dual-way bidirectional talk function.
It can be used alone or used in a network area. When it is used lonely, you can connect it to the
network and then use a network client-end. Due to its multiple functions and various uses, this series
network camera is widely used in many environments such as home, office, bank, road monitor and
etc.
1.2 Features
User
Management
Different user rights for each group, one user belongs to one group.
The user right shall not exceed the group right.
Data
transmission
Wire network data transmission via the Ethernet port.
Wireless product series supports WIFI wireless network data transmission.
Storage
Function
Support central server backup function in accordance with your configuration and
setup in alarm or schedule setting
Support record via Web and the recorded file are storage in the client-end PC.
Support Micro SD card storage (This function is optional. For some series
product only.), alarm record or snapshot storage.
Support network storage function such as FTP.
Alarm
Function
Real-time respond to external video detect (This function is optional. For some
series product only.)as user pre-defined activation setup and generate
corresponding message in screen and audio prompt(allow user to pre-record
audio file)
Real-time video detect: motion detect, camera masking, PIR human body
movement detect.
Trigger audio function. Audio file support pre-record and upload function (This
function is optional. For some series product only.)
Network
Monitor
Network camera supports one-channel video data transmit to network terminal
and then decode. Delay is within 270ms (network bandwidth support needed)
Max supports 20 connections.
Adopt the following video transmission protocol: HTTP, TCP, UDP, MULTICAST,
RTP/RTCP, RTSP and etc.
Support web access.
Network
Management
Realize network camera configuration and management via Ethernet.
Support device management via web or client-end.
Support various network protocols.
Power
External power adapter DC12V.

HD Cube Network Camera User’s Manual
2
Assistant
Function
Support PIR human body movement detect. (This function is optional. For some
series product only.).
Support motion detect function.
Support dual-stream, ACF.
Support picture parameter setup such as electronic shutter and gain setup.
Built-in microphone and speaker (This function is optional. For some series
product only.).
Support video watermark function to avoid vicious video modification.
Log function. Support system resource information and running status real-time
display.
Backlight compensation: screen auto split to realize backlight compensation to
adjust the bright.
1.3 Specifications
Please refer to the following sheet for product performance specification.
Model
Parameter
IPC-KW10
IPC-KW10W
IPC-KW12
IPC-KW12W
System
Main Processor
High performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network monitor, local record, and remote operation
at the same time.
User Interface
Remote operation interface such as WEB, DSS, PSS.
System Status
Bit stream statistics, log, and software version.
Video Parameter
Image Sensor
1/4-inch CMOS
Pixel
1280(H)*720(V)
Gain Control
Fixed/Auto
White Balance
Manual/Auto
BLC
On/Off
Exposure Mode
Manual/Auto
It ranges from 1/3 to 1/100000
Video
Compression
Standard
H.264/H.264B/MJPEG
Video Frame
Rate
PAL:
Main stream(1280*720@25fps)
extra stream(704*576@25fps)
NTSC:
Main stream(1280*720@30fps)
extra stream(704*480@30fps)
Video Bit Rate
H.264: 16Kbps-8192Kbps
MJPEG is adjustable and bit rate is adjustable
Support customized setup.
Video Flip
Support mirror.
Support flip function.
Snapshot
Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask
Supports max 4 privacy mask zones
Video Setup
Support parameter setup such as bright, contrast.
Video
Information
Channel title, time title, motion detect, camera masking.
Lens
3.6mm. Fixed focus.
Angle of view: 70°(H）*51.5°(V)

