Daikin FTXZ25NV1B User manual

Service
Manual
[Applied Models]
zInverter Pair : Heat Pump
Inverter Pair
Wall Mounted Type FTXZ-N Series
SiMT041311E

SiMT041311E
iTable of Contents
Inverter Pair
Wall Mounted Type
FTXZ-N Series
zHeat Pump
Indoor Unit
FTXZ25NV1B
FTXZ35NV1B
FTXZ50NV1B
Outdoor Unit
RXZ25NV1B
RXZ35NV1B
RXZ50NV1B

SiMT041311E
Table of Contents ii
1. Safety Cautions.......................................................................................v
1.1 Warnings and Cautions Regarding Safety of Workers.............................v
1.2 Warnings and Cautions Regarding Safety of Users................................ xi
2. Used Icons ........................................................................................... xiv
Part 1 List of Functions ................................................................ 1
1. Functions.................................................................................................2
Part 2 Specifications .................................................................... 3
1. Specifications ..........................................................................................4
Part 3 Printed Circuit Board Connector Wiring Diagram ............. 6
1. Indoor Unit...............................................................................................7
2. Outdoor Unit............................................................................................9
Part 4 Function and Control........................................................ 11
1. Main Functions......................................................................................12
1.1 Temperature Control ..............................................................................12
1.2 Frequency Principle................................................................................12
1.3 Airflow Direction Control.........................................................................14
1.4 Fan Speed Control for Indoor Unit .........................................................18
1.5 Thermostat Control.................................................................................19
1.6 URURU HUMIDIFY / HUMID HEATING Operation ...............................20
1.7 SARARA DRY / DRY COOLING Operation ...........................................27
1.8 AUTO Operation.....................................................................................30
1.9 Sensor Operation ...................................................................................31
1.10 ECONO / OUTDOOR UNIT QUIET Operation.......................................33
1.11 POWERFUL Operation ..........................................................................34
1.12 Air Purifying and Ventilation ...................................................................35
1.13 MOLD PROOF Operation ......................................................................38
1.14 CLEANING FILTER Operation...............................................................38
1.15 INFORMATION ......................................................................................40
1.16 Brightness Setting of Indoor Unit Lamps................................................40
1.17 TIMER Operation ...................................................................................41
1.18 COMFORT SLEEP TIMER Operation....................................................42
1.19 QUICK HEATING TIMER Operation ......................................................42
1.20 Other Functions......................................................................................43
2. Control Specification .............................................................................44
2.1 Frequency Control..................................................................................44
2.2 Controls at Mode Changing / Start-up....................................................46
2.3 Discharge Pipe Temperature Control.....................................................48
2.4 Input Current Control..............................................................................49
2.5 Freeze-up Protection Control .................................................................50
2.6 Heating Peak-cut Control .......................................................................50
2.7 Draught Prevention Control (Hot-Start Function) ...................................51
2.8 Dew Prevention Control .........................................................................52
2.9 Outdoor Fan Control...............................................................................52
2.10 Defrost Control .......................................................................................53
2.11 Electronic Expansion Valve Control .......................................................54

SiMT041311E
iii Table of Contents
Part 5 Installation / Operation Manual ....................................... 57
1. Installation Manual ................................................................................58
2. Operation Manual..................................................................................77
Part 6 Service Diagnosis.......................................................... 121
1. Service Diagnosis ...............................................................................123
1.1 Indoor Unit............................................................................................123
1.2 Outdoor Unit .........................................................................................123
1.3 Remote Controller ................................................................................123
2. Troubleshooting ..................................................................................125
2.1 Error Codes and Description ................................................................125
2.2 Air conditioner does not run. ................................................................126
2.3 Air conditioner runs but does not cool (heat) the room. .......................128
2.4 When operation starts, safety breaker works. ......................................129
2.5 Air conditioner makes big noise and vibration......................................130
2.6 Air is not humidified enough. ................................................................131
2.7 FLASH STREAMER AIR PURIFYING operation does not run. ...........132
2.8 INTELLIGENT EYE operation does not run. ........................................133
2.9 Indoor Unit PCB Abnormality ...............................................................134
2.10 Freeze-up Protection Control / Heating Peak-cut Control ....................135
2.11 Fan Motor (DC Motor) or Related Abnormality.....................................137
2.12 Thermistor or Related Abnormality (Indoor Unit)..................................139
2.13 Humidity Sensor (for Humidifying) /
Humidifying Thermistor Abnormality ....................................................140
2.14 Humidity Sensor (for Room) Abnormality.............................................141
2.15 Outdoor Unit PCB Abnormality.............................................................142
2.16 OL Activation (Compressor Overload) .................................................143
2.17 Compressor Lock .................................................................................145
2.18 DC Fan Lock ........................................................................................146
2.19 Input Overcurrent Detection .................................................................147
2.20 Four Way Valve Abnormality................................................................148
2.21 Discharge Pipe Temperature Control...................................................150
2.22 High Pressure Control in Cooling .........................................................151
2.23 Compressor System Sensor Abnormality ............................................152
2.24 Power Factor Correction Circuit Abnormality .......................................153
2.25 Position Sensor Abnormality ................................................................154
2.26 Thermistor or Related Abnormality (Outdoor Unit)...............................156
2.27 Electrical Box Temperature Rise..........................................................158
2.28 Radiation Fin Temperature Rise ..........................................................159
2.29 Output Overcurrent Detection ..............................................................161
2.30 Humidifier Fan Motor System Abnormality / Fan Lock .........................163
2.31 Heater Wire Abnormality ......................................................................164
2.32 Humidifying Thermistor Abnormality /
Humidifying Heater Temperature Abnormality .....................................165
2.33 Refrigerant Shortage ............................................................................167
2.34 Low-voltage Detection or Over-voltage Detection................................169
2.35 Signal Transmission Error (Between Indoor Unit and Outdoor Unit)....171
2.36 Outdoor Unit PCB Abnormality
or Communication Circuit Abnormality .................................................173
2.37 Signal Transmission Error on Microcomputer for Humidifying .............176
2.38 Unspecified Voltage (Between Indoor Unit and Outdoor Unit).............177

