OPERATION MANUAL
Split System
Ducted Air Conditioner
DAIKIN AUSTRALIA PTY LTD
To suit Daikin FDY "F" Series and FD "F" Series
(and other models incorporating BRC1B62/52 Remote Controller)
A
hr
C
o
AIR CONDITIONER
Dear Owner,
Thank you for installing a DAIKIN Fully Ducted Air Conditioning System. We
believe that you have purchased the best air conditioning system available.
Before operating the air conditioner please read this operating manual carefully. It
will advise you on how to operate the unit correctly, understand the air conditioners’
advanced features and help you in the unlikely event that a problem should occur.
Please keep this manual in a safe place for future reference.

2
CONTENTS
Important Safety Instructions..............................................................2
Main Switch......................................................................................2
Functions of the Remote Controller ...................................................4
General Operation ................................................................................6
Cooling.............................................................................................6
Heating.............................................................................................6
Auto Heat / Cool...............................................................................7
Program Dry.....................................................................................7
Fan Mode.........................................................................................8
Program Timer .................................................................................8
Programming the Stop Time ............................................................8
Programming the Start Time............................................................8
Programming the Start and Stop Time ............................................9
Cancelling the Start and Stop Time .................................................9
Advanced Features ..............................................................................9
Filter Clean Indicator........................................................................9
Defrost Function...............................................................................9
Hot Start System............................................................................10
Automatic Restart ..........................................................................10
Dual Remote Control Operation.....................................................10
Effective Operation.............................................................................10
Self Diagnosis.....................................................................................11
Maintenance........................................................................................11
The information provided in this manual is based on the default settings of the
microprocessor control system incorporated in the unit. The default setting may be altered
by the installer in which case the air conditioner (in particular the indoor fan) could operate
in a manner slightly different to the description in this manual. Your installer should advise
you of any alterations and their subsequent effect.

3
IMPORTANT SAFETY INSTRUCTIONS
•Never remove any fixed covers on the indoor or outdoor unit. Removal of the covers
may expose fast moving fan blades or electrical components operating at a hazardous
voltage. Contact with the blades or high voltage components may result in injury or
electric shock.
•Never insert any objects into the openings in the indoor or outdoor unit. This may
damage the product or result in injury to the person inserting the object.
•Do not expose the indoor unit or remote controller to rain or moisture. Water or other
fluids on the electrical components may result in fire or electric shock.
•Always replace any blown fuse with a fuse of the same specification. The use of the
wrong type fuse may allow the electrical wiring to overheat and catch on fire. If the
correct type fuse continues to blow contact your installer or electrician.
•Never operate the air conditioner without the return air filter(s) in place. Operating the
unit without the filter(s) will allow dust to enter the indoor unit and build up on the heat
exchanger coil and fan motor. This will cause a malfunction of the unit which will not be
covered by Warranty.
•This electrical appliance is not intended for use by young children. Young children
should be supervised to ensure that they do not play with the outdoor unit.
MAIN SWITCH
Ensure that your installer shows you the location of the main power switch for the air
conditioning system. This switch is normally located adjacent to the outdoor unit or in
the fuse box / switchboard.
The main switch must be turned on at least 6 hours before the air conditioner is
operated to warm up the compressor. Failure to do so may result in damage to the
compressor which will not be covered by warranty.
If the air conditioner is not going to be used for an extended period of time or you are
going away on holidays, the main switch should be turned off to prevent accidental
operation of the air conditioner. Remember that the main switch must be turned back
on at least 6 hours before operating the air conditioner.

