Daikin STREAMER C55WVM User manual

Model
MC55WVM
Floor standing or desktop type
OPERATION MANUAL
Air purifier
• Thank you for purchasing this air purifier.
• Please read the operation manual carefully and follow it for correct use.
• Please read the “Safety Precautions” section before use.
Please keep the operation manual in a safe place for later reference.
Air Purifier
►
Page 3-5
English
Nederlands
Deutsch
Français
Eλληνικά
Español
Italiano
Türkçe
Polski
Pyccкий
00_CV_3P595629-1B.indd 1 2020/04/16 11:24:32

1
01_EN_3P595629-1B.indd 1 2020/04/17 16:01:48

2
English
Contents
Troubleshooting
About the Indicator Lamps ............................................... 23
FAQs ............................................................................... 24
Troubleshooting .............................................................. 25
Specications .................................................................. 28
Advanced Settings
Streamer Output Settings ................................................ 16
Active Plasma Ion Output Settings ................................... 16
Dust / PM2.5 Sensor Sensitivity Setting ......................... 17
Settings of Modes within ECONO MODE ....................... 18
Useful Functions
Operating the Unit in a MODE ........................................ 13
AUTO FAN / ECONO / ANTI-POLLEN
Using the Child Proof Lock ............................................. 15
Adjusting Indicator Lamp Brightness ................................ 15
Operation Using Air Purifying Operation ......................................... 12
Changing the Airow Rate .............................................. 12
Maintenance
Maintenance .................................................................... 19
Streamer Unit Replace ..................................................... 21
Separately Sold Part ....................................................... 22
When Not Using the Unit for a Prolonged Period ........... 22
Safety Precautions .......................................................... 3
Precaution During Use .................................................... 5
Names of Parts and Operations ...................................... 6
Preparation Before Operation.......................................... 9
Read First
Read First
01_EN_3P595629-1B.indd 2 2020/04/17 16:01:48

3
Safety Precautions
Observe these precautions in order to prevent property damage or injury.
The consequences of incorrect use are categorised as follows:
WARNING CAUTION
Failure to follow these instructions properly
may result in personal injury or loss of life.
Failure to follow these instructions properly may
result in property damage or personal injury, which
may be serious depending on the circumstances.
Precautions to be observed are categorised using symbols:
Never attempt. Be sure to follow the instructions.
WARNING Observe in order to prevent re, electric shock or severe injury.
Concerning the power supply plug and cord
• Do not unplug while the unit is in operation. (Fire due to overheating or electric shock may result)
• Do not plug in or unplug with wet hands. (An electric shock may result)
• Do not use in such a way that the ratings of the power socket or wiring appliances
are exceeded or use a voltage outside of the range AC220-240V.
(Fire may result from overheating if the ratings of multi-socket power adapters, etc., are exceeded)
• Do not pull on the power supply cord when unplugging. (Overheating or re may result from wire breakage)
• Do not perform actions that might break the power supply plug and cord.
–Such actionsincluding damaging, modifying, forcibly bending, pulling, twisting, bundling up, placing heavy objects on
the power supply plug or cord.
If the power supply plug or cord is damaged, it must be replaced by the manufacturer, its service agent, or a similar
qualied person in order to avoid a hazard. (An electric shock, short circuiting or re may result from use while
damaged)
• Insert the power supply plug rmly all the way in.
–Do not use a damaged power supply plug or a loosely tted power socket.
(Electric shock, short circuiting or re due to overheating may result if the power supply plug is not rmly inserted)
• Periodically wipe dust off the power supply plug with a dry cloth.
–If the unit is not to be used for a prolonged period, unplug the power supply.
(Fire may be caused by defective insulation resulting from dust buildup with moisture, etc.)
• When performing maintenance, inspecting or moving the unit, be sure to turn off
and unplug the unit. (An electric shock or injury may result)
Do not use in the following places
• Places where oil or ammable gases are used or may leak. (Fire or smoke may result from
ignition or suction toward the unit, or injury may result from degradation or cracking of plastic)
• Places where there are corrosive gases or metal dust particles.
(Fire or smoke may result from ignition or suction toward the unit)
• Places where temperature and humidity levels are high or water may scatter, such
as a bathroom.
(Fire or an electric shock may result from electrical leakage)
• Places accessible to small children. (An electric shock or injury may result)
Read First
01_EN_3P595629-1B.indd 3 2020/04/17 16:01:49