SiMT041311E
Table of Contents iv
2.39 Improper Power Supply Wiring.............................................................178
2.40 Incomplete Setting for Hose Length.....................................................179
2.41 Lights-out of Microcomputer Status Lamp............................................180
3. Check ..................................................................................................181
3.1 Thermistor Resistance Check ..............................................................181
3.2 Fan Motor Connector Output Check ....................................................182
3.3 Humidity Sensor Check........................................................................182
3.4 Power Supply Waveforms Check.........................................................183
3.5 Electronic Expansion Valve Check.......................................................183
3.6 Four Way Valve Performance Check ...................................................184
3.7 Inverter Unit Refrigerant System Check...............................................184
3.8 Inverter Analyser Check .......................................................................185
3.9 Rotating Pulse Check on Outdoor Unit PCB ........................................187
3.10 Installation Condition Check.................................................................188
3.11 Discharge Pressure Check...................................................................188
3.12 Outdoor Fan System Check.................................................................189
3.13 Main Circuit Short Check......................................................................189
3.14 Power Module Check ...........................................................................190
Part 7 Tips for Servicing ........................................................... 191
1. Tips for Servicing ................................................................................192
1.1 Pump Down Operation .........................................................................192
1.2 Forced Cooling Operation ....................................................................192
2. Trial Operation ....................................................................................193
3. Field Settings ......................................................................................194
3.1 SET UP Menu ......................................................................................194
3.2 Service Setting Menu ...........................................................................194
3.3 Humidifying Hose Length Setting .........................................................197
4. Silicon Grease on Power Transistor / Diode Bridge............................198
Part 8 Appendix......................................................................... 199
1. Piping Diagrams..................................................................................200
1.1 Indoor Unit............................................................................................200
1.2 Outdoor Unit .........................................................................................200
2. Wiring Diagrams..................................................................................201
2.1 Indoor Unit............................................................................................201
2.2 Outdoor Unit .........................................................................................201

Safety Cautions SiMT041311E
v
1. Safety Cautions
Be sure to read the following safety cautions before conducting repair work.
After the repair work is complete, be sure to conduct a test operation to ensure that the
equipment operates normally, and explain the cautions for operating the product to the
customer.
Caution Items The caution items are classified into Warning and Caution. The Warning items are
especially important since they can lead to death or serious injury if they are not followed
closely. The Caution items can also lead to serious accidents under some conditions if they
are not followed. Therefore, be sure to observe all the safety caution items described below.
Pictograms This symbol indicates the item for which caution must be exercised.
The pictogram shows the item to which attention must be paid.
This symbol indicates the prohibited action.
The prohibited item or action is shown in the illustration or near the symbol.
This symbol indicates the action that must be taken, or the instruction.
The instruction is shown in the illustration or near the symbol.
1.1 Warnings and Cautions Regarding Safety of Workers
Warning
Do not store the equipment in a room with successive fire sources (e.g.,
naked flame, gas appliance, electric heater).
Be sure to disconnect the power cable plug from the plug socket before
disassembling the equipment for repair.
Working on the equipment that is connected to the power supply may cause an
electrical shock.
If it is necessary to supply power to the equipment to conduct the repair or
inspecting the circuits, do not touch any electrically charged sections of the
equipment.
If the refrigerant gas is discharged during the repair work, do not touch
the discharged refrigerant gas.
The refrigerant gas may cause frostbite.
When disconnecting the suction or discharge pipe of the compressor at
the welded section, evacuate the refrigerant gas completely at a well-
ventilated place first.
If there is gas remaining inside the compressor, the refrigerant gas or
refrigerating machine oil discharges when the pipe is disconnected, and it may
cause injury.
If the refrigerant gas leaks during the repair work, ventilate the area.
The refrigerant gas may generate toxic gases when it contacts flames.
Be sure to discharge the capacitor completely before conducting repair
work.
The step-up capacitor supplies high-voltage electricity to the electrical
components of the outdoor unit.
A charged capacitor may cause an electrical shock.

