• VRV® Systems • Indoor Unit 1
• Indoor Unit • Round Flow Cassette • FXSQ-P
TABLE OF CONTENTS
FXSQ-P
1 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Electrical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Safety device settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5 Capacity tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Cooling Capacity Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Heating Capacity Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6 Dimensional drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7 Centre of gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
8 Piping diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
9 Wiring diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Wiring Diagrams - Single Phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
10 Sound data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Sound Power Spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Sound Pressure Spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
11 Fan characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Fan Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
12 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Installation Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Filter Installation Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Switch Box Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
FXSQ_EN.pdf 3 29/06/2010 14:31:33

• Indoor Unit • Round Flow Cassette • FXSQ-P
• VRV® Systems • Indoor Unit
2
1 Specifications
IndoorUnit VRV®System
s
FXSQ-PRoundFlow
1-1 Technical Specifications FXSQ20P7VEB FXSQ25P7VEB FXSQ32P7VEB FXSQ40P7VEB FXSQ50P7VEB
Cooling capacity Nom. kW 2.2 (1) 2.8 (1) 3.6 (1) 4.5 (1) 5.6 (1)
Heating capacity Nom. kW 2.5 (2) 3.2 (2) 4.0 (2) 5.0 (2) 6.3 (2)
Power input - 50Hz Cooling Nom. kW 0.041 (1) 0.044 (1) 0.097 (1)
Heating Nom. kW 0.029 (2) 0.032 (2) 0.085 (2)
Power input - 60Hz Cooling Nom. kW 0.041 (1) 0.044 (1) 0.097 (1)
Heating Nom. kW 0.029 (2) 0.032 (2) 0.085 (2)
Casing Colour Unpainted
Material Galvanised steel
Dimensions Unit Height mm 300
Width mm 550 700
Depth mm 700
Packed unit Height mm 355
Width mm 770 920
Depth mm 900
Weight Unit kg 23 26
Packed unit kg 28 32
Decoration panel Model BYBS32DJW1 BYBS45DJW1
Colour White (10Y9/0.5)
Dimensions Height mm 55 0d
Width mm 650 800
Depth mm 500
Weight kg 3.0 3.5
Required ceiling void \> mm 350
Heat exchanger Fin pitch mm 1.75
Passes Quantity 3 4
Face area m² 0.097 0.148
Stages Quantity 16
Empty tubeplate
hole
Quantity 12 0
Tube type ø7 Hi-XSS
Fin Type Symmetric waffle louvre
Treatment Hydrophilic
Fan Type Sirocco fan
Quantity 1
Air flow rate - 50Hz Cooling High m³/min 9 9.5 16
Low m³/min 6.5 7 11
Heating High m³/min 9 9.5 16
Low m³/min 6.5 7 11
Air flow rate - 60Hz Cooling High m³/min 9 9.5 16
Low m³/min 6.5 7 11
Heating High m³/min 9 9.5 16
Low m³/min 6.5 7 11
External static
pressure - 50Hz
High Pa 70 100
Nom. Pa 30
External static
pressure - 60Hz
High Pa 70 100
Nom. Pa 30
Fan motor Quantity 1
Model Brushless DC motor
Speed Steps 9 10
Cooling High rpm 1031 1061 1186
Low rpm 802 827 875
Heating High rpm 1031 1061 1186
Low rpm 802 827 875
Output High W 90 140
Drive Direct drive
FXSQ_EN.pdf 4 29/06/2010 14:31:33

3
• VRV® Systems • Indoor Unit 3
• Indoor Unit • Round Flow Cassette • FXSQ-P
1 Specifications
Sound pressure level Cooling High dBA 32 33 37
Low dBA 26 27 29
Heating Super high dBA -
High dBA 32 33 37
Low dBA 26 27 29
Refrigerant Type R-410A
Control Electronic expansion valve
Piping connections Liquid Type Flare connection
OD mm 6.35
Gas Type Flare connection
OD mm 12.7
Drain VP25 (O.D. 32 / I.D. 25)
Heat insulation Both liquid and gas pipes
Sound absorbing insulation -
Drain-up height mm 625
Air filter Resin net with mold resistance
Notes Cooling: indoor temp. 27×CDB, 19×CWB; outdoor temp. 35×CDB; equivalent piping length: 7.5m; level
difference: 0m
1-1 Technical Specifications FXSQ63P7VEB FXSQ80P7VEB FXSQ100P7VEB FXSQ125P7VEB FXSQ140P7VEB
Cooling capacity Nom. kW 7.1 (1) 9.0 (1) 11.2 (1) 14.0 (1) 16.0 (1)
Heating capacity Nom. kW 8.0 (2) 10.0 (2) 12.5 (2) 16.0 (2) 18.0 (2)
Power input - 50Hz Cooling Nom. kW 0.074 (1) 0.118 (1) 0.117 (1) 0.185 (1) 0.261 (1)
Heating Nom. kW 0.062 (2) 0.106 (2) 0.105 (2) 0.173 (2) 0.249 (2)
Power input - 60Hz Cooling Nom. kW 0.074 (1) 0.118 (1) 0.117 (1) 0.185 (1) 0.261 (1)
Heating Nom. kW 0.062 (2) 0.106 (2) 0.105 (2) 0.173 (2) 0.249 (2)
Casing Colour Unpainted
Material Galvanised steel
Dimensions Unit Height mm 300
Width mm 1000 1400
Depth mm 700
Packed unit Height mm 355
Width mm 1220 1620
Depth mm 900
Weight Unit kg 35 46 47
Packed unit kg 42 54 55
Decoration panel Model BYBS71DJW1 BYBS125DJW1
Colour White (10Y9/0.5)
Dimensions Height mm 55 0d
Width mm 1100 1500
Depth mm 500
Weight kg 4.5 6.5
Required ceiling void \> mm 350
Heat exchanger Fin pitch mm 1.75 1.50
Passes Quantity 7 11
Face area m² 0.249 0.383
Stages Quantity 16
Empty tubeplate
hole
Quantity 0
Tube type ø7 Hi-XSS
Fin Type Symmetric waffle louvre
Treatment Hydrophilic
1-1 Technical Specifications FXSQ20P7VEB FXSQ25P7VEB FXSQ32P7VEB FXSQ40P7VEB FXSQ50P7VEB
FXSQ_EN.pdf 5 29/06/2010 14:31:33

• Indoor Unit • Round Flow Cassette • FXSQ-P
• VRV® Systems • Indoor Unit
4
1 Specifications
Fan Type Sirocco fan
Quantity 2 3
Air flow rate - 50Hz Cooling High m³/min 19.5 25 32 39 46
Lowm³/min1620232832
Heating High m³/min 19.5 25 32 39 46
Lowm³/min1620232832
Air flow rate - 60Hz Cooling High m³/min 19.5 25 32 39 46
Lowm³/min1620232832
Heating High m³/min 19.5 25 32 39 46
Lowm³/min16.020232832
External static
pressure - 50Hz
High Pa 100 120 140
Nom. Pa 30 40 50
External static
pressure - 60Hz
High Pa 100 120 140
Nom. Pa 30 40 50
Fan motor Quantity 1
Model Brushless DC motor
Speed Steps 8 9 11
Cooling High rpm 975 1161 1060 1218 1325
Low rpm 840 960 813 920 948
Heating High rpm 975 1161 1060 1218 1325
Low rpm 840 960 813 920 948
Output High W 350
Drive Direct drive
Sound pressure level Cooling High dBA 37 38 40 42
Low dBA 30 32 33 34
Heating Super high dBA -
High dBA 37 38 40 42
Low dBA 30 32 33 34
Refrigerant Type R-410A
Control Electronic expansion valve
Piping connections Liquid Type Flare connection
OD mm 9.52
Gas Type Flare connection
OD mm 15.9
Drain VP25 (O.D. 32 / I.D. 25)
Heat insulation Both liquid and gas pipes
Sound absorbing insulation -
Drain-up height mm 625
Air filter Resin net with mold resistance
Notes Cooling: indoor temp. 27×CDB, 19×CWB; outdoor temp. 35×CDB; equivalent piping length: 7.5m; level
difference: 0m
1-1 Technical Specifications FXSQ63P7VEB FXSQ80P7VEB FXSQ100P7VEB FXSQ125P7VEB FXSQ140P7VEB
FXSQ_EN.pdf 6 29/06/2010 14:31:33