4
English
WARNING Observe in order to prevent re, electric shock or severe injury.
During use
• Do not use chlorinated or acidic detergents. (Injury may result from degradation or cracking of
plastic, or harm may be caused to health from the production of toxic gases)
• Keep burning cigarettes or incense sticks away from the unit.
(Fire or smoke may result from ignition or suction toward the unit)
• Do not attempt to disassemble, reconstruct or repair the unit yourself.
(Fire, an electric shock or injury may result) For repairs, please contact the place of purchase.
• Do not insert ngers, sticks, or any other item, into the air inlets or air outlet.
(An electric shock, injury or damage may result)
• Do not pour water onto the air outlet or the unit. (Fire or an electric shock may result)
• Do not use ammable substances (hair spray, insecticide, etc.) near the unit.
Do not wipe the unit with benzine or thinner. (An electric shock, re or cracking may result)
Concerning the remote controller
• Do not place the remote controller in places that can be reached by small children.
(Bodily harm may result from misoperation of the unit or accidental ingestion of the battery)
• Make sure not to put the battery in the wrong polarity (+/-) orientation.
(Short circuiting, re or battery leakage may result)
Immediately turn off and unplug the unit if there are any signs of abnormality and
malfunction
Examples of abnormality and malfunction
•
The unit does not operate even if the switch is turned on.
• Current passes through the cord or fails to pass through if the cord is moved.
• There are abnormal sounds or vibrations during operation.
• The casing of the unit has become deformed or is abnormally hot.
• There is a burnt smell. (Malfunction, an electric shock, smoke, re, etc., may result if the abnormality is not addressed
and the unit continues to be used)
Contact the place of purchase.
CAUTION
Observe in order to prevent electrical leakage, injury or property damage.
During use
• Small children or immobile persons (due to illness or injury) should not operate the
unit by themselves.
For EU, Turkey:
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without
supervision.
For other regions:
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
–Children should be supervised to ensure that they do not play with the appliance.
–Persons who are heavily intoxicated or have taken sleep medication should not operate the unit.
(An electric shock, injury or poor health may result)
Read First
01_EN_3P595629-1B.indd 4 2020/04/17 16:01:49

5
CAUTION
Observe in order to prevent electrical leakage, injury or property damage.
• Do not use products that contain ne powder, such as cosmetics, near the unit.
(An electric shock or malfunction may result)
• Do not operate the unit when fumigating insecticide is in use.
–After using insecticide, be sure to sufciently ventilate the room before operating the unit.
(Harm may be caused to health from an outow of accumulated chemical compounds from the outlet)
• Do not use the unit near a smoke detector.
–If the air coming out of the unit ows in the direction of the smoke detector, the response of the smoke detector may
be delayed or it may fail to detect smoke.
• Frequently ventilate the room when using the unit together with combustion-based heating devices.
–Usage of this product is not a substitute for ventilation. (Potential cause of carbon monoxide poisoning)
This product cannot eliminate carbon monoxide.
• If the unit is placed within reach of a pet, be careful that the pet does not urinate on
the unit or chew on the power supply cord. (Fire, an electric shock or injury may result)
Concerning the unit body
• Do not block the air inlets or air outlet with laundry, cloth, curtains, etc.
(Overheating or re may result from poor circulation)
• Do not climb, sit or lean on the unit. (Injury may result from falling or toppling)
When moving the unit
• When picking up the unit to move it, handle the unit with caution.
–Be sure to always hold the unit using the correct grip locations. Do not hold the unit using
the grip on the deodorising lter unit. (Injury may result from the unit falling)
CJOR002EU
Hold these grips
(2 places)
Do not hold
this grip
Safety Precautions
Precaution During Use
Other consideration
Do not use this product for special purposes such as in the preservation of works of art, academic
texts/materials, etc.
(Degradation of preserved items may result)
Read First
About streamer discharge and active plasma ions
In some cases the air outlet may emit a slight odour as
trace amounts of ozone are generated. However, the
amount is negligible and is not harmful to your health.
This product cannot eliminate all of the toxic substances
in tobacco smoke (carbon monoxide etc.)
01_EN_3P595629-1B.indd 5 2020/04/17 16:01:49

