Daikin FXFQ-P Instruction Manual

EDUS391000 - F1
AMERICAS
FXFQ-P
Ceiling Mounted Cassette Type
(Round Flow)

EDUS391000-F1
FXFQ-P 1
FXFQ-P
Ceiling Mounted Cassette Type
(Round Flow)
1.Specifications ...................................................................... 2
2.Dimensions.......................................................................... 4
3.Piping Diagrams .................................................................. 7
4.Wiring Diagrams .................................................................. 8
5.Electric Characteristics ........................................................ 9
6.Capacity Tables................................................................. 10
6.1 Cooling Capacity ..................................................................10
6.2 Heating Capacity..................................................................11
7.Sound Levels (Reference)................................................. 12
7.1 Overall ..................................................................................12
7.2 Octave Band Level...............................................................12
8.Center of Gravity ............................................................... 14
9.Installation ......................................................................... 15
10.Accessories ..................................................................... 41

Specifications EDUS391000-F1
2FXFQ-P
1. Specifications
Ceiling Mounted Cassette Type (Round Flow)
Notes:
1 Nominal cooling capacities are based on the following conditions:
Return air temperature: 80°FDB (27°CDB), 67°FWB (19.4°CWB)
Outdoor temperature: 95°FDB (35°CFB)
Equivalent ref. piping length: 25ft (7.5 m) (Horizontal)
2 Nominal heating capacities are based on the following conditions:
Return air temperature: 70°FDB(21°CDB).
Outdoor temperature: 47°FDB, 43°FWB (8.3°CDB, 6°CWB)
Equivalent ref. piping length: 25ft (7.5 m) (Horizontal)
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
4 Refer to page 9 for Power Input.
5 Sound levels are measured under JIS conditions.
Model FXFQ09PVJU FXFQ12PVJU FXFQ18PVJU FXFQ24PVJU
1, 3Cooling Capacity Btu/h 9,500 12,000 18,000 24,000
2, 3Heating Capacity Btu/h 10,500 13,500 20,000 27,000
Casing / Color Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) in. (mm) 9-11/16 × 33-1/16 × 33-1/16
(246 x 840 x 840)
9-11/16 × 33-1/16 × 33-1/16
(246 x 840 x 840)
9-11/16 × 33-1/16 × 33-1/16
(246 x 840 x 840)
9-11/16 × 33-1/16 × 33-1/16
(246 x 840 x 840)
Coil (Cross
Fin Coil)
Rows×Stages×FPI 2×6×21 2×6×21 2×6×21 2×10×21
Face Area ft² (m²) 2.87 (0.9) 2.87 (0.9) 2.87 (0.9) 4.80 (1.46)
Fan
Model QTS48C15M QTS48C15M QTS48C15M QTS48C15M
Type Turbo Fan Turbo Fan Turbo Fan Turbo Fan
Motor Output W 56 56 56 56
Air Flow Rate (HH/H/L) cfm 460/390/350 460/390/350 560/470/390 780/620/470
Drive Direct Drive Direct Drive Direct Drive Direct Drive
Temperature Control Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material Polyurethane Form Polyurethane Form Polyurethane Form Polyurethane Form
Weight Lbs (kg) 43 (19.5) 43 (19.5) 43 (19.5) 48.5 (22)
5 Sound Level (HH/H/L) dBA 30/28/27 30/28/27 32/30/27 36/32/28
Piping
Connections
Liquid Pipes in. (mm) φ1/4 (6.4) (Flare Connection) φ1/4 (6.4) (Flare Connection) φ1/4 (6.4) (Flare
Connection) φ3/8 (9.5) (Flare Connection)
Gas Pipes in. (mm) φ1/2 (12.7) (Flare
Connection)
φ1/2 (12.7) (Flare
Connection)
φ1/2 (12.7) (Flare
Connection)
φ5/8 (15.8) (Flare
Connection)
Drain Pipe in. (mm)
VP25
External Dia. 1-1/4(31.8)
Internal Dia. 1(25.4)
VP25
External Dia. 1-1/4(31.8)
Internal Dia. 1(25.4)
VP25
External Dia. 1-1/4(31.8
Internal Dia. 1(25.4)
VP25
External Dia. 1-1/4(31.8
Internal Dia. 1(25.4)
Safety Devices Fuse Fuse Fuse Fuse
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R-410A VRV Series R-410A VRV Series R-410A VRV Series R-410A VRV Series
Standard Accessories
Operation Manual.
Installation Manual. Paper
Pattern for Installation. Drain
Hose. Sealing Pads. Clamps.
Washers. Screws. Insulation
for Fitting. Clamp Metal.
Operation Manual.
Installation Manual. Paper
Pattern for Installation. Drain
Hose. Sealing Pads. Clamps.
Washers. Screws. Insulation
for Fitting. Clamp Metal.
Operation Manual.
Installation Manual. Paper
Pattern for Installation.
Drain Hose. Sealing Pads.
Clamps. Washers. Screws.
Insulation for Fitting. Clamp
Metal.
Operation Manual.
Installation Manual. Paper
Pattern for Installation. Drain
Hose. Sealing Pads.
Clamps. Washers. Screws.
Insulation for Fitting. Clamp
Metal.
Decoration
Panels
(Option)
Model BYCP125K-W1 BYCP125K-W1 BYCP125K-W1 BYCP125K-W1
Color Fresh White Fresh White Fresh White Fresh White
Dimensions: (H×W×D) in. (mm) 2× 37-3/8 × 37-3/8
(51 x 949 x 949)
2 × 37-3/8 × 37-3/8
(51 x 949 x 949)
2 × 3 7 - 3 / 8 × 3 7 - 3 / 8
(51 x 949 x 949)
2 × 37-3/8 × 37-3/8
(51 x 949 x 949)
Air Filter Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Weight Lbs (kg) 12.2 (5.5) 12.2 (5.5) 12.2 (5.5) 12.2 (5.5)
Drawing No. C: 3D070521
(
)
(
)
(
)
(
)