3
• VRV® Systems • Indoor Unit 5
• Indoor Unit • Round Flow Cassette • FXSQ-P
1 Specifications
1-2 Electrical Specifications FXSQ20P7VEB FXSQ25P7VEB FXSQ32P7VEB FXSQ40P7VEB FXSQ50P7VEB
Power supply Name VE
Phase 1~
Frequency Hz 50/60
Voltage V 220-240/220
Voltage range Min. % -10 0d
Max. % 10 0d
Current - 50Hz Minimum circuit amps (MCA) A 0.5 1.2
Total overcurrent amps (TOCA) A -
Maximum fuse amps (MFA) A 16
Current - 60Hz Minimum circuit amps (MCA) A 0.5 1.2
Maximum fuse amps (MFA) A 16
1-2 Electrical Specifications FXSQ63P7VEB FXSQ80P7VEB FXSQ100P7VEB FXSQ125P7VEB FXSQ140P7VEB
Power supply Name VE
Phase 1~
Frequency Hz 50/60
Voltage V 220-240/220
Voltage range Min. % -10 0d
Max. % 10 0d
Current - 50Hz Minimum circuit amps (MCA) A 1.1 1.3 1.4 1.9 3.1
Total overcurrent amps (TOCA) A -
Maximum fuse amps (MFA) A 16
Current - 60Hz Minimum circuit amps (MCA) A 1.1 1.3 1.4 1.9 3.1
Maximum fuse amps (MFA) A 16
FXSQ_EN.pdf 7 29/06/2010 14:31:34

• Indoor Unit • Round Flow Cassette • FXSQ-P
• VRV® Systems • Indoor Unit
6
2 Electrical data
FXSQ-P
4TW31181-2A
Units Power Supply
Model TypeHz Volts Min. Max. MCAMFA
FXSQ20
VE 50/60 220~240V/220V-10% +10%
0.4 16
FXSQ250.4 16
FXSQ320.4 16
FXSQ40 1.216
FXSQ50 1.216
FXSQ63 1.1 16
FXSQ80 1.3 16
FXSQ100 1.6 16
FXSQ1252.1 16
FXSQ140 3.1 16
SYMBOLS
NOTES
MCA : Min.Circuit Amps. (A) 1 Voltage range
Units are suitable for use on electrical systems where voltage
supplied to unit terminal is not belowor above listed range
limits.
2Maximumallowable voltage variation between phases is 2%
3Select wire size based on the MCA.
4 Instead of afuse, use acircuit breaker.
MFA : Max. Fuse Amps. (A) (see note 4)
FXSQ_EN.pdf 8 29/06/2010 14:31:34

3
• VRV® Systems • Indoor Unit 7
• Indoor Unit • Round Flow Cassette • FXSQ-P
3 Safety device settings
FXSQ20-140P
3TW31189-2A
Safety devices 20 25 32 40 50 63 80 100 125 140
FXSQ
PC Board Fuse 250V
3.15A
250V
3.15A
250V
3.15A
250V
3.15A
250V
3.15A
250V
3.15A
250V
3.15A
250V
3.15A
250V
3.15A
250V
3.15A
PC Board Fuse (Fan Driver) 250V5A 250V5A 250V5A 250V5A 250V5A 250V6.3A 250V6.3A 250V6.3A 250V6.3A 250V6.3A
Fan Motor Thermal Protector °C——————————
Drain PumpFuse °C145 145 145 145 145 145 145 145 145 145
FXSQ_EN.pdf 9 29/06/2010 14:31:34

• Indoor Unit • Round Flow Cassette • FXSQ-P
• VRV® Systems • Indoor Unit
8
4 Options
FXSQ20-140P
3TW31189-3D
Options
Operation Control
(*1): Electrical heater and humidifier are field supply. These parts should not be installed inside the equipment (refer to installation manual EKRP1B2A)
(*2): If installing an electrical heater, an option PCB for external heater (EKRP1B2) for each indoor unit is required.
(*3): An electrical heater can not be used for VRVsystem cooling only.
(*4): Mounting plate KRP4A96 is required for these options. Maximum 2option PCB’s can be mounted.
(*5): Decoration panel option EKBYBSD is required for direct mounting of the decoration panel on the unit.
Contents of accessory bag
Item TypeFXSQ20,25,32FXSQ40,50 FXSQ63,80 FXSQ100,125,140
Panel related Decoration panel (*5) BYBS32BYBS45D BYBS71D BYBS125D
Air inlet and air discharge outlet related Air discharge adapter for round duct KDAJ25K36A KDAJ25K56A KDAJ25KA71A KDAJ25KA140A
Panel related Decoration panel option EKBYBSD
Item TypeFXSQ20,25,32FXSQ40,50 FXSQ63,80 FXSQ100,125,140
Remote Control Wired TypeBRC1D528 / BRC1E51A
Infrared typeHPBRC4C65
COBRC4C66
Simplified remote control BRC2C51
Remote control for hotel use BRC3A61
Option BCB for external el. heater, humidifier and/or hour meter (*1), (*2), (*3), (*4) EKRP1B2A
Adapter for wiring (interlock for fresh air intake fan) (*4) KRP1C64
Wiring adapter for electrical appendices (1) (*2), (*4) KRP2A51
Wiring adapter for electrical appendices (2) (*4) KRP4A51
Remote sensor KRCS01-4B
Central remote control DCS302CA51
Electrical box with earth terminal (3 blocks) KJB311A
Unified ON/OFF control DCS301BA51
Electrical box with earth terminal (2blocks) KJB212A
Schedule timer DST301BA51
External adapter for outdoor unit (installation on indoor unit) (*4) DTA104A61
Mounting plate for adapter PCBKRP4A96
Description Quantity
FXSQ 20,25,32,40,50,63,80,100,125,140
Hexagon tapping screw (M5x16) 16
Round plain washer for wood 8
Installation and operation manual 1
Hose band 1
Insulation for joint (GAS) 1
Insulation for joint (LIQUID) 1
Drain hose 1
Drain hose sealing material 1
Sealing material 2
NOTES
FXSQ_EN.pdf 10 29/06/2010 14:31:34