6
English
Names of Parts and Operations
Read First
CAUTION
Do not lift up the unit holding the grip on the deodorising lter unit. (Injury may result from the unit falling)
Front
Front
Back
Operating/Indicator panel
►
Page 7, 8
Deodorising
lter unit
Odour sensor
Inside the unit.
Grip
(for carrying the unit)
Active plasma ion
generation unit
Inside the air outlet.
Dust/PM2.5 sensor
Inside the air inlet
(left-side).
►
Page 7, 17, 19
Model name /
Production no. /
Manufacturing date
(MFG. DATE)
Air inlets
Front/Side
Power supply
cord
Air outlet
Power supply
plug
Main Removable Parts
Pre-lter
►
Page 19
Outow grille
►
Page 19
Streamer unit cover
►
Page 21
Deodorising lter unit
(Black lter: Deodorising lter)
►
Page 20
Dust collection lter
(electrostatic HEPA lter)
(White lter)
►
Page 20 Streamer unit
►
Page 21
Attention
To prevent malfunction, be sure to only operate the unit with all parts attached.
01_EN_3P595629-1B.indd 6 2020/04/17 16:01:49

7
Names of Parts and Operations
1About the child proof lock lamp
• When lit up, operations will be restricted. When buttons are pressed, only a tone (3 short beeps) will sound, preventing misoperation by small children.
►
Page 15
2About the streamer lamp
• During streamer operation, this lamp lights up. Streamer operation is conditional on the degree of air impurity.
• If the hissing sound generated by the streamer discharge or the odour of ozone bothers you, set streamer output to low.
►
Page 16
3About the dust sensor lamp / PM2.5 INDICATOR lamp
• After operation is started, the lamp will light green for the rst minute
(approx.) regardless of air impurity level.
• The responsiveness of the dust/PM2.5 sensor may be poor during FAN setting “Turbo” or when
airow is high in AUTO FAN MODE. The strong airow causes dust to be drawn into the air
inlets before it can be detected by the dust/PM2.5 sensor. This is normal (not a malfunction).
• If the responsiveness of the dust/PM2.5 sensor is poor, change the sensitivity
setting of the sensor.
►
Page 17
Dust/PM2.5 sensor detection range
Detectable matter
house dust, tobacco smoke, pollen, mite droppings and
remains, pet hairs, diesel particulate matter
Sometimes detectable
steam, oil smoke
4About the odour sensor lamp
• If operation is started immediately after the power supply plug is inserted, the
lamp will light green for the rst minute (approx.).
• If odour intensity levels are unchanging, the sensor may not respond even if there
is a strong odour in the air.
• The following types of odours may not be detected:
pet odours that do not include ammonia, garlic odours, etc.
• As odour perception varies by person, in some cases an odour may be sensed
even when the lamp is green.
If the odour bothers you, switch to manual airow rate, and select a high airow
rate.
►
Page 12
Odour sensor detection range
Detectable matter
tobacco odours, cooking odours, pet odours, toilet
smells, waste smells, mould odours, sprays, alcohol
Sometimes detectable
sudden changes in temperature/humidity, steam, oil
smoke, gas emitted from combustion-based heating
devices
The basic sensitivity of the odour sensor will be determined by odour levels in the rst minute (approx.) after the power supply plug is inserted
every time. Insert the power supply plug when the air is clean (odour-free).
Read First
Operating/Indicator panel When a lamp is blinking
►
Page 23
1
Child proof lock lamp [orange]
Lamp will be lit when the child proof lock active.
MODE lamps [green]
Indicate the MODE in operation.
ON/OFF lamp [green]
Lamp will light up when the power is ON.
FAN lamps [green]
Indicate the active FAN setting (4 settings: Quiet, Low, Standard, Turbo).
3Dust sensor lamp / PM2.5 INDICATOR lamps
Indicate the volume of dust in the ambient air.
• Green indicates that the air is clean.
• The dust/PM2.5 sensor can detect small (approx. 1.0-2.5μm) and large (approx. 2.5μm and
above) dust particles. The PM2.5 INDICATOR lamps light in response to small particles and
the dust lamp lights in response to large dust particles.
Green Orange Red
Low High
Lamp
colour
Dust
[Dust sensor lamp]
Low
HighGreen
Green
Lit up
Yellow Orange Red Purple Brown
Dust
[PM2.5 INDICATOR lamps]
2Streamer lamp [blue]
Lights up when the streamer is active.
4Odour sensor lamp
Indicates the intensity of odours in 3
colours: green, orange, red.
• Green indicates that the air is clean.
Green Orange Red
Low High
Lamp
colour
Odours
01_EN_3P595629-1B.indd 7 2020/04/17 16:01:50