EDUS391000-F1 Specifications
FXFQ-P 3
Ceiling Mounted Cassette Type (Round Flow)
Notes:
1 Nominal cooling capacities are based on the following conditions:
Return air temperature: 80°FDB(27°CDB), 67°FWB(19.4°CWB)
Outdoor temperature: 95°FDB (35°CDB)
Equivalent ref. piping length: 25ft (7.5 m)(Horizontal)
2 Nominal heating capacities are based on the following conditions:
Return air temperature: 70°FDB(21°CDB).
Outdoor temperature: 47°FDB (8.3°CDB ), 43°FWB (6°CWB)
Equivalent ref. piping length: 25ft (7.5 m) (Horizontal)
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
4 Refer to page 9 for Power Input.
5 Sound levels are measured under JIS conditions.
Model FXFQ30PVJU FXFQ36PVJU FXFQ48PVJU
1, 3Cooling Capacity Btu/h 30,000 36,000 48,000
2, 3Heating Capacity Btu/h 34,000 40,000 54,000
Casing / Color Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) in. (mm) 9-11/16 × 33-1/16 × 33-1/16
(246 x 840 x 840)
11-5/16×33-1/16×33-1/16
(287 x 840 x 840)
1 1 - 5 / 1 6 × 3 3 - 1 / 1 6 × 3 3 - 1 / 1 6
(287 x 840 x 840)
Coil (Cross
Fin Coil)
Rows×Stages×FPI 2×10×21 2×12×21 2×12×21
Face Area ft² (m2) 4.80 (1.46) 5.76 (1.8) 5.76 (1.8)
Fan
Model QTS48C15M QTS48C15M QTS48C15M
Type Turbo Fan Turbo Fan Turbo Fan
Motor Output W 56 120 120
Air Flow Rate (HH/H/L) cfm 830/670/530 1180/910/700 1220/970/790
Drive Direct Drive Direct Drive Direct Drive
Temperature Control Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material Polyurethane Form Polyurethane Form Polyurethane Form
Weight Lbs (kg 48.5 (22) 55 (25) 55 (25)
5 Sound Level (HH/H/L) dBA 38/35/31 44/38/32 45/40/34
Piping
Connections
Liquid Pipes in. (mm) φ3/8 (9.5) (Flare Connection) φ3/8 (9.5) (Flare Connection) φ3/8 (9.5) (Flare Connection)
Gas Pipes in. (mm) φ5/8 (15.8) (Flare Connection) φ5/8 (15.8) (Flare Connection) φ5/8 (15.8) (Flare Connection)
Drain Pipe in. (mm)
VP25
External Dia. 1-1/4 (31.8)
Internal Dia. 1(25.4)
VP25
External Dia. 1-1/4 (31.8)
Internal Dia. 1(25.4)
VP25
External 1-1/4 (31.8)
Internal Dia. 1 (25.4)
Safety Devices Fuse Fuse Fuse
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R-410A VRV Series R-410A VRV Series R-410A VRV Series
Standard Accessories
Operation Manual. Installation Manual.
Paper Pattern for Installation. Drain
Hose. Sealing Pads. Clamps. Washers.
Screws. Insulation for Fitting. Clamp
Metal.
Operation Manual. Installation Manual.
Paper Pattern for Installation. Drain
Hose. Sealing Pads. Clamps. Washers.
Screws. Insulation for Fitting. Clamp
Metal.
Operation Manual. Installation Manual.
Paper Pattern for Installation. Drain
Hose. Sealing Pads. Clamps.
Washers. Screws. Insulation for Fitting.
Clamp Metal.
Decoration
Panels
(Option)
Model BYCP125K-W1 BYCP125K-W1 BYCP125K-W1
Color Fresh White Fresh White Fresh White
Dimensions: (H×W×D) in. (mm) 2 × 3 7 - 3 / 8 × 3 7 - 3 / 8
(51 x 949 x 949)
2 × 3 7 - 3 / 8 × 3 7 - 3 / 8
(51 x 949 x 949)
2 × 3 7 - 3 / 8 × 3 7 - 3 / 8
(51 x 949 x 949)
Air Filter Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Weight Lbs (kg 12.2 (5.5) 12.2 (5.5) 12.2 (5.5)
Drawing No. C: 3D070521
(
)
(
)
(
)

Dimensions EDUS391000-F1
4FXFQ-P
2. Dimensions
FXFQ09PVJU
FXFQ12PVJU
FXFQ18PVJU
Unit (in.)
3D070522
DO NOT PLACE THE UNIT IN AREAS WITH EXCESSIVE HUMIDITY. WHEN HUMIDITY EXCEEDS 80%, CONDENSATION CAN FORM ON THE UNIT.