3
• VRV® Systems • Indoor Unit 9
• Indoor Unit • Round Flow Cassette • FXSQ-P
5 Capacity tables
5 - 1 CoolingCapacity Tables
FXSQ-P
3TW31182-1
TC: Total Capacity: kW; SHC: Sensible heat capacity: kW
Unit size
Outdoor
air temp.
(°CDB)
Indoor air temperature
14.0WB 16.0WB 18.0WB19.0WB20.0WB22.0WB24.0WB
20.0DB 23.0DB 26.0DB 27.0DB 28.0DB 30.0DB 32.0DB
TCSHCTCSHCTCSHCTCSHCTCSHCTCSHCTCSHC
20 10.0 1.5 1.5 1.8 1.8 2.1 1.92.21.92.3 1.92.6 2.0 2.8 2.1
12.0 1.5 1.5 1.8 1.8 2.1 1.92.21.92.3 1.92.6 2.0 2.7 2.0
14.0 1.5 1.5 1.8 1.8 2.1 1.92.21.92.3 1.92.6 2.0 2.7 2.0
16.0 1.5 1.5 1.8 1.8 2.1 1.92.21.92.3 1.92.6 2.0 2.7 2.0
18.0 1.5 1.5 1.8 1.8 2.1 1.92.21.92.3 1.92.6 2.0 2.6 2.0
20.0 1.5 1.5 1.8 1.8 2.1 1.92.21.92.3 1.92.5 1.92
.6 2.0
21.0 1.5 1.5 1.8 1.8 2.1 1.92.21.92.3 1.92.5 1.92.6 2.0
23.0 1.5 1.5 1.8 1.8 2.1 1.92.21.92.3 1.92.5 1.92.5 1.9
25.0 1.5 1.5 1.8 1.8 2.1 1.92.21.92.3 1.92.5 1.92.5 1.9
27.0 1.5 1.5 1.8 1.8 2.1 1.92.21.92.3 1.92.4 1.92.5 1.9
29.0 1.5 1.5 1.8 1.8 2.1 1.92.21.92.3 1.92.4 1.8 2.4 1.9
31.0 1.5 1.5 1.8 1.8 2.1 1.92.21.92.3 1.92.4 1.8 2.4 1.8
33.0 1.5 1.5 1.8 1.8 2.1 1.92.21.92.3 1.92.3 1.8 2.4 1.8
35.0 1.5 1.5 1.8 1.8 2.1 1.92.21.92.21.92.3 1.8 2.3 1.8
37.0 1.5 1.5 1.8 1.8 2.1 1.92.21.92.21.8 2.21.7 2.3 1.8
39.0 1.5 1.5 1.8 1.8 2.1 1.92.1 1.92.21.8 2.21.7 2.3 1.8
25 10.0 1.91.8 2.3 2.0 2.6 2.3 2.8 2.3 3.0 2.3 3.3 2.4 3.5 2.4
12.0 1.91.8 2.3 2.0 2.6 2.3 2.8 2.3 3.0 2.3 3.3 2.4 3.5 2.4
14.0 1.91.8 2.3 2.0 2.6 2.3 2.8 2.3 3.0 2.3 3.3 2.4 3.4 2.4
16.0 1.91.8 2.3 2.0 2.6 2.3 2.8 2.3 3.0 2.3 3.3 2.4 3.4 2.4
18.0 1.91.8 2.3 2.0 2.6 2.3 2.8 2.3 3.0 2.3 3.3 2.4 3.4 2.4
20.0 1.91.8 2.3 2.0 2.6 2.3 2.8 2.3 3.0 2.3 3.22.3 3.3 2.3
21.0 1.91.8 2.3 2.0 2.6 2.3 2.8 2.3 3.0 2.3 3.22
.3 3.3 2.3
23.0 1.91.8 2.3 2.0 2.6 2.3 2.8 2.3 3.0 2.3 3.22.3 3.22.3
25.0 1.91.8 2.3 2.0 2.6 2.3 2.8 2.3 3.0 2.3 3.1 2.3 3.22.3
27.0 1.91.8 2.3 2.0 2.6 2.3 2.8 2.3 3.0 2.3 3.1 2.23.22.3
29.0 1.91.8 2.3 2.0 2.6 2.3 2.8 2.3 3.0 2.3 3.0 2.23.1 2.2
31.0 1.91.8 2.3 2.0 2.6 2.3 2.8 2.3 2.92.3 3.0 2.23.1 2.2
33.0 1.91.8 2.3 2.0 2.6 2.3 2.8 2.3 2.92.3 2.92.23.0 2.2
35.0 1.91.8 2.3 2.0 2.6 2.3 2.8 2.3 2.8 2.22.92.1 3.0 2.2
37.0 1.91.8 2.3 2.0 2.6 2.3 2.8 2.3 2.8 2.22.92.1 2.92
.1
39.0 1.91.8 2.3 2.0 2.6 2.3 2.7 2.22.7 2.22.8 2.1 2.92.1
3210.0 2.4 2.22.92.5 3.4 2.8 3.6 2.93.8 2.94.3 3.0 4.6 3.0
12.0 2.4 2.22.92.5 3.4 2.8 3.6 2.93.8 2.94.3 3.0 4.5 3.0
14.0 2.4 2.22.92.5 3.4 2.8 3.6 2.93.8 2.94.3 3.0 4.4 3.0
16.0 2.4 2.22.92.5 3.4 2.8 3.6 2.93.8 2.94.3 3.0 4.4 3.0
18.0 2.4 2.22.92.5 3.4 2.8 3.6 2.93.8 2.94.23.0 4.3 2.9
20.0 2.4 2.22.92.5 3.4 2.8 3.6 2.93.8 2.94.22.94.3 2.9
21.0 2.4 2.22.92.5 3.4 2.8 3.6 2.93.8 2.94.1 2.94.22.9
23.0 2.4 2.22.92.5 3.4 2.8 3.6 2.93.8 2.94.1 2.94.22.9
25.0 2.4 2.22.92.5 3.4 2.8 3.6 2.93.8 2.94.0 2.94.1 2.8
27.0 2.4 2.22.92.5 3.4 2.8 3.6 2.93.8 2.94.0 2.8 4.1 2.8
29.0 2.4 2.22.92.5 3.4 2.8 3.6 2.93.8 2.93.92.8 4.0 2.8
31.0 2.4 2.22.92.5 3.4 2.8 3.6 2.93.8 2.93.8 2.8 3.92.7
33.0 2.4 2.22.92.5 3.4 2.8 3.6 2.93.7 2.8 3.8 2.7 3.92.7
35.0 2.4 2.22.92.5 3.4 2.8 3.6 2.93.6 2.8 3.7 2.7 3.8 2.7
37.0 2.4 2.22.92.5 3.4 2.8 3.5 2.8 3.6 2.8 3.7 2.7 3.8 2.7
39.0 2.4 2.22.92.5 3.4 2.8 3.5 2.8 3.5 2.7 3.6 2.6 3.7 2.6
40 10.0 3.0 2.93.6 3.4 4.23.8 4.5 3.8 4.8 3.8 5.4 3.95.7 4.0
12.0 3.0 2.93.6 3.4 4.23.8 4.5 3.8 4.8 3.8 5.4 3.95.6 4.0
14.0 3.0 2.93.6 3.4 4.23.8 4.5 3.8 4.8 3.8 5.4 3.95.5 4.0
16.0 3.0 2.93.6 3.4 4.23.8 4.5 3.8 4.8 3.8 5.4 3.95.5 3.9
18.0 3.0 2.93.6 3.4 4.23.8 4.5 3.8 4.8 3.8 5.3 3.95.4 3.9
20.0 3.0 2.93.6 3.4 4.23.8 4.5 3.8 4.8 3.8 5.23.8 5.3 3.9
21.0 3.0 2.93.6 3.4 4.23.8 4.5 3.8 4.8 3.8 5.23.8 5.3 3.8
23.0 3.0 2.93.6 3.4 4.23.8 4.5 3.8 4.8 3.8 5.1 3.8 5.23.8
25.0 3.0 2.93.6 3.4 4.23.8 4.5 3.8 4.8 3.8 5.0 3.7 5.1 3.8
27.0 3.0 2.93.6 3.4 4.23.8 4.5 3.8 4.8 3.8 5.0 3.7 5.1 3.7
29.0 3.0 2.93.6 3.4 4.23.8 4.5 3.8 4.8 3.8 4.93.7 5.0 3.7
31.0 3.0 2.93.6 3.4 4.23.8 4.5 3.8 4.7 3.8 4.8 3.6 4.93.6
33.0 3.0 2.93.6 3.4 4.23.8 4.5 3.8 4.6 3.7 4.7 3.6 4.8 3.6
35.0 3.0 2.93.6 3.4 4.23.8 4.5 3.8 4.6 3.7 4.7 3.5 4.8 3.6
37.0 3.0 2.93.6 3.4 4.23.8 4.4 3.8 4.5 3.6 4.6 3.5 4.7 3.5
39.0 3.0 2.93.6 3.4 4.23.8 4.4 3.7 4.4 3.6 4.5 3.4 4.6 3.5
50 10.0 3.8 3.6 4.5 3.95.23.8 5.6 4.4 6.0 4.5 6.7 4.1 7.1 4.7
12.0 3.8 3.6 4.5 3.95.23.8 5.6 4.4 6.0 4.5 6.7 4.1 7.0 4.7
14.0 3.8 3.6 4.5 3.95.23.8 5.6 4.4 6.0 4.5 6.7 4.1 6.94.6
16.0 3.8 3.6 4.5 3.95.23.8 5.6 4.4 6.0 4.5 6.7 4.1 6.8 4.6
18.0 3.8 3.6 4.5 3.95.23.8 5.6 4.4 6.0 4.5 6.6 4.1 6.7 4.5
20.0 3.8 3.6 4.5 3.95.23.8 5.6 4.4 6.0 4.5 6.5 4.0 6.6 4.5
21.0 3.8 3.6 4.5 3.95.23.8 5.6 4.4 6.0 4.5 6.4 4.0 6.6 4.5
23.0 3.8 3.6 4.5 3.95.23.8 5.6 4.4 6.0 4.5 6.4 4.0 6.5 4.4
25.0 3.8 3.6 4.5 3.95.23.8 5.6 4.4 6.0 4.5 6.3 3.96.4 4.4
27.0 3.8 3.6 4.5 3.95.23.8 5.6 4.4 6.0 4.5 6.23.96.3 4.3
29.0 3.8 3.6 4.5 3.95.23.8 5.6 4.4 5.94.5 6.1 3.8 6.24.3
31.0 3.8 3.6 4.5 3.95.23.8 5.6 4.4 5.94.4 6.0 3.8 6.1 4.3
33.0 3.8 3.6 4.5 3.95.23.8 5.6 4.4 5.8 4.4 5.93.8 6.0 4.2
35.0 3.8 3.6 4.5 3.95.23.8 5.6 4.4 5.7 4.3 5.8 3.7 5.94.2
37.0 3.8 3.6 4.5 3.95.23.8 5.5 4.4 5.6 4.3 5.7 3.7 5.94.1
39.0 3.8 3.6 4.5 3.95.23.8 5.4 4.3 5.5 4.25.6 3.6 5.8 4.1
FXSQ_EN.pdf 11 29/06/2010 14:31:34