8
English
Read First
Operating/Indicator panel
Signal receiver
Receives signals from the remote controller.
Receiving tones sound when signals are
received, conrming successful reception.
• Operation start...2 short beeps
• Setting change...1 short beep
• Operation end...1 long beep
FAN/MODE button
Press to cycle between FAN settings
and MODEs.
►
Page 12-14
ON/OFF button
Press to turn the power ON or OFF.
►
Page 12
Signal transmitter
• Transmits signals to the unit.
• The unit may fail to receive signals if
anything is blocking the signals, such as a
curtain.
• Maximum transmission range is approx.
6m (straight line).
Remote controller
ON/OFF button
Press to turn the power ON or OFF.
►
Page 12
FAN button
Press to cycle between FAN settings.
►
Page 12
MODE button
Press to cycle between MODEs.
►
Page 13, 14
BRIGHTNESS button
Press to cycle through brightness levels
(BRIGHT, DIM, OFF*).
*Not all lamps are turned off.
►
Page 15
LOCK button
Prevents misoperation by small children.
►
Page 15
Accessories
Remote controller .... 1Deodorising lter ................1
Attach to the unit before
operation.
Operation manual ...............1
In the bottom of the packing
case.
Remote controller
holder....................... 1
01_EN_3P595629-1B.indd 8 2020/04/17 16:01:50

9
Preparation Before Operation
Read First
1Positioning the unit
Before setting up, remove
the fixing tape on the bottom
which is securing the power
supply cord, then take out
the power supply cord.
Power supply cord
Fixing tape (blue)
Pointers for good positioning
• Choose a position from where airow can reach all areas of the
room.
• Place on a stable surface. If the unit is placed on an unstable
surface, vibrations from the unit may be amplied.
• If interference from the power circuit inside the unit or cables
causes disturbance of TV screen images or the emission of
static noise from nearby radios or stereos, move the unit to at
least 2m away from the device.
Keep cordless phones and radio-controlled clocks away from
the unit also.
Attention
• To avoid staining of walls, position the unit in accordance with
the positioning measurements in the illustration. However, note
that since this unit draws in dirty air, certain types of wall may
become stained even if the measurements are adhered to.
In such cases, be sure to maintain sufcient distance between
the unit and the wall.
• When used for a prolonged period in the same location, the
oor and surrounding walls may become stained as air is drawn
into air inlets near the base of the unit. Periodic cleaning is
recommended.
At least 100cm
away from ceiling
At least 30cm
away from wall Air ow
At least 10cm
away from wall
At least 30cm
away from wall
Do not use in the following places
Places exposed to direct sunlight
(A decline in the receptivity of the signal from the remote
controller or discolouration may result)
Positions near combustion-based heating and other
high temperature devices
(Discolouration/deformation due to overheating may
result)
Places where chemicals and pharmaceuticals are
used such as hospitals, factories, laboratories, beauty
salons, and photographic laboratories
(Volatilised chemicals and solvents may degrade
mechanical parts and lead to malfunction)
Places with high levels of electromagnetic waves such
as near an electromagnetic cooker, speakers, etc.
The unit may not function correctly.
Places exposed to soot (conductive dust) released by
candles, aromatic candles, etc.
The performance of the lters may be impaired, causing
the room to become dirty due to the build-up of dust that
is not captured.
Do not use cosmetics etc., containing silicone* near
the unit.
* Hair care products (split ends coating agents, hair
mousse, hair treatment agents etc.), cosmetics,
antiperspirants, antistatic agents, waterproof sprays,
lustering agents, glass cleaners, chemical wiping
cloths, wax, etc.
• Insulators such as silicone may adhere to the needle
ofthe streamer unit, and the streamer discharge may
not be generated.
• The dust collection lter may become clogged up,
resulting in loss of air purifying capacity.
Do not use an ultrasonic humidier or similar
appliance near the unit.
The dust collection lter may become clogged up,
resulting in loss of air purifying capacity.
Keep out of
direct sunlight
Do not block air
inlets or air outlet
Do not expose to direct airow
Keep TVs and radios
at least 2m away
01_EN_3P595629-1B.indd 9 2020/04/17 16:01:50