EDUS391000-F1 Dimensions
FXFQ-P 5
FXFQ24PVJU
FXFQ30PVJU
Unit (in.)
3D070524
DO NOT PLACE THE UNIT IN AREAS WITH EXCESSIVE HUMIDITY. WHEN HUMIDITY EXCEEDS 80%, CONDENSATION CAN FORM ON THE UNIT.

Dimensions EDUS391000-F1
6FXFQ-P
FXFQ36PVJU
FXFQ48PVJU
Unit (in.)
3D070523
DO NOT PLACE THE UNIT IN AREAS WITH EXCESSIVE HUMIDITY. WHEN HUMIDITY EXCEEDS 80%, CONDENSATION CAN FORM ON THE UNIT.

EDUS391000-F1 Piping Diagrams
FXFQ-P 7
3. Piping Diagrams
FXFQ09PVJU / FXFQ12PVJU / FXFQ18PVJU / FXFQ24PVJU / FXFQ30PVJU / FXFQ36PVJU / FXFQ48PVJU
Model GAS Liquid
FXFQ09 / 12 / 18PVJU φ1/2 φ1/4
FXFQ24 / 30 / 36 / 48PVJU φ5/8 φ3/8
4D024460D

Wiring Diagrams EDUS391000-F1
8FXFQ-P
4. Wiring Diagrams
FXFQ09PVJU / FXFQ12PVJU / FXFQ18PVJU / FXFQ24PVJU / FXFQ30PVJU / FXFQ36PVJU / FXFQ48PVJU
3D070301C
PROTECTIVE GROUND NOISELESS GROUND

EDUS391000-F1 Electric Characteristics
FXFQ-P 9
5. Electric Characteristics
4D070525A