HD Cube Network Camera User’s Manual
3
Lens Interface
M12. Lens is the default accessories
Audio
Audio Bit Stream
One-way
Dual-way
Audio
Input/Output
Built-in microphone
Built-in microphone and speaker
Audio Bit Rate
8/16kbps 16bit
Audio
Compression
Standard
G.711A/G.711Mu/PCM
Video
Motion Detect
396 (18*22) detection zones
Activation event: video storage, image snapshot, log, email SMTP
function and etc.
Camera Masking
Activation event: alarm device, audio/video storage, image snapshot,
log, email SMTP function and etc.
Record and Backup
Record Priority
Support remote and local record
SD Card Storage
N/A
Support
Storage
Management
Support display network and local storage status
Network
Wire Network
1-channel wire Ethernet port, 10/100 Base-T Ethernet
Wireless
Network
N/A
Support
N/A
Support
Network Protocol
Standard HTTP, TCP/IP, ARP, IGMP, ICMP, RTSP, RTP,UDP, RTCP,
SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour,
SNMP.
Remote
Operation
Monitor, system setup, file download, log information, maintenance ,
upgrade and etc.
AUX
Port
IR light
IR distance is 10M.
PIR Human Body
Movement Detect
N/A
Support
WPS
N/A
Click one
button to
enable WIFI
connection
N/A
Click one
button to
enable WIFI
connection
General Parameter
Power
DC 12V
Power
Consumption
3.4W MAX
5.4W MAX
3.4W MAX
5.4W MAX
Working
Temperature
-30℃~+60℃
-30℃~+55℃
-30℃~+60℃
-30℃~+55℃
Working
Humidify
≤95%
Dimensions(mm)
66.6*99.5*131.2
Weight
200g（Excluding box）
Installation
Installation with the bracket.

HD Cube Network Camera User’s Manual
4
Model
Parameter
IPC-KW100W
IPC-KW100A
IPC-KW100
System
Main Processor
High performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network monitor, local record, and remote
operation at the same time.
User Interface
Remote operation interface such as WEB, DSS, PSS.
System Status
Bit stream statistics, log, and software version.
Video Parameter
Image Sensor
1/3-inch CMOS
Pixel
1280(H)*960(V)
Gain Control
Fixed/Auto
White Balance
Manual/Auto
BLC
On/Off
Exposure Mode
Manual/Auto
It ranges from 1/3 to 1/100000.
Video
Compression
Standard
H.264/H.264H/MJPEG
Video Frame
Rate
PAL:
Main stream(1280*960@25fps)
extra stream(704*576@25fps)
NTSC:
Main stream(1280*960@30fps)
extra stream(704*480@30fps)
Video Bit Rate
H.264H: 16Kbps-8192Kbps
MJPEG is adjustable and bit rate is adjustable
Support customized setup.
Video Flip
Support mirror.
Support flip function.
Snapshot
Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask
Supports max 4 privacy mask zones
Video Setup
Support parameter setup such as bright, contrast.
Video
Information
Channel title, time title, motion detect, camera masking.
Lens
3.6mm. Fixed focus.
Lens Interface
M12. Lens is the default accessories
Audio
Audio Bit Stream
Dual-way
N/A
Audio
Input/Output
Built-in microphone and speaker
N/A
Audio Bit Rate
8/16kbps 16bit
N/A
Audio
Compression
Standard
G.711A/G.711Mu/PCM
N/A
Video
Motion Detect
396 (18*22) detection zones
Activation event: video storage, image snapshot, log, email
SMTP function and etc.
Camera Masking
Activation event: alarm device, audio/video storage, image
snapshot, log, email SMTP function and etc.
Alarm Port
1-channel input and 1-channel output(on-
off)
N/A

HD Cube Network Camera User’s Manual
5
Record and Backup
Record Priority
Manual>Video detect>Schedule
SD Card Storage
Support
N/A
Network
Wire Network
1-channel wire Ethernet port, 10/100 Base-T Ethernet
3G
N/A
Wireless
Network
IEEE802.11a/b/g/n,
built-in antenna.
N/A
Network Protocol
Standard HTTP, TCP/IP, ARP, IGMP, ICMP, RTSP, RTP, UDP,
RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPoE, UpnP, NTP,
Bonjour, SNMP, QoS, 802.1x
Remote
Operation
Monitor, system setup, file download, log information,
maintenance , upgrade and etc.
Connection
Protocol
PSIA/ONVIF
AUX
Port
IR light
IR distance is 10M.
PIR Human Body
Movement Detect
Support, activation event, video storage, image snapshot, log,
email SMTP, function and etc.
WPS
Click one button to
enable WIFI
connection
N/A
General Parameter
Power
DC 12V
DC 12V and PoE
Power
Consumption
5.5W MAX
Working
Temperature
-30℃~+55℃
-30℃~+60℃
Working
Humidify
≤95%
Dimensions(mm)
66.6*99.5*131.2
Weight
200g（Excluding box）
Installation
Installation with the bracket.