• Indoor Unit • Round Flow Cassette • FXSQ-P
• VRV® Systems • Indoor Unit
10
5 Capacity tables
5 - 1 CoolingCapacity Tables
FXSQ-P
3TW31182-1
TC: Total Capacity: kW; SHC : Sensible heat capacity: kW
Unit size
Outdoor
air temp.
(°CDB)
Indoor air temperature
14.0WB 16.0WB 18.0WB19.0WB20.0WB22.0WB24.0WB
20.0DB 23.0DB 26.0DB 27.0DB 28.0DB 30.0DB 32.0DB
TCSHCTCSHCTCSHCTCSHCTCSHCTCSHCTCSHC
63 10.0 4.8 4.25.7 4.96.6 5.4 7.1 5.5 7.6 5.6 8.5 5.8 9.0 6.4
12.0 4.8 4.25.7 4.96.6 5.4 7.1 5.5 7.6 5.6 8.5 5.8 8.96.3
14.0 4.8 4.25.7 4.96.6 5.4 7.1 5.5 7.6 5.6 8.5 5.8 8.7 6.3
16.0 4.8 4.25.7 4.96.6 5.4 7.1 5.5 7.6 5.6 8.5 5.8 8.6 6.3
18.0 4.8 4.25.7 4.96.6 5.4 7.1 5.5 7.6 5.6 8.3 5.8 8.5 6.2
20.0 4.8 4.25.7 4.96.6 5.4 7.1 5.5 7.6 5.6 8.25.7 8.4 6.2
21.0 4.8 4.25.7 4.96.6 5.4 7.1 5.5 7.6 5.6 8.25.7 8.3 6.2
23.0 4.8 4.25.7 4.96.6 5.4 7.1 5.5 7.6 5.6 8.1 5.6 8.26.1
25.0 4.8 4.25.7 4.96.6 5.4 7.1 5.5 7.6 5.6 7.95.6 8.1 6.1
27.0 4.8 4.25.7 4.96.6 5.4 7.1 5.5 7.6 5.6 7.8 5.5 8.0 6.1
29.0 4.8 4.25.7 4.96.6 5.4 7.1 5.5 7.5 5.6 7.7 5.4 7.96.0
31.0 4.8 4.25.7 4.96.6 5.4 7.1 5.5 7.4 5.5 7.6 5.4 7.8 6.0
33.0 4.8 4.25.7 4.96.6 5.4 7.1 5.5 7.3 5.5 7.5 5.3 7.6 5.9
35.0 4.8 4.25.7 4.96.6 5.4 7.1 5.5 7.25.4 7.4 5.3 7.5 5.9
37.0 4.8 4.25.7 4.96.6 5.4 7.0 5.5 7.1 5.4 7.25.27.4 5.9
39.0 4.8 4.25.7 4.96.6 5.4 6.95.4 7.0 5.3 7.1 5.1 7.3 5.8
80 10.0 6.1 5.3 7.26.1 8.4 6.99.0 7.0 9.6 7.1 10.8 7.4 11.4 7.4
12.0 6.1 5.3 7.26.1 8.4 6.99.0 7.0 9.6 7.1 10.8 7.4 11.27.4
14.0 6.1 5.3 7.26.1 8.4 6.99.0 7.0 9.6 7.1 10.8 7.4 11.1 7.3
16.0 6.1 5.3 7.26.1 8.4 6.99.0 7.0 9.6 7.1 10.7 7.4 10.97.2
18.0 6.1 5.3 7.26.1 8.4 6.99.0 7.0 9.6 7.1 10.6 7.3 10.8 7.2
20.0 6.1 5.3 7.26.1 8.4 6.99.0 7.0 9.6 7.1 10.4 7.210.6 7.1
21.0 6.1 5.3 7.26.1 8.4 6.99.0 7.0 9.6 7.1 10.4 7.210.6 7.1
23.0 6.1 5.3 7.26.1 8.4 6.99.0 7.0 9.6 7.1 10.27.1 10.4 7.0
25.0 6.1 5.3 7.26.1 8.4 6.99.0 7.0 9.6 7.1 10.1 7.0 10.3 6.9
27.0 6.1 5.3 7.26.1 8.4 6.99.0 7.0 9.6 7.1 9.97.0 10.1 6.9
29.0 6.1 5.3 7.26.1 8.4 6.99.0 7.0 9.5 7.1 9.8 6.910.0 6.8
31.0 6.1 5.3 7.26.1 8.4 6.99.0 7.0 9.4 7.0 9.6 6.8 9.8 6.7
33.0 6.1 5.3 7.26.1 8.4 6.99.0 7.0 9.3 7.0 9.5 6.7 9.7 6.7
35.0 6.1 5.3 7.26.1 8.4 6.99.0 7.0 9.1 6.99.3 6.6 9.5 6.6
37.0 6.1 5.3 7.26.1 8.4 6.98.96.99.0 6.8 9.26.6 9.4 6.5
39.0 6.1 5.3 7.26.1 8.4 6.98.7 6.8 8.8 6.7 9.0 6.5 9.3 6.5
100 10.0 7.6 6.4 9.0 7.3 10.5 8.3 11.28.5 11.98.7 13.4 9.0 14.28.9
12.0 7.6 6.4 9.0 7.3 10.5 8.3 11.28.5 11.98.7 13.4 9.0 14.0 8.9
14.0 7.6 6.4 9.0 7.3 10.5 8.3 11.28.5 11.98.7 13.4 9.0 13.8 8.8
16.0 7.6 6.4 9.0 7.3 10.5 8.3 11.28.5 11.98.7 13.3 9.0 13.6 8.7
18.0 7.6 6.4 9.0 7.3 10.5 8.3 11.28.5 11.98.7 13.28.913.4 8.6
20.0 7.6 6.4 9.0 7.3 10.5 8.3 11.28.5 11.98.7 13.0 8.8 13.28.5
21.0 7.6 6.4 9.0 7.3 10.5 8.3 11.28.5 11.98.7 12.98.8 13.28.5
23.0 7.6 6.4 9.0 7.3 10.5 8.3 11.28.5 11.98.7 12.7 8.7 13.0 8.4
25.0 7.6 6.4 9.0 7.3 10.5 8.3 11.28.5 11.98.7 12.5 8.6 12.8 8.3
27.0 7.6 6.4 9.0 7.3 10.5 8.3 11.28.5 11.98.7 12.3 8.5 12.6 8.2
29.0 7.6 6.4 9.0 7.3 10.5 8.3 11.28.5 11.98.6 12.28.4 12.4 8.1
31.0 7.6 6.4 9.0 7.3 10.5 8.3 11.28.5 11.7 8.6 12.0 8.3 12.28.0
33.0 7.6 6.4 9.0 7.3 10.5 8.3 11.28.5 11.5 8.5 11.8 8.212.1 7.9
35.0 7.6 6.4 9.0 7.3 10.5 8.3 11.28.5 11.3 8.4 11.6 8.1 11.97.8
37.0 7.6 6.4 9.0 7.3 10.5 8.3 11.0 8.4 11.28.3 11.4 8.0 11.7 7.7
39.0 7.6 6.4 9.0 7.3 10.5 8.3 10.8 8.3 11.0 8.211.27.911.5 7.6
125 10.0 9.5 7.8 11.3 8.913.1 9.6 14.0 9.914.910.3 16.8 10.7 18.4 11.0
12.0 9.5 7.8 11.3 8.913.1 9.6 14.0 9.914.910.3 16.8 10.7 18.210.9
14.0 9.5 7.8 11.3 8.913.1 9.6 14.0 9.914.910.3 16.8 10.7 18.0 10.7
16.0 9.5 7.8 11.3 8.913.1 9.6 14.0 9.914.910.3 16.8 10.7 17.7 10.6
18.0 9.5 7.8 11.3 8.913.1 9.6 14.0 9.914.910.3 16.8 10.7 17.5 10.4
20.0 9.5 7.8 11.3 8.913.1 9.6 14.0 9.914.910.3 16.8 10.7 17.210.3
21.0 9.5 7.8 11.3 8.913.1 9.6 14.0 9.914.910.3 16.8 10.7 17.1 10.2
23.0 9.5 7.8 11.3 8.913.1 9.6 14.0 9.914.910.3 16.5 10.6 16.910.1
25.0 9.5 7.8 11.3 8.913.1 9.6 14.0 9.914.910.3 16.3 10.4 16.6 10.0
27.0 9.5 7.8 11.3 8.913.1 9.6 14.0 9.914.910.3 16.1 10.3 16.4 9.9
29.0 9.5 7.8 11.3 8.913.1 9.6 14.0 9.914.910.3 15.8 10.1 16.29.8
31.0 9.5 7.8 11.3 8.913.1 9.6 14.0 9.914.910.3 15.6 10.0 15.99.6
33.0 9.5 7.8 11.3 8.913.1 9.6 14.0 9.914.910.3 15.3 9.915.7 9.5
35.0 9.5 7.8 11.3 8.913.1 9.6 14.0 9.914.8 10.215.1 9.8 15.4 9.4
37.0 9.5 7.8 11.3 8.913.1 9.6 14.0 9.914.5 10.1 14.99.7 15.29.3
39.0 9.5 7.8 11.3 8.913.1 9.6 14.0 10.0 14.3 9.914.6 9.6 15.0 9.2
140 10.0 10.8 9.0 12.910.4 15.0 11.7 16.0 12.0 17.0 12.3 19.1 12.7 20.212.6
12.0 10.8 9.0 12.910.4 15.0 11.7 16.0 12.0 17.0 12.3 19.1 12.7 20.0 12.5
14.0 10.8 9.0 12.910.4 15.0 11.7 16.0 12.0 17.0 12.3 19.1 12.7 19.7 12.4
16.0 10.8 9.0 12.910.4 15.0 11.7 16.0 12.0 17.0 12.3 19.1 12.7 19.4 12.3
18.0 10.8 9.0 12.910.4 15.0 11.7 16.0 12.0 17.0 12.3 18.8 12.6 19.212.2
20.0 10.8 9.0 12.910.4 15.0 11.7 16.0 12.0 17.0 12.3 18.5 12.4 18.912.1
21.0 10.8 9.0 12.910.4 15.0 11.7 16.0 12.0 17.0 12.3 18.4 12.4 18.8 12.1
23.0 10.8 9.0 12.910.4 15.0 11.7 16.0 12.0 17.0 12.3 18.1 12.3 18.5 12.0
25.0 10.8 9.0 12.910.4 15.0 11.7 16.0 12.0 17.0 12.3 17.912.1 18.3 11.9
27.0 10.8 9.0 12.910.4 15.0 11.7 16.0 12.0 17.0 12.3 17.6 12.0 18.0 11.8
29.0 10.8 9.0 12.910.4 15.0 11.7 16.0 12.0 17.0 12.3 17.4 11.917.8 11.7
31.0 10.8 9.0 12.910.4 15.0 11.7 16.0 12.0 16.7 12.1 17.1 11.8 17.5 11.6
33.0 10.8 9.0 12.910.4 15.0 11.7 16.0 12.0 16.5 12.0 16.8 11.7 17.211.5
35.0 10.8 9.0 12.910.4 15.0 11.7 16.0 12.0 16.211.916.6 11.5 17.0 11.3
37.0 10.8 9.0 12.910.4 15.0 11.7 15.7 11.915.911.7 16.3 11.4 16.7 11.2
39.0 10.8 9.0 12.910.4 15.0 11.7 15.5 11.8 15.7 11.6 16.1 11.3 16.5 11.1
FXSQ_EN.pdf 12 29/06/2010 14:31:34