Capacity Tables EDUS391000-F1
10 FXFQ-P
6. Capacity Tables
6.1 Cooling Capacity
FXFQ-P [Cooling Capacity]
TC : Total capacity ; MBh
SHC : Sensible heat capacity ; MBh
Indoor Unit
Outdoor
Air Temp.
Indoor Air Temp. °FWB
61 64 67 70 72 75
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
°FDB MBh MBh MBh MBh MBh MBh MBh MBh MBh MBh MBh MBh
09
75 7.5 7.5 8.5 8.5 9.5 9.5 10.5 9.8 10.7 9.6 10.9 9.2
79 7.5 7.5 8.5 8.5 9.5 9.5 10.4 9.7 10.5 9.5 10.7 9.0
83 7.5 7.5 8.5 8.5 9.5 9.5 10.2 9.5 10.3 9.6 10.5 9.2
87 7.5 7.5 8.5 8.5 9.5 9.5 10.0 9.7 10.2 9.5 10.3 9.0
91 7.5 7.5 8.5 8.5 9.5 9.5 9.9 9.5 10.0 9.6 10.2 8.8
95 7.5 7.5 8.5 8.5 9.5 9.5 9.7 9.7 9.8 9.1 10.0 8.7
99 7.5 7.5 8.5 8.5 9.3 9.3 9.5 9.5 9.6 9.0 9.8 8.8
103 7.5 7.5 8.5 8.5 9.2 9.2 9.3 9.3 9.5 9.1 9.7 8.7
12
75 9.5 9.1 10.7 9.8 12.0 10.3 13.3 11.2 13.5 10.4 13.7 10.0
79 9.5 9.1 10.7 9.8 12.0 10.3 13.1 11.0 13.3 10.3 13.5 9.9
83 9.5 9.1 10.7 9.8 12.0 10.3 12.9 10.9 13.0 10.4 13.3 10.0
87 9.5 9.1 10.7 9.8 12.0 10.3 12.7 10.3 12.8 10.5 13.1 10.0
91 9.5 9.1 10.7 9.8 12.0 10.3 12.5 10.4 12.6 10.3 12.8 9.9
95 9.5 9.1 10.7 9.8 12.0 10.3 12.2 10.5 12.4 10.4 12.6 10.0
99 9.5 9.1 10.7 9.8 11.8 10.4 12.0 10.4 12.2 9.9 12.4 9.5
103 9.5 9.1 10.7 9.8 11.6 10.2 11.8 10.5 12.0 10.0 12.2 9.6
18
75 14.2 12.3 16.1 13.3 18.0 14.1 19.9 14.9 20.2 14.1 20.6 13.8
79 14.2 12.3 16.1 13.3 18.0 14.1 19.7 14.7 19.9 14.1 20.2 13.5
83 14.2 12.3 16.1 13.3 18.0 14.1 19.3 14.7 19.6 13.8 19.9 13.5
87 14.2 12.3 16.1 13.3 18.0 14.1 19.0 14.2 19.2 13.8 19.6 13.5
91 14.2 12.3 16.1 13.3 18.0 14.1 18.7 14.2 18.9 13.5 19.3 13.5
95 14.2 12.3 16.1 13.3 18.0 14.1 18.4 14.2 18.6 13.5 18.9 13.2
99 14.2 12.3 16.1 13.3 17.7 14.1 18.0 13.8 18.3 13.5 18.6 13.2
103 14.2 12.3 16.1 13.3 17.3 13.8 17.7 13.8 17.9 13.5 18.3 12.6
24
75 18.9 16.6 21.5 18.2 24.0 18.9 26.5 19.9 27.0 19.1 27.4 18.3
79 18.9 16.6 21.5 18.2 24.0 18.9 26.2 19.7 26.5 17.0 27.0 18.2
83 18.9 16.6 21.5 18.2 24.0 18.9 25.8 19.6 26.1 18.6 26.6 18.2
87 18.9 16.6 21.5 18.2 24.0 18.9 25.3 19.5 25.7 18.6 26.1 17.8
91 18.9 16.6 21.5 18.2 24.0 18.9 24.9 19.1 25.2 18.2 25.7 17.9
95 18.9 16.6 21.5 18.2 24.0 18.9 24.5 18.7 24.8 18.1 25.3 17.9
99 18.9 16.6 21.5 18.2 23.6 18.9 24.0 18.6 24.4 18.3 24.8 17.4
103 18.9 16.6 21.5 18.2 23.1 18.8 23.6 18.2 23.9 17.9 24.4 17.4
30
75 23.7 19.4 26.8 21.1 30.0 22.3 33.2 23.5 33.7 22.4 34.3 21.3
79 23.7 19.4 26.8 21.1 30.0 22.3 32.8 23.2 33.2 22.1 33.7 21.4
83 23.7 19.4 26.8 21.1 30.0 22.3 32.2 23.1 32.6 21.6 33.2 20.9
87 23.7 19.4 26.8 21.1 30.0 22.3 31.7 22.6 32.1 21.7 32.7 21.0
91 23.7 19.4 26.8 21.1 30.0 22.3 31.1 22.1 31.5 21.2 32.1 20.5
95 23.7 19.4 26.8 21.1 30.0 22.3 30.6 22.2 31.0 21.3 31.6 20.6
99 23.7 19.4 26.8 21.1 29.5 22.2 30.0 21.7 30.4 20.8 31.0 20.1
103 23.7 19.4 26.8 21.1 28.9 21.6 29.5 21.5 29.9 20.9 30.5 20.0
36
75 28.4 24.6 32.2 26.7 36.0 28.6 39.8 30.1 40.4 28.8 41.1 28.0
79 28.4 24.6 32.2 26.7 36.0 28.6 39.3 29.7 39.8 28.5 40.5 27.6
83 28.4 24.6 32.2 26.7 36.0 28.6 38.7 29.2 39.1 27.9 39.8 27.3
87 28.4 24.6 32.2 26.7 36.0 28.6 38.0 28.9 38.5 27.9 39.2 27.3
91 28.4 24.6 32.2 26.7 36.0 28.6 37.4 28.9 37.8 27.6 38.5 26.8
95 28.4 24.6 32.2 26.7 36.0 28.6 36.7 28.6 37.2 27.2 37.9 26.4
99 28.4 24.6 32.2 26.7 35.3 28.6 36.1 28.0 36.5 27.2 37.2 26.1
103 28.4 24.6 32.2 26.7 34.7 28.0 35.4 27.7 35.9 26.9 36.6 26.1
48
75 37.9 30.2 42.9 33.1 48.0 35.3 53.1 37.4 53.9 35.9 54.9 34.3
79 37.9 30.2 42.9 33.1 48.0 35.3 52.4 36.9 53.0 35.5 54.0 33.8
83 37.9 30.2 42.9 33.1 48.0 35.3 51.5 36.3 52.2 35.0 53.1 33.9
87 37.9 30.2 42.9 33.1 48.0 35.3 50.7 36.1 51.3 34.6 52.3 33.5
91 37.9 30.2 42.9 33.1 48.0 35.3 49.8 35.6 50.4 34.3 51.4 33.0
95 37.9 30.2 42.9 33.1 48.0 35.3 48.9 35.2 49.6 33.8 50.5 32.6
99 37.9 30.2 42.9 33.1 47.1 35.2 48.1 34.9 48.7 33.4 49.7 32.3
103 37.9 30.2 42.9 33.1 46.3 34.6 47.2 34.5 47.8 32.9 48.8 31.8