SiMT041311E Safety Cautions
vi
Do not start or stop the air conditioner operation by plugging or
unplugging the power cable plug.
Plugging or unplugging the power cable plug to operate the equipment may
cause an electrical shock or fire.
Be sure to wear a safety helmet, gloves, and a safety belt when working
at a high place (more than 2 m).
Insufficient safety measures may cause a fall accident.
In case of R-32 / R-410A refrigerant models, be sure to use pipes, flare
nuts and tools for the exclusive use of the R-32 / R-410A refrigerant.
The use of materials for R-22 refrigerant models may cause a serious accident
such as a damage of refrigerant cycle as well as an equipment failure.
Do not mix air or gas other than the specified refrigerant (R-32 / R-410A /
R-22) in the refrigerant system.
If air enters the refrigerating system, an excessively high pressure results,
causing equipment damage and injury.
Warning
Caution
Do not repair the electrical components with wet hands.
Working on the equipment with wet hands may cause an electrical shock.
Do not clean the air conditioner by splashing water.
Washing the unit with water may cause an electrical shock.
Be sure to provide the earth / grounding when repairing the equipment in
a humid or wet place, to avoid electrical shocks.
Be sure to turn off the power switch and unplug the power cable when
cleaning the equipment.
The internal fan rotates at a high speed, and may cause injury.
Be sure to conduct repair work with appropriate tools.
The use of inappropriate tools may cause injury.
Be sure to check that the refrigerating cycle section has cooled down
enough before conducting repair work.
Working on the unit when the refrigerating cycle section is hot may cause
burns.

Safety Cautions SiMT041311E
vii
Checking the area
Before beginning work, conduct safety checks to minimise the risk of ignition. When repairing
the refrigerating system, take the following precautions before work.
Work procedure
Work shall be conducted under a controlled procedure so as to minimise the risk of working in
the presence of R-32 or vapour.
General working area
All maintenance staff and others working in the local area shall be instructed on the nature of
work being carried out.
Work in confined spaces shall be avoided.
The area around the workspace shall be sectioned off. Ensure that the conditions within the
area have been made safe by control of flammable materials.
Checking for presence of refrigerant
The working area shall be checked with an appropriate refrigerant detector before and during
work, to ensure the technician is aware of potentially flammable atmospheres.
Ensure that the leak detection equipment being used is suitable for use with R-32, i.e. non-
sparking, adequately sealed or intrinsically safe.
Fire extinguishing equipment
If any hot work is to be conducted on the refrigeration equipment or any associated parts,
appropriate fire extinguishing equipment shall be made available at hand. Prepare a dry powder
or CO2 fire extinguisher adjacent to the working area.
No ignition sources
During work on a refrigeration system which involves exposing any piping work that contains or
has contained R-32, any sources of ignition shall not be used in a manner that may lead to the
risk of fire or explosion. All possible ignition sources, including cigarette smoking, should be
kept at a safe distance from the site of installation, repairing, or removing space. Before starting
work, the area around the equipment shall be examined to make sure that there are no
flammable hazard or ignition risks. No Smoking signs shall be displayed.
Ventilated area
Ensure that the working area is open or that it is adequately ventilated before work.
Adequate ventilation shall be maintained during the entire period of work.
The ventilation should disperse any released refrigerant and preferably discharge it into the
external atmosphere.
Use the welder in a well-ventilated place.
Using the welder in an enclosed room may cause oxygen deficiency.
Caution