10
English
2Attaching the deodorising lter
1. Remove the deodorising lter unit from the
main unit.
►
Page 20
Front side
Back side
Hooks (large)
Hook (small)
Fixed parts
Hook (small)
Back side of the deodorising lter unit
►
Page 20
Deodorising lter unit
2. Remove the deodorising lter from the bag.
Wear gloves to prevent dust from the deodorising
lter making hands dirty.
Deodorising lter
3. Turn the deodorising lter unit over and
attach the deodorising lter.
1 Set the deodorising lter under the xed parts
(3places).
2While spreading the frame, set the deodorising
lter under the hooks (small) in 2 places.
Hook (small)
Deodorising lter
Hook (small)
Fixed parts
(Back side of deodorising lter unit)
Set while
spreading
the frame
3While pressing the protrusions on the hooks
(large) on the front side of the deodorising lter
unit, push the deodorising lter in and set it under
the hooks (large) in 2 places to attach.
Hooks (large)
(Back side of deodorising lter unit)
Deodorising lter
Press the protrusions on the
hooks (large) on the front side
of the deodorising lter unit.
4 Double check that the deodorising lter is set
under the hooks (large).
Hooks (large)
Deodorising lter
Hook (small) Hook (small)
Fixed parts
(Back side of deodorising lter unit)
4. Install the deodorising lter unit into the
main unit.
►
Page 20
• When starting operation, if the odour
sensor lamp blinks, the deodorising
filter is not properly attached.
• Observe local waste separation rules when
disposing of the lter bag and desiccant.
CAUTION
Carry out these steps before inserting the power supply plug.
Read First
01_EN_3P595629-1B.indd 10 2020/04/17 16:01:51

11
Preparation Before Operation
Read First
3Preparing the remote controller
1. Attach the remote controller holder.
• Insert the hook on the remote controller holder into
the notch in the back of the unit.
Notch
Insert all the way.
Hook
2. Pull out the transparent sheet.
• After removing the transparent sheet, the remote
controller is ready for use.
Battery is
pre-loaded
Transparent
sheet
How to use
• Direct the signal transmitter on the remote controller at
the signal receiver on the unit. The unit may fail to receive
signals if anything is blocking the signals, such as a
curtain.
•
Maximum transmission range is approx. 6m (straight line).
30° 30°
[Viewed from above]
Approx. 4mApprox. 4m
Approx. 6m
Signal
receiver Signal
transmitter
About the remote controller
• Be sure not to drop or allow water to get into the remote
controller. (Malfunction may result)
• Signal reception may be poor in rooms with electronic-
starter-type uorescent lamps (inverter-type uorescent
lamps etc.).
• Do not use near lighting equipment (within 1m).
(A decline in the receptivity of the signal from the remote
controller or discolouration may result)
Replacing the battery
1. Move the catch on the battery tray at the
bottom of the remote controller in the
direction of the arrow.
2. Pull out the battery tray.
3. Replace the battery.
4. Return the battery tray to its original position.
3
42
Battery (CR2025)
Load so that battery + side and side of
battery tray with + mark face same direction
Catch
+ mark
About the battery
• Keep batteries out of reach of children.
In the event that batteries are swallowed, go immediately
to the nearest medical emergency services.
• To avoid possible injury or damage from battery leakage
or rupturing, remove the battery when not using the
product for a prolonged period.
• If the battery solution should get in the eyes, do not rub
the eyes. Instead, immediately ush the eyes with tap
water and seek the attention of a medical professional.
• Do not expose batteries to heat or re. Do not
disassemble or modify batteries.
The insulation or other parts inside the battery may be
damaged, resulting in battery leakage, rupturing or
overheating.
• When disposing of the battery, insulate the terminal by
wrapping it in tape etc.
(Overheating, rupturing or re may result if stored
together with other metal objects or batteries)
Observe local waste separation rules when disposing
of batteries.
• While the general battery replacement timing is once a
year, if signal reception weakens, the battery should be
replaced with a new battery (CR2025).
• Batteries with an expiration date that is close may
require replacement sooner.
• The pre-loaded battery is for initial use of the unit and
may require replacement in less than 1 year.
4Inserting the power supply plug into the socket
• The basic sensitivity of the odour sensor will be determined by odour
levels in the rst minute (approx.) after the power supply plug is
inserted every time.
Insert the power supply plug when the air is clean (odour-free).
Power supply plug
Power socket
01_EN_3P595629-1B.indd 11 2020/04/17 16:01:51