A
hrhr
C
o
TEST
TEST
AIR CONDITIONER
BRC1B52/62
12345
7
8
13
14
16
15
11
12
9
17
18
19
20 21
10
6
24
23
22
REMOTE CONTROLLER
4

5
FUNCTIONS OF THE REMOTE CONTROLLER
All controls except for the ON / OFF BUTTON are located behind a swing down door on
the bottom half of the remote controller. To access these controls simply open the door by
gently pulling down on the finger grip located on the top right hand edge of the door. To
close the door simply swing it back up until it clicks into the closed position.
Once the desired temperature, fan speed and mode of operation have been set there is
no need to access the controls behind the door. Basic operation of the air conditioner is
simply a matter of pressing the ON / OFF BUTTON.
Please note that the selected temperature, fan speed and mode of operation will always
be displayed even when the air conditioner is not operating.
1. ON / OFF BUTTON
Press this button to start or stop the air conditioner.
2. OPERATION INDICATOR
This indicator illuminates when the air conditioner is operating.
3. CENTRALISED CONTROL INDICATOR
This symbol appears to indicate that the air conditioner is under control from an
optional centralised control panel.
4. HEAT RECLAIM VENTILATOR INDICATOR
This symbol appears to indicate that the optional Heat Reclaim Ventilation Unit is
operating. (for commercial use).
5. HEAT MODE INDICATOR
This symbol appears to indicate that the air conditioner is operating in the Heating
Mode. (Heat Pump model only)
6. COOL MODE INDICATOR
This symbol appears to indicate that the air conditioner is operating in the Cooling
Mode.
7. AUTO MODE INDICATOR
This symbol appears to indicate that the air conditioner is operating in the Automatic
Heating / Cooling Changeover Mode. (Heat Pump model only)
8. DRY MODE INDICATOR
This symbol appears to indicate that the air conditioner is operating in the Program
Dry Mode.
9. FAN MODE INDICATOR
This symbol appears to indicate that the air conditioner is operating in the Fan Only
Mode (ventilation).
10. TEST / INSPECTION INDICATOR
This symbol flashes to indicate that TEST / INSPECTION BUTTON has been
pressed or that the microprocessor has determined that a fault condition has
occurred.

6
11. PROGRAM STOP TIME INDICATOR
This symbol and number indicates the programmed stop (off) time.
12. PROGRAM START TIME INDICATOR
This symbol and number indicates the programmed start (on) time.
13. SELECTED TEMPERATURE DISPLAY
This display indicates the desired room temperature.
14. FAN SPEED DISPLAY
This display indicates the selected fan speed (ie. high or low).
15. FILTER CLEAN INDICATOR
This symbol appears to indicate that the indoor return air filter may require cleaning.
16. DEFROST INDICATOR
This symbol appears to indicate that the air conditioner is in the process of removing
the build up of ice on the outdoor unit. (Heat Pump model only).
17. TIMER MODE SELECT BUTTON
Press this button to enter the desired program stop time. Press the button a second
time to enter the desired program start time.
18. PROGRAM TIMER ON/OFF BUTTON
Press this button after entering the desired off/on time to initiate the timer function.
19. TEST BUTTON
This button is for use by installation or service technicians only.
20. PROGRAM TIME BUTTON
Push on the top section (up arrow) of this button to increase the desired program
stop / start time. Push on the bottom section (down arrow) of this button to decrease
the desired program stop / start time.
21. TEMPERATURE SET BUTTON
Push on the top section (up arrow) of this button to increase the desired room
temperature. Push on the bottom section (down arrow) of this button to decrease the
desired room temperature.
22. FILTER CLEAN RESET BUTTON
Press this button to extinguish the CLEAN FILTER INDICATOR after you have
inspected / cleaned the indoor return air filter.
23. FAN SPEED SELECTOR BUTTON
Press this button to toggle between high and low fan speed.
24. MODE SELECTOR BUTTON
Press this button to change the desired mode of operation. (ie. fan, program dry,
auto, cool, heat).