EDUS391000-F1 Capacity Tables
FXFQ-P 11
6.2 Heating Capacity
FXFQ-P [Heating Capacity]
TC :Total capacity ; MBh
Indoor Unit Outdoor Air Temp.
Indoor Air Temp. °FDB
62 65 68 70 72 75
TC TC TC TC TC TC
°FDB °FWB MBh MBh MBh MBh MBh MBh
09
22.0 20.0 9.3 9.3 9.3 9.3 9.3 9.2
26.0 24.0 9.9 9.8 9.8 9.8 9.8 9.5
30.0 28.0 10.4 10.4 10.4 10.4 10.1 9.5
35.0 32.0 11.1 11.0 10.9 10.5 10.1 9.5
39.0 36.0 11.7 11.5 10.9 10.5 10.1 9.5
44.0 40.0 12.2 11.5 10.9 10.5 10.1 9.5
47.0 43.0 12.2 11.5 10.9 10.5 10.1 9.5
51.0 47.0 12.2 11.5 10.9 10.5 10.1 9.5
54.0 50.0 12.2 11.5 10.9 10.5 10.1 9.5
57.0 53.0 12.2 11.5 10.9 10.5 10.1 9.5
60.0 56.0 12.2 11.5 10.9 10.5 10.1 9.5
12
22.0 20.0 12.0 12.0 11.9 11.9 11.9 11.9
26.0 24.0 12.7 12.7 12.6 12.6 12.6 12.3
30.0 28.0 13.4 13.4 13.4 13.4 13.0 12.3
35.0 32.0 14.2 14.2 14.0 13.5 13.0 12.3
39.0 36.0 15.1 14.7 14.0 13.5 13.0 12.3
44.0 40.0 15.7 14.7 14.0 13.5 13.0 12.3
47.0 43.0 15.7 14.7 14.0 13.5 13.0 12.3
51.0 47.0 15.7 14.7 14.0 13.5 13.0 12.3
54.0 50.0 15.7 14.7 14.0 13.5 13.0 12.3
57.0 53.0 15.7 14.7 14.0 13.5 13.0 12.3
60.0 56.0 15.7 14.7 14.0 13.5 13.0 12.3
18
22.0 20.0 17.8 17.7 17.7 17.7 17.6 17.6
26.0 24.0 18.8 18.7 18.7 18.7 18.7 18.1
30.0 28.0 19.9 19.8 19.8 19.8 19.3 18.1
35.0 32.0 21.1 21.0 20.7 20.0 19.3 18.1
39.0 36.0 22.3 21.9 20.7 20.0 19.3 18.1
44.0 40.0 23.3 21.9 20.7 20.0 19.3 18.1
47.0 43.0 23.3 21.9 20.7 20.0 19.3 18.1
51.0 47.0 23.3 21.9 20.7 20.0 19.3 18.1
54.0 50.0 23.3 21.9 20.7 20.0 19.3 18.1
57.0 53.0 23.3 21.9 20.7 20.0 19.3 18.1
60.0 56.0 23.3 21.9 20.7 20.0 19.3 18.1
24
22.0 20.0 24.0 23.9 23.9 23.9 23.8 23.8
26.0 24.0 25.4 25.3 25.3 25.2 25.2 24.5
30.0 28.0 26.9 26.8 26.8 26.7 26.0 24.5
35.0 32.0 28.5 28.4 28.0 27.0 26.0 24.5
39.0 36.0 30.2 29.5 28.0 27.0 26.0 24.5
44.0 40.0 31.5 29.5 28.0 27.0 26.0 24.5
47.0 43.0 31.5 29.5 28.0 27.0 26.0 24.5
51.0 47.0 31.5 29.5 28.0 27.0 26.0 24.5
54.0 50.0 31.5 29.5 28.0 27.0 26.0 24.5
57.0 53.0 31.5 29.5 28.0 27.0 26.0 24.5
60.0 56.0 31.5 29.5 28.0 27.0 26.0 24.5
30
22.0 20.0 30.2 30.1 30.1 30.0 30.0 29.9
26.0 24.0 31.9 31.9 31.8 31.8 31.7 30.9
30.0 28.0 33.8 33.7 33.7 33.7 32.7 30.9
35.0 32.0 35.8 35.8 35.3 34.0 32.7 30.9
39.0 36.0 38.0 37.1 35.3 34.0 32.7 30.9
44.0 40.0 39.7 37.1 35.3 34.0 32.7 30.9
47.0 43.0 39.7 37.1 35.3 34.0 32.7 30.9
51.0 47.0 39.7 37.1 35.3 34.0 32.7 30.9
54.0 50.0 39.7 37.1 35.3 34.0 32.7 30.9
57.0 53.0 39.7 37.1 35.3 34.0 32.7 30.9
60.0 56.0 39.7 37.1 35.3 34.0 32.7 30.9
36
22.0 20.0 35.5 35.4 35.4 35.3 35.3 35.2
26.0 24.0 37.6 37.5 37.4 37.4 37.3 36.3
30.0 28.0 39.8 39.7 39.6 39.6 38.5 36.3
35.0 32.0 42.2 42.1 41.5 40.0 38.5 36.3
39.0 36.0 44.7 43.7 41.5 40.0 38.5 36.3
44.0 40.0 46.7 43.7 41.5 40.0 38.5 36.3
47.0 43.0 46.7 43.7 41.5 40.0 38.5 36.3
51.0 47.0 46.7 43.7 41.5 40.0 38.5 36.3
54.0 50.0 46.7 43.7 41.5 40.0 38.5 36.3
57.0 53.0 46.7 43.7 41.5 40.0 38.5 36.3
60.0 56.0 46.7 43.7 41.5 40.0 38.5 36.3
48
22.0 20.0 48.0 47.9 47.8 47.7 47.7 47.6
26.0 24.0 50.7 50.6 50.5 50.5 50.4 49.0
30.0 28.0 53.7 53.6 53.5 53.4 52.0 49.0
35.0 32.0 56.9 56.8 56.0 54.0 52.0 49.0
39.0 36.0 60.3 59.0 56.0 54.0 52.0 49.0
44.0 40.0 63.0 59.0 56.0 54.0 52.0 49.0
47.0 43.0 63.0 59.0 56.0 54.0 52.0 49.0
51.0 47.0 63.0 59.0 56.0 54.0 52.0 49.0
54.0 50.0 63.0 59.0 56.0 54.0 52.0 49.0
57.0 53.0 63.0 59.0 56.0 54.0 52.0 49.0
60.0 56.0 63.0 59.0 56.0 54.0 52.0 49.0

