1 Features
IndoorUnit Split-Sk FVXS-FFloorstand • Its low height enables the unit to fit perfectly beneath a window
• Can be installed against a wall or recessed
• Vertical auto swing moves the discharge flaps up and down for
efficient air and temperature distribution throughout the room
• Online controller (optional): control your indoor unit from any location
via smartphone, laptop, pc, tablet or touch screen
• Weekly timer can be set to start heating or cooling anytime on a daily
or weekly basis
• Whisper quiet operation: down to 23dBA sound pressure level
Econo mode Night set mode Fan only Powerful mode Auto cooling-
heating
changeover
Whisper quiet Indoor unit
silent operation Vertical auto swing Auto fan speed
Fan speed
steps Dry programmeTitaniumapatite photocatalytic
air purification
filter
Weekly timer Infraredremote
control Auto-restart Self diagnosis Multi model application VRV for residential
application

3
2
• Split - Sky Air • FVXS-F 3
• Indoor Unit • FVXS-F
2 Specifications
2-1 Technical Specifications FVXS25F FVXS35F FVXS50F
Power input - 50Hz Cooling Nom. kW 0.015 0.027
Heating Nom. kW 0.017 0.034
Casing Colour White
Dimensions Unit Height/Width/
Depth mm 600/700/210
Packed unit Height/Width/
Depth mm 696/786/286
Weight Unit kg 14
Packed unit kg 18
Heat exchanger Length mm 510
Rows Quantity 2
Fin pitch mm 1.2
Stages Quantity 22
Tube type ø6.35 Hi-XU
Fin Type Multi slit fin
Fan Type Turbo fan
Quantity - 1
Air flow rate Cooling High m³/min 8.2 8.5 10.7
cfm 290 -
Nom. m³/min 8.2 8.5 10.7
cfm 290 -
Low m³/min 4.8 4.9 7.8
cfm 169 -
Silent
operati
on
m³/min 4.1 4.5 6.6
cfm 145 -
Heating High m³/min 8.8 9.4 11.8
cfm 311 -
Nom. m³/min 6.9 7.3 10.1
cfm 244 -
Low m³/min 5.0 5.2 8.5
cfm 177 -
Silent
operati
on
m³/min 4.4 4.7 7.1
cfm 155 -
Fan motor Quantity - 1
Model D48D-28
Speed Steps 5 + silent, + auto 5
Cooling High/
Mediu
m/Low/
Silent
operati
on
rpm 640/520/400/360 650/530/410/380 800/700/600/520
Heating High/
Mediu
m/Low/
Silent
operati
on
rpm 680/550/420/380 700/560/420/390 850/740/630/540
Output High W 48
Sound power level Cooling dBA 52 60
Heating dBA 52 60
Sound pressure level Cooling High/Nom./Low/
Silent operation dBA 38/32/26/23 39/33/27/24 44/40/36/32
Heating Super high/High/
Nom./Low/Silent
operation
dBA -/38/32/26/23 -/39/33/27/24 -/45/40/36/32
Refrigerant Type R-410A

• Indoor Unit • FVXS-F
2
• Split - Sky Air • FVXS-F
4
2 Specifications
Standard Accessories : Wireless remote control; Quantity : 1;
Standard Accessories : Air purification filter; Quantity : 2;
Standard Accessories : Batteries; Quantity : 2;
Standard Accessories : Remote control holder; Quantity : 1;
Standard Accessories : Thermal insulation tape; Quantity : 2;
Standard Accessories : Installation manual; Quantity : 1;
Standard Accessories : Drain hose; Quantity : 1;
Standard Accessories : Operation manual; Quantity : 1;
Standard Accessories : Air supply filter; Quantity : 1;
Notes
(1) 220V
(2) 230V
(3) 240V
(4) When connected with multi-system outdoor unit, refer to the specifications of the multi outdoor unit to be connected.
Piping connections Liquid OD 6.35
Gas OD 9.5 9.52 12.7
Drain 20
Heat insulation Both liquid and gas pipes
Temperature control Microcomputer control
Air direction control Right, Left, Horizontal, Downward
Air filter Type Removable / washable / mildew proof
2-2 Electrical Specifications FVXS25F FVXS35F FVXS50F
Power supply Name V1
Phase 1~
Frequency Hz 50
Voltage V 220-240
Current Nominal running
current(RLA)-50Hz Cooling A 0.14 / 0.13 / 0.12 0.17
Heating A 0.15 / 0.14 / 0.13 0.19
Current - 50Hz Zmax List - No requirements
Maximum running current A - 0.20
Wiring connections -
50Hz For power supply Quantity - 3
Remark 3 for power supply, 4 for interunit wiring (Earth wire included) 4 for interunit wiring (earth wire
included)
2-1 Technical Specifications FVXS25F FVXS35F FVXS50F