7
GENERAL OPERATION
COOLING
1. Press the MODE SELECTION BUTTON (24) (if required) until the COOL MODE
INDICATOR (6) is displayed.
2. Select the desired room temperature (if required) by momentarily pressing on the top
or bottom section of the TEMPERATURE SET BUTTON (21) until the desired
temperature is displayed. Each press of the button will increase or decrease the
desired temperature by 1 degree. The desired temperature may be set in the range
of 16 - 32 degrees.
3. Press the ON / OFF BUTTON (1) to commence operation. The OPERATION
INDICATOR (2) will illuminate.
4. Select the desired fan speed (if required) by pressing the FAN SPEED SELECTOR
BUTTON (23).
5. To turn the air conditioner off simply press the ON / OFF BUTTON (1). The
OPERATION INDICATOR (2) will extinguish.
HEATING
(Heat Pump Models Only)
1. Press the MODE SELECTION BUTTON (24) (if required) until the HEAT MODE
INDICATOR (5) is displayed.
2. Select the desired room temperature (if required) by momentarily pressing on the top
or bottom section of the TEMPERATURE SET BUTTON (21) until the desired
temperature is displayed. Each press of the button will increase or decrease the
desired temperature by 1 degree. The desired temperature may be set in the range
of 16 - 32 degrees.
3. Press the ON / OFF BUTTON (1) to commence operation. The OPERATION
INDICATOR (2) will illuminate.
4. Select the desired fan speed (if required) by pressing the FAN SPEED SELECTOR
BUTTON (23).
Notes: As the air conditioner incorporates a hot start system, the indoor fan will run
at an extra low (or low) speed irrespective of the selected fan speed for a few
minutes when the unit is first turned on.
During the heating mode you may notice the indoor fan changing speed.
This is due to the fan switching from the selected fan speed to extra low (or
low) when the desired room temperature is reached and the compressor
cycles off.
5. To turn the air conditioner off simply press the ON / OFF BUTTON (1). The
OPERATION INDICATOR (2) will extinguish.
Note: On some occasions the indoor fan will continue to run at extra low (or low)
speed for approximately one minute after the unit has been switched off.
This is not a malfunction, it is simply a function of the unit which runs the
indoor fan to remove any excess heat in the indoor unit heat exchanger.

8
AUTOMATIC HEATING / COOLING CHANGEOVER
(Heat Pump Models Only)
When the air conditioner is operated in this mode it will automatically switch between the
heating and cooling mode.
1. Press the MODE SELECTION BUTTON (24) (if required) until the AUTO MODE
INDICATOR (7) is displayed.
When the AUTO MODE is selected either the COOL or HEAT MODE INDICATOR
will also be displayed along with the most recent temperature setting. (ie. if the last
adjustment you made was the set the cooling mode temperature to 23° then when
you select the AUTO MODE it will display AUTO COOLING at a temperature of 23°).
The air conditioner will then measure the room temperature and select the applicable
mode (ie. heating or cooling) based on the current and desired room temperature.
2. Adjust the desired room temperature (if required) by momentarily pressing on the top
or bottom section of the TEMPERATURE SET BUTTON (21) until the desired
temperature is displayed. Each press of the button will increase or decrease the
desired temperature by 1 degree. The desired temperature may be set in the range
of 16 - 32 degrees.
3. Press the ON / OFF BUTTON (1) to commence operation. The OPERATION
INDICATOR (2) will illuminate.
4. Select the desired fan speed (if required) by pressing the FAN SPEED SELECTOR
BUTTON (23).
5. To turn the air conditioner off simply press the ON / OFF BUTTON (1). The
OPERATION INDICATOR (2) will extinguish.
PROGRAM DRY MODE
When the air conditioner is operated in this mode the microprocessor will give priority to
reducing the humidity level rather than the room temperature. (Please note that there may
still be some reduction in room temperature depending on ambient conditions). This mode
is normally used in very humid environments where the conditions may still be
uncomfortable even though the room temperature is fairly low. The air conditioner will not
enter the dry mode if the room temperature is below 16°C.
1. Press the MODE SELECTION BUTTON (24) (if required) until the DRY MODE
INDICATOR (8) is displayed.
2. Press the ON / OFF BUTTON (1) to commence operation. The OPERATION
INDICATOR (2) will illuminate.
3. To turn the air conditioner off simply press the ON / OFF BUTTON (1). The
OPERATION INDICATOR (2) will extinguish.
Please note that the SELECTED TEMPERATURE DISPLAY (13) and FAN SPEED
DISPLAY (14) will not appear during PROGRAM DRY operation.