3
• VRV® Systems • Indoor Unit 11
• Indoor Unit • Round Flow Cassette • FXSQ-P
5 Capacity tables
5 - 2HeatingCapacity Tables
FXSQ-P
3TW25512-2A
Unit Size
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
°CDB °CWB kW kW kW kW kW kW
20 -19.8 -20.0 1.5 1.5 1.5 1.5 1.5 1.5
-18.8 -19.0 1.5 1.5 1.5 1.5 1.5 1.5
-16.7 -17.0 1.6 1.6 1.6 1.6 1.6 1.6
-14.7 -15.0 1.7 1.7 1.7 1.7 1.7 1.7
-12.6 -13.0 1.8 1.8 1.8 1.8 1.8 1.8
-10.5 -11.0 1.91.91.91.91.91.9
-9.5 -10.0 1.91.91.91.91.91.9
-8.5 -9.1 2.0 2.0 1.91.91.91.9
-7.0 -7.6 2.0 2.0 2.0 2.0 2.0 2.0
-5.0 -5.6 2.1 2.1 2.1 2.1 2.1 2.1
-3.0 -3.7 2.22.22.22.22.22.2
0.0 -0.7 2.3 2.3 2.3 2.3 2.3 2.2
3.0 2.22.5 2.5 2.4 2.4 2.3 2.2
5.0 4.1 2.5 2.5 2.5 2.4 2.3 2.2
7.0 6.0 2.6 2.6 2.5 2.4 2.3 2.2
9.0 7.92.7 2.7 2.5 2.4 2.3 2.2
11.0 9.8 2.8 2.7 2.5 2.4 2.3 2.2
13.0 11.8 2.8 2.7 2.5 2.4 2.3 2.2
15.0 13.7 2.8 2.7 2.5 2.4 2.3 2.2
25 -19.8 -20.0 1.91.91.91.91.91.9
-18.8 -19.0 1.91.91.91.91.91.9
-16.7 -17.0 2.1 2.1 2.0 2.0 2.0 2.0
-14.7 -15.0 2.22.22.22.22.22.2
-12.6 -13.0 2.3 2.3 2.3 2.3 2.3 2.3
-10.5 -11.0 2.4 2.4 2.4 2.4 2.4 2.4
-9.5 -10.0 2.5 2.5 2.4 2.4 2.4 2.4
-8.5 -9.1 2.5 2.5 2.5 2.5 2.5 2.5
-7.0 -7.6 2.6 2.6 2.6 2.6 2.6 2.6
-5.0 -5.6 2.7 2.7 2.7 2.7 2.7 2.7
-3.0 -3.7 2.8 2.8 2.8 2.8 2.8 2.8
0.0 -0.7 3.0 3.0 3.0 3.0 3.0 2.8
3.0 2.23.1 3.1 3.1 3.1 3.0 2.8
5.0 4.1 3.3 3.23.23.1 3.0 2.8
7.0 6.0 3.4 3.4 3.23.1 3.0 2.8
9.0 7.93.5 3.4 3.23.1 3.0 2.8
11.0 9.8 3.6 3.4 3.23.1 3.0 2.8
13.0 11.8 3.6 3.4 3.23.1 3.0 2.8
15.0 13.7 3.6 3.4 3.23.1 3.0 2.8
32-19.8 -20.0 2.4 2.4 2.3 2.3 2.3 2.3
-18.8 -19.0 2.4 2.4 2.4 2.4 2.4 2.4
-16.7 -17.0 2.6 2.6 2.6 2.6 2.6 2.5
-14.7 -15.0 2.7 2.7 2.7 2.7 2.7 2.7
-12.6 -13.0 2.92.92.8 2.8 2.8 2.8
-10.5 -11.0 3.0 3.0 3.0 3.0 3.0 3.0
-9.5 -10.0 3.1 3.1 3.1 3.1 3.0 3.0
-8.5 -9.1 3.1 3.1 3.1 3.1 3.1 3.1
-7.0 -7.6 3.23.23.23.23.23.2
-5.0 -5.6 3.4 3.4 3.4 3.4 3.4 3.4
-3.0 -3.7 3.5 3.5 3.5 3.5 3.5 3.5
0.0 -0.7 3.7 3.7 3.7 3.7 3.7 3.5
3.0 2.23.93.93.93.93.7 3.5
5.0 4.1 4.1 4.1 4.0 3.93.7 3.5
7.0 6.0 4.24.24.0 3.93.7 3.5
9.0 7.94.3 4.3 4.0 3.93.7 3.5
11.0 9.8 4.5 4.3 4.0 3.93.7 3.5
13.0 11.8 4.5 4.3 4.0 3.93.7 3.5
15.0 13.7 4.5 4.3 4.0 3.93.7 3.5
40 -19.8 -20.0 3.0 2.92.92.92.92.9
-18.8 -19.0 3.0 3.0 3.0 3.0 3.0 3.0
-16.7 -17.0 3.23.23.23.23.23.2
-14.7 -15.0 3.4 3.4 3.4 3.4 3.4 3.4
-12.6 -13.0 3.6 3.6 3.6 3.5 3.5 3.5
-10.5 -11.0 3.7 3.7 3.7 3.7 3.7 3.7
-9.5 -10.0 3.8 3.8 3.8 3.8 3.8 3.8
-8.5 -9.1 3.93.93.93.93.93.9
-7.0 -7.6 4.0 4.0 4.0 4.0 4.0 4.0
-5.0 -5.6 4.24.24.24.24.24.2
-3.0 -3.7 4.4 4.4 4.4 4.4 4.4 4.4
0.0 -0.7 4.7 4.6 4.6 4.6 4.6 4.4
3.0 2.24.94.94.94.8 4.7 4.4
5.0 4.1 5.1 5.1 5.0 4.8 4.7 4.4
7.0 6.0 5.3 5.25.0 4.8 4.7 4.4
9.0 7.95.4 5.3 5.0 4.8 4.7 4.4
11.0 9.8 5.6 5.3 5.0 4.8 4.7 4.4
13.0 11.8 5.6 5.3 5.0 4.8 4.7 4.4
15.0 13.7 5.6 5.3 5.0 4.8 4.7 4.4
50 -19.8 -20.0 3.7 3.7 3.7 3.7 3.7 3.7
-18.8 -19.0 3.8 3.8 3.8 3.8 3.8 3.8
-16.7 -17.0 4.1 4.0 4.0 4.0 4.0 4.0
-14.7 -15.0 4.3 4.3 4.3 4.3 4.24.2
-12.6 -13.0 4.5 4.5 4.5 4.5 4.5 4.5
-10.5 -11.0 4.7 4.7 4.7 4.7 4.7 4.7
-9.5 -10.0 4.8 4.8 4.8 4.8 4.8 4.8
-8.5 -9.1 4.94.94.94.94.94.9
-7.0 -7.6 5.1 5.1 5.1 5.1 5.1 5.1
-5.0 -5.6 5.3 5.3 5.3 5.3 5.3 5.3
-3.0 -3.7 5.5 5.5 5.5 5.5 5.5 5.5
0.0 -0.7 5.95.95.8 5.8 5.8 5.5
3.0 2.26.26.26.26.1 5.95.5
5.0 4.1 6.4 6.4 6.3 6.1 5.95.5
7.0 6.0 6.6 6.6 6.3 6.1 5.95.5
9.0 7.96.8 6.7 6.3 6.1 5.95.5
11.0 9.8 7.0 6.7 6.3 6.1 5.95.5
13.0 11.8 7.1 6.7 6.3 6.1 5.95.5
15.0 13.7 7.1 6.7 6.3 6.1 5.95.5
FXSQ_EN.pdf 13 29/06/2010 14:31:34