12
English
Operation
WARNING
Do not turn off the unit by unplugging it from the power socket.
(Fire due to overheating or electric shock may result)
Operation
Operation
Remote controller
Operation via remote controller.
Unit
Operation via operating/indicator panel on unit.
Detailed settings can be made
using the remote controller.
Changing the Airow Rate
Select the desired FAN setting.
: Quiet : Low : Standard : Turbo
***
* The size of the symbols varies in accordance
with the FAN setting.
Remote controller
Press .
• Each press cycles between the FAN
lamps [green].
(Quiet)
(Turbo)
(Low)
(Standard)
Unit
Press .
• Each press cycles between the FAN lamps [green] and MODE lamps [green].
(Quiet) (Low) (Standard) (Turbo)
FAN
MODE
(ANTI-POLLEN) (ECONO) (AUTO FAN)
About FAN settings
Quiet A gentle breeze is emitted. Recommended for use during sleep hours.
As the deodorising capacity is reduced, it is recommended that the FAN setting be set to Standard or above if
odour needs to be quickly eliminated from a room.
Turbo The ambient air is quickly puried using a large airow. Recommended for use while you are cleaning up a room.
Using Air Purifying Operation (turning operation ON/OFF)
Puries the air in the room.
Remote controller
Press .
Unit
Press .
• Press again to turn OFF.
• ON/OFF lamp [green] lights up.
Attention
• Do not move the unit, or attach or remove parts to/from the unit while it is in operation. Breakage
or malfunction may result.
Note
• At the time of purchase, the unit is set to Air purifying operation, AUTO FAN MODE with active plasma ion generation set to ON.
• When the unit is unplugged or turned OFF, it will operate with the settings last used the next time it is turned ON.
• Operation settings cannot be changed for about 2 seconds immediately after the power supply plug is inserted.
01_EN_3P595629-1B.indd 12 2020/04/17 16:01:52

13
Useful Functions
Useful Functions
Remote controller Unit
Operating the Unit in a MODE
Select a MODE specic to your needs.
Airow is adjusted automatically when the unit is running in a MODE.
Remote controller
Press .
• Each press cycles between the MODE lamps [green].
(AUTO FAN) (ECONO) (ANTI-POLLEN)
Unit
Press .
• Each press cycles between the MODE lamps [green] and FAN lamps [green].
FAN
MODE
FAN
(Quiet)(Low) (Standard) (Turbo)
(AUTO FAN) (ECONO) (ANTI-POLLEN)
01_EN_3P595629-1B.indd 13 2020/04/17 16:01:53

14
English
Useful Functions
MODE Usage and Function
AUTO FAN
Automatic airflow rate adjustment
FAN setting (Quiet, Low, Standard, High) is automatically adjusted according to the degree of air
impurity.
Purifying capacity increases as airow rate rises.
• Degree of air impurity corresponds to the volume of dust and the intensity of odours in the ambient air.
ECONO
Saving energy
In Power saving mode within ECONO MODE, the FAN setting automatically switches between Quiet
and Low only. Power consumption (*1) and operating sounds are reduced.
If the air is clean, after a short while, Monitoring mode automatically activates.
Recommended for use during sleep hours.
*1 By comparison to AUTO FAN MODE (approx. 10.3Wh), power consumption in ECONO MODE (approx.
6.7Wh) is approx. 3.6Wh lower.
Test conditions: operation in 10m2area over 1 hour. Assuming 1 cigarette was smoked immediately
after the unit was turned on.
Power saving mode
If the air is clean, after
a short while...
Monitoring mode
• The fan starts and stops periodically. Dust
and odours are monitored.
• The following functions are turned off, further
reducing power consumption.
Streamer OFF
Active plasma ion OFF
If dust or odours are
detected...
FAN setting switches
automatically between
Quiet and Low.
• As the FAN setting is limited to Quiet and Low, air purifying capacity is reduced.
• As air is not drawn in when the fan has stopped, the dust/PM2.5 sensor and odour sensor reduce in
sensitivity. To prevent this reduction in sensitivity, turn Monitoring mode OFF.
►
Page 18
• FAN setting is adjusted automatically. Airow cannot be adjusted manually.
ANTI-
POLLEN
Reducing pollen levels
A gentle air current is created by switching every 5 minutes between the FAN setting Standard and
Low so that pollen can be drawn in and caught before it reaches the oor.
• FAN setting is adjusted automatically. Airow cannot be adjusted manually.
01_EN_3P595629-1B.indd 14 2020/04/17 16:01:53

15
Useful Functions
Useful Functions
Remote controller Unit
Using the Child Proof Lock
Button operation is restricted, preventing misoperation by small children.
Remote controller
Hold down for about 2
seconds.
Unit
Cannot be set from unit.
• Hold down for 2 seconds again to turn off child proof lock.
• When child proof lock is active, operations will be restricted. When buttons are pressed, only a tone (3 short beeps) will
sound, preventing misoperation by small children.
Note
• If the unit is unplugged when child proof lock is active, child proof lock is turned off.
• The child proof lock lamp [orange] lights up when the function is active.
Adjusting Indicator Lamp Brightness
Indicator lamp brightness is adjustable.
Remote controller
Press .
Unit
Cannot be set from unit.
• Press to cycle between settings.
BRIGHT DIM OFF
Note
• This function is useful if the lamps bother you during sleep hours etc.
• The ON/OFF lamp does not turn off even if the brightness is set to OFF.
This lamp will be set to DIM.
• If any of the below buttons are pressed when brightness is set to OFF, brightness will change to DIM and return to OFF after
about 10 seconds.
· · ·
01_EN_3P595629-1B.indd 15 2020/04/17 16:01:53