9
FAN MODE
When the air conditioner is operated in the FAN MODE only the indoor fan is energised.
The outdoor unit will not operate and therefore heating or cooling will not be provided. This
mode is useful for circulating the air within the building.
1. Press the MODE SELECTION BUTTON (24) (if required) until the FAN MODE
INDICATOR (9) is displayed.
2. Press the ON / OFF BUTTON (1) to commence operation. The OPERATION
INDICATOR (2) will illuminate.
3. Select the desired fan speed (if required) by pressing the FAN SPEED SELECTOR
BUTTON (23).
4. To turn the air conditioner off simply press the ON / OFF BUTTON (1). The
OPERATION INDICATOR (2) will extinguish.
Please note that the SELECTED TEMPERATURE DISPLAY (13) will not appear during
FAN MODE operation.
PROGRAM TIMER
The air conditioner can be programmed to automatically turn on or off in 1 hour
increments up to 72 hours in advance. It may also be programmed to turn on for a
determined time then off again or vice versa provided that the last operation (ie. switch on
or off) is within 72 hours.
PROGRAMMING THE STOP TIME
1. Press the TIMER MODE SELECT BUTTON (17) once. The PROGRAM STOP TIME
INDICATOR (11) will flash.
2. Select the desired STOP TIME by momentarily pressing on the top or bottom section
of the PROGRAM TIME BUTTON (20) until the desired elapsed time is displayed.
Each press of the button will increase or decrease the elapsed time by 1 hour.
3. Once the desired STOP TIME is displayed press the PROGRAM TIMER ON/OFF
BUTTON (18). The PROGRAM STOP TIME INDICATOR (11) will stop flashing and
remain displayed.
4. Operate the air conditioner in the desired mode as described above. The PROGRAM
STOP TIME INDICATOR (11) will count down towards zero. When zero is reached
the air conditioner will stop operating.
PROGRAMMING THE START TIME
1. Press the TIMER MODE SELECT BUTTON (17) two times (or only once if a stop
time has been set). The PROGRAM START TIME INDICATOR (12) will flash.
2. Select the desired START TIME by momentarily pressing on the top or bottom
section of the PROGRAM TIME BUTTON (20) until the desired elapsed time is
displayed. Each press of the button will increase or decrease the elapsed time by 1
hour.

10
3. Once the desired START TIME is displayed press the PROGRAM TIMER ON/OFF
BUTTON (18). The PROGRAM START TIME INDICATOR (12) will stop flashing and
remain displayed.
4. Set the air conditioner in the desired mode as described above but do not press the
ON/OFF BUTTON (1). The PROGRAM START TIME INDICATOR (12) will count
down towards zero. When zero is reached the air conditioner will start operating.
PROGRAMMING THE START AND STOP TIME
It is possible to set both the start and stop time so that the air conditioner either starts after
a predetermined time and then stops after a further predetermined time or stops after a
predetermined time and then starts again after a further predetermined time.
This is achieved by setting both the on and off time as described above. For example if
you require the air conditioner to stop in 3 hours time and then start up again 6 hours later
you would program a stop time of 3 hours and a start time of 9 hours (ie. 3 + 6 hours).
CANCELLING THE START OR STOP TIME
If you change your mind and do not want the air conditioner to automatically start or stop
simply press the PROGRAM TIMER ON/OFF BUTTON (18) and the START or STOP
TIME INDICATOR will extinguish.
ADVANCED FEATURES
FILTER CLEAN INDICATOR
The indoor microprocessor monitors the accumulated running time of the unit and after a
preset number of running hours displays the FILTER CLEAN INDICATOR (15) on the
remote controller. This indicator is a reminder to check and clean (if required) the return
air filter(s).
After you have inspected and cleaned the filter(s) press the FILTER CLEAN RESET
BUTTON (22) to extinguish the display and reset the accumulated time counter.
As the type of filter is selected by your installer it is not possible for us to describe the
method of removing and cleaning the filter(s). Please consult your installer regarding the
maintenance of the air filter(s).
DEFROST FUNCTION
During heating at low outside air temperatures it is possible for frost to build up on the
outdoor unit heat exchanger. This build up of frost will restrict the airflow through the heat
exchanger and therefore the performance of the air conditioner will gradually be reduced.
As the outdoor unit microprocessor is constantly monitoring system performance and
ambient temperature it will recognise that frost is building up on the heat exchanger and
activate the defrost mode.
When the unit enters the defrost mode both the indoor and outdoor fans will stop and the
DEFROST INDICATOR (16) will be displayed on the remote control. The unit will remain
in the defrost mode for around 4 to 8 minutes (10 min. max.) during which time the heat
exchanger will warm up to defrost itself.