Sound Levels (Reference) EDUS391000-F1
12 FXFQ-P
7. Sound Levels (Reference)
7.1 Overall
7.2 Octave Band Level
208V-230V, 60Hz
Location of microphone Notes:
1. The operating conditions are assumed to be
standard (JIS conditions). Power source 208-
230V, 60hz.
2. The operating values were obtained in an
anechoic chamber (conversion values).
3. Sound levels will vary depending on a range of
factors such as the construction (acoustic
absorption coefficient) of the particular room
in which the equipment is installed.
dBA
Model 208-230V, 60Hz
HH H L
FXFQ09PVJU 30 28 27
FXFQ12PVJU 30 28 27
FXFQ18PVJU 32 30 27
FXFQ24PVJU 36 32 28
FXFQ30PVJU 38 35 31
FXFQ36PVJU 44 38 32
FXFQ48PVJU 45 40 34
5 ft
(1.5 m)
1 ft
(0.3 m)
HH
H
L
HH
H
L
FXFQ09/12PVJU FXFQ18PVJU

EDUS391000-F1 Sound Levels (Reference)
FXFQ-P 13
FXFQ36PVJU FXFQ48PVJU
HH
H
L
HH
H
L
HH
H
L
L
H
HH
FXFQ24PVJU FXFQ30PVJU

Center of Gravity EDUS391000-F1
14 FXFQ-P
8. Center of Gravity
4D070529
Unit (in.)

EDUS391000-F1 Installation
FXFQ-P 15
9. Installation
3P161684-5H
English 1
VRV SYSTEM Inverter Heat Pump Installation manual
CONTENTS
1. SAFETY CONSIDERATIONS........................................................................................ 1
2. BEFORE INSTALLATION.............................................................................................. 3
3. SELECTING INSTALLATION SITE ............................................................................... 6
4. PREPARATIONS BEFORE INSTALLATION ................................................................ 7
5. INDOOR UNIT INSTALLATION..................................................................................... 9
6. REFRIGERANT PIPING WORK .................................................................................. 10
7. DRAIN PIPING WORK ................................................................................................ 13
8. ELECTRIC WIRING WORK......................................................................................... 16
9. WIRING EXAMPLE AND HOW TO SET THE REMOTE CONTROLLER ................... 17
10. INSTALLATION OF THE DECORATION PANEL...........................................................24
11. FIELD SETTING .......................................................................................................... 24
12. TEST OPERATION...................................................................................................... 26
1. SAFETY CONSIDERATIONS
Read these “SAFETY CONSIDERATIONS for Installation” carefully before installing air conditioning equip-
ment. After completing the installation, make sure that the unit operates properly during the startup operation.
Instruct the customer on how to operate and maintain the unit. Inform customers that they should store this
Installation Manual with the Operation Manual for future reference.
Always use a licensed installer or contractor to install this product. Improper installation can result in water or
refrigerant leakage, electrical shock, fire, or explosion.
Meanings of DANGER, WARNING, CAUTION, and NOTE Symbols:
DANGER ........... Indicates an imminently hazardous situation which, if not avoided, will result in death
or serious injury.
WARNING ......... Indicates a potentially hazardous situation which, if not avoided, could result in death
or serious injury.
CAUTION .......... Indicates a potentially hazardous situation which, if not avoided, may result in minor
or moderate injury. It may also be used to alert against unsafe practices.
NOTE................. Indicates situations that may result in equipment or property-damage accidents only.
DANGER
•Refrigerant gas is heavier than air and replaces oxygen. A massive leak can lead to oxygen depletion,
especially in basements, and an asphyxiation hazard could occur leading to serious injury or death.
•Do not ground units to water pipes, gas pipes, telephone wires, or lightning rods as incomplete grounding
can cause a severe shock hazard resulting in severe injury or death. Additionally, grounding to gas pipes
could cause a gas leak and potential explosion causing severe injury or death.
•If refrigerant gas leaks during installation, ventilate the area immediately. Refrigerant gas may produce toxic
gas if it comes in contact with fire. Exposure to this gas could cause severe injury or death.
•After completing the installation work, check that the refrigerant gas does not leak throughout the system.
•Do not install unit in an area where flammable materials are present due to risk of explosions that can cause
serious injury or death.