16
English
Advanced Settings
If the hissing sound generated by the streamer discharge or the odour of ozone
bothers you
*Setting at time of purchase
Streamer Output Settings
Setting procedures Remote controller
Hold down and for about 3 seconds with the power supply plug inserted and the
unit turned off.
• Each time and are held down for about 3 seconds, the setting switches between Regular and Low.
[When the setting is changed to Low]
A short beep sounds and the streamer lamp blinks for about 5 seconds.
[When the setting is changed to Regular]
A short beep sounds and the streamer lamp lights up for about 5 seconds.
Operation status of streamer
Regular Low
*The streamer operation status ON–OFF
means that the streamer turns ON and OFF
automatically depending on the degree of air
impurity and FAN setting.
FAN
Quiet, Low ON–OFF* OFF
Standard ON–OFF*
Turbo ON ON
MODE AUTO FAN, ANTI-POLLEN ON–OFF* ON–OFF*
ECONO OFF
FAN/MODE setting
Streamer output setting
• The streamer lamp turns off when streamer operation is OFF.
Note
• It is recommended that the streamer be set to Regular as deodorising capacity is reduced when set to Low.
• Settings are remembered even if the unit is unplugged.
Blinking
Lit up
When you want to turn off active plasma ion output
*Setting at time of purchase
Active Plasma Ion Output Settings ON* OFF
Setting procedures Remote controller
Hold down and for about 3 seconds with the power supply plug inserted and the
unit turned off.
• Each time and are held down for about 3 seconds, the setting switches between ON and OFF.
[When the setting is changed to OFF]
A short beep sounds and the dust lamp and odour sensor lamp blink green for about 5
seconds.
[When the setting is changed to ON]
A short beep sounds and the dust lamp and odour sensor lamp light up green for about 5
seconds.
Blinking
Lit up
Note
• Settings are remembered even if the unit is unplugged.
• If set to OFF, active plasma ion discharge stops, however, dust and odour removal continues.
• If the odour of ozone bothers you, set active plasma ion output to OFF.
• If the odour of ozone continues to bother you even after output has been set to OFF, set streamer output to Low.
Regular* Low
ON* OFF
Advanced Settings
01_EN_3P595629-1B.indd 16 2020/04/17 16:01:54

17
Advanced Settings
When the sensitivity of the dust/PM2.5 sensor does not meet your preferences
*Setting at time of purchase
Dust / PM2.5 Sensor Sensitivity Setting High
Normal* Low
Setting procedures Remote controller Unit
1. Hold down on the unit for about 5 seconds and when a short beep sounds, press on the
remote controller while pressing on the unit.
• This setting change can be performed when the unit is on or off.
2. Release both buttons when a short beep sounds.
• One of the FAN lamps ( (Low), (Standard), (Turbo)) will blink for about 5 seconds and then the lamp
corresponding to the currently set sensitivity will light up.
3. Press on the unit to change the sensitivity setting.
• Each press cycles between the FAN lamps allowing you to change the sensitivity.
To set sensitivity High
Select the FAN lamp (Turbo). (Turbo)
(Standard)
(Low)
High
Normal
Low
The sensor is
highly receptive.
The sensor is
slightly receptive.
Setting at time
of purchase
To set sensitivity Low
Select the FAN lamp (Low).
• Setting is indicated using the FAN lamps. If the FAN lamps do not change, unplug the unit, wait at least 5 seconds, then
re-insert the power supply plug and repeat the above procedure from the beginning.
4. Press on the remote controller after selecting the new setting.
• A short beep sounds and the new setting will blink. Unplug the unit while the lamp is blinking, wait at least 5 seconds,
and then re-insert the power supply plug. Setting is now complete.
• If this procedure is not performed, the unit will not return to regular operation mode.
Note
• Settings are remembered even if the unit is unplugged.
High Normal* Low
Advanced Settings
01_EN_3P595629-1B.indd 17 2020/04/17 16:01:54