11
HOT START SYSTEM
(Heat Pump Models Only)
To prevent a cold blast of air when the air conditioner turns on in the heating mode the
indoor unit incorporates a computer controller hot start system.
The indoor unit microprocessor monitors the temperature of the indoor heat exchanger
and operates the indoor fan at a speed lower than the normal low until the heat exchanger
temperature reaches a target temperature. When this target is reached the fan switches
from extra low to normal low. The air conditioner will then operate at normal low until a
second higher target temperature is reached at which point the fan will switch to selected
speed. This hot start feature is also utilised after defrost and during the heating cycle
when the compressor switches back on after the room temperature has fallen more than
1°C below the selected temperature.
AUTOMATIC RESTART AFTER POWER FAILURE
If the air conditioner is operating during a power failure it will automatically restart in the
same mode when the power is restored.
DUAL REMOTE CONTROL OPERATION (Optional)
A second (optional) remote control may be added to the system to allow setting and
control of the unit at two different locations. This is particularly useful in two storey
applications where one controller can be installed upstairs and the other controller
downstairs. When dual controls are used the air conditioner will obey the last command
entered into either controller. Both controllers will display the same information so if the
temperature on the downstairs controller is increased from 21 to 23 degrees, the upstairs
controller will also indicate 23 degrees.
EFFECTIVE OPERATION
For best results from your air conditioner we recommend the following:-
•Do not leave open any windows or door which will allow the loss of conditioner air.
•Draw blinds or curtains over windows to prevent direct sunlight entering during the
cooling cycle.
•Set the desired room temperature to avoid excessive heating or cooling.
•Keep the air filters clean.

12
SELF DIAGNOSIS FUNCTION
In the unlikely event that a fault develops with the air conditioner the microprocessor in the
indoor and outdoor units will diagnose the fault (where possible), display a unique fault
code on the remote controller (see below) and flash the OPERATION INDICATOR (2) on
and off. If this occurs take a note of the fault code (eg. E9) and contact your installer. This
code will indicate to the installer / repairer what the problem may be.
MAINTENANCE
•Regularly clean the indoor return air filter(s).
•Regularly inspect the outdoor unit to ensure the heat exchanger coil (aluminium fins)
and fan outlet are not obstructed by vegetation or any other foreign objects.
•Clean the outdoor unit heat exchanger coil annually or as required by location or
outdoor air quality. The coil may be cleaned by spraying the fins with low pressure
water in a downwards direction (ie. simulating heavy rain). Alternatively have the work
done by your installer.
•Regularly check the paint work of the outdoor unit for scratches or signs of corrosion.
Apply touch up or anti-corrosion paint as necessary.
DAIKIN AUSTRALIA PTY LIMITED
A.C.N 000 172 967
(Incorporated in NSW)
New South Wales Queensland Victoria
77-83 Alfred Road 75 Secam Street Unit A4,2A Westall Rd
Chipping Norton 2170 Mansfield 4122 Clayton 3168
Ph. [phone] Ph. [phone] Ph. [phone]
Unit G, Garden Grove Centre South Australia Western Australia
Adamstown 2289 155 Fullarton Road 75 Beechboro Road
Ph. [phone] Rose Park 5067 Bayswater 6053
Ph. [phone] Ph. [phone]
New Zealand (Daikin distributor)
3 Goodman Place
Penrose Auckland 6 NZ
Ph. [phone] Part No. OPMAN01-1 Printed in Australia