SiMT041311E Safety Cautions
viii
Checking the refrigeration equipment
Where electrical components are to be changed, the new components shall be fit for the
purpose and have the correct specifications.
The manufacturer's maintenance and service guidelines shall be followed at all times.
If there are any unclear points, consult the manufacturer's technical department for assistance.
The following checks shall be applied to any installation work involving R-32:
• The amount of charge is in accordance with the size of the room where the refrigerant
containing parts are installed;
• The ventilation machinery and outlets are operating adequately and are not obstructed;
• If an indirect refrigerating circuit is being used, the secondary circuit shall be checked for
the presence of refrigerant;
• Marking on the equipment is visible and legible. Markings and signs that are illegible shall
be corrected;
• Refrigeration pipes or components are installed in a position where they are unlikely to be
exposed to any substance which may corrode refrigerant containing components, or the
refrigerant containing components are constructed of materials which are inherently
resistant to corrosion or are suitably protected against corrosion.
Checking electrical devices
Repair and maintenance to electrical components shall include initial safety checks and
component inspection procedures. In case there is any fault that could endanger safety, no
electrical supply shall be connected to the circuit until the fault is satisfactorily dealt with.
Initial safety checks shall include:
• that capacitors are discharged: this shall be done in a safe manner to avoid possibility of
sparking;
• that no live electrical components and wiring are exposed while charging, recovering or
purging the system;
• that the equipment is earthed at all times.
Repairs to sealed components
During repairs to sealed components, all electrical supplies shall be disconnected from the
equipment being worked upon before the removal of any sealed covers, etc. If it is absolutely
necessary to have power supplied to equipment during servicing, continuously operating leak
detection shall be installed at the most dangerous point of the system in order to warn of a
potentially hazardous situation.
Particular attention shall be paid to the following: ensure that working on electrical components
does not alter the casing in such a way that affects the level of protection including damage to
cables, excessive number of connections, terminals different from the original specification,
damage to seals, incorrect fitting of glands, etc.
Ensure that the equipment is mounted securely.
Ensure that seals or sealing materials have not degraded such that they no longer serve the
purpose of preventing the ingression of flammable atmospheres. Replacement parts shall be in
accordance with the manufacturer's specifications.
The use of silicon sealant may inhibit the effectiveness of some types of leak detection
equipment. Intrinsically safe components do not have to be isolated before working on them.
Repair to intrinsically safe components
Do not apply any permanent inductive or capacitance load to the circuit without ensuring that
this will not exceed the permissible voltage and current for the equipment in use.
Only intrinsically safe components can be worked on in the presence of a flammable
atmosphere.
The test apparatus shall be of correct rating.
Replace components only with parts specified by the manufacturer. Using other parts may
result in ignition of the refrigerant leaked into the atmosphere.
Wiring
Check that wiring is not subject to wear, corrosion, excessive pressure, vibration, sharp edges
or any other adverse environmental effects. The check shall also take into account the effects of
ageing or continuous vibration from sources such as compressors or fans.

Safety Cautions SiMT041311E
ix
Detecting of R-32
Under no circumstances shall potential sources of ignition be used in the search for or detection
of refrigerant leaks. A halide torch (or any other detector using a naked flame) shall not be used.
Leak detection methods
The following leak detection methods can be applied for systems containing R-32.
Electronic leak detectors shall be used to detect R-32, but the sensitivity may not be adequate
or may need re-calibration (detection equipment shall be calibrated in a refrigerant-free area).
Ensure that the detector is not a potential source of ignition and that it is suitable for the
refrigerant used. Leak detection equipment shall be set to the percentage of the lower
flammability limit (LFL) of the refrigerant and calibrated to fit the refrigerant employed. The
appropriate percentage of gas (maximum 25%) shall be confirmed.
Leak detection fluids are suitable for use with most refrigerants but the use of detergents
containing chlorine shall be avoided as the chlorine may react with the refrigerant and corrode
the copper piping work.
If a leak is suspected, all naked flames shall be removed or extinguished.
If a refrigerant leakage which requires brazing is found, all of the refrigerant shall be recovered
from the system, or isolated (by means of shut off valves) in a part of the system remote from
the point of the leakage. Oxygen free nitrogen (OFN) shall then be purged through the system
both before and during the brazing process.
Removal and evacuation
When breaking the refrigerant circuit to make repairs or any other purpose, conventional
procedures may be used. However, flammability must be taken into consideration. The
following procedure shall be adhered to:
• Remove refrigerant;
• Purge the circuit with inert gas;
• Evacuate the inert gas;
• Purge again with inert gas;
• Carry out cutting or brazing of the circuit.
The refrigerant shall be recovered into the correct recovery cylinders. The system shall be
cleaned with OFN to render the unit safe. (= Flushing) This process may need to be repeated
several times. Compressed air or oxygen shall not be used for this task.
Flushing shall be achieved through breaking the vacuum by filling the system with OFN until the
working pressure is achieved, then venting the OFN into the atmosphere, and finally pulling the
system down to vacuum again. This process shall be repeated until no refrigerant remains
within the system. After the last OFN charge is finished, the system shall be vented down to
atmospheric pressure to enable work. This operation is especially important if brazing
operations on the piping work are to take place.
Ensure that the outlet for the vacuum pump is not close to any ignition sources and that there is
ventilation available.
Charging procedures
In addition to conventional charging procedures, the following requirements shall be met.
Ensure that the charging equipment to be used is not contaminated by different refrigerants.
Hoses or lines shall be as short as possible to minimise the amount of refrigerant contained in
them.
• Cylinders shall be kept upright.
• Ensure that the refrigeration system is earthed before charging the system with refrigerant.
• Label the system when charging is complete (if not already).
• Extreme care shall be taken not to overfill the refrigeration system.
Before recharging, the system shall be tested for leakage with OFN. On completion of charging,
the system shall be tested before commissioning. Follow up leakage test shall be carried out
before leaving the site.