HD Cube Network Camera User’s Manual
6
2Framework
2.1 Device Components
You can refer to the following figure for component information. See Figure 2-1.
Figure 2-1 Component
Please refer to the following sheet for detailed information.
SN
Port Name
Indicator
Connector
Note
1
Power indicator
light
POWER
/
Green light on: System boots
up.
Green light flashed (frequency=
0.5s).
System upgrade
Alarm
Wireless alarm study
(optional, supports by
some model only)
Green light flashes
(frequency=1s): Arming delay
(optional, supports by some
model only)
2
Network
indicator light
NET
/
Wire network connection-Red
light is on.
Wireless network connection-
Green light is on.

HD Cube Network Camera User’s Manual
7
SN
Port Name
Indicator
Connector
Note
3
PIR sensor
-
/
Passive IR motion detect port. It
can detect the IR object movement
(such as human body or other
heating object).
Note:
Only certain series have this
function.
4
IR light
/
/
For lighting at night
5
Speaker
/
/
Output audio signal.
(This function is optional. For some
series product only.)
6
Microphone
/
/
Directly receive audio signal.
7
Micro SD card
Micro SD
Micro SD
card slot
SD card storage.
(This function is optional. For some
series product only.).
8
Network port
LAN
Ethernet port
Connect to standard Ethernet
cable.
Note:
Some models do not support PoE.
9
Power port
DC12V
/
Input DC 12V power.
10
Reset/WPS
button
Reset/WPS
When device works normally:
Press the WPS button of the
router and the device
respectively for at least 2
seconds. Usually the device
can connect to the router.
(Optional function supported by
some series)
Press the button for 10s,
device restores default
settings.
11
Alarm port
-
I/O port
Alarm info input/output (optional,
supported by some models only)
Port Name
SN
Name
Note
I/O Port
1
ALARM_COM
Alarm output port. It is to output the alarm signal
to the alarm device.
2
ALARM_NO
Idle
3
GND
Ground port
4
ALARM_IN
Alarm input port. It is to receive the on-off signal
from the external alarm source.

HD Cube Network Camera User’s Manual
8
2.2 Dimensions
Please refer to the following figure for dimension information. The unit is mm. See Figure 2-2.
Figure 2-2 Dimension
2.3 Bidirectional talk
2.3.1 Device-end to PC-end
Device Connection
Please connect the earphone to the audio output port in the PC. Login the Web and then click the
Audio button to enable the bidirectional talk function. You can see the button becomes yellow after you
enabled the audio talk function. Click Audio button again to stop the bidirectional talk function.
Listening Operation
Speak or play music at the device-end, you can use the earphone or the sound box of the PC-end to
listen the audio information from the device-end.
2.3.2 PC-end to the Device-end
Device Connection
Connect the speaker or the MIC to the audio input port in the PC. Login the Web and then click the
Audio button to enable the bidirectional talk function. You can see the button becomes yellow after you
enabled the audio talk function. Click Audio button again to stop the bidirectional talk function.
Listening Operation
Speak or play music at the PC-end, you can use the built-in speaker of the device-end to listen.
Note
Please go to the Master Volume interface of the PC to set first if you want to use the dual-way
bidirectional talk. Please select Front Mic mode in the record control interface. (You can select
microphone enhanced in Advanced interface if the audio is too low.)

HD Cube Network Camera User’s Manual
9
2.4 Alarm
The alarm interface is shown as in Figure 2-3. Please follow the steps listed below for local alarm input
and output connection.
1) Connect the alarm input device to the alarm input port of the I/O cable.
2) Connect the alarm output device to the alarm output port of I/O cable. Alarm output port is open
collector output which requires pull-up resistor of 10k to 3.3V eternally.
3) Open the Web, go to the Figure 2-3. Set alarm input and output correspondingly. Alarm input on
WEB corresponds to I/O cable on device. When there is alarm, alarm input device will generate signal
of high and low level. Set corresponding NO and NC inputs.
4) Set the WEB alarm output. The alarm output s for the alarm output port of the device. It is the alarm
output port of the I/O cable.
Figure 2-3 Alarm
Please refer to the following figure for alarm input information. See Figure 2-4.
Alarm input: When the input signal is idle or grounded, the device can collect the different statuses of
the alarm input port. When the input signal is connected to the 5V or is idle, the device collects the
logic “1”. When the input signal is grounded, the device collects the logic “0”.
Figure 2-4 Alarm input
Please refer to the following figure for alarm output information. See Figure 2-5.