• Indoor Unit • Round Flow Cassette • FXSQ-P
• VRV® Systems • Indoor Unit
12
5 Capacity tables
5 - 2HeatingCapacity Tables
FXSQ-P
3TW25512-2A
Unit size
Outdoor
air temp.
Indoor air temperature: °CDB
16.0
18.0
20.0
21.0
22.0
24.0
°CDB °CWBkWkWkWkWkWkW
63 -19.8 -20.0 4.7 4.7 4.7 4.7 4.7 4.7
-18.8 -19.0 4.94.94.8 4.8 4.8 4.8
-16.7 -17.0 5.1 5.1 5.1 5.1 5.1 5.1
-14.7 -15.0 5.4 5.4 5.4 5.4 5.4 5.4
-12.6 -13.0 5.7 5.7 5.7 5.7 5.7 5.7
-10.5 -11.0 6.0 6.0 6.0 6.0 6.0 5.9
-9.5 -10.0 6.1 6.1 6.1 6.1 6.1 6.1
-8.5 -9.1 6.3 6.3 6.26.26.26.2
-7.0 -7.6 6.5 6.5 6.4 6.4 6.4 6.4
-5.0 -5.6 6.8 6.7 6.7 6.7 6.7 6.7
-3.0 -3.7 7.0 7.0 7.0 7.0 7.0 7.0
0.0 -0.7 7.5 7.4 7.4 7.4 7.4 7.0
3.0 2.27.97.8 7.8 7.7 7.5 7.0
5.0 4.1 8.1 8.1 8.0 7.7 7.5 7.0
7.0 6.0 8.4 8.4 8.0 7.7 7.5 7.0
9.0 7.98.7 8.5 8.0 7.7 7.5 7.0
11.0 9.8 8.98.5 8.0 7.7 7.5 7.0
13.0 11.8 9.0 8.5 8.0 7.7 7.5 7.0
15.0 13.7 9.0 8.5 8.0 7.7 7.5 7.0
80 -19.8 -20.0 5.95.95.95.95.95.8
-18.8 -19.0 6.1 6.1 6.0 6.0 6.0 6.0
-16.7 -17.0 6.4 6.4 6.4 6.4 6.4 6.4
-14.7 -15.0 6.8 6.8 6.8 6.7 6.7 6.7
-12.6 -13.0 7.1 7.1 7.1 7.1 7.1 7.1
-10.5 -11.0 7.5 7.5 7.5 7.5 7.4 7.4
-9.5 -10.0 7.7 7.7 7.6 7.6 7.6 7.6
-8.5 -9.1 7.8 7.8 7.8 7.8 7.8 7.8
-7.0 -7.6 8.1 8.1 8.1 8.1 8.0 8.0
-5.0 -5.6 8.5 8.4 8.4 8.4 8.4 8.4
-3.0 -3.7 8.8 8.8 8.8 8.7 8.7 8.7
0.0 -0.7 9.3 9.3 9.3 9.3 9.3 8.7
3.0 2.29.8 9.8 9.8 9.7 9.4 8.7
5.0 4.1 10.210.1 10.0 9.7 9.4 8.7
7.0 6.0 10.5 10.5 10.0 9.7 9.4 8.7
9.0 7.910.8 10.6 10.0 9.7 9.4 8.7
11.0 9.8 11.210.6 10.0 9.7 9.4 8.7
13.0 11.8 11.3 10.6 10.0 9.7 9.4 8.7
15.0 13.7 11.3 10.6 10.0 9.7 9.4 8.7
100 -19.8 -20.0 7.4 7.4 7.3 7.3 7.3 7.3
-18.8 -19.0 7.6 7.6 7.6 7.5 7.5 7.5
-16.7 -17.0 8.0 8.0 8.0 8.0 8.0 8.0
-14.7 -15.0 8.5 8.5 8.4 8.4 8.4 8.4
-12.6 -13.0 8.98.98.98.98.98.8
-10.5 -11.0 9.4 9.3 9.3 9.3 9.3 9.3
-9.5 -10.0 9.6 9.6 9.5 9.5 9.5 9.5
-8.5 -9.1 9.8 9.8 9.7 9.7 9.7 9.7
-7.0 -7.6 10.1 10.1 10.1 10.1 10.1 10.0
-5.0 -5.6 10.6 10.5 10.5 10.5 10.5 10.5
-3.0 -3.7 11.0 11.0 10.910.910.910.9
0.0 -0.7 11.6 11.6 11.6 11.6 11.6 10.9
3.0 2.212.3 12.3 12.212.1 11.7 10.9
5.0 4.1 12.7 12.7 12.5 12.1 11.7 10.9
7.0 6.0 13.1 13.1 12.5 12.1 11.7 10.9
9.0 7.913.5 13.3 12.5 12.1 11.7 10.9
11.0 9.8 14.0 13.3 12.5 12.1 11.7 10.9
13.0 11.8 14.1 13.3 12.5 12.1 11.7 10.9
15.0 13.7 14.1 13.3 12.5 12.1 11.7 10.9
125 -19.8 -20.0 9.4 9.4 9.4 9.4 9.4 9.3
-18.8 -19.0 9.7 9.7 9.7 9.7 9.6 9.6
-16.7 -17.0 10.3 10.3 10.210.210.210.2
-14.7 -15.0 10.910.8 10.8 10.8 10.8 10.8
-12.6 -13.0 11.4 11.4 11.4 11.4 11.3 11.3
-10.5 -11.0 12.0 12.0 11.911.911.911.9
-9.5 -10.0 12.3 12.212.212.212.212.2
-8.5 -9.1 12.5 12.5 12.5 12.5 12.4 12.4
-7.0 -7.6 13.0 12.912.912.912.912.8
-5.0 -5.6 13.5 13.5 13.5 13.4 13.4 13.4
-3.0 -3.7 14.1 14.0 14.0 14.0 14.0 13.9
0.0 -0.7 14.914.914.8 14.8 14.8 13.9
3.0 2.215.7 15.7 15.7 15.5 15.0 13.9
5.0 4.1 16.3 16.216.0 15.5 15.0 13.9
7.0 6.0 16.8 16.8 16.0 15.5 15.0 13.9
9.0 7.917.3 17.0 16.0 15.5 15.0 13.9
11.0 9.8 17.917.0 16.0 15.5 15.0 13.9
13.0 11.8 18.1 17.0 16.0 15.5 15.0 13.9
15.0 13.7 18.1 17.0 16.0 15.5 15.0 13.9
140 -19.8 -20.0 10.6 10.6 10.6 10.6 10.5 10.5
-18.8 -19.0 10.910.910.910.910.910.8
-16.7 -17.0 11.6 11.6 11.5 11.5 11.5 11.5
-13.7 -15.0 12.212.212.212.1 12.1 12.1
-11.8 -13.0 12.912.8 12.8 12.8 12.8 12.7
-9.8 -11.0 13.5 13.5 13.4 13.4 13.4 13.4
-9.5 -10.0 13.8 13.8 13.7 13.7 13.7 13.7
-8.5 -9.1 14.1 14.1 14.0 14.0 14.0 14.0
-7.0 -7.6 14.6 14.5 14.5 14.5 14.5 14.4
-5.0 -5.6 15.215.215.1 15.1 15.1 15.1
-3.0 -3.7 15.8 15.8 15.8 15.7 15.7 15.7
0.0 -0.7 16.8 16.7 16.7 16.7 16.7 15.7
3.0 2.217.7 17.7 17.6 17.4 16.8 15.7
5.0 4.1 18.3 18.3 18.0 17.4 16.8 15.7
7.0 6.0 18.918.918.0 17.4 16.8 15.7
9.0 7.919.5 19.218.0 17.4 16.8 15.7
11.0 9.8 20.1 19.218.0 17.4 16.8 15.7
13.0 11.8 20.3 19.218.0 17.4 16.8 15.7
15.0 13.7 20.3 19.218.0 17.4 16.8 15.7
FXSQ_EN.pdf 14 29/06/2010 14:31:34