SiMT041311E Safety Cautions
x
Decommissioning
Before carrying out this procedure, it is essential that the technician is completely familiar with
the equipment and all its details. It is recommended to train technicians so that all of the
refrigerant is recovered safely. In case analysis is required before re-using the reclaimed
refrigerant, an oil and refrigerant sample shall be taken before proceeding with
decommissioning. It is essential that electrical power is available before work.
a) Comprehend the equipment and its operation.
b) Isolate the system electrically.
c) Before starting work, ensure that:
• mechanical handling equipment is available if required, for handling refrigerant cylinders;
• protective equipment can be used in compliance with specifications;
• the recovery process is supervised by a competent person at all times;
• recovery equipment and cylinders conform to the appropriate standards.
d) Pump down the refrigerant system, if possible.
e) If vacuum can not be ensured, apply a manifold so that refrigerant can be removed from
various parts of the system.
f) Make sure that the cylinder is situated on the scale before recovery takes place.
g) Start the refrigerant recovery device and operate it in accordance with the manufacturer's
instructions.
h) Do not overfill cylinders. (Do not exceed 80% liquid charge volume).
i) Do not exceed the maximum working pressure of the cylinder, even temporarily.
j) When the cylinders have been filled correctly and the process is completed, make sure
that the cylinders and the equipment are removed from site promptly and all valves on the
equipment are closed.
k) Recovered refrigerant shall not be charged into another refrigeration system before it has
been cleaned and checked.
Labelling
Equipment shall be labelled stating that it has been decommissioned and emptied of refrigerant.
The label shall be dated and signed. Ensure that there are labels on the equipment stating the
equipment contains R-32.
Refrigerant recovery
When removing refrigerant from a system, either for servicing or decommissioning, it is
recommended to conduct training so that all refrigerants can be removed safely.
When transferring refrigerant into cylinders, ensure that only appropriate refrigerant recovery
cylinders are used.
Ensure that the correct number of cylinders for holding the total system charge are available. All
cylinders to be used must be designated for the recovered refrigerant and labelled for that
refrigerant (i.e. special cylinders for the recovery of refrigerant). Cylinders shall be equipped
with a pressure relief valve and associated shut-off valves in good working order. If possible,
empty recovery cylinders shall be cooled in a separate place before recovery is conducted.
The recovery equipment shall be in good working order with instructions concerning the
equipment at hand, and shall be suitable for the recovery of R-32. In addition, a set of calibrated
weighing scales shall be available and in good working order. Hoses shall be equipped with
leak-free disconnect couplings and in good condition. Before using the recovery device, check
that it has undergone proper maintenance, that it is in satisfactory working order, and that any
associated electrical components are sealed to prevent ignition in the event of a refrigerant
leakage. Consult manufacturer if in doubt.
The recovered refrigerant shall be returned to the refrigerant supplier in the correct recovery
cylinder, with the relevant Waste Transfer Note attached. Do not mix refrigerants in recovery
units and especially not in cylinders.
If compressors or compressor oil are to be removed, ensure that the refrigerant melted into the
oil has been evacuated to an acceptable level to make certain that R-32 does not remain within
the oil. The evacuation process shall be carried out before returning the compressor to the
supplier. Only electric heating to the compressor body shall be employed to accelerate this
process. Oil drained from the system shall be treated safely.

Safety Cautions SiMT041311E
xi
1.2 Warnings and Cautions Regarding Safety of Users
Warning
Do not store the equipment in a room with successive fire sources (e.g.,
naked flame, gas appliance, electric heater).
Be sure to use parts listed in the service parts list of the applicable model
and appropriate tools to conduct repair work. Never attempt to modify the
equipment.
The use of inappropriate parts or tools may cause an electrical shock,
excessive heat generation or fire.
If the power cable and lead wires have scratches or deteriorated, be sure
to replace them.
Damaged cable and wires may cause an electrical shock, excessive heat
generation or fire.
Do not use a joined power cable or extension cable, or share the same
power outlet with other electrical appliances, since it may cause an
electrical shock, excessive heat generation or fire.
Be sure to use an exclusive power circuit for the equipment, and follow
the local technical standards related to the electrical equipment, the
internal wiring regulations, and the instruction manual for installation
when conducting electrical work.
Insufficient power circuit capacity and improper electrical work may cause an
electrical shock or fire.
Be sure to use the specified cable for wiring between the indoor and
outdoor units.
Make the connections securely and route the cable properly so that there is no
force pulling the cable at the connection terminals.
Improper connections may cause excessive heat generation or fire.
When wiring between the indoor and outdoor units, make sure that the
terminal cover does not lift off or dismount because of the cable.
If the cover is not mounted properly, the terminal connection section may cause
an electrical shock, excessive heat generation or fire.
Do not damage or modify the power cable.
Damaged or modified power cable may cause an electrical shock or fire.
Placing heavy items on the power cable, and heating or pulling the power cable
may damage the cable.
Do not mix air or gas other than the specified refrigerant (R-32 / R-410A /
R-22) in the refrigerant system.
If air enters the refrigerating system, an excessively high pressure results,
causing equipment damage and injury.
If the refrigerant gas leaks, be sure to locate the leaking point and repair
it before charging the refrigerant. After charging refrigerant, make sure
that there is no refrigerant leak.
If the leaking point cannot be located and the repair work must be stopped, be
sure to perform pump-down and close the service valve, to prevent the
refrigerant gas from leaking into the room. The refrigerant gas itself is
harmless, but it may generate toxic gases when it contacts flames, such as fan
and other heaters, stoves and ranges.