HD Cube Network Camera User’s Manual
10
Alarm output: Alarm output is OC door, requiring increase of external pull-up resistor. Output signal is
high and low levels. After pull-up resistor is increased, output signal is high level by default. When
there is alarm output, output signal becomes low level.
Figure 2-5 Alarm output

HD Cube Network Camera User’s Manual
11
3Device Installation
This series camera support two installation modes: wall mount and pendant mount. See Figure 3-1
and Figure 3-2.
Important
Please make sure the installation surface can min support the 3X weight of the camera and the
bracket.
Step 1
Paste the installation map on the installation surface such as wall, ceiling or the wood.
Step 2
Dig holes in the installation surface according to the installation map.
Figure 3-1 Installation 1
Step 3
Insert the expansion bolts from the accessories bag to the holes you just dug. If it is the wood surface
you can skip to the next step.
Step 4

HD Cube Network Camera User’s Manual
12
Fix the device with screw in the accessories bag.
Step 5
Connect the cable and then boot up the device.
Step 6
Loosen the adjust knob for a little bit, adjust the camera to proper surveillance position according to
your actual requirements.
Step 7
Secure the knob of the bracket to fix the camera.
Figure 3-2 Installation 2

HD Cube Network Camera User’s Manual
13
4Quick Configuration Tool
4.1 Overview
Quick configuration tool can search current IP address, modify IP address. At the same time, you can
use it to upgrade the device.
Please note the tool only applies to the IP addresses in the same segment.
4.2 Operation
Double click the “ConfigTools.exe”icon; you can see an interface is shown as in Figure 4-1.
In the device list interface, you can view device IP address, port number, subnet mask, default
gateway, MAC address and etc.
Figure 4-1 Search interface
Select one IP address and then right click mouse, you can see an interface is shown as in Figure 4-2.
Select the “Open Device Web”item; you can go to the corresponding web login interface.
Figure 4-2 Search interface 2

HD Cube Network Camera User’s Manual
14
If you want to modify the device IP address without logging in the device web interface, you can go to
the configuration tool main interface to set.
In the configuration tool search interface, please select a device IP address and then double click it to
open the login interface. Or you can select an IP address and then click the Login button to go to the
login interface. See Figure 4-3.
In Figure 4-3, you can view device IP address, user name, password and port. Please modify the
corresponding information to login.
Please note the port information here shall be identical with the port value you set in TCP port in Web
Network interface. Otherwise, you can not login the device.
If you are using device background upgrade port 3800 to login, other setups are all invalid.
Figure 4-3 Login prompt
After you logged in, the configuration tool main interface is shown as below. See Figure 4-4.
Figure 4-4 Main interface
For detailed information and operation instruction of the quick configuration tool, please refer
to the Quick Configuration Tool User’s Manual included in the resources CD.

HD Cube Network Camera User’s Manual
15
5Web Operation
This series network camera products support the Web access and management via PC.
Web includes several modules: Monitor channel preview, system configuration, alarm and etc.
5.1 Network Connection
Please follow the steps listed below for network connection.
Make sure the network camera has connected to the network properly.
Please set the IP address, subnet mask and gateway of the PC and the network camera
respectively. Network camera default IP address is 192.168.1.108. Subnet mask is 255.255.255.0.
Gateway is 192.168.1.1
Use order ping ***.***.***.***(* network camera address) to check connection is OK or not.
5.2 Login and Main Interface
Open IE and input network camera address in the address bar. See Figure 5- 1.
Figure 5- 1 IP address
The login interface is shown as below. See Figure 5- 2.
Please input your user name and password.
Default factory name is admin and password is admin.
Note: For security reasons, please modify your password after you first login.
Input your IP
address here