3
3
• Split - Sky Air • FVXS-F 5
• Indoor Unit • FVXS-F
3 Options
3 - 1 Options

• Indoor Unit • FVXS-F
4
• Split - Sky Air • FVXS-F
6
4 Dimensional drawings
4 - 1 Dimensional Drawings
3D056135
F
VXS25-35F
unit (mm)
Main unit fixing screw
Note) 1. The mark (Y) shows piping direction
Main unit fixed screws
666 (half concealed)
Operation lamp
Timer lamp
Indoor unit ON/OFF switch
Signal receiver
Air outlet
selection
switch
(Inside)
Name plate
Drain
socket
Front panel fixed screws
Hole for splint
Hole for piping
Air flow
Required space
(for
maintenance)
(for
performance)
(Wall hole)
Wall hole for half concealed
Terminal block with earth
terminal
Liquid pipe (J6.4 CuT)
Gas pipe (J9.5 CuT)
Room temp. thermistor
Signal transmitter
Infrared remote control
Hole for splint
Hole for piping
Drain hose
Adjusting the air flow direction
Right/left (manual)
Upper air outlet
Lower air outlet
Upward air flow
limit (OFF)
Upward air flow
limit (ON)
Up/down (automatic)
Heat
(Heat pump model)
Hole for piping
For performance
584 (half concealed)
(Wall hole)
Front panel fixed screws
(inside)
VP20
I.D. J20
O.D. J26
L 220
50 MIN 50 MIN
Cooling / dry
A
Model name label
95 (Half concealed)
85
Cool, dry
3D056136
F
VXS50F
unit (mm)
Main unit fixing screw
Note) 1. The mark (Y) shows piping direction
Main unit fixed screws
666 (half concealed)
Operation lamp
Timer lamp
Indoor unit ON/OFF switch
Signal receiver
Air outlet
selection
switch
(Inside)
Name plate
Drain
socket
Front panel fixed screws
Hole for splint
Hole for piping
Air flow
Required space
(for
maintenance)
(for
performance)
(Wall hole)
Wall hole for half concealed
Terminal block with earth
terminal
Liquid pipe (J6.4 CuT)
Gas pipe (J12.7 CuT)
Room temp. thermistor
Signal transmitter
Infrared remote control
Hole for splint
Hole for piping
Drain hose
Adjusting the air flow direction
Right/left (manual)
Upper air outlet
Lower air outlet
Upward air flow
limit (OFF)
Upward air flow
limit (ON)
Up/down (automatic)
Cooling / dry Heat
(Heat pump model)
Hole for piping
For performance
584 (half concealed)
(Wall hole)
Front panel fixed screws
(inside)
VP20
I.D. J20
O.D. J26
L 220
50 MIN 50 MIN
A
Model name label
95 (Half concealed)
85
Cool, dry

3
5
• Split - Sky Air • FVXS-F 7
• Indoor Unit • FVXS-F
5 Centre of gravity
5 - 1 Centre of Gravity

• Indoor Unit • FVXS-F
6
• Split - Sky Air • FVXS-F
8
6 Piping diagrams
6 - 1 Piping Diagrams

3
7
• Split - Sky Air • FVXS-F 9
• Indoor Unit • FVXS-F
7 Wiring diagrams
7 - 1 Wiring Diagrams - Single Phase

• Indoor Unit • FVXS-F
8
• Split - Sky Air • FVXS-F
10
8 Sound data
8 - 1 Sound Pressure Spectrum - Cooling
∼
∼

3
8
• Split - Sky Air • FVXS-F 11
• Indoor Unit • FVXS-F
8 Sound data
8 - 2 Sound Pressure Spectrum - Heating
∼
∼