SiMT041311E Safety Cautions
xii
When relocating the equipment, make sure that the new installation site
has sufficient strength to withstand the weight of the equipment.
If the installation site does not have sufficient strength and if the installation
work is not conducted securely, the equipment may fall and cause injury.
Check to make sure that the power cable plug is not dirty or loose, then
insert the plug into a power outlet securely.
If the plug has dust or loose connection, it may cause an electrical shock or fire.
Be sure to install the product correctly by using the provided standard
installation frame.
Incorrect use of the installation frame and improper installation may cause the
equipment to fall, resulting in injury.
For unitary type
only
Be sure to install the product securely in the installation frame mounted
on the window frame.
If the unit is not securely mounted, it may fall and cause injury.
For unitary type
only
When replacing the coin battery in the remote controller, be sure to
dispose of the old battery to prevent children from swallowing it.
If a child swallows the coin battery, see a doctor immediately.
Warning
Caution
Installation of a leakage breaker is necessary in some cases depending
on the conditions of the installation site, to prevent electrical shocks.
Do not install the equipment in a place where there is a possibility of
combustible gas leaks.
If the combustible gas leaks and remains around the unit, it may cause a fire.
Check to see if the parts and wires are mounted and connected properly,
and if the connections at the soldered or crimped terminals are secure.
Improper installation and connections may cause excessive heat generation,
fire or an electrical shock.
If the installation platform or frame has corroded, replace it.
Corroded installation platform or frame may cause the unit to fall, resulting in
injury.

Safety Cautions SiMT041311E
xiii
Check the earth / grounding, and repair it if the equipment is not properly
earthed / grounded.
Improper earth / grounding may cause an electrical shock.
Be sure to measure the insulation resistance after the repair, and make
sure that the resistance is 1 MΩor higher.
Faulty insulation may cause an electrical shock.
Be sure to check the drainage of the indoor unit after the repair.
Faulty drainage may cause the water to enter the room and wet the furniture
and floor.
Do not tilt the unit when removing it.
The water inside the unit may spill and wet the furniture and floor.
Be sure to install the packing and seal on the installation frame properly.
If the packing and seal are not installed properly, water may enter the room and
wet the furniture and floor.
For unitary type
only
Caution

SiMT041311E Used Icons
xiv
2. Used Icons
The following icons are used to attract the attention of the reader to specific information.
Icon Type of
Information
Description
Warning
Warning A Warning is used when there is danger of personal injury.
Caution
Caution A Caution is used when there is danger that the reader, through
incorrect manipulation, may damage equipment, loose data, get
an unexpected result or has to restart (part of) a procedure.
Note:
Note A Note provides information that is not indispensable, but may
nevertheless be valuable to the reader, such as tips and tricks.
Reference A Reference guides the reader to other places in this binder or
in this manual, where he/she will find additional information on a
specific topic.

SiMT041311E
1List of Functions
Part 1
List of Functions
1. Functions.................................................................................................2

SiMT041311E Functions
List of Functions 2
1. Functions
Category Functions
New model
(FTXZ-N)
Old model
(FTXR-E)
Category Functions
New model
(FTXZ-N)
Old model
(FTXR-E)
Basic Function PAM control zzHealth and
Cleanliness Titanium apatite photocatalytic
air-purifying filter —z
Swing compressor zz
Reluctance DC motor zz Photocatalytic air-purifying and
deodorising filter z—
Standby electricity saving z—
Operation URURU HUMIDIFY operation zz Air filter (pre-filter) zz
SARARA DRY operation zz Air supply filter zz
DRY COOLING operation zz MOISTURISING operation zz
Programme dry operation — — FLASH STREAMER AIR
PURIFYING operation zz
AUTO operation zz
Comfortable
Airflow
Power-airflow flaps zz FRESH AIR SUPPLY
VENTILATION operation zz
Wide-angle louvres zz
Auto-swing (up and down) zz HOME LEAVE VENTILATION
operation —z
Auto-swing (right and left) zz MOULD PROOF operation zz
MOULD SHOCK OUT operation — z
3-D airflow zz CLEANING FILTER operation z—
3-area INTELLIGENT EYE
operation z—Filter cleaning indicator (remote
controller) —z
COMFORT AIRFLOW
operation —zMould proof stick — z
Hydrophilic coated indoor heat
exchanger z— Comfort airflow with
INTELLIGENT EYE sensor z—
Mould proof indoor heat
exchanger z—
Circulation airflow z—
COOLING BREEZE operation — zWashable upper grille — z
BREEZE airflow z— Wipe-clean flat panel zz
Living
Convenience
Auto fan speed zzComfortable
Temperature
Hot-start function zz
Indoor unit quiet operation zz Quick warming function
(preheating operation) —z
FAN ONLY operation z—
Inverter POWERFUL operation zz Automatic defrosting zz
ECONO operation z— Installation and
Service
Installation position setting z—
OUTDOOR UNIT QUIET
operation z—Multi-split / split type compatible
indoor unit ——
AUTO OFF operation z— Either side drain (right or left) zz
INFORMATION display zz Anti-corrosion treatment of
outdoor heat exchanger zz
CHILDPROOF LOCK zz
R/C with back light z— Low temperature cooling
operation (–15°C) ——
Remote controller setting
memory z—Self-diagnosis display (remote
controller) zz
Indoor unit lamp brightness
setting zz Home automation
correspondence zz
Multi-coloured indicator lamp — z
Indoor unit ON/OFF button zz
Auto-restart (after power failure) zz
Timer 24-hour ON/OFF TIMER
operation zz
DAILY ON/OFF TIMER
operation z—
WEEKLY TIMER operation — —
COUNTDOWN OFF TIMER
operation zz
NIGHT SET mode — z
COMFORT SLEEP TIMER
operation zz
QUICK HEATING TIMER
operation z—
Note: z: Available
— : Not available