Installation EDUS391000-F1
16 FXFQ-P
3P161684-5H
2English
•Safely dispose all packing and transportation materials in accordance with federal/state/local laws or ordi-
nances. Packing materials such as nails and other metal or wood parts, including plastic packing mate-
rials used for transportation may cause injuries or death by suffocation.
WARNING
•Only qualified personnel must carry out the installation work. Installation must be done in accordance with
this installation manual. Improper installation may result in water leakage, electric shock, or fire.
•When installing the unit in a small room, take measures to keep the refrigerant concentration from exceed-
ing allowable safety limits. Excessive refrigerant leaks, in the event of an accident in a closed ambient
space, can lead to oxygen deficiency.
•Use only specified accessories and parts for installation work. Failure to use specified parts may result in
water leakage, electric shocks, fire, or the unit falling.
•Install the air conditioner on a foundation strong enough that it can withstand the weight of the unit. A foun-
dation of insufficient strength may result in the unit falling and causing injuries.
•Take into account strong winds, typhoons, or earthquakes when installing. Improper installation may result
in the unit falling and causing accidents.
•Make sure that a separate power supply circuit is provided for this unit and that all electrical work is carried
out by qualified personnel according to local, state, and national regulations. An insufficient power supply
capacity or improper electrical construction may lead to electric shocks or fire.
•Make sure that all wiring is secured, that specified wires are used, and that no external forces act on the ter-
minal connections or wires. Improper connections or installation may result in fire.
•
When wiring, position the wires so that the control box lid can be securely fastened. Improper positioning of
the control box lid may result in electric shocks, fire, or the terminals overheating.
•Before touching electrical parts, turn off the unit.
•Be sure to install a ground fault circuit interrupter if one is not already available. This helps prevent electrical
shocks or fire.
•Securely fasten the outside unit terminal cover (panel). If the terminal cover/panel is not installed properly,
dust or water may enter the outside unit causing fire or electric shock.
•When installing or relocating the system, keep the refrigerant circuit free from substances other than the
specified refrigerant (R410A) such as air. Any presence of air or other foreign substance in the refrigerant
circuit can cause an abnormal pressure rise or rupture, resulting in injury.
•Do not change the setting of the protection devices. If the pressure switch, thermal switch, or other pro-
tection device is shorted and operated forcibly, or parts other than those specified by Daikin are used, fire
or explosion may occur.
CAUTION
•Do not touch the switch with wet fingers. Touching a switch with wet fingers can cause electric shock.
•Do not allow children to play on or around the unit to prevent injury.
•Do not touch the refrigerant pipes during and immediately after operation as the refrigerant pipes may be
hot or cold, depending on the condition of the refrigerant flowing through the refrigerant piping, compressor,
and other refrigerant cycle parts. Your hands may suffer burns or frostbite if you touch the refrigerant pipes.
To avoid injury, give the pipes time to return to normal temperature or, if you must touch them, be sure to
wear proper gloves.
•Heat exchanger fins are sharp enough to cut.
To avoid injury wear glove or cover the fins when working around them.
•Install drain piping to proper drainage. Improper drain piping may result in water leakage and property dam-
age.
•Insulate piping to prevent condensation.
•Be careful when transporting the product.
•Do not turn off the power immediately after stopping operation. Always wait for at least 5 minutes before
turning off the power. Otherwise, water leakage may occur.
•Do not use a charging cylinder. Using a charging cylinder may cause the refrigerant to deteriorate.

EDUS391000-F1 Installation
FXFQ-P 17
3P161684-5H
English 3
•Refrigerant R410A in the system must be kept clean, dry, and tight.
(a) Clean and Dry -- Foreign materials (including mineral oils such as SUNISO oil or moisture) should be
prevented from getting into the system.
(b) Tight -- R410A does not contain any chlorine, does not destroy the ozone layer, and does not reduce
the earth’s protection again harmful ultraviolet radiation. R410A can contribute to the greenhouse effect
if it is released. Therefore take proper measures to check for the tightness of the refrigerant piping
installation. Read the chapter Refrigerant Piping and follow the procedures.
•Since R410A is a blend, the required additional refrigerant must be charged in its liquid state. If the refrig-
erant is charged in a state of gas, its composition can change and the system will not work properly.
•The indoor unit is for R410A. See the catalog for indoor models that can be connected. Normal operation
is not possible when connected to other units.
•Indoor units are for indoor installation only. Outdoor units can be installed either outdoors or indoors.
•Do not install the air conditioner in the following locations:
(a) Where a mineral oil mist or oil spray or vapor is produced, for example, in a kitchen.
Plastic parts may deteriorate and fall off or result in water leakage.
(b) Where corrosive gas, such as sulfurous acid gas, is produced.
Corroding copper pipes or soldered parts may result in refrigerant leakage.
(c) Near machinery emitting electromagnetic waves.
Electromagnetic waves may disturb the operation of the control system and cause the unit to malfunction.
(d) Where flammable gas may leak, where there is carbon fiber, or ignitable dust suspension in the air, or
where volatile flammables such as thinner or gasoline are handled. Operating the unit in such condi-
tions can cause a fire.
•Take adequate measures to prevent the outside unit from being used as a shelter by small animals. Small
animals making contact with electrical parts can cause malfunctions, smoke, or fire. Instruct the customer
to keep the area around the unit clean.
NOTE
•Install the power supply and control wires for the indoor and outdoor units at least 3.5 feet away from tele-
visions or radios to prevent image interference or noise. Depending on the radio waves, a distance of
3.5 feet may not be sufficient to eliminate the noise.
•Dismantling the unit, treatment of the refrigerant, oil and additional parts must be done in accordance with
the relevant local, state, and national regulations.
•
Do not use the following tools that are used with conventional refrigerants: gauge manifold, charge hose, gas leak
detector, reverse flow check valve, refrigerant charge base, vacuum gauge, or refrigerant recovery equipment.
•If the conventional refrigerant and refrigerator oil are mixed in R410A, the refrigerant may deteriorate.
•This air conditioner is an appliance that should not be accessible to the general public.
•The wall thickness of field-installed pipes should be selected in accordance with the relevant local, state,
and national regulations.
2. BEFORE INSTALLATION
Do not exert pressure on the resin parts when opening the unit or when moving it after opening.
Be sure to check the type of R410A refrigerant to be used before doing any work. (Using an incorrect
refrigerant will prevent normal operation of the unit.)
•When opening the unit or moving it after opening, be sure to lift it by holding on to the lifting lugs without
exerting any pressure on other parts, especially, drain piping, and other resin parts.
•Decide upon a line of transport.
•Leave the unit inside its packaging while moving, until reaching the installation site. Use a sling of soft mate-
rial, where unpacking is unavoidable or protective plates together with a rope when lifting, to avoid damage
or scratches to the unit.
•Refer to the installation manual of the outdoor unit for items not described in this manual.
•Do not dispose of any parts necessary for installation until the installation is complete.