3
• VRV® Systems • Indoor Unit 13
• Indoor Unit • Round Flow Cassette • FXSQ-P
6 Dimensional drawings
FXSQ20-32P
3TW31184-1A
NOTE
1 Refer to ‘outlook drawing for installing optional accessories’
when installing optional accessories.
2The required ceiling depth varies according to the
configuration of the specific system.
3 For maintenance of the air filter, it is necessary to provide a
service access panel.
Refer to the ‘filter installation method’ drawing.
Nr Name Description
1Liquid pipe connection ø6.35 flare (connection)
2Gas pipe connection ø12.70 (flare connection)
3Drainpipe connection
VP20 (O.D. ø32/I.D. ø25)
4 Remote control wiring connection
5Power supply connection
6 Drain hole VP25 (OD
ø32/I.D. ø25 )
7Airfilter
8 Air suction side
9Air discharge side
10 Nameplate
View A-A Detail B
Suspension bolt
(Service space) Detail B
350 or more
(Service space)
(Suspension position)
(Suspension position)
FXSQ40-50P
3TW31214-1A
NOTE
1 Refer to ‘outlook drawing for installing optional
accessories’ when installing optional accessories.
2The required ceiling depth varies according to the
configuration of the specific system.
3 For maintenance of the air filter, it is necessary to
provide a service access panel.
Refer to the ‘filter installation method’ drawing.
Nr Name Description
1Liquid pipe connection ø6.35 flare (connection)
2Gas pipe connection ø12.70 (flare connection)
3 Drain pipe connection VP25 (O.D. ø32/I.D. ø25)
4 Remote control wiring connection
5Power supply connection
6 Drain hole VP25 (OD
ø32/I.D. ø25 )
7 Air filter
8 Air suction side
9Air discharge side
10 Nameplate
View A-A Detail B
Suspension bolt
(Service space) Detail B
350 or more
(Service space)
(Suspension position)
(Suspension position)
or more
FXSQ_EN.pdf 15 29/06/2010 14:31:34

• Indoor Unit • Round Flow Cassette • FXSQ-P
• VRV® Systems • Indoor Unit
14
6 Dimensional drawings
FXSQ63-80P
3TW31234-1A
NOTE
1 Refer to ‘outlook drawing for installing optional
accessories’ when installing optional accessories.
2The required ceiling depth varies according to the
configuration of the specific system.
3 For maintenance of the air filter, it is necessary to
provide a service access panel.
Refer to the ‘filter installation method’ drawing.
Nr Name Description
1Liquid pipe connection ø9.52flare (connection)
2Gas pipe connection ø15.90 (flare connection)
3Drainpipe connection
VP25 (O.D. ø32/I.D. ø25)
4 Remote control wiring connection
5Power supply connection
6 Drain hole VP25 (OD
ø32/I.D. ø25 )
7Airfilter
8 Air suction side
9Air discharge side
10 Nameplate
View A-A
Detail B
Suspension bolt
(Service space)
Detail B
350 or more
(Service space)
(Suspension position)
(Suspension position)
or more
FXSQ100-140P
3TW31254-1A
NOTE
1 Refer to ‘outlook drawing for installing optional
accessories’ when installing optional accessories.
2The required ceiling depth varies according to the
configuration of the specific system.
3 For maintenance of the air filter, it is necessary to
provide a service access panel.
Refer to the ‘filter installation method’ drawing.
Nr Name Description
1Liquid pipe connection ø9.52flare (connection)
2Gas pipe connection ø15.90 (flare connection)
3 Drain pipe connection VP25 (O.D. ø32/I.D. ø25)
4 Remote control wiring connection
5Power supply connection
6 Drain hole VP25 (OD
ø32/I.D. ø25 )
7 Air filter
8 Air suction side
9Air discharge side
10 Nameplate
View A-A
Detail B
Suspension bolt
(Service space)
Detail B
350 or more
(Service space)
(Suspension position)
(Suspension position)
or more
FXSQ_EN.pdf 16 29/06/2010 14:31:35