SiMT041311E
3Specifications
Part 2
Specifications
1. Specifications ..........................................................................................4

SiMT041311E Specifications
Specifications 4
1. Specifications
50 Hz, 220 - 230 - 240 V
Notes: The data are based on the conditions shown in the table below.
The maximum allowable refrigerant charge amount is 1.34 kg.
Model
Indoor Unit FTXZ25NV1B FTXZ35NV1B
Outdoor Unit RXZ25NV1B RXZ35NV1B
Cooling Heating Cooling Heating
Capacity Rated (Min. ~ Max.)
kW 2.5 (0.6 ~ 3.9) 3.6 (0.6 ~ 7.5) 3.5 (0.6 ~ 5.3) 5.0 (0.6 ~ 9.0)
Btu/h 8,500 (2,000 ~ 13,100) 9,600 (2,000 ~ 25,500) 11,900 (2,000 ~ 18,100) 17,100 (2,000 ~ 30,700)
kcal/h 2,150 (520 ~ 3,350) 2,150 (520 ~ 6,450) 3,010 (520 ~ 4,560) 2,150 (520 ~ 7,740)
Running Current (Rated) A2.0 - 1.9 - 1.9 2.9 - 2.8 - 2.7 3.1 - 2.9 - 2.8 4.6 - 4.4 - 4.3
Power Consumption Rated
(Min. ~ Max.) W410 (110 ~ 880) 620 (100 ~ 2,010) 660 (110 ~ 1,330) 1,000 (100 ~ 2,530)
Power Factor (Rated) %93.2 - 93.8 - 89.9 97.2 - 96.3 - 95.7 96.8 - 99.0 - 98.2 98.8 - 98.8 - 96.9
COP Rated (Min. ~ Max.) W/W 6.10 (5.45 ~ 4.43) 5.80 (6.00 ~ 3.73) 5.30 (5.45 ~ 3.98) 5.00 (6.00 ~ 3.56)
Piping
Connections
Liquid mm φ6.4 φ6.4
Gas mm φ9.5 φ9.5
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m10 10
Max. Interunit Height Difference m 8 8
Chargeless m10 10
Indoor Unit FTXZ25NV1B FTXZ35NV1B
Front Panel Colour White White
Airflow Rate
H
m³/min
(cfm)
10.7 (379) 11.7 (415) 12.1 (428) 13.3 (469)
M7.5 (265) 8.6 (303) 8.4 (295) 9.2 (324)
L5.3 (188) 6.7 (236) 5.6 (197) 6.9 (245)
SL 4.0 (141) 4.8 (168) 4.0 (141) 4.8 (168)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W30 30
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downwards Right, Left, Horizontal, Downwards
Air Filter Auto cleaning filter Auto cleaning filter
Running Current (Rated) A0.14 - 0.14 - 0.13 0.14 - 0.14 - 0.13 0.14 - 0.14 - 0.13 0.14 - 0.14 - 0.13
Power Consumption (Rated) W30 - 30 - 30 30 - 30 - 30 30 - 30 - 30 30 - 30 - 30
Power Factor (Rated) %97.4 - 93.2 - 96.2 97.4 - 93.2 - 96.2 97.4 - 93.2 - 96.2 97.4 - 93.2 - 96.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 798 × 372 295 × 798 × 372
Packaged Dimensions (H × W × D) mm 434 × 865 × 361 434 × 865 × 361
Weight (Mass) kg 15 15
Gross Weight (Gross Mass) kg 19 19
Sound Pressure
Level H / M / L / SL dB(A) 38 / 33 / 26 / 19 39 / 35 / 28 / 19 42 / 35 / 27 / 19 42 / 36 / 29 / 19
Sound Power Level (H) dB 54 56 57 57
Outdoor Unit RXZ25NV1B RXZ35NV1B
Casing Colour Ivory White Ivory White
Compressor Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC40DXD 2YC40DXD
Refrigerant Oil Type FW68DA FW68DA
Charge L0.405 0.405
Refrigerant Type R-32 R-32
Charge kg 1.34 1.34
Airflow Rate Hm³/min
(cfm)
31.0 (1,093) 28.3 (999) 34.4 (1,216) 31.5 (1,113)
L22.5 (794) 16.2 (571) 22.5 (794) 16.2 (571)
Fan Type PZ440 PZ440
Motor Output W71 71
Running Current (Rated) A1.9 - 1.8 - 1.8 2.8 - 2.7 - 2.6 3.0 - 2.8 - 2.7 4.5 - 4.3 - 4.2
Power Consumption (Rated) W380 590 630 970
Power Factor (Rated) %90.9 - 91.8 - 88.0 95.8 - 95.0 - 94.6 95.5 - 97.8 - 97.2 98.0 - 98.1 - 96.2
Starting Current A2.8 4.4
Dimensions (H × W × D) mm 693 × 795 × 300 693 × 795 × 300
Packaged Dimensions (H × W × D) mm 735 × 926 × 430 735 × 926 × 430
Weight (Mass) kg 50 50
Gross Weight (Gross Mass) kg 58 58
Sound Pressure Level (H) dB(A) 46 46 48 48
Sound Power Level (H) dB 59 59 61 61
Drawing No. 3D084168 3D084169
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB Indoor ; 20°CDB Outdoor ; 7°CDB / 6°CWB 5 m