Installation EDUS391000-F1
18 FXFQ-P
3P161684-5H
4English
1. PRECAUTIONS
•Be sure to read this manual before installing the indoor unit.
•When selecting installation site, refer to the paper pattern.
•This unit is suitable for installation in a household, commercial and light industrial environment.
•Do not install or operate the unit in rooms mentioned below.
•Laden with mineral oil, or filled with oil vapor or spray like in kitchens. (Plastic parts may deteriorate.)
•Where corrosive gas like sulfurous gas exists. (Copper tubing and brazed spots may corrode.)
•Where volatile flammable gas like thinner or gasoline is used.
•Where machines can generate electromagnetic waves. (Control system may malfunction.)
•Where the air contains high levels of salt such as that near the ocean and where voltage fluctuates
greatly such as that in factories. Also in vehicles or vessels.
2. ACCESSORIES
Check the following accessories are included with your unit.
Name (1) Drain hose (2) Metal clamp
(3) Washer for
hanger bracket
(4) Clamp (5) Paper pattern
for installation
Quantity 1 pc. 1 pc. 8 pcs. 6 pcs. 1 pc.
Shape
Also used as
packing material
Name (6) Screw (M4) (7) Washer
fixing plate
Insulation for
fitting Sealing pad
Quantity 4 pcs. 4 pcs. 1 each 1 each 1 pc. 1 pc.
Shape
(13) Small
Name Installation guide Insulation tube Conduit mounting
plate
(Other)
• Installation manual
• Operation manual
Quantity 1 pc. 1 pc. 1 each
Shape
For paper
pattern for
installation
(8) for gas
pipe
(9) for liquid
pipe
(11) Medium-1
(12) Medium-2
(10) Large
(14)
(15) (16)
(17)
(18)

EDUS391000-F1 Installation
FXFQ-P 19
3P161684-5H
English 5
3. OPTIONAL ACCESSORIES
•The optional decoration panel and remote controller are required for this indoor unit. (Refer to Table 1, 2)
(However, the remote controller is not required for the slave unit of a simultaneous operation system.)
Ta b l e 1
•These are two types of remote controllers: wired and wireless. Select a remote controller from Table 2
according to customer request and install in an appropriate place.
Ta b l e 2
NOTE
•If you wish to use a remote controller that is not listed in “Table 2” on page 5, select a suitable remote con-
troller after consulting catalogs and technical materials.
FOR THE FOLLOWING ITEMS, TAKE SPECIAL CARE DURING CONSTRUCTION AND
CHECK AFTER INSTALLATION IS FINISHED.
1. Items to be checked after completion of work
2. Items to be checked at time of delivery
* Also review the “1. SAFETY CONSIDERATIONS”
Unit model Optional decoration panel
FXFQ09 · 12 · 18 · 24 · 30 · 36 · 48PVJU BYCP125K-W1
Color : Fresh white
Remote controller
Wired type BRC1E71
Wireless type BRC7F812
Items to be checked If not properly done, what is likely to occur Check
Are the indoor unit and outdoor unit fixed firmly? The unit may drop, vibrate or make noise.
Is the outdoor unit fully installed? The unit may malfunction or the compo-
nents burn out.
Is the gas leak test finished? It may result in insufficient cooling.
Is the unit fully insulated? Condensate water may drip.
Does drainage flow smoothly? Condensate water may drip.
Does the power supply voltage correspond
to that shown on the name plate?
The unit may malfunction or the compo-
nents burn out.
Are wiring and piping correct? The unit may malfunction or the compo-
nents burn out.
Is the unit safely grounded? It may result in electric shock.
Is wiring size according to specifications? The unit may malfunction or the compo-
nents burn out.
Is something blocking the air outlet or inlet
of either the indoor or outdoor units? It may result in insufficient cooling.
Are refrigerant piping length and additional
refrigerant charge noted down?
The refrigerant charge in the system is not
clear.
Items to be checked Check
Are the control box lid, air filter, suction grille attached?
Did you explain about operations while showing the operation manual to your customer?
Did you hand the operation manual over to your customer?