3
• VRV® Systems • Indoor Unit 15
• Indoor Unit • Round Flow Cassette • FXSQ-P
7 Centre of gravity
FXSQ-P
4TW31189-1B
Model A B
FXSQ20~32220 550
FXSQ40,50 283 700
FXSQ63,80 441 1000
FXSQ100,125,140 6191400
FXSQ_EN.pdf 17 29/06/2010 14:31:35

• Indoor Unit • Round Flow Cassette • FXSQ-P
• VRV® Systems • Indoor Unit
16
8 Piping diagrams
FXSQ20-140P
3TW31185-1A
Heat exchanger
Liquid pipe connection port
Gas pipe connection port
Filter Filter
Electronic expansion
valve
Refrigerant flow
Cooling
Heating
Refrigerant pipe connection port diameters
Model Gas Liquid
FXSQ20,25,32,40,50 Ø12.70 Ø6.35
FXSQ63,80,100,125,140 Ø15.90Ø9.52
FXSQ_EN.pdf 18 29/06/2010 14:31:35

3
• VRV® Systems • Indoor Unit 17
• Indoor Unit • Round Flow Cassette • FXSQ-P
9 Wiring diagrams
9 - 1 WiringDiagrams - Single Phase
);643
7:
127(6
 8VHFRSSHUFRQGXFWRUVRQO\
 :KHQXVLQJWKHFHQWUDOUHPRWHFRQWUROVHHPDQXDOIRUFRQQHFWLRQWRWKHXQLW
 :KHQFRQQHFWLQJWKHLQSXWZLUHVIURPRXWVLGHIRUFHGµRII¶RUµRQRII¶RSHUDWLRQFDQEHVHOHFWHGE\WKHUHPRWHFRQWURO
6HHLQVWDOODWLRQPDQXDOIRUPRUHGHWDLOV
,QGRRU8QLW 57 7KHUPLVWRU/LTXLG
$3 3ULQWHGFLUFXLWERDUG 57 7KHUPLVWRU*DV
$3 3ULQWHGFLUFXLWERDUG)DQ 57 7KHUPLVWRU17&&XUUHQWOLPLWLQJ
$3 3ULQWHGFLUFXLWERDUG&DSDFLWRU 6/ )ORDWVZLWFK
&&& &DSDFLWRU 95 'LRGHEULGJH
)8 )XVH7$9 95 3RZHUPRGXOH
)8 )XVH7$9 ;0 7HUPLQDOVWULS3RZHUVXSSO\
)8 )XVH7$9 ;0 7HUPLQDOVWULS&RQWURO
)8 )XVH7$9 <( (OHFWURQLFH[SDQVLRQYDOYH
+$3 /LJKWHPLWWLQJGLRGH6HUYLFHPRQLWRUJUHHQ =&=& 1RLVH¿OWHU)HUULWHFRUH
.35.5 0DJQHWLFUHOD\ =) 1RLVH¿OWHU
/5 5HDFWRU &RQQHFWRURSWLRQDODFFHVVRU\
0) 0RWRUIDQ ;$ &RQQHFWRU3RZHUVXSSO\IRUZLULQJ
03 0RWRU'UDLQSXPS ;$ &RQQHFWRU)RUZLULQJ
36 6ZLWFKLQJSRZHUVXSSO\ ;$ &RQQHFWRU$GDSWHU
4', (DUWKOHDNGHWHFWRU ;$ &RQQHFWRU)RUZLULQJ
5 5HVLVWRU&XUUHQWOLPLWLQJ :LUHGUHPRWHFRQWURO
5 &XUUHQWVHQVLQJGHYLFH 57 7KHUPLVWRU$LU
55 5HVLVWRU(OHFWULFGLVFKDUJH 66 6HOHFWRUVZLWFK0DLQVXE
57 7KHUPLVWRU6XFWLRQDLU
)LHOGZLULQJ &RORUV %/. %ODFN 31. 3LQN
/ /LYH %/8 %OXH 5(' 5HG
1 1HXWUDO %51 %URZQ :+7 :KLWH
&RQQHFWRU *5< *UH\ </: <HOORZ
Ɣ :LUHFODPS 25* 2UDQJH *51 *UHHQ
3URWHFWLYHHDUWKVFUHZ
1a9+]
1a9+]
,QGRRU
7R
;0
)RUaFODVVaFODVVPHGLXPHVSGXFW
)RUaFODVVKLJKHVSGXFW
7R;$$3
)RUaFODVVaFODVVPHGLXPHVSGXFW
)RUaFODVVKLJKHVSGXFW
6ZLWFKER[,QGRRU
$3RQO\IRUaFODVVaFODVVPHGLXPHVSGXFW
$3RQO\IRUaFODVVKLJKHVSGXFW
:LUHGUHPRWHFRQWURO
2SWLRQDODFFHVVRU\
,QSXWIURP
RXWVLGHQRWH
WUDQVPLVVLRQ
ZLULQJ
FHQWUDOUHPRWH
FRQWURO
QRWH
FXSQ_EN.pdf 19 29/06/2010 14:31:36

• Indoor Unit • Round Flow Cassette • FXSQ-P
• VRV® Systems • Indoor Unit
18
10 Sound data
10 - 1 Sound Power Spectrum
FXSQ20-25P
3TW31187-2
Notes
1 Data is valid at free field condition
2Data is valid at nominal operation condition
3 dBA = A-weighted sound power level. (A-scale according to IEC)
4 Reference acoustic pressures 0dB = 20μPa
5 Location of microphine
Sound pressure level [dB]
Octave band center frequency [dB]
1.5m
Microphone
Unit
2m2m
1.5m
1m
High-tap
Medium-tap
Low-tap
DischargeSuction
FXSQ32P
3TW31207-2
Notes
1 Data is valid at free field condition
2Data is valid at nominal operation condition
3 dBA = A-weighted sound power level. (A-scale according to IEC)
4 Reference acoustic pressures 0dB = 20μPa
5 Location of microphine
Sound pressure level [dB]
Octave band center frequency [dB]
1.5m
Microphone
Unit
2m2m
1.5m
1m
High-tap
Medium-tap
Low-tap
DischargeSuction
FXSQ40-50P
3TW31217-2
Notes
1 Data is valid at free field condition
2Data is valid at nominal operation condition
3 dBA = A-weighted sound power level. (A-scale according to IEC)
4 Reference acoustic pressures 0dB = 20μPa
5 Location of microphine
Sound pressure level [dB]
Octave band center frequency [dB]
1.5m
Microphone
Unit
2m2m
1.5m
1m
High-tap
Medium-tap
Low-tap
DischargeSuction
FXSQ63P
3TW31237-2
Notes
1 Data is valid at free field condition
2Data is valid at nominal operation condition
3 dBA = A-weighted sound power level. (A-scale according to IEC)
4 Reference acoustic pressures 0dB = 20μPa
5 Location of microphine
Sound pressure level [dB]
Octave band center frequency [dB]
1.5m
High-tap
Medium-tap
Low-tap
mic. position
FXSQ_EN.pdf 20 29/06/2010 14:31:36