Specifications SiMT041311E
5Specifications
50 Hz, 220 - 230 - 240 V
Notes: The data are based on the conditions shown in the table below.
The maximum allowable refrigerant charge amount is 1.34 kg.
Model
Indoor Unit FTXZ50NV1B
Outdoor Unit RXZ50NV1B
Cooling Heating
Capacity Rated (Min. ~ Max.)
kW 5.0 (0.6 ~ 5.8) 6.3 (0.6 ~ 9.4)
Btu/h 17,100 (2,000 ~ 19,400) 21,500 (2,000 ~ 32,000)
kcal/h 4,300 (520 ~ 4,990) 5,420 (520 ~ 8,080)
Running Current (Rated) A5.1 - 4.9 - 4.6 6.5 - 6.2 - 6.0
Power Consumption Rated
(Min. ~ Max.) W1,100 (110 ~ 1,600) 1,410 (100 ~ 2,640)
Power Factor (Rated) %98.0 - 97.6 - 99.6 98.6 - 98.9 - 97.9
COP Rated (Min. ~ Max.) W/W 4.55 (5.45 ~ 3.63) 4.47 (6.00 ~ 3.55)
Piping
Connections
Liquid mm φ6.4
Gas mm φ9.5
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length m10
Max. Interunit Height Difference m 8
Chargeless m10
Indoor Unit FTXZ50NV1B
Front Panel Colour White
Airflow Rate
H
m³/min
(cfm)
15.0 (545) 14.4 (517)
M9.2 (326) 10.7 (378)
L6.6 (232) 7.7 (274)
SL 4.6 (164) 5.9 (210)
Fan
Type Cross Flow Fan
Motor Output W30
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downwards
Air Filter Auto cleaning filter
Running Current (Rated) A0.14 - 0.14 - 0.13 0.14 - 0.14 - 0.13
Power Consumption (Rated) W30 - 30 - 30 30 - 30 - 30
Power Factor (Rated) %97.4 - 93.2 - 96.2 97.4 - 93.2 - 96.2
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 798 × 372
Packaged Dimensions (H × W × D) mm 434 × 865 × 361
Weight (Mass) kg 15
Gross Weight (Gross Mass) kg 19
Sound Pressure
Level H / M / L / SL dB(A) 47 / 38 / 30 / 23 44 / 38 / 31 / 24
Sound Power Level (H) dB 60 59
Outdoor Unit RXZ50NV1B
Casing Colour Ivory White
Compressor Type Hermetically Sealed Swing Type
Model 2YC40DXD
Refrigerant Oil Type FW68DA
Charge L0.405
Refrigerant Type R-32
Charge kg 1.34
Airflow Rate Hm³/min
(cfm)
40.4 (1,427) 33.1 (1,170)
L22.5 (764) 16.2 (571)
Fan Type PZ440
Motor Output W71
Running Current (Rated) A5.0 - 4.8 - 4.5 6.4 - 6.1 - 5.9
Power Consumption (Rated) W1,070 1,380
Power Factor (Rated) %97.3 - 96.9 - 99.1 98.0 - 98.4 - 97.5
Starting Current A6.2
Dimensions (H × W × D) mm 693 × 795 × 300
Packaged Dimensions (H × W × D) mm 735 × 926 × 430
Weight (Mass) kg 50
Gross Weight (Gross Mass) kg 58
Sound Pressure Level (H) dB(A) 49 50
Sound Power Level (H) dB 63 64
Drawing No. 3D084170
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB Indoor ; 20°CDB Outdoor ; 7°CDB / 6°CWB 5 m