18
English
If you want to turn Monitoring mode (within ECONO MODE) OFF
*Setting at time of purchase
Settings of Modes within ECONO MODE Monitoring
ON* Monitoring OFF
Setting procedures Remote controller Unit
1. Hold down on the unit for about 5 seconds and when a short beep sounds, press on the
remote controller while pressing on the unit.
• This setting change can be performed when the unit is on or off.
2. Release both buttons when a short beep sounds.
• The FAN lamp (Quiet) and ECONO MODE lamp will light up after blinking for about 5 seconds.
The ECONO MODE lamp will light up or blink depending on the ON/OFF status of Monitoring mode.
3. Press on the unit to change the setting.
• Each press turns the ECONO MODE lamp ON or OFF.
(The FAN lamp (Quiet) will remain lit up.)
To turn Monitoring mode ON
Turn on the ECONO MODE lamp.
Setting at time
of purchase
ON
OFF
To turn Monitoring mode OFF
Turn off the ECONO MODE lamp.
• Setting is indicated using the ECONO MODE lamp. If the ECONO MODE lamp does not change, unplug the unit, wait at
least 5 seconds, then re-insert the power supply plug and repeat the above procedure from the beginning.
4. Press on the remote controller after selecting the new setting.
• A short beep sounds and the FAN lamp (Quiet) will blink. When Monitoring mode is turned ON, the ECONO MODE
lamp also blinks.
Unplug the unit while the lamp is blinking, wait at least 5 seconds, and then re-insert the power supply plug.
Setting is now complete.
• If this procedure is not performed, the unit will not return to regular operation mode.
Note
• Settings are remembered even if the unit is unplugged.
Monitoring
ON* Monitoring OFF
Advanced Settings
01_EN_3P595629-1B.indd 18 2020/04/17 16:01:54

19
Maintenance
WARNING
Before cleaning and maintenance work, be sure to unplug
the unit. (An electric shock or injury may result)
Maintenance
(Left-side) (Front)
(Right-
side)
Outow Grille
When dirt becomes an issue Wipe Wash/Rinse
• Wipe up dirt with a soft damp
cloth and rinse with water.
• Do not use a hard brush etc.
(Damage may result)
•
When dirt buildup is severe,
leave the part soaking in
lukewarm or room temperature
water mixed with kitchen-use
neutral detergent, thoroughly
rinse off the detergent, and leave
the part in shade to dry off.
Removing
Place ngers
into the notches
in the top of the
unit and lift.
Attaching
Pay attention
to orientation
and attach
securely.
Unit
When dirt becomes an issue Wipe
• Wipe up dirt with a soft damp cloth.
• When dirt buildup is severe, wipe up the dirt with a cloth which has
been moistened with kitchen-use neutral detergent.
• Do not use a hard brush etc. (Damage may result)
Pre-lter (Front/Left-side/Right-side)
About every 2 weeks
Vacuum clean
Wash/Rinse
• After removing any dust using a
vacuum cleaner, remove and
wash the lter with water and
then leave it in shade to dry off.
• Use a soft brush when cleaning
the spaces in the grid.
Attention
• Do not use a cotton bud or hard
brush etc.
(Partial breakage of the lter may
result)
• Do not apply heavy force. (Partial
breakage/damage of the lter may
result)
Removing
Grip the notch in the
pre-lter and pull.
1Grip either end of
the pre-lter resting
your thumb against
the unit.
2Pull toward
you.
Attaching
Insert the hooks
(2 places) into
the unit and
press until you
hear a catching
sound.
Hooks
( 2 places )
Insert the hook
(1place) into the
unit.
Push both ends
until securely
attached.
Hook (1 place)
Viewed from above
Reverse side
• When dirt buildup is severe,
leave the part soaking in
lukewarm or room temperature
water mixed with kitchen-use
neutral detergent, thoroughly
rinse off the detergent and leave
the part in shade to dry off.
Dust/PM2.5 Sensor
When dust has built up
Vacuum clean
1 Remove the pre-lter (left-side).
2
Vacuum off any dust that has adhered to
the air intake for dust/PM2.5 sensor using
the vacuum cleaner crevice tool or similar.
1
2
2
Move the
catch and pull
Lens
(internal
part)
Air intake for dust/PM2.5 sensor
About every 3 months Wipe
1 Remove the pre-lter (left-side) and the
cover for the air intake for dust/PM2.5
sensor.
2
Wipe the lens with a dry cotton bud.
Lens
Use a light if hard
to see
Use the vacuum cleaner crevice tool or similar to
remove any dust that has built up around the lens.
3Place the cover on securely.
(Malfunction may result if the cover is off)
01_EN_3P595629-1B.indd 19 2020/04/17 16:01:55
